SERVICE MANUAL
CORRECTION-2
Correct your service manual as shown below.
Correction of repair parts list
Ver 1.2 2005. 09
Page
58 2-597-672-01 FOOT(M), RUBBER
156 X-2025-588-1 CABINET (UPPER) ASSY (DARK SILVER)
(EXCEPT J)
757 A-1083-007-B BLOCKASSY, TENSION REGULATOR
58 2-549-075-01 FOOT, RUBBER
156 X-2025-588-2 CABINET (UPPER) ASSY (DARK SILVER)
(EXCEPT J)
757 A-1083-007-A BLOCKASSY, TENSION REGULATOR
Ref. No. Part No. DescriptionRef. No. Part No. Description
5. REPAIR PARTS LIST
5-1. EXPLODED VIEWS : Corrected portion
INCORRECT CORRECT
5-4
5-1-2. CABINET (R) SECTION
DCR-HC90/HC90E
DCR-HC90
US Model
Canadian Model
Korea Model
Japanese Model
DCR-HC90E
AEP Model
UK Model
Australian Model
Chinese Model
North European Model
Hong Kong Model
DCR-HC90/HC90E
E Model
Tourist Model
LEVEL 2
DCR-HC90/HC90E
RMT-831
5-1-4. CABINET (UPPER) SECTION
5-6
5-1-9. LS/MECHANICAL CHASSIS BLOCK ASSEMBLY-1
5-11

— 2 —
DCR-HC90/HC90E
Page INCORRECT CORRECT
5-13
• EXCEPT J MODEL
Checking supplied accessories.
•J MODEL
5-14
Power cord (Main lead) (1)
(UK, HK model)
0 1-783-374-12
Power cord (Main lead) (1)
(AUS model)
0 1-827-945-12
Power cord (Main lead) (1)
(UK, HK model)
0 1-783-374-11
Power cord (Main lead) (1)
(AUS model)
0 1-827-945-11
Lid Battery Case
3-083-973-01
Lid Battery Case
(not supplied)
: Corrected portion
Wireless Remote Commander
(RMT-831) (1)
1-477-898-41
Wireless Remote Commander
(RMT-831) (1)
1-477-898-41
