HDR-FX7
High Defi nition MiniDV (HDV™) Handycam® Camcorder
With the HDR-FX7 Handycam® Camcorder, capture every last detail in
high defi nition. The fi rst consumer level HDV 1080i recorder and player
in the world to include three CMOS Sensors which turns all your
memories into masterpieces. And with a 20x Optical Zoom Carl Zeiss®
Vario-Sonnar® T* Lens, your moments will never fade away.
3x 1/4” ClearVid™ CMOS Sensors
3x 1/4” ClearVid CMOS Sensors with 1,120k
(effective) pixels provide stunning detail and
clarity with exceptional video (up to 1080 lines
of HD resolution) and still image performance.
Real-Time HD Codec Engine
Utilizing a Real Time MPEG Encode/ Decode
system with reduced energy consumption, the
HDR-FX7 provides effi cient MPEG2 compression
— plus recording and playback of clear HD
images — at the same bit rate as the DV
format. This allows high defi nition videos to be
recorded onto the standard MiniDV cassettes.
20x Optical Carl Zeiss® Vario-
Sonnar® T* Lens
From the authority in lens technology, the Carl
Zeiss® Vario-Sonnar® T* lens provides a high-
quality 20x optical zoom. This high-quality lens
helps to maintain image clarity and color while
reducing glare and fl are.
Selectable Exposure/Iris Control
Allows you to adjust the amount of light
entering the lens. By adjusting Exposure,
brightness of the image is adjusted in
accordance with the Iris and gain (shutter
speed is locked). The Iris control allows the
volume of light to be adjusted (shutter speed
and gain are adjustable).
3.5” (16:9) Hybrid Clear Photo LCD
Plus™ Display (211k Pixels)3
Provides excellent viewing clarity with
improved resolution. The 211k pixel LCD display
makes images sharp and detailed during
playback or when monitoring recording. The
Hybrid LCD Screen provides accurate viewing
in sunlight or bright light, virtually eliminating
the "washout" common with traditional LCD
screens.
Super SteadyShot® Optical
Stabilization System
An advanced form of Sony’s Super
SteadyShot® Image Stabilization, this optical
stabilization system smoothes out an even
higher range of shakes and vibrations without
degradation.
Manual Zoom and Manual Focus
Ring
Dual independent Zoom and Focus rings
provide precise and detailed control over the
amount of zoom and focus. The natural "feel"
of the rings provides fast, intuitive framing
when zooming and makes fi nely detailed
focusing easier.
Picture Profi les
Allows users to set up as many as six different
picture profi les to be used under various
shooting conditions. These presets can then
be called up at the touch of a button.
Additional Features
• Assignable Buttons
• i.LINK® HDV/DV Interface4 (IEEE1394)
• Shot Transition
• Dual Record
• Smooth Slow Record
• Digital Still Memory Mode with Memory Stick
PRO Duo™ Media (sold separately)
• Battery Information
• Multi-Language Menu
Sony Electronics Inc. | 16530 Via Esprillo | San Diego, CA 92127 | 1.800.222.7669 | www.sony.com

HDR-FX7
High Defi nition Prosumer Handycam® Camcorder
Specifi cations
IMAGER
Imaging Device 3x 1/4" ClearVid™ CMOS Sensors
Processor N/A
Imager Pixel Gross Size 1120k
VIDEO
Video Actual 16:9 1037k pixels
Video Actual 4:3 778k pixels
Video Resolution Full HD 1440 x 1080
STILL PICTURE
Still Actual 16:9 1037k pixels
Still Actual 4:3 778k pixels
Still Picture Resolution 1 megapixel
AUDIO
Audio Recording Format MPEG-1 Audio Layer 2 - Stereo (HDV); PCM (DV)
Microphone Yes (Built-in)
MEDIA TYPE
MiniDV Cassette MiniDV / HDV
Memory Stick Duo™ Media Memory Stick PRO Duo™ Media (Sold Separately)
RECORDING CAPACITY
Rec. / Playback MiniDV / HDV™60min/80min., LP (DV only): 90min/121min.
OPTICS AND LENS
Lens Type Carl Zeiss® Vario-Sonnar® T* Lens
35mm Equivalent 16:9 37.4 - 748mm
35mm Equivalent 4:3 45.7 - 914mm
Aperture 1.6 - 2.8
Exposure Control 24 Steps (Menu)
Filter Diameter (mm)62mm
Focal Distance (mm)3.9 – 78mm
Focus System Full Range Auto/Manual (Ring)/One Touch
Progressive Shutter Mode N/A
Shutter Speed Auto: 1/60-1/2000; Manual: 1/4-1/10000;
Smooth Slow Record: 1/250 - 1/2000
Optical Zoom 20x
Digital Zoom N/A
DISPLAY
Display 3.5" (211k pixels) wide (16:9) touch panel3 Clear Photo
LCD Plus™
View Finder Wide (16:9), Color (252k Pixels)
HARDWARE
Flash N/A
Memory Stick PRO Duo™
Media Slot Yes
Manual / Auto Lens Cover Manual
Assignable Dial N/A
S/S & Zoom Button on LCD N/A
INPUTS & OUTPUTS
Audio/Video Remote Terminal N/A
Analog Audio/Video Output(s)Yes (Multi A/V)
LANC Terminal Yes (Stereo Mini)
Digital Audio/Video Output(s)Yes (i.LINK®4 and USB)
USB Port(s)Yes, ver. 1.1
i.LINK® Interface Yes
Component Video (Y/Pb/Pr)
Output(s)Yes
S-Video Output(s)Yes (via optional accessory) N/A
HDMI™ Connection Output(s)N/A
Headphone Jack Yes (Stereo Mini)
Microphone Input Yes (Stereo Mini)
Active Interface Shoe Yes (Cold)
CONVENIENCE
Dual Record Yes
Memory Stick PRO Duo™
Media Compatibility
Tested to support up to 2GB21 media capacity; does not
support high speed transfer function; does not support
Access Control security function
White Balance Auto, Indoor, One-push, Outdoor
CONVENIENCE FEATURES
Movie Mode(s)MPEG-2
Multiple Language Display Yes
PictBridge Compatible Yes
Remote Control Yes
POWER
Power Consumption HDV: 5.9W/5.9W (VF/LCD); DV: 5.7W/5.7W (VF/LCD)
Supplied Battery Type InfoLITHIUM® with AccuPower™ Meter System (NP-F570)
Power Requirements 7.2V (Battery Pack); 8.4V (AC Adaptor)
DIMENSIONS
Dimensions (Approx.)5 3/4 x 6 1/4 x 12 3/4 inch (145 x 156 x 322mm) with
lens hood attached
Weight (Approx.)3lbs 10oz (1.6kg) with supplied battery and lens hood
SUPPLIED ACCESSORIES
AC adaptor AC-L15
Rechargeable Battery Pack InfoLITHIUM® with AccuPower™ Meter System (NP-F570)
Remote Commander® control unit RMT-835
Component Video Cable Yes
Composite Video Cable Yes
USB Cable Yes
FOOTNOTES
3. Viewable area measured diagonally.
4. i.LINK is a trademark of Sony, used only to designate that a product contains an IEEE1394 connector. All
products with an IEEE1394 connector may not communicate with each other.
9. Requires Microsoft Windows XP SP3/ Windows Vista SP1. Not supported by Mac OS.
10. Smooth Slow Record captures 3 seconds of video which plays back over 12 seconds.
