Sony Handycam NEX-VG900 User manual

24.3MP 35mm Full Frame Sensor1
A whole new world of high-quality images are realized through the 24.3 MP eective 35 mm
full-frame sensor, a normal sensor range of ISO 100 – 32000, and a sophisticated balance of high
resolving power, gradation and low noise
Uncompressed HDMI Output
Easily record Full 1080 HD uncompressed clean-screen video les to external recording devices
via an HDMI connection in 24p, 60p and 60i frame-rates.
Full Frame Sensor Advantage
The NEX-VG900 includes the LA-EA3 adaptor to mount any A-mount lens with the full-frame sensor
advantage. Capture the full angle of view as well as allowing manual focus to be used for
cinematic follow focus eects.
When using E-mount or A-mount DT lenses, the NEX-VG900 automatically switches to APS-C
mode.
XGA OLED Tru-Finder w/ eye sensor
There’s never been anything quite like the Tru-Finder™ OLED electronic viewnder. For size, speed
and brightness even aer sunset, this is a gem. It begins with 2359K dots for amazing resolution
and high contrast ratio for incredible depth. OLED reduces motion blur to a bare minimum. You
can also see the results of camera adjustments in real time with superb color and detail.
Quad Capsule Spatial Array Stereo Microphone
High quality video requires high quality audio. The Quad Capsule Spatial Array stereo
microphone contains four precision placed microphone capsules that are perfectly angled at 45
degrees to provide exceptional front-side directivity and stereo separation.
Comprehensive Manual Control
Take full control over Iris, Gain and Shutter via easily accessible buttons on the side of your
camera. With full manual control you will be able to adapt to almost any lighting condition to
get the best shot.
Specications
Camera
Camera Type Full Frame Interchangeable Lens Camercorder
Lens Mount E-mount
Imaging Sensor
Imaging Sensor 35mm Full-Frame Exmor HD CMOS sensor(35.8 x 23.9mm)
Processor BIONZ™ Image processor
Anti Dust Charge protection coating on Filter
Pixel Gross Approx. 24.7 megapixels
Recording
Still Image Mode JPEG/JPEG+RAW/RAW
Still Image Size 3:2 L (24.0M): 6000 x 4000 M (10.3M): 3936 x 2624 S (4.6M): 2640 x 1760
NEX-VG900 Prosumer Interchangeable lens HD Camcorder w/ Full Size
Sensor

Video Mode HD PS:Approx.28Mbps/FX:Approx.24Mbps/FH:Approx.17Mbps/HQ:Approx.9Mbps/
LP:Approx.5Mbps; STD HQ:9Mbps
Audio Format Dolby® Digital 5.1ch, Dolby® Digital 5.1Creator; Dolby® Digital 2ch stereo
Microphone/Speaker Built-in Microphone/Monoral Speaker
Mic Level Control Yes(31steps)
Focus Control
Focus System Contrast AF
Exposure System
Picture Eect(s) Movie and Still:Posterization,Pop color,Retro Photo, Partial Color, High
constrastMonochrome, Toy Camera; Still Only:So Focus,Miniature
Noise Reduction Yes
Gain Control Auto/manual(0dB-30dB)
WB Shi Yes(G7-M7 15steps, A7-B7 15steps)
Drive System
Shutter Type Electronically-controlled, vertical-traverse, focal-plane type
Shutter Speeds Auto Control Range: 1/48-1/10000 (movie_24p) ,1/60-1/10000(movie_other)/ 30s-
1/8000 (Still); Manual: 1/4-1/10000 (movie) , 30s-1/8000 (Still)
Flash
Flash Type Multi interface Shoe
Flash Metering System Pre-ash TTL
Flash Modes Auto/Forced/Slow Sync./Rear Sync./Prohibited
Convenience Features
Quick On Yes
Self Timer Approx.10sec.(Still Image)
Red-Eye Reduction Yes(On/O)
Date / Time Stamp Yes(Rec Date and Time, Camera info)
View & Index Event
Advanced Features
Assignable Dial Yes(Exposure/Gain(ISO)/Iris/Shutter Speed/AE Shi/WB Temp./WB B-A/WB G-M Set)
Tracking Focus Yes
Audio Level Display Yes
CinemaTone Gamma/Color Yes
x.v.Color™ Yes
Interface
SD Output
Composite Video Out(A/V connecting cable(supplied))
Component Video Out(Component A/V cable(supplied))
S Video Out(A/V connecting cable with S Video(sold separately))
USB Port(s) mini-AB/USB2.0 Hi-speed (mass-storage/MTP)
A/V Remote Terminal Video/S Video/Audio/Component Out/Remote
Power
Power Consumption (in Operation) HD:4.7W; STD:4.5W
Software
Supplied Soware Vegas® Movie Studio HD Platinum 11 included via download to PC4
Service and Warranty Information
Limited Warranty Term 1 Year Parts & 90 days labor
Weights and Measurements
Dimensions (Approx.) Approx. 4 1/4in x 5 1/8in x 8 7/8in (WxHxD with including supplied NP-FV70 battery)
Weight (Approx.) Approx. 1 lb 13 oz (825g) (with supplied NP-FV70 battery)

Accessories
Supplied Accessories
Rechargeable Battery Pack(NP-FV70) (1)
AC Adaptor (1)
Power Cord (1)
Component A/V Cable (1)
A/V Connecting Cable (1)
USB Cable (1)
Body cap (1)
Mount Adaptor(LA-EA3) (1)
Wind screen (1)
Large eye cup (1)
CD-ROM("Handycam" Application Soware) (1)
Remote Commander(RMT-835 with Battery(CR2025)) (1)
Operating Guide(1)
1. As of September 11, 2012
© 2012 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written permission is prohibited. Sony, Handycam, Optical SteadyShot, Exmor, Tru-Finder, Xtra Fine LCD, Memory Stick PRO Duo, Memory Stick PRO-HG Duo and Memory Stick Duo are trade-
marks of Sony. Vegas is a trademark of Sony Creative Media. AVCHD is a trademark of Panasonic Corporation and Sony Corporation. HDMI is a trademark of HDMI Licensing LLC. Blu-ray Disc and its logo are trademarks. All other trademarks are trademarks of their respective
owners. Features and specications are subject to change without notice.
UPC:027242860001 / Updated: September 13, 2012
