SERVICE MANUAL
HDR-CX190/CX190E/CX200/CX200E/CX210/CX210E/PJ200/PJ200E/PJ210_L3
Check the SERVICE NOTE (LEVEL 2) before the service.
Revision History
Published by Sony Techno Create Corporation
Sony Corporation
LEVEL 3
983463711.pdf
Ver. 1.0 2011.12
Digital HD Video Camera Recorder
The components identified by mark
0or dotted line with mark 0are
critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0sont critiques pour la
sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
9-834-637-11
US Model
Canadian Model
AEP Model
UK Model
North European Model
E Model
Australian Model
Hong Kong Model
Chinese Model
Korea Model
Brazilian Model
Tourist Model
Japanese Model
Ver. Date History Contents S.M. Rev.
issued
1.0 2011.12 Official Release — —
2011L08-1
© 2011.12
HDR-CX190/CX190E/CX200/CX200E/CX210/CX210E/
PJ200/PJ200E/PJ210
MODEL GROUP
Projector Model: HDR-PJ200/PJ200E/PJ210
Non Projector Model: HDR-CX190/CX190E/CX200/CX200E/CX210/CX210E
IM Model (Internal Memory Model): HDR-CX210/CX210E/PJ210
Non IM Model (Non Internal Memory Model): HDR-CX190/CX190E/CX200/CX200E/PJ200/PJ200E
Photo: HDR-PJ210/Silver

– 2 –
HDR-CX190/CX190E/CX200/CX200E/CX210/CX210E/PJ200/PJ200E/PJ210_L3
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE WITH
MARK 0ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST
ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPO-
NENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY
SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REM-
PLACER CES COMPOSANTS QUE PAR DES PIÈCES SONY DONT
LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES
SUPPLÉMENTS PUBLIÉS PAR SONY.
Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
注意
電池の交換は，正しく行わないと破裂する恐れがあります。
電池を交換する場合には必ず同じ型名の電池又は同等品と
交換してください。
使用済み電池は，取扱指示に従って処分してください。
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer.
1. Check the area of your repair for unsoldered or poorly-soldered
connections. Check the entire board surface for solder splashes and
bridges.
2. Check the interboard wiring to ensure that no wires are “pinched”
or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly transistors,
that were installed during a previous repair. Point them out to the
customer and recommend their replacement.
4. Look for parts which, through functioning, show obvious signs of
deterioration. Point them out to the customer and recommend their
replacement.
5. Check the B+ voltage to see it is at the values specified.
6. Flexible Circuit Board Repairing
• Set the soldering iron tip temperature to 350 °C approximately.
• Do not touch the soldering iron on the same conductor of the circuit
board (within 3 times).
• Be careful not to apply force on the conductor when soldering or
unsoldering.
1. 注意事項をお守りください。
 サービスのとき特に注意を要する個所については，キャビ
ネット，シャーシ，部品などにラベルや捺印で注意事項を
表示しています。これらの注意書き及び取扱説明書等の注
意事項を必ずお守り下さい。
2. 指定部品のご使用を
 セットの部品は難燃性や耐電圧など安全上の特性を持った
ものとなっています。従って交換部品は，使用されていた
ものと同じ特性の部品を使用して下さい。特に回路図，部
品表に0印で指定されている安全上重要な部品は必ず指定
のものをご使用下さい。
3. 部品の取付けや配線の引きまわしはもとどおりに
 安全上，チューブやテープなどの絶縁材料を使用したり，
プリント基板から浮かして取付けた部品があります。また
内部配線は引きまわしやクランパによって発熱部品や高圧
部品に接近しないよう配慮されていますので，これらは必
ずもとどおりにして下さい。
4. サービス後は安全点検を
 サービスのために取外したネジ，部品，配線がもとどおり
になっているか，またサービスした個所の周辺を劣化させ
てしまったところがないかなどを点検し，安全性が確保さ
れていることを確認して下さい。
5. チップ部品交換時の注意
 ・ 取外した部品は再使用しないで下さい。
 ・ タンタルコンデンサのマイナス側は熱に弱いため交換時
は注意して下さい。
6. フレキシブルプリント基板の取扱いについて
 ・ 半田こてのこて先温度は約350℃に設定してください。
 ・ 同一パターンに何度もコテ先を当てないで下さい。（3回
以内）
 ・ パターンに力が加わらないよう注意して下さい。
サービス，点検時には次のことにご注意ください。
– ENGLISH – – JAPANESE –
UNLEADED SOLDER
This unit uses unleaded solder.
Boards requiring use of unleaded solder are printed with the lead free
mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with the
lead free mark due to their particular size.)
: LEAD FREE MARK
Be careful to the following points to solder or unsolder.
• Set the soldering iron tip temperature to 350°C approximately.
If cannot control temperature, solder/unsolder at high temperature
for a short time.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
Unleaded solder is more viscous (sticky, less prone to
flow) than ordinary solder so use caution not to let solder
bridges occur such as on IC pins, etc.
• Be sure to control soldering iron tips used for unleaded solder and
those for leaded solder so they are managed separately. Mixing un-
leaded solder and leaded solder will cause detachment phenomenon.
無鉛半田について
本機には無鉛半田が使用されています。
無鉛半田を使用している基板には，無鉛（LeadFree）を意味する
レッドフリーマークがプリントされています。
（注意：基板サイズによっては，無鉛半田を使用していてもレッ
ドフリーマークがプリントされていないものがありま
す）
：レッドフリーマーク
無鉛半田は，下記の点に注意して使用してください。
・ 半田こてのこて先温度は約350℃に設定してください。
 温度調節が無理な場合は，高温短時間で作業を行ってくだ
さい。
 注意：半田こてを長く当てすぎると，基板のパターン（銅
箔）がはがれてしまうことがありますので，注意して
ください。また，従来の半田よりも粘性が強いため，
IC端子などが半田ブリッジしないように注意してく
ださい。
・ 半田こてのこて先は，必ず無鉛半田用と有鉛半田用に分け
て管理してください。
 無鉛半田と有鉛半田が混在すると剥離現象が発生してしま
います。

HDR-CX190/CX190E/CX200/CX200E/CX210/CX210E/PJ200/PJ200E/PJ210_L3
2-1
Ref. No. Part No. DescriptionRef. No. Part No. Description
(ENGLISH)
NOTE:
• -XX, -X mean standardized parts, so they may have some differ-
ences from the original one.
• Items marked “*” are not stocked since they are seldom required for
routine service. Some delay should be anticipated when ordering
these items.
• The mechanical parts with no reference number in the exploded
views are not supplied.
• Due to standardization, replacements in the parts list may be dif-
ferent from the parts specified in the diagrams or the components
used on the set.
• CAPACITORS:
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA...: μA... , uPA... , μPA... ,
uPB... , μPB... , uPC... , μPC... ,
uPD..., μPD...
(JAPANESE)
【使用上の注意】
• ここに記載されている部品は,補修用部品であるため,回路図及び
セットに付いている部品と異なる場合があります。
• -XX,-Xは標準化部品のため, セットに付いている部品と異なる場
合があります。
• *印の部品は常備在庫しておりません。
• コンデンサの単位でuFはμFを示します。
• 抵抗の単位Ωは省略してあります。
 金 被：金属被膜抵抗。
 サンキン：酸化金属被膜抵抗。
• インダクタの単位でuHはμHを示します。
• 半導体の名称でuA...,uPA...,uPB...,uPC...,uPD...等はそれぞれμA...,
μPA...,μPB...,μPC...,μPD...を示します。
The components identified by mark 0
or dotted line with mark 0are critical
for safety.
Replace only with part number specified.
Les composants identifiés par une mar-
que 0sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
0印の部品，または0印付の点線で囲まれた部品は，
安全性を維持するために，重要な部品です。
従って交換時は，必ず指定の部品を使用してください。
When indicating parts by reference num-
ber, please include the board name.
図面番号で部品を指定するときは基板名又はブロック
を併せて指定してください。
お願い
A-1851-282-A CM-127 BOARD, COMPLETE
**********************
(IC6802 and CP003 (CMOS IMAGER) are not supplied, but they are included in CM-127
COMPLETE BOARD.)
< CAPACITOR >
C6803 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6805 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6807 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6808 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C6809 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6810 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C6812 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6814 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C6819 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6823 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C6824 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6825 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C6827 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C6828 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C6830 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6832 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C6833 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6835 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6836 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6839 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6840 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6841 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6842 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C7505 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C7506 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C7507 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C7508 1-114-411-21 CERAMIC CHIP 0.33uF 10% 6.3V
C7509 1-114-411-21 CERAMIC CHIP 0.33uF 10% 6.3V
C7512 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C7513 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C7514 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C7515 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
< CONNECTOR >
CN6805 1-822-378-11 CONNECTOR, FPC (ZIF) 33P
< COMPOSITION CIRCUIT BLOCK >
CP003 (Not supplied) IMX126CQL-13
(CP003 (CMOS IMAGER) is supplied included in CM-127 complete board.)
< IC >
IC6802 (Not supplied) IC MM3404A27URE
< COIL >
*L7501 1-481-425-21 INDUCTOR 10uH
< RESISTOR >
R6819 1-218-973-11 METAL CHIP 47K 5% 1/16W
R6832 1-218-953-11 METAL CHIP 1K 5% 1/16W
*R7508 1-250-559-11 METAL CHIP 470K 1% 1/16W
*R7509 1-250-559-11 METAL CHIP 470K 1% 1/16W
*R7510 1-250-511-11 METAL CHIP 4.7K 1% 1/16W
*R7511 1-250-511-11 METAL CHIP 4.7K 1% 1/16W
R7512 1-250-519-11 METAL CHIP 10K 1% 1/16W
R7513 1-250-519-11 METAL CHIP 10K 1% 1/16W
*R7514 1-250-559-11 METAL CHIP 470K 1% 1/16W
*R7515 1-250-559-11 METAL CHIP 470K 1% 1/16W
< SENSOR >
SE7501 1-487-653-11 SENSOR, ANGULAR VELOCITY (PITCH/YAW)
A-1810-716-A FP-1319 FLEXIBLE BOARD, COMPLETE
(Projector Model)
*******************************
(CN5505 is not supplied, but this is included in FP-1319 FLEXIBLE COMPLETE BOARD.)
< CAPACITOR >
C001 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN5503 1-842-687-11 CONNECTOR, BOARD TO BOARD 42P
CN5505 (Not supplied) CONNECTOR, BOARD TO BOARD
1-884-871-21 FP-1481 FLEXIBLE BOARD (Non Projector Model)
*********************
1-884-872-21 FP-1482 FLEXIBLE BOARD (Projector Model)
*********************
1-884-873-21 FP-1483 FLEXIBLE BOARD
*********************
1-885-587-11 FP-1556 FLEXIBLE BOARD
*********************
1-885-623-11 FP-1557 FLEXIBLE BOARD (IM Model)
*********************
A-1852-422-A MM-102 BOARD, COMPLETE (IM Model)
***********************
< CAPACITOR >
C8102 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C8103 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8104 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8701 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
< CONNECTOR >
*CN8101 1-816-647-61 FFC/FPC CONNECTOR (LIF) 18P
< IC >
IC8101 6-718-132-01 IC KLM8G2FEJA-A001T20
2-2. ELECTRICAL PARTS LIST
Note 1: イメージャの交換時は6-1ページの“イメージャ交換時の
注意”を必ずお読みください。
Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
注意
電池の交換は，正しく行わないと破裂する恐れがあります。
電池を交換する場合には必ず同じ型名の電池又は同等品と交換し
てください。
使用済み電池は，取扱指示に従って処分してください。
Note 2: Replace the battery holder (BH8001) together when replac-
ing the lithium storage battery (BT8001) on the MS-475
board. (The battery holder removed once cannot be used
again.)
When mounting these parts, mount new battery holder first
and attach new lithium battery next.
Note 2: MS-475基板のリチウム蓄電池（BT8001）を交換する場合は
バッテリホルダ（BH8001）も同時に新品に交換して下さい。
（一度使用したバッテリホルダは再使用できません。）
部品 取り付けの際は，先にバッテリホ ルダを取り付けて
からリチウム電池を装着して下さい。
Note 1: Be sure to read “Precautions for Replacement of Imager”
on page 6-1 when changing the imager.
CM-127 FP-1319 FP-1481 FP-1482 FP-1483 FP-1556 FP-1557 MM-102
2. REPAIR PARTS LIST

HDR-CX190/CX190E/CX200/CX200E/CX210/CX210E/PJ200/PJ200E/PJ210_L3
2-2
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. DescriptionRef. No. Part No. Description
IC8701 6-716-442-11 IC MM3404A29URE
< RESISTOR >
R8101 1-218-965-11 METAL CHIP 10K 5% 1/16W
R8103 1-218-990-81 SHORT CHIP 0
R8104 1-218-990-81 SHORT CHIP 0
R8105 1-218-990-81 SHORT CHIP 0
R8106 1-218-990-81 SHORT CHIP 0
R8107 1-218-990-81 SHORT CHIP 0
R8108 1-218-990-81 SHORT CHIP 0
R8109 1-218-990-81 SHORT CHIP 0
R8110 1-218-990-81 SHORT CHIP 0
R8112 1-218-990-81 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RB8101 1-234-371-11 RES, NETWORK 47 (1005X4)
RB8102 1-234-371-11 RES, NETWORK 47 (1005X4)
A-1851-283-A MS-475 BOARD, COMPLETE
**********************
(BT8001 is not supplied, but this is included in MS-475 COMPLETE BOARD.)
< BATTERY HOLDER >
BH8001 1-251-928-21 SOCKET, BATTERY
< BATTERY >
BT8001 1-756-135-15 BATTERY LITHIUM SECONDARY
< CAPACITOR >
C8003 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8004 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN8001 1-822-837-21 CARD CONNECTOR
*CN8002 1-818-818-81 CONNECTOR, FPC (ZIF) 29P
< RESISTOR >
R8003 1-218-973-11 METAL CHIP 47K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB8002 1-234-702-11 RES, NETWORK 68 (1005X4)
RB8003 1-234-702-11 RES, NETWORK 68 (1005X4)
A-1851-284-A PD-454 BOARD, COMPLETE (CX190/CX190E)
A-1851-285-A PD-454 BOARD, COMPLETE
(CX200/CX200E/CX210/CX210E)
**********************
< CAPACITOR >
C6503 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6505 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6508 1-127-861-11 CERAMIC CHIP 2.2uF 10% 16V
C6509 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C6512 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C6514 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C6515 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6520 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C6521 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6522 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C6523 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C6524 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C6525 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C6526 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V
(CX200/CX200E/CX210/CX210E)
C6527 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V
(CX200/CX200E/CX210/CX210E)
< CONNECTOR >
*CN6502 1-821-503-11 CONNECTOR, FPC (ZIF) 39P
CN6503 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
(CX200/CX200E/CX210/CX210E)
CN6504 1-822-378-11 CONNECTOR, FPC (ZIF) 33P
< COIL >
*L6501 1-481-102-21 INDUCTOR 10uH
< TRANSISTOR >
Q6501 6-552-538-01 TRANSISTOR DMG9640N0R
(CX200/CX200E/CX210/CX210E)
Q6502 6-552-538-01 TRANSISTOR DMG9640N0R
(CX200/CX200E/CX210/CX210E)
< RESISTOR >
R6513 1-218-964-11 METAL CHIP 8.2K 5% 1/16W
(CX190/CX190E)
R6514 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
(CX190/CX190E)
R6515 1-218-960-11 METAL CHIP 3.9K 5% 1/16W
(CX190/CX190E)
R6518 1-218-977-11 METAL CHIP 100K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB6503 1-234-388-21 RES, NETWORK 1.5K (1005X4)
(CX190/CX190E)
RB6504 1-234-375-21 RES, NETWORK 1K (1005X4)
< SWITCH >
*S6501 1-798-346-11 SWITCH, TACTILE (CX190/CX190E)
*S6502 1-786-914-51 SWITCH, TACTILE (CX190/CX190E)
< IC >
SE6501 6-600-814-01 IC MRMS511H
A-1851-286-A PD-457 BOARD, COMPLETE (Projector Model)
**********************
< CAPACITOR >
C6001 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6002 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V
C6003 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V
C6038 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6039 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6041 1-127-861-11 CERAMIC CHIP 2.2uF 10% 16V
C6042 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C6044 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C6045 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C6046 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6047 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C6048 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6049 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C6050 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C6051 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C6052 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C6102 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN6001 1-821-501-11 CONNECTOR, FPC (ZIF) 51P
CN6002 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
*CN6003 1-821-503-11 CONNECTOR, FPC (ZIF) 39P
CN6007 1-821-652-11 CONNECTOR, BOARD TO BOARD (REC
< IC >
*IC6101 6-712-051-01 IC SN65LVDS302ZQER
< COIL >
*L6001 1-481-102-21 INDUCTOR 10uH
*L6002 1-481-102-21 INDUCTOR 10uH
< TRANSISTOR >
Q6001 6-552-538-01 TRANSISTOR DMG9640N0R
Q6002 6-552-538-01 TRANSISTOR DMG9640N0R
< RESISTOR >
R6033 1-218-977-11 METAL CHIP 100K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB6003 1-234-375-21 RES, NETWORK 1K (1005X4)
< SENSOR >
SE6001 1-489-369-11 MR SENSOR (RM)
A-1853-345-A PJ-104 BOARD, COMPLETE (Projector Model)
*********************
(IC8605 is not supplied, but this is included in PJ-104 COMPLETE BOARD.)
< CAPACITOR >
C8501 1-164-934-11 CERAMIC CHIP 330PF 10% 50V
C8503 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C8504 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8505 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C8507 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8508 1-164-934-11 CERAMIC CHIP 330PF 10% 50V
C8509 1-164-934-11 CERAMIC CHIP 330PF 10% 50V
C8510 1-116-403-91 CERAMIC CHIP 10uF 10% 6.3V
C8512 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C8513 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C8514 1-164-934-11 CERAMIC CHIP 330PF 10% 50V
C8516 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C8517 1-164-934-11 CERAMIC CHIP 330PF 10% 50V
C8518 1-114-419-21 CERAMIC CHIP 10uF 10% 16V
C8519 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8520 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8521 1-116-403-91 CERAMIC CHIP 10uF 10% 6.3V
C8522 1-164-934-11 CERAMIC CHIP 330PF 10% 50V
C8523 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C8524 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C8525 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C8526 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C8527 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C8528 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C8530 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C8531 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C8533 1-116-403-91 CERAMIC CHIP 10uF 10% 6.3V
C8534 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8535 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C8536 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C8538 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8601 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8602 1-164-856-81 CERAMIC CHIP 18PF 5% 50V
C8603 1-164-856-81 CERAMIC CHIP 18PF 5% 50V
C8604 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8605 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8606 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C8607 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8608 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8609 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8610 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8611 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8612 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8617 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8618 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C8619 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8620 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8621 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8622 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8623 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8624 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8625 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8626 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8627 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C8628 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8629 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8701 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8702 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8703 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8706 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8708 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8710 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C8801 1-116-403-91 CERAMIC CHIP 10uF 10% 6.3V
C8802 1-164-934-11 CERAMIC CHIP 330PF 10% 50V
C8803 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
< CONNECTOR >
CN8501 1-842-687-11 CONNECTOR, BOARD TO BOARD 42P
CN8502 1-816-643-51 FFC/FPC CONNECTOR (LIF) 10P
CN8503 1-822-395-51 CONNECTOR, BOARD TO BOARD 60P
MM-102 MS-475 PD-454 PD-457 PJ-104

HDR-CX190/CX190E/CX200/CX200E/CX210/CX210E/PJ200/PJ200E/PJ210_L3
2-3
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. DescriptionRef. No. Part No. Description
< DIODE >
*D8501 6-502-629-01 DIODE 1SS420 (TL3SONY.F)
*D8502 6-502-629-01 DIODE 1SS420 (TL3SONY.F)
D8503 6-503-106-01 DIODE DZ2S100M0L
< FERRITE BEAD >
FB8501 1-400-915-21 INDUCTOR (EMI FERRITE) (2012)
FB8508 1-400-915-21 INDUCTOR (EMI FERRITE) (2012)
FB8601 1-400-915-21 INDUCTOR (EMI FERRITE) (2012)
FB8602 1-400-915-21 INDUCTOR (EMI FERRITE) (2012)
FB8801 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
< IC >
IC8501 6-716-995-01 IC TC7SZ07AFS
IC8502 6-716-996-01 IC RT8522GQW
IC8503 6-716-997-01 IC RT8035GQW
IC8601 6-712-602-01 IC 74LVC139BQ-118
IC8602 6-717-009-01 IC TC7WG04FC
IC8603 6-718-207-01 IC W25X40BVPY09
IC8605 (Not supplied) IC DPP2601
IC8701 6-717-010-01 IC K4X56163PN-FGC6T
IC8801 6-717-011-01 IC LM3549SQX/NOPB
< COIL >
L8501 1-457-526-11 INDUCTOR 2.2uH
L8503 1-457-526-11 INDUCTOR 2.2uH
L8504 1-481-035-11 INDUCTOR 10uH
L8801 1-457-526-11 INDUCTOR 2.2uH
< RESISTOR >
R8501 1-220-210-11 METAL CHIP 200K 5% 1/16W
R8502 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8503 1-220-210-11 METAL CHIP 200K 5% 1/16W
R8505 1-220-205-11 METAL CHIP 75K 5% 1/16W
R8506 1-220-196-81 METAL CHIP 13K 5% 1/16W
R8507 1-218-965-11 METAL CHIP 10K 5% 1/16W
R8508 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8509 1-218-953-11 METAL CHIP 1K 5% 1/16W
R8510 1-208-953-11 METAL CHIP 560K 0.5% 1/16W
R8511 1-218-979-11 METAL CHIP 150K 5% 1/16W
R8512 1-218-981-91 METAL CHIP 220K 5% 1/16W
R8513 1-208-713-11 METAL CHIP 18K 0.5% 1/16W
R8516 1-218-990-81 SHORT CHIP 0
R8518 1-218-949-11 METAL CHIP 470 5% 1/16W
R8601 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8602 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8605 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8608 1-218-935-11 METAL CHIP 33 5% 1/16W
R8610 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8611 1-218-941-81 METAL CHIP 100 5% 1/16W
R8612 1-218-989-11 METAL CHIP 1M 5% 1/16W
R8613 1-218-935-11 METAL CHIP 33 5% 1/16W
R8614 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8616 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8617 1-218-935-11 METAL CHIP 33 5% 1/16W
R8618 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8619 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8620 1-218-935-11 METAL CHIP 33 5% 1/16W
R8621 1-218-935-11 METAL CHIP 33 5% 1/16W
R8623 1-218-935-11 METAL CHIP 33 5% 1/16W
R8624 1-218-935-11 METAL CHIP 33 5% 1/16W
R8625 1-218-935-11 METAL CHIP 33 5% 1/16W
R8626 1-218-935-11 METAL CHIP 33 5% 1/16W
R8627 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8628 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8702 1-208-922-11 METAL CHIP 30K 0.5% 1/16W
R8703 1-218-935-11 METAL CHIP 33 5% 1/16W
R8801 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8803 1-220-210-11 METAL CHIP 200K 5% 1/16W
< VIBRATOR >
X8601 1-814-480-11 QUARTZ CRYSTAL OSCILLATOR (16.66667MHz)
A-1852-423-A VC-651 BOARD, COMPLETE (SERVICE)
(CX190/CX190E)
A-1852-424-A VC-651 BOARD, COMPLETE (SERVICE)
(CX200/CX200E/CX210/CX210E)
A-1852-425-A VC-651 BOARD, COMPLETE (SERVICE)
(Projector Model)
******************************
(IC1301 is not supplied, but this is included in VC-651 COMPLETE BOARD (SERVICE).)
< CAPACITOR >
C1001 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1006 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1007 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1010 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C1011 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C1012 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
(Projector Model)
C1013 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
(Projector Model)
C1301 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1302 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1303 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1304 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1306 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1307 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1308 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1309 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1310 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1313 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1314 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1315 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1316 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1317 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1318 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1320 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1321 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1322 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1323 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1324 1-164-933-11 CERAMIC CHIP 220PF 10% 50V
C1325 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1326 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1339 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1340 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1407 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1409 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1410 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1411 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1412 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1413 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1414 1-127-772-81 CERAMIC CHIP 0.033uF 10% 10V
C1415 1-127-772-81 CERAMIC CHIP 0.033uF 10% 10V
C1416 1-127-772-81 CERAMIC CHIP 0.033uF 10% 10V
C1417 1-127-772-81 CERAMIC CHIP 0.033uF 10% 10V
C1421 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1422 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1424 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1428 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1431 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1433 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1434 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1435 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1437 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1439 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1441 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1446 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1447 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1450 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1501 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C1503 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C1504 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1505 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1506 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C1507 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1508 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C1509 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C1510 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1512 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1513 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1514 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1515 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1516 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1518 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1519 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1520 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1521 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1522 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C1523 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1524 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C1526 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1527 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1528 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C1529 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1530 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2301 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2302 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2303 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C2304 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C2305 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2307 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2308 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2309 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2310 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2311 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C2312 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C2313 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2314 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2315 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C2316 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C2317 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C2318 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C2319 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C2320 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2321 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C2322 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C2323 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C2324 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C2325 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C3301 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
(Projector Model)
C4101 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C4102 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C4103 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C4301 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C4302 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C4303 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C4304 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C4305 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C4306 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C4308 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C4309 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4310 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4311 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4312 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4313 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4314 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4315 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4316 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4317 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4318 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C4319 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C4320 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C4321 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4322 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4323 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C4324 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C4325 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4326 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C4327 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C4328 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C4329 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C4330 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C4331 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4332 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C4333 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C4334 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C4337 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C4338 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C4349 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4350 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C4353 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4354 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
PJ-104 VC-651

HDR-CX190/CX190E/CX200/CX200E/CX210/CX210E/PJ200/PJ200E/PJ210_L3
2-4
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. DescriptionRef. No. Part No. Description
C4801 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C4802 1-164-852-11 CERAMIC CHIP 12PF 5% 50V
C4803 1-164-852-11 CERAMIC CHIP 12PF 5% 50V
C4804 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C4805 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4806 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4807 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4808 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4809 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C4810 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4811 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C4812 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C5310 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C5311 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C5312 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C5313 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C5314 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C5316 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C5317 1-100-902-91 TANTAL. CHIP 10uF 20% 10V
C5318 1-100-902-91 TANTAL. CHIP 10uF 20% 10V
C5319 1-127-772-81 CERAMIC CHIP 0.033uF 10% 10V
C5320 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C5321 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C5323 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C5325 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C5326 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C5327 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C5328 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C5330 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C5331 1-127-772-81 CERAMIC CHIP 0.033uF 10% 10V
C5332 1-100-902-91 TANTAL. CHIP 10uF 20% 10V
C9101 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C9102 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C9103 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C9104 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C9105 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C9107 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C9109 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C9111 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C9112 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C9113 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C9115 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C9116 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C9118 1-100-670-91 CERAMIC CHIP 4.7uF 20% 16V
C9119 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
CN1001 1-842-602-11 CONNECTOR, HDMI
CN1002 1-822-378-11 CONNECTOR, FPC (ZIF) 33P
CN1004 1-815-794-13 CONNECTOR (MULTIPLE)
CN1005 1-816-650-51 FFC/CONNECTOR, FPC (LIF) 24P
*CN1006 1-820-857-81 CONNECTOR, FPC (ZIF) 51P (Projector Model)
*CN1007 1-819-572-62 CONNECTOR, FFC/FPC (LIF) 30P
(Non Projector Model)
CN1008 1-779-333-51 CONNECTOR, FFC/FPC 18P
(EXCEPT CX190/CX190E)
*CN1009 1-779-331-51 CONNECTOR, FFC/FPC 14P
CN1010 1-794-057-21 PIN, CONNECTOR (PC BOARD) 2P
CN1011 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
CN1012 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
CN1013 1-691-550-11 PIN, CONNECTOR (1.5MM) (SMD) 3P
*CN1014 1-822-893-11 CONNECTOR, FPC (ZIF) 33P
CN9101 1-843-120-11 HEADER ASSEMBRY
CN9102 1-822-425-21 CONNECTOR, USB (MINI AB)
< DIODE >
D1001 6-503-219-01 DIODE RKZ12B2KJR1
D1003 6-501-216-01 DIODE CL-271HR-C-TS
*D1305 6-502-988-01 DIODE RB480Y-40T2R
D1401 6-503-126-01 DIODE DA2S10100K8
D1402 6-503-126-01 DIODE DA2S10100K8
D4101 6-503-126-01 DIODE DA2S10100K8
D5301 8-719-069-28 DIODE 1SS400FJTE61
D5302 8-719-069-28 DIODE 1SS400FJTE61
*D9101 6-502-988-01 DIODE RB480Y-40T2R
D9102 6-503-702-01 DIODE RB070M-30FJTR
D9103 6-502-934-01 DIODE DB2S31100K8
D9104 6-503-217-01 DIODE RKZ5.6B2KJR1
D9105 6-503-217-01 DIODE RKZ5.6B2KJR1
< FUSE >
F001 1-523-133-31 FUSE (1.4A/50V)
F002 1-523-133-31 FUSE (1.4A/50V)
F003 1-523-133-31 FUSE (1.4A/50V)
F004 1-523-133-31 FUSE (1.4A/50V)
F005 1-523-133-31 FUSE (1.4A/50V)
*F006 1-576-872-31 FUSE (0.25A/50V)
F007 1-523-134-31 FUSE (2A/50V)
< FERRITE BEAD >
FB401 1-481-747-21 INDUCTOR, FERRITE BEADS
FB1006 1-400-927-31 BEAD, FERRITE (1005)
FB1007 1-400-927-31 BEAD, FERRITE (1005)
FB1008 1-400-833-21 SMD EMI FERRITE
FB1401 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
FB1402 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
FB1403 1-400-723-11 INDUCTOR, FERRITE BEAD (1005)
FB1404 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)
FB1405 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)
(EXCEPT CX190/CX190E)
FB1410 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB1411 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB1412 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB1413 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB1414 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB1415 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB1416 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB1417 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB1501 1-481-912-21 EMI FERRITE (SMD) (1005)
< IC >
IC1001 6-717-032-01 IC TC7MP3125FTG (EB) (Projector Model)
IC1301 (Not supplied) IC AVY1G2G04B
IC1302 6-716-878-01 IC AK8153AU-L
IC2301 6-718-156-01 IC BU76312GUW-E2
*IC3301 6-712-050-01 IC SN65LVDS301ZQER (Projector Model)
IC4301 6-717-389-01 IC BD8330AGU-E2
IC4302 6-716-945-01 IC BD8331GU-E2
IC4303 6-718-155-01 IC R1207N823B-TR-FE
*IC4304 6-714-502-01 IC BD2224G-TR
*IC4305 6-716-539-01 IC MM3404A46URE
IC4801 6-718-258-01 IC MB95005ABGL-G-135-ERE1
*IC5306 6-712-278-01 IC BD6373GW-E2
*IC5309 6-714-440-01 IC BH72220FVM-TR
IC5313 6-715-932-01 IC BA2904SFV-E2
IC5314 6-715-932-01 IC BA2904SFV-E2
IC5315 6-715-932-01 IC BA2904SFV-E2
IC9101 6-718-158-01 IC MAX14593EEWV+TG1A
IC9102 6-718-154-01 IC BD8668GW-E2
IC9104 6-716-783-01 IC BD11600NUX-E2
*IC9105 6-714-833-01 IC TPS2553DBVR-1
IC9106 6-716-783-01 IC BD11600NUX-E2
< COIL >
L2301 1-400-588-11 INDUCTOR 10uH
L4301 1-460-355-11 INDUCTOR 4.7uH
L4302 1-460-370-11 INDUCTOR 10uH
L4303 1-460-370-11 INDUCTOR 10uH
L4304 1-460-370-11 INDUCTOR 10uH
L4305 1-460-370-11 INDUCTOR 10uH
L4306 1-460-355-11 INDUCTOR 4.7uH
L4307 1-460-369-11 INDUCTOR 33uH
*L5301 1-481-425-21 INDUCTOR 10uH
*L5302 1-400-674-21 INDUCTOR 4.7uH
*L9102 1-457-858-11 INDUCTOR 4.7uH
< LINE FILTER >
LF1001 1-457-223-11 COMMON MODE CHOKE COIL
LF1002 1-457-223-11 COMMON MODE CHOKE COIL
LF1003 1-457-223-11 COMMON MODE CHOKE COIL
LF1004 1-457-223-11 COMMON MODE CHOKE COIL
LF9101 1-457-223-11 COMMON MODE CHOKE COIL
LF9102 1-457-223-11 COMMON MODE CHOKE COIL
< TRANSISTOR >
*Q1001 6-552-397-01 TRANSISTOR DSC300100L
Q1301 6-552-621-01 TRANSISTOR SSM3K37MFV, L3SOF
*Q1302 6-552-723-01 TRANSISTOR SSM6N37FE, RSONYM
*Q1402 6-552-344-01 TRANSISTOR DRA3143T0L
*Q1403 6-552-535-01 TRANSISTOR DMG964030R
Q2302 8-729-056-75 TRANSISTOR MCH3211-TL-E
Q4101 8-729-043-60 TRANSISTOR CPH6102-TL-E
*Q4102 6-552-354-01 TRANSISTOR DRC3144E0L
Q4103 6-551-663-01 TRANSISTOR MTM684110LS0
Q4304 6-552-749-01 TRANSISTOR RN2131MFV
Q4305 6-552-749-01 TRANSISTOR RN2131MFV
*Q4801 6-552-535-01 TRANSISTOR DMG964030R
*Q5301 6-552-344-01 TRANSISTOR DRA3143T0L
*Q5302 6-552-397-01 TRANSISTOR DSC300100L
*Q5303 6-552-397-01 TRANSISTOR DSC300100L
Q9102 6-553-025-01 TRANSISTOR MCH6341
*Q9103 6-552-354-01 TRANSISTOR DRC3144E0L
*Q9107 6-552-348-01 TRANSISTOR DRC3114E0L
< RESISTOR >
R1001 1-218-989-11 METAL CHIP 1M 5% 1/16W
R1003 1-220-169-11 METAL CHIP 75 5% 1/16W
R1004 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1005 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R1006 1-218-943-11 METAL CHIP 150 5% 1/16W
R1007 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
R1008 1-220-802-11 METAL CHIP 3.3 5% 1/16W
R1009 1-220-802-11 METAL CHIP 3.3 5% 1/16W
R1010 1-220-802-11 METAL CHIP 3.3 5% 1/16W
R1011 1-220-802-11 METAL CHIP 3.3 5% 1/16W
R1012 1-220-802-11 METAL CHIP 3.3 5% 1/16W
R1013 1-220-802-11 METAL CHIP 3.3 5% 1/16W
R1014 1-220-802-11 METAL CHIP 3.3 5% 1/16W
R1015 1-220-802-11 METAL CHIP 3.3 5% 1/16W
R1017 1-218-945-11 METAL CHIP 220 5% 1/16W
R1018 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1025 1-218-973-11 METAL CHIP 47K 5% 1/16W
(PJ200/PJ200E/PJ210)
R1025 1-218-990-81 SHORT CHIP 0
(CX200/CX200E/CX210/CX210E)
R1026 1-218-977-11 METAL CHIP 100K 5% 1/16W
(PJ200/PJ200E/PJ210)
R1026 1-218-990-81 SHORT CHIP 0 (CX190/CX190E)
R1043 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1044 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1059 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1304 1-218-990-81 SHORT CHIP 0
R1315 1-208-869-11 METAL CHIP 180 0.5% 1/16W
R1321 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R1331 1-250-481-11 METAL CHIP 270 1% 1/16W
R1332 1-218-970-11 METAL CHIP 27K 5% 1/16W
R1335 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1342 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R1343 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R1362 1-218-937-11 METAL CHIP 47 5% 1/16W
*R1367 1-250-469-11 METAL CHIP 82 1% 1/16W
R1409 1-218-943-11 METAL CHIP 150 5% 1/16W
R1410 1-218-942-11 METAL CHIP 120 5% 1/16W
R1411 1-218-941-81 METAL CHIP 100 5% 1/16W
R1412 1-218-941-81 METAL CHIP 100 5% 1/16W
R1413 1-208-859-81 METAL CHIP 68 0.5% 1/16W
(EXCEPT CX190/CX190E)
R1414 1-218-943-11 METAL CHIP 150 5% 1/16W
(EXCEPT CX190/CX190E)
R1421 1-218-941-81 METAL CHIP 100 5% 1/16W
R1422 1-218-971-11 METAL CHIP 33K 5% 1/16W
R1423 1-218-971-11 METAL CHIP 33K 5% 1/16W
R1424 1-218-971-11 METAL CHIP 33K 5% 1/16W
R1425 1-218-971-11 METAL CHIP 33K 5% 1/16W
R1426 1-208-859-81 METAL CHIP 68 0.5% 1/16W
(EXCEPT CX190/CX190E)
R1427 1-208-859-81 METAL CHIP 68 0.5% 1/16W
(EXCEPT CX190/CX190E)
R1428 1-208-859-81 METAL CHIP 68 0.5% 1/16W
(EXCEPT CX190/CX190E)
R1429 1-208-859-81 METAL CHIP 68 0.5% 1/16W
(EXCEPT CX190/CX190E)
R1430 1-208-859-81 METAL CHIP 68 0.5% 1/16W
(EXCEPT CX190/CX190E)
VC-651

HDR-CX190/CX190E/CX200/CX200E/CX210/CX210E/PJ200/PJ200E/PJ210_L3
2-5E
Ref. No. Part No. Description Ref. No. Part No. Description
R1431 1-208-859-81 METAL CHIP 68 0.5% 1/16W
(EXCEPT CX190/CX190E)
R1432 1-208-859-81 METAL CHIP 68 0.5% 1/16W
(EXCEPT CX190/CX190E)
R1433 1-208-859-81 METAL CHIP 68 0.5% 1/16W
(EXCEPT CX190/CX190E)
R1450 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1452 1-218-937-11 METAL CHIP 47 5% 1/16W
R1453 1-218-937-11 METAL CHIP 47 5% 1/16W
R1454 1-218-990-81 SHORT CHIP 0 (Projector Model)
R1455 1-218-990-81 SHORT CHIP 0 (Non Projector Model)
R1515 1-208-668-11 METAL CHIP 240 0.5% 1/16W
R2320 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R2321 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R2322 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2323 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2326 1-218-973-11 METAL CHIP 47K 5% 1/16W
R2328 1-218-977-11 METAL CHIP 100K 5% 1/16W
R2331 1-218-977-11 METAL CHIP 100K 5% 1/16W
R2332 1-218-973-11 METAL CHIP 47K 5% 1/16W
R2333 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R2334 1-218-971-11 METAL CHIP 33K 5% 1/16W
R2336 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R4101 1-216-796-11 METAL CHIP 8.2 5% 1/10W
R4102 1-218-953-11 METAL CHIP 1K 5% 1/16W
R4103 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R4302 1-218-941-81 METAL CHIP 100 5% 1/16W
R4303 1-250-535-11 METAL CHIP 47K 1% 1/16W
R4315 1-250-449-11 METAL CHIP 12 1% 1/16W
R4317 1-250-449-11 METAL CHIP 12 1% 1/16W
R4334 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4802 1-245-604-11 METAL CHIP 10M 5% 1/16W
R4803 1-208-893-11 METAL CHIP 1.8K 0.5% 1/16W
R4807 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R4808 1-218-973-11 METAL CHIP 47K 5% 1/16W
R4810 1-218-949-11 METAL CHIP 470 5% 1/16W
R4812 1-218-973-11 METAL CHIP 47K 5% 1/16W
R4814 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R4815 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R4817 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R4818 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R4820 1-218-985-11 METAL CHIP 470K 5% 1/16W
R4821 1-218-989-11 METAL CHIP 1M 5% 1/16W
R5329 1-216-797-11 METAL CHIP 10 5% 1/10W
R5330 1-218-941-81 METAL CHIP 100 5% 1/16W
R5331 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5332 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5333 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5334 1-218-962-11 METAL CHIP 5.6K 5% 1/16W
R5335 1-218-971-11 METAL CHIP 33K 5% 1/16W
R5338 1-218-980-11 METAL CHIP 180K 5% 1/16W
R5339 1-218-972-11 METAL CHIP 39K 5% 1/16W
R5340 1-218-980-11 METAL CHIP 180K 5% 1/16W
R5342 1-218-968-11 METAL CHIP 18K 5% 1/16W
R5344 1-218-962-11 METAL CHIP 5.6K 5% 1/16W
R5345 1-218-969-11 METAL CHIP 22K 5% 1/16W
R5346 1-218-980-11 METAL CHIP 180K 5% 1/16W
R5349 1-218-980-11 METAL CHIP 180K 5% 1/16W
R5350 1-218-980-11 METAL CHIP 180K 5% 1/16W
R5352 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5353 1-218-969-11 METAL CHIP 22K 5% 1/16W
R5354 1-218-947-11 METAL CHIP 330 5% 1/16W
R5355 1-218-953-11 METAL CHIP 1K 5% 1/16W
R5356 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5398 1-218-973-11 METAL CHIP 47K 5% 1/16W
R5399 1-218-973-11 METAL CHIP 47K 5% 1/16W
R9116 1-218-941-81 METAL CHIP 100 5% 1/16W
R9120 1-218-989-11 METAL CHIP 1M 5% 1/16W
R9133 1-248-311-11 RES-CHIP 0.1 1% 1/4W
R9134 1-250-535-11 METAL CHIP 47K 1% 1/16W
R9135 1-218-969-11 METAL CHIP 22K 5% 1/16W
R9136 1-218-944-11 METAL CHIP 180 5% 1/16W
R9137 1-250-521-11 METAL CHIP 12K 1% 1/16W
R9138 1-218-973-11 METAL CHIP 47K 5% 1/16W
R9139 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
R9140 1-257-317-11 RES, METAL FILM CHIP 47 (1632)
R9152 1-218-953-11 METAL CHIP 1K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB1301 1-234-377-21 RES, NETWORK 4.7K (1005X4)
RB1402 1-234-371-11 RES, NETWORK 47 (1005X4)
RB1403 1-234-702-11 RES, NETWORK 68 (1005X4)
RB1406 1-234-373-21 RES, NETWORK 220 (1005X4)
(Non Projector Model)
RB1407 1-234-373-21 RES, NETWORK 220 (1005X4)
(Non Projector Model)
RB1412 1-234-375-21 RES, NETWORK 1K (1005X4)
RB1413 1-234-375-21 RES, NETWORK 1K (1005X4)
RB1415 1-234-381-11 RES, NETWORK 100K (1005X4)
*RB1416 1-234-384-11 RES, NETWORK 1M (1005X4)
RB1417 1-234-377-21 RES, NETWORK 4.7K (1005X4)
RB1418 1-234-380-21 RES, NETWORK 47K (1005X4)
RB1419 1-234-378-21 RES, NETWORK 10K (1005X4)
RB4801 1-234-378-21 RES, NETWORK 10K (1005X4)
RB4802 1-234-378-21 RES, NETWORK 10K (1005X4)
RB9101 1-234-381-11 RES, NETWORK 100K (1005X4)
< SWITCH >
S1001 1-798-119-11 SWITCH, TACTILE (EXCEPT CX190/CX190E)
S1002 1-798-119-11 SWITCH, TACTILE (Projector Model)
S1003 1-798-119-11 SWITCH, TACTILE
< SENSOR >
*SE1001 1-487-118-21 GMR SENSOR (Non Projector Model)
*SE1002 1-487-118-21 GMR SENSOR (Projector Model)
< VARISTOR >
VD1004 1-802-090-21 VARISTOR, CHIP
VD1007 1-802-090-21 VARISTOR, CHIP
VD1008 1-802-090-21 VARISTOR, CHIP
VD1010 1-802-090-21 VARISTOR, CHIP
< VIBRATOR >
X1302 1-814-219-31 QUARTZ CRYSTAL OSCILLATOR (60MHz)
X4801 1-781-525-11 VIBRATOR, CRYSTAL (32.768kHz)
VC-651

4-1
HDR-CX190/CX190E/CX200/CX200E/CX210/CX210E/PJ200/PJ200E/PJ210_L3
4. BLOCK DIAGRAMS
4-1. OVERALL BLOCK DIAGRAM (1/3)( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
CMOS
IMAGER
(1/2)
CP003
IRIS
(SHUTTER)
LENS BLOCK (1/2)
XCS_LCD
XBB_RST
AV_SO/SCK
PANEL_NOR/REV
TP_X/Y/SEL1
XPJ_PARK
PJ_TEMP_AD
XPJ_RESET
LCD_G_0 - LCD_G_7
LCD_R_0 - LCD_R_7
LCD_XVD/HXD
LCD_CLK
LCD_DATEN
I2C_SDA/SCK
CN6805
DOAP - DOBP,
DOAM - DOBM
XVS
SDI,SDO,SCK
DCKP,DCKM
INCK
XCLR
FP-1483
FLEXIBLE
BOARD
CM-127 BOARD
CN1002
VC-651 BOARD (1/2)
SENS_VD
SUBL_CLKINN/CLKINP
SUBL_DINN2-DINN9/DINP2-DINP9
XFLASH_RST
CLK_CMOS_IN_IMG
CLK_CMOS_IN_IMG
CPU,
AV SIGNAL,
LENS CONTROL,
MODE CONTROL,
HDMI PROCESS
(2/11 - 4/11)
LCD SERIAL
INTERFACE
TRANSMITTER
(6/13)
IC3301
IC2301
BCK_OUT/MCK_INOUT/LRCK_OUT
SDO
AV_SO/SCK
INT_MIC_L
INT_MIC_R
AUDIO_L_I/O
AUDIO_R_I/O
JACK_AD
AUDIO
PROCESSOR
(5/11) COMPO_VIDEO
CN1004
A/V R
JACK_AD
CN1006
IC1301
(1/2)
CLOCK
GENERATOR
(2/13)
IC1302
CLK_SYS_IN
CLK_CMOS_IN
XHS
X1302
60MHz
XCE
IC_1301_SENSSI/SENSSO/SENSSCK
IC_1301_SENSXCS
SENS_HD
XPJ_PARK
PJ_TEMP_AD
: VIDEO SIGNAL
: AUDIO SIGNAL
LANC_SIG
COMPO_VIDEO
SP901
(SPEAKER)
MIC901
MICROPHONE
UNIT
CN1010
SP ±
(L)
(R)
CN1011
SDIO_SPDIF_IN
LCD_XVD/XHD
XCS_LCD
XBB_RST
AV_SO/SCK
PANEL_NOR/REV
TP_X/Y/SEL1
KEY_AD2
Q1402
TP_SEL2
LCD_CLK
CN1007
XCS_LCD
XBB_RST
AV_SO/SCK
PANEL_NOR/REV
TP_X/Y/SEL1
LCD_DATA_0-DATA_7
KEY_AD2
I2C_SDA/SCK,
XPJ_RESET
LCD_B_0 - LCD_B_7
D0±−D2±, CLK±
CN1005
I_BIAS±, I_HALL±,
I_DRIVE±
LENS_TEMP_AD
FC_SENSE_OUT
IRIS
DRIVE
LENS TEMP
SENSOR
LENS BLOCK
ZOOM_A/B/XA/XB
ZM_SENSE_OUT
FOCUS_A/B/XA/XB
ZOOM
DRIVE
FOCUS
DRIVE
I_DRIVE-
LENS_TEMP_AD
FC_SENSE_OUT
ZM_SENSE_OUT
AO1 DAC_STRB
XCAM_SCK
CAM_SO
IRIS_MD_BRAKE
FC_LENSV_ENB,
FC_LENSV_DIR_A/B
ZM_ENB, ZM_DIR_A/B
SHUTTER_ON
PITCH_AD
YAW_AD
CRESET_P
PITCH/YAW
SENSOR
(2/2)
IC7501 PITCH_AD
YAW_AD
CRESET_P
XFLASH_RST
XCS_LCD
XBB_RST
AV_SO/SCK
D0±−D2±, CLK±
LCD_DATA_0-DATA_7
LANC_SIG
08
Non Projector Model
Projector Model
LCD_XVD/XHD/CLK
AO2
I_HALL_AD
AO3
I_HALL_AD
AO3
IRIS_PWM
AO3
I_HALL-
I_BIAS+
I_DRIVE-
I_BIAS-
I_HALL+
I_BIAS+
I_HALL_AD
F2
K2
18,17,
24,23
14
21,20
11,12,
10
32
8
11,17,
10,16
20
14,13
22,23,
24
2
26
AK28
9
1
6
7
8
6
48,50,
38,40,
34,36,
44,46,
28,24,
27
7,4
12,12,
14
9
11
29
H2,H1
4
1
3
AF2
AD30
G3
G1
13
9
35
25
AC30
AC29
OVERALL (2/3)
(PAGE 4-2)
2
2
6
3
1,2
12
13
15,16,
18,19,
21,22,
24,25
29,30,
27
11,10
7,6,
5
4
8
W1,W2
AE10
LEVEL
SHIFT
(1/11)
IC1001
29
8
27
5
6
7
15,17,
16,18,
13,14
1,4,
2,3
22,24,
21,23
7
11
6
FOCUS/ZOOM
MOTOR DRIVE
(10/11)
IC5306
EVR
(D/A CONVERTER)
(10/11)
IC5309
OVERALL (2/3)
(PAGE 4-2)
1
OVERALL (3/3)
(PAGE 4-3)
3
OVERALL (3/3)
(PAGE 4-3)
4
HALL
BIAS/GAIN
CONTROL
(10/11)
IC5315
IRIIS DRIVE
(10/11)
IC5313
Q5303
BUFFER
Q5302
BUFFER
IRIAS DRIVE,
HALL AMP
(10/11)
IC5314

4-2
HDR-CX190/CX190E/CX200/CX200E/CX210/CX210E/PJ200/PJ200E/PJ210_L3
TOUCH
PANEL
2.7 INCH
WIDE COLOR
LCD
LCD901
(LCD MODULE)
CN6001
CN6003
TP_SEL1
TP_X/YTP_X/Y/SEL1
CN6002
TP_R
TP_BOT
TOUCH PANEL
INTERFACE
Q6001, Q6002
SE6001
XCS_LCD
PANEL_NOR/REV
XBB_RST
PD-457 BOARD
PANEL
NORMAL/REVERSE
DETECTION
(1/2)
AV_SO/SCK
LCD_DG0-DG7
IC6101
LCD SERIAL
INTERFACE
RECEIVER
(2/2) LCD_VD/HD
CN6007
LCD_DR0-DR7
I2C_SDA, I2C_SCK, XPJ_RESET
XPJ_PARK
PJ_TEMP_AD
D0±−D2±, CLK±
XCS_LCD
XBB_RST
AV_SO/SCK
PANEL_NOR/REV
TP_X/Y/SEL1
XPJ_PARK
PJ_TEMP_AD
FP-1482
FLEXIBLE
BOARD
XCS_LCD
XBB_RST
AV_SO/SCK
PDATA0 - PDATA7
PJ-104 BOARD FP-1319 FLEXIBLE
BOARD
CN8503
CN8501
CN8502
DMD_D0 - D11
DMD_SAC_BUS
DMD_STRB/0EZ
DMD_LOADB/SCTRL
DMD_DCLK/BUS
LED_SEL0
LED_SEL1
PDATA8 - PDATA15
PDATA16 - PDATA23
VSYNC_WE, HSYNC_CS,
PCLK
SDA/SCL_2601,
DPP_RESETZ
PARKZ
CN5503CN5505
DMD_D0 - D11
DMD_SAC_BUS
DMD_STRB/OEZ
DMD_LOADB/SCTRL
DMD_DCLK/BUS
RED_STROBE
BLU_STROBE
GRN_STROBE
LEDDRV_ON
SDA/SCL_2601
LED_ANODE
PROJECTOR
UNIT
RED_CATMODE
GRN_CATMODE
BLU_CATMODE
PJ_TEMP_AD
MEMO_A0 - A12
MEMO_DQ0 - DQ15
X8601
16.66667MHz
MEMO_CLK_N/P
MEMO_BA0/BA1
MEMO_LDM/UDM
MEMO_LDQS/UDQS
MEMO_CASZ/RASZ/CSZ
MEMO_CKE/WEZ
OVERALL (1/3)
(PAGE 4-1)
2
D1 ± −D2 ±, CLK ±LCD_DB0-DB7
LCD_CK
LCD_DATEN
I2C_SDA,
I2C_SCK,
XPJ_RESET
LCD_VD/HD/CK
LCD_DB0 - DB7
I2C_SDA, I2C_SCK, XPJ_RESET
XPJ_PARK
PJ_TEMP_AD
LCD_VD/HD/CK
PJ_TEMP_AD
DATEN_CMD
DPP_RESETZ
TOUCH
PANEL
2.7 INCH
WIDE COLOR
LCD
LCD901
(LCD MODULE)
CN6504
CN6502
TP_SEL1
TP_X/Y
TP_X/Y/SEL1
CN6503
TP_R
TP_BOT
TOUCH PANEL
INTERFACE
Q6501, Q6502
SE6501
XCS_LCD
LCD_VD/HD/CK
PANEL_NOR/REV
XBB_RST
PD-454 BOARD
PANEL
NORMAL/REVERSE
DETECTION
AV_SO/SCK
LCD_D0-D7
LCD_XVD/XHD
XCS_LCD
XBB_RST
AV_SO/SCK
PANEL_NOR/REV
TP_X/Y/SEL1
FP-1481
FLEXIBLE
BOARD
XCS_LCD
XBB_RST
AV_SO/SCK
OVERALL (1/3)
(PAGE 4-1)
1
KEY_AD2
S6501,S6502
KEY_AD2
LCD_VD/HD/CK
08
Projector Model
Non Projector Model
: VIDEO SIGNAL
CX190/CX190E
CX200/CX200E/
CX210/CX210E
FLASH
MEMORY
(2/4)
IC8603
SPIDIN_INT, SPIDOUT_INT
SPICS_INT, SPICLJK_INT
2
5
4, 1
4
3
17 - 10
8, 7, 9
5, 6
54,56,
38,36,
32,30,
26,24
13,15,
19
23,25,
29,31,
35,37,
41,43
55,53,
49,47,
42,44,
48,50
16
3,512
7
8
6
48,50,
38,40,
34,36,
44,46
7,4
12,13,
14
29
23,25,
29,31,
35,37,
41,43
54,56,
38,36,
32,30,
26,24
13,15,
19
3,5,
12
16
7
DMD
CONTROL
(2/4)
IC8605
25, 3,
7, 11,
13, 15,
23, 19,
8, 4,
14, 12
32
29, 36
20, 24
18, 28
25, 3,
7, 11,
13, 15,
23, 19,
8, 4,
14, 12
29, 36
20, 24
18, 28
25, 3,
7, 11,
13, 15,
23, 19,
8, 4,
14, 12
29, 36
20, 24
18, 28
LED
DECODER
(2/4)
IC8601
SDRAM
(3/4)
IC8701
INVERTER
(2/4)
IC8602
LED
DRIVE
(4/4)
IC8801 1, 2
3, 4
7, 8
9, 10
6
4
2
5
3
1
K15
J15
32 32
9
H8,H9
28,24,
27
9
1
55,53,
49,47,
42,44,
48,50
9
2
5
4, 1
4
3
17 - 10
8, 7, 9
5, 6
22
21
19,18,
15,14,
11,10,
7,6
2,1,
4
23,24
27,28,
29
26
30
4-2. OVERALL BLOCK DIAGRAM (2/3)( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.

4-3
HDR-CX190/CX190E/CX200/CX200E/CX210/CX210E/PJ200/PJ200E/PJ210_L3
BUILT-IN
USB CABLE
CHARGE
MEMORY
STICK
PRO DUO
SD
MSX_BS/CLK
MS-475 BOARD
CN8002CN8001
MSX_BS/CLK
TE0_XSDCD
MSX_INS_HIZ
TE0_XSDCD
TE0_CMD/SDWP/CLK
MSX_INS_HIZ
TE0_CMD/SDWP/CLK
FP-1556
FLEXIBLE
BOARD
VC-651 BOARD (2/2)
CN1014
CN1009
XPHOTO_LED
XCHARGE_LED
SS
CONTROL
SWITCH
BLOCK
(PS27800)
MEMORY CARD
SLOT
MSX_INS_HIZ
08
VIDEO/AUDIO SIGNAL
D1402
D1401
XCAM_LED
FR_XRESET
KEY_AD2
KEY_AD3
S1001
TE0_DAT_0 - DAT_3
MSX_BIO_0 - BIO_3 MSX_BIO_0 - BIO_3
KEY_AD1
ZOOM_VR_AD
XSYS_RST
XFLASH_RST
XRESET_REQ
IC4801
(9/11)
LANC INTERFACE,
HI CONTROL
XCS_FRONT
XPWR_OFF
FR_SI/SO/SCK
X4801
32.768KHz
CN1001
HDMI_TXCN/TXCP
HDMI_TX0SOP-TX2SOP, HDMI_TX0SON-TX2SON
Q1302
Q1301
Q1403 HPD
HDMI_JACK_IN
CEC CEC
SDA, SCL SDA, SCL
HDMI
OUT
USB_D±
USB SWITCH
(13/13)
IC9106
USB POWER
MANEGEMENT
(13/13)
IC9101
CN9102
CN9101
(USB)
USB_ID2
USB_SEL
USB_D±_STD_CN
USB_DP/DM
ISET1
ISET2
SMART
POWER
SELECTOR
(13/13)
IC9102
ISETOUT1
ISETOUT2
USB_DD_PGOOD
USB_DD_EN
VBUSOK
USB_ID2
ISETOUT1
ISETOUT2
USB_DD_PGOOD
USB_DD_EN
VBUSOK
PANEL
OPEN/CLOSE
SENSOR
(1/13)
SE1001
Q1001
XPANEL_POWER_ON
DC/DC CONVERTER,
LANC INTERFACE
(8/13)
IC4302
LANC_SIG
LANC_IN/OUT
NENU
NENU
USB_VCC
USB SWITCH
(13/13)
IC9104
USB_ID
USB_VBUS
USB_SEL
USB_SEL
(1/2)
IC8101
TE1_CLK/CMD TE1_CLK/CMD
TE1_DAT_0 - DAT_0-7
INTERNAL
MEMORY
TE1_DAT_0-DAT_0-7
TE1_CLK/CMD
CN8101
MM-102 BOARD
(2/2)
IC8201
INTERNAL
MEMORY
TE1_DAT_0 - DAT_0-7
CN1008
TE0_XSDCD
FR_XRESET
FR_XRESET
TE0_DAT_0 - DAT_3
XCHARGE_LED
XCAM_LED
USB_ID
USB_VBUS
LANC_SIG
USB_DP/DM
IM Model
S1002
S1003
EXCEPT CX190/CX190E
Projector Model
FP-1557
FLEXIBLE
BOARD
D1003
XMS_ACC_LED
Non Projector Model
PANEL
OPEN/CLOSE
SENSOR
(1/13)
SE1002
Projector Model
10,8,11,1621,23,1,3
24
14
6 - 9
25
11
9,8,10,11
6
23
6,15,26
28 - 25
31,5,8
7,17
30,21
4,13
22,23,21,203,26,13
CPU,
AV SIGNAL,
LENS CONTROL,
MODE CONTROL,
HIDMI PROCESS
(2/11-4/11)
7
3
2
IC1301
(2/2)
5
8
13
A8
B8
L3
L2
14
8,5,2,9,6,312,1116,15
19
LEVEL SHIFT
3, 2
3, 2
4
LEVEL SHIFT
LEVEL SHIFT
1
2 - 911,13
10 - 178,6
K2
E5
OVERALL (1/3)
(PAGE 4-1)
4
OVERALL (1/3)
(PAGE 4-1)
3
AH2
4-3. OVERALL BLOCK DIAGRAM (3/3)( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.

4-4
HDR-CX190/CX190E/CX200/CX200E/CX210/CX210E/PJ200/PJ200E/PJ210_L3
BUILT-IN
USB CABLE
BATTERY
TERMINAL
CN1013
+
S
–
Q4103
ACV/BATT SWITCH
Q4101, Q4102
BATTERY CHARGE
SWITCH
F003 L4301
F004
DC/DC CONVERTER
(8/11)
IC4301
LX1a
FB1
LX1b
L4306
LX6a
FB6
LX6b
L4305
LX5a
FB5
LX5b
L4302
LX2
FB2
LDO1_SOURCE
B+ SWITCH
(8/11)
IC4304
VOUT
VIN
EN 4.6V REG
(8/11)
IC4305
VOUT
CE
EN
F002
BATT_UNREG_SENSE
D_1.2V
L4303
LX3a
FB3
LX3b
LD02_SOURCE
D_1.8V
L4304
LX4
FB4
AU_2.8V
D_2.8V
A_3.3V
D_3.3V
SD_PWR_ON TE0_VCC
A_4.6V
D_3.3V
J_5.0V
A_5.0V
MT_5.0V
MT_5.0V
DC/DC CONVERTER
(8/11)
IC4303
VOUT
VIN
LX
BL_H
LCD_CABC_PWM
L4307
F4006
EN
FB BL_L
LDO2_OUT
HB_1.2V
HB_1.8V
LDO1_OUT
CORE_UNREG
I/O_UNREG
MT_UNREG
XLANC_PWR_ON
XLANC_ON
BATT_IN
XCS_IC_4302
DC/DC CONVERTER
LANC INTERFACE
(8/11)
IC4302
F005
F001 ACV_UNREG
ACV_ON
BATT_ON
BATT/XEXT_CN
LANC INTERFACE,
HI PROCESSOR
(9/11)
IC4801
VC-651 BOARD (1/3)
BATT_UNREG_CN
BATT_SIG
FR_EVER_SI/SO/SCK
VuC
XLANC_ON
XLANC_PWR_ON
UNREG_IN
CS
ACV_ON
EVER_
.3.0V
LDO1_OUT
LDO1_FB
PVDD_LDO1
LDO2_OUT
LDO2_ON
LOAD_IN
LOAD_OUT
LOAD_ON
VCH
LANC_DC
D_1.2V
A_1.125V_SENSE
A_1.125V
HDMI_5V
MS_PWR_ON
MSX_3.3V
BATT_LI_3V
LANC_DC
LDO1_ENB
PVDD1a
PVDD1b
PVDD2
PVDD3a
PVDD3b
PVDD4
PVDD5a
PVDD5b
PVDD_CP
AVDD
PVDD6a
PVDD6b
LDO2_ENB
A_1.8V
A_2.8V
A_VID_1.1V
D_VID_1.1V
LDO1_ON
VOUT
ACV_ON
BATT_ON
LDO2_ON
BATT_GND
CN9101
USB_VCC_STD
USB POWER
MANAGEMENT
(11/11)
IC9101
VBUS1
SMART POWER
SELECTOR
(11/11)
IC9102
L9102
D9102
Q9102
V FB
V FB
SW1
F007
DC IN
VB1
VB2
NVP
OUT1
OUT2
REG33
D9101
UNREG_IN_DET
VBUS2
ISNS
VBUSLIM SW2
1D+
USB
SWITCH
(11/11)
IC9104
2D+
D+
VCC
1D-
CN9102
(USB)
USB_VCC
MAIN_UNREG
USB_ID2
OUT
CURRENT LIMITTER
(11/11)
IC9105
IN
X_FAULT
EN
F500
VCC
D_2.8V
EVER_3.0V
USB_VBUS
J_5.0V
J_5.0V
XVBUS_XOVR_CUR
VBUS_EN
CH1_OUT
CH2_OUT
CH3_OUT
CH4_OUT
CH6_OUT
CH5_OUT
D9103
VTR_UNREG
PVDD_LP02
ACV_UNREG
BATT_ON
LDO1_ON
FR_EVER_SO/SCK
FR_EVER_
SI/SO/SCK
DD_ON
UNREG_IN_DET
UNREG_IN_DET
BATT_UNREG
BATT_UNREG_SENSE
D4101 EP_2.8V
AVDD18_SUBL
HB_1.2V
HB_1.8V
MS_PWR_ON
SD_PWR_ON
LCD_CABC_PWM
D_2.8V
J_5.0V
USB_VBUS
VBUS_XOVR_CUR
VBUS_EN
CPU,
AV SIGNAL,
LENS CONTROL,
MODE CONTROL,
HDMI PROCESS
(2/11 - 4/11)
IC1301
(1/2)
XO_CS_IC_4302
XPUI_LANC_PWR_ON
XO_LANC_IC_ON
I_BATT_IN HB_1.2V
HB_1.8V
XBUS_DET_STD_A
XVBUS_DET
Q9103
Q9107
USB_VCC
08
FRC_RTG_IN1
LCD_CABC_PWM
GPIO_S__6
VBUS_EN
GPIO_S__2
GPIO_S__1
XVBUS_DET_STD_A
XBUS_DET
GPIO_SB__5
USB_VBUS
EVER_3.0V
BATT_LI_3V
EVER_3.0V
A_1.125V
HDMI_5V
MSX_3.3V
LANC_DC
BL_H,BL_L
J_5.0V
A_5.0V
MT_5.0V
TE0_VCC
EVER_3.0V
POWER (2/3)
(PAGE 4-5)
A
USB SWITCH
(11/11)
IC9106
ACV_UNREG_CN
BATT/XEXT_CN
ACV_GND
MEDIA_3.3V
J1001
BT9001
J_5.0V
CHARGE
D1
D2
B8
C5
A6
D3
A2
C4
B4
B2
H7
E4
H4
E3
G4
5
1
3
3
1
4
E8
D5
E7
5
6
1
4
3
A5
D6
A4
E1
E2
C8
A1
B1
H6
H5
G5
H2
B7
D8
D7
B1
A1
B2
A3
A5
B6
A6
B5
F5
C2
C4
E4
F4
1
2
G1 G6
E3K9
C1
A7
E5
D3
C4
F10
A4
C7
Q4801
D6
E2
XPUIO_BATT_SIG
O_INIT_CHARGE
PUI_BATT_XEXT
XCS_DD
DD_ON
XO_CS_DDCON
H2
O_LDO1.2_ON
O_LDO1.8_ON
CS
INIT_CHARGE_ON
BATT_SIG
3
1
E4
D4
B5
A5
USB_VBUS
SWITCH A6
B6
A1
A2
C4
A1
A2
A3
A5 D5
3
8
10
1
2
1
4
1
63
B2
B1
4
E6
A4
Q4305
AC_UNREG
SWITCH F1
D1
C1
F2
O_SYS_DD_ON
D2F1
O_SYS_DD_ON_IC_4302 SYS_DD_ON_IC_4302
F2
E1
Q4304
BATT_UNREG
SWITCH
SWITCH
AF10
Y10
P24
AJ20
AE21
R25
R26
T25
F6
F5 DD_ON
MAIN_UNREG_SENSE
Projector Model
IM Model
4-4. POWER BLOCK DIAGRAM (1/3) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.

4-5
HDR-CX190/CX190E/CX200/CX200E/CX210/CX210E/PJ200/PJ200E/PJ210_L3
4-5. POWER BLOCK DIAGRAM (2/3) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
Projector Model
Projector Model
Non Projector
Model
IM Model
IM Model
FP-1482
FLEXIBLE
BOARD
PD-457 BOARD
CN6001
D_1.8V
BL_H, BL_L
D_1.8V
BL_H, BL_L
EP_2.8V
CN1006 CN6003
L6001
TOUCH
PANEL
INTERFACE
Q6001, Q6002
SE6001
PANEL
NORMAL/REVERSE
DETECT
EP_2.8V
2.7 INCH
WIDE COLOR
LCD
LCD901
(LCD MODULE)
LCD BACKLIGHT
POWER CONTROL
(1/4)
VOUTA
SW
VINB
IC8502
ENA
ENB
VOUTB
DMD_VOFS
DMD_VBIAS
POWER CONTROL
(1/4)
LX2
VIN1
VIN2
IC8503
EN1
EN2
LX1
P1P8V
P1P0V
L8501
L8503
LED DECODER
(2/4)
IC8601
INVERTER
(2/4)
IC8602
DMD CONTROL
(2/4)
IC8605
LED DRIVE
(4/4)
IC8801
SDRAM
(3/4)
IC8701
POWER_EN
INVERTER
(1/4)
OUTY
VCC
INA
IC8501
DMD_EN
DMD_PWR_EN
VFLASH
VFLASH
L8504
PJ_SYSPWR
D8501,D8502
FP-1319
FLEXIBLE
BOARD
CN8501
CN8503
DMD_VOFS
DMD_VBIAS
P1P8V
DMD_VRST DMD_VRST
CN5505 CN5503
PROJECTOR UNIT
PJ-104 BOARD
A_5.0V
D_3.3V
PJ_PWR_EN
CN6007
A_5.0V
D_3.3V
PJ_PWR_EN
D_3.3V
A_5.0V
PJ_PWR_EN
L6002
FLASH MEMORY
(2/4)
IC8603
P1P8V
P1P8V
PJ_SYSPWR
LCD SERIAL
INTERFACE
RECEIVER
(2/2)
IC6101
VC-651 (2/3) BOARD
D_1.2V
D_1.8V
A_1.8V
D_2.8V
LANC_DC
TE0_VCC
MT_5.0V
MSX_3.3V
BATT_LI_3V
A_1.125V
A_2.8V
BL_H,BL_L
A_5.0V
AVDD18_SUBL
POWER (1/3)
(PAGE 4-4)
A
POWER (3/3)
(PAGE 4-6)
C
EP_2.8V
HDMI_5.0V
AU_2.8V
A_3.3V
D_3.3V
D_VID_1.1V
MEDIA_3.3V
A_VID_1.1V
CN6805
CM-127 BOARD
CMOS
IMAGER
CP003
FP-1483
FLEXIBLE
BOARD
LVDS_I/O_1.8V
I/O_1.8V
A_2.7V
CMOS_A_3.3V
2.7V REG.
VOUT
CE
IN
IC6802
CN6702
AVDD18_SUBL
D_1.8V
A_3.3V
A_2.8V
SE7501
PITCH/YAW
SENSOR
(2/2)
L7501
A_2.8V
P1P0V
(1/2)
D_2.8V D_2.8V
A_1.8V A_1.8V
P1P8V
FP-1481
FLEXIBLE
BOARD
PD-454 BOARD
CN6504
EP_2.8V/D_2.8V
BL_H, BL_L
EP_2.8V
BL_H, BL_L
CN1007 CN6502
TOUCH
PANEL
INTERFACE
Q6001, Q6002
SE6501
PANEL
NORMAL/REVERSE
DETECT
L6501
(1/2)
2.7 INCH
WIDE COLOR
LCD
LCD901
(LCD MODULE)
LCD BACKLIGHT
POWER (3/3)
(PAGE 4-6)
B
EVER_3.0V
A_4.6V
D_1.2V
LANC_DC
TE0_VCC
MT_5.0V
MSX_3.3V
BATT_LI_3V
A_1.125V
HDMI_5.0V
AU_2.8V
D_VID_1.1V
MEDIA_3.3V
A_VID_1.1V
EVER_3.0V
A_4.6V
D_1.8V
A_1.8V
D_2.8V
A_2.8V
A_3.3V
D_3.3V
30
11,10
30
11,10
32
38,39
25
26
32
2
7
8
11
4
9
5
8
3
1
6
10
4
5
1
4,6,8,10
20
18
30
1,2,21,22,41,42
31
39
30
1,2,21,22,41,42
31
39
30
31
39
20
18
23
16,17,18
21
23
16,17,18
21
1,2,21,22,41,42
4,6,8,10
4
5
3
1
3
4
30
29
31
2
33
3131
22
31
32,33
3
1,2
38,39
25,26

HDR-CX190/CX190E/CX200/CX200E/CX210/CX210E/PJ200/PJ200E/PJ210_L3
4-6E
4-6. POWER BLOCK DIAGRAM (3/3) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
Non Projector Model
Projector Model
IM Model
IM Model
IM Model Projector Model
CONTROL
SWITCH
BLOCK
(PS27800)
CN1009
D_2.8V
FP-1556
FLEXIBLE
BOARD
CN1014
MS-475 BOARD
CN8002 CN8001
MSX_3.3V
TE0_VCC
BT8001
LITHIUM
BATTERY
MSX_3.3V
TE0_VCC
BATT_LI_3V BATT_LI_3V
A_1.125V
D_1.2V
A_1.8V
D_1.8V
LANC_DC
D_VID_1.1V
A_VID_1.1V
MSX_3.3V
D_2.8V
A_2.8V
CLOCK
GENERETOR
(2/11)
IC1302
AUDIO
PROCESSOR
(5/11)
IC2301
A_1.8V
FOCUS/ZOOM
MOTOR DRIVE
(10/11)
IC5306
PANEL
OPEN/CLOSE
SENSOR
(1/11)
SE1001
POWER (2/3)
(PAGE 4-5)
B
D_3.3V
A_3.3V
MEDIA_3.3V
AU_2.8V
MT_5.0V
A_4.6V
CN1004
A/V R
LANC_DC
CN1001
HDMI_5.0V HDMI OUT
EVR
(D/A CONVERTER)
(10/11)
IC5309
L2301
A_2.8V
L5301
VC-651 BOARD (3/3)
TE0_VCC
BATT_LI_3V
HDMI_5.0V
LEVEL SHIFT
(1/11)
IC1001
D_1.8V
D_2.8V
MT_5.0V
D_2.8V
D_1.8V
A_4.6V
D_2.8V
LCD SERIAL
INTERFACE
TRANSMITTER
(6/11)
IC3301
L5302
MT_5.0V
A_1.8V
EVER_3.0V
PANEL
OPEN/CLOSE
SENSOR
(1/11)
SE1002
EVER_3.0V
CPU,
AV SIGNAL,
LENS CONTROL,
MODE CONTROL,
HDMI PROCESS
IC1301
(2/2)
(2/11 - 4/11)
XZM_RST_LED
GPIO_SB__2
A_1.125V
A_1.8V
A_2.8V
A_3.3V
D_1.8V
D_2.8V
D_2.8V
D_3.3V
MEDIA_3.3V
TE0_VCC
TE1_VCC
A_VID_1.1V
D_1.2V
A_2.8V_IC_1301_1
D_2.8V_IC_1301_1
D_2.8V_IC_1301_2
D_1.8V_IC_1301_2
D_1.8V_IC_1301_1
D_1.8V_IC_1301_3
MMC_PWR_ON1
PJ_PWR_EN
GPIO_S__4
UART1_RXO
D_VID_1.1V
CN8101
MM-102 BOARDFP-1557
FLEXIBLE
BOARD
TE1_VCCMEDIA_3.3V
2.9V REG
IC8701
MMC_PWR_ON1
TE1_VCC
MEMORY CARD
SLOT
CN1008
CN1005
MEDIA_3.3V
MMC_PWR_ON1
TE1_VCC
ZM_SENSE_VCC
Q5301
CE
VDD VOUT
INTERNAL
MEMORY
(1/2, 2/2)
IC8101
IC8201
POWER (2/3)
(PAGE 4-5)
C
A_2.8V
EVER_3.0V
EVER_3.0V
IRIAS DRIVE
(10/11)
IC5313
IRIAS DRIVE,
HALL AMP
(10/11)
IC5314
HALL
BIAS/GAIN
CONTROL
(10/11)
IC5315
MEMORY
STICK
PRO DUO
SD
6,14 14,153,4
17,1827,28
19
12
10 1
4
18
REG
P26
F7
1
34
1,2
3
4
17,18
15
16
8,10
LENS
BLOCK
B+
SWITCH
V24
Q2302

5-1
HDR-CX190/CX190E/CX200/CX200E/CX210/CX210E/PJ200/PJ200E/PJ210_L3
5. FRAME SCHEMATIC DIAGRAMS
5-1. FRAME SCHEMATIC DIAGRAM (1/2) : Projector Model
J1001
BUILT-IN
USB CABLE
PJ210
Projector Model EXCEPT CX190/
CX190E
1
232
33
241
1
2
17
18
1
2
13
14
12
16
1
3
15
67
CN1002
CN1008 CN1009
CN1010
CN1012
CN1013
CN9101
129 26 30
2728
2
1
28
29
CN8001
CN8002
1
232
33
CN6805
119
23
22
21
20
162973
845 10
11
12
13
14
2
51
1
50 16
1
32
2
33
1
6
7
8
9
5CN1001
CN1004
IC1301
(Not supplied)
CN1006
CN1011
CN1014
CN9102
CN1005
BH8001
CP003
(Not supplied)
32
33 1
2
16
1
238
39
1
2
59
60
CN6001
CN6002
CN6003
CN6007
1
2
59
60
CN8503
110
CN8501
CN8502
242 4446
141 4345
S1002 S1001
S1003
133 291
18 1
181
33 1
33 1
242
CN5503
CN5505
141
44 46 43 45
242 4446
141 4345
51
1
1
51
118
CN8101
FP-1556
FLEXIBLE
BOARD
FP-1483
FLEXIBLE
BOARD
FP-1557 FLEXIBLE
BOARD
MM-102 BOARD
(SIDE A)
VC-651 BOARD
(SIDE A)
CM-127 BOARD
(SIDE A) CM-127 BOARD (SIDE B)
MS-475 BOARD
(SIDE A)
SP901
(SPEAKER)
CONTROL
SWITCH
BLOCK
(PS27800)
VC-651 BOARD
(SIDE B)
RESETPROJECTOR
HDMI
OUT
MIC901
MICROPHONE
UNIT
A/V R
LITHIUM
BATTERY
BT8001
CPC
(FOR CHECK)
(USB)
FP-1319
FLEXIBLE
BOARD
PD-457 BOARD
(SIDE A)
FP-1482 FLEXIBLE
BOARD
PJ-104 BOARD
(SIDE B) PJ-104 BOARD (SIDE A)
LCD901
(LCD MODULE)
2.7 INCH
WIDE COLOR
LCD
TOUCH PANEL
PROJECTOR
UNIT
LENS BLOCK
DC IN
S
BATTERY
TERMINAL
CHARGE

HDR-CX190/CX190E/CX200/CX200E/CX210/CX210E/PJ200/PJ200E/PJ210_L3
5-2E
5-2. FRAME SCHEMATIC DIAGRAM (2/2) : Non Projector Model
J1001
CX210/CX210E
Projector Model EXCEPT CX190/
CX190E
EXCEPT CX190/CX190E
1
232
33
241
1
2
17
18
1
2
13
14
12
16
1
3
15
67
CN1002
CN1008 CN1009
CN1010
CN1012
CN1013
CN9101
16
32
33
133
1
2
1
238
39
CN6503
CN6504
CN6502
129 26 30
2728
2
1
28
29
CN8001
CN8002
1
232
33
CN6805
30 1
119
23
22
21
20
162973
845 10
11
12
13
14
2
29
1
30 16
1
32
2
33
1
6
7
8
9
5CN1001
CN1004
IC1301
(Not supplied)
CN1007
CN1011
CN1014
CN9102
CN1005
BH8001
CP003
(Not supplied)
S1001S1002
S1003
129
133
18 1
181
33 1
33 1
BUILT-IN
USB CABLE
118
CN8101
PD-454 BOARD
(SIDE A)
FP-1481 FLEXIBLE
BOARD
FP-1556
FLEXIBLE
BOARD
FP-1483
FLEXIBLE
BOARD
FP-1557 FLEXIBLE
BOARD
MM-102 BOARD
(SIDE A)
VC-651 BOARD
(SIDE A)
CM-127 BOARD
(SIDE A) CM-127 BOARD (SIDE B)
MS-475 BOARD
(SIDE A)
S
BATTERY
TERMINAL
SP901
(SPEAKER)
CONTROL
SWITCH
BLOCK
(PS27800)
VC-651 BOARD
(SIDE B)
RESETPROJECTOR
HDMI
OUT
MIC901
MICROPHONE
UNIT
A/V R
LCD901
(LCD MODULE)
2.7 INCH
WIDE COLOR
LCD
TOUCH PANEL
(EXCEPT CX190/CX190E)
LITHIUM
BATTERY
BT8001
CPC
(FOR CHECK)
(USB)
LENS BLOCK
DC IN
CHARGE

6-1
HDR-CX190/CX190E/CX200/CX200E/CX210/CX210E/PJ200/PJ200E/PJ210_L3
6. SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS
– ENGLISH – – JAPANESE –
Precautions for Replacement of Imager
• If the imager has been replaced, carry out all the adjustments
for the camera section.
• As the imager may be damaged by static electricity from its
structure, handle it carefully like for the MOS IC.
In addition, ensure that the receiver is not covered with dusts
nor exposed to strong light.
イメージャ交換時の注意
・ イメージャを交換した場合は，カメラ部の全調整を行って
ください。
・ イメージャは構造上，静電気により破壊される恐れがある
ため，MOSICと同様に注意して取り扱ってください。
 また，受光部にはゴミの付着，および強い光がはいること
のないように注意してください。
The components identified by mark 0
or dotted line with mark 0are critical
for safety.
Replace only with part number specified.
Les composants identifiés par une mar-
que 0sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
When indicating parts by reference num-
ber, please include the board name.
0印の部品，または0印付の点線で囲まれた部品は，
安全性を維持するために，重要な部品です。
従って交換時は，必ず指定の部品を使用してください。
図面番号で部品を指定するときは基板名又はブロック
を併せて指定してください。
お願い
THIS NOTE IS COMMON FOR SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS
(In addition to this, the necessary note is printed in each block)
回路図，プリント図共通ノート
（他に必要なノートは各セクションに記載しています）
For Schematic Diagrams
• All capacitors are in μF unless otherwise noted. pF :
μF. 50 V or less are not indicated except for electrolytics
and tantalums.
• Chip resistors are 1/10 W unless otherwise noted.
kΩ=1000 Ω, MΩ=1000 kΩ.
• Caution when replacing chip parts.
New parts must be attached after removal of chip.
Be careful not to heat the minus side of tantalum capacitor,
Because it is damaged by the heat.
• Some chip part will be indicated as follows.
Example C541 L452
22U 10UH
TA A 2520
Kinds of capacitor External dimensions (mm)
Case size
• Constants of resistors, capacitors, ICs and etc with XX
indicate that they are not used.
In such cases, the unused circuits may be indicated.
• Parts with differ according to the model/destination.
Refer to the mount table for each function.
• All variable and adjustable resistors have characteristic curve
B, unless otherwise noted.
• Signal name
XEDIT →EDIT PB/XREC →PB/REC
•: non flammable resistor
• : fusible resistor
• : panel designation
• : B+ Line
• : B– Line
• : IN/OUT direction of (+, –) B LINE.
• : adjustment for repair.
For Printed Wiring Boards
• : Uses unleaded solder.
•: Circuit board
: Flexible board
Pattern from the side which enables seeing.
: pattern of the rear side
(The other layers’ patterns are not indicated)
• Through hole is omitted.
• There are a few cases that the part printed on diagram isn’t
mounted in this model.
• : panel designation
• Chip parts.
Transistor Diode
21
3
21
3
21
3
345
21
123
654
EB
C
31
5
2
46
123
654
31
5
2
46
123
54
43
12
312
45
534
12
14
23
46
2
5
31
12
43
14
23
回路図ノート
・ ケミコン，タンタルを除くコンデンサで，耐圧50V以下の
ものはその耐圧を省略。単位はすべてμF（pはpF）。
・ チップ抵抗で指示のないものは，1/10W以下。
 kΩ＝1000Ω，MΩ＝1000kΩ
・ チップ部品交換時の注意
 取り外した部品は再使用せず，未使用の部品をご使用く
ださい。
 タンタルコンデンサのマイナス側は熱に弱いため注意し
てください。
・ チップ部品には下記のように表示したものがあります。
 例 C541 L452
  22U 10UH
  TA A 2520
  種類 外形寸法（mm）
  ケースサイズ
・ 抵抗，コンデンサ，ICなど定数にXXがあるものは，使用
していない事を示しています。このため，使用していな
い回路が記載されている事があります。
・ ★印のある部品は，機種などにより異なりますので機能
別マウント一覧表を参照してください。
・ 可変抵抗と半固定抵抗で，B特性の表示を省略。
・ 信号名表記について，下記のような場合があります。
 XEDIT → EDIT PB/XREC → PB/REC
・ は不燃性抵抗。
・ はヒューズ抵抗。
・ はパネル表示名称。
・ はB＋ライン。
・ はB−ライン。
・ はBライン（＋，−）の入出力方向を示す。
・ は調整名称。
プリント図ノート
・ ：無鉛半田を使用しています。
・ ：基板
 ：フレキシブル配線板
 見ている面側のパターン。
 ：裏側のパターン
 （他のパターンについては表示されていません）
・ スルーホールは省略。
・ プリント図には，本機で使用していない部品が記載され
ている場合があります。
・ はパネル表示名称。
• Chipparts.
 Transistor Diode
21
3
21
3
21
3
345
21
123
654
EB
C
31
5
2
46
123
654
31
5
2
46
123
54
43
12
312
45
534
12
14
23
46
2
5
31
12
43
14
23

6-2
HDR-CX190/CX190E/CX200/CX200E/CX210/CX210E/PJ200/PJ200E/PJ210_L3
6-1. SCHEMATIC DIAGRAMS
FP-1483
FLEXIBLE
LND001
(PAGE 6-10)
XCLR
XHS
XVS
INCK
INCK
XVS
XHS
XCLR
Note: CP003 and IC6802 are not
supplied, but they are included
in CM-127 COMPLETE BOARD.
12345 6 7 8 9
A
B
C
D
E
F
A
B
C
D
E
F
08
CM-127 BOARD (1/2)
CMOS IMAGER
XX MARK: NO MOUNT
DOAP
DOAM
DCKP
DCKM
DOBP
DOBM
CMOS_A_3.3V A_2.7V
INCK
A_2.7V
LVDS_I/O_1.8V
SCK
D_1.8V D_1.8V
R6808
XX
REG_GND
LVDS_I/O_1.8V
C6803
1u
C6805
1u
A_2.7V
CMOS_A_3.3V
DCKP
XCE
SDI
SCK
REG_GND
DCKM
A_2.7V
LVDS_I/O_1.8V
REG_GND
D_1.8V
R6812 XX
XCE
SDI
R6834 XX
SCK
C6840
0.1u
C6839
1u
C6807
1u
C6808
2.2u
C6809 0.1u
C6832
0.001u
C6833
0.1u
R6818
XX
R6809
XX
C6819
0.1u
R6814
XX
C6812
0.1u
C6828
2.2u C6830
1u
C6835
0.1u
C6836
0.1u
C6810 2.2u
C6825
2.2u
C6824
0.1u
R6815
XX
C6823
10u
C6814
0.001u
R6819 47k
D_1.8V
C6822
XX
R6832 1k
DOAP
DOAM
DOBP
DOBM
DCKP
DCKM
DOBM
DOBP
DOAM
DOAP
CMOS_A_3.3V
LF6802
XX
2
1
34
LF6803
XX
2
1
34
LF6804
XX
2
1
34
R6820
XX
C6827
10u
C6826
XX
CL6801
CL6802
CL6803
CL6804
C6842
0.001u
C6841
0.1u
CP003
IMX126CQL-13
M1
NC4
M2
NC4
L3
NC3
K3
NC3
M3
NC3
L2
NC4
M4
NC3
M5
NC3
M6
VDDLIO
M7
VSSLIO
K5
VDDLCN2
K4
VSSLCN1
K6
VDDLCN3
K7
VSSLCN2
L5
VDDLSC1
L4
VSSLSC1
L6
VDDLSC2
L7
VSSLSC1
M8
VDDSUB2
L8
TOUT
K8
TENABLE
L9
TSCANEN
M9
NC6
M10
NC5
L10
NC5
L11
NC5
M11
NC5
K9
XVS
J9
XHS
H9
SDO
G9
SDI
F9
SCK
E10
XCE
D10
XCLR
K11
VSSLIO
K10
NC6
J11
DOBM
J10
DOBP
H11
DCKM
H10
DCKP
G11
DOAM
G10
DOAP
F11
VSSLIO
F10
NC6
E11
VDDHCM2
D11
NC6
D9
VDDLCN4
E9
VSSLCN2
A11
NC7
C11
NC6
A10
NC7
B11
NC7
B10
NC7
C10
ASMON2
C9
ASMON1
B9
NC6
A3
VDDSUB1
A9
VDDSUB3
A7
VDDHDA
A8
VSSHDA
A5
VDDHPX
A6
VSSHPX
B7
NC6
B6
VLOADLM
B5
VEXRES
C5
VBGR
C7
NC6
C6
NC6
A4
NC2
C8
NC6
B8
NC6
C4
NC2
B4
NC2
B3
NC2
C3
NC2
A2
NC1
B2
NC1
C2
NC2
A1
NC1
B1
NC1
C1
NC2
D2
NC2
E2
NC2
E1
VDDHCM1
D1
NC2
G1
VDDHVS
F1
VSSHVS
H1
VDDHCP
H2
VSSHCP
F3
NC3
F2
VRL
G2
VCP
G3
NC3
H3
NC3
D3
VDDLCN1
E3
VSSLCN1
K1
VDDHPL
K2
VSSHPL
J1
NC3
J2
NC3
J3
INCK
L1
NC4
CN680533P
1REG_GND
2A_2.8V
3CMOS_A_3.3V
4LVDS_I/O_1.8V
5
D_1.8V
6
REG_GND
7REG_GND
8XCLR
9XCE
10SCK
11SDI
12SDO
13XHS
14XVS
15
REG_GND
16REG_GND
17DOAM
18DOAP
19REG_GND
20DCKM
21DCKP
22REG_GND
23DOBM
24DOBP
25REG_GND
26REG_GND
27CRESET_P
28PITCH_AD
29YAW_AD
30REG_GND
31REG_GND
32INCK
33REG_GND
CL6805
REG_GND
REG_GND
PITCH_AD
YAW_AD
CRESET_P
A_2.8V
SDO
SDO
MM3404A27URE
IC6802
1
CE
2
GND Vout
3
VDD
4
R6835
XX
COM680
1
A_2.7V_IMX102_VDDCM1/2
2
A_2.7V
2.7V REG
COMS IMAGER

6-3
HDR-CX190/CX190E/CX200/CX200E/CX210/CX210E/PJ200/PJ200E/PJ210_L3
30kHz/35kHz
SE7501
1
VCC
2
NC
3
NC
4
APOX
5
AFBX
6
AINX
7
OUTX
8
VREF
9
GND
10
OUTY
11
AINY
12
AFBY
13
APOY
14
SCT
15
VCC
16
NC
C7516
XX
CL7501
YAW_AD
R7515 470k
R7511
4700
GYRO_2.8V
REG_GND
L7501 10uH
R7514 470k
C7510
XX
R7513 10k
GYRO_2.8V
C7505 0.1u
R7520
XX
C7511
XX
R7508 470k
C7506 0.001u
C7513 10u
CMOS_A_3.3V
C7514
0.1u
REG_GND
C7507 0.001u
C7515
4.7u
CRESET_P
R7509 470k
R7512 10k
C7517
XX
R7510
4700
C7512 10u
R7521
XX
C7509 0.33u
C7508
0.33u
PITCH_AD
XX
IC7501
1
CE
2
GND
OUT
3
VDD
4
A_2.8V
(PITCH/YAW SENSOR)
12345 6 7 8 9
A
B
C
D
E
F
A
B
C
D
E
F
08
CM-127 BOARD (2/2)
PITCH/YAW SENSOR
XX MARK: NO MOUNT

6-4
HDR-CX190/CX190E/CX200/CX200E/CX210/CX210E/PJ200/PJ200E/PJ210_L3
FP-1483
FLEXIBLE
LND002
(PAGE 6-10)
XFLASH_RST
SENS_VD
SENS_HD
CLK_CMOS_IN_IMG
XBB_RST
XPJ_RESET
XBB_RST
FP-1481
FLEXIBLE
LND001
(PAGE 6-19)
FP-1557
FLEXIBLE
LND004
(PAGE 6-15)
FP-1482
FLEXIBLE
LND001
(PAGE 6-19)
FP-1556
FLEXIBLE
LND002
(PAGE 6-15)
Note: CONTROL SWITCH BLOCK (PS27800)
is not included in VC-651
COMPLETE BOARD (SERVICE).
Note: LENS BLOCK is replaced as block,
so that PRINTED WIRING BOARD and
SCHEMATIC DIAGRAM are omitted.
Projector Model
Non Projector Model
EXCEPT CX190/CX190E
CX190/CX190E/PJ200/PJ200E/PJ210
Note: BT901 and J1001 are not included
in VC-651 COMPLETE BOARD (SERVICE).
EXCEPT CX190/CX190E Projector Model
Projector Model
Non Projector Model
Note: MIC901 and SP901 are not included in
VC-651 COMPLETE BOARD (SERVICE).
EXCEPT CX190/CX190E
12345 6 7 8 9
A
B
C
D
E
F
A
B
C
D
E
F
08
VC-651 BOARD (1/11)
CONNECTORS
XX MARK: NO MOUNT
CN1002 33P
1REG_GND
2INCK
3REG_GND
4REG_GND
5YAW_AD
6PITCH_AD
7CRESET_P
8REG_GND
9REG_GND
10DOBP
11DOBM
12REG_GND
13DCKP
14DCKM
15REG_GND
16DOAP
17DOAM
18REG_GND
19REG_GND
20XVS
21XHS
22SDO
23SDI
24SCK
25XCE
26XCLR
27REG_GND
28REG_GND
29D_1.8V
30LVDS_I/O_1.8V
31CMOS_A_3.3V
32A_2.8V
33REG_GND
REG_GND
R1026
R1025
GENERAL_AD
D_2.8V
VD1004
COMPO_VIDEO
JACK_AD
REG_GND
C1011 470p
VD1007
LANC_SIG
LANC_DC
AUDIO_L_I/O
AUDIO_R_I/O
VD1008
C1010 470p
ACV_UNREG_CN
BATT_SIG
R1020
XX
BATT/XEXT_CN
R1017 220
VD1010
ACV_GND
BATT_GND
BATT_UNREG_CN
C1007 0.001u
C1006 0.001u
R1018
1k
D1001
RKZ12B2KJR1
COM102
1
REG_GND
2
BATT_GND
COM101
1
REG_GND
2
ACV_GND
AVDD18_SUBL
FB1006
FB1007
BATT_GNDACV_GND
REG_GND
D_1.8V
A_3.3V
AVOP_SENSXCS
AVOP_SENSSO
AVOP_SENSSCK
CN1010 2P
1SP+
2SP-
SP+
SP-
REG_GND
C1001
0.1u
XPANEL_POWER_ON
EVER_3.0V
R1001
1M
Q1001
DSC300100L
SE1001
4
OUT
1N.C.
2GND 3
VDD
ZM_SENSE_VCC
ZOOM_A
LENS_TEMP_AD
REG_GND
IRIS_DRIVE-
FOCUS_A
FOCUS_XB
FC_SENSE_OUT
IRIS_BIAS+
FOCUS_B
FOCUS_XA
IRIS_BIAS-
IRIS_HALL-
ZOOM_XB
IRIS_DRIVE+
CN100524P
1ZOOM_A
2ZOOM_XA
3ZOOM_XB
4ZOOM_B
5REG_GND
6LENS_TEMP_AD
7FC_SENSE_OUT
8FC_SENSE_VCC
9REG_GND
10ZM_SENSE_VCC
11ZM_SENSE_OUT
12REG_GND
13IRIS_DRIVE+
14IRIS_DRIVE-
15IRIS_BIAS+
16IRIS_HALL+
17IRIS_BIAS-
18IRIS_HALL-
19NC.
20REG_GND
21FOCUS_XA
22FOCUS_A
23FOCUS_XB
24FOCUS_B
IRIS_HALL+
ZM_SENSE_OUT
ZOOM_XA
ZOOM_B
AUDIO_GND
INT_MIC_R
INT_MIC_L
CN10116P
1AUDIO_GND
2AUDIO_GND
3INT_MIC_L
4AUDIO_GND
5AUDIO_GND
6INT_MIC_R
CN1004 10P
1
AUDIO_L
2LANC_SIG
3
S_GND
4
LANC_DC
5
S_C/D3_PB
6
AUDIO_R
7
MULTI_JACK_IN
8
VIDEO/AUDIO_GND
9
VIDEO/D3_PR
10
S_Y/D3_Y
HDMI_TX0SOP
SDA
HPD
HDMI_5V
HDMI_TX2SOP
HDMI_TXCN
HDMI_TX2SON
SCL
CEC
HDMI_TX0SON
HDMI_TXCP
HDMI_TX1SOP
CN1001
19P
1TMDS_DATA2_SHIELD
2TMDS_DATA2_+
3TMDS_DATA2_-
4TMDS_DATA1_SHIELD
5TMDS_DATA1_+
6TMDS_DATA1_-
7TMDS_DATA0_SHIELD
8TMDS_DATA0_+
9TMDS_DATA0_-
10TMDS_CLOCK_SHIELD
11TMDS_CLOCK_+
12TMDS_CLOCK_-
13DDC_CEC_GND
14CEC
15SCL
16SDA
21
22 20 23
17RESERVED
18+5V_POWER
19HPD
HDMI_TX1SON
REG_GND
R1043 1k
R1047
XX
MSX_BIO_1
TE0_DAT_0
TE0_DAT_3
TE0_SDWP
MSX_BIO_2
MSX_BS
MSX_INS_HIZ
R1044 1k
REG_GND
MSX_BIO_0
TE0_CMD
MSX_3.3V
MSX_CLK
TE0_DAT_2
TE0_XSDCD
TE0_CLK
TE0_DAT_1
TE0_VCC
MSX_BIO_3
LF1001
31
2
4
LF1002
31
2
4
LF1003
31
2
4
LF1004
31
2
4
VD1009
XX
VD1006
XX
S1001
1
2
3
4
REG_GND
S1003
1
2
3
4
FR_XRESET
REG_GND
KEY_AD2
D0+
XPJ_PARK
PJ_PWR_EN
BL_H
TP_SEL1
A_5.0V
CN1006 51P
1 PJ_TEMP_AD
2A_1.8V
3 REG_GND
4 AV_SCK
5 REG_GND
6 XBB_RST
7 AV_SO
8 XCS_LCD
9 XPJ_PARK
10 BL_L
11 BL_H
12 TP_X
13 TP_Y
14 TP_SEL1
15 REG_GND
16 A_5.0V
17 A_5.0V
18 A_5.0V
19 REG_GND
20 REG_GND
21 D_3.3V
22 SYSTEM_AD
23 PJ_PWR_EN
24 I2C_SCK
25 REG_GND
26 REG_GND
27 XPJ_RESET
28 I2C_SDA
29 PANEL_NOR/REV
30 D_1.8V
31 D_2.8V
32 EP_2.8V
33 REG_GND
34 D2+
35 N.C
36 D2-
37 REG_GND
38 D1+
39 N.C
40 D1-
41 REG_GND
42 REG_GND
43 REG_GND
44 CLK+
45 N.C
46 CLK-
47 REG_GND
48 D0+
49 N.C
50 D0-
51 REG_GND
TP_X
D0-
CLK-
CLK+
I2C_SCK
A_1.8V
PANEL_NOR/REV
PJ_TEMP_AD
REG_GND
D2+
I2C_SDA
BL_L
EP_2.8V
D1-
D1+
D_3.3V
TP_Y
D2-
LCD_XVD
LCD_DATA_5
LCD_CLK
PANEL_NOR/REV
LCD_XHD
LCD_DATA_7
BL_L
LCD_DATA_1
SYSTEM_AD
EP_2.8V
LCD_DATA_2
LCD_DATA_3
LCD_DATA_4
LCD_DATA_6
LCD_DATA_0
BL_H
KEY_AD2
CN1007 30P
1 BL_L
2 BL_H
3 EP_2.8V
4 KEY_AD2
5 TP_SEL1
6TP_Y
7TP_X
8 PANEL_NOR/REV
9SYSTEM_AD
10 AV_SCK
11 AV_SO
12 XCS_LCD
13 XBB_RST
14 REG_GND
15 LCD_B_0
16 LCD_B_1
17 REG_GND
18 LCD_B_2
19 LCD_B_3
20 REG_GND
21 LCD_B_4
22 LCD_B_5
23 REG_GND
24 LCD_B_6
25 LCD_B_7
26 REG_GND
27 LCD_CLK
28 REG_GND
29 LCD_VS
30 LCD_HS
XCS_LCD
AV_SO
AV_SCK
TE1_DAT_2
TE1_DAT_7
TE1_DAT_3
TE1_DAT_1
TE1_DAT_6
TE1_DAT_5
TE1_CMD
CN100818P
1MEDIA_3.3V
2MEDIA_3.3V
3MMC_PWR_ON1
4TE1_VCC
5
REG_GND
6TE1_CMD
7REG_GND
8TE1_CLK
9REG_GND
10TE1_DAT_3
11TE1_DAT_4
12TE1_DAT_0
13TE1_DAT_5
14TE1_DAT_1
15TE1_DAT_6
16TE1_DAT_2
17TE1_DAT_7
18REG_GND
TE1_DAT_0
REG_GND
TE1_DAT_4
TP_X
TP_SEL1
TP_Y
REG_GND
DEBUG_UART0_RXD
BOOT_MODE_1
D_2.8V
CN10126P
1REG_GND
2DEBUG_UART0_TXD
3DEBUG_UART0_RXD
4BOOT_MODE_1
5D_2.8V
6N.C.
DEBUG_UART0_TXD
A_2.8V
PITCH_AD
YAW_AD
CRESET_P
SUBL_DINN7
SUBL_DINP7
SUBL_CLKINN
SUBL_CLKINP
SUBL_DINN6
SUBL_DINP6
CN1009 14P
1 REG_GND
2 START_STOP
3 CHARGE_LED_VDD
4 XCHARGE_LED
5 XPHOTO_LED
6 MODE_LED_VDD
7 XCAM_LED
8 XMODE_SW
9 REG_GND
10 PHOTO_FREEZE
11 PHOTO_REC
12 REG_RND
13 ZOOM_VR_AD
14 D_2.8V
REG_GND
R1004
1k
VD1005
XX
D1002
XX
XCAM_LED
R1005
2700
XPHOTO_LED
SS
R1003
75
XCHARGE_LED
ZOOM_VR_AD
D_2.8V
EVER_3.0V
R1007
6800
KEY_AD1
REG_GND
TE1_CLK
ZM_SENSE_VCC
AV_SO
XCS_LCD
AV_SCK
D_1.8V
D_2.8V
R1052
XX
R1051
XX
R1050
XX
R1049
XX
R1054
XX
R1053
XX C1012
0.1
C1013
0.1
CN1013 3P
1BATT_UNREG
2BATT_SIG
3BATT_GND
J1001 HOT
2
SW
3
1COLD
R1008 3.3
R1009 3.3
R1010 3.3
R1011 3.3
R1012 3.3
R1013 3.3
R1014 3.3
R1015 3.3
SYSTEM_AD
D_2.8V
R1055 XX
R1056 XX
R1057 XX
R1058 XX
D_1.8V
AVOP_SENSSI
R1059
1k
XMS_ACC_LED
D1003
CL-271HR-C-TS
D_2.8V
IC1001
1
2DIR
2
1A1
3
1A2
4
2A1
5
2A2
6
GND
7
GND
8
2B2
9
2B1
10
1B2
11
1B1
12
2OE
13
1OE
14
VccB
15
VccA
16
1DIR
S1002
1
2
3
4
KEY_AD3
REG_GND
VD1013
XX
MEDIA_3.3V
MMC_PWR_ON1
TE1_VCC
SE1002
4
OUT
1N.C.
2GND 3
VDD
CN101433P
1REG_GND
2REG_GND
3TE0_VCC
4TE0_VCC
5TE0_SDWP
6TE0_XSDCD
7REG_GND
8TE0_DAT_1
9TE0_DAT_0
10TE0_DAT_2
11TE0_DAT_3
12REG_GND
13
REG_GND
14MSX_3.3V
15MSX_3.3V
16REG_GND
17REG_GND
18TE0_CLK
19REG_GND
20REG_GND
21MSX_CLK
22REG_GND
23MSX_INS_HIZ
24REG_GND
25MSX_BIO_2
26MSX_BIO_3
27MSX_BIO_1
28MSX_BIO_0
29REG_GND
30MSX_BS
31TE0_CMD
32N.C
33BATT_LI_3V BATT_LI_3V
FB1008
R1006
150
SWITCH
BLOCK
CONTROL
(PS27800)
LENS
BLOCK
PANEL
OPEN/CLOSE
SENSOR
PANEL
OPEN/CLOSE
SENSOR
INVERTER
s
BT901
TERMINAL
BATTERY
DC IN
TC7MP3125F
LEVEL SHIFT
PROJECTOR
RESET
0: CX200/CX200E/CX210/CX210E
47k: PJ200/PJ200E/PJ210
0: CX190/CX190E
100k: PJ200/PJ200E/PJ210
(MS ACCESS)
HDMI OUT
(SPEAKER)
SP901 (MICROPHONE UNIT)
MIC901
(CPC)
A/V R
REG_GND

6-5
HDR-CX190/CX190E/CX200/CX200E/CX210/CX210E/PJ200/PJ200E/PJ210_L3
XPJ_RESET
SENS_VD
SENS_HD
CLK_CMOS_IN
XBB_RST
XSYS_RST
CLK_SYS_IN
CLK_SYS_IN
CLK_CMOS_IN_IMG
CLK_CMOS_IN
Note: IC1301 is not supplied, but this is included
in VC-651 COMPLETE BOARD (SERVICE).
12345 6 7 8 9
A
B
C
D
E
F
A
B
C
D
E
F
08
VC-651 BOARD (2/11)
CPU, AV SIGNAL PROCESS, LENS CONTROL,
MODE CONTROL, HDMI PROCESS (1/3)
XX MARK: NO MOUNT
REG_GND
XPJ_PARK
ZM_DIR_A
ZM_DIR_B
ZM_ENB
FC_LENSV_DIR_B
FC_LENSV_DIR_A
FC_LENSV_ENB
R1313 XX IC_1301_SENSSCK
IC_1301_SENSSO
IC_1301_SENSXCS
REG_GND A_2.8V
REG_GND
L1301 XX
C1323
0.1u
C1326
0.01u R1331 270
REG_GND
R1320 XX C1314
10u
REG_GND
A_1.125V
A_1.8V
C1313
10u
HDMI_TX0SON
HDMI_TX2SOP
HDMI_TX2SON
HDMI_TXCN
HDMI_TXCP
HDMI_TX1SOP
HDMI_TX1SON
HDMI_TX0SOP
REG_GND
R1321
6800
REG_GND
A_3.3V
REG_GND
R1307 XX
USB_VBUS
USB_ID
R1315
180
VBUS_EN
VBUS_UNLIMIT
SUBL_DINN6
SUBL_DINP6
SUBL_DINP7
SUBL_DINN7
SUBL_CLKINP
SUBL_CLKINN
USB_ID2
REG_GND
R1335 1k
XRESET_REQ
REG_GND
REG_GND
R1302
XX
A_1.125V
Q1302
SSM6N37FE,RSONYM
6
1
52
4
3
Q1301
SSM3K37MFV,L3SOF
HDMI_5V
R1343
1800
R1342
1800
SCL
SDA
CEC
REG_GND
A_1.8V R1303 XX
AVDD18_SUBL
A_1.125V
R1318
XX
REG_GND
REG_GND
USB_DM
USB_DP
C1305
XX
C1306
0.1u
REG_GND
C1301
10u C1304
0.1u C1310
0.1u
C1302
10u
C1307
0.1u
C1308
0.1u
C1309
0.1u
REG_GND
C1316
0.1u
C1317
0.1u
REG_GND
C1320
0.1u C1322 0.1u
C1318
0.1u
C1315
0.1u
REG_GND
R1332 27k
C1321
0.1u
C1325
0.1u
A_1.125V_SENSE
C1303
10u
AL21 AVDD_DAC_0
AK23 AVDD_DAC_1
AL23 AVDD_DAC_2
AK21 AVSS_DAC_0
AJ21 AVSS_DAC_1
AJ23 AVSS_DAC_2
AL25 DVDD_DAC_0
AK25 DVSS_DAC_0
M1 IOVDD_AUMIC
L1 VSS
AL16 AVDD18_HDMI
AK16 AVDD_HDMI
AL9 AVDD_HDMI
AK9 AVDD_HDMI
AJ9 AVDD_HDMI
AL15 AVSS_HDMI
AK15 AVSS_HDMI
AJ15 AVSS_HDMI
AJ14 AVSS_HDMI
AL10 AVSS_HDMI
AK10 AVSS_HDMI
AJ11 AVSS_HDMI
AJ16 IOVDD_HMI2C
AH1 IOVDD_MERGE2
AJ1 VSS
AF1 IOVDD_CLK_SYS
AE3 VSS
AF31 AVDD_PLL0
AF30 AVDD_PLL1
AF29 AVDD_PLL1
AF26 AVDD_PLL2
AF25 AVDD_PLL2
AK24
DAC_IOUTN_A_Pr
AL24
DAC_IOUTP_B_Pb
AJ25DAC_IOUTN_B_Pb
AK26DAC_IOUTP_C_Y
AL26DAC_IOUTN_C_Y
M6DIG_MIC_CLK
M2SDI3
M3SDI2
AL11HDMI_TX2SOP
AK11
HDMI_TX2SON
AL12
HDMI_TX1SOP
AK12
HDMI_TX1SON
AL13
HDMI_TX0SOP
AK13HDMI_TX0SON
AL14HDMI_TXCP
AK14HDMI_TXCN
AJ12
HDMI_CKREFP
AJ13
HDMI_CKREFN
AJ10HDMI_REXT
AF13HDMI_SDA
AF14HDMI_SCL
AF15CEC_INOUT
AJ8TPU5_OUT
AK7TPU4_OUT
AL7
TPU3_OUT
AJ6TPU2_OUT
AK6TPU1_INA_OUT
AL6TPU1_INB
AJ7TPU0_INA_OUT
AF9TPU0_INB
AF10FRC_RTG_IN1
AD10FRC_RTG_IN0
AA10FRC_RTG_OUT3
AB10FRC_RTG_OUT2
AE10
FRC_RTG_OUT1
AE9FRC_RTG_OUT0
AD15
EXTIN_CLK2
AD16
EXTIN_CLK1
AE16EXTIN_CLK0
AA13
EXTOUT_CLK1
AB13EXTOUT_CLK0
AB18
BONOBO_PANDA_CLK
AD14BYPASS_PLL_1
AA14
BYPASS_PLL_0
AB15PLL_MODE_0
AA15DDRCKSEL
AB14
PLL3_FREQ_SEL
AH3XRESET_REQ
AH2XRESET
AF3TEST_MODE
AB12DEBUG_MODE_2
AD12
DEBUG_MODE_1
AE12DEBUG_MODE_0
AA16
BOOT_MODE_2
AB16
BOOT_MODE_1
AA17BOOT_MODE_0
AF2CLK_SYS_IN
AD1
AVDD_PLL3
AD2
AVDD_PLL4
AE1
AVSS_PLL3
AE2
AVSS_PLL4
AJ22DAC_VREF
AK22DAC_IREF
AL22
DAC_VBP
AJ24
DAC_IOUTP_A_Pr
AE25 AVSS_PLL2
AE30 AVSS_PLL1
AE26 AVSS_PLL2
AE31 AVSS_PLL0
AE29 AVSS_PLL1
C1324
220p
CL1306
CL1307
CL1308
BOOT_MODE_1
REG_GND
SD_PWR_ON
REG_GND
REG_GND
REG_GND
REG_GND
R1306 XX
A_2.8V A2.8V_IC_1301_1
A2.8V_IC_1301_1
D_2.8V_IC_1301_2
D_2.8V D_2.8V_IC_1301_1
D_2.8V_IC_1301_1
D_2.8V_IC_1301_1
D_2.8V_IC_1301_2
D_2.8V_IC_1301_2
D_2.8V_IC_1301_2
D_1.8V_IC_1301_3
D_1.8V_IC_1301_2
D_1.8V D_1.8V_IC_1301_1
D_1.8V_IC_1301_1
D_1.8V_IC_1301_2
C1339 0.1u
REG_GND
R1360 XX
IC1302
AK8153AU-L
1
12M
2
SEL
3
ICLK
4
REF
5
GND
6
VDD
C1340 10u
A_1.8V
X1302
60MHz
D_3.3V
COM131
1
A_1.125V_AVDD11_SUBL
2
A_1.125V_SENSE
R1362 47
COM137
1
A_2.8V
2
A_2.8V_AVIP1
COM138
1
A_1.125V_AVDD11_SUBL
2
A_1.125V
COM139
1
A_1.8V
2
AVDD18_SUBL
R1319 XX
R1340
XX
C1327
XX
C1319
XX
ZM_SENSE_OUT
SHUTTER_ON
IRIS_PWM
CRESET_P
DAC_STRB
FC_SENSE_OUT
COMPO_VIDEO
R1367
82
1/16W
RB1301
4700
12 34 56 78
D1305
RB480Y-40T2R
41 3
2
FB401
IRIS_MD_BRAKE
A20 AVDD_PI
B20 AVSS_PI
A19 IOVDD_PI
C13 VSS
A14 IOVDD_MERGE1
B13 VSS
V29 AVDD11_SUBL
W29 AVDD11_SUBL
Y29 AVDD11_SUBL
AB31 AVDD11_SUBL
AB30 AVDD11_SUBL
L29 AVDD18_SUBL
K29 AVDD18_SUBL
J29 AVDD18_SUBL
H31 AVDD18_SUBL
H30 AVDD18_SUBL
M29 VSS
N29 VSS
P29 VSS
R29 VSS
T29 VSS
U29 VSS
AC31 IOVDD_CMOSSIO
Y26 VSS
AD31 IOVDD_CLKCMOS
AD29 VSS
AK17 AVDD33_USB
AL17 AVDD33_USB
AJ19 AVSS33_USB
AK19 AVSS33_USB
AL19 AVSS33_USB
AF17 AVSS33C_USB
AF16 IOVDD_USBPERI
AJ17 VSS
AE17 VSS
C19SENS2
B19SENS0
F19FG1A
C20FG1B
AD18SYS_V
AD17CAM_V
AB17PANDA_VD
G19MSHUT_EN
F18STRB_ON2_MSHUT_EN2
G18STRB_ON3_MSHUT_EN3
H19STRB_ON1
C17DIR2A
C18DIR2B
A15BRK2A_EN2
B15BRK2B
C15DIR1A
C16DIR1B
B14BRK1A_EN1
C14BRK1B
F16DIR0A
F17DIR0B
G14BRK0A_EN0
F14BRK0B
F15SENS1A
G15SENS1B
H18ND_DIR_A
H17ND_DIR_B
G17
ND_EN
B16IRIS0_BONOBO2_P_LIMIT
A16IRIS1
H16AS_PWM1A
G16AS_PWM1B
H14AS_PWM0A
H15AS_PWM0B
AA31SUBL_DINP11
AA30SUBL_DINN11
Y31SUBL_DINP10
Y30SUBL_DINN10
W31SUBL_DINP9
W30SUBL_DINN9
V31SUBL_DINP8
V30SUBL_DINN8
U31SUBL_DINP7
U30SUBL_DINN7
T31SUBL_DINP6
T30SUBL_DINN6
P31SUBL_DINP5
P30SUBL_DINN5
N31SUBL_DINP4
N30SUBL_DINN4
M31SUBL_DINP3
M30SUBL_DINN3
L31SUBL_DINP2
L30SUBL_DINN2
K31SUBL_DINP1
K30SUBL_DINN1
J31SUBL_DINP0
J30SUBL_DINN0
R31SUBL_CLKINP
R30SUBL_CLKINN
AC30SENS_VD
AC29
SENS_HD
AB29
SENSSCK
U26SENSSO
AA29
SENSSI
V26
SENSXCS
W26
CIS_SHT_RST
AD30
CLK_CMOS_IN
AJ18USB_TXRTUNE
AJ20
USB_VBUS
AF18
USB_ID
AL18USB_DP
AK18USB_DM
AE18USB_XO
AE19USB_XI
AF19USB_ANALOGTEST
AE21VBUS_EN
AD19
VBUS_UNLIMIT
AD20
USB_ID_EXT
AD21USB_CHG_EN
AF20USB_CHG_HL
AF21
USB_PWR_EN
AE20USB_ACV_DET
IC_1301_SENSSI
LF1301
XX
3
1
24
COM133
1
D_2.8V
2
D_2.8V_AVIP2
COM132
1
D_2.8V_AVIP1
2
D_2.8V
COM134
1
D_1.8V_AVIP1
2
D_1.8V
COM135
1
D_1.8V
2
D_1.8V_AVIP2
COM136
1
D_1.8V
2
D_1.8V_AVIP3
GPIO_SB_4
XCS_ACO
R1371
XX
Q1303
XX 1
2
3
REG_GND
R1373
XX
C1343
XX
L1302
XX
C1341
XX
COM140 1
GPIO_SB_4
2
XCS_ACO
R1304
0
PIsensor
DEVICE_SYNC
BEAR/ETC
USB PERI
subLVDS
USB
CMOS I/O
VDAC
HDMI
FRC_RTG
PLL
CMOS CLK IN
Digital MIC
HDMI LINK
TPU
SYSTEM
SYS CLK
MODE CONTROL,
AV SIGNAL PROCESS,
LENS CONTROL,
IC1301 (1/6)
AVY1G2G04B
HDMI PROCESS
HDMI PROCESS
MODE CONTROL,
AV SIGNAL PROCESS,
LENS CONTROL,
IC1301 (2/6)
AVY1G2G04B
Q1301, Q1302
LEVEL SHIFT
CLOCK GENERATOR
