Sony XCL5005CR User manual

Technical Manual
A-CY5-100-11 (1)
Digital Video
Camera Module
© 2008 Sony Corporation
XCL-5005CR
XCL-5005

Table of Contents
2
Table of Contents
Overview
Features .................................................................. 3
Typical CCD Phenomena ..................................... 4
System Components .............................................. 5
Connection ............................................................. 6
Location and Function of Parts and Operation
.................................................................................. 7
Front/Top/Bottom ............................................... 7
Using a tripod ..................................................... 7
Rear .................................................................... 8
Connecting the cables ........................................ 9
Trigger signal specifications .............................. 9
DVAL/Exposure output specific (only DC IN
terminal) ......................................................... 10
Functions
1. CCD loaded on XCL-5005CR/5005 ..............11
2. Compatibility with previous model XCL-5000
...........................................................................12
3. Video output format .......................................13
3.1. Switching TAP ........................................13
3.2. Color pixel array .....................................13
3.3. Data order ...............................................14
3.3.1. 1TAP 80 MHz .................................... 14
3.3.2. 2TAP 40 MHz .................................... 14
3.4. Port assignment .......................................15
3.5. Output data size ......................................15
4. Camera mode ..................................................16
4.1. Horizontal timing ....................................16
4.2. Vertical timing .........................................17
4.2.1. Normal mode ..................................... 17
4.2.2. Binning mode ..................................... 17
4.2.3. Partial scan mode ............................... 18
4.2.4. Trigger mode ...................................... 21
4.2.5. Trigger binning mode ......................... 22
4.2.6. Trigger partial scan mode ................... 23
5. Shutter setting ................................................25
5.1. Preset shutter ...........................................25
5.2. Arbitrary shutter setting ..........................26
5.3. Overlap ....................................................27
5.4. WEN-STRB ............................................27
6. DSP Operation ................................................28
6.1. Signal processing block chart .................28
6.2. Flip-flop [XCL-5005] ...............................29
6.3. Digital clamp [XCL-5005CR] [XCL-5005]
.................................................................29
6.3.1. Clamp setting value ............................ 29
6.3.2. Correlation factor ............................... 29
6.4. Digital gain [XCL-5005] ..........................29
6.5. Pixel gain [XCL-5005CR] .........................29
6.5.1. Definition equation ............................ 29
6.5.2. White balance ..................................... 30
6.6. Black balance [XCL-5005CR] ..................30
6.6.1. Black balance automatic adjustment
method ................................................ 30
6.6.2. Black balance direct adjustment method
............................................................. 30
6.7. Gamma correction [XCL-5005CR]
[XCL-5005] .............................................. 31
6.7.1. Arbitrary setting method .................... 31
6.7.2. Five-point approximate linear
interpolation ....................................... 31
6.7.3. Coefficient input method .................... 32
6.8. 3 × 3 filter [XCL-5005] ............................ 33
6.8.1. Mode 1 ............................................... 33
6.8.2. Mode 2 ............................................... 34
6.9. Edge detection/enhancement (DTL)
[XCL-5005] .............................................. 35
6.10. Binarization [XCL-5005] ......................... 36
6.11. Digital pedestal [XCL-5005CR] [XCL-5005]
................................................................. 37
6.12. 8/10/12 bit length selection [XCL-5005CR]
[XCL-5005] .............................................. 37
6.13. Grayscale chart [XCL-5005] .................... 37
6.14. Color chart [XCL-5005CR] ...................... 38
Camera Control Commands
General ..................................................................39
Serial Communication Specifications ...............39
Command system .............................................39
Command format ..............................................39
Command input and response ...........................39
Command Specification ......................................40
Camera control commands ...............................40
AFE Setting Command .....................................40
DTL/Binarization Setting Command (XCL-5005
only) ................................................................41
WB Setting Command (XCL-5005CR only) ...41
AJ Setting Command (XCL-5005CR only) .....42
Digital Setting Command .................................43
Gamma Setting Command ................................43
Filter Setting Command (XCL-5005 only) ......44
Binning / Partial Setting Command ..................44
IN/OUT Setting Command ...............................44
Setting Value Control Command ......................45
Setting Initialization Command ........................45
Save Setting Command .....................................45
Read Setting Command ....................................45
Setting Value Accession Command ..................46
Others ................................................................48
Command Limitation ........................................48
Command List ......................................................49
Parameter List ......................................................51
Information ...........................................................52
Specifications
Specifications ........................................................53
Spectral Sensitivity Characteristics (Typical
Values) ...................................................................54
XCL-5005CR/5005 Dimensions ..........................55

Overview
Features 3
Overview
The XCL-5005CR/5005 is a digital video camera
module. This camera module outputs digital images
utilizing LVDS via the digital interface connector.
XCL-5005CR: Color digital video camera module
XCL-5005: Black and white digital video camera
module
Features
Digital interface connector
Equipped with a Camera Link standard small connector.
The XCL-5005CR/5005 can output a digital image at 15
frames per second.
Supports the camera link PoCL standard
The XCL-5005CR/5005 supports the PoCL (Power over
Camera Link) standard. By connecting a PoCL-
compatible camera link cable to a PoCL-compatible
camera module interface board, you can power, control,
and output images from the camera using a single cable.
This module is also provided with a DC IN connector
like that of the XCL-5000 to enable you to use a power
adaptor and a camera module interface board without
support for PoCL (non-PoCL) to operate the camera in
the same manner as previously.
High image quality
The XCL-5005CR/5005 has a progressive scan CCD of
5,000,000 pixels. Both cameras produce high-resolution
images. By adopting square pixels, images can be
processed using the original aspect ratio without a
converting procedure.
Various mode settings
Sending a command from the host device allows the
following mode settings.
•Gain
• Read mode: normal/binning (XCL-5005 only)
• Partial scan
• Shutter: Normal/Trigger shutter
• Shutter speed
• Gamma
• Switching an output Bit Length
• Switching an output tap
• White balance (XCL-5005CR only)
• Switching color output: RAW data/RGB data (XCL-
5005CR only)
• Edge detection, Edge enhancement (XCL-5005 only)
• Binarization (XCL-5005 only)
Electronic shutter function
Shutter speed can be selected from variety of available
speeds.
External trigger shutter function (2 to
1/10000 s)
You can obtain a still picture by inputting an external
trigger. This function is useful to shoot a fast-moving
object clearly.
Partial scan
The camera module can limit the number of the actual
video output lines to achieve high frame rates, enabling
high-speed image processing.
Body fixing
The screw holes to install the camera module are located
under the front panel (the CCD reference plane).
Installing the camera module on the front panel
minimizes deviation of the optical axis.
Gamma
You can switch to OFF or ON.
When you switch to ON, you can select from various
modes, and draw not only the default gamma line but
also an original gamma curve.
Switching an Output Bit Length
You can select 12 bit output, 10 bit output, or 8 bit
output.
Switching an Output Tap
You can select 1TAP output or 2TAP output.
When you select 2TAP output, the clock frequency for
data transfer becomes half, so you can extend the cable
length and use a camera module interface board with a
low clock frequency.
Switching color output (XCL-5005CR
only)
You can select RAW data output for outputting the
information of each pixel of the CCD unmodified and
RGB data output for outputting RGB data obtained by
processing signals within the camera to convert the
information to RGB data.
When RGB data output is selected, 2TAP output is
unavailable. The output bit length is limited to 8 bits.
Binning (XCL-5005 only)
By “binning” two pixels that align vertically, you can
acquire a frame rate twice as high as that in the normal
mode.
Edge detection, Edge enhancement
(XCL-5005 only)
Edge detection detects an edge from a picture, and
outputs an image made of the edge only.
Edge enhancement outputs a clear image emphasized on
the edge.

Overview
Typical CCD Phenomena
4
Binarization (XCL-5005 only)
Outputs an binarized image. Sensitivity can be changed.
Note
The CCD is driven at high speed during a Partial scan or
Binning operation. In this situation, if intense light is
input to the camera, the peripheral areas of the video
image may be affected. In such a situation, adjust the
amout of light using the iris.
Note
(XCL-5005CR only)
Some fading will occur with the color filter of the color
CCD after prolonged exposure to bright light. In
addition, some variation may occur in the spectral
sensitivity characteristics of the built-in infrared-cut
filter for reasons such as change over time. The above
factors may result in variation in coloring after extensive
use of the camera, but this does not indicate a
malfunction.
In such cases, simply readjust the white balance.
Typical CCD Phenomena
The following effects on the monitor screen are
characteristic of CCD cameras. They do not indicate any
fault with the camera module.
Smear
This occurs when shooting a very bright object such as
electric lighting, the sun, or a strong reflection.
This phenomenon is caused by an electric charge
induced by infrared radiation deep in the photosensor. It
appears as a vertical smear, since the CCD imaging
element uses an interline transfer system.
Vertical aliasing
When you shoot vertical stripes or lines, they may
appear jagged.
Blemishes
A CCD image sensor consists of an array of individual
sensor elements (pixels). A malfunctioning sensor
element will cause a single pixel blemish in the picture
(This is generally not a problem.).
White speckles
While CCD image pickup device is made by an accurate
technique, imperceptible speckless may rarely come up
on the screen due to cosmic rays and so on. This is
connected to the principle of CCD image pickup device,
not a malfunction. And the white speckless are easy to
come up in the following conditions.
• Using the camera in high temperature
• When turning up the gain
Level difference between left and right
As CCD used in this camera adopts the left-right 2 ch
output system, left half and right half of the image area
are output individually. Sometimes a level difference
may appear in the center of the window according to the
setting mode of the camera. This is not a malfunction.
Note
If strong light enters a wide area of the screen, the screen
may become dark. This is not a malfunction.
If this occurs, avoid strong light or adjust the lens iris to
reduce the light amount.

Overview
System Components 5
System Components
Video Camera Module
XCL-5005CR/5005
Camera cable
CCXC-12P02N (2 m, 6.6 ft)
CCXC-12P05N (5 m, 16.4 ft)
CCXC-12P10N (10 m, 32.8 ft)
CCXC-12P25N (25 m, 82 ft)
C-mount lens
High-resolution lens
Camera adaptor
DC-700/700CE
Tripod adaptor
VCT-ST70I (Insulated type)
Camera Link cable
(Sony Camera-compatible)
Camera module interface
board
Install the board in a PCI bus slot in devices such as a computer. Select a commercially available interface
board compatible with the Camera Link feature. You can use either a board that supports PoCL, or one
that does not.
In the board corresponding to PCI 32 bit, the frame rate may become low according to lack of processing
capacity. When you want to make this product output 15 frames per second, use a board corresponding
to more than PCI 64 bit (PCI-X).
When you use XCL-5005CR with RGB data output, the frame rate may become low because of insufficient
processing capacity even if you use a PCI 64 bit compatible board. If you want to output 15 frames of
images every second, use a PCI Express board. Performance may also be dependent on the host device
(e.g., Computer), so consult the dealer if images are not displayed properly.
This cable connects to the digital interface connector on the rear panel of the camera module. Image/
control signals are transmitted via this cable.
If there is support for PoCL, power is also supplied at the same time. If you use a camera module interface
board with support for PoCL, be sure to use a camera link cable with support for PoCL. You can use a
single cable up to 7 meters long in the case of 1TAP output, and extend the cable length even further in
the case of 2TAP output. Select a proper cable as the maximum usable length of a cable differs due to the
attribute of each cable.
Spotted noise may appear in a specific brightness in the window according to the attribute of the cable. If
this noise is an obstacle, shorten the cable.

Overview
Connection
6
Connection
C-mount lens
Tripod adaptor
VCT-ST70I
Camera cable
CCXC-12P02N
CCXC-12P05N
CCXC-12P10N
CCXC-12P25N
Camera adaptorDC-700/700CE
(Conforms to EIAJ 12-pin assignments)
AC
TRIG
Digital interface cable
Camera module interface board
XCL-5005CR/5005
Power supply
You can supply power to the XCL-5005CR/5005 using the following methods.
Using the DIGITAL IF (interface) connector
The XCL-5005CR/5005 supports the PoCL (Power over Camera Link) standard. By connecting a PoCL-compatible camera link cable to
a PoCL-compatible camera module interface board, you can power, control, and output images from the camera using a single cable.
Using the DC IN connector
You can supply power via the DC IN connector using the power adapter.
Use DC-700/700CE which is the stable power source free from ripple or noise.
When both the DIGITAL IF and DC IN connectors are used, the power supply from the DC IN connector is given priority.
*If the camera module interface board for the camera supports PoCL, the
camera can be operated even if the items within the dashed line are not
connected.

Overview
Location and Function of Parts and Operation 7
Location and Function of Parts and Operation
Front/Top/Bottom
aLens mount (C-mount)
Attach any C-mount lens or other optical equipment.
Note
The lens must not project more than 10 mm (13/32 inch)
from the lens mount.
When you use the camera with the lens attached, the
resolution of the image output from the camera may
differ according to the performance of the lens. Note it
when you select a lens.
The performance of a lens may change according to the
aperture level.
If the resolution is not enough, adjust the aperture level.
bGuide holes (Top)
cReference holes (bottom)
These precision screw holes are for locking the camera
module. Locking the camera module into these holes
secures the optical axis alignment.
You can install the camera on a tripod. To install on
a tripod, you will need to install a tripod adaptor
VCT-ST70I to the camera on the reference holes
c.
Note
Refer to XCL-5005CR/5005 Demensions in page 55 for
about the position/size of the Guide hole and the
Reference hole.
Using a tripod
To use the tripod, install the tripod adaptor VCT-ST70I
(not supplied) on the camera module.
Use a tripod screw with a protrusion (4) extending from
the installation surface, as follows, and tighten it, using
a screwdriver. Be sure that the protrusion does not
exceed 5.5 mm (0.2 in.) in length.
ISO standard 4: Length 4 to 5 mm
ASA standard 4: Length 0.16 to 0.20
inches
Note
If you install a tripod adapter (not supplied), use the
screws provided.
a
b
c
Lens mount (C-mount)
Guide holes (Top)
Reference holes (bottom)

Overview
Location and Function of Parts and Operation
8
Rear
dDC IN (DC power input) connector (12-pin)
You can connect a camera cable CCXC-12P05N etc. to
input the +12 V DC power supply. The pin configuration
of this connector is as follows. You can operate the
camera without using this connector when using a
PoCL-compatible camera module interface board.
For details on the pin arrangement, see the following
table.
* Signal output from the Tenth pin of 12 pins
connector
You can select one of the following signals according
to the setting.
Ground / DVAL output / Exposure pules output
The default setting in the factory is Ground.
eDIGITAL IF (Interface) connector (26-pin)
Camera Link Base Configuration: 1TAP/2TAP
You can connect a Camera Link cable to this connector
to control a camera module from a host device utilizing
the serial communication protocol while outputting a
video signal from the camera module. If you use a
camera module interface board with support for PoCL,
you can also supply power from this connecter. You can
input the external trigger signal via the 26-pin connector
and operate a camera module in the external trigger
mode. The output system allows you to change the
output tap, and you can select from 1TAP and 2TAP.
When setting the output tap, you need to set the camera
module interface board and change the file when you
change the camera settings. When images are not
displayed correctly, refer to the user’s manual and other
documentation for the camera module interface board,
and check the settings.
The following table shows the relation between the pin
numbers of the digital interface connector and the input/
output signals and the like.
* About the 1st pin and 26th pin of the 26-pin
connector
The connection differs depending on the type of
camera module interface board you use.
In the case of PoCL support:
Both the 1st pin and 26th pin are
POWER (power supply)
ed
dDC IN (DC power input) connector (12-pin)
eDIGITAL IF (Interface) connector (26-pin)
Pin No. Signal Pin No. Signal
1 Ground 7 NC
2 +12 V DC 8 Ground
3 Ground 9 NC
4 NC 10 Signal output*
5 Ground 11 Triger pulse input
6 NC 12 Ground
Pin No. Signal Pin No. Signal
1 Power supply or
Ground*14 INNER_SHIELD
(Ground)
2 X0– output
(Signal)
15 X0+ output (Signal)
3 X1– output
(Signal)
16 X1+ output (Signal)
4 X2– output
(Signal)
17 X2+ output (Signal)
5 XCLK– output
(Signal)
18 XCLK+ output
(Signal)
6 X3– output
(Signal)
19 X3+ output (Signal)
7 Ser TC+ (Signal) 20 Ser TC– (Signal)
8 Ser TFG– (Signal) 21 Ser TFG+ (Signal)
9 TRIG– input
(Signal)
22 TRIG+ input
(Signal)
10 NC 23 NC
11 NC 24 NC
12 NC 25 NC
13 INNER_SHIELD
(Ground)
26 Power supply or
Ground*

Overview
Location and Function of Parts and Operation 9
In the case of non-PoCL support:
Both the 1st pin and 26th pin are
INNER_SHIELD (Ground)
Note
When you operate a camera module by inputting an
external trigger signal via the 26-pin connector, make
sure to input external trigger signals that meet the
following specifications to both the two pins.
Specifications for the External Trigger Signal
Amplitude: LVDS using a 3.3 volt IC
Connections: Input a TRIG (–) signal to the 9th
pin.
Input a TRIG (+) signal to the 22nd
pin.
Polarity: Positive
Connecting the cables
Connect the camera cable to the DC IN connector and
the Camera Link cable to the digital interface cable
respectively. If you use a camera module interface board
with support for PoCL, you can operate the camera even
if you do not connect the camera cable to the DC IN
connector. When you connect the Camera Link cable,
turn the two fastening screws on the connector to secure
the cable tightly.
Connect the other end of the camera cable to the DC-
700/700CE and the other end of the Camera Link cable
to the camera module interface board.
Note
When using the camera with a PoCL connection, make
sure you connect a PoCL compatible cable. Connecting
a cable that is not compatible with PoCL (non-PoCL)
may cause a malfunction of the camera or camera
module interface board.
Controlling the camera from the host
device
You can control the camera from host device such as a
computer. The following table shows the control
functions.
You can send a command corresponding to the control
items, with parameters for the desired settings, if
necessary, from the host device to control the camera.
Refer to “Camera Control Commands” on page 39 for
details on how to send a command, the commands, and
their parameters.
Note
Make sure to supply power to the camera module and
confirm that the camera module is operating before
inputting a trigger signal. If you input trigger signal to a
camera module without the power supplied, this may
cause a mulfunction of the camera module.
Trigger signal specifications
Input impedance: Stated in the voltage determined at
more than 10 k ohms
b
a
c
d
e
Digital interface connector
Camera Link cable
Fastening screws
DC IN
connector Camera cable
Control functions Description
Operating mode Normal/Trigger
Shutter speed Normal 2 to 1/10000 s
Trigger edge 2 to 1/10000 s
Trigger pulse
width
Setting by
trigger pulse
width
Gain 0 to +18 dB
Partial Scan OFF/ON
Gamma control OFF/ON (Mode 1 to 7)
External trigger input 26 pin connector/12 pin connector
Video output switch 12 bits/10 bits/8 bits
Swtich output tap 1TAP/2TAP
White balance
(XCL-5005CR only)
PRESET/MANUAL/ONE PUSH
(AUTO)
Switch color output
(XCL-5005CR only)
RAW data/RGB data
Binning (XCL-5005 only) OFF/ON
Edge detection, Edge
enhancement (XCL-5005
only)
OFF/ON
Binarization (XCL-5005
only)
OFF/ON
3×3 image filtering
(XCL-5005 only)
OFF/ON
DC IN terminal
90%
10%
2 - 5 V
10.0 µs - 2 s
Width
0 - 0.6 V
Rising time
Less than
2.0 µs
Amplitude

Overview
Location and Function of Parts and Operation
10
Convert the signal which meets the specifications above
into LVDS format (3.3 V power drive IC output), and
inputs the converted signal.
Note that the signal level cannot be recognized correctly
by the camera if it does not meet the following
conditions.
H level: 1.5 V to 1.7 V
L level: 0.8 V to 1.0 V
DVAL/Exposure output specific
(only DC IN terminal)
Stated in the voltage of when terminating at more than
10 k ohms
DIGITAL IF terminal
4 - 5 V
0 V

Functions
1. CCD loaded on XCL-5005CR/5005 11
Functions
1. CCD loaded on XCL-5005CR/5005
The 5 million-pixel CCD mounted on XCL-5005CR/
5005 has two signal outputs-left and right two channels
output system CCD-in order to improve the frame rate.
There is a boundary of two imaging areas in the center.
The left and right images of each area are combined one
image by digital signal processing.
Each area of the two channels output system CCD has its
output amplifier. Even so, the boundary does not appear
in the center of the window when the left and right
signals are combined into one picture if the output
amplifier characteristic accord with each other. It is,
however, very difficult for the CCD manufacturing
technique to make two amplifier characteristics accord
completely, and the output levels of left and right may be
different. In this case, a boundary appears in the center
of the window due to the difference of the left and right
levels. XCL-5005CR/5005 has an automatic correction
function that automatically detects and corrects the
difference between the levels in order to make it
indistinguishable. The automatic correction function is
set to on in the factory setting. Otherwise you can cancel
the automatic correction function and set the correction
of left and right levels manually.
A step or a boundary may be seen in the center of the
window according to the camera setting mode. This is
not a malfunction. The boundary is especially easily
seen in the GainUp.
MUX
1224 1224
2050
Output
2448 (H) ×2050 (V)
Left Right
Boundary of imaging areas
Left
Right

Functions
2. Compatibility with previous model XCL-5000
12
2. Compatibility with previous model XCL-5000
The XCL-5005CR/5005 is a model with upward
compatibility that is based on the XCL-5000 and
supports the PoCL standard. Control commands used on
the XCL-5000 can also be used in the same way on the
XCL-5005, as they are both black and white models. In
addition, commands that are shared across black and
white models and color models can be used in the same
way on the XCL-5005CR. This model has also been
enhanced with a variety of additional functions and
control commands.
However, you can still use a power adapter and a camera
module interface board without PoCL support (non-
PoCL) to operate the camera as previously.

Functions
3. Video output format 13
3. Video output format
You can select the video output system from 1TAP 80
MHz and 2TAP 40 MHz. The 1TAP 80 MHz output
system is only enabled during RGB 24-bit output.
3.1. Switching TAP
Configure this setting with IMG-TAP. 1TAP outputs 1
pixel (D1) per clock (80 MHz) and 2TAP outputs 2
pixels (D1 and D2) per clock (40 MHz).
3.2. Color pixel array
When the XCL-5005CR outputs 8, 10, and 12 bit RAW
data, the signals of all pixels are sequentially output
according to the Bayer array shown in the figure below.
This is common for each operation mode.
In the case of RGB 24 bit, there are 8 bits of each of R,
G, and B per pixel.
IMG-TAP XCL-5005 XCL-5005CR
8/10/12 bits RAW 8/10/12 bits RGB 24 bits
1TAP 80 MHz 0 aaa
2TAP 40 MHz 1 aa–
1TAP 80 MHz 2TAP 40 MHz
8 bits 10 bits 12 bits RGB 24 bits 8 bits 10 bits 12 bits
D1 D1 [0:7] D1 [0:9] D1 [0:11] DR [0:7]
DG [0:7]
DB [0:7]
D1 [0:7] D1 [0:9] D1 [0:11]
D2 – – – – D2 [0:7] D2 [0:9] D2 [0:11]
D1
D1 D1 D1
D2 D2 D2
D1 D1 D1 D1 D1 D1
STROBE
80 MHz
Video
output
STROBE
40 MHz
Video
output
2TAP 40 MHz
1TAP 80 MHz

Functions
3. Video output format
14
3.3. Data order
This section shows the order of data when an image
made up of 2448 × N pixels is transmitted by 1TAP/
2TAP. In normal mode, N = 2050. With the 2TAP 40
MHz transmission system, D1 is a horizontal odd
number pixel that is output, and D2 is an even number
pixel.
3.3.1. 1TAP 80 MHz
3.3.2. 2TAP 40 MHz
1· · ·
· · ·
23 2445 2446 2447 2448
1
2
4
N -1
N
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
D1
2448 × N pixels
1· · ·
· · ·
23
1
2
4
N -1
N
D1
D1
D1
D1
D1
D1
D1
D1
D2
D2
D2
D2
D2
D2
D2
D2
D1
D1
D1
D1
D1
D1
D1
D1
D2
D2
D2
D2
D2
D2
D2
D2
D1
D1
D1
D1
D1
D1
D1
D1
D2
D2
D2
D2
D2
D2
D2
D2
D1
D1
D1
D1
D1
D1
D1
D1
D2
D2
D2
D2
D2
D2
D2
D2
2445 2446 2447 2448
2448 × N pixels

Functions
3. Video output format 15
3.4. Port assignment
The following table shows the assignment for the three
ports A, B, and C and each of the video signals (D1, D2,
and DR, DG, and DB when RGB 24 bits) of 1TAP/
2TAP, which is defined in the base configuration.
3.5. Output data size
Both the XCL-5005CR and XCL-5005 have an effective
output line number of 2448 × 2050 (horizontal/vertical),
and both output 2448 clocks for LVAL and 2050 lines
for FVAL.
The pixel count for image output on the XCL-5005CR
when set to RGB output mode is equivalent to the 2448
× 2050 effective line number mentioned above. When it
is set to RAW data output mode and depending on your
camera module interface board (frame grabber board),
one less pixel may be displayed around the outer
circumference after data processing, making the pixel
count for image output 2446 × 2048 (horizontal/
vertical).
Port 1TAP 80 MHz 2TAP 40 MHz
8 bits 10 bits 12 bits RGB 24 bits 8 bits 10 bits 12 bits
Port A0 D1 [0] D1 [0] D1 [0] DR [0] D1 [0] D1 [0] D1 [0]
Port A1 D1 [1] D1 [1] D1 [1] DR [1] D1 [1] D1 [1] D1 [1]
Port A2 D1 [2] D1 [2] D1 [2] DR [2] D1 [2] D1 [2] D1 [2]
Port A3 D1 [3] D1 [3] D1 [3] DR [3] D1 [3] D1 [3] D1 [3]
Port A4 D1 [4] D1 [4] D1 [4] DR [4] D1 [4] D1 [4] D1 [4]
Port A5 D1 [5] D1 [5] D1 [5] DR [5] D1 [5] D1 [5] D1 [5]
Port A6 D1 [6] D1 [6] D1 [6] DR [6] D1 [6] D1 [6] D1 [6]
Port A7 D1 [7] D1 [7] D1 [7] DR [7] D1 [7] D1 [7] D1 [7]
Port B0 D1 [8] D1 [8] DG [0] D2 [0] D1 [8] D1 [8]
Port B1 D1 [9] D1 [9] DG [1] D2 [1] D1 [9] D1 [9]
Port B2 D1 [10] DG [2] D2 [2] D1 [10]
Port B3 D1 [11] DG [3] D2 [3] D1 [11]
Port B4 DG [4] D2 [4] D2 [8] D2 [8]
Port B5 DG [5] D2 [5] D2 [9] D2 [9]
Port B6 DG [6] D2 [6] D2 [10]
Port B7 DG [7] D2 [7] D2 [11]
Port C0 DB [0] D2 [0] D2 [0]
Port C1 DB [1] D2 [1] D2 [1]
Port C2 DB [2] D2 [2] D2 [2]
Port C3 DB [3] D2 [3] D2 [3]
Port C4 DB [4] D2 [4] D2 [4]
Port C5 DB [5] D2 [5] D2 [5]
Port C6 DB [6] D2 [6] D2 [6]
Port C7 DB [7] D2 [7] D2 [7]

Functions
4. Camera mode
16
4. Camera mode
4.1. Horizontal timing
The horizontal timing is common for all modes. The
XCL-5005CR/5005 are provided with a horizontal
partial scan function (HPARTIAL) that is capable of
changing the length of the Hi section of the LVAL signal.
Configuring the setting in increments of 4 columns from
128 columns to 2448 columns without changing the
center position of the effective video area of the
horizontal enables a reduction in the number of columns
imported on the host device (computer) side. The frame
rate does change even if HPARTIAL is set to ON.
Note
When HPARTIAL is set to ON, set the column number
for the effective video area.
Set the read column number to a multiple of 4 between
the range of 128 to 2448. An error will occur if the
configured column number is out of range or not a
multiple of 4.
72 CLK 2448 CLK
2444 CLK76 CLK
1
CENTER 2444
CENTER
24461 2 3 2447 2448
1 CLK
LVA L
DVAL
Video
output
Horizontal timing: Common for each mode 1 CLK=1/80 MHz = 12.5 ns 1 H=2520 CLK
LVA L
DVAL
STROBE
Video
output
[XCL-5000] [XCL-5005CR] [XCL-5005]
HPARTIAL ON
[XCL-5005CR] [XCL-5005]
Example: HPARTIAL 1 2444
2 columns 2 columns
The read column number
2444 columns
(Set the read column
number to multiple of 4.)
2448 pixels
The effective video area
(LVAL = “H”)

Functions
4. Camera mode 17
4.2. Vertical timing
The vertical timing is common for the XCL-5005CR
and XCL-5005.
4.2.1. Normal mode
This mode is for outputting the individual video signals
of all pixels as continuous video at 15 frames per second.
4.2.2. Binning mode
This mode is for adding two vertical lines to read from
the CDD in order to almost double the frame rate. The
binning mode is not available for the XCL-5005CR.
Note
The camera cannot be operated with the binning mode
and the partial scan mode set to ON at the same time.
66 H 2050 H
1 2 3 4 5 2048 2049 2050
1 H
Normal 1 V = 2116 H
FVAL
LVA L
DVAL
Video
output
1 H
33 H 1025 H
1 2 3 4 5 1023 1024 1025
Binning 1 V = 1058 H
FVAL
LVA L
DVAL
Video
output
(The horizontal timing is the same as in normal mode.)

Functions
4. Camera mode
18
4.2.3. Partial scan mode
This mode increases the frame rate by dividing the
whole video period vertically, reading only the
necessary lines as the actual video, and transferring
unnecessary lines at high-speed. Set the read beginning
position (block number PSAH for high-speed
transferring) and read block number (normal
transferring block number or line number PSAF).
There are five types of partial scan mode.
In Modes 1 to 4 divide the actual video vertically into
any of approximately 16 or approximately 32 areas and
then reads them as the actual video. Mode 5 improves
the flexibility of area selection and allows for much
more detailed area settings to be configured.
Line number of actual video
For each of Mode 1 and Mode 3, Mode 2 and Mode 4,
the division numbers of approximately 16 and
approximately 32 are the same, but the beginning
positions of the actual video are different. Mode 1 and
Mode 2 are the same as the division settings on the XCL-
5000, but they cannot be selected on the XCL-5005CR.
Mode 3 and Mode 4 have common settings for the XCL-
5005 and XCL-5005CR. Mode 5 allows for detailed
setting of the actual video lines.
Partial scan offset
You can use partial scan offset (PARTIAL-OFFSET) to
offset the beginning position of the actual video output
in the normal transferring period in increments of 1 line.
To make the beginning position of the actual video
output the same as any that of any mode other than
partial scan, set PARTIAL-OFFSET=0.
To use Mode 1 of XCL-5005 with the same setting as
XCL-5000, set PARTIAL-OFFSET=38. The setting is
PARTIAL-OFFSET=38 at the time of shipment.
The setting range available for PARTIAL-OFFSET may
be different depending on the mode.
Beginning and ending position of the actual
video
In Modes 1 to 4, when the ending position of the actual
video is set by selecting a certain area and then a
different setting is configured so that the corresponding
point becomes the beginning point, both points may not
match. This is because the high-speed transferring
period cannot be partitioned in increments of 64 lines.
You can, however, make both points match if you use a
partial scan offset.
Mode XCL-5005 XCL-5005CR PSAF Line number of actual video
1a– 0 - 15 128 × (PSAF+1)
2a– 0 - 31 64 × (PSAF+1)
3aa0 - 15 128 × (PSAF+1)
4aa0 - 31 64 × (PSAF+1)
5aa1 - 2050 PSAF
High-speed transferring period
High-speed transferring period
High-speed transferring block number
(High-speed transferring period PSAH)
Modes 1 to 4 : Normal transferring block number
Mode 5 : Normal transferring line number
(Normal transferring period PSAF)
Whole
area
Normal transferring period
(Effective video output)
PARTIA L-
OFFSET
Mode Setting range (fixed
value)
XCL-5000 – 1, 2 (38)
XCL-5005 a1 to 4 Integer from 0 to 38
5 Integer from 0 to 51
XCL-
5005CR
a1 to 4 Even value from 0 to 38
5 Even value from 0 to 50

Functions
4. Camera mode 19
Note
If the area at the bottom part of the window is selected,
the video at the bottom may appear black. This is caused
by the optical black being displayed as a result of the
partial scan offset, and is not an indication of a
malfunction. Furthermore, the settings of partial scan
offset may be restricted depended on the mode and type
of camera.
In Modes 1 to 4, the line number A of the actual video,
vertical blanking period B, and frame rate are
determined by the normal transferring period PSAF.
Mode 1 and Mode 3 (PARTIAL-OFFSET = 38)
Mode 2 and Mode 4 (PARTIAL-OFFSET = 38)
BA
12345 A
1 H
Partial scan
FVAL
LVA L
DVAL
Video
output
(The horizontal timing is the same as in normal mode.)
PSAF A [LINE] B [LINE] Rate [fps]
0 128 447 55
1 256 422 47
2 384 396 41
3 512 370 36
4 640 345 32
5 768 319 29
6 896 294 27
7 1024 268 25
8 1152 242 23
9 1280 217 21
10 1408 191 20
11 1536 166 19
12 1664 140 18
13 1792 114 17
14 1920 89 16
15 2048 63 15
PSAF A [LINE] B [LINE] Rate [fps]
0 64 455 61
1 128 442 56
2 192 429 51
3 256 417 47
4 320 404 44
5 384 391 41
6 448 378 39
7 512 365 36
8 576 353 34
9 640 340 32
10 704 327 31
11 768 314 29
12 832 301 28
13 896 289 27
14 960 276 26
15 1024 263 25
16 1088 250 24
17 1152 237 23
18 1216 225 22
19 1280 212 21
20 1344 199 21
21 1408 186 20
22 1472 173 19
23 1536 161 19
24 1600 148 18
25 1664 135 18
26 1728 122 17
27 1792 109 17
28 1856 97 16
29 1920 84 16
30 1984 71 15
31 2048 58 15
PSAF A [LINE] B [LINE] Rate [fps]

Functions
4. Camera mode
20
Mode 5
You configure detailed settings of the read beginning
position and read line number. Set the read beginning
position in increments of 5 lines for the XCL-5005, and
in increments of 10 lines for the XCL-5005CR. Set the
read line number in increments of 1 line. Depending on
the camera module interface board (frame grabber
board) you are using, the pixels in the last line may not
display properly.
Use of this mode in combination with a partial scan
offset allows you to set the read beginning position and
read line number in increments of 1 line.
The line number A of the actual video, vertical blanking
period B, and frame rate are determined by the values of
the read line number PSAF and partial scan offset.
* PER = 432 + 0.8 × (PSAF + PARTIAL-OFFSET)
Set the PARTIAL-OFFSET and read line number PSAF
so that the total line number does not exceed the actual
video range that can be output.
PARTIAL-OFFSET + PSAF ≤2050
Read beginning
position PSAH
Read line number
PSAF
XCL-5005 Integer from 0 to 408 1 to 2050
XCL-
5005CR
Even number from 0 to
408
1 to 2050
A [LINE] PSAF
B [LINE] PER*– PSAF
Rate [fps] 1000000/(PER × 31.5)
