Sony DSX-MS60 User manual

The DSX-MS60 Marine Digital Media Receiver by Sony® features a USB5 1-wire Tune
Tray that lets you protect, connect, charge and control your iPod®2 while boating.
Make the most of your time on the water enjoying your music library with Sony
audio technologies like DM+, Quick-BrowZer® and ZAPPIN™.
DSX-MS60 DSX-MS60 Marine Digital Media Receiver
Bullets
• Detachable faceplate with 2-line display and front aux
• Integrated Tune Tray with USB5 1-wire input
• MP3/WMA/AAC playback1 with DM+ enhancement technology
• Intuitive Quick-BrowZer® and ZAPPIN™ search features
• Satellite radio3/HD Radio™ ready4 using Sony® Bus
• Anti-corrosion coated circuit boards
• Ultraviolet (UV) resistant nishes
• 2V front and rear/subwoofer pre-outs with HPF/LPF
• Radio Data System (RDS)
• Wireless card remote included (RM-X151)
Features
Flip-down Face with Front USB Input
The easy-to-read 2-line LCD display shows clock, station ID and track data when playing back your
digital MP3/WMA/AAC les1 from the internal USB input. Front aux input lets you connect almost any
portable audio device to your car’s sound system.
Integrated Tune Tray
The Tune Tray compartment lets you easily connect, control and charge your iPod®2, Walkman® player
or other compatible music devices via the USB5 1-Wire input. Your player is secured inside, eliminating
unsightly and distracting wires.
MP3/WMA/AAC playback1
Multi-format playback lets you play your MP3, WMA, or AAC songs1. Hear digital music les in their
original vibrancy with DM+ (Digital Music Plus), a Sony® codec enhancer that reproduces detailed
frequencies from compressed audio les.
Intuitive Search Features
Use Quick-BrowZer® feature to nd music by artist, album, genre, song or playlist. Jump Mode allows
you to fast forward through a category in 10% increments while the ZAPPIN™ feature can play a 6, 9, or
30 second intro clip to help you nd a specic song.
Satellite Radio3/HD Radio™ Ready4
The DSX-MS60 integrates seamlessly with Satellite Radio3 and HD Radio4 using Sony® Bus adaptors so
you can receive digital satellite radio or HD Radio broadcasts.
Anti-corrosion coated circuit board
Sony Marine receivers use conformal coated circuit boards and are safeguarded by HAYA high humidity
resistant vinyl resin.
Ultraviolet (UV) resistant nishes
Sony Marine receivers are specically designed to withstand the ASTM G154 test for UV resistance. This
means the faceplate is treated to resist fading and discoloring after prolonged exposure to UV light.
RCA outputs for external ampliers

Specications
Amplier Section
Max power output 52 watts x 4 at 4 ohms
Speaker Impedance 4-8 Ohms
Audio
Band AM / FM
Digital-to-Analog Converter 24bit
Equalizer
EQ3: 3 band EQ
br+/- 10 dB at 60 Hz
br+/- 10 dB at 1 kHz
br+/- 10 dB at 10 kHz
Format(s) Supported MP3/WMA/AAC les1
Preout Impedance 220 ohms
Preout Voltage 2 volt
S/N Ratio Audio Power: CEA2006 S/N 80 dBA
Station Preset(s) 18 FM / 12 AM
Tuner Frequency Range brFM:Tuner Frequency Range(MHz): 87.5-107.9 brAM:Tuner Frequency Range(kHz): 530-1710
Tuner Type SSIR-EXA with RDS
Volume Control Tel/Nav Attenuation
Convenience
Tilt Range 0-45° mounting angle
Convenience Features
Dimmer Adjust Slectable Auto adjust or manual on/o
Key Illumination Blue
On-Screen Clock 12H
Display
Display Color White color / Positive
Display Technology LCD
Text Displayed Source, artist, track, playback time, menu and clock
Text Lines 2 lines of information
General
Color Piano Black
Inputs and Outputs
12V Trigger Output(s) brPower antenna
brAmplier turn on
Antenna Terminal(s) AM/FM Antenna Input Terminal
When you’re ready to expand your sound system, the DSX-MS60 oers selectable rear or subwoofer
pre-amp RCA outputs for external ampliers. Set the built in electronic HPF/LPF crossovers to improve
sound quality and reduce system distortion.
Radio Data System (RDS)
Radio Data System (RDS) feature displays radio broadcast information such as artist and track
information when listening to compatible AM/FM stations.
Wireless card remote
Control your receiver while keeping your eyes on the road with the included wireless card remote (RM-
X151).

Audio In
brFront Aux with variable level: -8dB ~ +18dB
brInternal USB input
brSony Bus terminals
Digital Audio Input(s)
Ability to use all forms of USB devices may vary as not all devices are compatible.
brThis unit can be connected to the following iPods. Update your iPod to the latest software before you use it.
br iPod Nano 1st generation*
br iPod Nano 2nd generation (aluminum)
br iPod Nano 3rd generation (video)
br iPod 5th generation (video)*
br iPod Classic
br iPod Touch
br iPhone
brThis unit is compliant with MSC (Mass Storage Class) and MTP (Media Transfer Protocol) type USB devices compliant
with the USB standard.
br This unit cannot recognize USB devices via a USB hub.
br If you have any questions or problems concerning your unit that are not covered in the owners manual, consult your
nearest Sony dealer.
Infrared Port Wireless remote input
RCA Audio Output(s) Front and Rear/Sub selectable RCA pre-amp outputs
Remote Jack Optional wired remote terminal
USB Port(s) USB - Full Speed
Power
Current Drain 3 - 5 amps
Input Voltage 12 V DC car battery (negative ground)
Output Power 52W x4 Watts Max Power - CEA2006 Standard Power Output: 17 Watts RMS per channel into 4 Ohms, 4 channels driven
from 20 Hz to 20 kHz with less than 1% THD+N.
Tuner
FM Usable Sensitivity 10 dBf
Frequency Response FM: 20-15,000 Hz
S/N Ratio 70 dB (mono)
Selectivity 75 dB at 400 kHz
Stereo Separation 40 dB at 1 KHz
Weights and Measurements
Dimensions (Approx.) 178 x 50 x 179mm
Weight (Approx.) 1.3 kg (2 lb. 14 oz.)
Supplied Accessories
Supplied Accessories
brParts for installation and connections (1 set)
brRM-X151 wireless remote
brXA-50IP USB connector for iPod
Optional Accessories
Optional Accessories
Replacement remote: RM-X151
CD changer (6 discs): CDX-T69
Source selector: XA-C40
Aux-in selector: XA-300
HD Radio® tuner: XT-100HD
Walkman® player USB adapter: XA-50WM

1. Not all MP3, WMA, AAC les may playback due to le variations. Copyright protected ACC-LC les cannot be played back.
2. Ability to use all generations of iPod products may vary as not all products are compatible.
3. Satellite radio service requires a satellite radio tuner and service subscription, sold separately.
4. HD Radio® capability requires an optional HD Radio tuner (XT-100HD).
5. Ability to use all forms of USB devices may vary as not all devices are compatible.
© 20010 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written permission is prohibited. Sony, Xplōd, ZAPPIN, Quick-BrowZer and the Sony and Xplōd logos are trademarks of Sony.
iPod is a trademark of Apple Inc. All other trademarks are trademarks of their respective owners. Features and specications are subject to change without notice. Non-metric weights and measures are approximate
and may vary.
Updated: June 13, 2011
