Sony CDP-XE700 User manual

— 1 —
Model Name Using Similar Mechanism CDP-XE800
CD Mechanism Type CDM36-14
Base Unit Type BU-14
Optical Pick-up Type KSS-213B/S-N
SPECIFICATIONS
MICROFILM
COMPACT DISC PLAYER
CDP-XE700
AEP Model
UK Model
Compact disc player
Laser Semiconductor laser (λ= 780 nm)
Emission duration: continuous
Laser output Max 44.6 µW*
* This output is the value measured at
a distance of 200 mm from the
objective lens surface on the Optical Pick-
up block with 7 mm aperture.
Frequency response 2 Hz to 20 kHz ± 0.5 dB
Signal-to-noise ratio More than 102 dB
Dynamic range More the 98 dB
Harmonic distortion Less than 0.0035%
Channel separation More than 100 dB
General
Power requirements 220 V – 230 V AC, 50/60 Hz
Power consumption 12W
Dimensions (approx.) 430 ×1107 ×295 mm
(w/h/d) (17 ×4 1/4 ×11 5/8 in.) incl. projecting
parts
Mass (approx.) 3.6 kg (7 lbs 15 oz)
Supplied accessories
Audio cord (2 phono plugs–2 phono plugs) (1)
Remote commander (RM-D820) (1)
Sony SUM-3 (NS) batteries (2)
Design and specifications are subject to change without notice.
PHOTO : AEP model
SERVICE MANUAL
Outputs
Jack Maximum Load
type output impedance
level
LINE OUT Phono 2 V Over 50 kilohms
jacks (at 50 kilohms)
DIGITAL Optical –18 dBm Wave length : 660 nm
OUT output
(OPTICAL) connector
PHONES Stereo 10 mW 32 ohms
phone
jack

— 2 —
SAFETY-RELATED COMPONENT WARNING !!
COMPONENTS IDENTIFIED BY MARK !OR DOTTED
LINE WITH MARK !ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.
This appliance is classified as
a CLASS 1 LASER product.
The CLASS 1 LASER
PRODUCT MARKING is
located on the rear exterior.
CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous ra-
diation exposure.
Notes on chip component replacement
• Never reuse a disconnected chip component.
• Notice that the minus side of a tantalum capacitor may be
damaged by heat.
Flexible Circuit Board Repairing
• Keep the temperature of soldering iron around 270˚C
during repairing.
• Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
• Be careful not to apply force on the conductor when soldering
or unsoldering.
This caution
label is located
inside the unit.
TABLE OF CONTENTS
Section Title Page
SECTION 1. SERVICING NOTE ...................................3
SECTION 2. GENERAL ...................................................... 4
SECTION 3.DISASSEMBLY
3-1. Front Panel Assembly......................................................... 5
SECTION 4.TEST MODE..............................................6
SECTION 5. ELECTRICAL BLOCK CHECKING......8
SECTION 6. DIAGRAMS
6-1. Circuit Boards Location ................................................... 10
6-2. IC Pin Function
• IC801 System Control,
Fluorescent Indicator Tube Drive (CXP82316-069Q) .. 11
6-3. Printed Wiring Board — BD Section — .......................... 13
6-4. Schematic Diagram — BD Section —............................. 15
6-5. Printed Wiring Board — Main Section — ....................... 20
6-6. Schematic Diagram — Main Section — .......................... 23
SECTION 7. EXPLODED VIEWS
7-1. Front Panel Section .......................................................... 27
7-2. Chassis Section................................................................. 28
7-3. CD Mechanism Section (CDM36-14).............................. 29
7-4. Base Unit Section (BU-14)............................................... 30
SECTION 8. ELECTRICAL PARTS LIST ................. 31
ADVARSEL :USYNLIG LASERSTRÅLING VED ÅBNING NÅR
SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION. UNDGÅ UDSAETTELSE
FOR STRÅLING.
CAUTION :INVISIBLE LASER RADIATION WHEN OPEN AND
INTERLOCKS DEFEATED. AVOID EXPOSURE TO BEAM.
VARO! :AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET ALT-
TIINA NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE. ÄLÄ KATSO SÄTEESEEN.
VARNING :OSYNLIG LASERSTRÅLING NÄR DENNA DEL ÄR ÖPP-
NAD OCH SPÄRREN ÄR URKOPPLAD. BETRAKTA EJ STRÅLEN.
VORSICHT : UNSICHTBARE LASERSTRAHLUNG, WENN
ABDECKUNG GE
Ö FFNET UND SICHEREITSVERRIEGELUNG
ÜBERBRÜCKT. NICHT DEM STRAHL AUSSETZEN.
ADVARSEL :USYNLIG LASERSTRÅLING NÅR DEKSEL ÅPNES OG
SIKKERHEDSLÅS BRYTES. UNNGÅ EKSPONERING FOR STRÅLEN.
The laser component in this product
is capable of emitting radiation
exceeding the limit for Class 1.
MODEL IDENTIFICATION
— BACK PANEL —
4-978-904-1π: AEP, German model
4-979-904-8π: UK model

— 3 —
SECTION 1
SERVICING NOTE
HOW TO OPEN THE DISC TRAY WHEN POWER SWITCH
TURNS OFF
Insert a screwdriver into the aperture of the unit bottom, and
move it in the direction of arrow.
NOTES ON HANDLINGTHE OPTICAL PICK-UP BLOCK
OR BASE UNIT
The laser diode in the optical pick-up block may suffer
electrostatic breakdown because of the potential difference
generated by the charged electrostatic load, etc. on clothing and
the human body.
During repair, pay attention to electrostatic breakdown and also
use the procedure in the printed matter which is included in the
repair parts.
The flexible board is easily damaged and should be handled with
care.
NOTES ON LASER DIODE EMISSION CHECK
The laser beam on this model is concentrated so as to be focused
on the disc reflective surface by the objective lens in the optical pick-
up block. Therefore, when checking the laser diode emission,
observe from more than 30 cm away from the objective lens.
LASER DIODE AND FOCUS SEARCH OPERATION
CHECK
Carry out the “S curve check” in “CD section adjustment” and
check that the S curve waveform is output three times.

— 4 —
SECTION 2
GENERAL
LOCATION OF PARTS AND CONTROLS
Front Panel
12
3
4
567
8
9
0
!¡!™
!£!¢
!∞
!§
!¶
!•
@º !ª
@¡
@™
1POWER switch
2PLAY MODE button
3REPEAT button
4FADER button
5TIME button
6Disc tray
7Remote sensor
80/) buttons
9Display window
0CHECK button
!¡ CLEAR button
!™ ENTER button
!£ ≠AMS* ±knob
!¢ p(stop) button
!∞ P(pause) button
!§ ·(play) button
!¶ §OPEN/CLOSE button
!• MUSIC SCAN button
!ª AUTO SPACE button
@º PEAK SEARCH button
@¡ EDIT/TIME FADE button
@™ PHONES jack (EXCEPT UK)
* AMS is the abbreviation for Automatic Music Sensor.

— 5 —
SECTION 3
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
3-1. FRONT PANEL ASSEMBLY
1 Push the part A in the direction of arrow to
remove the loading panel upward.
A part
6 Two screws
(BVTP2.6x8)
8 Panel bracket
4 Connector
(CN751)
Claw
3 Screw (BVTP3x8)
(AEP, G only)
2 Three screws
(BVTP3x8)
5 Connector (CN302)
(Flat type 23 core)
Claw
7 Wire
9 Remove the front panel assembly
with care to claws.

— 6 —
When the pbutton is pressed, the following will be displayed.
(partial lighting 2)
When the OPEN/CLOSE §button is pressed, all will light up
again.
• Key check
All buttons have corresponding button numbers.When a button is
pressed, the counter will count up and display the button’s num-
ber. However, the counter will only count to “17”. It will not count
for buttons already pressed once, but will display the button’s
number.
SECTION 4
TEST MODE
4-1. AF MODE
The following checks can be performed in the AF mode, which is set
by connecting the TP2 (AFADJ) terminal on MAIN board to the
Ground and turning on the power.
• FL tube check
After all segments light up, when the ·button is pressed, the
following will be displayed. (Partial lighting 1)
24
6810
12 14
16 18 20 (Partial lighting 2)
(Partial lighting 1)
8888
• Remote commander check
When the ·button of the remote commander is pressed, the
“·” lights up. All go off when the other buttons are pressed.
• Audio check
• Initial setting of digital filter and release of mute.
• WhentheTP2 (AFADJ)terminal on MAINboardis set to HIGH
(VDD), emphasis turns on.When set to LOW (Ground), it turns
off.
TIME
FADER
REPEAT
PLAY MODE
EDIT/
TIME FADE
PEAK SEARCH
AUTO SPACE
MUSIC SCAN
P
00
01
02
03
ENTER
CLEAR
CHECK
)
0
OPEN/
CLOSE §
PLAY ·
STOP p
32
33
34
35
36
04
05
06
07
25
Button Button No.
Displayed Button Button No.
Displayed
88888888
Â
Display of counting
Â
Display of button number
All lit
Partial lighting 1
Partial lighting 2

— 7 —
4-2. ADJ MODE
The following operations are performed in the ADJ mode, which
is set by connecting the TP1 (ADJ) terminal to the Ground and
turning on the power.
• During playback, there is no problem even if the GFS is continu-
ously LOW.
• High speed search is prohibited during access.
• During playback, the gain of focus servo and spindle servo does
not decrease.
• Servo related manual operations and measurement can be
performed.
(For details of operations, refer to Table of Key Operrations inADJ
Mode.)
4-3. CLV-S MODE
The spindle servo for playback sets into the CLV-S mode when
the TP1 (ADJ) terminal is connected to Ground after turning on the
power.
TABLE OF BUTTON OPERATIONS IN ADJ MODE
The jitter value display mode can be set after the all-music
remaining number mode using the TIME button.
The functions of the number buttons are shown in the following
table.
FUNCTIONS OF NUMBER BUTTONS
(With the attached remote commander)
[ MAIN BOARD ] — Component Side —
CN302
IC920
TP1 (ADJ)
TP2 (AFADJ)
CN301
1
2
3
4
5
6
7
8
10
Focus bias 8-step up
Middle of focus bias up/down turning point
Tracking servo, sled servo off
Auto gain initialization
Focus servo off
Focus bias 8-step down
Immediate readjustment of focus bias
Tracking servo, sled servo on
Auto focus bias start point
Function
Button

— 8 —
SECTION 5
ELECTRICAL BLOCK CHECKING
Note:
1. CD Block is basically designed to operate without adjustment.
Therefore, check each item in order given.
2. UseYEDS-18 disc (3-702-101-01) unless otherwise indicated.
3. Use an oscilloscope with more than 10MΩimpedance.
4. Clean the object lens by an applicator with neutral detergent when
the signal level is low than specified value with the following
checks.
S Curve Check
Procedure :
1. Connect oscilloscope to test point TP (FE) on BD board.
2. Connect between test point TP (FEI) and TP (VC) by lead wire.
3. Turned Power switch on.
4. Put disc (YEDS-18) in and turned Power switch on again and
actuate the focus search. (actuate the focus search when disc table
is moving in and out.)
5. Check the oscilloscope waveform (S-curve) is symmetrical
between A and B. And confirm peak to peak level within 3±1
Vp-p.
S-curve waveform
6. After check, remove the lead wire connected in step 2.
Note : • Try to measure several times to make sure than the ratio of
A : B or B : A is more than 10 : 7.
• Take sweep time as long as possible and light up the
brightness to obtain best waveform.
RF Level Check
Procedure :
1. Connect oscilloscope to test point TP (RF) on BD board.
2. Turned Power switch on.
3. Put disc (YEDS-18) in to play the number five track.
4. Confirm that oscilloscope waveform is clear and check RF signal
level is correct or not.
Note: A clear RF signal waveform means that the shape “◊” can be
clearly distinguished at the center of the waveform.
RF signal waveform
E-F Balance (1Track Jump) Check
(Without remote commander)
Procedure :
1. Connect oscilloscpe to test point TP (TE) on BD board.
2. Turned Power switch on.
3. Put disc (YEDS-18) in to play the number five track.
4. Press the “P(Pause)” button. (Becomes the 1 track jump mode)
5. Check the level B of the oscilliscope's waveform and the A (DC
voltage) of the center of the Traverse waveform.
Confirm the following :
A/B x 100 = less than ± 22%
1 track jump waveform
E-F Balance Check (With remote commander)
Procedure :
1. Connect the test point TP1 (ADJ) on MAIN board to the ground
with a lead wire on main board.
2. Connect oscilloscpe to test point TP (TE) on BD board.
3. Turn the Power switch on to set the ADJ mode.
4. Put disc (YEDS-18) in to play the number five track.
5. Press the “3” button. (The tracking servo and the sledding servo
are turned OFF.)
oscilloscope
BD board
TP (FE)
TP (VC)
symmetry
A
B
within 3 ± 1 Vp-p
BD board
TP (RF)
TP (VC)
oscilloscope
level : 1.3 Vp-p
VOLT/DIV : 200mV
TIME/DIV : 500ns
+0.25
–0.20
oscilloscope
BD board
TP (TE)
TP (VC)
Center of the waveform
0V
B
level : 1.3 ± 0.6Vp-p symmetry
A (DC voltage)
oscilloscope
BD board
TP (TE)
TP (VC)

— 9 —
Center of the waveform
B
level : 1.3 ± 0.6Vp-p
0V
7. Press the “8” button. (The tracking servo and sledding servo are
turned ON.) Confirm the C (DC voltage) is almost equal to theA
(DC voltage) is step 6.
Traverse waveform
8. Disconnect the lead wire of TP1 (ADJ) connected in step 1.
2. Turned Power switch on.
3. Put the disc (YEDS-18) in to play the number five track.
Confirm that reading on frequency counter is 4.3218MHz.
Adjustment Location :
[ BD BOARD ] — Side A —
IC102
TP (TE) TP (FE) TP (VC)
TP (RF)
[ MAIN BOARD ] — Component Side —
6. Check the level B of the oscilliscope's waveform and the A (DC
voltage) of the center of the Traverse waveform.
Confirm the following :
A/B x 100 = less than ± 22%
Traverse waveform
A (DC voltage)
0V
RF PLL Free-run Frequency Check
Procedure :
1. Connect frequency counter to test point (XPLCK) with lead wire.
TP (XPLCK)
IC101
TP (FEI)
IC103
frequency counter
BD board
TP (XPLCK)
CN301
CN302
TP1 (ADJ)
TP2 (AFADJ)
IC305
J401
IC920
C (DC
voltage)
Tracking servo
Sledding servo
ON
Tracking servo
Sledding servo
OFF

— 10 —
KEY board
SLED board
DISPLAY board
MAIN board
SPINDLE board
SECTION 6
DIAGRAMS
6-1. CIRCUIT BOARDS LOCATION
POWER board
BD board
LOADING board
HP board

— 11 —
6-2. IC PIN FUNCTION
• IC801 SYSTEM CONTROL, FLUORESCENT INDICATORTUBE DRIVE (CXP82316-069Q)
Function
Connected to +5V.
Audio bus input.
Connected to +5V.
Not used. (open)
Latch signal output to digital filter (IC303).
Serial clock output.
SENSE signal input.
Serial data output.
Read out clock output for subcode Q data.
Subcode Q data input.
Not used. (open)
Analog muting control signal output.
Optical pickup laser diode control output.
Serial data latch signal output.
Not used. (open)
Remote commander volume +. (Not used)
Remote commander volume –. (Not used)
Loading motor control signal output.
Key input. (S801 to S810, S820 to S826, S828)
ADJ, AFADJ test pin.
Loading IN/OUT switch input.
Reset signal input.
Clock input. (4 MHz)
Clock output. (4 MHz)
Ground
Not used. (open)
Fluorescent Indicator Tube segment output.
Fluorescent Indicator Tube grid output.
–30V pin for Fluorescent Indicator tube.
Pin No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22 to 27
28
29
30
31
32
33
34 to 41
42 to 62
63 to 70
71
72
73
74
75
76
77
78
79
80
Pin Name
TIMER
RM (BUSIN)
+5V
OPEN
OPEN
(BUS-OUT)
PRGL
CLK
SENSE
DATA
SQCK
SUBQ
OPEN
AMUTE
LDON
XLT
RVLED
RV+
RV–
LDOUT
LDIN
KEY0 to KEY5
ADJ/AFADJ
IN/OUTSW
RST
EXTAL
XTAL
VSS
OPEN
S1 to S21
1G to 8G
VFDP (–30V)
VDD (+5V)
—
SEL1
IN PORT
IN PORT
IN PORT
SCOR
SEL2
SEL3
I/O
–
I
–
–
–
–
O
O
I
O
O
I
–
O
O
O
–
O
O
O
O
I
–
I
I
I
O
–
–
O
O
–
–
–
–
–
–
–
I
–
–
+5V pin.
Connected to Ground.
Connected to +5V.
Read out timing signal input for subcode Q data.
Connected to Ground.
Connected to Ground.

— 27 —
Ref. No. Part No. Description Remark
SECTION 7
EXPLODEDVIEWS
NOTE:
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• The mechanical parts with no reference number in
the exploded views are not supplied.
• Hardware (# mark) list and accessories and pack-
ing materials are given in the last of this parts list.
7-1. FRONT PANEL SECTION
Ref. No. Part No. Description Remark
*1 4-980-480-01 CUSHION (LOADING)
2 4-978-900-01 PANEL, LOADING
3 4-977-590-21 KNOB (AMS)
4 3-354-981-01 SPRING (SUS), RING
5 4-974-510-01 SCREW (+BV3X8B)(UK)
5 7-685-646-79 SCREW +BVTP3X8 TYPE 2 N-S (AEP,G)
6 X-4946-575-1 PANEL ASSY (ALS), FRONT
*7 4-978-398-11 CUSHION (UK)
*7 4-978-398-21 CUSHION (AEP,G)
8 4-963-404-21 EMBLEM (5-A), SONY
9 4-951-620-01 SCREW (2.6X8), +BVTP
*10 1-658-820-11 HP BOARD (AEP,G)
*11 1-658-818-11 KEY BOARD
*12 A-4673-778-A DISPLAY BOARD, COMPLETE
13 3-363-099-01 SCREW (CASE 3 TP2)(AEP,G)
13 4-974-509-01 SCREW (CASE 3B)(UK)
*14 4-978-901-01 CASE (409526)
*15 4-962-329-01 DAMPER (UK)
16 4-977-589-21 BUTTON (POWER)
17 4-977-358-01 CUSHION (8X12.5)
18 4-978-897-01 PLATE, INDICATION
19 X-3371-435-1 FOOT ASSY (F50150S)
The components identified by
mark !or dotted line with mark
!are critical for safety.
Replace only with part number
specified.
• Abbreviation
G : German model
not supplied
5
14
13
11
10
9
912 9
9
16
not supplied
9
5 (AEP, G only)
15
13
17
5
19
not supplied
5
17
19
not supplied
not supplied
5
6
4
3
7
18
5
5
2
17
8

— 28 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
*61 4-978-904-81 PANEL, BACK (UK)
62 3-703-244-00 BUSHING, CORD
*63 4-949-235-01 HOOK (AEP,G)
63 4-956-370-02 BAND, PLUG FIXED (UK)
*64 3-309-144-21 HEAT SINK
65 4-974-510-01 SCREW (+BV3X8 B)(UK)
65 7-685-646-79 SCREW +BVTP3X8 TYPE2 N-S (AEP,G)
66 4-956-619-01 LABEL, LASER CAUTION (UK)
66 4-950-813-01 LABEL, LASER CAUTION (AEP,G)
!CNP901 1-575-651-21 CORD, POWER (AEP,G)
!CNP901 1-696-907-11 CORD, POWER (UK)
!T901 1-429-367-11 TRANSFORMER, POWER
*51 4-954-051-51 HOLDER, PC BOARD
52 4-955-939-01 WASHER (CASE)
*53 3-349-025-41 HOLDER, PC BOARD
54 3-703-319-00 PURSE LOCK (DIA.15)
55 1-776-235-11 WIRE (FLAT TYPE) (23 CORE)
*56 A-4673-777-A MAIN BOARD, COMPLETE (AEP,G)
*56 A-4673-908-A MAIN BOARD, COMPLETE (UK)
*57 4-962-200-01 PLATE (TR), GROUND
*58 1-658-819-11 POWER BOARD
59 2-383-566-00 SCREW
60 4-959-077-01 DAMPER (UK)
*61 4-978-904-11 PANEL, BACK (AEP,G)
7-2. CHASSIS SECTION
The components identified by
mark !or dotted line with mark
!are critical for safety.
Replace only with part number
specified.
51
53
not supplied
#2
CD MECHANISM (CDM36-14)
58
T901
not supplied
59
#2
#1
#2
#1
51
57
54
55
61 62
CNP901 (UK)
CNP901
(AEP, G)
63
63
65
65
64
55
60
56
52
52
not supplied
#2

— 29 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
101 1-452-820-11 MAGNET (ASSY)
*102 4-977-902-01 PANEL (DRAWER)
*103 4-977-894-01 HOLDER (AP)
*104 A-4673-722-A BD BOARD, COMPLETE
105 1-776-998-11 WIRE (FLAT TYPE) (21 CORE)
106 4-948-503-01 SPRING (BU), COMPRESSION
107 4-977-897-01 GEAR
*108 4-977-893-01 CAM, SLIDE
109 4-977-896-01 PULLEY
110 4-968-905-01 BELT (CDM)
*111 1-658-710-11 LOADING BOARD
*112 4-977-891-01 PLATE, GROUND
113 4-977-898-01 LEVER (SWING)
*114 4-977-892-01 BEARING
*115 4-977-888-01 SHAFT
*116 4-977-889-01 PLATE (BU), GROUND
M151 A-4660-968-A MOTOR ASSY (LOADING)
109
not supplied
M151
#1
101
102
108
104
105
107
113 110
#1
#1
#1
#1
#1
111
not supplied
#3
not supplied
not supplied
114
115
116
not supplied
#1
106
106
not supplied
BASE UNIT (BU-14)
not supplied
103
7-3. CD MECHANISM SECTION (CDM36-14)
not supplied
112

— 30 —
Ref. No. Part No. Description RemarkRef. No. Part No. Description Remark
151 4-977-925-01 SPRING(SLIDE BASE),COMPRESSION
152 4-977-926-01 RACK, SLIDE
153 4-977-915-01 CAP, CENTERING
154 4-977-927-01 SPRING (CENTERING),COMPRESSION
155 4-977-923-01 SHAFT, SLED
*156 1-658-708-11 SPINDLE BOARD
157 1-775-990-11 WIRE (FLAT TYPE) (5 CORE)
*158 4-977-928-01 SPRING (SPINDLE), LEAF
159 4-977-921-01 GEAR (B), FLAT
!160 8-848-376-01 OPTICAL PICK-UP KSS-213B/S-N
161 1-775-991-11 WIRE (FLAT TYPE) (16 CORE)
*162 4-977-924-01 SPRING (OP), LEAF
163 4-951-940-01 INSULATOR (BU)
*164 4-977-918-01 BASE (OUTSERT)
165 4-977-920-01 GEAR (C), FLAT
*166 1-658-709-11 SLED BOARD
167 4-951-620-01 SCREW (2.6X8), +BVTP
M101 X-4947-304-1 MOTOR ASSY (SPINDLE)
M102 X-4947-303-1 MOTOR ASSY (SLED)
151 152 153
154
M101
7-4. BASE UNIT SECTION (BU-14)
The components identified by
mark !or dotted line with mark
!are critical for safety.
Replace only with part number
specified.
160
155 159 155
157
156
164
#3
158
#4
#3
#3
162
161
163
165
163
M102
167
167
166
not supplied

— 31 —
BD
Note:
• Due to standardization, replacements in the parts list
may be different from the parts specified in the dia-
grams or the components used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they are sel-
dom required for routine service. Some delay should
be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
G : German model
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SECTION 8
ELECTRICAL PARTS LIST
The components identified by
mark !or dotted line with mark
!are critical for safety.
Replace only with part number
specified.
Whenindicatingparts byreference
number, please include the board
name.
*A-4673-722-A BD BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C102 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C103 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C105 1-135-155-21 TANTALUM CHIP 4.7uF 10% 16V
C106 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C107 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C108 1-163-035-00 CERAMIC CHIP 0.047uF 50V
C109 1-163-145-00 CERAMIC CHIP 0.0015uF 5% 50V
C110 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C111 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C112 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C113 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C115 1-126-607-11 ELECT CHIP 47uF 20% 4V
C116 1-126-607-11 ELECT CHIP 47uF 20% 4V
C117 1-126-209-11 ELECT 100uF 20% 4V
C118 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C119 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C120 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C121 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C123 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C124 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C131 1-164-346-11 CERAMIC CHIP 1uF 16V
C132 1-164-346-11 CERAMIC CHIP 1uF 16V
C140 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C141 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C151 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C152 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C153 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C154 1-164-336-11 CERAMIC CHIP 0.33uF 25V
C155 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C156 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C157 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C158 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C159 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C160 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C161 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C162 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C171 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C172 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C173 1-164-232-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
CN101 1-770-072-11 CONNECTOR, FFC 23P
CN102 1-750-753-11 CONNECTOR, FFC/FPC 21P
CN103 1-774-653-21 PIN, CONNECTOR (PC BOARD) 3P
< DIODE >
D101 8-719-016-74 DIODE 1SS352
< IC >
IC101 8-752-369-78 IC CXD2545Q
IC102 8-759-071-79 IC BA6297AFP
IC103 8-752-072-45 IC CXA1821M-T6
< COIL >
L101 1-414-234-11 INDUCTOR, FERRITE BEAD
< TRANSISTOR >
Q101 8-729-010-08 TRANSISTOR MSB710-R
Q102 8-729-010-08 TRANSISTOR MSB710-R
< RESISTOR >
R101 1-216-077-00 METAL CHIP 15K 5% 1/10W
R102 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R103 1-216-077-00 METAL CHIP 15K 5% 1/10W
R104 1-216-085-00 METAL CHIP 33K 5% 1/10W
R105 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R106 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R107 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R108 1-216-073-00 METAL CHIP 10K 5% 1/10W
R109 1-216-121-91 METAL GLAZE 1M 5% 1/10W
R110 1-216-025-91 METAL GLAZE 100 5% 1/10W
R112 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R113 1-216-073-00 METAL CHIP 10K 5% 1/10W
R114 1-216-073-00 METAL CHIP 10K 5% 1/10W
R117 1-216-073-00 METAL CHIP 10K 5% 1/10W
R118 1-216-073-00 METAL CHIP 10K 5% 1/10W
R121 1-216-073-00 METAL CHIP 10K 5% 1/10W
R122 1-216-073-00 METAL CHIP 10K 5% 1/10W
R123 1-216-073-00 METAL CHIP 10K 5% 1/10W
R124 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R125 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R126 1-216-049-91 METAL GLAZE 1K 5% 1/10W
