Sony CFD-V30L User manual

CFD-V20/V30/V30L.E.G_3-859-117-3X.CED/CEK/EE1/SP5/KR2/E23/EA1/HK2
3-859-117-31(2)
CD Radio
Cassette-Corder
1996 by Sony Corporation
CFD-V20
CFD-V30
CFD-V30L
EN
Operating Instructions page 2EN
Bedienungsanleitung Seite 2DD

Introduction
CFD-V20/V30/V30L.E.G_3-859-117-3X.CED/CEK/EE1/SP5/KR2/E23/EA1/HK2
2EN
Warning
To prevent fire or shock hazard, do
not expose the player to rain or
moisture.
To avoid electrical shock, do not open
the cabinet. Refer servicing to
qualified personnel only.
Information
For customers in Europe
Notice for customers in the United
Kingdom
A moulded plug complying with BS 1363 is
fitted to this equipment for your safety and
convenience.
Should the fuse in the plug supplied need to
be replaced, same rating fuse approved by
ASTA or BSI to BS 1362, (i.e. marked with
or mark) must be used.
If the plug supplied with this equipment has
a detachable fuse cover, be sure to attach the
fuse cover after you change the fuse. Never
use the plug without the fuse cover. If you
should lose the fuse cover, please contact
your nearest Sony service station.
This Compact Disc player is classified as
a CLASS 1 LASER product.
The CLASS 1 LASER PRODUCT label is
located on the bottom exterior.
WARNING
Do not install the appliance in a confined
space, such as a bookcase or built-in cabinet.
The FUNCTION selector is located at the
front.
When you turn on the player, the OPR/BATT
indicator lights up.
About this manual
The instructions in this manual are for the
CFD-V20, CFD-V30 and CFD-V30L. Before
you start reading, check your model number.
The CFD-V20 is the model used for
illustration purpose.

3EN Introduction
Basic Operations
CFD-V20/V30/V30L.E.G_3-859-117-3X.CED/CEK/EE1/SP5/KR2/E23/EA1/HK2
Table of contents
Basic Operations
4Playing a CD
6Listening to the radio
8Playing a tape
10 Recording on a tape
The CD Player
12 Using the display
13 Locating a specific track
14 Playing tracks repeatedly
(Repeat Play)
15 Creating your own program
(Program Play)
Setting Up
16 Choosing the power sources
18 Adjusting the sound emphasis
(TONE/MEGA BASS)
Additional Information
19 Precautions
21 Troubleshooting
23 Maintenance
24 Specifications
25 Index
EN

CFD-V20/V30/V30L.E.G_3-859-117-3X.CED/CEK/EE1/SP5/KR2/E23/EA1/HK2
Basic Operations4EN
Playing a CD
Basic Operations
1
42,3
OPEN/CLOSE
OPEN/CLOSE
CFD-V20/V30 CFD-V30L
Connect the supplied AC power cord (see page 16).
1Set FUNCTION to CD.
2Press 6OPEN/CLOSE down to
open the CD compartment and
place a CD on the CD
compartment.
3Close the CD compartment.
With the label side up

Basic Operations
Basic Operations
5EN
CFD-V20/V30/V30L.E.G_3-859-117-3X.CED/CEK/EE1/SP5/KR2/E23/EA1/HK2
Display
Track number
4Press ^.
The player plays all the tracks
once.
Playing time
Use these buttons for additional operations
VOLUME ^p 6OPEN/CLOSE
FUNCTION
=/+
To Do this
Adjust the volume Turn VOLUME.
Stop playback Press p.
Pause playback Press ^.
Press again to resume play
after pause.
Go to the next track Press +.
Go back to the previous track Press =.
Remove the CD Press 6OPEN/CLOSE.
Turn off the player Set FUNCTION to TAPE
(CD/RADIO OFF).

CFD-V20/V30/V30L.E.G_3-859-117-3X.CED/CEK/EE1/SP5/KR2/E23/EA1/HK2
Basic Operations6EN
Listening to the radio
Connect the supplied AC power cord (see page 16).
1Select the band (CFD-V20/V30:
FM or AM, CFD-V30L: FM or
LW).
2Turn TUNE to tune in a radio
station.
If the received FM stereo is too
weak, the reception becomes
monaural.
12
CFD-V20/V30 CFD-V30L

Basic Operations
Basic Operations
7EN
CFD-V20/V30/V30L.E.G_3-859-117-3X.CED/CEK/EE1/SP5/KR2/E23/EA1/HK2
Use these buttons for additional operations
FUNCTIONVOLUME
To Do this
Adjust the volume Turn VOLUME.
Turn off the radio Set FUNCTION to TAPE
(CD/RADIO OFF).
To improve broadcast reception
Reorient the antenna for FM. Reorient the player itself
for AM/LW.
For FM For AM/LW
Tip
To receive an FM stereo
program (only for the
models equipped with
FM MODE/ISS selector
at the rear)
Set the FM MODE/ISS
selector at the rear to
STEREO. If the FM
broadcast is noisy, set
the selector to MONO
and the radio will play
in monaural.

CFD-V20/V30/V30L.E.G_3-859-117-3X.CED/CEK/EE1/SP5/KR2/E23/EA1/HK2
Basic Operations8EN
Playing a tape
32 1
With the side you want
to play facing upward
Connect the supplied AC power cord (see page 16).
1Set FUNCTION to TAPE (CD/
RADIO OFF).
2Press p6 to open the tape
compartment and insert a
recorded tape. Use TYPE I
(normal) tape only. Close the
compartment.
3Press (.
CFD-V20/V30 CFD-V30L

Basic Operations
Basic Operations
9EN
CFD-V20/V30/V30L.E.G_3-859-117-3X.CED/CEK/EE1/SP5/KR2/E23/EA1/HK2
Use these buttons for additional operations
P0/) p6
VOLUME
To Do this
Adjust the volume Turn VOLUME.
Stop playback Press p6.
Fast-forward or rewind the tape Press )or 0for the
side facing upward.
Pause playback Press P.
Press the button again to
resume play after pause.
Eject the cassette Press p6.

CFD-V20/V30/V30L.E.G_3-859-117-3X.CED/CEK/EE1/SP5/KR2/E23/EA1/HK2
Basic Operations10EN
Connect the supplied AC power cord (see page 16).
1Press p6 to open the tape
compartment and insert a blank
tape. Use TYPE I (normal) tape
only.
2Select the program source you
want to record.
To record from the CD player, set
FUNCTION to CD and insert a
CD (see page 4).
To record from the radio, select
the band and tune in the station
you want (see page 6).
Recording on a tape
31
Display
With the side you want to
record on facing upward
CFD-V30L
CFD-V20/V30 CFD-V30L
CFD-V20/V30
