Sony SLT-A58K User manual

SLT-A58K/A58M/A58Y_L2 Sony Corporation
SERVICE MANUAL
Revision History
SERVICE NOTE (Check the following note before the service.)
LEVEL 2
983473231.pdf
2013C08-1
© 2013.03
Published by Sony Techno Create Corporation
INTERCHANGEABLE LENS DIGITAL CAMERA
1-1. METHOD FOR REPLACING THE P.O.I.
1-2. PRECAUTION ON REPLACING THE AM-1001 BOARD
1-3. NOTES FOR REPLACING THE EVF DISPLAY DEVICE (LCD902) OR THE AM-1001
BOARD
1-4. ADDITION OF DESTINATION DATA FILE
1-5. METHOD FOR CHECKING THE AS SLIDER UNIT (863)
1-6. METHOD FOR ADJUSTING THE TEBURE REVISE
1-7. METHOD FOR REPLACING THE AS SLIDER B ASSY T
1-8. METHOD FOR REPLACING THE AS HOLDER ACTUATOR ASSY
1-9. NOTE ON REMOVING THE AP IRIS RING
1-10. HOW TO CHANGE THE APERTURE
1-11. METHOD OF CONFIRMING THE PHASES OF AP IRIS RING AND AP SENSOR GEAR
9-834-732-31
[About the service of this model]
SLT-A58K/A58M/A58Y are commodity that packed the Interchangeable Lens Digital Camera and Interchangeable Lenses.
Refer to each following service manual the Interchangeable Lens kit, when you repair.
Model Lens Service Manual of Lens
SLT-A58K SAL1855-2 (DT 18-55mm F3.5-5.6 SAM II) 9-834-733-[]
SLT-A58M SAL18135 (DT 18-135mm F3.5-5.6 SAM) 9-834-677-[]
SLT-A58Y SAL1855-2 (DT 18-55mm F3.5-5.6 SAM II) 9-834-733-[]
SAL55200-2 (DT 55-200mm F4-5.6 SAM) 9-852-692-[]
The components identified
by mark 0or dotted line with
mark 0are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
SLT-A58K/A58M/A58Y
US Model
Canadian Model
AEP Model
UK Model
Russian Model
E Model
Australian Model
Chinese Model
Korea Model
Photo: SLT-A58 (Main body)
Ver. 1.0 2013.03
Ver. Date History Contents S.M. Rev.
issued
1.0 2013.03 Official Release — —

SLT-A58K/A58M/A58Y_L2
– 2 –
SPECIFICATIONS
Model information table
Model SLT-A58K SLT-A58M SLT-A58Y
Destination US, CND, AEP, UK, RU, E, KR,
CH, AUS AEP, UK, RU, E, AUS AEP, UK, RU, E, AUS
Lens SAL1855-2
DT 18-55mm F3.5-5.6 SAM II
SAL18135
DT 18-135mm F3.5-5.6 SAM
SAL1855-2 DT 18-55mm F3.5-5.6 SAM II/
SAL55200-2 DT 55-200mm F4-5.6 SAM
• Abbreviation
Camera
[System]
Camera Type Interchangeable Lens Digital Camera
Lens A-mount lens
[Image sensor]
Image format 23.2 mm×15.4 mm (APS-C format),
CMOS image sensor
Total pixel number of image sensor
Approx. 20 400 000 pixels
Effective pixel number of camera
Approx. 20 100 000 pixels
[SteadyShot]
For still images System: Image sensor-shift mechanism
Effect: Approx. 2.5 EV to 4.5 EV in shutter
speed
(depending on shooting conditions and the
attached lens)
For movies System: Electronic
[Anti-Dust]
System Charge protection coating on Low-Pass
Filter and image sensor-shift mechanism
[Auto focus system]
System TTL phase-detection system, 15 points (3
points cross type)
Sensitivity Range –1 EV to 18 EV (at ISO 100 equivalent)
AF illuminator Approx. 1 m to 5 m (3.3 ft. to 16.4 ft.)
[Electronic viewfinder]
Type Electronic viewfinder
Screen size 1.0 cm (0.39 type)
Total number of dots 1 440 000 dots
Frame coverage 100%
Eye Point Approximately 26.5 mm from the eye-
piece, 23 mm from the eyepiece frame (at
–1 m–1)
Diopter Adjustment –4.0 m–1 to +4.0 m–1 (diopter)
[LCD screen]
LCD panel 6.7 cm (2.7 type) TFT drive/Clear Photo
LCD screen
Total number of dots 460 800 dots
[Exposure control]
Metering Cell “Exmor” CMOS sensor
Metering method 1 200-zone evaluative metering
Metering Range –2 EV to +17 EV (at ISO 100 equivalent
with F1.4 lens)
ISO sensitivity (Recommended exposure index)
Still images: AUTO (ISO 100 – 3 200),
ISO 100 to 16 000 (1 EV step)
Movies: AUTO (ISO 100 – 3 200 equiva-
lent), ISO 100 to 3 200 equivalent (1 EV
step)
Exposure compensation
±3.0 EV (1/3 EV step)
[Shutter]
Type Electronically-controlled, vertical-traverse,
focal-plane type
Speed range Still images: 1/4 000 second to 30 seconds,
BULB
Movies: 1/4 000 second to 1/4 second (1/3
step), up to 1/60 second in AUTO mode
Flash sync speed 1/160 second
[Built-In-Flash]
Flash G.No. GN 10 (in meters at ISO 100)
Recycling time Approx. 4 seconds
Flash coverage Covering 18 mm lens (focal length that the
lens indicates)
Flash compensation ±2.0 EV (1/3 EV step)
Flash range
Aperture F2.8 F4.0 F5.6
ISO setting
100 1 m – 3.6 m
(3.3 feet – 11.8
feet)
1 m – 2.5 m
(3.3 feet – 8.2
feet)
1 m – 1.8 m
(3.3 feet – 5.9
feet)
200 1 m – 5 m
(3.3 feet – 16.4
feet)
1 m – 3.6 m
(3.3 feet – 11.8
feet)
1 m – 2.5 m
(3.3 feet – 8.2
feet)
400 1.4 m – 7.1 m
(4.6 feet – 23.3
feet)
1 m – 5 m
(3.3 feet – 16.4
feet)
1 m – 3.6 m
(3.3 feet – 11.8
feet)
800 2 m – 10 m
(6.6 feet – 32.8
feet)
1.4 m – 7.1 m
(4.6 feet – 23.3
feet)
1 m – 5 m
(3.3 feet – 16.4
feet)
[Continuous shooting]
Continuous shooting speed
[Tele-zoom Cont. Priority AE]:
Maximum 8 images per second/
: Maximum 5 images per second/
: Maximum 2.5 images per second
• Our measurement conditions. The speed
of continuous shooting may be slower,
depending on shooting conditions (Image
size, ISO setting, High ISO NR, or the
setting of [Lens Comp.: Distortion]).
The maximum number of continuous shots
In [Tele-zoom Cont. Priority AE] mode
Fine: 16 images/Standard: 19 images
In Continuous shooting
Fine: 7 images/Standard: 8 images/RAW &
JPEG: 5 images/RAW: 6 images
[Image zooming playback]
Scaling range Image size: L: Approx. ×1.0 – ×15.4/M:
Approx. ×1.0 – ×11.2/S: Approx. ×1.0 –
×7.7
[Recording format]
File format JPEG-compliant (DCF Ver. 2.0, Exif Ver.
2.3, MPF Baseline), RAW (Sony’s exclu-
sive ARW2.3 format)
Movie (AVCHD format)
AVCHD format Ver. 2.0 compatible
Video: MPEG-4 AVC/H.264
Audio: Dolby Digital 2ch, equipped with
Dolby Digital Stereo Creator
• Manufactured under license from Dolby
Laboratories.
Movie (MP4 format) Video: MPEG-4 AVC/H.264
Audio: MPEG-4 AAC-LC 2ch
[Recording media]
“Memory Stick XC Duo” media, “Memory
Stick PRO Duo” media, SD card
[Input/output terminals]
Multi/Micro USB Terminal*
USB communication
* Supports Micro USB compatible device.
HDMI HDMI type D micro jack
Mic Terminal φ3.5 mm Stereo minijack
[Power, general]
Battery pack Rechargeable battery pack NP-FM500H
Power consumption (during shooting)
When using the viewfinder: Approx. 1.7 W
When using the LCD screen: Approx. 1.7 W
(With the SAL18552 lens attached, for
shooting still images)
[Others]
Microphone Stereo
Speaker Monaural
Print features Exif Print compatible, PRINT Image
Matching III compatible, DPOF compat-
ible
Dimensions (Approx.)
128.6 mm × 95.5 mm × 77.7 mm
(5 1/8 inches × 3 7/8 inches × 3 1/8 inches)
(W/H/D, excluding protrusions)
Mass (Approx.) 573 g (1 lb 4.2 oz) (with battery and
“Memory Stick PRO Duo” media)
492 g (1 lb 1.4 oz) (body only)
Operating temperature
0°C to 40°C (32°F to 104°F)
On image data compatibility
• This camera conforms with the DCF (Design rule for Camera
File system) universal standard established by JEITA (Japan
Electronics and Information Technology Industries Associa-
tion).
• Playback on other equipment of images recorded using your
camera and playback on your camera of images recorded or
edited using other equipment are not guaranteed.
Design and specifications are subject to change without notice.
Battery charger/Battery
BC-VM10A Battery charger
Input rating 100 V - 240 V AC, 50/60 Hz, 9 W
Output rating 8.4 V DC, 0.75 A
Operating temperature range
0°C to 40°C (32°F to 104°F)
Storage temperature range
–20°C to +60°C (–4°F to +140°F)
Maximum dimensions
Approx. 70 mm × 25 mm × 95 mm
(2 7/8 inches × 1 inch × 3 3/4 inches)
(W/H/D)
Mass Approx. 90 g (3.2 oz)
Rechargeable battery pack NP-FM500H
Battery Lithium-ion battery
Maximum voltage DC 8.4 V
Nominal voltage DC 7.2 V
Maximum charge voltage
DC 8.4 V
Maximum charge current
2.0 A
Capacity Typical 11.8 Wh (1 650 mAh)
Minimum 11.5 Wh (1 600 mAh)
Maximum dimensions
Approx. 38.2 mm × 20.5 mm × 55.6 mm
(1 9/16 inches × 13/16 inches × 2 1/4
inches) (W/H/D)
Mass Approx. 78 g (2.8 oz)
AUS : Australian model
CH : Chinese model
CND : Canadian model
KR : Korea model
RU : Russian model

SLT-A58K/A58M/A58Y_L2
– 3 –
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE WITH
MARK 0ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST
ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPO-
NENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY
SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REM-
PLACER CES COMPOSANTS QUE PAR DES PIÈCES SONY DONT
LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES
SUPPLÉMENTS PUBLIÉS PAR SONY.
Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
CHEMICALS
Some chemicals used for servicing are highly volatile.
Their evaporation caused by improper management affects your health
and environment, and wastes resources.
Manage the chemicals carefully as follows.
• Store chemicals sealed in a specific place to prevent from exposure
to high temperature or direct sunlight.
• Avoid dividing chemicals into excessive numbers of small containers
to reduce natural evaporation.
• Keep containers sealed to avoid natural evaporation when chemicals
are not in use.
• Avoid using chemicals as much as possible. When using chemicals,
divide only required amount to a small plate from the container and
use up it.
EXTERIOR PARTS
Be careful to the following points for plastic parts used in this unit.
• Use a piece of cleaning paper or cleaning cloth for cleaning plastic
parts. Avoid using chemicals.
Even if you have to use chemicals to clean heavy dirt, don’t use paint
thinner, ketone, nor alcohol.
• Insert the specific screws vertically to the part when installing a
plastic part.
Be careful not to tighten screws too much.
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer.
1. Check the area of your repair for unsoldered or poorly-soldered
connections. Check the entire board surface for solder splashes and
bridges.
2. Check the interboard wiring to ensure that no wires are “pinched”
or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly transistors,
that were installed during a previous repair. Point them out to the
customer and recommend their replacement.
4. Look for parts which, through functioning, show obvious signs of
deterioration. Point them out to the customer and recommend their
replacement.
5. Check the B+ voltage to see it is at the values specified.
6. Flexible Circuit Board Repairing
• Keep the temperature of the soldering iron around 350°C during
repairing.
• Do not touch the soldering iron on the same conductor of the circuit
board (within 3 times).
• Be careful not to apply force on the conductor when soldering or
unsoldering.
UNLEADED SOLDER
This unit uses unleaded solder.
Boards requiring use of unleaded solder are printed with the lead free
mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with the
lead free mark due to their particular size.)
: LEAD FREE MARK
Be careful to the following points to solder or unsolder.
• Set the soldering iron tip temperature to 350°C approximately.
If cannot control temperature, solder/unsolder at high temperature
for a short time.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
Unleaded solder is more viscous (sticky, less prone to
flow) than ordinary solder so use caution not to let solder
bridges occur such as on IC pins, etc.
• Be sure to control soldering iron tips used for unleaded solder and
those for leaded solder so they are managed separately. Mixing
unleaded solder and leaded solder will cause detachment phenom-
enon.

SLT-A58K/A58M/A58Y_L2
1-1
1. SERVICE NOTE
1-2. PRECAUTION ON REPLACING THE AM-1001 BOARD
Destination Data
When you replace to the repairing board, the written destination data of repairing board also might be changed to original setting.
USB Serial No.
The set is shipped with a unique ID (USB Serial No.) written in it.
This ID has not been written in a new board for service, and therefore it must be entered after the board replacement.
1-1. METHOD FOR REPLACING THE P.O.I.
Method of Removal
(1) Press the MB Mirror Frame Holder Lock SP to raise the P.O.I.
MB Mirror Frame Holder Lock SP
(2) Unjoint the two claws while pressing the P.O.I. backward.
Claw
Claw
P.O.I.
Method of Attachment
(1) When attaching the P.O.I., make the concave side of it face the
front and attach it downward.
Claw
Claw
P.O.I.
Concave side
1-3. NOTES FOR REPLACING THE EVF DISPLAY DEVICE (LCD902) OR THE AM-1001 BOARD
WB adjustment values of each EVF display device (LCD902) are stored on the AM board.
Therefore, when the LCD902 or the AM board has been replaced, write WB adjustment values.
Adjustment
value
1-A
1-A
When LCD902 is replaced:
1. Check and write down the adjustment values printed on the LCD902 label.
2. After the LCD902 has been replaced, execute “EVF WB Adj” on the ADJUST tab by using the Adjust manual to write the adjustment values.
When replacing AM board (in case adjustment values can be read):
1. In case the unrepaired unit starts and adjustment values can be read by using the Adjust manual, execute “ADJUSTMENT DATA BACKUP” on
the DATA tab.
2. After the AM board has been replaced with a AM board for repair, execute “ADJUSTMENT DATA BACKUP” on the DATA tab of the Adjust
manual to write the extracted data to the unit.
When replacing AM board (in case adjustment values cannot be read):
1. When adjustment values cannot be read from the unrepaired unit, disassemble the unit and write down the adjustment values printed on the LCD902
label.
2. After the AM board has been replaced with a AM board for repair, execute “EVF WB Adj.” on the ADJUST tab by using the Adjust manual to
write adjustment values to the unit.
1-4. ADDITION OF DESTINATION DATA FILE
If the Destination Data file included in the Adjust manual is old, “DESTINATION DATA WRITE” cannot be executed in some cases.
In that case, download a new Destination Data file from the TISS homepage according to the following procedure.
Note 1: To perform Destination Data Write for this model, the Adjust manual of the DSC-WX50 series must have been installed.
Install the Adjust manual of the DSC-WX50 series in advance.
Note 2: The actual image may differ from the image shown above.
1) If the Destination Data file in the Adjust manual in use is old, the window shown in Fig. 1 is displayed.
Click the [OK] button.
Fig. 1

SLT-A58K/A58M/A58Y_L2
1-2
2) The Destination Data Write window opens.
Check the version of the Destination Data file retained in the Adjust manual.
Destination Ver. window
3) Search the model whose new Destination Data file you want to get on the TISS homepage.
When the Destination Data file has been updated, a file with a name “Destination File For ‘model name’.zip” is registered.
(Example) Destination File For DSC-WX50.zip
Furthermore, the version supported by the Destination Data file is shown in the Remarks column.
Note : If the Destination Data file has not been updated, contact the Service Headquarters.
4) Download the Destination Data file of the relevant model and unzip the file.
5) Execute “DESTINATION DATA WRITE” in the Adjust tab of the Adjust manual.
Click the [START] button.
6) Click the [File Update] button in the window.
7) A file selection screen opens. Select the Destination Data file to be added and click the [Open] button.
8) When the file has been successfully added, the following window opens.

SLT-A58K/A58M/A58Y_L2
1-3
1-5. METHOD FOR CHECKING THE AS SLIDER UNIT (863)
Make sure to confirm below before replacing the AS Slider B Assy T or the AS Holder Actuator Assy.
(1) Remove the Rear Cover Section, and temporally mount the AS Slider Unit (863).
(2) Set the AS Slider Unit (863) upwards as shown in figure, and put it on a stable place.
(3) Select “Slider Unit Check” of the adjustment software, and then confirm the movement to the directions of Pitch and Yaw, and if an error occurs,
replace it with the component part corresponding to the movement.
1-6. METHOD FOR ADJUSTING THE TEBURE REVISE
Make sure to confirm below after replacing the AS Slider B Assy T or the AS Holder Actuator Assy.
(1) Remove the Rear Cover Section, temporally mount the AS Slider Unit (863) mounted with the Imager Sensor, and then set up the camera
body and hold the AS Slider Unit (863) as shown in figure.
(2) Select “Slider Unit Check” of the adjustment software, and then confirm if the result is OK.
(3) Select “Tebure Revise Adj.” of the adjustment software, and then confirm if the result is OK.
(4) Mount the AS Slider Unit (863) to the camera.
9) Check the Destination Ver. window and confirm that the version has been updated.
Destination Ver. window

SLT-A58K/A58M/A58Y_L2
1-4
1-7. METHOD FOR REPLACING THE AS SLIDER B ASSY T
Removal Procedure
(1) Remove the spring.
Spring
(2) Remove the solder on the enamel wires at two places.
Solde
r
Solde
r
(3) Remove the flexible board from the AS Slider B Assy T.
Flexible Board
(4) Remove the two screws.
(5) Remove the AS Unit Holder Ball.
AS Unit Holder Ball
(6) Remove the two Ball Bearings.
Ball Bearing
Ball Bearing
(7) Remove the Cap SPs (for Pitch and Yaw).
Cap SP
(8) Remove the Caps (for Pitch and Yaw).
Cap
(9) Remove the AS Slider A Assy.
It can be done easily if Ais removed beforehand.
AS Slider A Ass
y
A
(10) Remove the AS Slider B Assy T.
It can be done easily if Bis removed beforehand.
AS Slider B Assy T
B
(11) Remove the three Ball Bearings.
Ball Bearings
Assembly Procedure
Note: Make sure to perform the assembly procedures after assembling the AS Holder Actuator Assy.
The assembly procedure is the reverse of the removal procedure.
Apply grease to the portions indicated below.
* After applying grease, attach the Ball Bearings.
Ball Bearings
GG-15
AS Slider B Assy T
GG-15 and GG-116
* After applying grease, attach the Ball Bearings.
Ball Bearing
GG-15
Ball Bearing
GG-15

SLT-A58K/A58M/A58Y_L2
1-5
1-8. METHOD FOR REPLACING THE AS HOLDER ACTUATOR ASSY
Removal Procedure
Note: Make sure to perform the removal procedures after removing the
AS Slider B Assy T.
(1) Remove the solder on the enamel wires at two places.
Solders
(2) Remove the flexible board from the hook on the AS Holder Actuator
Assy.
Hoo
k
(3) Remove the four screws to remove the AS Holder Actuator Assy.
AS Holder Actuator Assy
Assembly Procedure
Note: Make sure to perform the assembly procedures before assembling
the AS Slider B Assy T.
The assembly procedure is the reverse of the removal procedure.
Apply grease to the portions indicated below.
AS Holder Actuator Assy A
GG-15 and GG-116
1-9. NOTE ON REMOVING THE AP IRIS RING
If the AP Iris Ring is removed, the aperture charge cannot be retained. Therefore, after removing the AP Iris Ring, retain the charge in the procedure
below.
(4) While keeping the pin inserted, remove the Ring Roller B and AP
Ring Roller (C).
Pin
A
P Ring Roller (C)
Ring Roller B
(5) While keeping the pin inserted, remove the AP Iris Ring.
Pin
AP Iris Ring
(1) Rotate clockwise the AP Iris Ring as far as it goes.
AP Iris Ring
(2) Remove the MB P Mount Assy, and MB Ring SP COM, unscrewing
six screws.
MB Ring SP COM
MB P Mount Assy
(3) Insert the pin (approx. 1mm in diameter) through the hole of front
frame and drop the tip of pin in the cut portion of AP Sensor Gear
to fix the AP Sensor Gear.
Pin
Pin
Cut portion of
AP Sensor Gear
Hole of front
frame

SLT-A58K/A58M/A58Y_L2
1-6E
1-10.HOW TO CHARGE THE APERTURE
When installing the AP Aperture Unit, charge the aperture in the procedure below.
(1) Confirm that the arm of spring is free (initial position).
Spring is free
(initial position)
(2) Align the cut portion of AP Sensor Gear with the cut portion of side
charge plate by moving the AP Torque Limiter Assy (T).
AP Torque Limiter Assy (T)
Cut portion of
AP Sensor Gear
Cut portion of side
charge plate
(3) Align the hole of front frame with the cut portion of AP Sensor Gear
by turning counterclockwise the AP Torque Limiter Assy (T) to turn
the AP Sensor Gear 3 rotations (approx. 1000 degrees).
Cut portion of
A
P Sensor Gear
Turn the AP Sensor Gear 3 rotations
Hole of front
frame
AP Torque Limiter Assy (T)
(4) Insert the pin (approx. 1mm in diameter) through the hole of front
frame and drop the tip of pin in the cut portion of AP Sensor Gear
to fix the AP Sensor Gear.
Pin
Pin
Cut portion of
AP Sensor Gear
(5) While keeping the pin inserted, install theAPAperture Unit, aligning
the mark of AP Aperture Ring with the center (the position where
the mark is overlapped within the range in the figure of projection)
of limit gear assembly.
Pin
The gap exists.
This line is parallel
and contacts the
right side of projection.
This line orients toward the
center of front frame.
The mark of AP Iris Ring should
be in between two parallel lines.
AP Iris Ring
(1) Rotate the AP Iris Ring as far as it goes by rotating clockwise the AP
Torque Limiter Assy (T).
AP Iris Ring
AP Torque Limiter Assy (T)
(2) Measure the resistance between LN8201 and LN8202 on theAP-037
Flexible Board and confirm that the resistance is 100 to 450 Ω.
LN8202
AP-037
Flexible Board
LN8201
1-11. METHOD OF CONFIRMING THE PHASES OF AP IRIS RING AND AP SENSOR GEAR
After installing the AP Iris Ring, confirm the phases of AP Iris Ring and AP Sensor Gear in the following procedure.

SLT-A58K/A58M/A58Y_L2
2-1
2. REPAIR PARTS LIST
Follow the disassembly in the numerical order given.
IDENTIFYING PARTS
Link
• Abbreviation
AUS : Australian model
CH : Chinese model
CND : Canadian model
KR : Korea model
RU : Russian model
(ENGLISH)
NOTE:
• -XX, -X mean standardized parts, so they may have some differences from the original one.
• Items marked “*” are not stocked since they are seldom required for routine service. Some delay
should be anticipated when ordering these items.
• The mechanical parts with no reference number in the exploded views are not supplied.
• Due to standardization, replacements in the parts list may be different from the parts specified
in the diagrams or the components used on the set.
• Color Indication of Appearance Parts
Example:
(SILVER) : Cabinet’s Color
(Silver) : Parts Color
The components identified by mark 0or
dotted line with mark 0are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
When indicating parts by reference number,
please include the board name.
Bottom View
Top V iew
Back View
Right View
Left View
Front View
View Position
ACCESSORIESDISCHARGING OF THE CHARGING CAPACITOR ASSEMBLY
9Imager Section
• IS-1007 Board
• HOL-007 Flexible Board
• ISL-006 Flexible Board
• ISP-2001 Flexible Board
4AM-1001 Board
qs Mirror Box Section
• AFP-007 Flexible Board
• AP-037 Flexible Board
• BL-038 Flexible Board
• SLK-009 Flexible Board
qa ALX-8631
(AF Module)
• AF-131 Flexible Board
6
BD Bottom Frame Assy
7 Jack Holde Block Assy
• RM-100 Flexible Board
q;
Shutter Unit
(AFE-3032)
8 Battery Holder Section
• GO-1002 Board
• MCR-2000 Flexible Board
5
BD Top Frame
1 Rear Cover/LCD Section
• PD-1017 Board
• LCD-2002 Flexible Board
3
Strobe Base / VF Lens Section
• EYE-012 Flexible Board
•
MIS-2000 Flexible Board
•
SHM-2000 Flexible Board
2 Front Cover Section

SLT-A58K/A58M/A58Y_L2
2-2
NOTE FOR REPAIR
• Make sure that the flat cable and flexible board are not cracked
of bent at the terminal.
Do not insert the cable insufficiently nor crookedly.
• When remove a connector, don’t pull at wire of connector. It is
possible that a wire is snapped.
• When installing a connector, don’t press down at wire of con-
nector.
It is possible that a wire is snapped.
• Do not apply excessive load to the gilded flexible board.
Cut and remove the part of gilt
which comes off at the point.
(Be careful or some
pieces of gilt may be left inside)
Cut and remove the part of gilt
which comes off at the point.
(Be careful or some
pieces of gilt may be left inside)
DISCHARGING OF THE CHARGING
CAPACITOR (C901)
The charging capacitor is charged up to the maximum 315 V
potential.
There is a danger of electric shock by this high voltage when the
capacitor is handled by hand. The electric shock is caused by the
charged voltage which is kept without discharging when the main
power of the unit is simply turned off. Therefore, the remaining
voltage must be discharged as described below.
Preparing the Short Jig
To preparing the short jig, a small clip is attached to each end of
a resistor of 1 kΩ/1 W (1-215-869-11).
Wrap insulating tape fully around the leads of the resistor to
prevent electrical shock.
1kΩ/1 W
Wrap insulating tape.
1kΩ/1 W
Wrap insulating tape.
Note: High-voltage cautions
Discharging the Capacitor
Short-circuit between two points with
the short jig about 10 seconds.
R: 1 kΩ/ 1 W
(Part code: 1-215-869-11)
AM-1001 Board
AM-1001 Board
G: Grease
G-15 (J-6082-619-A)
G-85 (J-6082-626-A)
G-116 (J-6082-628-A)
SUBSIDIARY MATERIALS

SLT-A58K/A58M/A58Y_L2
2-3
2-1. EXPLODED VIEWS
2-1-1. OVERALL SECTION
DISASSEMBLY
1. Remove in numerical order (1to 5) in the left figure.
#112
Back View
Ref. No. Part No. Description Ref. No. Part No. Description
1 4-460-617-01 VM EYE CUP (876)
2 4-460-613-01 BD AM ST CARE SHEET (876)
*3 4-154-680-01 CV DIOPTER ADJUST DIAL (857)
4 4-460-615-01 CV JACK LID (876)
#2 2-635-562-31 SCREW (M1.7)
#12 3-080-204-21 SCREW, TAPPING, P2
#112 2-178-410-11 TITE (UB TITE) 1.4
DISCHARGING OF THE CHARGING CAPACITOR
5
2#112 X 1
3
#12
Back View
#2
Bottom View
#12
Right View
#12
Left View
3#12 X 2 →#2 X 3 →#12 X 3 →Open the Jack Lid (3) →#12 X 4
Screw
#2: M1.7 X 4.0
(Black)
2-635-562-31
4.0
1.7
#12: M1.7 X 5.0 (Tapping)
(Black)
3-080-204-21
1.7
5.0
#112: M1.4 X 5.0
(Black)
2-178-410-11
5.0
1.4
5
1
#12
Front Panel Section
(See page 2-4)
3
2
#12
#112
#12
#2
3
2
4
1
Rear Cover/LCD Section
(See page 2-9)
4
3
#12

SLT-A58K/A58M/A58Y_L2
2-4
2-1-2. FRONT PANEL SECTION
Ref. No. Part No. Description Ref. No. Part No. Description
51 X-2586-491-1 CV GRIP COVER(876) ASSY
52 4-460-618-01 CV DECO RING (876)
53 4-460-614-01 CV DC LID (876)
54 X-2586-489-1 CV FRONT COVER ASSY(876)
55 1-492-092-11 SWITCH BLOCK, CONTROL (TK87600)
56 4-449-470-01 CV MODEL NAME PLATE (876)
57 4-143-883-31 LOGO EMBLEM (A)
58 3-274-513-01 TAPE (ASCD)
#2 2-635-562-31 SCREW (M1.7)
#5 3-080-204-01 SCREW, TAPPING, P2
#12 3-080-204-21 SCREW, TAPPING, P2
#140 2-635-562-01 SCREW (M1.7)
A
A
G
F
F
G
E
E
B
B
C
C
2
Main Board Section
(See page 2-5)
Strobe Base/
VF Lens Section
(See page 2-10)
Strobe Base/
VF Lens Section
(See page 2-10)
#12 #12
#2
#12
#12
#5
#5
#5
#2
#140
151
52
254
55
58
53
57
56
Claw
Claws
Claw
3
4
DISASSEMBLY
1. Remove in numerical order (1to 4) in the left figure.
Bottom View
#12
3#2 X 4
1#12 X 1
2
Top View
Bottom ViewFront View Left View
#12#2 #140
#12 #12
2#12 X 4 →#2 X 1 →Popup the Strobe (2) →#140 X 1
Screw
Top View
#2
#2
#2: M1.7 X 4.0
(Black)
2-635-562-31
4.0
1.7
#5: M1.7 X 3.5 (Tapping)
(Black)
3-080-204-01
3.5
1.7
#12: M1.7 X 5.0 (Tapping)
(Black)
3-080-204-21
1.7
5.0
#140: M1.7X 2.0
(Black)
2-635-562-01
2.0
1.7

SLT-A58K/A58M/A58Y_L2
2-5
Ref. No. Part No. Description Ref. No. Part No. Description
101 CAUTION 2 BD TOP FRAME SHEET (876)
102 4-460-620-01 BD TOP FRAME (876)
103 4-460-621-01 BD AS ABSORBER
104 4-293-608-01 BD AM HEATSINK PLATE
105 4-460-622-01 BD LIGHT GUARD SHEET (876)
106 A-1935-877-A AM-1001 BOARD, COMPLETE (SERVICE)
107 X-2582-398-1 BD BOTTOM FRAME ASSY
BH3101 1-251-928-21 SOCKET, BATTERY (Note)
BT3101 1-756-134-15 BATTERY, LITHIUM (SECONDARY) (Note)
#5 3-080-204-01 SCREW, TAPPING, P2
#12 3-080-204-21 SCREW, TAPPING, P2
#109 2-515-483-21 SCREW (M1.7), LOCK ACE, P2
2-1-3. MAIN BOARD SECTION
ns: not supplied
DISASSEMBLY
1. Remove in numerical order (1to 4) in the left figure.
2. The meaning of the symbol in left figure is as follows. Be careful when you remove it.
◇: Solder
#109
#12
Back View
1#109 X 4 →#12 X 1
#5
Front View
#12
Top V iew
3#5 X 2 →#12 X 2
Screw
#5: M1.7 X 3.5 (Tapping)
(Black)
3-080-204-01
3.5
1.7
#12: M1.7 X 5.0 (Tapping)
(Black)
3-080-204-21
1.7
5.0
#109: M1.7 X 3.0
(Black)
2-515-483-21
3.0
1.7
Shutter Unit Section
(See page 2-6)
BT3101
(Note)
BH3101
(Note)
ns
#12
#109
#12
#12
#12
#5
A
B
CD
E
F
G
I
H
K
J
A
B
CD
I
J
K
H
G
FE
101
3102
103
2104
105
4107
1106
: BT3101 (BATTERY LITHIUM SECONDARY)
Board on the mount position.
(See page 6-34 of Level 3)
(Size: 11.0mm X 21.0mm)

#12
Back View
2#12 X 4
#12
Bottom View
4#12 X 4
Note
Note : Replace the battery holder (BH3101) together when
replacing the lithium storage battery (BT3101) on the AM-
1001 board.
(The battery holder removed once cannot be used again.)
When mounting these parts, mount new battery holder first
and attach new lithium storage battery next.
CAUTION 1
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
CAUTION 2
For the part of 101 : BD TOP FRAME SHEET (876) cut NON WO-
VEN (T0.25) (3-076-631-01) into the desired length and use it.

SLT-A58K/A58M/A58Y_L2
2-6
DISASSEMBLY
1. Remove in numerical order (1to 4) in the left figure.
2. The meaning of the symbol in left figure is as follows. Be careful when you remove it.
◇: Solder
2-1-4. SHUTTER UNIT SECTION
Screw
#12: M1.7 X 5.0 (Tapping)
(Black)
3-080-204-21
1.7
5.0
1#12 X 1
#12
Right View
3#12 X 4
#12
Back View
Ref. No. Part No. Description Ref. No. Part No. Description
151 1-884-791-22 RM-100 FLEXIBLE BOARD
152 X-2586-484-1 BD JACK HOLDER ASSY (876)
153 1-487-960-23 SHUTTER UNIT (AFE-3032) (Note 1)
154 A-1869-165-A ALX-8631 (Note 2)
(including AF-131 flexible complete board)
155 2-693-420-01 SP, S ADJUSTMENT
J901 1-821-194-51 JACK, DC
SP901 1-826-403-61 LOUDSPEAKER (1.0CM)
#12 3-080-204-21 SCREW, TAPPING, P2
#207 4-191-605-01 S ADJUSTMENT SCREW
4#207 X 3
Top View
#207
#207: M1.6 X 8.0
(Silver)
4-191-605-01
8.0
1.6
SP901
J901 #12
#12
#12
A
A
151
1152
153
(Note 1)

3Imager Section
(See page 2-7)
2Battery Holder Section
(See page 2-11)
Mirror Box Section (Sub Unit-1)
(See page 2-12)
#207
4154
(including AF-131 flexible complete board)
(Note 2)
155 155
2#12 X 1
#12
Left View
Note 1: Refer to “Assembly-1: Assemble Shutter Unit” when assem-
bling.
Note 2: Refer to “Assembly-2: Assemble ALX-8631 (AF Module)”
when assembling.
Note

SLT-A58K/A58M/A58Y_L2
2-7
2-1-5. IMAGER SECTION
ns: not supplied
Screw
#64: M1.7 X 5.0 (Tapping)
(Silver)
2-666-551-21
5.0
1.7
Ref. No. Part No. Description Ref. No. Part No. Description
Note
201 A-1935-767-A IM IMAGER UNIT ASSY (876)
(including CP6001 (CMOS imager) and IS-1007
complete board) (Note 1, 2, 3)
202 4-194-226-01 IM PLATE, LPF RETAINER
203 1-856-482-11 FILTER BLOCK, OPTICAL (Note 1, 2)
204 4-281-915-01 IM GS TAPE (Note 1)
205 4-281-914-01 IM SPACER (869) (Note 1)
206 4-194-225-01 IM TAPE FPC GUIDE
*207 4-194-227-01 IM PLATE GUIDE IMAGER FPC
208 1-888-338-11 ISP-2001 FLEXIBLE BOARD
209 1-883-908-11 ISL-006 FLEXIBLE BOARD
#64 2-666-551-21 SCREW, TAPPING, P2
203 (Note 1, 2)
204 (Note 1)
205 (Note 1)
204 (Note 1)
Anti Shake Unit Section
(See page 2-8)
202
201
(including CP6001 (CMOS imager) and IS-1007 complete board)
(Note 1, 2, 3)
208
209
206
207
#64
ns
#64
Note 1: Refer to the following statements when replacing the Optical
filter block.
Method of Removal
(1) Pour resolvent (alcohol or cleaning agent) between the
imager and the IM spacer.
Wait for that the adhesive power of the IM GS tape
weakens.
(2) Remove the IM spacer from the imager.
Pour resolvent (alcohol or cleaning agent)
between the imager and the IM spacer.
Method of Attachment
(1) Attach the IM GS tape and the Optical filter block by
aligning them with the outer shape of the IM GS tape
evenly.
The two-layer side of the Optical filter block is on the
imager side.
(2) Attach the IM spacer fixed tape by aligning it with the
outer shape of the IM GS tape evenly.
The two-layer
side is on the
imager side.
Mount
Side
Imager
Side
Optical Filter Block
Peel off the
released paper.
Peel off the
released paper.
Peel off the
released paper.
IM GS Tape
IM Spacer (869)
IM GS Tape
(3) Set the Optical filter block in its attachment jig
(J-6082-737-A), with the attached IM GS tape facing
upward.
(4) Press the imager down into the jig as shown below to
attach it to the Optical filter block.
J-6082-737-A
Imager
Peel off the released paper.
Note 2: Refer to “3-2. CLEANING PROCEDURE OF OLPF” on
page 3-2 for method of cleaning the OLPF.
Note 3: Precautions for Replacement of Imager
•If the imager has been replaced, carry out all the adjust-
ments for the camera section.
•As the imager may be damaged by static electricity from
its structure, handle it carefully like for the MOS IC.
In addition, ensure that the receiver is not covered with
dusts nor exposed to strong light.

SLT-A58K/A58M/A58Y_L2
2-8
2-1-6. ANTI SHAKE UNIT SECTION
ns: not supplied
Ref. No. Part No. Description Ref. No. Part No. Description
251 A-1782-917-A SLIDER UNIT (863 SERVICE), AS (Note 1, 2)
(including HOL-007 flexible complete board)
252 4-110-892-01 SPRING, ADJUSTMENT AO
253 X-2548-677-3 AS HOLDER ACTUATOR ASSY (Note 4)
254 2-695-356-11 BALL, BEARING
255 X-2581-038-2 AS SLIDER B ASSY T (Note 3)
#14 2-599-475-11 SCREW (M1.7)
#87 2-689-328-01 SCREW, CCD AO ADJUSTMENT
1. The meaning of the symbol in left figure is as follows. Be careful when you remove it.
◇: Solder
DISASSEMBLY
Screw
#14: M1.7 X 2.5
(Silver)
2-599-475-11
2.5
1.7
B
B
A
A
ns
ns
ns
ns
ns
ns ns
ns
ns
252 252
251
(including HOL-007 flexible complete board)
(Note 1,2)
(Note 3)
253 (Note 4)
254
255
254 254
254
252
#14
#14
#87
254


Note 1: Refer to “1-5. METHOD FOR CHECKING THE AS SLIDER
UNIT (863)” on page 1-3 before replasing the AS Slider B
Assy T or the AS Holder Actuator Assy.
Note 2: Refer to “1-6. METHOD FOR ADJUSTING THE TEBURE
REVISE” on page 1-3 after replasing the AS Slider B Assy
T or the AS Holder Actuator Assy.
Note
Note 3: Refer to “1-7. METHOD FOR REPLACING THE AS SLID-
ER B ASSY T” on page 1-4 when replacing the AS Slider B
Assy T.
Note 4: Refer to “1-8. METHOD FOR REPLACING THE AS
HOLDER ACTUATOR ASSY” on page 1-5 when replacing
the AS Holder Actuator Assy.
#87: M1.6 X 5.3
(Black)
2-689-328-01
5.3
1.6

SLT-A58K/A58M/A58Y_L2
2-9
2-1-7. REAR COVER/LCD SECTION
ns: not supplied
Ref. No. Part No. Description Ref. No. Part No. Description
301 1-492-091-11 SWITCH BLOCK, CONTROL (RS87600)
302 4-460-616-01 CT MODE DIAL PLATE S (876)
303 X-2586-478-1 CV REAR COVER ASSY (876)
304 3-274-513-01 TAPE (ASCD)
305 4-423-396-01 CV P CABINET M (871)
306 X-2349-080-4 CV LCD HINGE ASSY
307 4-423-395-01 CV LCD HINGE COVER (871)
308 4-424-467-01 CV LCD FPC GUARD (B) (871)
309 X-2584-216-1 CV P CABINET (C) ASSY (871)
310 1-888-340-11 LCD-2002 FLEXIBLE BOARD
311 A-1933-716-A PD-1017 BOARD, COMPLETE
312 4-460-649-01 EM LCD BOARD TAPE (876)
313 4-424-893-01 EM LCD INSULATING TAPE (871)
314 4-423-394-01 EM LCD UNIT CASE (871)
LCD901 A-1943-506-A LCD BLOCK ASSY (SERVICE)
#2 2-635-562-31 SCREW (M1.7)
#12 3-080-204-21 SCREW, TAPPING, P2
Screw
#12: M1.7 X 5.0 (Tapping)
(Black)
3-080-204-21
1.7
5.0
#2: M1.7 X 4.0
(Black)
2-635-562-31
4.0
1.7
#12
#12
#12
#12
#12
ns
ns
304
308 309
311
312
313
314
310
306
#12
#2
LCD901
ns
ns
ns
301
303
307
305
A
A
302

SLT-A58K/A58M/A58Y_L2
2-10
2-1-8. STROBE BASE/VF LENS SECTION
ns: not supplied
Screw
#2: M1.7 X 4.0
(Black)
2-635-562-31
4.0
1.7
#5: M1.7 X 3.5 (Tapping)
(Black)
3-080-204-01
3.5
1.7
Ref. No. Part No. Description Ref. No. Part No. Description
#12: M1.7 X 5.0 (Tapping)
(Black)
3-080-204-21
1.7
5.0
351 1-492-093-11 FLASH UNIT (FL87600)
352 4-460-636-01 ST CASE U (876)
353 A-1933-717-A MIS-2000 FLEXIBLE BOARD, COMPLETE
354 4-460-633-01 ST SHOE COVER (876)
355 4-460-635-01 CV MIC GRILLE (876)
356 4-293-724-01 ST ARM COVER
357 4-293-710-01 CV MIC CUSHION
358 4-293-709-01 CV MIC UNIT HOLDER
359 1-820-649-11 HOUSING, CONNECTOR 2P (Red)
360 1-820-649-21 HOUSING, CONNECTOR 2P (Yellow)
361 X-2587-047-1 BD SHOE FRAME ASSY (876)
362 A-1933-718-A SHM-2000 FLEXIBLE BOARD, COMPLETE
363 X-2587-048-1 ST BASE ASSY (876)
364 4-293-682-01 IM SHEET, RADIATION
365 X-2586-488-1 VM VF LENS ASSY(876)
366 A-1933-720-A EYE-012 FLEXIBLE BOARD, COMPLETE
367 4-460-634-01 ST SWITCH PLATE (876)
LCD902 8-753-379-22 ECX333AA-1
MIC901 1-542-899-21 MICROPHONE UNIT
PL901 1-455-061-11 SOLENOID, PLUNGER
#2 2-635-562-31 SCREW (M1.7)
#5 3-080-204-01 SCREW, TAPPING, P2
#12 3-080-204-21 SCREW, TAPPING, P2
ns
ns ns
#5
#5
#5
#2
#2
#12
PL901
MIC901
ns
352
353
354
355
351
356
357
358
367
361
362
363
#5

LCD902
(Note)
364
365
366
A
A
B
B
Claws
359 360
1. The meaning of the symbol in left figure is as follows. Be careful when you remove it.
◇: Solder
DISASSEMBLY
Note: Refer to “1-3. NOTES FOR REPLACING THE EVF
DISPLAY DEVICE (LCD902) OR THE AM-1001 BOARD”
on page 1-1.
Note

SLT-A58K/A58M/A58Y_L2
2-11
2-1-9. BATTERY HOLDER SECTION
ns: not supplied
Ref. No. Part No. Description Ref. No. Part No. Description
401 4-192-221-01 BD CONDENSER TAPE
402 X-2586-485-1 BD GYRO BASE ASSY (876)
403 A-1933-719-A MCR-2000 FLEXIBLE BOARD, COMPLETE
404 A-1933-715-A GO-1002 BOARD, COMPLETE
405 2-891-459-01 LID (SP), BATTERY
406 4-293-726-01 EM BT EMI PLATE
407 X-2586-486-1 BD BATTERY HOLDER ASSY(876)
408 4-293-657-01 CV MEDIA LID COVER SHAFT
409 4-460-629-01 CV MEDIA COVER (876)
410 4-293-658-01 CV MEDIA LID COVER SP
411 4-293-652-01 BD BATTERY LOCK
412 4-293-654-01 BD BATTERY LOCK SHAFT
413 4-293-653-01 BD BATTERY LOCK SP
414 4-293-662-01 BD BT LID COVER SHAFT
415 X-2582-396-1 BD BATTERY LID ASSY
BT901 1-780-588-21 TERMINAL BOARD, BATTERY
C901 1-116-522-11 CAP, ELECT 180uF 330V
#2 2-635-562-31 SCREW (M1.7)
#5 3-080-204-01 SCREW, TAPPING, P2
DISASSEMBLY
1. The meaning of the symbol in left figure is as follows. Be careful when you remove it.
◇: Solder
Screw
#2: M1.7 X 4.0
(Black)
2-635-562-31
4.0
1.7
#5: M1.7 X 3.5 (Tapping)
(Black)
3-080-204-01
3.5
1.7
ns
ns
ns
ns
BT901
ns
#5
#5
#2
C901
407
408
409
410
413
402
401
404 403
406
414
405
415
411
412

