SERVICE MANUAL

CD/DVD PLAYER

System

Laser: Semiconductor laser

Signal format system:

PAL/NTSC (NC60K: E/NC62K)

Signal format system:

NTSC (NC60K: MX)

Audio characteristics

Frequency response: DVD VIDEO

(PCM 96 kHz): 2 Hz to 44 kHz

(±1.0 dB)/DVD VIDEO

(PCM 48 kHz): 2 Hz to 22 kHz

(±0.5 dB)/

CD: 2 Hz to 20 kHz (±0.5 dB)

Signal-to-noise ratio (S/N ratio): 115 dB

(LINE OUT L/R (AUDIO) jacks only)

Harmonic distortion: 0.003%

Dynamic range: DVD VIDEO: 103 dB/

CD: 99 dB

Wow and flutter: Less than detected value

(±0.001% W PEAK)

Outputs

(Jack name: Jack type/Output level/

Load impedance)

LINE OUT (AUDIO): Phono jack/

2 Vrms/ 10 kilohms

DIGITAL OUT (OPTICAL):

Optical output jack/–18 dBm

(wave length 660 nm)

DIGITAL OUT (COAXIAL): Phono jack/

0.5 Vp-p/75 ohms

COMPONENT VIDEO OUT (NC62K)

(Y, PB/CB, PR/CR): Phono jack/

Y: 1.0 Vp-p, PB/CB,

PR/CR: 0.7 Vp-p/75 ohms

COMPONENT VIDEO OUT (NC60K)

(Y, PB, PR):

Phono jack/Y: 1.0 Vp-p/PB, PR:

interlace*1 = 0.648 Vp-p, progressive or

interlace*2 = 0.7 Vp-p/75 ohms

*1 BLACK LEVEL

(COMPONENT OUT) is ON

*2 BLACK LEVEL

(COMPONENT OUT) is OFF

LINE OUT (VIDEO): Phono jack/

1.0 Vp-p/ 75 ohms

S VIDEO OUT: 4-pin mini DIN/Y:

1.0 Vp-p, C: 0.3 Vp-p (PAL),

0.286 Vp-p (NTSC)/ 75 ohms

(NC60K: E/NC62K)

S VIDEO OUT: 4-pin mini DIN/Y:

1.0 Vp-p, C: 0.286 Vp-p/ 75 ohms

(NC60K: MX)

MIC Input 1/2: Phono jacks

SPECIFICATIONS

General

Power requirements:

110 – 240 V AC, 50/60 Hz

(NC60K: E/NC62K)

120 V AC, 60 Hz

(NC60K: MX)

Power consumption: 11 W

Dimensions (approx.):

430 ×83 × 416 mm

(16 15/16 ×3 17/64 ×16 24/64 in.)

(width/height/depth) incl. projecting

parts

Mass (approx.): 4.4 kg (9 58/64 lb)

Operating temperature: 5°C to 35°C

Operating humidity: 25% to 80%

Supplied accessories

See page 14.

Specifications and design are subject to

change without notice.

Latin America Model

Mexico Model

DVP-NC60K

Australia/New Zealand Model

Singapore Model

DVP-NC62K

DVP-NC60K/NC62K

RMT-D178A/RMT-D178P

Photo : DVP-NC62K

RMT-D178P

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

— 2 —

DVP-NC60K/NC62K

SAFETY CHECK-OUT

1. Check the area of your repair for unsoldered or poorly-soldered

connections. Check the entire board surface for solder splashes

and bridges.

2. Check the interboard wiring to ensure that no wires are “pinched”

or contact high-wattage resistors.

3. Look for unauthorized replacement parts, particularly transis-

tors, that were installed during a previous repair. Point them out

to the customer and recommend their replacement.

4. Look for parts which, though functioning, show obvious signs

of deterioration. Point them out to the customer and recommend

their replacement.

5. Check the line cord for cracks and abrasion.

Recommend the replacement of any such line cord to the cus-

tomer.

6. Check the B+ voltage to see it is at the values specified.

7. Check the antenna terminals, metal trim, “metallized” knobs,

screws, and all other exposed metal parts forAC leakage. Check

leakage as described below.

WARNING!!

WHEN SERVICING, DO NOT APPROACH THE LASER EXIT

WITH THE EYE TOO CLOSELY. IN CASE IT IS NECESSARY TO

CONFIRM LASER BEAM EMISSION, BE SURE TO OBSERVE

FROM A DISTANCE OF MORE THAN 25 cm FROM THE SURFACE

OF THE OBJECTIVE LENS ON THE OPTICAL PICK-UP BLOCK.

CAUTION:

The use of optical instrument with this product will increase eye

hazard.

CAUTION

Use of controls or adjustments or performance of procedures

other than those specified herein may result in hazardous radiation

exposure.

SAFETY-RELATED COMPONENT WARNING!!

COMPONENTS IDENTIFIED BY MARK OR DOTTED LINE

WITH MARK ON THE SCHEMATIC DIAGRAMS AND IN

THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.

REPLACE THESE COMPONENTS WITH SONY PARTS

WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS

MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.

After correcting the original service problem, perform the following

safety checks before releasing the set to the customer:

LEAKAGETEST

The AC leakage from any exposed metal part to earth ground and

from all exposed metal parts to any exposed metal part having a

return to chassis, must not exceed 0.5mA (500 microampers).

Leakage current can be measured by any one of three methods.

1. A commercial leakage tester, such as the Simpson 229 or RCA

WT-540A. Follow the manufacturers’ instructions to use these

instruments.

2. A battery-operated AC milliammeter. The Data Precision 245

digital multimeter is suitable for this job.

3. Measuring the voltage drop across a resistor by means of a

VOM or battery-operated AC volmeter. The “limit” indication

is 0.75V, so analog meters must have an accurate low voltage

scale. The Simpson 250 and Sanwa SH-63Trd are examples of

a passive VOM that is suitable. Nearly all battery operated

digital multimeters that have a 2V AC range are suitable. (See

Fig. A)

Unleaded solder

Boards requiring use of unleaded solder are printed with the lead-

free mark (LF) indicating the solder contains no lead.

(Caution: Some printed circuit boards may not come printed with

the lead free mark due to their particular size.)

: LEAD FREE MARK

Unleaded solder has the following characteristics.

• Unleaded solder melts at a temperature about 40°C highter than

ordinary solder.

Ordinary soldering irons can be used but the iron tip has to be

applied to the solder joint for a slightly longer time.

Soldering irons using a temperature regulator should be set to

about 350°C

Caution: The printed pattern (copper foil) may peel away if the

heated tip is applied for too long, so be careful!

• Strong viscosity

Unleaded solder is more viscous (sticky, less prone to flow) than

ordinary solder so use caution not to let solder bridges occur such

as on IC pins, etc.

• Usable with ordinary solder

It is best to use only unleaded solder but unleaded solder may also

be added to ordinary solder.

ATTENTION AU COMPOSANT AYANT RAPPORT

À LA SÉCURITÉ!

LES COMPOSANTS IDENTIFÉS PAR UNE MARQUE SUR

LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES

SONT CRITIQUES POUR LA SÉCURITÉ DE

FONCTIONNEMENT. NE REMPLACER CES COMPOSANTS

QUE PAR DES PIÈSES SONY DONT LES NUMÉROS SONT

DONNÉS DANS CE MANUEL OU DANS LES SUPPÉMENTS

PUBLIÉS PAR SONY.

To Exposed Metal

Parts on Set

0.15 F 1.5k

Voltmeter

(0.75 V)

Earth Ground

Fig.A. Using an Acvoltmeter to check AC leakage.

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

— 3 —

DVP-NC60K/NC62K

TABLE OF CONTENTS

1. GENERAL

Warning .......................................................................... 1-1

Notes About the Discs .................................................. 1-1

Precautions.................................................................... 1-1

About this Manual .......................................................... 1-1

This Player Can Play the Following Discs................... 1-1

Index to Parts and Controls ......................................... 1-2

Guide to the Control Menu Display .............................. 1-3

Hookups ................................................................................ 1-3

Hooking Up the Player .................................................. 1-3

Step 1: Unpacking ......................................................... 1-3

Step 2: Inserting Batteries into the Remote ................. 1-3

Step 3: Connecting the Video Cords ............................ 1-4

Step 4: Connecting the Audio Cords ............................ 1-4

Step 5: Connecting the Mains Lead ............................. 1-5

Step 6: Quick Setup ...................................................... 1-5

Playing Discs ......................................................................... 1-5

Playing Discs ................................................................. 1-5

Resuming Playback from the Point Where You

Stopped the Disc (Multi-disc Resume) .................. 1-6

Using the DVD's Menu .................................................. 1-6

Selecting “ORIGINAL” or “PLAY LIST” on a

DVD-RW/DVD-R....................................................... 1-6

Playing VIDEO CDs With PBC Functions

(PBC Playback) ........................................................ 1-7

Various Play Mode Functions (Program Play,

Shuffle Play, Repeat Play, A-B Repeat Play ........... 1-7

Searching for a Scene .......................................................... 1-8

Searching for a Particular Point on a Disc (Search,

Scan, Slow-motion Play, Freeze Frame) ............... 1-8

Searching for a Title/Chapter/Track/Scene, etc. ......... 1-8

Searching by Scene (PICTURE NAVIGATION) ......... 1-9

Enjoying Karaoke .................................................................. 1-9

Using Karaoke ............................................................... 1-9

Changing the Key (Key Control) .................................. 1-9

Playing Karaoke with Any Stereo Disc

(Karaoke Pon) .......................................................... 1-9

Selecting the Vocals (Vocal Select) .............................. 1-10

Turning the Guide Melody On and Off

(Guide Melody) ......................................................... 1-10

Inserting the Applause Effect (Applause) .................... 1-10

Viewing Information About the Disc ..................................... 1-10

Checking the Playing Time and Remaining Time ........ 1-10

Sound Adjustments ............................................................... 1-11

Changing the Sound ...................................................... 1-11

TV Virtual Surround Settings (TVS) ............................. 1-11

Enjoying Movies .................................................................... 1-12

Changing the Angles ..................................................... 1-12

Displaying the Subtitles................................................. 1-12

Adjusting the Playback Picture

(CUSTOM PICTURE MODE) ................................. 1-12

Sharpening the Pictures (SHARPNESS)..................... 1-13

Enjoying MP3 Audio and JPEG Images .............................. 1-13

About MP3 Audio Tracks and JPEG Image Files ....... 1-13

Playing MP3 Audio Tracks or JPEG Image Files........ 1-13

Enjoying JPEG Images as a Slide Show ..................... 1-14

Enjoying DivX Videos ............................................................ 1-15

Playing DivX Video Files ............................................... 1-15

Using Various Additional Functions...................................... 1-15

Locking Discs (CUSTOM PARENTAL CONTROL,

PARENTAL CONTROL) .......................................... 1-15

Controlling Your TV with the Supplied Remote ............. 1-16

Settings and Adjustments..................................................... 1-16

Using the Setup Display ............................................... 1-16

Setting the Display or Sound Track Language

(LANGUAGE SETUP) ............................................. 1-17

Settings for the Display (SCREEN SETUP) ................ 1-17

Custom Settings (CUSTOM SETUP) .......................... 1-17

Settings for the Sound (AUDIO SETUP) ..................... 1-17

Additional Information ............................................................ 1-18

Troubleshooting ............................................................. 1-18

Self-diagnosis Function (When letters/

numbers appear in the display ................................ 1-19

Glossary ........................................................................ 1-19

Specifications................................................................. 1-19

2. DISASSEMBLY

2-1. Disassembly ............................................................ 2-1

2-2. Upper Case ............................................................. 2-1

2-3. Rear Panel Section ................................................. 2-2

2-4. MV-045 Board .......................................................... 2-2

2-5. Front Panel Section ................................................. 2-3

2-6. Table Ass’y .............................................................. 2-3

2-7. IF-127 Board............................................................ 2-4

2-8. Loading Motor Ass’y ............................................... 2-5

2-9. Optical Pick-Up

(Device, Optical KHM-310CAB/C2NP) ............ 2-6

2-10. Power Block ............................................................. 2-7

2-11. FR-231, SW-443 and MC-154 Boards .................. 2-7

2-12. Internal Views........................................................... 2-8

2-13. Circuit Boards Location........................................... 2-9

3. BLOCK DIAGRAMS

3-1. Overall Block Diagram .................................................. 3-1

3-2. Power Line Block Diagram ........................................... 3-3

3-3. System Control/Signal Processor Block Diagram ...... 3-5

3-4. RF/Servo Block Diagram .............................................. 3-7

3-5. Audio Block Diagram..................................................... 3-9

3-6. Video Block Diagram..................................................... 3-11

3-7. Interface Control Block Diagram .................................. 3-13

4. PRINTED WIRING BOARDS AND

SCHEMATIC DIAGRAMS

4-1. Frame Schematic Diagram ........................................... 4-1

4-2. Printed Wiring Boards and Schematic Diagrams........ 4-3

4-3. Waveform ...................................................................... 4-4

• MV-045 Printed Wiring Board .................................. 4-5

• MV-045 (CPU, Servo-DSP, AVDEC)

Schematic Diagram ............................................ 4-7

• MV-045 (Drive) Schematic Diagram ....................... 4-9

• MV-045 (Video) Schematic Diagram....................... 4-11

• MV-045 (Audio) Schematic Diagram....................... 4-13

• MV-045 (Power) Schematic Diagram...................... 4-15

• IF-127 Printed Wiring Board .................................... 4-17

• IF-127 (Interface) Schematic Diagram .................. 4-19

• SW-443 Printed Wiring Board ................................. 4-21

• SW-443 (Switch) Schematic Diagram .................... 4-23

• FR-231 Printed Wiring Board .................................. 4-25

• FR-231 (FR) Schematic Diagram ........................... 4-27

• MC-154 Printed Wiring Board ................................. 4-29

• MC-154 (MIC-ECHO) Schematic Diagram ............ 4-31

• Power Block (SRV1487UC)

Printed Wiring Board ........................................... 4-33

• Power Block (SRV1487UC) Schematic Diagram ... 4-35

• Power Block (SRV1501WW)

Printed Wiring Board ........................................... 4-37

• Power Block (SRV1501WW)

Schematic Diagram ............................................ 4-39

5. IC PIN FUNCTION DESCRIPTION

5-1. System Control Pin Function

(MV-045 BOARD IC101) .............................................. 5-1

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

— 4 —

DVP-NC60K/NC62K

— 4E —

6. TEST MODE

6-1. Executing IOP Measurement ....................................... 6-1

6-2. Emergency History Check ........................................... 6-1

6-3. Initializing Setup Data .................................................... 6-2

6-4. Version Information ....................................................... 6-3

6-5. If Con Self Diagnostic Function .................................... 6-3

7. ELECTRICAL ADJUSTMENT

7-1. Power Supply Output Voltage Check ........................... 7-1

7-2. Adjustment of Video System ......................................... 7-2

8. REPAIR PARTS LIST

8-1. Exploded Views ............................................................. 8-1

8-1-1. Main Section ............................................................. 8-1

8-1-2. Front Panel Section.................................................. 8-3

8-1-3. Loading Section ........................................................ 8-4

8-1-4. Chassis Section ....................................................... 8-5

8-2. Electrical Parts List ....................................................... 8-6

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1-1

DVP-NC60K/NC62K

WARNING

To prevent fire or shock

hazard, do not expose the

unit to rain or moisture.

To avoid electrical shock, do

not open the cabinet. Refer

servicing to qualified

personnel only.

The mains lead must only be

changed at a qualified

service shop.

CAUTION

The use of optical instruments with

this product will increase eye

hazard. As the laser beam used in

this CD/DVD player is harmful to

eyes, do not attempt to disassemble

the cabinet.

Refer servicing to qualified

personnel only.

Disposal of Old Electrical &

Electronic Equipment

This symbol is applicable only in

the European Union and other

European countries with separate

collection systems.

Precautions

Safety

To prevent fire or shock hazard, do

not place objects filled with

liquids, such as vases, on the

apparatus.

Installing

• Do not install the unit in an

inclined position. It is designed

to be operated in a horizontal

position only.

• Keep the unit and discs away

from equipment with strong

magnets, such as microwave

ovens, or large loudspeakers.

• Do not place heavy objects on

the unit.

Notes About the

Discs

• To keep the disc clean, handle

the disc by its edge. Do not touch

the surface.

• Do not expose the disc to direct

sunlight or heat sources such as

hot air ducts, or leave it in a car

parked in direct sunlight as the

temperature may rise

considerably inside the car.

• After playing, store the disc in its

case.

• Clean the disc with a cleaning

cloth.

Wipe the disc from the centre

out.

• Do not use solvents such as

benzine, thinner, commercially

available cleaners, or anti-static

spray intended for vinyl LPs.

• If you have printed the disc’s

label, dry the label before

playing.

About This Manual

• Instructions in this manual describe the controls on the remote. You can also use the controls on the player if they have

the same or similar names as those on the remote.

• “DVD” may be used as a general term for DVD VIDEOs, DVD+RWs/DVD+Rs (+VR mode) and DVD-RWs/DVD-Rs

(video mode).

• The meaning of the icons used in this manual is described below:

Icons Meanings

Functions available for DVD VIDEOs and DVD+RWs/DVD+Rs in +VR mode or DVD-

RWs/DVD-Rs in video mode

Functions available for DVD-RWs/DVD-Rs in VR (Video Recording) mode

Functions available for VIDEO CDs (including Super VCDs or CD-Rs/CD-RWs in video CD

format or Super VCD format)

Functions available for music CDs or CD-Rs/CD-RWs in music CD format

Functions available for DATA CDs (CD-ROMs/CD-Rs/CD-RWs containing MP3

audio

tracks, JPEG image files, and DivX

*2*3

video files)

Functions available for DATA DVDs (DVD-ROMs/DVD+Rs/DVD+RWs/DVD-Rs/DVD-

RWs) containing MP3

audio tracks, JPEG image files and DivX

*2*3

video files

*1 MP3 (MPEG-1 Audio Layer III) is a standard format defined by ISO (International Organization for Standardization)/IEC

(International Electrotechnical Commission) MPEG which compresses audio data.

*2 DivX

is a video file compression technology, developed by DivXNetworks, Inc.

*3 DivX, DivX Certified, and associated logos are trademarks of DivXNetworks, Inc. and are used under license.

This Player Can Play the

Following Discs

“DVD+RW,” “DVD-RW,” “DVD+R,”

“DVD-R,” “DVD VIDEO,” and “CD” logos

are trademarks.

Note about CDs/DVDs

The player can play CD-ROMs/CD-Rs/CD-

RWs recorded in the following formats:

– music CD format

– video CD format

– MP3 audio tracks, JPEG image files, and

DivX video files of format conforming to

ISO 9660* Level 1/Level 2, or its extended

format, Joliet

– KODAK Picture CD format

* A logical format of files and folders on CD-

ROMs, defined by ISO (International

Organization for Standardization).

The player can play DVD-ROMs/

DVD+RWs/DVD-RWs/DVD+Rs/DVD-Rs

recorded in the following format:

– MP3 audio tracks, JPEG image files and

DivX video files of format conforming to

UDF (Universal Disk Format).

Example of discs that the player

cannot play

The player cannot play the following discs:

• CD-ROMs/CD-Rs/CD-RWs other than

those recorded in the formats listed on this

page.

• CD-ROMs recorded in PHOTO CD format.

• Data part of CD-Extras.

• DVD Audios.

• DATA DVDs that do not contain MP3

audio tracks, JPEG image files, or DivX

video files.

• HD layer on Super Audio CDs.

Also, the player cannot play the following

discs:

• A DVD VIDEO with a different region

code.

• A disc that has a non-standard shape (e.g.,

card, heart).

• A disc with paper or stickers on it.

• A disc that has the adhesive of cellophane

tape or a sticker still left on it.

Region code

Your player has a region code printed on the

back of the unit and only will play DVD

VIDEOs (playback only) labelled with

identical region codes. This system is used to

protect copyrights.

DVD VIDEOs labelled will also play on

this player.

If you try to play any other DVD VIDEO, the

message “Playback prohibited by area

limitations.” will appear on the TV screen.

Depending on the DVD VIDEO, there may

be no region code indication, even though

playing the DVD VIDEO is prohibited by

area restrictions.

Format of discs

DVD VIDEO

DVD-RW/-R

DVD+RW/+R

VIDEO CD/

Music CD

CD-RW/-R

ALL

DVP–XXXX

00V 00Hz

00W

NO.

0-000-000-00

Region code

Precautions

On safety

Should any solid object or liquid fall into the

cabinet, unplug the player and have it

checked by qualified personnel before

operating it any further.

On power sources

• The player is not disconnected from the AC

power source (mains) as long as it is

connected to the wall outlet, even if the

player itself has been turned off.

• If you are not going to use the player for a

long time, be sure to disconnect the player

from the wall outlet. To disconnect the AC

power cord (mains lead), grasp the plug

itself; never pull the cord.

On placement

• Place the player in a location with adequate

ventilation to prevent heat build-up in the

player.

• Do not place the player on a soft surface

such as a rug.

• Do not place the player in a location near

heat sources, or in a place subject to direct

sunlight, excessive dust, or mechanical

shock.

On operation

• If the player is brought directly from a cold

to a warm location, or is placed in a very

damp room, moisture may condense on the

lenses inside the player. Should this occur,

the player may not operate properly. In this

case, remove the disc and leave the player

turned on for about half an hour until the

moisture evaporates.

• When you move the player, take out any

discs. If you don’t, the disc may be

damaged.

On adjusting volume

Do not turn up the volume while listening to

a section with very low level inputs or no

audio signals. If you do, the speakers may be

damaged when a peak level section is played.

On cleaning

Clean the cabinet, panel, and controls with a

soft cloth slightly moistened with a mild

detergent solution. Do not use any type of

abrasive pad, scouring powder or solvent

such as alcohol or benzine.

On cleaning discs

Do not use a commercially available cleaning

disc. It may cause a malfunction.

On transporting the player

Before transporting the player, follow the

procedure below to return the internal

mechanisms to their original positions.

Remove all the discs from the disc tray.

Press Ato close the disc tray.

Make sure that “NO DISC” appears on

the front panel display.

Press ?/1to turn off the player.

The player enters standby mode.

Disconnect the AC power cord (mains

lead).

If you have any questions or problems

concerning your player, please consult your

nearest Sony dealer.

IMPORTANT NOTICE

Caution: This player is capable of holding a

still video image or on-screen display image

on your television screen indefinitely. If

you leave the still video image or on-screen

display image displayed on your TV for an

extended period of time you risk permanent

damage to your television screen. Plasma

display panel televisions and projection

televisions are susceptible to this.

SECTION 1

GENERAL

This section is extracted from instruction

manual. 2-595-906-12

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1-2

DVP-NC60K/NC62K

Notes

• Notes about DVD+RWs/DVD+Rs, DVD-RWs/

DVD-Rs or CD-Rs/CD-RWs

Some DVD+RWs/DVD+Rs, DVD-RWs/DVD-

Rs, or CD-Rs/CD-RWs cannot be played on this

player due to the recording quality or physical

condition of the disc, or the characteristics of the

recording device and authoring software.

The disc will not play if it has not been correctly

finalized. For more information, refer to the

operating instructions for the recording device.

Note that some playback functions may not work

with some DVD+RWs/DVD+Rs, even if they

have been correctly finalized. In this case, view

the disc by normal playback. Also some DATA

CDs/DATA DVDs created in Packet Write

format cannot be played.

• Music discs encoded with copyright protection

technologies

This product is designed to playback discs that

conform to the Compact Disc (CD) standard.

Recently, various music discs encoded with

by some record companies. Please be aware that

among those discs, there are some that do not

conform to the CD standard and may not be

playable by this product.

•Note on DualDiscs

A DualDisc is a two sided disc product which

mates DVD recorded material on one side with

digital audio material on the other side.

However, since the audio material side does not

conform to the Compact Disc (CD) standard,

playback on this product is not guaranteed.

Note on playback operations of

DVDs and VIDEO CDs

Some playback operations of DVDs and

VIDEO CDs may be intentionally set by

software producers. Since this player plays

DVDs and VIDEO CDs according to the disc

contents the software producers designed,

some playback features may not be available.

Also, refer to the instructions supplied with

the DVDs or VIDEO CDs.

Copyrights

This product incorporates copyright

protection technology that is protected by

U.S. patents and other intellectual property

rights. Use of this copyright protection

technology must be authorized by

Macrovision, and is intended for home and

other limited viewing uses only unless

otherwise authorized by Macrovision.

Reverse engineering or disassembly is

prohibited.

Index to Parts and Controls

For more information, see the pages indicated in parentheses.

Front panel

A[/1(on/standby) button (22)

BDISC 1 – 5 buttons (23)

CH(play) button (22)

DX (pause) button (23)

Ex(stop) button (23)

F./>(previous/next) buttons (32)

GA(open/close) button (22)

HDISC SKIP button (22)

IPROGRESSIVE button/indicator (17)

Lights up when the player outputs

progressive signals.

J(remote sensor) (14)

KEXCHANGE button (24)

LDisc tray (22)

MFront panel display (9)

NMIC 1/2 (microphone) connectors (36)

OMIC 1/2 (microphone) LEVEL control

(36)

Rear panel

ADIGITAL OUT (COAXIAL) jack (18)

BLINE OUT L/R (AUDIO) jacks (18)

CLINE OUT (VIDEO) jack (15)

DS VIDEO OUT jack (15)

ECOMPONENT VIDEO OUT (Y, PB/

CB, PR/CR) jacks (15)

FDIGITAL OUT (OPTICAL) jack (18)

S VIDEO OUT

LINE OUT

COMPONENT VIDEO OUT

R-AUDIO-L

DIGITALOUT

COAXIAL VIDEO

YPB/CBPR/CR

OPTICAL

Front panel display

When playing back a DVD VIDEO/DVD-RW

When playing back a VIDEO CD with Playback Control (PBC) (27)

When playing back a CD, DATA CD (MP3 audio/DivX video)/DATA DVD (MP3 audio/DixV

video), or VIDEO CD (without PBC)

When playing DATA DVDs, the DVD indicator is displayed.

When playing DivX video files, the current track is not displayed.

zHint

You can adjust the lighting of the front panel

display by setting “DIMMER” in “CUSTOM

SETUP.” (page 69)

Note

The front panel display will turn off automatically

when the disc tray is opened.

Disc type

Current audio signal (45)

Lights up when you can

change the angle (48)

Lights up during Repeat Play (30)

Playing

status

Current disc

Disc numbers (23)

All Discs

Repeat mode

(30)

Playing time of the

current title (42)

Disc type

Playing

status

Lights up during A-B Repeat Play (31)

Disc numbers (23)

Current playing time (42)

Current disc

Disc type

Current track

(42)

Lights up during Repeat Play (30)

Lights up when playing MP3 audio tracks (52)

Playing

status

Current

disc

Disc numbers (23)

Current playing time (42)

All Discs Repeat

mode (30)

,continued

Remote

ATV [/1(on/standby) button (65)

BZ(open/close) button (23)

CNumber buttons (26)

The number 5 button has a tactile dot.*

DCLEAR button (28)

ETOP MENU button (26)

FC/X/x/cbuttons (26)

GORETURN button (22)

H/ (replay/step/advance/

step) buttons (23, 33)

I./>(previous/next) buttons (23)

Jm/M(scan/slow) buttons

(33)

KZOOM button (23, 56)

LSLOW PLAY/FAST PLAY buttons

(23)

MSUR (surround) button (46)

NVOCAL SELECT button (39)

O(audio) button (44)

P(subtitle) button (48)

Q[/1(on/standby) button (22)

R2(volume) +/– buttons (65)

The + button has a tactile dot.*

St(TV/video) button (65)

TPICTURE NAVI (picture navigation)

button (35, 55)

UTIME/TEXT button (41)

VMENU button (26)

WENTER button (20)

XDISPLAY button (11)

YH(play) button (22)

The Hbutton has a tactile dot.*

Zx(stop) button (23)

wj X(pause) button (23)

wk KEY CONTROL (#-2) buttons (37)

wl APPLAUSE button (40)

e; KARAOKE PON button (38)

ea DISC SKIP button (24)

es (angle) button (48)

* Use the tactile dot as a reference when operating

the player.

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1-3

DVP-NC60K/NC62K

Guide to the Control Menu Display

Use the Control Menu to select a function and to view related information. Press DISPLAY

repeatedly to turn on or change the Control Menu display as follows:

You can use the Control Menu display items for KARAOKE PON, VOCAL SELECT, GUIDE

MELODY or KEY CONTROL when the player is in karaoke mode only. For details, see page

36.

Control Menu display

The Control Menu display 1 and 2 will show different items depending on the disc type. For

details about each item, see the pages in parentheses.

Example: Control Menu display 1 when playing a DVD VIDEO.

Displays the scene number for VIDEO CDs

(PBC is on), track number for VIDEO CDs/CDs,

album number for DATA CDs/DATA DVDs.

Displays the index number for VIDEO CDs,

MP3 audio track number or JPEG image file

number for DATA CDs/DATA DVDs. DivX

video file number for DATA CDs/DATA DVDs.

Displays Super VCD as “SVCD,” DVD-R in VR

mode as “DVD-RW.”

Displays the date for JPEG files.

Appears when the player is in karaoke mode.

To turn off the display

Press DISPLAY repeatedly.

Control Menu display 1

Control Menu display 2

Control Menu display off

OFF

1 8 (3 4 )

1 2 (2 7 )

1 : 3 2 : 5 5

DVD VIDEO

Quit:

PROGRAM

ENTER DISPLAY

SET

OFF

Currently playing chapter number*

Playing time*

Total number of

chapters*

Options

Current setting

Total number of titles*

Playback status

(NPlayback,

XPause,

xStop, etc.)

Function name of

selected Control

Menu item

Operation message

Selected item

Control Menu items

Type of disc

being played*

Currently playing title number*

Currently playing disc number

,continued

List of Control Menu items

Item Item Name, Function

DISC (page 33)

Selects the disc to be played.

TITLE (page 33)/SCENE (page 34)/TRACK (page 33)

Selects the title, scene, or track to be played.

CHAPTER (page 33)/INDEX (page 33)

Selects the chapter or index to be played.

TRACK (page 34)

Selects the track to be played.

ORIGINAL/PLAY LIST (page 26)

Selects the type of titles (DVD-RW/DVD-R) to be played, the ORIGINAL one, or an

edited PLAY LIST.

TIME/TEXT (page 33)

Checks the elapsed time and the remaining playback time.

Input the time code for picture and music searching.

Displays the DVD/CD text, or the DATA CD/DATA DVD track or file name.

PROGRAM (page 28)

Selects the title, chapter, or track to play in the order you want.

SHUFFLE (page 29)

Plays the title, chapter, or track in random order.

REPEAT (page 30)

Plays the entire disc (all titles/all tracks/all albums) repeatedly or one title/chapter/track/

album/file repeatedly.

A-B REPEAT (page 31)

Specifies the parts you want to play repeatedly.

CUSTOM PICTURE MODE (page 49)

Adjusts the video signal from the player. You can select the picture quality that best suits

the programme you are watching.

SHARPNESS (page 51)

Exaggerates the outline of the image to produce a sharper picture.

PARENTAL CONTROL (page 62)

Set to prohibit playback on this player.

SETUP (page 66)

QUICK Setup (page 20)

Use Quick Setup to choose the desired language of the on-screen display, the aspect ratio

of the TV and the audio output signal.

CUSTOM Setup

In addition to the Quick Setup setting, you can adjust various other settings.

RESET

Returns the settings in “SETUP” to the default setting.

ALBUM (page 34)

Selects the album that contain JPEG image file to be played.

FILE (page 34)

Selects the JPEG image file to be played.

ALBUM (page 34)

Selects the album that contain DivX video file to be played.

FILE (page 34)

Selects the DivX video file to be played.

zHint

The Control Menu icon indicator lights up in green

when you select any item

except “OFF” (“PROGRAM,” “SHUFFLE,”

“REPEAT,” “A-B REPEAT,” “CUSTOM

PICTURE MODE,” “SHARPNESS,” “KARAOKE

MODE,” “KARAOKE PON,” “VOCAL

SELECT,” “GUIDE MELODY” only). The

“ORIGINAL/PLAY LIST” indicator lights up in

green when you select “PLAY LIST” (default

setting).

DATE (page 56)

Displays the date the picture was taken by a digital camera.

INTERVAL (page 58)

Specifies the duration for which the slides are displayed on the screen.

EFFECT (page 58)

Selects the effects to be used for changing slides during a slide show.

MODE (MP3, JPEG) (page 57)

Selects the data type; MP3 audio track (AUDIO), JPEG image file (IMAGE) or both

(AUTO) to be played when playing a DATA CD or DATA DVD.

KARAOKE PON (page 38)

Enjoys karaoke with a stereo-recorded disc, even if it is a non-karaoke disc, by reducing

the sound of the vocals.

VOCAL SELECT (page 39)

Selects different kind of vocals recorded in the disc.

GUIDE MELODY (page 40)

Listens to the guide melody.

KEY CONTROL (page 37)

Changes the key to suit your vocal range.

KARAOKE MODE (page 36)

Setting the player to karaoke mode.

Hookups

Hooking Up the Player

Follow steps 1 to 6 to hook up and adjust the settings of the player.

Notes

• Plug cords securely to prevent unwanted noise.

• Refer to the instructions supplied with the components to be connected.

• You cannot connect this player to a TV that does not have a video input jack.

• Be sure to disconnect the mains lead of each component before connecting.

Step 1: Unpacking

Check that you have the following items:

• Audio/Video cord (phono plug ×3 yphono plug ×3) (1)

• Remote commander (remote) (1)

• R6 (size AA) batteries (2)

Step 2: Inserting Batteries Into the Remote

You can control the player using the supplied remote. Insert two R6 (size AA) batteries by

matching the 3and #ends on the batteries to the markings inside the compartment. When

using the remote, point it at the remote sensor on the player.

Notes

• Do not leave the remote in an extremely hot or humid place.

• Do not drop any foreign object into the remote casing, particularly when replacing the batteries.

• Do not expose the remote sensor to direct light from the sun or a lighting apparatus. Doing so may cause a

malfunction.

• If you do not use the remote for an extended period of time, remove the batteries to avoid possible damage

from battery leakage and corrosion.

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1-4

DVP-NC60K/NC62K

Hookups

Step 3: Connecting the Video Cords

Connect this player to your TV monitor, projector, or AV amplifier (receiver) using a video cord.

Select one of the patterns Athrough C, according to the input jack on your TV monitor,

projector, or AV amplifier (receiver).

In order to view progressive signal (525p or 625p) pictures with a compatible TV, projector, or

monitor, you must use pattern C.

AIf you are connecting to a video input jack

Connect the yellow plug of an audio/video cord (supplied) to the yellow (video) jack. You will

enjoy standard quality images.

With this connection, select “NORMAL (INTERLACE)” (default) by pressing the

PROGRESSIVE button on the front panel.

VIDEO

AUDIO

INPUT

COMPONENT

VIDEO IN

INPUT

S VIDEO

Audio/video

cord (supplied)

Component video

cord (not supplied)

(yellow)

TV, projector, or AV

amplifier (receiver)

to S VIDEO OUT

TV, projector, or AV

amplifier (receiver)

(green)

S VIDEO cord

(not supplied)

TV, projector, or AV

amplifier (receiver)

(red)

(green)

(blue)

(red)

to LINE OUT (VIDEO)

l: Signal flow

CD/DVD player

to COMPONENT

VIDEO OUT

(blue)

(yellow)

Yellow

White (L)

Red (R)

Yellow

White (L)

Red (R)

,continued 16

BIf you are connecting to an S VIDEO input jack

Connect an S VIDEO cord (not supplied). You will enjoy high quality images.

With this connection, select “NORMAL (INTERLACE)” (default) by pressing the

PROGRESSIVE button on the front panel.

CIf you are connecting to a monitor, projector, or AV amplifier

(receiver) having component video input jacks (Y, P

, P

)

Connect the component via the COMPONENT VIDEO OUT jacks using a component video

cord (not supplied) or three video cords (not supplied) of the same kind and length. You will

enjoy accurate colour reproduction and high quality images.

If your TV accepts progressive 525p/625p format signals, use this connection and press the

PROGRESSIVE button on the front panel to output progressive signals. For details, see “Using

the PROGRESSIVE button” (page 17).

When connecting to a standard 4:3 screen TV

Depending on the disc, the image may not fit your TV screen. To change the aspect ratio, see

page 68.

To change the colour system

If the on-screen menu of the player does not appear on the connected TV, switch the player’s

colour system to match the colour system of the TV (NTSC or PAL).

First turn off the player by pressing "/1, and then press "/1again while holding down Xon the

player. The player turns back on, and the name of the colour system scrolls across the front panel

display.

Notes

• Do not connect a VCR, etc., between your TV and the player. If you pass the player signals via the VCR,

you may not receive a clear image on the TV screen. If your TV has only one audio/video input jack,

connect the player to this jack.

• Consumers should note that not all high definition television sets are fully compatible with this product and

may cause artifacts to be displayed in the picture. In case of 525 or 625 progressive scan picture problems,

it is recommended that the user switch the connection to the ‘standard definition’ output. If there are

questions regarding your TV set compatibility with this 525p and 625p DVD player model, please contact

our customer service centre.

Green

Blue

Red

Green

Blue

Red

VCR

CD/DVD player TV

Connect

directly

Hookups

Using the PROGRESSIVE button

By using the PROGRESSIVE button on the front panel, you can select the signal format in

which the player outputs video signals (Progressive or Interlace), and the conversion method for

progressive signals. The PROGRESSIVE indicator lights up when the player outputs

progressive signals.

Each time you press PROGRESSIVE, the display changes as follows:

PROGRESSIVE AUTO

PROGRESSIVE VIDEO

NORMAL (INTERLACE)

◆PROGRESSIVE AUTO

Select this setting when:

– your TV accepts progressive signals, and,

– the TV is connected to the COMPONENT VIDEO OUT jacks.

Normally select this under the above condition. This automatically detects the software type, and

selects the appropriate conversion method.

Note that the picture will not be clear or no picture will appear if you select these settings when

either of the above conditions is not met.

◆PROGRESSIVE VIDEO

Select this setting when:

– your TV accepts progressive signals, and,

– the TV is connected to the COMPONENT VIDEO OUT jacks, and

– you want to fix the conversion method to PROGRESSIVE VIDEO for video-based software.

Select this if the image is not clear when you select PROGRESSIVE AUTO.

Note that the picture will not be clear or no picture will appear if you select these settings when

either of the above conditions is not met.

◆NORMAL (INTERLACE)

Select this setting when:

– your TV does not accept progressive signals, or,

– your TV is connected to jacks other than the COMPONENT VIDEO OUT jacks (LINE OUT

(VIDEO) or S VIDEO OUT).

◆About DVD software types and the conversion method

DVD software can be divided into two types: film-based software and video-based software.

Video-based software is derived from TV, such as dramas and sit-coms, and displays images at

30 frames/60 fields (25 frames/50 fields) per second. Film-based software is derived from film

and displays images at 24 frames per second. Some DVD software contains both video and film.

In order for these images to appear natural on your screen when output in progressive format,

the progressive signals need to be converted to match the type of DVD software that you are

watching.

Notes

• When you play video-based software in progressive signal format, sections of some types of images may

appear unnatural due to the conversion process when output through the COMPONENT VIDEO OUT

jacks. Images from the S VIDEO OUT and LINE OUT (VIDEO) jacks are unaffected as they are output in

the normal (interlace) format.

• When using LINE OUT (VIDEO) or S VIDEO OUT, the picture may appear to flicker each time the

PROGRESSIVE button on the front panel is pressed (Interlace switches to Progressive or vice versa).

Step 4: Connecting the Audio Cords

Select one of the following patterns Aor B, according to the input jack on your TV monitor,

projector, or AV amplifier (receiver).

This will enable you to listen to sound.

zHint

For correct speaker location, see the operating instructions supplied with the connected components.

SVIDEO OUT

COMPONENT VIDEO OUT

VIDEO

AUDIO

INPUT

DIGITALOUT

COAXIAL

OPTICAL

R-AUDIO-L

LINE OUT

R-AUDIO-L

VIDEO

DIGITAL OUT

COAXIAL

OPTICAL

AV amplifier (receiver)

with a decoder

(red)

TV, projector, or AV

amplifier (receiver)

Audio/video

cord (supplied)

: Signal flow

Coaxial digital cord

(not supplied)

to DIGITAL OUT

(COAXIAL or OPTICAL)

to LINE OUT L/R (AUDIO)

Optical digital cord (not supplied)

Rear (L)

CD/DVD player

(white)

(yellow)*

(white)

(red)

[Speakers]

Front (L)

[Speakers]

to coaxial

digital input

Rear (R)

Front (R)

Subwoofer

Centre

* The yellow plug is used for video signals (page 15).

to optical

digital input

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1-5

DVP-NC60K/NC62K

Hookups

AConnecting to audio L/R input

jacks

This connection will use your TV’s or stereo

amplifier’s (receiver’s) two speakers for

sound. Connect using the audio/video cord

(supplied).

• Surround effect (page 46)

TV: Dynamic Theatre, Dynamic, Wide,

Night

Stereo amplifier (receiver): Standard, Night

BConnecting to a digital audio

input jack

If your AV amplifier (receiver) has a Dolby

Digital*

, DTS*

, or MPEG audio decoder

and a digital input jack, use this connection.

Connect using a coaxial or optical digital cord

(not supplied).

• Surround effect

Dolby Digital (5.1ch), DTS (5.1ch), MPEG

audio (5.1ch)

Manufactured under license from Dolby

Laboratories.

“Dolby,” “Pro Logic,” and the double-D symbol

are trademarks of Dolby Laboratories.

“DTS” and “DTS Digital Out” are trademarks of

Digital Theater Systems, Inc.

Notes

• After you have completed the connection, make

the appropriate settings in Quick Setup (page 20).

If your AV amplifier (receiver) has an MPEG

audio decoder function, set “MPEG” to “MPEG”

in AUDIO SETUP (page 71). Otherwise, no

sound or a loud noise will come from your

speakers.

• The surround sound effects of this player cannot

be used with this connection.

• In order to listen to DTS sound tracks, you must

use this connection. DTS sound tracks are not

output through the LINE OUT L/R (AUDIO)

jacks, even if you set “DTS” to “ON” in Quick

Setup (page 20).

Yellow

White (L)

Red (R)

Yellow

White (L)

Red (R)

Coaxial cord

Optical cord

Step 5: Connecting the Mains Lead

Plug the player and TV mains lead (power cord) into a mains.

Step 6: Quick Setup

Follow the steps below to make the minimum number of basic adjustments for using the player.

To skip an adjustment, press >. To return to the previous adjustment, press .. The on-

screen displays differ depending on the player model.

Turn on the TV.

Press [/1.

Switch the input selector on your

TV so that the signal from the

player appears on the TV screen.

“Press [ENTER] to run QUICK SETUP”

(press enter to run Quick Setup) appears

at the bottom of the screen. If this

message does not appear, select

“QUICK” (quick) under “SETUP”

(setup) in the Control Menu to run Quick

Setup (page 67).

Press ENTER without inserting a

disc.

The Setup Display for selecting the

language used in the on-screen display

appears.

The available languages differ depending

upon the player model.

Press X/xto select a language.

The player displays the menu and

subtitles in the selected language.

ENTER

LANGUAGE SETUP

OSD:

MENU:

AUDIO:

SUBTITLE:

CHINESE1

ENGLISH

CHINESE2

THAI

Hookups

Press ENTER.

The Setup Display for selecting the

aspect ratio of the TV to be connected

appears.

Press X/xto select the setting that

matches your TV type.

◆If you have a wide-screen TV or a 4:3

standard TV with a wide-screen mode

• 16:9 (page 68)

◆If you have a 4:3 standard TV

• 4:3 LETTER BOX or 4:3 PAN SCAN

(page 68)

Press ENTER.

The Setup Display for selecting the type

of jack used to connect your amplifier

(receiver) appears.

Press X/xto select the type of jack

(if any) you are using to connect to

an amplifier (receiver), then press

ENTER.

If you did not connect an AV amplifier

(receiver), select “NO,” then go to step

13.

If you connected an AV amplifier

(receiver) using just an audio cord, select

“YES: LINE OUTPUT L/R (AUDIO),”

then go to step 13.

If you connected an AV amplifier

(receiver) using either a digital optical or

coaxial cord, select “YES: DIGITAL

OUTPUT.”

Press X/xto select the type of

Dolby Digital signal you wish to

send to your amplifier (receiver).

If your AV amplifier (receiver) has a

Dolby Digital decoder, select “DOLBY

DIGITAL.” Otherwise, select “D-PCM.”

Press ENTER.

“DTS” is selected.

Press X/xto select whether or

not you wish to send a DTS signal

to your amplifier (receiver).

If your AV amplifier (receiver) has a

DTS decoder, select “ON.” Otherwise,

select “OFF.”

Press ENTER.

Quick Setup is finished and connections

are complete.

If your AV amplifier (receiver) has an

MPEG audio decoder, set “MPEG” to

“MPEG” (page 71).

SCREEN SETUP

TV TYPE: 16:9

4:3 LETTER BOX

4:3 PAN SCAN

FULL

COLOR SYSTEM:

BACKGROUND:

SCREEN SAVER:

4:3 OUTPUT:

16:9

YES

Is this player connected to an

amplifier (receiver) ? Select the type

of jack you are using.

LINE OUTPUT L/R (AUDIO)

DIGITAL OUTPUT

AUDIO SETUP

AUDIO ATT:

AUDIO DRC:

DIGITAL OUT:

DOLBY DIGITAL:

MPEG:

OFF

STANDARD

DOWNMIX: DOLBY SURROUND

D-PCM

DTS: DOLBY DIGITAL

48kHz/96kHz PCM: 48kHz/16bit

D-PCM

AUDIO SETUP

AUDIO ATT:

AUDIO DRC:

DIGITAL OUT:

DOLBY DIGITAL:

MPEG:

OFF

STANDARD

DOWNMIX: DOLBY SURROUND

D-PCM

PCM

DTS:

48kHz/96kHz PCM:

OFF

Playing Discs

Depending on the DVD or VIDEO CD, some

operations may be different or restricted.

Refer to the operating instructions supplied

with your disc.

Turn on your TV.

Press [/1.

The player turns on.

Switch the input selector on your

TV so that the signal from the

player appears on the TV screen.

◆When using an amplifier (receiver)

Turn on the amplifier (receiver) and

select the appropriate channel so that you

can hear sound from the player.

Press Aon the player, and place a

disc on the disc tray.

To place other discs on the tray, press

DISC SKIP and place the discs in the

order you want to play them.

Each time you press DISC SKIP, the disc

tray turns so you can place the discs on

the empty compartments. The player

plays from the last disc placed on the tray.

Press H.

The disc tray closes. The player starts

playback (continuous play). Adjust the

volume on the TV or the amplifier

(receiver).

Depending on the disc, a menu may

appear on the TV screen. For DVD

VIDEOs, see page 26. For VIDEO CDs,

see page 27.

To turn off the player

Press [/1. The player enters standby mode.

zHint

You can have the player turn off automatically

whenever you leave it in stop mode for more than

30 minutes. To turn this function on or off, set

“AUTO POWER OFF” in “CUSTOM SETUP” to

“ON” or “OFF” (page 69).

Notes on playing DTS sound tracks on a

DVD VIDEO

• DTS audio signals are output only through

the DIGITAL OUT (COAXIAL or

OPTICAL) jack.

• When you play a DVD VIDEO with DTS

sound tracks, set “DTS” to “ON” in

“AUDIO SETUP” (page 72).

• If you connect the player to audio

equipment without a DTS decoder, do not

set “DTS” to “ON” in “AUDIO SETUP”

(page 72). A loud noise may come out from

the speakers, affecting your ears or causing

the speakers to be damaged.

Note

Discs created on DVD recorders must be correctly

finalized before they can be played. For more

information about finalizing, refer to the operating

instructions supplied with the DVD recorder.

DISC SKIP

DISC SKI

ENTER

RETURN

Playback side

facing down

Disc

compartment

number

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1-6

DVP-NC60K/NC62K

Playing Discs

Additional operations

DVD VIDEOs/DVD-RWs/DVD-Rs only. The

button cannot be used for DivX video files.

DVD VIDEOs/DVD-RWs/DVD-Rs/

DVD+RWs/DVD+Rs only. The button cannot

be used for DivX video files.

Video and JPEG pictures only (except

BACKGROUND pictures). You can move the

enlarged picture using C/X/x/c. Depending

upon the contents of the disc, the zoom function

may be cancelled automatically when the

picture is moved.

Note

You may not be able to use the Replay or Advance

function with some scenes.

Playback quickly or slowly with

sound

You can listen to dialogue or sound while

playing the current scene quickly or slowly.

During playback, press FAST PLAY or

SLOW PLAY.

The speed changes when you press either

FAST PLAY or SLOW PLAY.

To return to normal playback

Press H.

Notes

• You can only use this function with DVDs/

VIDEO CDs/Super VCDs and DVD-RWs/DVD-

Rs in VR mode only.

• “Operation not possible” will appear when

maximum or minimum speed is reached.

• During Fast Play or Slow Play mode, you cannot

change the angle (page 48), subtitle (page 48) and

sound (page 44). The sound can only be changed

for VIDEO CDs/Super VCDs.

• Fast Play and Slow Play functions do not work

when playing DTS sound tracks.

• You cannot use Fast Play or Slow Play functions

when playing a still picture on DVD-RW/DVD-R

in VR mode.

To Operation

Select a disc Press DISC 1-5 on the

player

Stop Press x

Pause Press X

Resume play after

pause

Press Xor H

Go to the next disc Press DISC SKIP

Go to the next chapter,

track, or scene in

continuous play mode

Press >

Go back to the

previous chapter,

track, or scene in

continuous play mode

Press .

Stop play and remove

the disc

Press Z

Replay the previous

scene*

Press (replay)

during playback

CLEAR

(replay)

ZOOM

SLOW PLAY FAST PLAY

DISC SKIP

(advance)

DISC SKIP

DISC 1-5

CLEAR

(replay)

ZOOM

SLOW PLAY FAST PLAY

DISC SKIP

(advance)

Briefly fast forward

the current scene*

Press

(advance) during

playback

Magnify the image*

Press ZOOM

repeatedly. Press

CLEAR to cancel.

To Operation

,continued 24

Replacing discs while playing a

disc (EXCHANGE)

You can open the disc tray while playing a

disc so that you can check which discs are to

be played next and replace discs without

interrupting playback of the current disc.

Press EXCHANGE.

The disc tray opens and two disc

compartments appear. Even if the player

is playing a disc, it doesn’t stop playing.

Replace the discs in the

compartments with new ones.

Press DISC SKIP.

The disc tray turns and another two disc

compartments appear.

Replace the discs in the

compartments with new ones.

Press EXCHANGE.

The disc tray closes.

zHint

While the disc tray is open,

– If the playback of the current disc end, the player

stops playing. If the disc is played in One Disc

Repeat Play mode (page 30), the current disc

starts playing again.

– In Shuffle Play mode (page 29), titles/tracks/

chapters are reshuffled only on the current disc.

– In Program Play mode (page 28), the titles/tracks/

chapters only on the current disc are played.

Note

Do not push the disc tray to close in step 5, as you

may damage the player.

Locking the disc tray (Child

Lock)

You can lock the disc tray to prevent children

from opening it.

When the player is in standby mode, press

ORETURN, ENTER, and then [/1on the

remote.

The player turns on and “LOCKED” appears

on the front panel display. The

and

EXCHANGE

buttons on the player and the Z

button on the remote do not work while the

Child Lock is set.

To unlock the disc tray

When the player is in standby mode, press

ORETURN, ENTER, and then [/1again.

Note

Even if you select “RESET” under “SETUP” in the

Control Menu (page 67), the disc tray remains

locked.

EXCHANGE

DISC SKIP

Playing Discs

Resuming Playback From

the Point Where You

Stopped the Disc

(Multi-disc

Resume)

The player stores the point where you stopped

the disc for up to 6 discs and resumes

playback the next time you insert the same

disc. If you store a resume playback point for

the seventh disc, the resume playback point

for the first disc is deleted.

While playing a disc, press xto

stop playback.

“RESUME” appears on the front panel

display.

Press H.

The player starts playback from the point

where you stopped the disc in step 1.

zHint

To play from the beginning of the disc, press x

twice, then press H.

Notes

• “MULTI-DISC RESUME” in “CUSTOM

SETUP” must be set to “ON” (default) for this

function to work (page 70).

• The point where you stopped playing is cleared

when:

– you change the play mode.

– you change the settings on the Setup Display.

• For DVD-RWs/DVD-Rs in VR mode, CDs,

DATA CDs, and DATA DVDs, the player

remembers the resume playback point for the

current disc.

The resume point is cleared when:

– you press DISC SKIP or DISC 1–5.

– you opened the disc tray.

– you disconnect the mains lead (CD or DATA CD/

DATA DVD only).

– the player enters standby mode (DATA CD/

DATA DVD only).

• Resume Play does not work during Shuffle Play

and Programme Play.

• This function may not work with some discs.

• If “MULTI-DISC RESUME” in “CUSTOM

SETUP” is set to “ON” and you playback a

recorded disc such as DVD-RW, the player may

playback other recorded discs from the same

resume point. To play from the beginning, press

xtwice and then press H.

Using the DVD’s Menu

A DVD is divided into long sections of a

picture or a music feature called “titles.”

When you play a DVD which contains

several titles, you can select the title you want

using the TOP MENU button.

When you play DVDs that allow you to select

items such as language for the sound and

subtitles, select these items using the MENU

button.

Press TOP MENU or MENU.

The disc’s menu appears on the TV

screen.

The contents of the menu vary from disc

to disc.

Press C/X/x/cor the number

buttons to select the item you want

to play or change.

If you press the number buttons, the

following display appears.

Press the number buttons to select the

item you want.

Press ENTER.

Selecting “ORIGINAL” or

“PLAY LIST” on a DVD-

RW/DVD-R

Some DVD-RWs/DVD-Rs in VR (Video

Recording) mode have two types of titles for

playback: originally

recorded

titles (ORIGINAL)

and titles that can be created on recordable

DVD players for editing (PLAY LIST). You

can select the type of title to be played.

Press DISPLAY when the player is

in stop mode.

The Control Menu appears.

Press X/xto select

(ORIGINAL/PLAY LIST), then press

ENTER.

The options for “ORIGINAL/PLAY

LIST” appear.

Press X/xto select a setting.

• PLAY LIST: plays the titles created

from “ORIGINAL” for editing.

• ORIGINAL: plays the titles originally

recorded.

Press ENTER.

ENTER

TOP MENU

Number

buttons

ENTER

DISPLAY

1 8 (3 4 )

1 2 (2 7 )

DVD-RW

PLAY LIST

ORIGINAL

1 : 3 0 : 5 0

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1-7

DVP-NC60K/NC62K

Playing Discs

Playing VIDEO CDs With

PBC Functions

(PBC Playback)

PBC (Playback Control) allows you to play

VIDEO CDs interactively by following the

menu on the TV screen.

Start playing a VIDEO CD with PBC

functions.

The menu for your selection appears.

Press the number buttons to select

the item number you want.

Press ENTER.

Follow the instructions in the

menu for interactive operations.

Refer to the instructions supplied with the

disc, as the operating procedure may

differ depending on the VIDEO CD.

To return to the menu

Press ORETURN.

zHint

To play without using PBC, press ./> or the

number buttons while the player is stopped to select

a track, then press H or ENTER.

“Play without PBC” appears on the TV screen and

the player starts continuous play. You cannot play

still pictures such as a menu.

To return to PBC playback, press xtwice then

press H.

Note

Depending on the VIDEO CD, “Press ENTER” in

step 3 may appear as “Press SELECT” in the

instructions supplied with the disc. In this case,

press H.

ENTER

RETURN

Number

buttons

Various Play Mode

Functions

(Programme Play,

Shuffle Play, Repeat Play, A-B Repeat

Play)

You can set the following play modes:

• Programme Play (page 28)

• Shuffle Play (page 29)

• Repeat Play (page 30)

• A-B Repeat Play (page 31)

Note

The play mode is cancelled when:

– you open the disc tray.

– the player enters standby mode by pressing [/1.

Creating your own programme

(Programme Play)

You can play the contents of a disc in the

order you want by arranging the order of the

titles, chapters, or tracks on the disc to create

your own programme. You can programme

up to 99 titles, chapters, and tracks.

1Press DISPLAY.

The Control Menu appears.

2Press X/xto select

(PROGRAM), then press ENTER.

The options for “PROGRAM” appear.

3Press X/xto select “SET

t,” then

press ENTER.

4Press c.

The cursor moves to the title or track row

“T” (in this case, “01”).

5Select the title, chapter, or track you

want to programme.

◆When playing a DVD VIDEO

For example, select chapter “03” of title

“02.”

Press X/x to select “02” under “T,” then

press ENTER.

CLEAR ENTER

DISPLAY

OFF

SET

PLAY

1 8 (3 4 )

1 2 (2 7 )

1 : 3 2 : 5 5

DVD VIDEO

PROGRAM

1. TITLE

ALL CLEAR

2. TITLE – –

3. TITLE – –

4. TITLE – –

5. TITLE – –

6. TITLE – –

7. TITLE – –

– –

“TRACK” is displayed when you play

a VIDEO CD, or CD.

Titles or tracks

recorded on a disc

PROGRAM

1. TITLE – –

ALL CLEAR

2. TITLE – –

3. TITLE – –

4. TITLE – –

5. TITLE – –

6. TITLE – –

7. TITLE – –

ALL

– –

Chapters recorded on a disc

PROGRAM

1. TITLE – –

ALL CLEAR

2. TITLE – –

3. TITLE – –

4. TITLE – –

5. TITLE – –

6. TITLE – –

7. TITLE – –

ALL

– –

Playing Discs

Next, press X/xto select “03” under “C,”

then press ENTER.

◆When playing a VIDEO CD, or CD

For example, select track “02.”

Press X/xto select “02” under “T,” then

press ENTER.

6To programme other titles, chapters,

or tracks, repeat steps 4 to 5.

The programmed titles, chapters, and

tracks are displayed in the selected order.

7Press Hto start Programme Play.

Programme Play begins.

When the programme ends, you can

restart the same programme again by

pressing H.

To return to normal play

Press CLEAR, or select “OFF” in step 3. To

play the same programme again, select “ON”

in step 3 and press ENTER.

To change or cancel a programme

Follow steps 1 to 3 of “Creating your

own programme (Programme Play).”

Select the programme number of the title,

chapter, or track you want to change or

cancel using X/x and press c. If you

want to delete the title, chapter, or track

from the programme, press CLEAR.

Follow step 5 for new programming. To

cancel a programme, select “--” under

“T,” then press ENTER.

To cancel all of the titles, chapters, or

tracks in the programmed order

Follow steps 1 to 3 of “

Creating your own

programme (Programme Play).”

Press X and select “ALL CLEAR.”

Press ENTER.

zHint

You can perform Repeat Play or Shuffle Play of

programmed titles, chapters, or tracks. During

Programme Play, follow the steps of Repeat Play

(page 30) or Shuffle Play (page 29).

Notes

• All Discs Repeat is automatically changed into

One Disc Repeat when you set to programme play

mode (page 30). You can only programme the

contents of the current disc.

• When you programme tracks on a Super VCD, the

total playing time is not displayed.

• You cannot use this function with VIDEO CDs or

Super VCDs with PBC playback.

Playing in random order (Shuffle

Play)

You can have the player “shuffle” titles,

chapters, or tracks. Subsequent “shuffling”

may produce a different playing order.

1Press DISPLAY during playback.

The Control Menu appears.

2Press X/x to select

(SHUFFLE), then press ENTER.

The options for “SHUFFLE” appear.

3Press X/xto select the item to be

shuffled.

◆When playing a DVD VIDEO

•TITLE

•CHAPTER

– –

PROGRAM

1. TITLE 0 2 – 0 3

ALL CLEAR

2. TITLE – –

3. TITLE – –

4. TITLE – –

5. TITLE – –

6. TITLE – –

7. TITLE – –

Selected title and chapter

Selected track

Set: Quit:

ENTER

Start:

PLAY

PROGRAM

1. TRACK 0 2

ALL CLEAR

2. TRACK – –

3. TRACK – –

4. TRACK – –

5. TRACK – –

6. TRACK – –

7. TRACK – –

0:15:30

– –

DISPLAY

Total time of the programmed tracks

PLAY

1 8 (3 4 )

1 2 (2 7 )

1 : 3 2 : 5 5

OFF

CHAPTER

TITLE

OFF

DVD VIDEO

,continued

◆When playing a VIDEO CD or CD

•TRACK

◆When Programme Play is activated

•ON: shuffles titles, chapters, or tracks

selected in Programme Play.

Press ENTER.

Shuffle Play starts.

To return to normal play

Press CLEAR, or select “OFF” in step 3.

zHints

• You can set Shuffle Play while the player is

stopped. After selecting the “SHUFFLE” option,

press H. Shuffle Play starts.

• Up to 200 chapters in a disc can be played in

random order when “CHAPTER” is selected.

Notes

• You cannot use this function with VIDEO CDs or

Super VCDs with PBC playback.

• All Discs Repeat is automatically changed into

One Disc Repeat when you set to shuffle play

mode. You can only shuffle the contents of the

current disc.

Playing repeatedly (Repeat Play)

You can play all of the titles or tracks on a

disc, or a single title, chapter, or track

repeatedly.

You can use a combination of Shuffle or

Programme Play modes.

Press DISPLAY during playback.

The Control Menu appears.

Press X/x to select

(REPEAT), then press ENTER.

The options for “REPEAT” appear.

Press X/xto select the item to be

repeated.

◆When playing a DVD VIDEO

• ALL DISCS: repeats all of the discs.

• ONE DISC: repeats all of the titles on

the current disc.

• TITLE: repeats the current title on a disc.

• CHAPTER: repeats the current chapter.

◆When playing a DVD-RW

• ALL DISCS: repeats all of the discs.

• ONE DISC: repeats all of the titles of

the selected type.

• TITLE: repeats the current title on a

disc.

• CHAPTER: repeats the current chapter.

◆When playing a VIDEO CD, or CD

• ALL DISCS: repeats all of the discs.

• ONE DISC: repeats all of the tracks on

the current disc.

• TRACK: repeats the current track.

◆When playing a DATA CD/DATA DVD

with MP3 audio tracks or JPEG image

files

• ALL DISCS: repeats all of the discs.

• ONE DISC: repeats all of the albums on

the current disc.

• ALBUM: repeats the current album.

• TRACK (MP3 audio tracks only):

repeats the current track.

• FILE (DivX video files only): repeats

the current file.

◆When Programme Play or Shuffle Play

is activated

•ON: repeats Programme Play or

Shuffle Play.

Press ENTER.

Repeat Play starts.

To return to normal play

Press CLEAR, or select “OFF” in step 3.

zHint

You can set Repeat Play while the player is stopped.

After selecting the “REPEAT” option, press H.

Repeat Play starts.

Notes

• You cannot use this function with VIDEO CDs or

Super VCDs with PBC playback.

• When repeating a DATA CD/DATA DVD which

contains MP3 audio tracks and JPEG image files,

and their playing times are not the same, the sound

will not match the image.

• When “MODE (MP3, JPEG)” is set to “IMAGE

(JPEG)” (page 57), you cannot select “TRACK.”

PLAY

1 8 (3 4 )

1 2 (2 7 )

1 : 3 2 : 5 5

OFF

ALL DISCS

ONE DISC

OFF

DVD VIDEO

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1-8

DVP-NC60K/NC62K

Playing Discs

Repeating a specific portion

(A-B Repeat Play)

You can play a specific portion of a title,

chapter or track repeatedly. (This function is

useful when you want to memorize lyrics,

etc.)

Press DISPLAY during playback.

The Control Menu appears.

Press X/xto select (A-B

REPEAT), then press ENTER.

The options for “A-B REPEAT”

appear.

Press X/xto select “SET t,” then

press ENTER.

The “A-B REPEAT” setting bar appears.

During playback, when you find the

starting point (point A) of the portion to

be played repeatedly, press ENTER.

The starting point (point A) is set.

When you reach the ending point

(point B), press ENTER again.

The set points are displayed and the

player starts repeating this specific

portion.

To return to normal play

Press CLEAR, or select “OFF” in step 3.

Notes

• When you set A-B Repeat Play, the settings for

Shuffle Play, Repeat Play, and Programme Play

are cancelled.

• A-B Repeat Play does not work across multiple

titles.

• You may not set A-B Repeat Play for contents on

a DVD-RW/DVD-R (VR mode) that contain still

pictures.

PLAY

SET

OFF

1 8 (3 4 )

1 2 (2 7 )

1 : 3 2 : 5 5

DVD VIDEO

A 18 - 1:32:30 B

A 18 - 1:32:55 B 18 - 1:33:05

Searching for a Scene

Searching for a

Particular Point on a

Disc

(Search, Scan, Slow-motion

Play, Freeze Frame)

You can quickly locate a particular point on a

disc by monitoring the picture or playing back

slowly.

Notes

• Depending on the disc, you may not be able to do

some of the operations described.

• For DATA CDs/DATA DVDs, you can search for

a particular point only on MP3 audio track or

DivX video file.

Locating a point quickly using

the PREV (previous)/NEXT (next)

buttons (Search)

You can search for the next or previous

chapter, track, or scene using ./>on

the player.

During playback, press >or .once

briefly to go to the next or previous chapter/

track/scene. Or, press and hold >or .

to search forward or backwards, and release

the button when you find the point you want

to return to normal playback. (Search)

Locating a point quickly by

playing a disc in fast forward or

fast reverse (Scan)

Press mor Mwhile playing a

disc. When you find the point you want, press

Hto return to normal speed. Each time you

press mor Mduring scan, the

scan speed changes. With each press the

indication changes as shown below. Actual

speeds may differ between discs.

Playback direction

Opposite direction

* DivX video only

The “×2B”/ “×2b” playback speed is about

twice the normal speed.

The “3M”/“3m” playback speed is faster

than “2M”/“2m” and the “2M”/“2m”

playback speed is faster than “1M”/

“1m.”

(step) (step)

×2Bt 1Mt2Mt3M

3M(DVD VIDEO/DVD-RW/VIDEO CD/DATA

CD*/DATA DVD*only)

×2B(DVD VIDEO/CD only)

×2bt1mt2mt3m

3m(DVD VIDEO/DVD-RW/VIDEO CD/DATA

CD*/DATA DVD*only)

×2b(DVD VIDEO only)

Searching for a Scene

Watching frame by frame

(Slow-motion Play)

Press mor Mwhen the player is

in pause mode. To return to normal speed,

press H.

Each time you press mor M

during Slow-motion Play, the playback speed

changes. Two speeds are available. With each

press the indication changes as follows:

Playback direction

2y1

Opposite direction (DVD/DVD-RW only)

2y1

The “2 y”/“2 ” playback speed is slower

than “1 y”/“1 .”

Note

For DATA CDs/DATA DVDs, this function works

only for DivX video files.

Playing one frame at a time

(Freeze Frame)

When the player is in the pause mode, press

(step) to go to the next frame. Press

(step) to go to the preceding frame

(DVD/DVD-RW only). To return to normal

playback, press H.

Notes

• You cannot search for a still picture on a DVD-

RW/DVD-R in VR mode.

• For DATA CDs/DATA DVDs, this function

works only for DivX video files.

Searching for a Title/

Chapter/Track/Scene,

etc.

You can search a DVD by title or chapter, and

you can search a VIDEO CD/CD/DATA CD/

DATA DVD by track, index, or scene. As

titles and tracks are assigned unique numbers

on the disc, you can select the desired one by

entering its number. You can also search for a

scene using the time code.

Press DISPLAY (when playing a

DATA CD or DATA DVD with JPEG

image files, press twice).

The Control Menu appears.

Press X/xto select the search

method.

◆When playing a DVD VIDEO/DVD-RW

DISC

TITLE

CHAPTER

TIME/TEXT

Select “TIME/TEXT” to search for a starting

point by inputting the time code.

◆When playing a VIDEO CD or Super VCD

without PBC playback

DISC

TRACK

INDEX

ENTER

CLEAR

DISPLAY

Number

buttons

,continued

◆When playing a VIDEO CD or Super VCD

with PBC Playback

DISC

SCENE

◆When playing a CD

DISC

TRACK

◆When playing a DATA CD/DATA DVD

DISC

ALBUM

TRACK (MP3 audio tracks only)

FILE (JPEG image files only)

◆When playing a DATA CD/DATA DVD

(DivX video files)

DISC

ALBUM

FILE

Example: when you select

CHAPTER

“** (**)” is selected (** refers to a number).

The number in parentheses indicates the total

number of titles, chapters, tracks, indexes,

scenes, album or files.

Press ENTER.

“** (**)” changes to “-- (**).”

Press the number buttons to select

the title, chapter, track, index,

scene, etc., number you want to

search.

If you make a mistake

Cancel the number by pressing CLEAR,

then select another number.

Press ENTER.

The player starts playback from the

selected number.

To search for a scene using the time code

(DVD VIDEO/DVD-RW only)

In step 2, select TIME/TEXT.

“T **:**:**” (playing time of the current

title) is selected.

Press ENTER.

“T **:**:**” changes to “T --:--:--.”

Input the time code using the number

buttons, then press ENTER.

For example, to find the scene at 2 hours,

10 minutes, and 20 seconds after the

beginning, just enter “2:10:20.”

zHints

• When the Control Menu display is turned off, you

can search for a chapter (DVD VIDEO/DVD-

RW), track (CD/DATA CD/DATA DVD), or file

(DATA CD/DATA DVD (DivX video)) by

pressing the number buttons and ENTER.

• You can display the first scene of titles, chapters,

or tracks recorded on the disc on a screen divided

into 9 sections. You can start playback directly by

selecting one of the scenes. For details, see

“Searching by Scene (PICTURE

NAVIGATION)” (page 35).

Notes

• The title, chapter, or track number displayed is the

same number recorded on the disc.

• You cannot search for a scene on a DVD+RW/

DVD+R using the time code.

DVD VIDEO

1 8 (3 4 )

1 2 (2 7 )

1 : 3 2 : 5 5

Selected row

DVD VIDEO

(3 4 )

1 2 (2 7 )

1 : 3 2 : 5 5

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1-9

DVP-NC60K/NC62K

Searching for a Scene

Searching by Scene

(PICTURE NAVIGATION)

You can divide the screen into 9 subscreens

and find the desired scene quickly.

Press PICTURE NAVI during

playback.

The following display appears.

Press PICTURE NAVI repeatedly to

select an item.

• CHAPTER VIEWER (DVD VIDEO

only): displays the first scene of each

chapter.

• TITLE VIEWER (DVD VIDEO only):

displays the first scene of each title.

• TRACK VIEWER (VIDEO CD/

Super VCD only): displays the first

scene of each track.

Press ENTER.

The first scene of each chapter, title, or

track appears as follows.

Press C/X/x/cto select a chapter,

title, or track, and press ENTER.

Playback starts from the selected scene.

To return to normal play during setting

Press ORETURN or DISPLAY.

zHint

If there are more than 9 chapters, titles, or tracks, V

is displayed at the bottom right of the screen.

To display the additional chapters, titles, or tracks,

select the bottom scenes and press x. To return to

the previous scene, select the top scenes and press

Note

Depending on the disc, you may not be able to select

some items.

DISPLAY


NAVI

RETURN

ENTER

CHAPTER VIEWER

ENTER

Enjoying Karaoke

Using Karaoke

You can enjoy karaoke (singing along with a

disc) by setting this player to karaoke mode.

You can connect up to two microphones (not

supplied) to the player.

Setting the player to karaoke

mode

The player enters karaoke mode when a

microphone is plugged into the MIC 1 or 2

connector.

The player exits from karaoke mode when

you disconnect the microphones from both of

the MIC 1 and 2 connectors.

You may also turn the karaoke mode on and

off by selecting “KARAOKE MODE” in the

Control Menu display using X/x, and then

pressing ENTER. For details about the

Control Menu operations, see “Guide to the

Control Menu Display” on page 11.

When you turn the karaoke mode on with

DVDs or Super VCDs, karaoke play is

performed with the audio channel you

selected using the (audio) button

(page 44). With CDs or VIDEO CDs, the

Audio setting automatically changes to “1/L”

so that only the accompaniment is played

when you turn the karaoke mode on. If the

vocal audio is heard with some discs, select

the audio channel for karaoke play using the

(audio) button (page 44).

Note

When you set the player to the karaoke mode, you

cannot use the Fast Play or Slow Play function

(page 23).

Adjusting the microphone

1Set the MIC 1/2 LEVEL control of the

MIC connector to MIN.

2Plug a microphone (not supplied) into

the MIC connector.

When a microphone is connected to the

MIC 1 or 2 connector, the player enters

karaoke mode.

3Set the ON/OFF switch on the

microphone to ON and turn the MIC

1/2 LEVEL control to adjust the

microphone volume.

zHint

If howling occurs:

– move the microphone away from the speakers.

– lower the overall volume.

Notes

• The sound input from the microphone is not

output from the DIGITAL OUT (OPTICAL and

COAXIAL) connectors.

• You can turn the karaoke mode off even when a

microphone is connected to the MIC 1 or 2

connectors by selecting the “KARAOKE MODE”

to “OFF” in the Control Menu display.

ENTER

DISPLAY

MIC 1/2 connectors

MIC 1/2 LEVEL control

Microphones

(not supplied)

Enjoying Karaoke

Dolby Digital Karaoke format

Dolby Digital format, which reproduces

surround sound using 5 channels, can also

contain the “Dolby Digital Karaoke” format

which is specialized for karaoke. In the Dolby

Digital Karaoke format discs, guide melody

and guide vocal tracks are recorded in

addition to the accompaniment. You can

select them when the player is in karaoke

mode.

Speaker output in normal Dolby Digital

format (5 channel surround)

Speaker output in Dolby Digital Karaoke

format

You can check the audio information using

(audio) button (page 44). When playing a

Dolby Digital Karaoke disc, “9” appears at

the current audio format (page 45).

Example:

Changing the Key

(Key

Control)

You can change the key to suit your vocal

range.

While playing karaoke, press one of the KEY

CONTROL buttons repeatedly to find the key

that suits your vocal range.

Press KEY CONTROL while playing

a disc in karaoke mode.

The following display appears.

Press KEY CONTROL repeatedly to

select the desired vocal range.

Front (L) Centre Front (R)

Rear (L) Rear (R)

Accompaniment

(L)

Accompaniment

(R)

Guide melody

Guide vocal 1 Guide vocal 2

You can select any of these. These are

output from the front speakers (L, R).

DOLBY DIGITAL

3/2

2/0: Recorded only with

accompaniment.

3/0: Recorded with guide

melody.

3/1: Recorded with guide

melody and guide

vocal.

3/2: Recorded with guide

melody and two kinds

of guide vocals.

To Press

Raise the key # (Sharp)

Lower the key 2 (Flat)

You can adjust the key in 15 half-tone

steps (7 steps higher, 7 steps lower and

the original or natural (3) key).

KEY

CONTRO

7654321 1234567

,continued

zHint

The key automatically returns to the original key

when:

– You turn off the power

– You remove the disc

– The title or track changes

Note

Depending on the discs, you may not be able to do

the operations above.

Playing Karaoke with

Any Stereo Disc

(Karaoke

Pon)

You can enjoy karaoke with a stereo-recorded

disc, even if it is a non-karaoke disc, by

reducing the sound of the vocals.

Press KARAOKE PON while playing a

disc in karaoke mode

The following display appears.

To cancel the Karaoke Pon function

Press KARAOKE PON again.

Notes

• This function may not work well in the following

cases:

– Only a few instruments are playing

– A duet is playing

– The vocals on the disc deviate from the centre

– Monaural-recorded discs (the accompaniment is

also reduced)

– Multiplex

• During the Karaoke Pon mode, the stereo effect is

reduced.

KARAOKE

PON

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1-10

DVP-NC60K/NC62K

Enjoying Karaoke

Selecting the Vocals

(Vocal Select)

You can select different kinds of vocals

recorded in the disc.

Press VOCAL SELECT while

playing a disc in karaoke mode.

The following display appears.

Press VOCAL SELECT repeatedly

to select the desired vocal

channel.

The output channel changes as follows.

The default setting is underlined.

◆When playing a DVD VIDEO

◆When playing a VIDEO CD or CD

◆When playing a Super VCD

zHints

• The channel returns to the default setting when:

– you turn off the power.

– you remove the disc.

• When playing a DVD VIDEO recorded only with

one kind of guide vocal, select “1.”

Notes

• When playing a DVD VIDEO, the function works

only with the Dolby Digital Karaoke format.

• Depending on the discs, you may not be able to do

the operations above.

• While playing a Super VCD on which the audio

track 2 is not recorded, no sound will come out

when you select “2:L+R” or “2:STEREO.”

VOCAL SELECT

1+2

OFF

1+2 (Guide vocal 1+2)

1 (Guide vocal 1)

2 (Guide vocal 2)

OFF

L+R (same sound is output from

both speakers)

STEREO (The standard stereo

sound)

OFF

1:L+R

1:STEREO (The stereo sound of

the audio track 1)

2:L+R

2:STEREO (The stereo sound of

the audio track 2)

Turning the Guide

Melody On and Off

(Guide

Melody)

You can listen to the guide melody.

Press DISPLAY twice while

playing a disc in karaoke mode.

The Control Menu appears.

Press X/x to select

(GUIDE MELODY), then press

ENTER.

The options for “GUIDE MELODY”

appear.

Press X/x to select the setting.

•OFF: To cancel the guide melody.

•ON: To turn on the guide melody.

Press ENTER.

Notes

• This function works only with the Dolby Digital

Karaoke format.

• If no guide melody is recorded on the disc, you

cannot hear the guide melody even if you turn it

on.

Inserting the Applause

Effect

(Applause)

When using the Karaoke mode, you can insert

applause with cheers.

Press APPLAUSE while playing a disc

in karaoke mode

Applause with cheers will sound each time

you press the button.

Notes

• This effect may not work with some DVDs or

during PBC playback of VIDEO CDs/Super

VCDs.

• You will not be able to hear the applause effect

from DIGITAL OUT (COAXIAL or OPTICAL)

jack when:

– you play a disc with DTS sound tracks.

– you set “DOLBY DIGITAL” to “DOLBY

DIGITAL” or “MPEG” to “MPEG” after setting

“DIGITAL OUT” to “ON” in “AUDIO SETUP.”

ENTER

DISPLAY

OFF

DVD VIDEO

APPLAUSE

Viewing Information About the Disc

Viewing Information About the

Disc

Checking the Playing

Time and Remaining

Time

You can check the playing time and

remaining time of the current title, chapter, or

track. Also, you can check the DVD/CD text

or track name (MP3 audio), or file name

(DivX video) recorded on the disc.

Press TIME/TEXT during playback.

The following display appears.

Press TIME/TEXT repeatedly to

change the time information.

The available time information depends

upon the type of disc you are playing.

◆When playing a DVD VIDEO or DVD-

•T

(hours: minutes: seconds)

Playing time of the current title

•T–

Remaining time of the current title

•C

Playing time of the current chapter

•C–

Remaining time of the current chapter

◆When playing a VIDEO CD or Super

VCD (with PBC functions)

•

(minutes: seconds)

Playing time of the current scene

◆When playing a VIDEO CD (without

PBC functions), or CD

•T

(minutes: seconds)

Playing time of the current track

•T–

Remaining time of the current track

•D

Playing time of the current disc

•D–

Remaining time of the current disc

◆When playing a Super VCD (without

PBC functions)

•T

(minutes: seconds)

Playing time of the current track

◆When playing a DATA CD (MP3 audio)/

DATA DVD (MP3 audio)

•T

(minutes: seconds)

Playing time of the current track

◆When playing a DATA CD (DivX video)/

DATA DVD (DivX video)

•

(hours: minutes: seconds)

Playing time of the current file

TIME/TEXT

T 1:01:57

Time

information

,continued

Checking the play information of

the disc

To check the DVD/CD text

Press TIME/TEXT repeatedly in step 2 to

display text recorded on the DVD/CD.

The DVD/CD text appears only when text is

recorded in the disc. You cannot change the

text. If the disc does not contain text, “NO

TEXT” appears.

To check DATA CD/DATA DVD album

name, etc.

By pressing TIME/TEXT while playing MP3

audio tracks or DivX video files on a DATA

CD/DATA DVD, you can display the name

of the album/track, and the audio bit rate (the

amount of data per second of the current

audio track) on your TV screen.

* Appears when:

– playing an MP3 audio track on a DATA CD/

DATA DVD.

– playing a DivX video file that contains MP3

audio on a DATA CD/DATA DVD.

Checking the information on the

front panel display

You can view the time information and text

displayed on the TV screen also on the front

panel display. The information on the front

panel display changes as follows when you

change the time information on your TV

screen.

When playing a DVD VIDEO or DVD-RW

When playing a DATA CD/DATA DVD (MP3

audio)

BRAHMS SYMPHONY

T 17:30 128k

JAZZ

RIVER SIDE

Bit rate*

Album name Track/file name

Playing time of the current title

Remaining time of the current title

Playing time of the current chapter

Remaining time of the current chapter

Text

Current title and chapter number

(returns to top automatically)

Playing time and number of the

current track

Track name

Current album and track number

(returns to top automatically)

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1-11

DVP-NC60K/NC62K

Viewing Information About the Disc

When playing a DATA CD (DivX video), or

DATA DVD (DivX video)

When playing a VIDEO CD (without PBC

functions), or CD

* The current track and index number appear only

when playing a VIDEO CD.

zHints

• When playing a VIDEO CDs without PBC

functions, the track number and the index number

are displayed after text.

• When playing VIDEO CDs with PBC functions,

the scene number or the playing time are

displayed.

• Long text that does not fit in a single line will

scroll across the front panel display.

• You can also check the time information and text

using the Control Menu (page 11).

Notes

• Depending on the type of disc being played, the

DVD/CD text or track name may not be

displayed.

• The player can only display the first level of the

DVD/CD text, such as the disc name or title.

• Playing time of MP3 audio tracks and DivX video

files may not be displayed correctly.

• If you play a disc containing JPEG image files

only, “NO AUDIO DATA” appears when

“MODE (MP3, JPEG)” is set to “AUTO,”

“JPEG” appears when “MODE (MP3, JPEG)” is

set to “IMAGE (JPEG)” in the front panel display.

Playing time of the current file

The current file name

The current album and file number

(returns to top automatically)

Track playing time and current disc

track number

Remaining time of the current track

Remaining time of the disc

Text

Playing time of the disc

Current disc, track

, and index number

(returns to top automatically)

Sound Adjustments

Changing the Sound

When playing a DVD VIDEO, DATA DVD

(DivX video files), or DATA CD (DivX

video files) recorded in multiple audio

formats (PCM, Dolby Digital, MPEG audio,

or DTS), you can change the audio format. If

the DVD VIDEO is recorded with

multilingual tracks, you can also change the

language.

With CDs, DATA CDs/DATA DVD, or

VIDEO CDs, you can select the sound from

either the right or left channel and listen to the

sound of the selected channel through both

the right and left speakers. For example, when

playing a disc containing a song with the

vocals on the right channel and the

instruments on the left channel, you can hear

the instruments from both speakers by

selecting the left channel.

Press (audio) during playback.

The following display appears.

Press (audio) repeatedly to

select the desired audio signal.

◆When playing a DVD VIDEO

Depending on the DVD VIDEO, the

choice of language varies.

When 4 digits are displayed, they

indicate a language code. See “Language

Code List” on page 79 to see which

language the code represents. When the

same language is displayed two or more

times, the DVD VIDEO is recorded in

multiple audio formats.

◆When playing a DVD-RW

The types of sound tracks recorded on a

disc are displayed. The default setting is

underlined.

Example:

• 1: MAIN (main sound)

• 1: SUB (sub sound)

• 1: MAIN+SUB (main and sub sound)

◆When playing a VIDEO CD, CD, or

DATA CD/DATA DVD (MP3 audio)

The default setting is underlined.

• STEREO: the standard stereo sound

• 1/L: the sound of the left channel

(monaural)

• 2/R: the sound of the right channel

(monaural)

◆When playing a DATA CD (DivX

video), or DATA DVD (DivX video)

The choice of DATA CD or DATA DVD

audio signal formats differ, depending on

the DivX video file contained on the disc.

The format is shown in the display.

◆When playing a Super VCD

The default setting is underlined.

• 1:STEREO: the stereo sound of the

audio track 1

• 1:1/L: the sound of the left channel of

the audio track 1 (monaural)

• 1:2/R: the sound of the right channel of

the audio track 1 (monaural)

• 2:STEREO: the stereo sound of the

audio track 2

• 2:1/L: the sound of the left channel of

the audio track 2 (monaural)

• 2:2/R: the sound of the right channel of

the audio track 2 (monaural)

Note

While playing a Super VCD on which the audio

track 2 is not recorded, no sound will come out

when you select “2:STEREO,” “2:1/L,” or “2:2/R.”

(audio)

ENGLISH DOLBY DIGITAL 3/2.1

Sound Adjustments

Checking the audio signal

format

You can check the audio signal format by

pressing (audio) repeatedly during

playback. The format of the current audio

signal (Dolby Digital, DTS, PCM, etc.)

appears as shown below.

◆When playing a DVD VIDEO

Example:

Dolby Digital 5.1 ch

Example:

Dolby Digital 3 ch

◆When playing a DivX video file on a DATA

CD or a DATA DVD

Example:

MP3 audio

About audio signals

Audio signals recorded in a disc contain the

sound elements (channels) shown below.

Each channel is output from a separate

speaker.

• Front (L)

• Front (R)

•Centre

• Rear (L)

• Rear (R)

• Rear (Monaural): This signal can be either

the Dolby Surround Sound processed

signals or the Dolby Digital sound’s

monaural rear audio signals.

• LFE (Low Frequency Effect) signal.

Notes

• If “DTS” is set to “OFF” in “AUDIO SETUP”

(page 72) the DTS track selection option will not

appear on the screen even if the disc contains DTS

tracks.

• MPEG audio signals with more than two channels

will appear as shown above (3/2.1, 2/1), but only

the Front (L) and Front (R) signals will be output

from your two front speakers.

ENGLISH DOLBY DIGITAL

3 / 2 .1

Rear (L/R)

Front (L/R)

+ Centre

LFE (Low Frequency

Effect)

2:SPANISH DOLBY DIGITAL

2 / 1

Front (L/R) Rear

(Monaural)

1: MP3 128k

Bit rate

TV Virtual Surround

Settings

(TVS)

When you connect a stereo TV or 2 front

speakers, TVS (TV Virtual Surround) lets

you enjoy surround sound effects by using

sound imaging to create virtual rear speakers

from the sound of the front speakers (L: left,

R: right) without using actual rear speakers.

TVS was developed by Sony to produce

surround sound for home use using just a

stereo TV.

This only works when playing a multichannel

Dolby audio soundtrack. Furthermore, if the

player is set up to output the signal from the

DIGITAL OUT (OPTICAL or COAXIAL)

jack, the surround effect will only be heard

when “DOLBY DIGITAL” is set to “D-

PCM” in “AUDIO SETUP” (page 71).

Press SUR during playback.

The following display appears.

Press SUR repeatedly to select

one of the TVS sounds.

See the explanations given for each item

in the following section.

• TVS DYNAMIC THEATER

• TVS DYNAMIC

•TVSWIDE

• TVS NIGHT

• TVS STANDARD

To cancel the setting

Select “OFF” in step 2.

◆TVS DYNAMIC THEATER

Creates one set of LARGE virtual rear

speakers and virtual subwoofer from the

sound of the front speakers (L, R) without

using actual rear speakers and subwoofer

(shown below).

This mode is effective when the distance

between the front L and R speakers is short,

such as with built-in speakers on a stereo TV.

◆TVS DYNAMIC

Creates one set of virtual rear speakers from

the sound of the front speakers (L, R) without

using actual rear speakers (shown below).

This mode is effective when the distance

between the front L and R speakers is short,

such as with built-in speakers on a stereo TV.

◆TVS WIDE

Creates five sets of virtual rear speakers from

the sound of the front speakers (L, R) without

using actual rear speakers (shown below).

This mode is effective when the distance

between the front L and R speakers is short,

such as with built-in speakers on a stereo TV.

SUR

TVS DYNAMIC THEATER

Sub

woofer

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1-12

DVP-NC60K/NC62K

Sound Adjustments

◆TVS NIGHT

Large sounds, such as explosions, are

suppressed, but the quieter sounds are

unaffected. This feature is useful when you

want to hear the dialogue and enjoy the

surround sound effects of “TVS WIDE” at

low volume.

◆TVS STANDARD

Creates three sets of virtual rear speakers

from the sound of the front speakers (L, R)

without using actual rear speakers (shown

below). Use this setting when you want to use

TVS with 2 separate speakers.

Notes

• When the playing signal does not contain a signal

for the rear speakers, the surround effects cannot

be heard.

• When you select one of the TVS modes, turn off

the surround setting of the connected TV or

amplifier (receiver).

• Make sure that your listening position is between

and at an equal distance from your speakers, and

that the speakers are located in similar

surroundings.

• Not all discs will respond to the “TVS NIGHT”

function in the same way.

• The TVS effects do not work when using the Fast

Play or Slow Play functions, even though you can

change the TVS modes.

• You select one of the TVS modes, the player does

not output the sound of center speaker.

L: Front speaker (left)

R: Front speaker (right)

: Virtual speaker

L R

Enjoying Movies

Changing the Angles

If various angles (multi-angles) for a scene

are recorded on the DVD VIDEO, “ ”

appears in the front panel display. This means

that you can change the viewing angle.

Press (angle) during playback.

The number of the angle appears on the

display.

Press (angle) repeatedly to

select an angle number.

The scene changes to the selected angle.

Note

Depending on the DVD VIDEO, you may not be

able to change the angles even if multi-angles are

recorded on the DVD VIDEO.

Displaying the Subtitles

If subtitles are recorded on the discs, you can

change the subtitles or turn them on and off

whenever you want while playing a DVD.

Press (subtitle) during

playback.

The following display appears.

Press (subtitle) repeatedly to

select a setting.

◆When playing a DVD VIDEO

Select the language.

Depending on the DVD VIDEO, the

choice of language varies.

When 4 digits are displayed, they

indicate a language code. See “Language

Code List” on page 79 to see which

language the code represents.

◆When playing a DVD-RW

Select “ON.”

◆When playing a DATA CD (DivX

video), or DATA DVD (DivX video)

The choices of DATA CD or DATA

DVD subtitles differ, depending on the

DivX video file contained on the disc.

The choices are shown in the display.

(angle)

(subtitle)

1:ENGLISH

Enjoying Movies

To turn off the subtitles

Select “OFF” in step 2.

Notes

• Depending on the DVD VIDEO, you may not be

able to change the subtitles even if multilingual

subtitles are recorded on it. You also may not be

able to turn them off.

• With DATA CDs/DATA DVDs, subtitles can be

changed for DivX video files only.

• You can change the subtitles if the DivX video

file has an “.AVI” or “.DIVX” extension and

contains subtitle information within the same file.

• While playing a disc with subtitles, the subtitle

may disappear when you press FAST PLAY or

SLOW PLAY button.

Adjusting the Playback

Picture (CUSTOM PICTURE MODE)

You can adjust the video signal of the DVD,

VIDEO CD, DATA CD/DATA DVD in

JPEG format, or DATA CD/DATA DVD

containing DivX video files from the player

to obtain the picture quality you want. Choose

the setting that best suits the programme you

are watching. When you select “MEMORY,”

you can make further adjustments to each

element of the picture (colour, brightness,

etc.).

Press DISPLAY twice during

playback.

The Control Menu appears.

Press X/xto select

(CUSTOM PICTURE MODE), then

press ENTER.

The options for “CUSTOM PICTURE

MODE” appear.

DISPLAY

RETURN

ENTER

,continued

Press X/xto select the setting you

want.

The default setting is underlined.

• STANDARD: displays a standard

picture.

• DYNAMIC 1: produces a bold

dynamic picture by increasing the

picture contrast and the colour

intensity.

• DYNAMIC 2: produces a more

dynamic picture than DYNAMIC 1 by

further increasing the picture contrast

and colour intensity.

• CINEMA 1: enhances details in dark

areas by increasing the black level.

• CINEMA 2: white colours become

brighter and black colours become

richer, and the colour contrast is

increased.

• MEMORY: adjusts the picture in

greater detail.

Press ENTER.

The selected setting takes effect.

zHint

When you watch a movie, “CINEMA 1” or

“CINEMA 2” is recommended.

Adjusting the picture items in

“MEMORY”

You can adjust each element of the picture

individually.

• PICTURE: changes the contrast

• BRIGHTNESS: changes the overall

brightness

• COLOR: makes the colours deeper or

lighter

• HUE: changes the colour balance

1In step 3 of “Adjusting the Playback

Picture,” select “MEMORY” and press

ENTER.

The “PICTURE” adjustment bar appears.

2Press C/cto adjust the picture

contrast.

To go the next or previous picture item

without saving the current setting, press

X/x.

3Press ENTER.

The adjustment is saved, and

“BRIGHTNESS” adjustment bar

appears.

4Repeat step 2 and 3 to adjust

“BRIGHTNESS,” “COLOR,” and

“HUE.”

To turn off the display

Press ORETURN, or DISPLAY.

Note

The “BRIGHTNESS” setting is not effective if you

connect the player via the LINE OUT (VIDEO) or

S VIDEO OUT jack and select “PROGRESSIVE

AUTO” or “PROGRESSIVE VIDEO” by using the

PROGRESSIVE button on the front panel.

DVD VIDEO

DYNAMIC 1

STANDARD

CINEMA 1

DYNAMIC 2

()

0 1 : 3 2 : 5 5


Cancel :Select :

ENTER RETURN

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1-13

DVP-NC60K/NC62K

Enjoying Movies

Sharpening the Pictures

(SHARPNESS)

You can enhance the outlines of images to

produce a sharper picture.

Press DISPLAY twice during

playback.

The Control Menu appears.

Press X/xto select

(SHARPNESS), then press ENTER.

The options for “SHARPNESS” appear.

Press X/xto select a level.

• 1: enhances the outline.

• 2: enhances the outline more than 1.

Press ENTER.

The selected setting takes effect.

To cancel the “SHARPNESS” setting

Select “OFF” in step 3.

Note

This setting is not effective if you connect the player

via the LINE OUT (VIDEO) or S VIDEO OUT jack

and select “PROGRESSIVE AUTO” or

“PROGRESSIVE VIDEO” by using the

PROGRESSIVE button on the front panel.

ENTER

DISPLAY

DVD VIDEO

OFF

Enjoying MP3 Audio and JPEG

Images

About MP3 Audio Tracks

and JPEG Image Files

MP3 is audio compression technology that

satisfies the ISO/IEC MPEG regulations.

JPEG is image compression technology.

You can play DATA CDs/DATA DVDs that

contain MP3 audio tracks or JPEG image

files.

DATA CDs/DATA DVDs that the

player can play

You can play back DATA CDs (CD-ROMs/

CD-Rs/CD-RWs) or DATA DVDs (DVD-

ROMs/DVD+RWs/DVD+Rs/DVD-RWs/

DVD-Rs) recorded in MP3 (MPEG-1 Audio

Layer III) and JPEG format.

However, this player only plays DATA CDs

whose logical format is ISO 9660 Level 1/

Level 2 or Joliet, and DATA DVDs of

Universal Disk Format (UDF).

Refer to the instructions supplied with the

disc drives and the recording software (not

supplied) for details on the recording format.

Note

The player may not be able to play some DATA

CDs/DATA DVDs created in the Packet Write

format.

MP3 audio track or JPEG image

file that the player can play

The player can play the following tracks and

files:

– MP3 audio tracks with the extension

“.MP3.”

– JPEG image files with the extension

“.JPEG” or “.JPG.”

– JPEG image files that conform to the DCF*

image file format.

* “Design rule for Camera File system”: Image

standards for digital cameras regulated by JEITA

(Japan Electronics and Information Technology

Industries Association).

Notes

• The player will play any data with the extension

“.MP3,” “.JPG,” or “.JPEG,” even if they are not

in MP3 or JPEG format. Playing these data may

generate a loud noise which could damage your

speaker system.

• The player does not conform to audio tracks in

mp3PRO format.

• Some JPEG files cannot be played.

• You cannot play MP3 audio tracks/JPEG image

files in DATA CDs/DATA DVDs that contain

DivX video files.

Enjoying MP3 Audio and JPEG Images

About playback order of albums,

tracks, and files

Albums play in the following order:

◆Structure of disc contents

When you insert a DATA CD/DATA DVD

and press H, the numbered tracks (or files)

are played sequentially, from 1through 7.

Any sub-albums/tracks (or files) contained

within a currently selected album take

priority over the next album in the same tree.

(Example: Ccontains Dso 4is played

before 5.)

When you press MENU and the list of album

names appears (page 54), the album names

are arranged in the following order:

AtBtCtDtFtG. Albums

that do not contain tracks (or files) (such as

album E) do not appear in the list.

zHints

• If you add numbers (01, 02, 03, etc.) to the front

of the track/file names when you store the tracks

(or files) in a disc, the tracks and files will be

played in that order.

• Since a disc with many trees takes longer to start

playback, it is recommended that you create

albums with no more than two trees.

Notes

• Depending on the software you use to create the

DATA CD/DATA DVD, the playback order may

differ from the above illustration.

• The playback order above may not be applicable

if there are more than 200 albums and 300 tracks/

files in each album.

• The player can recognize up to 200 albums (the

player will count just albums, including albums

that do not contain MP3 audio tracks and JPEG

image files). The player will not play any albums

beyond the 200th album.

• Proceeding to the next or another album may take

some time.

ROOT

Tree 1 Tree 2 Tree 3 Tree 4 Tree 5

Album Track or file

Playing MP3 Audio

Tracks or JPEG Image

Files

You can play MP3 audio tracks and JPEG

image files on DATA CDs (CD-ROMs/CD-

Rs/CD-RWs) or DATA DVDs (DVD-ROMs/

DVD+RWs/DVD+Rs/DVD-RWs/DVD-Rs).

zHint

You can view the disc information while playing

MP3 audio tracks (page 41).

Notes

• DATA CDs recorded in KODAK Picture CD

format automatically start playing when inserted.

• If no MP3 audio track or JPEG image file is

recorded on the DATA CD/DATA DVD, “No

audio data” or “No image data” appears on the

screen.

Selecting an album

Press MENU.

The list of albums on the disc appears.

When an album is being played, its title is

shaded.

Press X/xto select the album you

want to play.

Press H.

Playback starts from the selected album.

To select MP3 audio tracks, see

“Selecting an MP3 audio track”

(page 55).

To select JPEG image files, see

“Selecting a JPEG image file” (page 55).

To stop playback

Press x.

To go to the next or previous page

Press cor C.

To turn on or off the display

Press MENU repeatedly.

zHint

Of the selected album, you can select to play only

the MP3 audio tracks, JPEG image files, or both, by

setting “MODE (MP3, JPEG)” (page 57).


NAVI

RETURN

ENTER

ZOOM

1 (3 0 )

ROCK BEST HIT

KARAOKE

JAZZ

R&B

MY FAVORITE SONGS

CLASSICAL

SALSA OF CUBA

BOSSANOVA

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1-14

DVP-NC60K/NC62K

Enjoying MP3 Audio and JPEG Images

Selecting an MP3 audio track

After step 2 of “Selecting an album,”

press ENTER.

The list of tracks in the album appears.

Press X/xto select a track, and press

ENTER.

Playback starts from the selected track.

To stop playback

Press x.

To go to the next or previous page

Press cor C.

To return to the previous display

Press O RETURN.

To go to the next or previous MP3 audio

track

Press >or .during playback. You can

select the first track of the next album by

pressing >during playback of the last

track of the current album.

Note that you cannot return to the previous

album by using ., and that you need to

select the previous album from the album list.

Selecting a JPEG image file

After step 2 of “Selecting an album,”

press PICTURE NAVI.

The image files in the album appear in 16

subscreens. A scroll box is displayed on

the right.

To display the additional image, select

the bottom images and press x. To return

to the previous image, select the top

images and press X.

Press C/X/x/cto select the image you

want to view, and press ENTER.

The selected image appears.

Example

To go to the next or previous JPEG image

file

Press Cor c during playback. You can select

the first file of the next album by pressing c

during playback of the last file of the current

album.

Note that you cannot return to the previous

album by using C, and that you need to select

the previous album from the album list.

JAZZ

1 (9 0 )

01SHE IS SPECIAL

02ALL YOU NEED IS ...

03SPICY LIFE

04HAPPY HOUR

05RIVER SIDE

06 5

07TAKE TIME,TAKE TIME

1234

5678

13 14 15 16

9101112

,continued 56

To rotate a JPEG image

Press X/xwhile viewing the image. Each

time you press X, the image rotates

counterclockwise by 90 degrees.

To return to normal view, press CLEAR.

Note that the view also returns to normal if

you press C/cto go to the next or previous

image.

Example: when Xis pressed once.

To magnify a JPEG image (ZOOM)

Press ZOOM while viewing the image. You

can enlarge the image up to four times the

original size, and scroll using C/X/x/c.

To return to normal view, press CLEAR.

◆When pressed once (x2)

The image enlarges twice the original size.

◆When pressed twice (x4)

The image enlarges four times the original

size.

To stop viewing the JPEG image

Press x.

zHints

• While viewing JPEG image files, you can set

options such as “INTERVAL” (page 58),

“EFFECT” (page 58), and “SHARPNESS”

(page 51).

• You can view JPEG images files without MP3

audio by setting “MODE (MP3, JPEG)” to

“IMAGE (JPEG)” (page 57).

• The date the picture was taken is displayed beside

“DATE” in the Control Menu (page 11). Note that

no date may appear depending on the digital

camera.

Note

PICTURE NAVI does not work if “AUDIO (MP3)”

is selected in “MODE (MP3, JPEG)” (page 57).

Enjoying JPEG Images as

a Slide Show

You can play JPEG image files on a DATA

CD or DATA DVD successively as a slide

show.

Press MENU.

The list of albums on the DATA CD/

DATA DVD appears.

Press X/xto select an album.

Press H.

The JPEG images in the selected album

start playing as a slide show.

To stop playback

Press x.

Notes

• The slide show stops when X/xor ZOOM is

pressed.To resume the slide show, press H.

• This function does not work if “MODE (MP3,

JPEG)” is set to “AUDIO (MP3)” (page 57).

Rotating direction

ENTER

DISPLAY

1 (3 0 )

ROCK BEST HIT

KARAOKE

JAZZ

R&B

MY FAVORITE SONGS

CLASSICAL

SALSA OF CUBA

BOSSANOVA

Enjoying MP3 Audio and JPEG Images

Viewing a slide show with sound

(MODE (MP3, JPEG))

When JPEG image files and MP3 audio

tracks are placed in the same album, you can

enjoy a slide show with sound.

1Press DISPLAY during stop mode.

The Control Menu appears.

2Press X/xto select (MODE

(MP3, JPEG)), and press ENTER.

The options for “MODE (MP3, JPEG)”

appear.

3Press X/xto select “AUTO” (default),

and press ENTER.

• AUTO: plays both the JPEG image files

and MP3 audio tracks in the same

album as a slide show.

• AUDIO (MP3): plays only MP3 audio

tracks continuously.

• IMAGE (JPEG): plays only JPEG

image files continuously.

4Press MENU.

The list of albums on the DATA CD/

DATA DVD appears.

5Press X/xto select the album that

contains both the MP3 audio tracks

and JPEG images you want to play.

6Press H.

A slide show starts with sound.

zHints

• To repeat both MP3 audio tracks and JPEG image

files in a single album, repeat the same MP3 audio

track or album when “MODE (MP3, JPEG)” is set

to “AUTO.” See “Playing repeatedly (Repeat

Play)” (page 30) to repeat the track or album.

• The player recognizes a maximum of 200 albums

regardless of the selected mode. Of each album,

the player recognizes up to 300 MP3 audio tracks

and 300 JPEG image files when “AUTO” is

selected, 600 MP3 audio tracks when “AUDIO

(MP3)” is selected, 600 JPEG image files when

“IMAGE (JPEG)” is selected.

Notes

• This function does not work if the MP3 audio

tracks and JPEG image files are not placed in the

same album.

• If playing time of JPEG image or MP3 audio is

longer than the other, the longer one continues

without sound or image.

• If you play large MP3 track data and JPEG image

data at the same time, the sound may skip. It is

recommended that you set the MP3 bit rate to 128

kbps or lower when creating the file. If the sound

still skips, then reduce the size of the JPEG file.

• The player skips to the next disc if the current disc

contains MP3 audio tracks only and “MODE

(MP3, JPEG)” is set to “IMAGE (JPEG),” or the

disc contains JPEG image files only and “MODE

(MP3, JPEG)” is set to “AUDIO (MP3).” It is

recommended that you set “MODE (MP3,

JPEG)” to “AUTO.”

DATA CD

MP3

1 8 (3 4 )

1 2 (2 7 )

IMAGE (JPEG)

AUDIO (MP3)

AUTO

3 2 : 5 5

1 (3 0 )

ROCK BEST HIT

KARAOKE

JAZZ

R&B

MY FAVORITE SONGS

CLASSICAL

SALSA OF CUBA

BOSSANOVA

,continued

Setting the pace for a slide show

(INTERVAL)

You can set the time the slides are displayed

on the screen.

1Press DISPLAY twice while viewing a

JPEG image or when the player is in

stop mode.

The Control Menu appears.

2Press X/xto select

(INTERVAL), then press ENTER.

The options for “INTERVAL” appear.

3Press X/xto select a setting.

The default setting is underlined.

•NORMAL

: sets the duration to between

6 to 9 seconds.

• FAST: sets a duration shorter than

NORMAL.

• SLOW 1: sets a duration longer than

NORMAL.

• SLOW 2: sets a duration longer than

SLOW 1.

4Press ENTER.

Note

Some JPEG files, especially progressive JPEG files

or JPEG files of 3,000,000 pixels or more, may take

longer to display than others, which may make the

duration seem longer than the setting you selected.

Selecting the slides’ appearance

(EFFECT)

You can select the way the slides are

displayed during a slide show.

1Press DISPLAY twice while viewing a

JPEG image or when the player is in

stop mode.

2Press X/xto select (EFFECT),

then press ENTER.

The options for “EFFECT” appear.

3Press X/xto select a setting.

The default setting is underlined.

•MODE1

: the image sweeps in from top

to bottom.

• MODE 2: the image sweeps in from left

to right.

• MODE 3: the image stretches out from

the centre of the screen.

• MODE 4: the images randomly cycle

through the effects.

• MODE 5: the next image slides over the

previous image.

• OFF: turns off this function.

4Press ENTER.

2 0 0 5 / 1 0 / 2 9

NORMAL

DATA CD JPEG

NORMAL

INTERVAL

FAST

SLOW 1

SLOW 2

3 ( 1 2) 2 0 0 5 / 1 0 / 2 9

MODE 1

DATA CD JPEG

WIPE

MODE 1

MODE 2

MODE 3

MODE 4

MODE 5

OFF

3 ( 1 2)

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1-15

DVP-NC60K/NC62K

Enjoying DivX

Videos

Enjoying DivX®Videos

About DivX Video Files

DivX

is a video file compression

technology, developed by DivXNetworks,

Inc. This product is an official DivX

Certified product.

You can play DATA CDs and DATA DVDs

that contain DivX video files.

DATA CDs and DATA DVDs that

the player can play

Playback of DATA CDs (CD-ROMs/CD-Rs/

CD-RWs) and DATA DVDs (DVD-ROMs/

DVD+RWs/DVD+Rs/DVD-RWs/DVD-Rs)

on this player is subject to certain conditions:

– With DATA CDs/DATA DVDs that

contain DivX video files in addition to MP3

audio tracks or JPEG image files, the player

plays only the DivX video files.

However, this player only plays DATA CDs

whose logical format is ISO 9660 Level 1/

Level 2 or Joliet, and DATA DVDs of

Universal Disk Format (UDF).

Refer to the instructions supplied with the

disc drives and the recording software (not

supplied) for details on the recording format.

About playback order of data on DATA CDs

or DATA DVDs

See “About playback order of albums, tracks,

and files” (page 53). Note that the playback

order may not be applicable, depending on

the software used for creating the DivX video

file, or if there are more than 200 albums and

600 DivX video files in each album.

Note

The player may not be able to play some DATA

CDs/DATA DVDs created in the Packet Write

format.

DivX video files that the player

can play

The player can play data that is recorded in

DivX format, and which has the extension

“.AVI,” or “.DIVX.” The player will not play

files with the extension “.AVI” or “.DIVX” if

they do not contain a DivX video.

zHint

For details about playable MP3 audio tracks or

JPEG image files on DATA CDs/DATA DVDs, see

“DATA CDs/DATA DVDs that the player can

play” (page 52).

Notes

• The player may not play a DivX video file when

the file has been combined from two or more

DivX video files.

• The player cannot play a DivX video file of size

more than 720 (width) ×576 (height)/2 GB.

• Depending on the DivX video file, the picture

may be unclear or the sound may skip.

• The player cannot play some DivX video files that

are longer than 3 hours.

Playing DivX Video Files

You can play DivX video files on DATA CDs

(CD-ROMs/CD-Rs/CD-RWs) and DATA

DVDs (DVD-ROMs/DVD+RWs/DVD+Rs/

DVD-RWs/DVD-Rs).

zHints

• You can view the disc information while playing

a DivX video file (page 41).

• The player plays DivX video file either in PAL or

NTSC colour system according to the current

setting.

Notes

• If there are no DivX video files recorded on the

DATA CD/DATA DVD, a message appears to

indicate that the disc is not playable.

• Depending on the DivX video file, the picture

may pause or be unclear. In which case, it is

recommended that you create the file at a lower

bit rate. If the sound is still noisy, MP3 is the

recommended audio format. Note, however, this

player does not conform to WMA (Windows

Media Audio) format.

• Because of the compression technology used for

DivX video files, it may take some time after you

press H(play) for the picture to appear.

• Depending on the DivX video file, the sound may

not match the pictures on the screen.

Selecting an album

1Press MENU.

A list of albums on the disc appears. Only

albums that contain DivX video files are

listed.

2Press X/xto select the album you

want to play.

3Press H.

Playback starts from the selected album.

To select DivX video files, see “Selecting

a DivX video file” (page 61).

To stop playback

Press x.

To go to the next or previous page

Press Cor c.

To turn the display on or off

Press MENU repeatedly.

RETURN

ENTER

DISPLAY

3 (3)

SUMMER 2003

NEW YEAR'S DAY

MY FAVOURITES

Enjoying DivX

Videos

Selecting a DivX video file

1After step 2 of “Selecting an album,”

press ENTER.

The list of files in the album appears.

2Press X/xto select a file, and press

ENTER.

The selected file starts playing.

To stop playback

Press x.

To go to the next or previous page

Press Cor c.

To return to the previous display

Press ORETURN.

To go to the next or previous DivX video

file without turning on the above file list

You can select the next or previous DivX

video file in the same album by pressing >

or ..

You can also select the first file of the next

album by pressing >during playback of

the last file of the current album. Note that

you cannot return to the previous album by

using .. To return to the previous album,

select it from the album list.

zHint

If the number of viewing times is preset, you can

play the DivX video files as many times as the

preset number. The following occurrences are

counted:

– when the player is turned off. This includes when

the player is automatically turned off by the Auto

Power Off function. Press Xinstead of xwhen

you want to stop viewing

– when the disc tray is opened.

– when another file is played.

MY FAVOURITES

1 (2 )

HAWAII 2004

VENUS

Using Various Additional

Functions

Locking Discs

(CUSTOM

PARENTAL CONTROL, PARENTAL

CONTROL)

You can set two kinds of playback restrictions

for a disc.

• Custom Parental Control

You can set playback restrictions so that the

player will not play inappropriate discs.

• Parental Control

Playback of some DVD VIDEOs can be

limited according to a predetermined level

such as the age of the users. Scenes may be

blocked or replaced with different scenes.

The same password is used for both Parental

Control and Custom Parental Control.

Custom Parental Control

You can set the same Custom Parental

Control password for up to 40 discs. When

you set the 41st-disc, the first disc is

cancelled.

Insert the disc you want to lock.

If the disc is playing, press xto stop

playback.

Press DISPLAY while the player is in

stop mode.

The Control Menu appears.

Press X/xto select

(PARENTAL CONTROL), then press

ENTER.

The options for “PARENTAL

CONTROL” appear.

Press X/xto select “ON t,” then

press ENTER.

◆If you have not entered a password

The display for registering a new

password appears.

Enter a 4-digit password using the

number buttons, then press ENTER.

The display for confirming the password

appears.

◆When you have already registered a

password

The display for entering the password

appears.

Enter or re-enter your 4-digit password

using the number buttons, then press

ENTER.

“Custom parental control is set.” appears

and then the screen returns to the Control

Menu.

To turn off the Custom Parental Control

function

Follow steps 1 to 3 of “Custom Parental

Control.”

Press X/xto select “OFF t,” then press

ENTER.

Enter your 4-digit password using the

number buttons, then press ENTER.

ENTER

DISPLAY

Number

buttons

OFF

PASSWORD

PLAYER

DVD VIDEO

1 8 (3 4 )

1 2 (2 7 )

1 : 3 2 : 5 5

PARENTAL CONTROL

Enter a new 4-digit password,

then press .

ENTER

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1-16

DVP-NC60K/NC62K

Using Various Additional Functions

To play a disc for which Custom Parental

Control is set

1Insert the disc for which Custom Parental

Control is set.

The “CUSTOM PARENTAL

CONTROL” display appears.

2Enter your 4-digit password using the

number buttons, then press ENTER.

The player is ready for playback.

zHint

If you forget your password, enter the 6-digit

number “199703” using the number buttons when

the “CUSTOM PARENTAL CONTROL” display

asks you for your password, then press ENTER.

The display will ask you to enter a new 4-digit

password.

Parental Control (limited

playback)

Playback of some DVD VIDEOs can be

limited according to a predetermined level

such as the age of the users. The

“PARENTAL CONTROL” function allows

you to set a playback limitation level.

Press DISPLAY while the player is in

stop mode.

The Control Menu appears.

Press X/xto select

(PARENTAL CONTROL), then press

ENTER.

The options for “PARENTAL

CONTROL” appear.

Press X/xto select “PLAYER t,”

then press ENTER.

◆If you have not entered a password

The display for registering a new

password appears.

Enter a 4-digit password using the

number buttons, then press ENTER.

The display for confirming the password

appears.

◆When you have already registered a

password

The display for entering the password

appears.

Enter or re-enter your 4-digit password

using the number buttons, then press

ENTER.

The display for setting the playback

limitation level appears.

Press X/xto select “STANDARD,”

then press ENTER.

The selection items for “STANDARD”

are displayed.

Press X/xto select a geographic area

as the playback limitation level, then

press ENTER.

CUSTOM PARENTAL CONTROL

Custom parental control is already

set. To play, enter your password

and press

ENTER

OFF

PASSWORD

PLAYER

DVD VIDEO

1 8 (3 4 )

1 2 (2 7 )

1 : 3 2 : 5 5

PARENTAL CONTROL

Enter a new 4-digit password,

then press .

ENTER

PARENTAL CONTROL

LEVEL: OFF

USA

STANDARD:

PARENTAL CONTROL

LEVEL: OFF

USA

STANDARD:

USA

OTHERS

,continued 64

The area is selected.

When you select “OTHERS t,” select

and enter a standard code in the table on

page 79 using the number buttons.

Press X/xto select “LEVEL,” then

press ENTER.

The selection items for “LEVEL” are

displayed.

Select the level you want using X/x,

then press ENTER.

Parental Control setting is complete.

The lower the value, the stricter the

limitation.

To turn off the Parental Control function

Set “LEVEL” to “OFF” in step 8.

To play a disc for which Parental Control is

set

1Insert the disc and press H.

The display for entering your password

appears.

2Enter your 4-digit password using the

number buttons, then press ENTER.

The player starts playback.

zHint

If you forget your password, remove the disc and

repeat steps 1 to 3 of “Parental Control (limited

playback).” When you are asked to enter your

password, enter “199703” using the number

buttons, then press ENTER. The display will ask

you to enter a new 4-digit password. After you enter

a new 4-digit password, replace the disc in the

player and press H. When the display for entering

your password appears, enter your new password.

Notes

• When you play discs which do not have the

Parental Control function, playback cannot be

limited on this player.

• Depending on the disc, you may be asked to

change the parental control level while playing

the disc. In this case, enter your password, then

change the level. If the Resume Play mode is

cancelled, the level returns to the previous level.

Changing the password

Press DISPLAY while the player is in

stop mode.

The Control Menu appears.

Press X/xto select

(PARENTAL CONTROL), then press

ENTER.

The options for “PARENTAL

CONTROL” appear.

Press X/x to select “PASSWORD

t,” then press ENTER.

The display for entering the password

appears.

Enter your 4-digit password using the

number buttons, then press ENTER.

Enter a new 4-digit password using the

number buttons, then press ENTER.

To confirm your password, re-enter it

using the number buttons, then press

ENTER.

If you make a mistake entering your

password

Press Cbefore you press ENTER and input

the correct number.

PARENTAL CONTROL

LEVEL: OFF

OFF

STANDARD:

NC17

PARENTAL CONTROL

LEVEL:

STANDARD: USA

4: PG13

Using Various Additional Functions

Controlling Your TV with

the Supplied Remote

You can control the sound level, input source,

and power switch of your Sony TV with the

supplied remote.

You can control your TV using the buttons

below.

Note

Depending on the connected unit, you may not be

able to control your TV using all or some of the

buttons on the supplied remote.

Controlling other TVs with the

remote

You can control the sound level, input source,

and power switch of non-Sony TVs as well.

If your TV is listed in the table below, set the

appropriate manufacturer’s code.

1While holding down TV [/1, press the

number buttons to select your TV’s

manufacturer’s code (see the table

below).

2Release TV [/1.

Code numbers of controllable TVs

If more than one code number is listed, try

entering them one at a time until you find the

one that works with your TV.

Notes

• When you replace the batteries of the remote, the

code number you have set may be reset to the

default setting. Set the appropriate code number

again.

• Depending on the connected unit, you may not be

able to control your TV using all or some of the

buttons on the supplied remote.

By pressing You can

TV [/1Turn the TV on or off

2(volume) +/– Adjust the volume of the TV

t(TV/video) Switch the TV’s input source

between the TV and other

input sources.

2 (volume)+/

–

t(TV/video)

Number

buttons

Manufacturer Code number

Sony 01 (default)

Aiwa 01 (default)

Grundig 11

Hitachi 24

JVC 33

LG 06

Loewe 06

Panasonic 17, 49

Philips 06, 08

Samsung 06, 71

Sanyo 25

Sharp 29

Thomson 43

Toshiba 38

Settings and Adjustments

Using the Setup Display

By using the Setup Display, you can make

various adjustments to items such as picture

and sound. You can also set a language for the

subtitles and the Setup Display, among other

things.

For details on each Setup Display item, see

pages from 67 to 72.

Note

Playback settings stored in the disc take priority

over the Setup Display settings and not all of the

functions described may work.

Press DISPLAY when the player is

in stop mode.

The Control Menu appears.

Press X/xto select

(SETUP), then press ENTER.

The options for “SETUP” appear.

Press X/xto select “CUSTOM,”

then press ENTER.

The Setup Display appears.

Press X/xto select the setup item

from the displayed list:

“LANGUAGE SETUP,” “SCREEN

SETUP,” “CUSTOM SETUP,” or

“AUDIO SETUP.” Then press

ENTER.

The Setup item is selected.

Example: “SCREEN SETUP”

Press X/xto select an item, then

press ENTER.

The options for the selected item appear.

Example: “TV TYPE”

ENTER

DISPLAY

STOP

(5)

QUICK

CUSTOM

RESET

DVD VIDEO

QUICK

LANGUAGE SETUP

OSD:

MENU:

AUDIO:

SUBTITLE:

ENGLISH

ORIGINAL

ENGLISH

SCREEN SETUP

TV TYPE:

SCREEN SAVER:

BACKGROUND:

16:9

COLOR SYSTEM: AUTO

JACKET PICTURE

4:3 OUTPUT: FULL

Selected item

Setup items

SCREEN SETUP

TV TYPE:

SCREEN SAVER:

COLOR SYSTEM:

BACKGROUND:

16:9

4:3 LETTER BOX

4:3 OUTPUT:

4:3 PAN SCAN

FULL

16:9

Options

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

This manual suits for next models

Table of contents

Other Sony DVD Player manuals

Sony

Sony MEXDV2200 - DVD/SACD/CD Receiver User manual

Sony

Sony MV-101 - Mobile Dvd User manual

Sony

Sony DVP-SR101P User guide

Sony

Sony DVP-NC615 User manual

Sony

Sony DVP-NS39 User manual

Sony

Sony DVP-NS400D User manual

Sony

Sony DVP-S335 User manual

Sony

Sony DVP-S536D User manual

Sony

Sony DVP-NC85H - HDMI/CD Progressive Scan DVD... User manual

Sony

Sony XD-AX36 User manual

Sony

Sony 480p User manual

Sony

Sony DVP-F11 User manual

Sony

Sony SLV-D550P User manual

Sony

Sony DVP-SR760H User manual

Sony

Sony DVP-SR360 User guide

Sony

Sony DVP-SR450K User guide

Sony

Sony DVP-NS425P User manual

Sony

Sony DVP-NS38 User manual

Sony

Sony DVPC-X850D User manual

Sony

Sony DVP-NS78H User manual

Sony

Sony HCD-LF1 User manual

Sony

Sony DVP-FX820P - Portable Dvd Player Use and maintenance manual

Sony

Sony UBP-X700 User manual

Sony

Sony RDR-GX330 - DVD Recorder With TV Tuner User manual

Popular DVD Player manuals by other brands

Philips

Philips PD7000B Product data

Philips

Philips VidQuad TC8277 Specification sheet

AMW

AMW P460 user guide

waves system

waves system ID-AL My Video Player VP320 quick start guide

LG LH-SW5100 manual

Akai

Akai DV-P3470S Service manual

JVC

JVC XV-N327B user manual

Dazzle

Dazzle Creation Station 200 quick start guide

Toshiba

Toshiba HD-XA2 owner's manual

Philips

Philips DVP3146K/98 user manual

Philips

Philips MCD196/93 quick start guide

Denon

Denon DVD-1600 specification

Pioneer

Pioneer AVH-P4900DVD - DVD Player With LCD Monitor Service manual

Philips

Philips DVP762/75 user manual

Denver

Denver MTW-754 TWIN operating manual

NAD

NAD T512 owner's manual

Harman Kardon

Harman Kardon DVD 38 Service manual

Koss

Koss KS5845-2 owner's manual

Sony DVP-NC60K User manual

Popular DVD Player manuals by other brands
