KDL-V40XBR1
BRAVIA ™ XBR® Flat Panel Television
Key Features
ATSC Integrated Tuner with CableCARD™Slot
16:9 HD Resolution S-PVA Panel -1366(H) x 768(V)
WEGA Engine ™System
WCG-CCFL (Wide Color Gamut-CCFL) backlight
WEGA GATE ™-Easy Operation Guide
PC Input
HDMI™(High Definition Multimedia Interface) Connector
Key Technologies
7th Generation Sony ® LCD Panel The Sony® BRAVIA ™ XBR ®series uses the world’s first 7th generation Sony
LCD panel for truly matchless image quality and performance. Specially crafted at the S - LCD plant, these panels
are produced from the world ’s biggest mother glass to efficiently create large, high quality panels. The 1 Mega
Pixel S - PVA high definition display (1366 x 768) that is used offers an astounding 178 degree viewing angle, very
fast response times (8 ms total rise and fall time) and a spectacular contrast ratio.
WCG -CCFL (Wide Color Gamut-Cold Cathode Fluorescent Light) Sony brings decades of television expertise
and experience to LCD with a revolutionary backlight - WCG - CCFL. New spectrum phosphors have been developed
exclusively by Sony to deliver a very wide color gamut that exceeds the color gamut of ordinary CCFL backlights
and produces true reds, vivid greens and vibrant blues. Images are reproduced with enhanced vibrancy and
intensity resulting in an even greater sense of realism.
WEGA Engine ™ Because of the special demands HDTV places on signal quality a new generation of Sony’s
exclusive WEGA Engine™advanced picture quality system has evolved. Two innovative digital imaging processes
have been added to improve overall picture quality. A High Contrast Image processor dynamically detects the
histogram of each frame and instantly applies the ideal contrast level for crisper images. And the Natural High
Density Picture image processor reduces noise elements by intelligently separating the noise from the video
signal for a purer more detailed picture. Enjoy a stunning display of realistic images, amazing detail and
sharpness, reduced noise and enhanced clarity with improved depth and contrast.
WEGA GATE ® User Guide Explore and navigate your Sony “ BRAVIA ”television effortlessly with the WEGA GATE
user guide. You can easily change your settings or access your favorite TV channels and external inputs. Simply
touch the WEGA GATE button on the remote control to activate the comprehensive graphic menu. Your eyes remain
on the screen instead of searching in the dark for tiny buttons on the remote control.

SonyElectronicsInc. • 16530ViaEsprillo Drive • SanDiego,CA 92127 • 1-800-222-7669 • www.sony.com
Last Updated: 04/27/2006
KDL-V40XBR1
BRAVIA ™ XBR® Flat Panel Television
Pleasevisit theDealer Network forcurrent
information at www.sony.com/dn
Features
General
AutoSAP: Yes
ClosedCaption(CC): Yes
ID1Detection: Yes
VideoLabel: Yes
CleanWireManagement: Yes
Video
ScreenorDisplay Technology: 7th Generation LCD
Panel
Tuner: 8 VBS, ATSC, NTSC, Clear QAM
VideoProcessing: Yes (WEGA Engine ™ Technology)
ColorTemperature: Cool, Neutral, Warm 1, Warm 2
ColorCorrection: High, Low, Off
NoiseReduction: Yes
BlackCorrector: High, Medium, Low, Off
ClearWhite: High, Low, Off
ColorSpace: Wide, Normal
GammaCompensation: Max, High, Medium, Low, Off
LiveColor: High, Medium, Low, Off
CineMotion®Reverse 3:2PulldownTechnology: Yes
ContrastEnhancer: High, Low, Off
DirectDigitalII Circuitry: Yes
ScreenModes(4:3): Wide Zoom, Normal, Full, Zoom, Off
WideMode(16:9): Wide Zoom, Full, Zoom
WideMode(4:3): Wide Zoom, Normal, Full, Zoom
WideMode(PC): Normal, Full, Full 2, Zoom, Off
SlideShowMode: Slide Show transitions
DisplayMode for PCInput: Video, Text
CombFilter: 3D Digital Comb Filter
DRC®MultiFunctionCircuitry: Yes (DRC MF V1)
DRC®Mode: Yes
DRC®PalettePresets: Yes
GameMode: On/Off
AutoAdjustment(PC): Yes
Phase(PCOnly): Yes
Pitch(PCOnly): Yes
LightSensor: Yes
AdvancedVideoMenu: Yes
PictureModes: Vivid, Standard, Custom
ColorSystem: ATSC, NTSC
Audio
ToneControl(s): Treble, Bass
SoundMode: Dynamic, Standard, Custom
MTSStereoDecoder: Yes
A/VSynch: Off/1/2/3
DigitalAmplifier: Yes (S-Master®Digital Amplifier)
AudioMute: Yes
SpeakerOn/Off: Yes
SimulatedSurround: Yes
SRS®TruSurround®XTAudioEffect: Yes
Convenience
ChannelCaption: On, Off, Program
ChannelLabel: Yes
ChannelSkip/Add: Yes
ChannelJump: Yes
FavoriteChannel: Yes
Speed Surf™ChannelSelection: Yes
WEGA GATE™Technology: Yes
Scrolling Channel Index®System: 2 Event
ProgramGuideAccess: Yes
AutoChannelProgramming: Yes
MenuColor: Yes
MultipleLanguageDisplay: English, Español, Fran ç ais
Parental Control (V-Chip): Yes
ModeMemory: Yes
InfoBanner: Yes
ProgrammableTimer: 2 Event
SleepTimer: 15, 30, 45, 60, 90, Off
TimerEvents: Timer 1, Timer 2
CaptionVision: Basic, Digital CC, Advanced
Clock: Yes
PowerSaveMode: Standard, Reduced, Picture Off
Built -inACAdaptor: Yes
PictureFreeze: Yes (with side-by-side viewing)
Specifications
General
AspectRatio: 16:9
ScreenSize: 40"
Video
NativeResolution: 720p
ContrastRatio: 1300:1
DisplayResolution: 1366 x 768
Overscan: Normal, -1, -2
ViewingAngle: Right/Left: 178 ° , Up/Down: 178 °
DisplayResponseTime: 8ms
VerticalSize: Yes
VerticalCenter: Yes
HorizontalCenter: Yes
Brightness: Typical 480 cd/m
Audio
SpeakerType: 2-Way, Oval Cone
Speakers(Total): 4
TweeterSize: 1 4/7" (40mm)
FullRangeSpeaker Size: 40 x100mmOval, 40mm
Tweeter
AudioPowerOutput: 26W Total (13W x 2)
Inputs and Outputs
AnalogAudioInput(s): 6 (1 Front/5 Rear)
AudioOut(Variable/Fixed): 1 (Rear)
CableCARD™Slot: 1 (Rear)
ComponentVideo (Y/Pb/Pr )Input(s): 3(1 Front/2 Rear)
480i, 480p, 720p, 1080i
CompositeVideoInput(s): 3 (1 Front/2 Rear)
RFConnectionInput(s): 2 (Rear)
S-VideoInput(s): 1 (Rear)
HeadphoneOutput(s): 1 (Front)
PCAudioInput(s): 1 (Rear)
PCVideoInput(s): 1 (Rear)
HDMI™Connection(s): 1 (Rear) with Audio Input
OpticalAudioDigital Output(s): 1 (Rear) Dolby®
Digital
Power
InternalPowerSupply: Yes
PowerConsumption(in Operation): 240W
PowerConsumption(in Standby): Less than 0.15W
PowerRequirements: AC 120-240V, 50/60Hz
PowerManagement: Yes
Regulation and Standard Compliance
Energy Star®Compliant: Yes
VESA: Yes (200 x 100 hole pattern/ M4 thead size/
14mm hole depth)
Service and Warranty Information
LimitedWarranty: 1 Year Parts / 1 Year Labor
1
2
Dimensions
Weight: 68 lbs, 5 oz (34.3 kg) with pedestal; 54 lbs, 0 oz
(28.1 kg) without pedestal
Measurements: 3915/16" x28 15/16" x14
9/16" (1014.4 x 722.7 x 370.3 mm) with pedestal; 39
15/16" x 26 7/8" x 4 15/16" (1014.4 x 683.3 x 121.3 mm)
without pedestal
Supplied Accessories
Remote Control (RM-YD002)
Battery (Type AA, x2)
AC Power Cord
75-ohmCoaxialCable - TBD
D15-D15 Cable
Cable Clamper
Support Belt
Securing Screws
Operating Instructions
Quick Setup Guide
Warranty Card (SEL, SOCAN)
Leaflet - TBD
On-line Registration Card (SEL)
Optional Accessories
Wall-mount Bracket (SU-PW2)
UPCCode: 027242677272
Confidential Sony Information. For Internal Use Only.
1. Screen Size measured diagonally.
©2005 Sony Electronics Inc. All rights reserved.
Sony, XBR, S - Master, WEGA, WEGA GATE, WEGA Engine, Speed Surf, Dynamic
Picture, CineMotion and DRC are trademarks of Sony. CableCARD is a
trademark of Cable Television Laboratories, Inc. SRS and the SRS symbol,
and TruSurround are trademarks of SRS Labs, Inc. ENERGY STAR®and the
ENERGY STAR®mark are registered U.S. marks. BBE™is a trademark of BBE
Sound, Inc. This TV incorporates High - Definition Multimedia Interface (HDMI™ )
technology. HDMI, the HMDI logo and High - Definition Multimedia Interface
are trademarks or registered trademarks of HDMI Licensing LLC. All other
trademarks are property of their respective owners.
Features and specifications are subject to change without notice. Non -
metric weights and measures are approximate.
