PROTOCOL MANUAL
1st Edition

FWD-40LX1
FWD-32LX1R
Table of Contents
1. Communication Parameter ............................................................. 1
2. Pin Configuration .................................................................................. 1
3. Communication Data Format ......................................................... 1
4. General Function ................................................................................... 3
5. Picture/Sound ........................................................................................ 11
6. Size/Shift .................................................................................................. 13
7. Status Enquiry ....................................................................................... 15
8. User Reset ............................................................................................... 18

1
FWD-40LX1
FWD-32LX1R
1. Communication Parameter
Communication system RS-232C
Synchronous system Asynchronous communication
Baud rate 9600 bps
Character length 8 bit
Parity None
Start bit 1 bit
Stop bit 1 bit
Flow control None
2. Pin Configuration
12345
Display side (D-sub 9-pin)
_External view _
6789
12345
6789
Host side (D-sub 9-pin)
_External view _
FWD-40LX1
FWD-32LX1R
Personal computer
Pin No. Signal
1NC
2RD
3TD
4NC
5 GND
6NC
7NC
8NC
9NC
Pin No. Signal
1NC
2RD
3TD
4NC
5 GND
6NC
7NC
8NC
9NC
3. Communication Data Format
(a) Control (Host →Request of Write to Display)
No. Item Value
1 Header 0x8C:Control
2 Category 0xXX
3 Function 0xXX
4 Data1 (Length) 0xXX
5 Data2 (Data1) 0xXX
: : 0xXX
: : 0xXX
X Data (X-3) 0xXX
X+1 Check Sum 0xXX
*Check Sum: Sum total of 1 to X. Lower one-byte data is validated when a
value exceeds 255 (1 byte).
*Set the command interval to 500 ms or more when transmitting the
Control command continuously.
*Set the command interval to 500 ms or more when transmitting the same
command (Enquiry) after the Control command.
(b) Enquiry (Host →Request of Read to Display)
No. Item Value
1 Header 0x83:Enquiry
2 Category 0xXX
3 Function 0xXX
4 Data1 0xFF
5 Data2 0xFF
6 Check Sum 0xXX
*Check Sum: Sum total of 1 to 5. Lower one-byte data is validated when a
value exceeds 255 (1 byte).

FWD-40LX1
FWD-32LX1R
2
(c) Answer (Display →Response to Host)
1Answer at the time of Control request
No. Item Value
1 Header 0x70:Answer
2 Answer*0x00:Completed (Normal completion)
0x01:Limit Over
(Abnormal completion: Over upper limit)
0x02:Limit Under
(Abnormal completion: Under lower limit)
0x03:Command Canceled
(Abnormal completion)
3 Check Sum 0xXX
*0x00: Completed Packet is correctly received and process is
also correctly completed.
0x01:Limit Over Packet is correctly received, but the data
value is over the upper limit.
0x02:Limit Under Packet is correctly received, but the data
value is under the lower limit.
0x03:Command Canceled Packet is correctly received, but the data
value is not correct or the request cannot be
accepted in the current host state.
*Check Sum: If the value of a sum total of 1 and 2 exceeds
255 (1 byte), the data of 1 lower byte is
effective.
2Answer at the time of Enquiry request
(Normal completion)
No. Item Value
1 Header 0x70:Answer
2 Answer 0x00:Completed
3 Return Data Size 0xXX
4 Return Data1 0xXX
: : 0xXX
: : 0xXX
X Return Data (X-3) 0xXX
X+1 Check Sum 0xXX
*0x00:Completed Completed packet is correctly received and process is
also correctly completed.
*Return Data returns the read value.
*Check Sum: If the value of a sum total of 1 to X exceeds 255 (1 byte), the
data of 1 lower byte is effective.
3Answer at the time of Enquiry request
(Abnormal completion)
No. Item Value
1 Header 0x70:Answer
2 Answer 0x03:Command Canceled
(Abnormal completion)
3 Check Sum 0x73
*0x03: Command Canceled Packet is correctly received, but the data
value is not correct or the request cannot be
accepted in the current host state.
4Error Answer
No. Item Value
1 Header 0xE0:Answer
2 Answer*0x00:No Function Error
0x01:Check Sum Error
0x02:Data Length Error
3 Check Sum 0xXX
*0x00:No Function Error Packet header, category and function code are
not included in this protocol.
0x01:Check Sum Error Check sum value of received packet is not
correct.
0x02:Data Length Error Packet is correctly received, but the data size is
over the upper limit.
*Check Sum: If the value of a sum total of 1 and 2 exceeds 255
(1 byte), the data of 1 lower byte is effective.

3
FWD-40LX1
FWD-32LX1R
4. General Function
(a) Mode control
Syntax Header Category Function Data1 Data2 Check Sum
Control 0x8C 0x00 Code Table(1-a)[a] 0x02 Code Table(1-a)[b] 0xXX
Enquiry 0x83 0xFF 0xFF 0xXX
Answer Header Answer Check Sum
Control 0x70 0x00 0x70 Completed
0x70 0x01 0x71 Limit Over
0x70 0x02 0x72 Limit Under
0x70 0x03 0x73 Command Canceled
Answer Header Answer Return to Data Size Return Data1 Check Sum
Enquiry 0x70 0x00 0x02 Code Table (1-a)[b] 0xXX Completed
Code Table(1-a)
[a]Function [b]Range/Switch Code Command
Control Enquiry Standby Power On
0x00 Power*10x00 OFF Yes Yes Enable Enable
0x01 ON
0x01 Input Select*20x0A INPUT2 RGB Yes Yes Disable Enable
0x0B INPUT2 COMPONENT
0x0C OPTION1 VIDEO
0x0D OPTION1 S VIDEO
0x0E OPTION1 RGB
0x0F OPTION1 COMPONENT
0x10 OPTION2 VIDEO
0x11 OPTION2 S VIDEO
0x12 OPTION2 RGB
0x13 OPTION2 COMPONENT
0x20 INPUT1 DVI
0x02 Force Status Display 0x00 ON Yes Yes Disable Enable
0x01 OFF
0x03 Audio Mute 0x00 OFF Yes Yes Disable Enable
0x01 ON
0x04 Auto Status Display 0x00 ON Yes Yes Enable Enable
0x01 OFF
0x05 Closed Caption 0x00 OFF Yes Yes Disable Enable
0x01 CC1
0x02 CC2
0x03 CC3
0x04 CC4

FWD-40LX1
FWD-32LX1R
4
Code Table(1-a)
[a]Function [b]Range/Switch Code Command
Control Enquiry Standby Power On
0x06 Color System 0x00 Auto Yes Yes Disable Enable
0x01 NTSC
0x02 NTSC4.43
0x03 PAL
0x04 SECAM
0x05 PAL-M
0x06 PAL-N
0x07 PAL60
0x0F Language 0x00 Japanese Yes Yes Disable Enable
0x01 English
0x02 Deutsch
0x03 Français
0x04 Español
0x05 Italiano
0x10 Index Number 0x01 - 0xFF Yes Yes Disable Enable
0x13 Power Saving 0x00 Standard Yes Yes Disable Enable
0x01 Reduce
0x14 Speaker Out 0x00 ON Yes Yes Disable Enable
0x01 OFF
0x16 HD Mode 0x00 1080i Yes Yes Disable Enable
0x01 1035i
0x17 RGB Mode 0x00 DTV Yes Yes Disable Enable
0x01 PC
0x18 Sync Mode 0x00 H/Comp Yes Yes Disable Enable
0x01 Video
0x1B Clock Display 0x00 OFF Yes Yes Disable Enable
0x1B ON
0x24 Input Detect(Option1) 0x00 FW12(HD15) No Yes Disable Enable
0x01 FW10(CVBS, Y/C)
0x02 FW11(BNC)
0x03 Reserved
0x04 FW31/32
0x05 FW50
0x06 Reserved
0x07 Reserved
0x08 Reserved
0x09 Reserved
0x0A Reserved
0x0B Reserved
0x0C Reserved
0x0D Reserved
0x0E Reserved (Continued)

5
FWD-40LX1
FWD-32LX1R
Code Table(1-a)
[a]Function [b]Range/Switch Code Command
Control Enquiry Standby Power On
0x24 Input Detect(Option1) 0x0F Not Connect No Yes Disable Enable
0x25 Input Detect(Option2) 0x00 FW12(HD15) No Yes Disable Enable
0x01 FW10(CVBS, Y/C)
0x02 FW11(BNC)
0x03 Reserved
0x04 FW31/32
0x05 FW50
0x06 Reserved
0x07 Reserved
0x08 Reserved
0x09 Reserved
0x0A Reserved
0x0B Reserved
0x0C Reserved
0x0D Reserved
0x0E Reserved
0x0F Not Connect
0x26 Auto Shut OFF 0x00 OFF Yes Yes Disable Enable
0x01 ON
0x30 PAP*20x00 OFF Yes Yes Disable Enable
0x01 P&P
0x02 PinP
0x31 Active Picture 0x00 Left(P&P)/Main(PinP) Yes Yes Disable Enable
0x01 Right(P&P)/Sub(PinP)
0x02 Swap*2
0x32 Picture Size(P&P) 0x00 - 0x0E Yes Yes Disable Enable
0x33 Sub Picture Size (PinP) 0x00 Large Yes Yes Disable Enable
0x01 Small
0x34 Picture Position(PinP)*30x00 Position1 Yes Yes Disable Enable
0x01 Position2
0x02 Position3
0x03 Position4
0x35 PAP Input Detect (Left/Main) 0x0A INPUT2 RGB No Yes Disable Enable
0x0B INPUT2 COMPONENT
0x0C OPTION1 VIDEO
0x0D OPTION1 S VIDEO
0x0E OPTION1 RGB
0x0F OPTION1 COMPONENT
0x10 OPTION2 VIDEO
0x11 OPTION2 S VIDEO
0x12 OPTION2 RGB
0x13 OPTION2 COMPONENT (Continued)

FWD-40LX1
FWD-32LX1R
6
12
43
Code Table(1-a)
[a]Function [b]Range/Switch Code Command
Control Enquiry Standby Power On
0x35 PAP Input Detect (Left/Main) 0x20 INPUT1 DVI No Yes Disable Enable
0x36 PAP Input Detect (Right/Sub) 0x0A INPUT2 RGB No Yes Disable Enable
0x0B INPUT2 COMPONENT
0x0C OPTION1 VIDEO
0x0D OPTION1 S VIDEO
0x0E OPTION1 RGB
0x0F OPTION1 COMPONENT
0x10 OPTION2 VIDEO
0x11 OPTION2 S VIDEO
0x12 OPTION2 RGB
0x13 OPTION2 COMPONENT
0x20 INPUT1 DVI
*1: Transmit the next command 10 seconds after Power On and Power Off commands are transmitted. If not, correct data may not be able to be acquired.
*2: For INPUT SELECT, PAP, and Active Picture (SWAP), check the busy state using a Busy to INPUT command.
*3: The Picture Position arrangement is as shown below.
Code Table(1-a)
[a]Function [b]Range/Switch code Command
Control Enquiry Standby Power On
0x43 BackLight 0x00 - 0x64 Yes Yes Disable Enable
0x44 Illumination 0x00 OFF Yes Yes Disable Enable
0x01 Low
0x02 High
0x45 Control Mode 0x00 Main+Remocon Yes Yes Disable Enable
0x01 Main
0x02 Remocon
0x46 On Off Timer Mode 0x00 Every Day Yes Yes Enable Enable
0x01 Day Of Week
0x47 On Timer Enable bit0 Sunday 1:Enable, 0:Disable Yes Yes Enable Enable
bit1 Monday 1:Enable, 0:Disable
bit2 Tuesday 1:Enable, 0:Disable
bit3 Wednesday 1:Enable, 0:Disable
bit4 Thursday 1:Enable, 0:Disable
bit5 Friday 1:Enable, 0:Disable
bit6 Saturday 1:Enable, 0:Disable
bit7 Every day 1:Enable, 0:Disable*4
