Operating Instructions
BDV-F7
©2010 Sony Corporation
4-184-718-12(1)

WARNING
To reduce the risk of fire
or electric shock, do not
expose this apparatus to
rain or moisture.
Do not install the appliance in a
confined space, such as abookcase
or built-in cabinet.
To reduce the risk
of fire, do not
coverthe ventilation opening
of the
apparatus with newspapers,
tablecloths, curtains, etc. Do not
place the naked flame sources such
as lighted candles on the apparatus.
Do not expose batteries or
apparatus with battery-installed to
excessive heat such as sunshine,
fire
or the like.
To prevent injury, this apparatus
must be securely attached to the
floor/wall in accordance with the
installation instructions.
Indoor use only.
CAUTION
The use of optical instruments with
this product will increase eye
hazard. As the laser beam used in
this Blu-ray Disc /DVD Home
Theatre System is harmful to eyes,
do not attempt to disassemble the
cabinet.
Refer servicing to qualified
personnel only.
CAUTION ClASS 3R YISISU AND INV!SIBLE lASER RADIATION WHEN OPEN
AlJO;Q [}IRECT EYt EXPOSURE
VORSICHT KlASSE3RSICMlBAREU~DUNSICHTBARflASERSTRAHLUNGWENN
GEdFFNfTUNMmELBAAENAIJGENKONTAKlVEAMEIDEN.
ADVARSEl S~NlIG [)G U$YNlIG LASERSTMUNG Af KLASSE 3R VED ABNiNG
UNDGAAlSEDIREKTEPAslRALEN
ADVARSEl SYNU(J OG USYNlIG LASERSTRAUNG I KLASSE 3A NAR GOSH APNES
UNNMOlAEKTEEKSPONERINGAVI:mIENE
VARNING KLASS 3R $YNll(; DCH OSVNlIG lASERSTAALNiNG NAR DENNA DEL All
OPPNADUNDV1KAITOIREKTEXPONERAOGONENFORSlRALNINGEN
VARD! AVAnLINALUOKAN 3A ~Y'JMJA NAKYMATONT~ lASERSATEllYA
VALTA M1SEEN SUORM AL11$IAMIS1A
liS rrJfBjli3Rl!iifJil~iifJilIJ!IUI~I''f!'lIMffJ!iM
This appliance is classified as a
CLASS 3R LASER product.
Visible and invisible laser radiation
is emitted when the laser protective
housing is opened,
so be sure to
avoid direct eye exposure.
This marking is located on the laser
protective housing inside the
enclosure.
CLASS 1LASER PRODUCT
LASER KLASSE 1
LUOKAN 1LASERLAITE
KLASS 1LASERAPPARAT
1~~J'{;F~
This appliance is classified as a
CLASS ILASER product. The
CLASS ILASER PRODUCT
MARKING is located on the laser
protective housing inside the
enclosure.
Precautions
On power sources
•The unit is not disconnected from
the mains as long as it is
connected to the AC outlet, even
ifthe unit itselfhas been turned
off.
•As the main plug is used to
disconnect the unit from the
mains, connect the unit to
an
easily accessible AC outlet.
Should you notice an abnormality
in the unit, disconnect the main
plug from the AC outlet
immediately.
On watching 3D video
images
Some people may experience
discomfort (such as eye strain,
fatigue, or nausea) while watching
3D video images. Sony
recommends that all viewers take
regular breaks while watching 3D
video images. The length and
frequency
of necessary breaks will
vary from person to person. You
mustdecide what works best. Ifyou
experience any discomfort, you
should stop watching the 3D video
images until the discomfort ends;
consult adoctor if you believe
necessary. You should also review
(i) the instruction manual and/orthe
caution message
of any other
device used with, or Blu-ray Disc
contents played with this product
and (ii) our website (http://
esupport.sony.com/) for the latest
information. The vision
of young
children (especially those under six
years old) is still under
development. Consult your doctor
(such as apediatrician
or eye
doctor) before allowing young
children
to watch 3D video images.
Adults should supervise young
children to ensure they follow the
recommendations listed above.
~ This symbol is intended to
Lh alert the user to the
presence
of uninsulated
"dangerous voltage" within the
product's enclosure that may be
of
sufficient magnitude to constitute a
risk
of electric shock to persons.
Lh
This symbol is intended to
Ialert the user to the
•presence
of important
operating and maintenance
(servicing) instructions in the
literature accompanying the
appliance.
Owner's Record
The model and serial numbers are
located at the rear exterior
of the
control unit. Record the serial
number in the space provided
below. Refer to them whenever you
call upon your Sony dealer
regarding this product.
Model No. BDV-F7
Serial No. _
The following FCC statement
applies only to the version
of this
model manufactured for sale
in the
U.S.A. Other versions may not
comply with FCC technical
regulations.
NOTE:
This equipment has been tested and
found to comply with the limits for
aClass Bdigital device, pursuant to
Part
15 of the FCC Rules. These
limits are designed to provide
reasonable protection against
harmful interference
in aresidential
installation. This equipment
generates, uses, and can radiate
radio frequency energy and,
if not
installed and used
in accordance
with the instructions, may cause
harmful interference to radio

communications. However, thereis
no guarantee that interference will
not occur in aparticular
installation.
If this equipment does
cause harmful interference to radio
or television reception, which can
be determined by turning the
equipment
off and on, the user is
encouraged to try to correct the
interference by one
or more of the
following measures:
-Reorient orrelocate the receiving
antenna (aerial).
-Increase the separation between
the equipment and receiver.
-Connect the equipment into an
outlet on acircuit different from
that to which the receiver
is
connected.
-Consult the dealer or an
experienced
radiorrV technician
for help.
CAUTION
You are cautioned that any changes
or modifications not expressly
approved in this manual could void
your authority to operate this
equipment.
Important Safety
Instructions
I) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near
water.
6) Clean only with dry cloth.
7) Do not block any ventilation
openings. Install
in accordance
with the manufacturer's
instructions.
8) Do not install near any heat
sources such as radiators, heat
registers, stoves,
or other
apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety
purpose
of the polarized or
grounding-type plug. A
polarized plug has two blades
with one widerthan the other. A
grounding type plug has two
blades and athird grounding
prong. The wide blade or the
third prong are provided for
your safety.
If the provided
plug does not fit into your
outlet, consult an electrician for
replacement
of the obsolete
outlet.
10) Protect the power cord from
being walked on
or pinched
particularly at plugs,
convenience receptacles, and
the point where they exit from
the apparatus.
II) Only use attachments/
accessories specified by the
manufacturer.
12) Use only with the cart, stand,
tripod, bracket,
or table
specified
by the manufacturer,
or sold with the apparatus.
When acart
is used, use caution
when moving the cart!
apparatus combination to avoid
injury from tip-over.
13) Unplug this apparatus during
lightning storms
or when
unused for long periods
of time.
14) Refer all servicing to qualified
service personnel. Servicing is
required when the apparatus
has been damaged in any way,
such as power-supply cord
or
plug is damaged, liquid has
been spilled or objects have
fallen into the apparatus, the
apparatus has been exposed to
rain or moisture, does not
operate normally, or has been
dropped.
For the USB Wireless
LAN Adapter (UWA.
BR100)
Pursuant to FCC regulations, you
are cautioned that any changes or
modifications not expressly
approved in this manual could void
your authority to operate this
equipment.
To prevent radio interference to the
licensed service, this device
is
intended to be operated indoors and
away from windows to provide
maximum shielding. Equipment(or
its transmit antenna) that is
installed outdoors is subject to
licensing.
Only use Wireless LAN indoors
when using it with IEEE
802.ll a
(5 GHz).
High power radars are allocated as
primary users (meaning they have
priority)
of 5250-5350 MHz and
5650-5850
MHz and these radars
could cause interference and/or
damage to this device.
This device uses 5GHz band for
wireless
LAN communication and
the maximum gain
of the antenna in
this device is 5dBi.
This equipment complies with
FCC/IC radiation exposure limits
set forth for
an uncontrolled
environment. This equipment
should be installed and operated
with minimum distance 20 cm
between the radiator and your body
(excluding extremities: hands,
wrists and feet).
This device and its antenna(s) must
not be co-located
or operating with
any other antenna or transmitter
except Grant condition.
Ifyou have any questions about this
product, contact Sony Customer
Information Service Center at
1-800-222-7669
or visit
http://www.sony.com/on the
Internet.
The telephone number below
is for
FCC-related matters only.
Regulatory Information
3
US

4
US
Declaration of Conformity
Trade Name: SONY
Model: UWA-BRIOO
Responsible Party: Sony
Electronics Inc.
Address: 16530 Via Esprillo, San
Diego,
CA 92127 U.S.A.
Telephone Number: 858-942-
2230
This devicecomplies wi
th part 15
of the FCC rules. Operation is
subject to the following two
conditions: (1) This device may
not cause harmful interference,
and (2) this device must accept
any interference received,
including interference that may
cause undesired operation.
Copyrights and
Trademarks
•This system incorporates with
Dolby* Digital and the DTS**
Digital Surround System.
*Manufactured under license
from Dolby Laboratories.
Dolby and the double-D
symbol are trademarks
of
Dolby Laboratories.
** Manufacturedunderlicense
under U.S. Patent #'s:
5,45 L,942; 5,956,674;
5,974,380; 5,978,762;
6,226,616; 6,487,535;
7,212,872; 7,333,929;
7,392,195; 7,272,567 &
other U.S. and worldwide
patents issued &pending.
DTS and the Symbol are
registered trademarks, &
DTS-HD, DTS-HD Master
Audio, and the DTS logos
are trademarks
of DTS, Inc.
Product includes software.
©DTS, Inc. All Rights
Reserved.
•"A
VCHD" and the "A VCHD"
logo are trademarks of Matsushita
Electric Industrial Co., Ltd. and
Sony Corporation.
•Java and all Java-based
trademarks and logos are
trademarks or registered
trademarks
of Sun Microsystems,
Inc.
. ·i··, "XMB," and "xross media
bar" are trademarks
of Sony
Corporation and Sony Computer
Entertainment Inc.
•This system incorporates High-
Definition MuLtimedia Interface
(HDMI™) technology.
HDMI, the
HDMIlogo and High-
Definition Multimedia Interface
are trademarks
or registered
trademarks
of HDMI Licensing
LLC.
•"Blu-ray Disc" is atrademark.
•"Blu-ray Disc,"
"DVD+RW,"
"DVD-RW," "DVD+R," "DVD-
R,"
"DVD VIDEO," and "CD"
logos are trademarks.
•
"BD-LIVE" and
"BONUSVIEW" are trademarks
of Blu-ray Disc Association.
•"Blu-ray 3D" and "Blu-ray 3D"
logo are trademarks of Blu-ray
Disc Association.
•
"BRA VIA" is atrademark of
Sony Corporation.
•"PhotoTV
HD" and the "PhotoTV
HD" logo are trademarks of Sony
Corporation.
•
MPEG Layer-3 audio coding
technology and patents licensed
from Fraunhofer lIS and
Thomson.
•Music and video recognition
technology and related data are
provided by Gracenote®.
Gracenote is the industry standard
in music recognition technology
and related content delivery. For
more information, please visit
www.gracenote.com.
CD, DVD, Blu-ray Disc, and
music and video-related data from
Gracenote, Inc., copyright ©
2000-present Gracenote.
Gracenote Software, copyright ©
2000-present Gracenote. One or
more patents owned by Gracenote
apply to this product and service.
See the Gracenote website for a
nonexhaustive list
of applicable
Gracenote patents. Gracenote,
CDDB, MusicID, MediaVOCS,
the Gracenote logo
and logotype,
and the "Powered by Gracenote"
logo are either registered
trademarks
or trademarks of
Gracenote in the United States
and/or other countries.
f gracenote.
•Windows Media is either a
registered trademark
or trademark
of Microsoft Corporation in the
United States and/or
other
countries.
•DLNA
®, the DLNA Logo and
DLNA CERTIFlEDTM
are
trademarks, service marks, or
certification marks
of the Digital
Living Network Alliance.
•iPod is atrademark
of Apple Inc.,
registered in the U.S.
and other
countries.
•"Made for iPod" means that an
electronic accessory has been
designed to connect specifically
to iPod and has been certified by
the developer to meet Apple
performance standards.
•Apple
is not responsible for the
operation
of this device or its
compliance with safety
and
regulatory standards.
•"PLAYSTATION"
is atrademark
of Sony Computer Entertainment
Inc.
•Other system and product names
are generally trademarks
or
registered trademarks of the
manufacturers. ™and ®marks
are not indicated
in this document.

About These
Operating
Instructions
•The instructions in these
Operating Instructions
describe the controls on the
remote. You can also use the
controls on the unit
if they
have the same
or similar
names as those on the remote.
•In this manual, "disc" is used
as ageneral reference for
BDs, DVDs, Super Audio
CDs, orCDs unless otherwise
specified by the text or
illustrations.
•The items displayed on the
TV screen may vary
depending
on the area.
•The default setting is
underlined.
5
US

Table of Contents
About These Operating Instructions 5
Unpacking 7
Index to Parts and Control 8
Getting Started
Step 1: Installing the System 14
Step 2: Connecting the System 17
Step 3: Connecting to the
Network 25
Step 4: Performing the Easy
Setup 29
Step 5: Selecting the Source 30
Step 6: Enjoying Surround
Sound
31
Playback
Playing aDisc 33
Playing from aUSB Device 34
Enjoying an iPod
35
Playing via aNetwork 35
Available Options 38
Sound Adjustment
Selecting the Effect to Suit the
Source 40
Selecting the Audio Format, Multilingual
Tracks, or Channel 40
Enjoying Multiplex Broadcast Sound
.. .41
Tuner
Listening to the Radio .42
Other Operations
Using the Control for HDMI Function for
"BRAVIA" Sync 44
Setting the Speakers .46
Using the Sleep Timer .47
Changing the Illumination LED Lighting
Type 47
Deactivating the Buttons on the Unit....47
Controlling Your TV with the Supplied
Remote 48
Saving Power in Standby Mode .48
Settings and Adjustments
Using the Setup Display .49
[Network Update] .49
[Screen Settings] 50
[Audio Settings].
51
[BD/DVD Viewing Settings] 52
[Parental Control Settings] 52
[Music Settings] 53
[System Settings] 53
[Network Settings] 54
[Easy Setup] 55
[Resetting] 55
Additional Information
Precautions 56
Notes about the Discs 57
Troubleshooting 58
Playable Discs 64
Playable Types
of Files 65
Supported Audio Formats 66
Specifications 67
Language Code List.. 69
Glossary 70
Index 72

Unpacking
~
OOODlo ooeee 0
Dggg~ . OBOe =
DDDDD ~oeee~
•Cable tie (1)
•Remote commander
(remote) (1)
•Foot pad (1)
•R6 (size AA) batteries (2)
•Operating Instructions
•Quick Setup Guide
•End user license agreement
II
~
~(( J»
•UWA-BR I00 External
cable (1)
•Speaker cords (2, white/red,
purple)
•FM wire antenna (aerial) (1)
•Video cord (1)
!I
•Unit (1)
•Front speaker (1)
•Subwoofer (1)
•USB Wireless LAN Adapter
(UWA-BRlOO)
(I)
Insert two R6 (size AA) batteries (supplied) by matching the (±) and 8ends on the batteries to the
markings inside the compartment.
7
US

Index to Parts and Control
For more information, refer to the pages indicated in parentheses.
1
Left side
543
BUS
[II Ventilation slots
[g] VOL (volume) +/-
Adjusts the system's volume.
~ Front panel display
@] I!iJ (remote sensor)
I]J Illumination LED (page 47)
lID ~ (USB) port (left) (page 34)
Used for connecting aUSB device.

1 2
.",
6
6
o
.
o
3
[] 11(') (on/standby)
Turns on the unit, orsets it to standby mode.
[gJ Disc slot (page 33)
~ Play operation buttons
~ (play)
Starts or re-starts playback (resume play).
Plays aslideshow when adisc containing
JPEG image files is inserted.
•(stop)
Stops playback and remembers the stop
point (resume point).
The resume point for atitle/track is the last
point you played or the last photo for a
photo folder.
FUNCTION
Selects the playback source.
~ (eject)
Ejects the disc.
@] LAN (100) terminal (page 25)
[§] VIDEO OUT jack (page 21)
lID HDMI OUT jack (page 21)
[I] ~ (USB) port (right) (page 34)
Used for connecting aUSB device.
1m TV (DIGITAL IN OPTICAL) jack (page
22)
lID SAT/CABLE (DIGITAL IN OPTICAL)
jack (page 23)
[Q] AUDIO (IN UR) jacks (page 23)
II1J ANTENNA (FM 75Q COAXIAL) jack
(page 24)
gus

10
US
[j] Ventilation slots
[2J SPEAKERS jacks (page 18)

About the indications in the front panel display
. . ..
... . ...
:
: .. :: ..
5
4
3
14
[jJ Lights
up when the system is playing
rnJ
Lights up when outputting 1920 x
via the PARTY STREAMING function. 1080p/24
Hz video signals.
[g] Flashes when the sleep timer is set.
[ID
Lights up during playback with "2CH
(page
47) STEREO."
~Lights
up when astation is received.
[1Q]
Lights up when the sound of the
(Radio only) (page
42) system is muted.
@]
Lights up when "FM MODE" is set to
[1] Lights up when outputting
DTS Neo:6
"MONO." (Radio only) (page 42) mode sound.
[§] Lights up when stereo sound is
!I2J
Lights up during playback with "WIDE
received. (Radio only) (page
42) STAGE" surround sound effect.
[ID
Lights up when the HDMI OUT jack is
~
Lights up when a disc is loaded.
correctly connected
to an HDCP (High-
[H]
Displays system's status such as
bandwidth Digital Content Protection)- chapter, title,
or track number, time
compliant device with
HDMI or DVI
information, radio frequency, playing
(Digital Visual Interface) input. status, etc.
[l]
Lights up when outputting 720p/1080i/
[j]]
Lights up when repeat play is
1080p video signals from the
HDMI
activated.
OUT jack. @Displays system's playing status.

[g] Number buttons (pages 43, 48)
Enters the title/chapter numbers, radio
frequencies, etc.
AUDIO (pages 40,41)
Selects the audio format/track.
l/eJ
THEATERON~i:.~CH TVI/C> 0
Cl Cl Cl
SUBTITLE (page 52)
.
G)®@
Selects the subtitle language when
CJ
multilingual subtitles are recorded on aBD-
SLEEP
@@@
Cl
ROM/DVD VIDEO.
SYSTEM
MENU
0®®
Cl
D.TUNING (direct tuning) (page 42)
FAVORITES
AUDIO @ SUBTITLE
Selects the radio frequencies.
Cl
G:J 0 Cl
YELL BLUE RED
GR EN
[ID
Color buttons (YELLOW/BLUE/REDII II II
II I
TOP MENU
POP UPI MENU
GREEN)
~~o
Short cut keys for selecting items on some
+ (J +4BD menus (can also be used for Java
.~. ~ ~~;
interactive operations on BDs).
0+0
@]
TOP MENU
FUNCTION SOUND MOD
0(
HOME)
05Opens or closes the
BD's or DVD's Top
PRESET-REPLAY ADVANCE PRESEH
Menu on the TV screen.
1.-11··11·..1
[~I
TUNING- PLAY TUNING+
POP UP/MENU
I-II
~o
18
DISPLAY PAUSE STOP
Opens or closes the BD-ROM's Pop-up
80
[E]
mMenu, or the DVD's menu.
~
~NO;
7OPTIONS (page 38)
Displays the options menu on the TV
screen.
Number 5, AUDIO, VOL +, and
~ buttons
have atactile dot. Use the tactile dot as a
reference when operating the remote.
· em: For TV operations
(For details, see "Controlling Your TV with
the Supplied Remote" (page 48).)
[j] THEATEF! (page 45) em
Switches to the optimum video mode for
watching movies automatically.
.ONE-TOUCH PLAY (page 45)
Activates One-Touch Play.
TV IIC) (on/standby) (page 48) em
Turns on the TV or sets it to standby mode.
IIC) (on/standby) (pages 29, 42)
Turns on the system or sets it to standby
mode.
RETURN
Returns to the previous display.
+-/1' I.J, 1-+
Moves the highlight to adisplayed item.
8(ENTER)
Enters the selected item.
[§] FUNCTION (pages 30, 42)
Selects the playback source.
HOME (pages 29, 42, 46, 49)
Enters or exits the system's home menu on
the TV screen.
SOUND MODE (page 40)
Selects the sound mode.
[§] Playback operation buttons
See "Playback" (page 33).
..... /~ (previous/next)
Skip to the previous/next chapter, track, or
file.
".1." (replay/advance)
12
US

Briefly replay the current scenes for 10
seconds. /Briefly fast forwards the current
scenes for
15 seconds.
.... /~ (fast reverse/fast forward)
Fast reverse/fast forward the disc during
playback. Each time you press the button,
search speed changes.
Activates slow-motion play when pressed
for more than one second in pause mode.
Plays one frame at atime when pressed in
pause mode.
~ (play)
Starts or re-starts playback (resume play).
Plays aslideshow when adisc containing
lPEG image files is inserted.
II (pause)
Pauses or re-starts playback.
•(stop)
Stops playback and remembers the stop
point (resume point). The resume point for
atitle/track is the last point you played or
the last photo for aphoto folder.
Radio operation buttons
See "Tuner" (page 42).
PRESET +/-
TUNING +/-
[1] MUTING
Turns offthe sound temporarily.
VOL +/- (page 42)
Adjusts the volume.
TV VOL +/- OYJ
Adjusts the TV volume.
TV INPUT OYJ
Switches the TV's input source between the
TV and other input sources.
[§] DISPLAY (pages 33, 35)
Displays the playback information on the
TV screen.
When the function is "TV"
or "SAT/
CABLE" and digital signals are input via
the TV (DIGITAL IN OPTICAL)
or SAT/
CABLE (DIGITAL IN OPTICAL) jack,
displays the stream information in the front
paneldisplay.
[ID ~ (eject)
Ejects the disc.
SLEEP (page 47)
Sets the sleep timer.
SYSTEM MENU (pages 31, 39, 42, 47)
Enters or exits the system menu in the front
panel display.
FAVORITES
Displays the Internet contents added to the
Favorites List. You can save
18 favorite
Internet contents.
13
US

Position the system as illustrated below.
®Front speaker
®Subwoofer
©Unit
Approximately
6inches (15 cm)
b::===~·L
14
US
Getting Started
When installing the front speaker on a TV stand
When installing the front speaker on a wall
For details, see "To install the front speaker on awall" (page 15).
®Front speaker
®Subwoofer
©Unit
Step 1: Installing the System
•Use caution when placing the speakers on aspecially treated (waxed, oiled, polished, etc.) floor, as staining or
discoloration may result.
•Image distortion on the TV screen may occur depending on the location
of the subwoofer. In this case, place the
subwoofer away from the TV.
-
•Place the subwoofer on aflat and firm floor (not on thick pile carpet, for example).
•Leave aspace for inserting/ejecting the disc (approximately 6inches (15 cm)) to the right (disc slot) side
of the unit
when placing an object nearby.

Caution
Hole on the back of
the speaker
T5mm
o (1/
5inch)
-!=l-10 mm
(% inch)
G\\\\\\\\\\\\\\1> t-4mm C/
6inch)
I. .1
more than 25 mm (1 inch)
6to 7mm
(approx. 1/4inch)
•Do not block the ventilation slots
of the unit (page 8).
•Place the front speaker forward from the TV. Make sure there are
no reflecting obstacles in front of the speaker.
•The front speaker should be pointed straight forward. Do not place the speaker at an angle.
15
US
To install the front speaker on a wall
•Contact ascrew shop or installer regarding the wall material or screws to be used.
•Use screws that are suitable for the wall material and strength. As aplaster board wall is especially fragile, attach
the screws securely to abeam and fasten them to the wall. Install the speaker on avertical and flat wall where
reinforcement
is applied.
•Be sure to subcontract the installation to Sony dealers or licensed contractors and pay special attention to safety
during the installation.
•Sony
is not responsible for accidents or damage caused by improper installation, insufficient wall strength or
improper screw installation, natural calamity, etc.
1Connect the speaker cord to the front speaker.
For details, see "To connect the speaker cord to the front speaker" (page 18).
2Prepare screws (not supplied) that are suitable for the holes on the back of the speaker.
See the illustrations below.
1m
•The length and type of the screw are examples. Select screws in accordance with the material or strength of
the wall to which you install the speaker.
3Fasten the screws to the wall. The screws should protrude 6to 7mm (approx. 1/
4inch).
4Hang the speaker onto the screws.
Align the holes on the back of the speakerto the screws, then hang the speaker onto the two screws.

-
• Be careful not to pinch the speaker cord while tightening the screws.
16
US

Step 2: Connecting the System
For connecting the system, read the information on the following pages.
Do not connect the AC power cord (mains lead)
of the unit to awall outlet (mains) until all the other
connections are made.
-
•When you connect another component with avolume control, tum down the volume of the other components to a
level where sound is not distorted.
To remove the panel cover of the unit
Before connecting the cables, remove the panel cover from the unit.
CI
CI
CI
Hold the panel cover at (0), then slide it out to
the side.
-
•Before using the unit, remove the seal attached at the lower rear of the unit.
17
US

The connectors of the speaker cords are color-coded depending on the type of speaker. Connect the
speaker cords to match the color of the SPEAKERS jacks of the unit.
To connect speaker cords to the unit
Fully insert the speaker cord connectors into the unit.
White
(Front speaker (L))
Purple
(Subwoofer)
Red
(Front speaker (R))
..
•Make sure to place the unit on asoft thick cloth to prevent damaging the unit.
To connect the speaker cord to the front speaker
1Remove the screw of the cover at the rear of the speaker, and then remove the cover.
..
•The cover is attached to the speaker sturdily to prevent it from falling down or dropping off. Firmly remove it.
18
US

2Connect the speaker cord.
The connector of the speaker cord is color-coded depending on the speaker channel. Connect the
connector
of the speaker cord to match the color of the speakerjack.
Rear of the speaker
3Guide the speaker cord through the square notch at the bottom of the cover, and then
reattach the cover to the speaker and secure it with the screw removed
in Step 1.
19
U5

Color tube (purple)
20
US
~ Foot pad (supplied)
~
o I~~~
L ~.'"
Attach the foot pad (supplied) to the bottom of the speaker by removing the
protective cover and aligning the foot pad with the mark
(0).
To install the front speaker at an upward angle
The front speaker can be tilted upward by attaching the foot pad. This is useful for projecting the sound
upward when installing the front speaker on alow rack or low TV stand, etc.
Bottom of the speaker
2Thread the speaker cord through the gap along the side of the subwoofer, and secure it
in the speaker cord holder.
To connect the speaker cord to the subwoofer
1Connect the speaker cord to the subwoofer.
Be sure to match the speaker cord to the appropriate terminal on the subwoofer: the speaker cord
with the color tube to
<B, and the speaker cord without the color tube to 8. Do not catch the
speaker cord insulation (rubber covering) in the speaker terminals.
Bottom of the subwoofer
