SERVICE MANUAL
Published by Sony Techno Create Corporation
Sony Corporation
Audio&Video Business Group
HOME THEATRE SYSTEM
9-889-499-01
2009E05-1
© 2009.05
US Model
Canadian Model
AEP Model
UK Model
Saudi Arabia Model
Ver. 1.0 2009.05
• HT-CT500 is composed of following models.
As service manuals are issued for each component model,
please refer to them.
SPECIFICATIONS
COMPONENT MODEL NAME
HT-CT500
HT-CT500
Active Subwoofer SA-WCT500
Speaker System SS-CT500
Speaker Bracket WS-CT500EB
Unpacking
• Subwoofer (SA-WCT500) (1)
• Speaker (SS-CT500) (1)
• AM loop antenna (aerial) (1)
• FM wire antenna (aerial) (1)
• Speaker cord (1)
• Digital optical cord for a TV (2.5 m) (1)
• Remote commander (1)
• R6 (size AA) batteries (2)
• WS-CT500EB
• Extension bracket (1)
• Rear cover (1)
• Screws for the extension bracket (large, +PSW5 x 12 mm) (7)
• Screws for the rear cover (small, M3 x 8 mm) (4)
• Support belt (1)
• Screw for the support belt (+PSW4 x 20 mm) (1)
• Wood screw for the support belt (M3.8 x 20 mm) (1)
• Operating Instructions (1)
WS-CT500EB
Extension bracket
Dimensions (approx.) 286 mm × 179 mm × 60 mm
(11 3/8 in ×7 1/8 in × 2 3/8 in) (w/h/d)
Mass (approx.) 1.3 kg (2 lb 14 oz)
Rear cover
Dimensions (approx.) 294 mm × 185 mm × 67 mm
(11 5/8 in × 7 3/8 in × 2 3/4 in) (w/h/d)
Mass (approx.) 0.56 kg (1lb 4oz)
General
Power requirements
US, Canadian models: 120V AC, 60 Hz
Other models: 220 – 240 V AC, 50/60 Hz
Power consumption
On: 110 W
Standby mode: 0.3 W (when “CTRL: HDMI”
and “S-AIR STBY” are set to “OFF.”)
Power output
(DIGITAL MEDIA PORT) DC OUT: 5 V, 700 mA
Design and specifications are subject to change without notice.
• Standby power consumption 0.3 W.
• Halogenated flame retardants are not used in the
certain printed wiring boards.
• Over 85 % power efficiency of amplifier block is
achieved with the full digital amplifier, S-master.
Note: WS-CT500EB has been described to this service manual.

HT-CT500
2
ACCESSORIES
4-143-833-11 MANUAL, INSTRUCTION
(ENGLISN, FRENCH, SPANISH) (US, CND)
4-143-834-11 MANUAL, INSTRUCTION (ENGLISH)
(AEP, RU, UK)
4-143-834-21 MANUAL, INSTRUCTION
(FRENCH, SPANISH, PORTUGUESE) (AEP)
4-143-834-31 MANUAL, INSTRUCTION
(GERMAN, DUTCH, ITALIAN) (AEP)
4-143-834-41 MANUAL, INSTRUCTION
(DANISH, FINNISH, NORWEGIAN) (AEP)
4-143-834-51 MANUAL, INSTRUCTION
(GREEK, SWEDISH, POLISH) (AEP)
4-143-834-61 MANUAL, INSTRUCTION
(HUNGARIAN, CZECH, TURKISH) (AEP)
4-143-834-71 MANUAL, INSTRUCTION
(RUMANIAN, BULGARIAN, SLOVAKIAN) (AEP)
4-143-834-81 MANUAL, INSTRUCTION (RUSSIAN, UKRAINIAN)
(RU)
4-143-834-91 MANUAL, INSTRUCTION
(ENGLISH, FRENCH, ARABIC) (EA)
1 1-754-059-12 ANTENNA, LOOP (AM loop antenna (aerial))
2 1-793-184-23 CONNECTOR (F TYPE ADAPTOR)
(FM wire antenna (aerial))
3 1-836-453-11 CORD WITH PLUG (Speaker cord)
4 1-757-988-12 CORD, LIGHT PLUG
(Digital optical cord for a TV (2.5 m))
5 1-487-215-11 REMOTE COMMANDER (RM-ANP037) (US, CND)
5 1-487-216-11 REMOTE COMMANDER (RM-ANP038)
(AEP, RU, UK, EA)
6 X-2348-477-1 BRACKET (NECK) ASSY (Extension bracket)
(WS-CT500EB)
7 X-2348-539-1 COVER(NECK RR) ASSY (Rear cover)
(WS-CT500EB)
8 3-700-528-01 CLAMP, CABLE (Clamper)
9 2-580-607-01 SCREW, +PSW M5X12 (Screw for the extension
bracket (large, +PSW5 x 12 mm)) (1 piece)
10 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3 (Screw for the
rear cover (small, M3 x 8 mm)) (1 piece)
11 X-2342-530-1 BAG ASSY, FALL LOCK BELT (Support belt)
12 2-580-604-01 SCREW, +PSW M4X20
(Screw for the support belt (+PSW4 x 20 mm))
13 2-580-663-02 SCREW, WOOD 3.8X20
(Wood screw for the support belt (M3.8 x 20 mm))
Ref. No. Part No. Description Remark
• Abbreviation
CND : Canadian model
EA : Saudi Arabia model
RU : Russian model
AM loop antenna (aerial)
u1
FM wire antenna (aerial)
u1
Speaker cord
u1
Remote commander
u1
Extension bracket
u1
Rear cover
u1
Clamper
u1
Screws for the rear cover
(small, M3 × 8 mm)
u4
Screw for the support belt
(+PSW4 × 20 mm)
u1
Wood screw for the support belt
(M3.8 × 20 mm)
u1
Support belt
u1
Screws for the extension bracket
(large, +PSW5 × 12 mm)
u7
Digital optical cord for a TV (2.5 m)
u1
:6&7(%
18
2
11
3
9
4
10
5
6
12
7
13

HT-CT500
3
MEMO

HT-CT500
REVISION HISTORY
Checking the version allows you to jump to the revised page.
Also, clicking the version at the top of the revised page allows you to jump to the next revised page.
Ver. Date Description of Revision
1.0 2009.05 New
