Home Theater in a Box
• Silver Color Components (matches Sony WEGA® Televisions)
• 600 Watts Total System Power (500W Receiver + 100W Powered Sub)
• STR-K4800P Receiver: 100 Watts X 5 (8 ohms 1 kHz, 10% THD)
• Powered 8" Subwoofer: 100W X 1 (6 ohms 28-200 Hz, 10% THD)
• Dolby® Digital, dts®, Dolby® Pro Logic® II, MP3 Decoding
• CD-R/CD-RW*, DVD-R,DVD+RW, DVD-RW (in the video mode), MP3 Playback
• Speaker Package Includes: Slim Center, Front/Rear Speakers, Powered Sub
• Single Disc DVD Player with Progressive Scan Output
HT-4800DP

Home Theater in a Box
For more information:
http://www.sony.com/dn
HT-4800DP
Features
General
• Silver Color Components
• STR-K8400P Receiver 100W x 5 (8 ohms
1 kHz, 10% THD)
• DVP-NC675P 5-Disc DVD/CD Changer
• SS-CNP760 Center Channel Speaker
(with Slim Design)
• SS-MSP760 Front & Surround Speaker
• SA-WMSP76 100W Powered Subwoofer
DVD/CD Changer
• 5-Disc DVD/CD Changer: DVP-NS675P
• Progressive Scan Output
• Precision Drive™ 3 System w/ Dual Laser
Assembly and Dynamic Tilt Compensation
• CD-R/CD-RW*, DVD-R, DVD+RW,
DVD-RW (in the video mode), MP3
Playback
• 12 Bit/54 MHz Video D/A Converter
• Dolby® Digital/dts® Coaxial Digital
Output
• Block Noise Reduction, Custom Picture
Mode, Digital Video Enhancer
• Inputs and Outputs: 1 Component Video
Output (Interlace Output)
• Inputs and Outputs: 1 S-Video Output
• Inputs and Outputs: 1 Coaxial Digital
Output
• Inputs and Outputs: 1 Analog Audio
Output
• Convenience Features Multi-Disc Resume
Playback Feature (6 Disc)
• Convenience Features Play Exchange
Function - Play 1 Disc, Exchange 4
• Convenience Features Easy to Use - Color
Coded GUI for MP3 Access
• Convenience Features Quick Set-Up
Function
• Convenience Features TV Virtual Surround
• Convenience Features Custom Parental
Control (40 Disc)
Receiver Section
• STR-K4800P
• Power Output Stereo 100W x 2 (8 ohms
40 - 20,000 Hz, 10% THD)
• Multi-Channel Output 100W x 5 (8 ohms 1
kHz, 0.7% THD)
• Dolby® Digital, dts®, Dolby® Pro Logic®
II Decoding
• Digital Cinema Sound™ System
• Tuner with 20 FM + 10 AM Station Presets
• Inputs and Outputs: 1 Coaxial Digital Input
• Inputs and Outputs: 1 Optical Digital Input
• Inputs and Outputs: 2 Analog Audio
Inputs
• Inputs and Outputs: 3 Analog Audio
Inputs
• Inputs and Outputs: 2 Analog Audio
Outputs
• Inputs and Outputs: 1 Subwoofer Line
Level Output
• Inputs and Outputs: 1 Composite Video
Output
• Inputs and Outputs: 1/4" Headphone Jack
Subwoofer
• SA-WMSP76
• Active Woofer
• 100W x 1 (6 ohm 28-200 Hz, 0.8% THD)
• Input Line In (RCA Type)
• High Frequency Cut-Off Frequency 150
Hz
• Convenience Features Magnetic Shielded
(Front, Center, Surround, Sub) Speakers
• Convenience Features Slim Design
Center Speaker
• Convenience Features 8 ohm Nominal
Impedance
Specifications
General
• Power Requirements AC120V, 60 Hz
• Power Consumption TBD
DVD/CD Changer
• Frequency Response DVD Video (PCM 96
kHz): 2 Hz - 44 kHz (?1.0 dB)
(PCM 48 kHz): 2 Hz - 22 kHz (?0.5dB)
CD: 2 Hz - 20 kHz (?0.5dB)
• Signal-to-Noise Ratio 115dB (Line Out
L/R (Audio) 1/2 Jacks only)
• Harmonic Distortion 0.003%
• Dynamic Range DVD Video: 103dB/CD:
99dB
• Output Level Impedance Analog Line
Output Audio (RCA Type): 2 Vrms/10
kohms
Digital Output (Coaxial): RCA Output Jack
0.5 Vp-p/75 ohms
Component Video Output (Y, Pb, Pr): (Y) 1
Vp-p (Pb, Pr) 0.7 Vp-p/75 ohms
Composite Line Output (Video 1 & 2 RCA
Type): 1 Vp-p/75 ohms
S-Video Output: (Video 1 & Video 2): (Y) 1
Vp-p (C) .286 Vp-p/75 ohms
Tuner
• PLL Quartz-Locked Digital Synthesizer
System
• FM Tuner Section 87.5 - 108.0 MHz
• FM Tuner Section 75 ohms Unbalanced
• AM Tuner Section 530 - 1,710 kHz
• AM Tuner Section External Antenna
Terminal
Amplifier Section
• Power Output 100W x 2 (8 ohms 40 -
20,000 Hz, 10% THD)
• Multi-Channel Output 100W x 5 (8 ohms 1
kHz, 10% THD)
• Frequency Response CD, MD/Tape,
DVD/LD Video 1, 2: 10 Hz-50 kHz
+/-0.5dB/-2dB
• Analog Input Sensitivity Impedance
Multi-Ch In, CD, MD/Tape, DVD/LD,
Video 1, 2: 250 mV/50kohm, S/N 96dB
• Coaxial Digital Input Sensitivity
Impedance DVD/LD: 75 ohms, S/N 100dB
• Optical Digital Input Sensitivity
Impedance Video 2: S/N 100dB
• Composite Input Video 1, Video 2,
DVD/LD: 1 Vp-p 75 ohms
• Analog Output Voltage Impedance
MD/Tape (Out), Video 1 (Audio Out): 250
mV/10k ohm; Subwoofer: 2 V/1k ohm
• Composite Video Output Video 1,
Monitor: 1 Vp-p 75 ohms
Center Speaker
• Speaker System Slim Design Bass Reflex
Magnetically Shielded Type
• Speaker Unit 3 1/4"
• Sensitivity 86db (1W/1M)
Front/Rear Speaker
• Speaker System Bass Reflex Magnetically
Shielded Type
• Speaker Unit 3 1/4"
• Sensitivity 86dB (1W/1M)
• Frequency Range 160 Hz - 20,000 Hz
• Power Handling 100 Watts Maximum
• Nominal Impedance 6 ohms
Subwoofer
• Speaker System Active Subwoofer,
Magnetically Shielded, Acoustically
Loaded Bass Reflex
• Speaker Unit 8" Woofer
• Frequency Range 28 - 200 Hz
Weights and Measurements
• Receiver Dimensions TBD
• Receiver Weight TBD
• DVD/CD Dimensions TBD
• DVD/CD Weights TBD
• Front/Rear Dimensions 4" x 5.9" x 4.9"
(102 x 150 x 126.4) (including projecting
parts)
• Front/Rear Weights TBD
• Center Dimensions 8.8" x 4" x 4.9" (225 x
102 x 125.9mm) (including projecting
parts)
• Center Weights TBD
• Subwoofer Dimensions 10.6" x 12.7" x
15.6" ( 270 x 325 x 398mm)(including
projecting parts)
Supplied Accessories
• Instruction Manual
• Remote Commander® Remote Control
RM-PP760
• Batteries AA x 2
• AM Loop Antenna
• FM Lead Antenna
• Video Cable x 1
• Long Speaker Cord x 2
• Short Speaker Cord x 3
• Foot Pads Speakers (20)
• Foot Pad Subwoofer (4)
• Monaural Connecting Cord (1 phono to 1
phono) (1)
Optional Accessories
• WS-FV11D - Floor Speaker Stands (1 pair)
• WS-WV10D - Wall Mount Speaker
Brackets (1 pair)
UPC Codes
• 0272426438020
