Bar Speaker
Subwoofer
© 2018 Sony Corporation Printed in China
Startup Guide
Home Theatre System
HT-S700RF
4-735-135-41(1)
1Installing the surround speakers (SUR L/SUR R) on the floor
Place the surround speaker on the floor with the front side facing up.
Thread the speaker cord from the surround speaker through the hole in the speaker base.
Position the speaker base so that “FRONT ” points upward.
Secure the speaker base and the surround speaker with four screws.
Slide the speaker cord into the slot at the speaker base.
Note
•Spread a cloth on the floor to avoid damaging the floor when you assemble the surround speakers.
2Connecting the speakers
Gray (from SUR R)
Blue (from SUR L)
IR repeater cord
Subwoofer
SUR L
SUR R
Bar Speaker
Green
Red
White
Note
•Place the subwoofer 5 cm or more away from a TV rack, walls, etc.
•Connect the speaker cords to the matching color of the SPEAKERS jacks on the rear panel of the subwoofer.
What’s in the box
Bar Speaker (1) Subwoofer (1) Surround speaker (2),
speaker base (2), and screw (8)
Remote control (1) R03 (size AAA) battery (2) HDMI cable (1)
WALL MOUNT TEMPLATE (1) Operating Instructions Startup Guide (this document)
To set up the remote control
3Connecting with a TV
YES NO
Are there any HDMI IN jacks labeled “ARC” on your TV?
Blu-ray Disc™ player,
cable box or satellite
box, etc. HDMI cable
(supplied)
HDMI cable
(supplied)
: Video signal
: Audio signal
Blu-ray Disc player, cable
box or satellite box, etc.
Optical digital cable
(not supplied)*
: Video signal
: Audio signal
* If your TV does not support the ARC (Audio Return Channel) function, connect an optical digital cable (not supplied) to listen to the TV sound.
4Turning on the system
Front panel display
Power
Turn on the TV.
Connect the AC power cord (mains lead) of the subwoofer to the wall outlet (mains).
Press (power) on the remote control of the system.
The front panel display lights up.
5Listening to the sound
+/–
SW +/–
INPUT
TV ANALG BT USB
/
Press INPUT repeatedly until the input source you want appears in the front panel display.
To listen to TV audio, make sure that “TV” is displayed in the front panel display, then select the program you want using the TV remote control. When “TV” is not displayed in the front
panel display, press INPUT on the remote control of the system to select the TV input.
Press +/– to adjust the system volume and press SW+/– to adjust the subwoofer volume.
Note
•Depending on the order in which you turn on the TV and the system, the system may enter muting mode. In this case, turn on the TV first, then the system.
