VAIO® Computer
Quick Start
PCG-SRX99/PCG-SRX99K/PCG-SRX99P
Spitfire_QS.book Page 1 Monday, July 8, 2002 6:52 PM

Spitfire_QS.book Page 2 Monday, July 8, 2002 6:52 PM

3
Welcome.......................................................5
Features .......................................................................5
Unpacking Your Computer .........................................6
Registering Your Computer ........................................8
Accessing the User Guide ...........................................8
About Adding Memory ...............................................8
Setting up your dial-up connection .............................9
Setting Up Your VAIO Computer .............13
Locating the Controls and Ports ................................14
Connecting a Power Source ......................................18
Starting Your Computer ............................................25
Shutting Down Your Computer ................................26
Using Power Saving Modes ......................................28
Software and Support Information ..........31
Software Overview....................................................32
Software Support Information...................................34
Using the Recovery CDs...........................37
Application and System Recovery CDs ....................38
Using Your Recovery CDs........................................39
Troubleshooting ........................................45
Getting Help ...............................................51
Support Options.........................................................51
Index ...........................................................53
Spitfire_QS.book Page 3 Monday, July 8, 2002 6:52 PM

VAIO® Computer Quick Start
4
Spitfire_QS.book Page 4 Monday, July 8, 2002 6:52 PM

5
Welcome
Congratulations on your purchase of the Sony VAIO® computer. Sony has
combined leading-edge technology in audio, video, computing, and
communications to provide you with state-of-the-art personal computing.
Features
Here are just some of the features your VAIO® computer has to offer:
❑Exceptional performance — Your computer includes a fast Intel®
Pentium® processor.*
❑Portability — The rechargeable battery pack provides hours of use without
AC power.
❑Wireless functionality — Your computer can connect to a Local Area
Network (LAN) and the Internet, all without direct cable connections.
❑Sony audio and video quality — A high-resolution LCD screen enables
you to take advantage of today’s advanced multimedia applications, games,
and entertainment software.
❑Microsoft® Windows® operating system — Your system includes the
Microsoft® Windows® operating system.
❑Communications — Access popular online services, send and receive
e-mail, browse the Internet, and use fax features.
* Depending on the specific model you purchased, speed controlling technology may not be
present.
✍For a complete description of the specifications of your VAIO® computer, see the
VAIO® Computer Specifications supplied with your computer.
Spitfire_QS.book Page 5 Monday, July 8, 2002 6:52 PM

VAIO® Computer Quick Start
6
Unpacking Your Computer
Remove the following hardware items from the box:
Documents
❑VAIO® Computer User Guide — A searchable online help file that
contains detailed information on how to use your new notebook. To open
this file, click Start on the Windows® taskbar, select Help and Support, and
click VAIO User Guide.
❑VAIO® Computer Quick Start — Contains information on unpacking and
setting up your notebook, the features of your notebook, and how to solve
common problems.
Main Unit AC Adapter
Rechargeable Battery Pack Vertical Installation Base
Power Cord Display Adapter i.LINK Optical Disc Drive
Spitfire_QS.book Page 6 Monday, July 8, 2002 6:52 PM

Unpacking Your Computer
7
❑Microsoft® Windows® manual — Explains how to use the basic features
of the Windows operating system installed on your computer.
❑VAIO® Computer Notes on Use — Explains notes on using your notebook
and offers safety tips.
❑VAIO® Computer Specifications — An online file that details the
hardware specifications and lists the installed software applications for your
computer. To access this file, open the VAIO® User Guide and click on the
specifications link on the Welcome page.
Software CD
❑Microsoft® Word — Enables you to reinstall Microsoft Word to the VAIO
computer you purchased, if the application becomes corrupted or is erased.
Recovery CDs
❑Application Recovery CD(s) — Enables you to reinstall individual
applications if they become corrupted or are erased.
❑System Recovery CD(s) — Enables you to format the C:\ partition of the
hard disk drive, then reinstall the operating system and software titles that
shipped with your notebook if they become corrupted or are erased.
Other
❑Packet containing special product offers
❑Limited Warranty card
✍To use these recovery CDs, you need to connect and use an optical disc drive. See
“Using the Recovery CDs” on page 37 for information on how to use the recovery
CDs.
Spitfire_QS.book Page 7 Monday, July 8, 2002 6:52 PM

VAIO® Computer Quick Start
8
Registering Your Computer
Take advantage of Sony’s commitment to quality customer support and receive
these benefits by registering your computer:
❑Sony Customer Support — Talk to a Support Representative to
troubleshoot problems you may be having with your notebook.
❑Limited Warranty — Protect your investment. See the Warranty Card for
more details.
Accessing the User Guide
The VAIO® computer User Guide is a searchable online help file that contains
detailed information on how to use your new notebook. To open this file, click
Start on the Windows® taskbar, select Help and Support, and click VAIO User
Guide.
About Adding Memory
Depending on the configuration you purchased, your computer may accept
additional memory modules. For information about installation procedures, refer
to the online User Guide and print those relevant steps. The supplied
Specifications lists the amount of memory installed, and required memory
modules for upgrades.
✍You are prompted to register your computer the first time you turn on the unit. Follow
the on-screen instructions to complete the registration process. If you are not able to
register your computer during the first session, you are provided with additional
registration opportunities later.
Spitfire_QS.book Page 8 Monday, July 8, 2002 6:52 PM

Setting up your dial-up connection
9
Setting up your dial-up connection
This section describes the basic steps for setting up your dial-up connection. The
Connection Wizard guides you through the process of connecting to the Internet
and then choosing an Internet Service Provider (ISP) or setting up an existing
account.
Setting up your dial-up connection
(Windows® XP Home Edition/Windows® XP Professional)
1Click Start from the Windows taskbar and select All Programs.
2Point to Accessories, Communications, and then click New Connection
Wizard. The Location Information window appears.
3Follow the instructions on-screen and then click OK to continue. The Phone
and Modem Options window appears.
Location Information window
Spitfire_QS.book Page 9 Monday, July 8, 2002 6:52 PM

VAIO® Computer Quick Start
10
4Select the location from where you are dialing and then click OK. The New
Connection Wizard appears.
Phone and Modem Options window
Spitfire_QS.book Page 10 Monday, July 8, 2002 6:52 PM

Setting up your dial-up connection
11
5Follow the on-screen instructions to finish setting up your dial-up
connection.
New Connection Wizard
Spitfire_QS.book Page 11 Monday, July 8, 2002 6:52 PM

VAIO® Computer Quick Start
12
(Windows® 2000 Professional)
1Double-click the Connect to the Internet icon on the Windows desktop. The
Internet Connection Wizard appears.
2Follow the on-screen instructions to finish setting up your dial-up
connection and to choose your ISP.
Internet Connection Wizard
Spitfire_QS.book Page 12 Monday, July 8, 2002 6:52 PM

13
Setting Up Your VAIO Computer
This section describes the following topics:
❑Locating the Controls and Ports
❑Connecting a Power Source
❑Starting Your Computer
❑Shutting Down Your Computer
❑Using Power Saving Modes
Spitfire_QS.book Page 13 Monday, July 8, 2002 6:52 PM

VAIO® Computer Quick Start
14
Locating the Controls and Ports
Front
1Wireless LAN indicator 9Memory Stick® media slot
2Jog Dial control 10 Speaker
3Jog Dial back button 11 Display
4Left/Right buttons 12 Hard disk drive indicator
5Touchpad 13 Num Lock indicator
6Power indicator 14 Caps Lock indicator
7Battery indicator 15 Scroll Lock indicator
8Memory Stick indicator
2
345
Spitfire_QS.book Page 14 Monday, July 8, 2002 6:52 PM

Locating the Controls and Ports
15
Left
1Speakers 6Monitor port
2Ethernet port 7i.LINK® (IEEE 1394) S400
port
3PC Card slot 8Peripheral device DC Out port*
* Compatible with certain optical disc drives.
4Wireless LAN on/off switch 9Modem jack
5PC Card release button
Spitfire_QS.book Page 15 Monday, July 8, 2002 6:52 PM

VAIO® Computer Quick Start
16
Right
1Memory Stick® media slot 4Microphone jack
2USB port 5Ventilation duct
3Headphone jack 6DC In port
Do not cover the ventilation duct while your computer is on.
Spitfire_QS.book Page 16 Monday, July 8, 2002 6:52 PM

Locating the Controls and Ports
17
Bottom
1Battery lock/unlock lever 3Ventilation fan
2Battery unlock lever
Spitfire_QS.book Page 17 Monday, July 8, 2002 6:52 PM

VAIO® Computer Quick Start
18
Connecting a Power Source
You can use either AC power or a rechargeable battery pack as a power source.
Using the AC adapter
1Plug the cable attached to the AC adapter into the DC In port on the
computer.
2Plug one end of the power cord into the AC adapter.
3Plug the other end of the power cord into an AC outlet.
Connecting Computer to AC Outlet
✍Use your notebook only with the supplied AC adapter. To disconnect your notebook
completely from the main power source, unplug the AC adapter. Make sure that the
electrical outlet is easily accessible.
Computer
DC In
AC adapter
(supplied) Power Cable
Spitfire_QS.book Page 18 Monday, July 8, 2002 6:52 PM

Connecting a Power Source
19
Notes on the AC adapter
❑Your computer operates on 100-240 V AC 50/60 Hz.
❑Do not share the AC outlet with other power-consuming equipment, such as
a copy machine or shredder.
❑You can purchase a power strip with a surge protector. This device prevents
damage to your computer caused by sudden power surges such as those that
may occur during an electrical storm.
❑Do not place heavy objects on the power cord.
❑To disconnect the cord, pull it out by the plug. Never pull the cord itself.
❑Unplug your computer from the wall outlet if you will not be using the
computer for a long time.
❑When the AC adapter is not in use, unplug it from the AC outlet.
❑Use only the AC adapter supplied. Do not use any other AC adapter.
Using battery power
You can use a battery pack as a source of power. The battery pack that comes
with your computer is not fully charged at the time of purchase. Follow the steps
below to insert and charge the battery pack.
✍You can also purchase the high-capacity battery pack as a separate option.
Spitfire_QS.book Page 19 Monday, July 8, 2002 6:52 PM

VAIO® Computer Quick Start
20
To insert the battery pack
1Make sure the lock/unlock lever on the bottom of the computer is in the
“unlock” position.
2Align the grooves and tabs on the battery with the notches and tabs on the
back of the computer. Slide the battery toward the computer until it clicks
into place.
3Slide the lock/unlock lever into the lock position.
Inserting Battery Pack
Battery
Grooves
Spitfire_QS.book Page 20 Monday, July 8, 2002 6:52 PM
