About the Software on Your
Notebook Computer
Your Sony notebook computer is ready to help you work, play, learn, and
communicate as soon as you turn it on. This section gives you an
overview of the activities you can perform with your software titles.
For general information, please refer to your Customer Service Guide.
Sony software
MD Editor
Sony Electronics
When you connect a Sony MD deck that includes a CONTROL A1 jack to your
computer, you can use this software to operate the MD deck from the computer. In
addition to the normal MD playback operations, you can edit MiniDisks while
viewing the computer's display and input disc names and track names using the
computer's keyboard. In addition, if you connect a Sony CD Player that includes a
CONTROL A1 jack to the MD deck, you can also operate the CD player
(playback) from the computer and carry out drag-and-drop recording from a CD
to an MD. For questions, compatibility and technical assistance, please read the
MD Editor Help file or your Customer Service Guide.
PictureGear
Sony Electronics
Create your own environment with the Digital Image Library (photos,
backgrounds, wallpapers, slide shows, etc). PictureGear is your assistant for
creating and implementing personal screen savers... You can even animate your
preferred gifs with Gif Animation Tools. For questions and technical assistance,
please read your Customer Service Guide.
DVgate Still
Sony Electronics
Attaching a DV device to the i.LINK connector enables you to transfer the images
you have captured to your hard drive. DVgate Still displays digital video images
sent from a digital video cassette recorder or a digital video camera recorder, and

About the Software on Your Notebook Computer
6
captures them as still pictures on your notebook computer.
For more details please refer to the on-line help files. For questions and technical
assistance, please read your Customer Service Guide.
Media Bar
Sony Electronics
The Media Bar allows you to play audio and video CDs in the CD-ROM drive or
play audio or video files in various formats on your hard drive.Video images are
displayed in a separate Movie window, which you can move and resize (to full
screen). See a summary of the features in “Using the Media Bar” on page 33. For
questions and technical assistance, please read your Customer Service Guide.
PPK Setup
Sony Electronics
PPK Setup sets the three programmable Power Keys (on the top of the keyboard).
The 12 settings enable you to start any application you want, to establish a dialup
connection or read an e-mail by simply pressing the programmable Power Keys in
combination with other control keys. See the chapter “To use the PPK Setup
screen:” on page 23 for details.
VoiceMemo
Sony Electronics
VoiceMemo enables you to record the voice and play back reminders when
needed; for example, recording phone numbers or appointment times. It can also
be used as a normal memo with text. For questions and technical assistance,
please read your Customer Service Guide.
BatteryScope
Sony Electronics
BatteryScope is a flexible battery management system that gathers critical
information from the battery in your notebook computer, processes it, and
displays the information on the screen in a way that is easy to understand. For
questions and technical assistance, please read your Customer Service Guide.
PowerPanel
Sony Electronics
As a major component of PowerSuite, the PowerPanel utility controls the power
management of your notebook computer and provides key information about
system activity and battery life. Automatic power management selects the most
appropriate profile, depending on the application you’re working with and the
conditions of use.
See the chapter “Controlling Power Management” on page 15 for more
information. PowerPanel Help also provides futher details.

Sony software
7
Sony Notebook Setup
Sony Electronics
Use the Sony Notebook Setup to confirm system information, specify preferences
for system behavior, and change hardware settings for your Sony Notebook
computer.
For more information, refer to the chapter “Sony Notebook Setup” on page 13 or
click Help on the Notebook Setup screen to display the help file. For questions
and technical assistance, please read your Customer Service Guide.
Product Recovery CD-ROM
Sony ITE
The Product Recovery CD-ROM allows you to reinstall individual applications
and device drivers if they are corrupted or accidentally erased. It also allows you
to restore the software titles that were shipped with your computer if they become
corrupted or are erased accidentally. Reinstalling an individual device driver or
software title may correct a problem you are experiencing with your computer,
and you may not need to recover the entire contents of your hard drive.
!You can only use this Recovery CD-ROM on the Sony notebook you purchased and not on
any other Sony PC or other manufacturer's PC.

About the Software on Your Notebook Computer
8
Operating System and other pre-installed software
Windows®98
Microsoft Corporation
Microsoft®Windows®98 makes your computer work better by integrating tightly
with the Internet and providing better system performance and easier system
diagnostics and maintenance. With Windows 98, your system plays better as well
with support for the latest graphics, sound, and multimedia technologies, easy
addition and removal of peripheral devices, and the convergence of the TV and
PC in your home. This exciting new operating system builds on the
groundbreaking features introduced with Windows 95. At the same time,
Windows 98 maintains the best support for older Windows-based applications
and technologies. For questions and technical assistance, go online to
http://www.microsoft.com/support/
Internet Explorer 4.01
Microsoft Corporation
Internet Explorer is the Internet browser of Microsoft.The Setup Wizard
configures your computer to connect automatically to the service provider of your
choice. A full e-mail package enables you to send and receive mail—including
attached files—across the Internet. NetMeeting, Outlook Express and Microsoft
Chat are just some of the components bundled with Internet Explorer 4.01. A
complete online tutorial helps new users become comfortable using the Internet.
For questions and technical assistance, go online to
http://www.microsoft.com/support/
Adobe®Acrobat®Reader 3.01
Adobe Systems Incorporated
Acrobat Reader software allows you to view, navigate, and print electronic
documents in Adobe Portable Document Format (PDF), an open file format that is
intended to preserve the fidelity of documents created on all major computer
platforms. Once Acrobat Reader is installed, you can open and view PDF files
from within your Web browser by clicking on a PDF file embedded in a HTML
file. You quickly see the first page while the rest of the document is being
downloaded. Use the Acrobat Reader to read the Sony Notebook Computer User
Guide online. For questions and technical assistance, go online at
http://www.adobe.com
QuickTime 3.0
Apple
QuickTime is the Apple technology that makes video, sound, music, 3D and
virtual reality come alive for Windows. Now QuickTime takes your multimedia
capabilities to the next level - and the one beyond.
QuickTime 3.0: offering the best in video, sound, music, and voice compression

Operating System and other pre-installed software
9
technologies, QuickTime 3.0 also lets you experience video and audio as soon as
they arrive.
QuickTime VR transports you to virtual reality. Rotate objects, zoom in or out,
look in any direction and navigate from one scene to another.
For further information, see the web site at http://www.apple.com/quicktime/
VirusScan
McAfee
VirusScan is McAfee's powerful and advanced anti-virus solution.
If a virus is detected, VirusScan can attempt to remove it from the infected file,
move the file to a quarantine location, or delete the infected file.
VirusScan is an important element of a comprehensive security program that
includes a variety of safety measures such as regular backups, meaningful
password protection, training, and awareness. For details, please refer to the on-
line help files or for technical support, go to
http://www.mcafee.com

About the Software on Your Notebook Computer
10
Communication software
Phone Tools
BVRP Software
PhoneTools is a powerful communication tool which provides a full range of
features: fax, dialer, telephone directory through an user-friendly interface. In
addition, PhoneTools allows complete management of GSM cellular phone:
phone directories and short messages. Online manual and contextual help are
provided with PhoneTools.
COM One Platinium Card Loader
COM One Company
The Platinium Card loader allows users to upgrade or change the functionnalities
of the PC card modem (firmware of the card is changed).
The Platinium Card is delivered with PSTN V.90, ISDN* and GSM Sony CMD-Z1*
functionnalities.
The upgrade or change can be made by selecting a new firmware (card
programming) in the list provided with the Loader software or by accessing
COM-ONE Web site (http://www.com1.fr). See the online Platinum Card
Manual.
✍*See your retailer for GSM and ISDN kits.

Communication software
11
Features offered by PhoneTools with your Platinium PC card:
Fax transmission:
Fax transmission:Fax transmission:
Fax transmission:
Via PSTN:
Your notebook is delivered with PhoneTools and the PC card configured for fax
transmission.
Via GSM:
If you own a Sony GSM CMD-Z1 or CMD-Z1 Plus, you can purchase a cable to
connect your phone to the PC card: without modifying the settings, PhoneTools
will allow you to send and receive faxes through your mobile phone.
Connection cables for Sony GSM CM-DX1000 and CMD-X2000 are also available.
In order to use this GSM, you must update:
- the PC card settings ,by using the COM1 Platinium Loader program (select the
settings matching your mobile phone)
- the PhoneTools driver (see Configuration/Hardware Configuration/Select
modem): select the MC220 + ISDN + the mobile phone you are using.
With other GSM phones, the set of functions offered by Phonetools may be
limited.
Via ISDN:
You can purchase an ISDN kit from COM1 company or VAIO Direct.
It will allow you to send and receive faxes via ISDN.
GSM Special Features:
GSM Special Features:GSM Special Features:
GSM Special Features:
If you own a Sony GSM CMD-Z1 or CMD-Z1 Plus or CMD-X2000,
PhoneTools allows you to:
- send and receive SMS (this depends on your GSM subscription)
- manage your GSM Phone Book for an easy update of your GSM telephone
directories.
Dialer function:
Dialer function:Dialer function:
Dialer function:
When a telephone is connected to the same line as your notebook modem (PSTN),
the dialer function allows you to dial from the Phonetools telephone directory.
However, the actual telephone conversation will be conducted via your regular
telephone.
Data transmission:
Data transmission:Data transmission:
Data transmission:
Microsoft HyperTerminal provided with Windows 98 allows you to transmit data
via PSTN, ISDN and GSM networks.

12

13
Customizing Your Notebook
Computer
You can customize the settings of your notebook computer. The following
sections briefly describe how to change your computer’s settings. You can
also refer to the Help files of the software for more detailed information.
In addition, you can select the display modes via NeoMagic and enjoy the
benefits of displaying your desktop on two screens.
❑Sony Notebook Setup, page 13
❑PowerPanel, page 15
❑BatteryScope, page 20
❑PPK Setup, page 23
❑NeoMagic tab, page 27
❑Dual Display function, page 31
Sony Notebook Setup
To display the Sony Notebook Setup screen:
1Click the Start button on the Windows 98 taskbar.
2In Programs, select Sony Notebook Setup. The “Basic” window will
appear; you can then enhance the features by clicking the
“Advanced” tab.
3Select the tab for the item you want to change.
4After you finish, click OK.

Customizing Your Notebook Computer
14
Notebook Setup Tabs
Tab Descriptions
About This Computer Display system information, including memory
capacity, serial number, and BIOS version.
Printer Select printer port mode settings.
Power On
Device Sequence
Select the drive and device order you wish to
use for loading the operating system. You can
specify the hard drive as well as other drives
inserted into your computer.
Touchpad You can disable your touchpad by connecting an
optional mouse to your computer’s mouse port
(PS/2 or USB). You can also customize the
settings of your mouse using the mouse utility.
Power On Password Set the password to secure your computer.
Audio Change the volume when loading the operating
system.
Enable Ports Disabling ports releases resources to the system.
To change the serial, infrared settings, click
Advanced on the Basic/Advanced tab.
Basic/Advanced Toggle between Advanced mode (additional
screens with advanced settings) and Basic mode
of display. Advanced mode includes Serial,
Infrared and View Resources tabs.
✍For more information about each option, click Help on the Notebook Setup screen to display
the help file.

PowerPanel
15
PowerPanel
Controlling Power Management
The PowerPanel utility controls the power management of your notebook
computer and provides key information about system activity and
battery life. In combination with BatteryScope, the automatic power
management selects the most advantageous profiles, or lets you
customize the profiles you choose, according to your own needs, with the
goal of extended battery life.
PowerPanel main features
❑Automatic Profile Selection (APS) based on the currently active
application
❑Ability to select special Power Profiles manually from the menu
❑Ability to edit and create new profiles
❑A toolbar shared with BatteryScope
❑Works in harmony with Windows settings.
To activate PowerPanel
When you start your computer, the PowerPanel tasktray appears on the
taskbar by default. If the tasktray does not appear, right click the taskbar
at the bottom of the screen. Select Toolbars from the pop-up menu, then
click PowerPanel. The PowerPanel will appear on the task bar, or:
1Click the Start button on the Windows 98 taskbar.
2In Programs, select (PowerSuite 98) PowerPanel.
The Power Management tasktray appears (you can change it into a
floating window or auto-hide it). When you move the pointer over
the icon on the tasktray, a tooltip with the name of the active
power management profile appears.
3Click the button you want to set.
The appropriate power management command will be activated.
✍When you use the battery pack as power source, your system selects the Maximum Battery
Life power management profile by default. If you select a different power management
profile while using battery power, the same profile will be automatically selected the next
time you use the battery pack to power your computer.

Customizing Your Notebook Computer
16
Power Management Profiles
PowerPanel provides several predefined power management profiles.
Each profile consists of a group of specific power management settings
that are designed to meet specific power management goals, ranging
from maximum power management to no power management.
Main preset profiles
Icon Description
Maximum Battery Life – Provides power saving features to give
you maximum battery life and good performance. It reduces the
brightness of the display and puts it into System Suspend mode
after a specified time period.
Maximum Performance – Provides the best system performance
while still conserving power.
AC Profile – The power management state when AC power is in
use. Similar to the Power Management Off setting. PowerPanel
automatically loads the AC profile unless you disable this feature.
Power Management Off – Turns off all power management features
such as System Suspend and System Hibernation modes.

PowerPanel
17
Power Management Commands
PowerPanel provides power management commands that you can use to
activate specific power management functions and to control power for a
specific device. You might use these commands when you want to
override a profile setting or initiate an immediate action, such as putting
the system into Video Standby mode before the Video Standby timer
expires.
Automatic Profiles Selection (APS)
A Power Profile is a set of timer values for a variety of system devices.
PowerPanel automatically selects the profile associated with the
application you’re using and changes profiles as you switch between
applications.
The Power Management lets your system enter energy saving modes by
levelling some energy consuming parameters, such as LCD brightness, or
hard disk activity.
Icon Description
System Idle - This mode is convenient if you don’t need to use
your computer for a short period. The hard disk and the video
display enter a low power state and the CPU clock and processor
stop. To return the system to the active state, press any key or the
power switch on your computer.
System Suspend – Puts the system into System Suspend mode, a
power management state that saves the state of the system and
peripheral devices in memory (RAM). Power consumption reduces
to a minimum, and the system remains on. To return the system to
the active state, press any key or the power switch on your
computer.
System Hibernation – Provides for the lowest level of power
consumption. The system writes the state of the system and
peripheral devices to the hard disk and turns off the system power.
To return the system to the original state, use the power switch to
turn on power. The system saves the data in the Save to Disk
Partition on the hard drive.
LCD (Video) Standby – Turns off the LCD to save power. If you
turn off the Video Standby timer, the display remains active except
when the system enters System Suspend mode. The video display
system is one of the largest consumers of power in the system.

Customizing Your Notebook Computer
18
Choosing Automatic Profiles
By clicking the button on the left of your PowerPanel taskbar, you can
indicate the kind of application you’re using: this automatically enables
PowerPanel set the power management settings:
Icon Description
Automatic Profile Selection –Analyses the performance of each
application you choose and matches the profiles to its needs.
Word Processing – Optimizes power management with longer
timeouts on the hard disk and display screen. You can also establish
settings for LCD (Video) Standby, Hard Disk Standby, and System
Suspend to optimize power management for your system.
Spreadsheet – Reduces the LCD brightness to “medium”, as
your software doesn’t require higher performance. The sleep
timer is set to 15 minutes.
Presentation – Keeps the display on at all times while it conserves
power. This option is ideal for slide show presentations. You can
establish settings for LCD (Video) Standby, Hard Disk Standby, and
System Suspend to optimize power management for your system.
Communications – Extends battery life by initiating a quick display
time-out. You can also establish settings for LCD (Video) Standby,
Hard Disk Standby, and System Suspend to optimize power
management for your system.
Games – Disables the display and the Hard Disk Spindle Down
timer.

PowerPanel
19
Customizing PowerPanel
You can customize the PowerPanel toolbar to suit your portable
computing needs. You can edit the pre-defined Power Management
settings or create new profiles. Please refer to PowerPanel Help for more
information.

Customizing Your Notebook Computer
20
Displaying Battery Information
You can display detailed information for the batteries used in your
computer. The following sections briefly describe how to display your
computer’s general battery information. You can also refer to the
BatteryScope Help for more detailed information.
Activating BatteryScope
To activate BatteryScope
When you start your computer, the BatteryScope toolbar appears on the
taskbar by default. If the toolbar does not appear, right click the taskbar at
the bottom of the screen. Select toolbar from the pop-up menu, then click
BatteryScope. The BatteryScope appears on the task bar, or:
1Click the Start button on the Windows 98 taskbar.
2In Programs, click (PowerSuite 98) BatteryScope.
When you move the pointer over the battery icon on the task tray, a
tooltip appears indicating the total capacity remaining in the battery and
the estimated time until the battery fully discharges.
You can also view battery gauges on the shared PowerPanel and
BatteryScope toolbar.
❑Percentage indicator
Displays the percentage of the remaining capacity.
❑Time indicator
Displays estimated time (hours/minutes) remaining before the
battery fully drains, also referred to as the time-to-empty.
