Sony VAIO VGN-TX51B User manual

Sony Confidential
VGN-TX51B/TX91PS/TX91S
VGN-TX750FP/TX750P/TX751P/TX770P/TX790P
VGN-TX2HP/TX2XP/TX2XRP
VGN-TX25C/TX26C/TX26GP/TX26LP/TX26SP/TX26TP/TX27CP/TX27GP/TX27LP/TX27TP/TX28CP
SERVICE MANUAL
Ver 4-2006C
9-876-452-04
PERSONAL COMPUTER
Revision History
• ᧄᯏߩ઀᭽߅ࠃ߮ᄖⷰߪޔᡷ⦟ߩߚ߼๔ߥߊ
ᄌᦝߔࠆߎߣ߇޽ࠅ߹ߔ߇ޔߏᛚߊߛߐ޿ޕ
zDesign and specifications are subject to
change without notice.
Area Model Lineup
VGN-TX51B/B
Japanese Japanese VGN-TX91PS∗
VGN-TX91S∗
VGN-TX750P/B
VGN-TX751P/B
VGN-TX770P/B
American US/Canadian VGN-TX770P/T
VGN-TX770P/W
VGN-TX790P/L
Latin VGN-TX750FP
VGN-TX2HP/W
European AEP/UK VGN-TX2XP/B
VGN-TX2XP/L
VGN-TX2XRP/B
VGN-TX26GP/W
International VGN-TX27GP/B
VGN-TX27GP/T
VGN-TX27GP/W
Korean VGN-TX26LP/W
VGN-TX27LP/B
Asian/ VGN-TX25C/W
Oceania/ VGN-TX26C/B
South Africa VGN-TX26C/T
Chinese VGN-TX26C/W
VGN-TX27CP/B
VGN-TX27CP/L
VGN-TX28CP/L
Taiwan VGN-TX26TP/W
VGN-TX27TP/B
Thai VGN-TX26SP/W
∗: CTO model
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3

- 2 -
VGN-TX51B/TX91PS/TX91S (J)
VGN-TX750FP/TX750P/TX751P/TX770P/TX790P (AM)
VGN-TX2HP/TX2XP/TX2XRP (EU)
VGN-TX25C/TX26C/TX26GP/TX26LP/TX26SP/TX26TP/TX27CP/TX27GP/TX27LP/TX27TP/TX28CP (AO)
Sony Confidential
Information in this document is subject to
change without notice.
Sony, VAIO and CLIE are trademarks or regis-
tered trademarks of Sony. Microsoft, Windows,
Windows Media, Outlook, Bookshelf and other
Microsoft products are trademarks or registered
trademarks of Microsoft Corporation in the
United States and other countries. The word
Bluetooth and the Bluetooth logo are trademarks
of Bluetooth SIG, Inc. AMD, the AMD logo, other
AMD product names and combinations thereof
are trademarks of Advanced Micro Devices, Inc.
Intel Inside logo, Pentium, Celeron and Core are
trademarks or registered trademarks of Intel Cor-
poration. Transmeta, the Transmeta logo, Crusoe
Processor, the Crusoe logo and combinations
thereof are trademarks of Transmeta Corporation
in the USA and other countries. Graffiti, Hot-
Sync, PalmModem, and Palm OS are registered
trademarks, and the Hotsync logo and Palm are
trademarks of Palm, Inc. or its subsidiaries. (M)
and Motrola are trademarks of Motrora, Inc. Other
Motrola products and services with (R) mark like
Dragomball are the trademarks of Motrola, Inc.
All other names of systems, products and services
in this manual are trademarks or registered trade-
marks of their respective owners. In this manual,
the (TM) or (R) mark are not specified.
Caution Markings for Lithium/Ion Battery - The
following or similar texts shall be provided on
battery pack of equipment or in both the operating
and the service instructions.
CAUTION: Danger of explosion if battery is
incorrectly replaced. Replace only with the same
or equivalent type recommended by the manu-
facturer. Discard used batteries according to the
manufacturer’s instructions.
CAUTION: The battery pack used in this device
may present a fire or chemical burn hazard if mis-
treated. Do not disassemble, heat above 100°C
(212°F) or incinerate. Dispose of used battery
promptly. Keep away from children.
CAUTION: Changing the back up battery.
Overcharging, short circuiting, reverse charg-
ing, multilation or incineration of the cells must
be avoided to prevent one or more of the fol-
lowing occurrences; release of toxic materials,
release of hydrogen and/or oxygen gas, rise in
surface temperature.
If a cell has leaked or vented, it should be
replaced immediately while avoiding to touch
it without any protection.
Service and Inspection Precautions
1. Obey precautionary markings and
instructions
Labels and stamps on the cabinet, chassis, and
components identify areas requiring special pre-
cautions. Be sure to observe these precautions,
as well as all precautions listed in the operating
manual and other associated documents.
2. Use designated parts only
The set’s components possess important safety
characteristics, such as noncombustibility and
the ability to tolerate large voltages. Be sure that
replacement parts possess the same safety charac-
teristics as the originals. Also remember that the
mark, which appears in circuit diagrams and
parts lists, denotes components that have particu-
larly important safety functions; be extra sure to
use only the designated components.
3. Always follow the original design
when mounting parts and routing
wires
The original layout includes various safety fea-
tures, such as inclusion of insulating materials
(tubes and tape) and the mounting of parts above
the printer board. In addition, internal wiring has
been routed and clamped so as to keep it away
from hot or high-voltage parts. When mounting
parts or routing wires, therefore, be sure to du-
plicate the original layout.
4. Inspect after completing service
After servicing, inspect to make sure that all
screws, components, and wiring have been
returned to their original condition. Also check
the area around the repair location to ensure that
repair work has caused no damage, and confirm
safety.
5. When replacing chip components...
Never reuse components. Also remember that
the negative side of tantalum capacitors is easily
damaged by heat.
6. When handling flexible print
boards...
The temperature of the soldering-iron tip
should be about 270°C.
z
z
z
z
z
Do not apply the tip more than three times to
the same pattern.
Handle patterns with care; never apply force.
Caution: Remember that hard disk drives are
easily damaged by vibration. Always handle
with care.
ATTETION AU COMPOSANT AYANT
RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFÉS PAR UNE
MARQUE SUR LES DIAGRAMMES
SCHÉMATIQUES ET LA LISTE DES PIÈCES
SONT CRITIQUES POUR LA SÉCURITÉ DE
FONCTIONNEMENT. NE REMPLACER CES
COMPOSANTS QUE PAR DES PIÈSES SONY
DONT LES NUMÉROS SONT DONNÉSDANS
CE MANUEL OU DANS LES SUPPÉMENTS
PUBLIÉS PAR SONY.
CAUTION −CLASS 3B VISIBLE AND INVISIBLE LASER RADIATION
WHEN OPEN. AVOID EXPOSURE TO THE BEAM.

- 3 -
VGN-TX51B/TX91PS/TX91S (J)
VGN-TX750FP/TX750P/TX751P/TX770P/TX790P (AM)
VGN-TX2HP/TX2XP/TX2XRP (EU)
VGN-TX25C/TX26C/TX26GP/TX26LP/TX26SP/TX26TP/TX27CP/TX27GP/TX27LP/TX27TP/TX28CP (AO)
Sony Confidential
TABLE OF CONTENTS
Section Title Page
CHAPTER 1. SPECIFICATIONS
1-1. Specifications ...................................................................................................................................... 1-1
(to 1-2)
CHAPTER 2. BLOCK DIAGRAM .............................................................................................. 2-1
(to 2-1)
CHAPTER 3. FRAME HARNESS DIAGRAM ................................................................. 3-1
(to 3-1)
CHAPTER 4. EXPLODED VIEWS AND PARTS LIST
Palmrest
P-1 .......................................................................................................................................................... 4-2
Main Board
M-14-4
Bottom
B-1 ......................................................................................................................................................... 4-6
LCD
L-1. 11.1/WXGA HDAR/BR (To) ........................................................................................................ 4-8
Accessories
A-1 ....................................................................................................................................................... 4-10
(to 4-10)
History of the changes is shown as the
“Revision History” at the end of this data.
ᄌᦝጁᱧߪޔ“ Revision History ” ߣߒߡޔ
ᧄ࠺࡯࠲ᧃߦ⸥タߒߡ޽ࠅ߹ߔޕ
Section Title Page
CHAPTER 5. OTHERS
5-1. The Barcode Label .............................................................................................................................. 5-1
5-2. Precautions for Handling the Drive ................................................................................................... 5-2
5-3. Note for WWAN Board Replacement ................................................................................................ 5-3
(to 5-3)
[MA]
3

CHAPTER 1.
SPECIFICATIONS
1 - 1
VGN-TX51B/TX91PS/TX91S (J)
VGN-TX750FP/TX750P/TX751P/TX770P/TX790P (AM)
VGN-TX2HP/TX2XP/TX2XRP (EU)
VGN-TX25C/TX26C/TX26GP/TX26LP/TX26SP/TX26TP/TX27CP/TX27GP/TX27LP/TX27TP/TX28CP (AO)
Sony Confidential
Area
Model VGN-TX51B/B VGN-TX91PSVGN-TX91SVGN-TX790P/L VGN-TX770P/B VGN-TX770P/T VGN-TX770P/W VGN-TX750P/B
ULV-PM/Do/753/1.20GHz or ULV-PM/Do/753/1.20GHz or
ULV-PM/Do/773/1.30GHz or ULV-PM/Do/773/1.30GHz or
ULV-CelM/Do/383/1GHz ULV-CelM/Do/383/1GHz
Chipset Intel 915GMS Intel 915GMS Intel 915GMS Intel 915GMS Intel 915GMS Intel 915GMS Intel 915GMS Intel 915GMS
Graphics Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated
LCD 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR
40GB/1.8/4200 or 40GB/1.8/4200 or
60GB/1.8/4200 or 60GB/1.8/4200 or
80GB/1.8/4200/PATA 80GB/1.8/4200/PATA
512MB on-board or 512MB on-board or
1GB(512MB on-board+512MBx1) or 1GB(512MB on-board+512MBx1) or
1.5GB(512MB on-board+1GBx1) 1.5GB(512MB on-board+1GBx1)
Memory Max 1.5GB(+1GB) 1.5GB(+1GB) 1.5GB(+1GB) 1.5GB(+1GB) 1.5GB(+1GB) 1.5GB(+1GB) 1.5GB(+1GB) 1.5GB(+1GB)
Optical SuperMulti/9.5/x4/+DL SuperMulti/9.5/x4/+DL or SuperMulti/9.5/x4/+DL or DVD+-RW/9.5/x4/+DL DVD+-RW/9.5/x4/+DL DVD+-RW/9.5/x4/+DL DVD+-RW/9.5/x4/+DL DVD+-RW/9.5/x4/+DL
Combo/9.5/x24 Combo/9.5/x24
Wireless LAN 802.11abg/Intel/mPCI 802.11abg/Intel/mPCI 802.11abg/Intel/mPCI 802.11bg/Intel/mPCI 802.11bg/Intel/mPCI 802.11bg/Intel/mPCI 802.11bg/Intel/mPCI 802.11bg/Intel/mPCI
Wireless WAN × × × 䂾䂾䂾䂾䂾
Bluetooth 䂾䂾䂾䂾䂾䂾䂾䂾
Felica 䂾䂾䂾 ×××××
1seg TV Tuner × × or 䂾× or 䂾×××××
AC Adapter VGP-AC16V7 VGP-AC16V7 VGP-AC16V7 VGP-AC16V8 VGP-AC16V8 VGP-AC16V8 VGP-AC16V8 VGP-AC16V8
VGP-BPS5 or VGP-BPS5 or
VGP-BPL5 VGP-BPL5
Premium Blue or Premium Blue or
Black or Black or
White or White or
Copper Copper
US English or US English
Japanese Japanese
OS XP Home XP Pro XP Home XP Pro XP Pro XP Pro XP Pro XP Pro
XP Personal or XP Personal or
None or None or
XP Pro XP Pro
Area
Model VGN-TX751P/B VGN-TX750FP VGN-TX2XP/B VGN-TX2XP/L VGN-TX2XRP/B VGN-TX2HP/W
CPU ULV-PM/Do/753/1.20GHz ULV-PM/Do/753/1.20GHz ULV-PM/Do/753/1.20GHz ULV-PM/Do/753/1.20GHz ULV-PM/Do/753/1.20GHz ULV-PM/Do/733/1.10GHz
Chipset Intel 915GMS Intel 915GMS Intel 915GMS Intel 915GMS Intel 915GMS Intel 915GMS
Graphics Integrated Integrated Integrated Integrated Integrated Integrated
LCD 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR
HDD 80GB/1.8/4200/PATA 60GB/1.8/4200 80GB/1.8/4200/PATA 80GB/1.8/4200/PATA 80GB/1.8/4200/PATA 80GB/1.8/4200/PATA
Memory Std 1GB(512MB on-board+512MBx1) 1GB(512MB on-board+512MBx1) 1GB(512MB on-board+512MBx1) 1GB(512MB on-board+512MBx1) 1GB(512MB on-board+512MBx1) 512MB on-board
Memory Max 1.5GB(+1GB) 1.5GB(+1GB) 1.5GB(+1GB) 1.5GB(+1GB) 1.5GB(+1GB) 1.5GB(+1GB)
Optical DVD+-RW/9.5/x4/+DL DVD+-RW/9.5/x4/+DL DVD+-RW/9.5/x4/+DL DVD+-RW/9.5/x4/+DL DVD+-RW/9.5/x4/+DL DVD+-RW/9.5/x4/+DL
Wireless LAN 802.11bg/Intel/mPCI 802.11bg/Intel/mPCI 802.11bg/Intel/mPCI 802.11bg/Intel/mPCI 802.11bg/Intel/mPCI 802.11bg/Intel/mPCI
Wireless WAN ××××××
Bluetooth 䂾䂾䂾䂾䂾䂾
Felica ××××××
1seg TV Tuner ××××××
AC Adapter VGP-AC16V8 VGP-AC16V8 VGP-AC16V8 VGP-AC16V8 VGP-AC16V8 VGP-AC16V8
Battery VGP-BPS5 VGP-BPS5 VGP-BPS5 VGP-BPS5 VGP-BPS5 VGP-BPS5
Color Variation Black Black Black Premium Blue Black White
Keyboard US English Latin By the language By the language Russian By the language
OS XP Pro XP Pro XP Pro XP Pro XP Pro XP Pro
Office None None None None None None
EUAM
JAM
1GB(512MB on-board+512MBx1) 512MB on-board512MB on-board 1.5GB(512MB on-board+1GBx1) 1GB(512MB on-board+512MBx1) 1GB(512MB on-board+512MBx1)Memory Std
Copper White BlackColor Variation Black Premium Blue Black
Battery VGP-BPS5
Keyboard Japanese US English (WAN) US English (WAN) US English (WAN) US English (WAN) US English (WAN)
Office XP Personal None None None None None
HDD 80GB/1.8/4200/PATA 80GB/1.8/4200/PATA 80GB/1.8/4200/PATA
CPU ULV-CelM/Do/383/1GHz ULV-PM/Do/773/1.30GHz ULV-PM/Do/773/1.30GHz ULV-PM/Do/753/1.20GHz
VGP-BPS5 VGP-BPS5 VGP-BPS5
80GB/1.8/4200/PATA80GB/1.8/4200/PATA 80GB/1.8/4200/PATA
VGP-BPS5 VGP-BPS5
ULV-PM/Do/773/1.30GHz ULV-PM/Do/773/1.30GHz
1-1. Specifications

The trademarks or registered trademarks of above table, refer to page 2.

The model that is accompanied by astarisk (∗) is CTO model.
• ᧄ⴫ߩ໡ᮡ࡮⊓㍳໡ᮡߦߟ޿ߡߪޔ㧞ࡍ࡯ࠫࠍߏෳᾖߐ޿ޕ
• ᯏ⒳ฬߦ∗߇ߟߊߩߪޔ%61ࡕ࠺࡞ߢߔޕ
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
2
[MA]
1
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3

1 - 2
VGN-TX51B/TX91PS/TX91S (J)
VGN-TX750FP/TX750P/TX751P/TX770P/TX790P (AM)
VGN-TX2HP/TX2XP/TX2XRP (EU)
VGN-TX25C/TX26C/TX26GP/TX26LP/TX26SP/TX26TP/TX27CP/TX27GP/TX27LP/TX27TP/TX28CP (AO)
Sony Confidential
(END)
The trademarks or registered trademarks of above table, refer to page 2.
ᧄ⴫ߩ໡ᮡ࡮⊓㍳໡ᮡߦߟ޿ߡߪޔ㧞ࡍ࡯ࠫࠍߏෳᾖߐ޿ޕ
[MA]
2
Area AO
Model VGN-TX27GP/B VGN-TX27GP/T VGN-TX27GP/W VGN-TX27LP/B VGN-TX27TP/B VGN-TX26GP/W VGN-TX26SP/W VGN-TX26LP/W VGN-TX26TP/W
CPU ULV-PM/Do/753/1.20GHz ULV-PM/Do/753/1.20GHz ULV-PM/Do/753/1.20GHz ULV-PM/Do/753/1.20GHz ULV-PM/Do/753/1.20GHz ULV-PM/Do/733/1.10GHz ULV-PM/Do/733/1.10GHz ULV-PM/Do/733/1.10GHz ULV-PM/Do/733/1.10GHz
Chipset Intel 915GMS Intel 915GMS Intel 915GMS Intel 915GMS Intel 915GMS Intel 915GMS Intel 915GMS Intel 915GMS Intel 915GMS
Graphics Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated
LCD 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR
HDD 60GB/1.8/4200 60GB/1.8/4200 60GB/1.8/4200 60GB/1.8/4200 60GB/1.8/4200 60GB/1.8/4200 60GB/1.8/4200 60GB/1.8/4200 60GB/1.8/4200
Memory Std 1GB(512MB on-board+512MBx1) 1GB(512MB on-board+512MBx1) 1GB(512MB on-board+512MBx1) 1GB(512MB on-board+512MBx1) 1GB(512MB on-board+512MBx1) 512MB on-board 512MB on-board 512MB on-board 512MB on-board
Memory Max 1.5GB(+1GB) 1.5GB(+1GB) 1.5GB(+1GB) 1.5GB(+1GB) 1.5GB(+1GB) 1.5GB(+1GB) 1.5GB(+1GB) 1.5GB(+1GB) 1.5GB(+1GB)
Optical DVD+-RW/9.5/x4/+DL DVD+-RW/9.5/x4/+DL DVD+-RW/9.5/x4/+DL DVD+-RW/9.5/x4/+DL DVD+-RW/9.5/x4/+DL Combo/9.5/x24 Combo/9.5/x24 Combo/9.5/x24 Combo/9.5/x24
Wireless LAN 802.11bg/Intel/mPCI 802.11bg/Intel/mPCI 802.11bg/Intel/mPCI 802.11bg/Intel/mPCI 802.11bg/Intel/mPCI 802.11bg/Intel/mPCI 802.11bg/Intel/mPCI 802.11bg/Intel/mPCI 802.11bg/Intel/mPCI
Wireless WAN ×××××××××
Bluetooth 䂾䂾䂾䂾䂾䂾䂾䂾䂾
Felica ×××××××××
1seg TV Tuner ×××××××××
AC Adapter VGP-AC16V8 VGP-AC16V8 VGP-AC16V8 VGP-AC16V8 VGP-AC16V8 VGP-AC16V8 VGP-AC16V8 VGP-AC16V8 VGP-AC16V8
Battery VGP-BPS5 VGP-BPS5 VGP-BPS5 VGP-BPS5 VGP-BPS5 VGP-BPS5 VGP-BPS5 VGP-BPS5 VGP-BPS5
Color Variation Black Copper White Black Black White White White White
Keyboard US English US English US English Korean Taiwanese US English Thai Korean Taiwanese
OS XP Pro XP Pro XP Pro XP Pro XP Pro XP Pro XP Pro XP Pro XP Pro
Office None None None None None None None None None
Area AO
Model VGN-TX28CP/L VGN-TX27CP/B VGN-TX27CP/L VGN-TX26C/B VGN-TX26C/T VGN-TX26C/W VGN-TX25C/W
CPU ULV-PM/Do/773/1.30GHz ULV-PM/Do/753/1.20GHz ULV-PM/Do/753/1.20GHz ULV-PM/Do/733/1.10GHz ULV-PM/Do/733/1.10GHz ULV-PM/Do/733/1.10GHz ULV-CelM/Do/383/1GHz
Chipset Intel 915GMS Intel 915GMS Intel 915GMS Intel 915GMS Intel 915GMS Intel 915GMS Intel 915GMS
Graphics Integrated Integrated Integrated Integrated Integrated Integrated Integrated
LCD 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR 11.1/WXGA_HDAR/BR
HDD 80GB/1.8/4200/PATA 80GB/1.8/4200/PATA 80GB/1.8/4200/PATA 60GB/1.8/4200 60GB/1.8/4200 60GB/1.8/4200 60GB/1.8/4200
Memory Std 1GB(512MB on-board+512MBx1) 512MB on-board 512MB on-board 512MB on-board 512MB on-board 512MB on-board 512MB on-board
Memory Max 1.5GB(+1GB) 1.5GB(+1GB) 1.5GB(+1GB) 1.5GB(+1GB) 1.5GB(+1GB) 1.5GB(+1GB) 1.5GB(+1GB)
Optical DVD+-RW/9.5/x4/+DL DVD+-RW/9.5/x4/+DL DVD+-RW/9.5/x4/+DL Combo/9.5/x24 Combo/9.5/x24 Combo/9.5/x24 Combo/9.5/x24
Wireless LAN 802.11bg/Intel/mPCI 802.11bg/Intel/mPCI 802.11bg/Intel/mPCI 802.11bg/Intel/mPCI 802.11bg/Intel/mPCI 802.11bg/Intel/mPCI 802.11bg/Atheros/mPCI
Wireless WAN ×××××××
Bluetooth 䂾䂾䂾䂾䂾䂾䂾
Felica ×××××××
1seg TV Tuner ×××××××
AC Adapter VGP-AC16V8 VGP-AC16V8 VGP-AC16V8 VGP-AC16V8 VGP-AC16V8 VGP-AC16V8 VGP-AC16V8
Battery VGP-BPS5 VGP-BPS5 VGP-BPS5 VGP-BPS5 VGP-BPS5 VGP-BPS5 VGP-BPS5
Color Variation Premium Blue Black Premium Blue Black Copper White White
Keyboard US English US English US English US English US English US English US English
OS XP Pro XP Pro XP Pro XP Home XP Home XP Home XP Home
Office None None None None None None None

2 - 1
CHAPTER 2.
BLOCK DIAGRAM
VGN-TX51B/TX91PS/TX91S (J)
VGN-TX750FP/TX750P/TX751P/TX770P/TX790P (AM)
VGN-TX2HP/TX2XP/TX2XRP (EU)
VGN-TX25C/TX26C/TX26GP/TX26LP/TX26SP/TX26TP/TX27CP/TX27GP/TX27LP/TX27TP/TX28CP (AO)
Sony Confidential
(END)
PC Card Slot
Dothan
ULV
PROCESSOR-M
478uFCBGA
MS/MS Duo
PSB
DMI
400MHz
Single
Chanel
DDR2
System power supply
&
Charger
PCI Bus (33 MHz)
LVDS
LPC (33 MHz)
Alviso-GM
GMS
uFCBGA
Clock
Gen.
Azalia
USB
DC Jack
16V
WLAN
(Mini PCI
Type III B socket)
DC/DC
I/F connectors
Port 0
Port 3
SDVO
Port Replicatior
Main Unit
Port 2
i.LINK &
PC Card/
Memory Card
TI PCI7411B
I/F connectors
RJ-45
LCD
11.1" WSXGA
USB
Button
- Power
- Mute
- Volume+
- Volume-
- AV Mode
- ODD Eject
- Play/Pause
- Stop
- Rewind
- Forward
- Touch PAD L/R
Switch
- Wireless On/Off
LEDs
- Power/Standby
- Battery Discharge/Charge
- HDD Access
- *Num Lock
- *CapsLock
- *Scroll Lock
- MS/SD Access
- Optical Drive Access
- BT (for BT Model)
- Wireless LAN
- Wireless WAN (for WAN Model)
- MUTE
VGA
Port 1
USB2
FWH
EC/
KBC
Debug
DC Jack
16V
i.LINK
w/o pwr supply
(4pin x 1)
Port 4
100Base
Ether
Internal Keyboard
USB
Port 5
USB
USB 2.0
Hub
VGA
USB 1
RJ-45
Ether
Audio
CODEC
Internal
Stereo
Speaker
Headphone
Microphone
Magnet
Module
MDC
Modem
BT
Module
TouchPad
ICH6-M
421BGA
RJ-11
Port 6
Port 7
DDR2
SO-DIMM
VGA
IDE
On Board
512MB
PATA
Composit
L-Battery
(10 cell)
SD(MMC)
Slot
1.8inch
HDD
Master
Opt.
Drive
Slave
Battery
(6 cell)
EXTCOMM 2
Fellica Module
EXTCOMM 1 or 3
WWAN
1seg Module
Magnet
Module
(N/A when Docked)
Intel Kinnereth
(100BASE)
802.11bg/ag
EEPROM
(GUID)
EEPROM
(password)
EEPROM
(MAC address)
BT
Antenna
ATF0
ADM1032
CPUCORE
Power
IMVP4+

CHAPTER 3.
FRAME HARNESS DIAGRAM
3 - 1
VGN-TX51B/TX91PS/TX91S (J)
VGN-TX750FP/TX750P/TX751P/TX770P/TX790P (AM)
VGN-TX2HP/TX2XP/TX2XRP (EU)
VGN-TX25C/TX26C/TX26GP/TX26LP/TX26SP/TX26TP/TX27CP/TX27GP/TX27LP/TX27TP/TX28CP (AO)
Sony Confidential
LCD
SWX-197 BOARD SIDE A
FFC(ANL-SWX)
HDD
Side L
Rear
I.LINK
USB
CNX-338
BOARD
SIDE A
HARNESS
(DC)
FFC
(MBX- LEX)
FFC
(LEX-SWX)
FPC-25
PC CARD
MBX-138 BOARD
SIDE A
KEYBOARD
UNIT
FAN
(R)
FILM ANTENNA
(L)
MEMORY
STICK
COMPACT
FLASH
Front
HARNESS
(RJ11)
LEX-70 BOARD
SIDE A SWX-196 BOARD SIDE A
DC IN
LITHIUM ION
BATTERY PACK
USB
MODEM
CARD
PHONE
IFX-421 BOARD
SIDE A
FPC-30
Optical
DRIVE
FPC-23
FPC-60
SIM CARD
LITHIUM
RECHARGEABLE
BATTERY
PORT
REPLICATOR
Bottom
FPC-27
CNX-316
BOARD
SIDE A
NETWORK
HARNESS
(RJ45)
EDGE CARD
FPC-29
FPC-28
FFC(SWX-
TOUCHPAD)
BLUETOOTH MODULE
SPEAKER
MIC
IN
HEAD
PHONE
MDL-19 BOARD
SIDE A
FILM
A
NTENNA
(BT)
FFC
(ANL-
LASSY)
TOUCH PAD
COAXIAL
CABLE
WAN ANTENNA
WAN Model only
Bluetooth
Model
only
Ferica Model only
Type To
Type Hi
(BASE UNIT)
Side R
MONITOR
LCD HARNESS
113
61 30 115
16 2
1
1
2
79
80
2
1
54
123 24
12
1
159
2
59
60
1
259
60
1
1
2
2
60
50
21
123
124
21
23
24
1
2
2
1
80
79
1
68
59 1
541 1
8
1
ANT1
ANT2
12
121
112
161
200
199
12
11
2
1
110
1
50
160
41 16116
43
12
44
49 50
12
60 2
6
1
2
20 19
1
12 1
116
89
VOL + VOL - MUTE W-LAN SW
LID SW LEFT BUTTON RIGHT BUTTON
POWER
PLAY/PAUSE STOP
FFREW EJECT
WIRELESS LAN CARD
FILM ANTENNA
CN6600
CN6605
CN6070
CN6000
CN6560
CN6570
CN2301
CN5002 CN4858
CN6050
CN2101
CN1701
CN5001
CN2401 CN4700
CN6500 CN6520
CN6200
S6201 S6202 S6203 S6204 S6205
CN5500
CN6310
CN6300
CN6360
J5850 J5800
S5402 S5401 S5400
CN5510 S5403
CN5520
S6300
S6310
S6311
CN3
CN2
CN1
S5700
S6206 S6200
CN6170
CN6630
CN6400
CN6010
CN6060
CN6100
CN2901
CN2201
CN2331
CN60
CN2500
CN5503
CN1251
CN1901
CN2951
CN6450
CN6350
CN6410
CN4971
CN6160
CN6103
CN6625
CN2601
ANL-59
BOARD
SIDE A
MEMORY
FFC
(MBX-
FORCE)
AV MODE
HDD
MDL-17 BOARD
SIDE A
COAXIAL
CABLE
COAXIAL
FPC-59
CABLE
TV ANTENNA
TV Model only
(BASE UNIT)
(GRY)
FFC 24P
(MDL-17)
(BLK)
[MA]
3
(END)
From board to connector (direct connection)
Harness (connector at both end)
Harnes s (s oldered a t one end)
C onnectors s oldered on boa rd and appea ring on the pa nel
ၮ᧼߆ࠄࠦࡀࠢ࠲߳㧔࠳ࠗ࡟ࠢ࠻ធ⛯㧕
ࡂ࡯ࡀࠬ㧔┵߇ࠦࡀࠢ࠲ઃ߈㧕
ࡂ࡯ࡀࠬ㧔৻ᣇ߇ඨ↰ઃߌ㧕
ࠦࡀࠢ࠲㧔ၮ᧼஥ඨ↰ઃߌ˴ࡄࡀ࡞஥ࠦࡀࠢ࠲㧕

CHAPTER 4.
EXPLODED VIEWS AND PARTS LIST
4 - 1
VGN-TX51B/TX91PS/TX91S (J)
VGN-TX750FP/TX750P/TX751P/TX770P/TX790P (AM)
VGN-TX2HP/TX2XP/TX2XRP (EU)
VGN-TX25C/TX26C/TX26GP/TX26LP/TX26SP/TX26TP/TX27CP/TX27GP/TX27LP/TX27TP/TX28CP (AO)
Sony Confidential
Palmrest Main Board Bottom LCD Accessories
TX51B/B P-1 M-1 B-1 L-1 A-1
J TX91PS∗P-1 M-1 B-1 L-1 A-1
TX91S∗P-1 M-1 B-1 L-1 A-1
TX790P/L P-1 M-1 B-1 L-1 A-1
TX770P/B P-1 M-1 B-1 L-1 A-1
TX770P/T P-1 M-1 B-1 L-1 A-1
AM TX770P/W P-1 M-1 B-1 L-1 A-1
TX750P/B P-1 M-1 B-1 L-1 A-1
TX751P/B P-1 M-1 B-1 L-1 A-1
TX750FP P-1 M-1 B-1 L-1 A-1
TX2XP/B P-1 M-1 B-1 L-1 A-1
EU TX2XP/L P-1 M-1 B-1 L-1 A-1
TX2XRP/B P-1 M-1 B-1 L-1 A-1
TX2HP/W P-1 M-1 B-1 L-1 A-1
TX27GP/B P-1 M-1 B-1 L-1 A-1
TX27GP/T P-1 M-1 B-1 L-1 A-1
TX27GP/W P-1 M-1 B-1 L-1 A-1
TX27LP/B P-1 M-1 B-1 L-1 A-1
TX27TP/B P-1 M-1 B-1 L-1 A-1
TX26GP/W P-1 M-1 B-1 L-1 A-1
AO TX26SP/W P-1 M-1 B-1 L-1 A-1
TX26LP/W P-1 M-1 B-1 L-1 A-1
TX26TP/W P-1 M-1 B-1 L-1 A-1
TX28CP/L P-1 M-1 B-1 L-1 A-1
TX27CP/B P-1 M-1 B-1 L-1 A-1
TX27CP/L P-1 M-1 B-1 L-1 A-1
TX26C/B P-1 M-1 B-1 L-1 A-1
TX26C/T P-1 M-1 B-1 L-1 A-1
TX26C/W P-1 M-1 B-1 L-1 A-1
TX25C/W P-1 M-1 B-1 L-1 A-1
zThe parts list is compiled by blocks of a palmrest and
bottom etc.The sections of the parts list are different
depending on the model.Please refer to list of contents
shown in the below.
Section Page
Palmrest
P-1 ............................................................................. 4-2
Main Board
M-1 ........................................................................... 4-4
Bottom
B-1 ............................................................................ 4-6
LCD
L-1. 11.1/WXGA HDAR/BR (To) ........................... 4-8
Accessories
A-1 .......................................................................... 4-10
• ಽ⸃࿑䈫ㇱຠ⴫䈲㪃㩷䊌䊷䊛䊧䉴䊃㪃㩷䊗䊃䊛䈭䈬䈱䊑䊨䉾䉪䈗䈫䈮
ಽ䈎䉏䈩䈇䉁䈜䇯ᯏ⒳䈮䉋䈦䈩ㇱຠ⴫䈱䉶䉪䉲䊢䊮䈏⇣䈭䉍䉁
䈜䈱䈪㪃㩷⹦⚦䈲ฝ䈱৻ⷩ⴫䉕ෳᾖ䈚䈩䈒䈣䈘䈇䇯
Palmrest
LCD
Bottom
Main Board
∗: CTO model
NOTE:
The components identified by
mark or
dotted line with mark
are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
Items marked “
*
“ are not stocked since they are seldom
required for routine service. Some delay should be
anticipated when ordering these items.
The mechanical parts with no reference number in the
exploded views are not supplied.
When two or more parts are shown, use the part described
first as the main part.

The parts marked “ $ “ are the High Value Modules (HVM).
The parts marked “ # “ are the parts on which barcode label
is attached.For the barcode label, refer to CHAPTER 5.

The parts marked “ & “ are the “Customer Replacable Parts
(CRP)” that can be replaced by Field Customer Support.
Especially the parts with the <&> mark require the special
attention to use them. Here fore, check first Whether the
desired part is one of the targetted part the Customer
Replaceable Parts (CRP), or the non-targetted parts by
referring to the exploded view.

Regarding the boards of this model, the discrete parts on the
boards cannot be replaced. However, Some connectorscan be
replaced.

The model that is accompanied by asterisk (∗) is the CTO
model.
ޣ૶↪ߩᵈᗧޤ
㨯*ශߩㇱຠߪᏱ஻࿷ᐶߒߡ߅ࠅ߹ߖࠎޕ
㨯࿑㕙⇟ภߩߥ޿ㇱຠߪଏ⛎ߒ߹ߖࠎޕ
㨯૬⸥ㇱຠߩ႐วㇱ⸥タㇱຠࠍࡔࠗࡦㇱຠߣߒߡ
૶↪ߒߡߊߛߐ޿ޕ
㨯ㇱຠฬ⒓ߩ೨ߦශߩߟ޿ߚㇱຠߪ*KIJ8CNWG
/QFWNG*8/ߢߔޕ
㨯ㇱຠฬ⒓ߩ೨ߦශߩߟ޿ߚㇱຠߪࡃ࡯ࠦ࡯࠼࡜ࡌ࡞
⾍ઃㇱຠߢߔޕ
ࡃ࡯ࠦ࡯࠼࡜ࡌ࡞ߦߟ޿ߡߪ%*#26'4ࠍෳᾖߒߡ
ߊߛߐ޿ޕ
㨯ㇱຠฬ⒓ߩ೨ߦශߩߟ޿ߚㇱຠߪ߅ቴ᭽⓹ญ
ߥߤߢ߽឵น⢻ߥ%WUVQOGT4GRNCECDNG2CTVU
%42ߢߔޕ
․ߦ ශߩߟ޿ߚㇱຠߪ૶޿ಽߌ߇ᔅⷐߥㇱຠ
ߢߔߩߢಽ⸃࿑ߢ%QWUVQOGT4GRNCECDNG2CTVU
ኻ⽎ㇱຠ߆ኻ⽎ᄖㇱຠ߆ࠍᔅߕᓮ⏕⹺ߊߛߐ޿ޕ
㨯ᧄࡕ࠺࡞ߩၮ᧼ߦߟ޿ߡߪၮ᧼ߩฦㇱຠߩୃℂ
ߪⴕ߁ߎߣ߇ߢ߈߹ߖࠎޕߚߛߒ৻ㇱߩࠦࡀࠢ࠲
ߦߟ޿ߡߪୃℂน⢻ߢߔޕ
㨯ᯏ⒳ฬߦ߇ߟߊߩߪ%61ࡕ࠺࡞ߢߔޕ
ශߩㇱຠ߹ߚߪ
ߪ቟ోᕈࠍ⛽ᜬߔࠆߚ߼ߦ㊀ⷐߥㇱຠߢߔޕᓥߞߡ
឵ᤨߪᔅߕᜰቯߩㇱຠࠍ૶↪ߒߡߊߛߐ޿ޕ
  ශઃ߈ߩὐ✢ߢ࿐߹ࠇߚㇱຠ
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3

4 - 2
VGN-TX51B/TX91PS/TX91S (J)
VGN-TX750FP/TX750P/TX751P/TX770P/TX790P (AM)
VGN-TX2HP/TX2XP/TX2XRP (EU)
VGN-TX25C/TX26C/TX26GP/TX26LP/TX26SP/TX26TP/TX27CP/TX27GP/TX27LP/TX27TP/TX28CP (AO)
Sony Confidential
WAN, TV
Model
only
TV Model
only
TV Model
only
TV Model
only
Felica
Model
only WAN, TV
Model
only Except
WAN, TV
Model only
Bluetooth Model
only
B3
14
B2
24
42
46
25 B15
(z1)
E
26
27 B3
C
B
8
51
49
50
19
E
41
54
G
M-1
F
22
16 40
52
48
15
14
37
B-1
L
B-1
B2
36
35
45
44
B-1
D
B4
12
9
10
18
M-1
I
W
17 53
55
28
4
1
6
C
UW
14
M-1
A
M-1
D
B13
M-1
A
21
30
15
B-1
B
B2
47
45
45
B-1
C
1
B
313
H
5
43
34
11
G
28
H
20
B2
23
57
58
56
45
59
[ADD]
2
[MA]
3
[MA]
3
[ADD]
3
[MA]
3
P-1. Palmrest P-1
㪈㩷㪩㪼㪽㪅㩷㪥㫆㪅㩷㪙㪈㪌㩷䈲䋬․ᱶ䊎䉴䈱䈢䉄ข䉍ᄖ䈚䈮䈲ᰴ䈱䈇䈝䉏䈎䈱ኾ↪Ꮏౕ䈏ᔅⷐ䈪䈜䇯
DRIVER (H4M 6.0G), SPECIAL
(Part No. : J-2507-713-1)
BIT (H4, 6.0G), SPECIAL
(Part No. : J-2507-712-1)
1 Since Ref. No. B15 is special screws, one of the following special tools is needed for removal.

4 - 3
VGN-TX51B/TX91PS/TX91S (J)
VGN-TX750FP/TX750P/TX751P/TX770P/TX790P (AM)
VGN-TX2HP/TX2XP/TX2XRP (EU)
VGN-TX25C/TX26C/TX26GP/TX26LP/TX26SP/TX26TP/TX27CP/TX27GP/TX27LP/TX27TP/TX28CP (AO)
Sony Confidential
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
P-1. Palmrest
Ref.No. Part No. Description
1 1-826-232-21 SPEAKER (1.6CM)
3 2-637-041-01 BRACKET (SPL)
4 2-637-042-01 BRACKET (SPR)
8 A-1149-384-A $ COMPLETE PWB ANL-59 (S)
9 A-1149-388-A $ COMPLETE PWB LEX-70 (S)
10 A-1149-389-A $ COMPLETE PWB SWX-196 (S)
11 A-1149-390-A $ COMPLETE PWB SWX-197 (S)
12 2-637-035-01 COVER (PALM REST)
14 2-638-452-01 CUSHION (PA)
16 X-2067-117-1 ESCUTCHEON (F) ASSY
17 1-830-633-11 FFC 1 (MBX138-LEX70)
18 1-830-634-12 FFC 2 (LEX70-SWX196)
19 1-830-637-11 FFC 5 (ANL59-SWX197)
20 1-830-638-13 FFC 6 (SWX197-TOUCHPAD)
22 2-637-030-01 KNOB (WL)
23 2-637-039-01 PLATE (TP), GROUND
24 X-2067-119-1 REINFORCEMENT (OP) ASSY
26 2-638-451-01 SHEET (AU)
27 2-349-989-01 SHEET (AUDIO)
41 A-1153-257-A COMPLETE FPC FPC-29 (S)
47 2-656-001-01 REINFORCEMENT (LOCK)
48 2-187-191-01 LASER CAUTION LABEL
49 1-819-666-11 JA9333L-R1M9-7F
50 1-819-667-21 FOXCONN AUDIO JACK
51 2-661-313-01 SHEET (ANL)
52 2-661-314-01 SHEET (FP)
53 2-661-315-01 SHEET (LEX)
54 2-660-311-01 TAPE (6X17)
59 2-680-715-11 TAPE, KAPTON
B2 4-676-936-01 +SCREW,O2 +SPECIAL HEAD SELF S
B3 4-645-214-01 GRIP, M2
B4 4-642-229-01 TAPPING (B 2X)
B13 4-644-637-21 GRIP, M2 EG
TX51B/B TX91PS∗ TX91S∗ TX790P/L TX770P/B TX770P/T TX770P/W TX750P/B TX751P/B TX750FP TX2XP/B TX2XP/L TX2XRP/B TX2HP/W TX27GP/B TX27GP/T TX27GP/W TX27LP/B TX27TP/B TX26GP/W TX26SP/W TX26LP/W TX26TP/W TX28CP/L TX27CP/B TX27CP/L TX26C/B TX26C/T TX26C/W TX25C/W
JAM EU AO
P-1
• This parts list contains two different types of parts.
The first type is the parts that are common to all models.
The other type is the parts that are different depending on each model.
• ߎߩㇱຠ⴫ߪޔᯏ⒳౒ㅢߩㇱຠߣޔᯏ⒳ߦࠃߞߡ૶޿ಽߌ߇ᔅⷐߥㇱຠߦಽ߆ࠇߡ޿߹ߔޕ
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[ADD]
2
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
2
[MA]
1
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
Ref. No. Part No. Description
5 2-637-032-01 BUTTON (TP) [Black/Premium Blue/Copper] zzzzz z z zzzzz zz zz zzzzz
2-637-032-11 BUTTON (TP) [White] zz zz z zzzz zz
6 X-2067-118-1 CAP (PALM R)(M) ASSY [Black/Premium Blue/Copper] zzz zzzzz zz zz zzzzz
X-2067-353-1 CAP (PALM R) (W) ASSY [White] zz z z zzzz zz
13 A-1154-224-A PAD ASSY (B) (S), TOUCH [Black/Premium Blue/Copper] zzzzz z z zzzzz zz zz zzzzz
A-1154-225-A PAD ASSY (W) (S), TOUCH [White] zz zz z zzzz zz
15 2-654-723-01 CUSHION (PALM) [Black/Premium Blue] zzzzz z z zzzzz zz zz zzzzz
2-654-723-11 CUSHION (PALM) [White] zz zz z zzzz zz
21 1-479-449-11 # KEY BOARD UNIT (JP) zzz
1-479-449-21 # KEY BOARD UNIT (US) zz z zzz z zzzzzzz
1-479-449-81 # KEY BOARD UNIT (US) zz z z z
1-479-450-71 # KEY BOARD UNIT (LA) z
1-479-449-61 # (English)...KEY BOARD UNIT (PT) zz
1-479-449-71 # (Russian)...KEY BOARD UNIT (RU) z
1-479-450-11 # (English)...KEY BOARD UNIT (GB) zz z
1-479-450-21 # (German)...KEY BOARD UNIT (DE) zz z
1-479-450-31 # (English,German,French,Italian)...KEY BOARD UNIT (CH) zz
1-479-450-41 # (French)...KEY BOARD UNIT (FR) zz z
1-479-450-51 # (Italian)...KEY BOARD UNIT (IT) zz z
1-479-450-61 # (Spanish)...KEY BOARD UNIT (ES) zz z
1-479-450-81 # (English)...KEY BOARD UNIT (SE) zz
1-479-450-91 # (English)...KEY BOARD UNIT (BE) zz z
1-479-449-31 # KEY BOARD UNIT (KR) zz
1-479-449-41 # KEY BOARD UNIT (TH) z
1-479-449-51 # KEY BOARD UNIT (TW) zz
25 A-1154-927-A $ RW MODULE ASSY (S) zzz
28 4-676-302-01 TAPE (COMMON) zzzzz z z z zzzzzzzz zzzzzz zzzzz zzz
30 X-2067-116-1 PALMREST(M) ASSY [Black/Premium Blue] zz z z zzzzz zz zz zzzz z
X-2067-350-1 PALMREST(MF) ASSY [Black/Premium Blue/Copper] zzz
X-2067-351-1 PALMREST(W) ASSY [White] zz z zzzz zz
X-2067-352-1 PALMREST(WF) ASSY [White] zz
X-2108-095-1 PALM REST (WF1) ASSY [White] zz
X-2108-096-1 PALM REST (MF1) ASSY [Black/Premium Blue/Copper] zz
34 1-479-129-13 BLUETOOTH MODULE zzzzz z z z zzzzzzzzzz zzzzzz zzz zz z
35 2-654-503-01 PLATE (GAR) zzzz z z z
36 1-754-391-21 ANTENNA, WAN (BASE UNIT) zz z z z
1-754-429-21 ANTENNA, TV (BASE UNIT) zz
37 1-754-391-11 ANTENNA, WAN (ELEMENT UNIT) zz z z z
1-754-429-11 & ANTENNA, TV (ELEMENT UNIT) zz
40 2-637-031-11 PANEL (F) zzz zzzzzzzzzzzzzzzzzzzzzz
2-637-031-21 PANEL (F) zz z z z
42 2-650-362-01 SHEET, FERRITE zzz
43 1-754-332-31 FILM ANTENNA(BT) zzzzz z z z zzzzzzzz zzzzzz zz zzz zz z
44 1-830-851-21 CABLE, COAXIAL (WITH U.F.L CON) zz z z z
1-830-851-11 CABLE, COAXIAL (WITH U.F.L CON zz
45 4-658-789-02 TAPE (HARNESS) zzzzz z z z zzzzzzzz zzzzzz zz zzz zz z
46 1-830-636-11 FFC 4 (ANL59-LASSY) zzz
55 1-832-126-11 CABLE, COAXIAL (WITH U.F.L CON zz
56 4-672-493-01 COVER (SC) zz
57 A-1177-549-A COMPLETE FPC FPC-59 (S) zz
58 2-637-027-04 SHEET (SP) [Black/Premium Blue/Copper] zz
2-637-027-14 SHEET (SP) [White] zz
B15 4-680-939-01 SCREW(M2)(GOKUHIRA)(MITSUMIZO) zzz
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[ADD]
3
[MA]
3

4 - 4
VGN-TX51B/TX91PS/TX91S (J)
VGN-TX750FP/TX750P/TX751P/TX770P/TX790P (AM)
VGN-TX2HP/TX2XP/TX2XRP (EU)
VGN-TX25C/TX26C/TX26GP/TX26LP/TX26SP/TX26TP/TX27CP/TX27GP/TX27LP/TX27TP/TX28CP (AO)
Sony Confidential
M-1. Main Board M-1
325
325
B5
B5
307
323
B2
318
E
KB2
L
B-1
B-1
B-1 L-1
MP-1
I
P-1
F
B-1
R
B-1
N
P-1
A
L-1
O
L-1
P302
324
312
B-1
F
B-1
S
B-1
Q
P-1
D
B-1
G
316
301
303
B-1
J
P-1
A
317
[ADD]
3

4 - 5
VGN-TX51B/TX91PS/TX91S (J)
VGN-TX750FP/TX750P/TX751P/TX770P/TX790P (AM)
VGN-TX2HP/TX2XP/TX2XRP (EU)
VGN-TX25C/TX26C/TX26GP/TX26LP/TX26SP/TX26TP/TX27CP/TX27GP/TX27LP/TX27TP/TX28CP (AO)
Sony Confidential
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Ref. No. Part No. Description
302 1-789-095-81 # CARD,WIRELESS LAN [a/b/g] zzz
1-761-864-51 # WIRELESS LAN CARD [b/g] zz z z z zz z z
1-761-864-71 # WIRELESS LAN CARD [b/g] zzzzzzzz zzz z zzz zz
1-789-014-31 # CARD,WIRELESS LAN [b/g] z
303 A-1183-063-A $ # COMPLETE PWB MBX138(C10_5)B(S) zzz z
A-1183-064-A $ # COMPLETE PWB MBX138(P11_5)B(S) zzzzzzzz
A-1183-065-A $ # COMPLETE PWB MBX138(P12_5)B(S) zz zzzzzz zzzzz zz
A-1177-527-A $ # COMPLETEPWB MBX138(P13_512)(S) zzzz z z z
312 6-707-504-01 # IC HYS64T128021HDL-5-A [1GB] zzz
6-707-350-01 # IC HYS64T64020HDL-5-A [512MB] zz zzz zzzzz zzzzz z
Ref.No. Part No. Description
301 2-637-075-01 BRACKET (CPU)
307 1-787-364-11 D.C. FAN
316 2-638-456-01 SHEET (MBX)
317 2-654-740-01 THERMAL SHEET (GM)
318 4-673-367-02 THERMAL SHEET(CPU)
323 2-650-083-01 SHEET (FIN)
324 1-756-584-11 LITHIUM RECHARGEABLE BATTERY
325 2-655-677-01 CUSHION (GM)
B2 4-676-936-01 +SCREW,O2 +SPECIAL HEAD SELF S
B5 4-672-834-51 SCREW, +B EG GRIP
M-1. Main Board M-1
TX51B/B TX91PS∗ TX91S∗ TX790P/L TX770P/B TX770P/T TX770P/W TX750P/B TX751P/B TX750FP TX2XP/B TX2XP/L TX2XRP/B TX2HP/W TX27GP/B TX27GP/T TX27GP/W TX27LP/B TX27TP/B TX26GP/W TX26SP/W TX26LP/W TX26TP/W TX28CP/L TX27CP/B TX27CP/L TX26C/B TX26C/T TX26C/W TX25C/W
JAM EU AO
• This parts list contains two different types of parts.
The first type is the parts that are common to all models.
The other type is the parts that are different depending on each model.
• ߎߩㇱຠ⴫ߪޔᯏ⒳౒ㅢߩㇱຠߣޔᯏ⒳ߦࠃߞߡ૶޿ಽߌ߇ᔅⷐߥㇱຠߦಽ߆ࠇߡ޿߹ߔޕ
[MA]
1
[MA]
1
[MA]
1
[MA]
2
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3

4 - 6
VGN-TX51B/TX91PS/TX91S (J)
VGN-TX750FP/TX750P/TX751P/TX770P/TX790P (AM)
VGN-TX2HP/TX2XP/TX2XRP (EU)
VGN-TX25C/TX26C/TX26GP/TX26LP/TX26SP/TX26TP/TX27CP/TX27GP/TX27LP/TX27TP/TX28CP (AO)
Sony Confidential
WAN Model
only
Type To
Except
WAN
Model only
565
559
M-1
SB3
P-1
D
556 (z2)
564
TV Model
only
565
577
M-1
S
B3
P-1
P-1
576 (z1)
564
579
M-1
N
530
563
515
B2
513
562
B2
M-1
K
518
569
575
503 M-1
L-1
L-1
M-1
G
B2
554
553
B11
554
554
570
554 M-1
Q
V
546
558
561
B2
P-1
M-1
P-1
B
X
566
514
545
B1
521
532
544 B5
M-1
L-1
J
525
560
45
523
M-1
L
H
E
X
C
547
551
535
529
B14
516
B14 520
B14
520
B14 524
549
526
550
528
519
557
568
522
J
F
D
U
B6
504
578
B2
B10
555 45
567 506
527
550
543
V
552
M-1
R
J
28
572
534
536
507
501
B2 B2
B6
505
B5 517
K
I
B5
546
512
540
Type Hi
553
574
573
V
[ADD]
2
[ADD]
3
[MA]
3
[MA]
3
B-1. Bottom B-1
1) When replacing the Ref.576, be sure to write the key with the jig No. [VSJ-00061-1].
1) 4GHࠍ឵ߔࠆ㓙ߦߪࠫࠣ⇟ภ=85,?ߢᔅߕ㎛ߩᦠ߈ㄟߺࠍߒߡߊߛߐ޿ޕ
2) Wen replacing the WWAN board (Ref.556), be sure to refer to "5-3. Note for WWAN Board Replacement".
2) 99#0ၮ᧼㧔4GH㧕ࠍ឵ߔࠆ㓙ߦߪᔅߕޟ99#0ၮ᧼឵ᤨߩᵈᗧޠࠍෳᾖߒߡߊߛߐ޿ޕ
[ADD]
2
[MA]
3

4 - 7
VGN-TX51B/TX91PS/TX91S (J)
VGN-TX750FP/TX750P/TX751P/TX770P/TX790P (AM)
VGN-TX2HP/TX2XP/TX2XRP (EU)
VGN-TX25C/TX26C/TX26GP/TX26LP/TX26SP/TX26TP/TX27CP/TX27GP/TX27LP/TX27TP/TX28CP (AO)
Sony Confidential
B-1. Bottom B-1
Ref.No. Part No. Description
28 4-676-302-01 TAPE (COMMON)
45 4-658-789-02 TAPE (HARNESS)
503 2-637-077-01 BRACKET (HDD)
504 2-637-084-01 BRACKET (OPL)
505 2-637-085-01 BRACKET (OPR)
506 2-637-070-01 BRACKET (VGA)
512 A-1149-385-A $ COMPLETE PWB CNX-316 (S)
513 A-1149-386-A $ COMPLETE PWB CNX-338 (S)
514 A-1149-387-A $ COMPLETE PWB IFX-421 (S)
515 1-819-775-11 CONNECTOR, PC CARD
516 2-637-071-01 & COVER (MEMORY)
517 2-187-193-01 CUSHION (OP)
518 2-514-300-01 CUSHION (SCREW)
519 2-637-054-01 DOOR (POTORI)
520 2-177-286-01 & FOOT
521 1-963-843-11 HARNESS(RJ11)
522 1-963-842-11 HARNESS(RJ45)
523 1-963-879-11 HARNESS,CONNECTOR WITH
524 X-2067-120-1 HOUSING (BOTTOM) ASSY
525 2-650-288-01 INSULATOR (MDCR)
526 2-637-048-01 KNOB (BT)
527 2-637-049-01 LATCH (BL)
528 2-637-050-01 LATCH (BR)
530 2-671-906-01 SHEET (FPCPC)
532 1-417-539-12 # MODEM CARD
534 2-637-067-01 PLATE (BT), SHIELD
535 2-637-068-01 PLATE (BTL), SHIELD
536 2-637-069-01 PLATE (BTR), SHIELD
540 2-654-880-01 SHEET (BF)
543 2-656-349-01 SHEET (FPC)
544 2-650-713-01 SHEET (MDC)
545 2-654-982-01 SHEET (MSD)
546 2-656-350-01 SHEET (PR)
547 2-637-047-01 SHUTTER (PCC)
549 2-637-051-01 SPRING (BT), COMPRESSION COIL
550 2-637-052-01 SPRING (LATCH), COIL
551 2-637-053-01 SPRING (PCC), TORSION
555 A-1153-259-A COMPLETE FPC FPC-28 (S)
558 1-868-275-11 PWB, FPC-27 PRINT
560 1-868-277-11 PWB, FPC-30 PRINT
561 2-650-082-01 SHEET (FAN)
562 1-794-548-31 CONNECTOR, USB(A)
563 A-1153-258-A COMPLETE FPC FPC-25 (S)
566 1-818-784-21 USB CONNECTOR (A)
567 2-656-461-01 WASHER (6.5-3.3),COPPER LEAF
568 2-657-424-01 SHEET (LAN)
569 2-655-676-01 DUMMY CARD
570 2-661-114-01 CUSHION(KBMS)
572 2-657-644-01 TAPE (40X15)
575 2-660-915-03 SPACER PCC
578 2-670-734-01 SHIELD TAPE (7X30)
B1 4-651-989-61 SPACER (MBX)
B2 4-676-936-01 +SCREW,O2 +SPECIAL HEAD SELF S
B5 4-672-834-51 SCREW, +B EG GRIP
B6 2-022-855-01 SCREW M2 EG
B10 4-674-716-01 SCREW (NO.4-40) (UNC)
B11 4-673-751-01 NUT (M2) (TYPE2)
B14 4-672-834-31 & SCREW, +B EG GRIP
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
TX51B/B TX91PS∗ TX91S∗ TX790P/L TX770P/B TX770P/T TX770P/W TX750P/B TX751P/B TX750FP TX2XP/B TX2XP/L TX2XRP/B TX2HP/W TX27GP/B TX27GP/T TX27GP/W TX27LP/B TX27TP/B TX26GP/W TX26SP/W TX26LP/W TX26TP/W TX28CP/L TX27CP/B TX27CP/L TX26C/B TX26C/T TX26C/W TX25C/W
JAM EU AO
• This parts list contains two different types of parts.
The first type is the parts that are common to all models.
The other type is the parts that are different depending on each model.
• ߎߩㇱຠ⴫ߪޔᯏ⒳౒ㅢߩㇱຠߣޔᯏ⒳ߦࠃߞߡ૶޿ಽߌ߇ᔅⷐߥㇱຠߦಽ߆ࠇߡ޿߹ߔޕ
[MA]
1
[CHG]
2
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[ADD]
3
Ref. No. Part No. Description
501 X-2067-123-1 BEZEL(M) ASSY, OPT [Black/Premium Blue/Copper] zzzzz z z zzzzz zz z z z zzz z
X-2067-354-1 BEZEL (W) ASSY, OPT [White] zz zz z zzzz zz
507 A-1149-397-A $ # COMBODRIVE(UJDA765,9.5MM,R)(S) [Combo/9.5/x24] zz zzzz zzzz
A-1149-395-A $ # DVD+-RW (UJ-832M,9.5MM,R) (S) [DVD+-RW/9.5/x4/+DL] zz z zz zzzzzzzzzzz zzz
A-1149-396-A $ # DVDRWSM (UJ-832M,9.5MM,R) (S) [SuperMulti/9.5/x4/+DL] zzz
529 2-637-057-01 COVER (L) [Black/Premium Blue/Copper] zzzzz z z zzzzz zz z z zzzz z
2-637-057-11 COVER (L) [White] zz zz z zzzz zz
552 A-1153-260-A COMPLETE FPC FPC-23 (TO) (S) zzz z z z zzzzzz zz zz zzzzzz zzz zz z
A-1177-526-A COMPLETE FPC FPC-60 (S) zz z zzz zz
553 A-1149-392-A $ # HDD (MK4006GAH-40GB) (S) zz
A-1149-393-A $ # HDD (MK6006GAH-60GB) (S) zz z zzzzzzzzz zzzz
A-1177-528-A $ # HDD (HTC426060G8CE00-60GB) (S) zz z zzz zz
A-1178-396-A $ # HDD (MK8007GAH-80.0GB)(8M)(S) zzzzz z zz zzzzz zzz
554 2-637-080-01 CUSHION (HDDTO) zzzzz z zz zzzzzz zz zz zzzz zz zzz zz z
556 A-1153-774-A $ # W WAN UNIT (-31) (S) zz z z z
557 2-637-074-01 SHEET (GPOP) zzz zzzzzzzzzzzzzzzzzzzzzz
559 1-830-635-11 FFC 3 (MBX138-FORCE) zz z z z
564 2-637-073-01 SHEET (BTR) zzzz z zz
565 2-656-348-01 TAPE (MW) zzzz z zz
573 2-637-078-01 CUSHION (HDDHIF) zz z zzz zz
574 2-637-079-01 CUSHION (HDDHIB) zz z zzz zz
576 A-1177-525-A $ COMPLETE PWB MDL-17 (S) zz
577 1-831-885-11 CABLE, FLEXIBLE FLAT 24P(MDL-17) zz
579 2-680-714-01 GASKET (10-5) zz
B3 4-645-214-01 GRIP, M2 zzzz z zz

4 - 8
VGN-TX51B/TX91PS/TX91S (J)
VGN-TX750FP/TX750P/TX751P/TX770P/TX790P (AM)
VGN-TX2HP/TX2XP/TX2XRP (EU)
VGN-TX25C/TX26C/TX26GP/TX26LP/TX26SP/TX26TP/TX27CP/TX27GP/TX27LP/TX27TP/TX28CP (AO)
Sony Confidential
M-1
B-1
M-1
B-1
P-1
B-1
M-1
M
P
Black,
Premium Blue
Model only
B7 (z1)
B8 (z1)
White, Copper
Model only
WAN
Model only
TV Model
only
WAN
Model only
M
M
I
O
H
L
K
B16
1024
1022 1003
1019
1040
1028
1039
1041
1044
1031
1027 1008
1043
1011
1033
1002
B5
B6 1016
1027
1035
1038
B6
1013
1001
1027
1042
1007
1009
B5
1032
1034
B5
B5
[MA]
3
[ADD]
3
TV
Model only
1044
1045
[ADD]
3
[MA]
3
L-1. LCD 11.1/WXGA HDAR/BR
- Made by To -
L-1
㪈㩷㪩㪼㪽㪅㩷㪥㫆㪅㩷㪙㪎㪃㩷㪙㪏㩷䈲䋬․ᱶ䊎䉴䈱䈢䉄ข䉍ᄖ䈚䈮䈲ᰴ䈱䈇䈝䉏䈎䈱ኾ↪Ꮏౕ䈏ᔅⷐ䈪䈜䇯
Driver for PIN-FACE M2
(Part No. : J-2507-928-1)
1 Since Ref. No. B7, B8 are special screws, one of the following special tools is needed for removal.

4 - 9
VGN-TX51B/TX91PS/TX91S (J)
VGN-TX750FP/TX750P/TX751P/TX770P/TX790P (AM)
VGN-TX2HP/TX2XP/TX2XRP (EU)
VGN-TX25C/TX26C/TX26GP/TX26LP/TX26SP/TX26TP/TX27CP/TX27GP/TX27LP/TX27TP/TX28CP (AO)
Sony Confidential
L-1. LCD 11.1/WXGA HDAR/BR
- Made by To -
Ref.No. Part No. Description
1001 1-754-393-11 ANTENNA, FILM (L)
1002 1-754-393-21 ANTENNA, FILM (R)
1007 2-637-055-01 COVER (BL)
1008 2-637-056-01 COVER (BR)
1027 2-637-009-01 CUSHION (LCD)
1031 1-964-045-11 HARNESS, LCD
1032 2-637-002-01 HINGE (L)
1033 2-637-003-01 HINGE (R)
1034 A-1178-395-A $ # LCD LTD111EXCY (S)
1038 2-637-004-01 MAGNET
1042 2-660-980-01 TAPE(CBL)
B5 4-672-834-51 SCREW, +B EG GRIP
B6 2-022-855-01 SCREW M2 EG
B16 2-663-662-01 <&> SCREW (M2), STEP
L-1
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
TX51B/B TX91PS∗ TX91S∗ TX790P/L TX770P/B TX770P/T TX770P/W TX750P/B TX751P/B TX750FP TX2XP/B TX2XP/L TX2XRP/B TX2HP/W TX27GP/B TX27GP/T TX27GP/W TX27LP/B TX27TP/B TX26GP/W TX26SP/W TX26LP/W TX26TP/W TX28CP/L TX27CP/B TX27CP/L TX26C/B TX26C/T TX26C/W TX25C/W
JAM EU AO
• This parts list contains two different types of parts.
The first type is the parts that are common to all models.
The other type is the parts that are different depending on each model.
• ߎߩㇱຠ⴫ߪޔᯏ⒳౒ㅢߩㇱຠߣޔᯏ⒳ߦࠃߞߡ૶޿ಽߌ߇ᔅⷐߥㇱຠߦಽ߆ࠇߡ޿߹ߔޕ
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[ADD]
3
[ADD]
3
Ref. No. Part No. Description
1003 X-2102-540-1 BEZEL (B) ASSY [Black] zzz zzzzz z z zz z z
X-2102-541-1 BEZEL (W) ASSY [White] zz zzzzzzz zz
X-2102-542-1 BEZEL (X) ASSY [Premium Blue] zzzzzz
X-2108-407-1 BEZEL (M) ASSY [Copper] zz zzz
1009 2-637-001-01 COVER (HL) [Black/Premium Blue/Copper] zzzzzz zzzzzzzzzz zzzzz
2-637-001-11 COVER (HL) [White] zz zzzzzzz zz
1011 2-637-000-01 COVER (HR) [Black/Premium Blue/Copper] zzzzzz zzzzzzzzzz zzzzz
2-637-000-11 COVER (HR) [White] zz zzzzzzz zz
1013 2-636-999-01 COVER (WLANL) [Black] zzz zzzzz z z zz z z
2-636-999-11 COVER (WLANL) [White] zz zzzzzzz zz
2-636-999-21 COVER (WLANL) [Premium Blue] zzzzzz
2-636-999-31 COVER (WLANL) [Copper] zz zzz
1016 2-636-998-01 COVER (WLANR) [Black] zzz zzzzz z z zz z z
2-636-998-11 COVER (WLANR) [White] zz zzzzzzz zz
2-636-998-21 COVER (WLANR) [Premium Blue] zzzzzz
2-636-998-31 COVER (WLANR) [Copper] zz zzz
1019 2-637-008-01 & CUSHION (DCC) [Black] zzz zzzzz z z zz z z
2-637-008-11 & CUSHION (DCC) [White] zz zzzzzzz zz
2-637-008-21 & CUSHION (DCC) [Premium Blue] zzzzzz
2-637-008-31 & CUSHION (DCC) [Copper] zz zzz
1022 2-637-007-01 & CUSHION (DD) [Black] zzz zzzzz z z zz z z
2-637-007-11 & CUSHION (DD) [White] zz zzzzzzz zz
2-637-007-21 & CUSHION (DD) [Premium Blue] zzzzzz
2-637-007-31 & CUSHION (DD) [Copper] zz zzz
1024 2-637-006-01 & CUSHION (DU) [Black] zzz zzzzz z z zz z z
2-637-006-11 & CUSHION (DU) [White] zz zzzzzzz zz
2-637-006-21 & CUSHION (DU) [Premium Blue] zzzzzz
2-637-006-31 & CUSHION (DU) [Copper] zz zzz
1028 4-670-190-21 & CUSHION (SIDE) [Black] zzz zzzzz z z zz z z
4-670-190-31 & CUSHION (SIDE) [White] zz zzzzzzz zz
4-670-190-41 & CUSHION (SIDE) [Premium Blue] zzzzzz
4-670-190-51 & CUSHION (SIDE) [Copper] zz zzz
1035 A-1154-928-A LOGO(B)ASSY,DISPLAY(S) [Black] zzz zzzzz z z zz z z
A-1154-929-A LOGO (W) ASSY,DISPLAY(S) [White] zz zzzzzzz zz
A-1154-930-A LOGO(CARBON)ASSY,DISPLAY(S) [Premium Blue] zzzzzz
A-1177-103-A LOGO (T) ASSY ,DISPLAY (S) [Copper] zz zzz
1039 2-656-347-01 SHEET (BEZEL), EMI zzzzz
1040 2-671-567-01 LABEL ID (J) zz
2-671-567-11 LABEL ID (J) zz
2-671-567-21 LABEL ID (J) zz
2-671-567-31 LABEL ID (J) zz
2-671-567-41 LABEL ID (J) zz
2-671-567-51 LABEL ID (J) zz
2-671-567-61 LABEL ID (J) zz
2-671-567-71 LABEL ID (J) zz
2-671-567-81 LABEL ID (J) z
2-671-570-01 LABEL ID (U) z
2-671-570-11 LABEL ID (U) z
2-671-570-21 LABEL ID (U) z
2-671-570-31 LABEL ID (U) z
2-671-570-41 LABEL ID (U) z
2-671-570-51 LABEL ID (U) z
2-671-570-61 LABEL ID (U) z
2-671-571-01 LABEL ID (E) z
2-671-571-11 LABEL ID (E) z
2-671-571-21 LABEL ID (E) z
2-671-571-31 LABEL ID (E) z
2-671-573-01 LABEL ID (C) z
2-671-573-11 LABEL ID (C) z
2-671-573-21 LABEL ID (C) z
2-671-573-31 LABEL ID (C) z
2-671-573-41 LABEL ID (C) z
2-671-573-51 LABEL ID (C) z
2-671-573-61 LABEL ID (C) z
2-671-967-01 LABEL ID (IAW) z
2-671-967-11 LABEL ID (IAW) z
2-671-967-21 LABEL ID (IAW) z
2-671-967-31 LABEL ID (IAW) z
2-671-967-41 LABEL ID (IAW) z
2-671-968-01 LABEL ID (IBW) z
2-671-968-11 LABEL ID (IBW) z
2-671-968-21 LABEL ID (IBW) z
2-671-968-31 LABEL ID (IBW) z
1041 2-656-346-01 SHEET (BEZEL) zzzzz
1043 2-667-543-01 GASKET F zzzzz
1044 2-680-713-01 SHEET, EMI (T0.1) zz
1045 2-680-715-01 TAPE, KAPTON zz
B7 2-660-372-01 SCREW (PIN-FACE M2), ORNAMENT zzzzz zzzzzz z zz zzzz
B8 2-660-372-11 SCREW (PIN-FACE M2), ORNAMENT zz zz z zz zzzz zzz

4 - 10
VGN-TX51B/TX91PS/TX91S (J)
VGN-TX750FP/TX750P/TX751P/TX770P/TX790P (AM)
VGN-TX2HP/TX2XP/TX2XRP (EU)
VGN-TX25C/TX26C/TX26GP/TX26LP/TX26SP/TX26TP/TX27CP/TX27GP/TX27LP/TX27TP/TX28CP (AO)
Sony Confidential
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Ref. No. Part No. Description
2001 1-478-583-24 $ & AC ADAPTOR zzz
2002 1-478-860-51 $ & AC ADAPTOR zz z z zzzzz zzzzzzzzzzzzzzzzz
1-479-404-11 $ & ADAPTOR, AC z
2003 A-1149-398-A $ & S BATTERY (J) (S) zzz
A-1149-399-A $ & S BATTERY (U) (S) zz z z zz
A-1149-400-A $ & S BATTERY (E/I/C) (S) zz zz zz z zz z zz z zz zz z zz z
2004 A-1149-416-A $ & L BATTERY (J) (S) zz
2005 1-770-019-61 & ADAPTOR, CONVERSION PLUG zzz z
2006 1-827-945-31 & CORD, POWER zzz z
2008 1-790-732-81 & CORD, POWER zzz
2011 1-827-946-31 & (English)...CORD, POWER zz z
2012 1-830-375-11 & (Russian)...POWER-SUPPLY CORD z
2014 1-830-518-21 & POWER-SUPPLY CORD SET zz
2015 8-954-048-93 & HEADPHONE MDR-Q22LP/S2 SET zzzz zzzz zzzzz zz z
2016 A-1144-728-A HEADSET(JP) zz
2018 1-823-947-61 & POWER-SUPPLY CORD zz
2019 1-824-910-41 & CORD, POWER zzz z
2020 1-827-481-31 & (English,German,French,Italian,Spanish)...POWER-SUPPLY CORD zz z z
2021 1-782-476-61 & CORD, POWER zzzzzzz
2022 1-829-810-31 & CORD, POWER zz
2023 1-829-237-21 & CORD, POWER zz z z z
- 2-669-981-01 & Insruction Manual (XP Professional, XP Home Edition) zzz
- 2-669-983-01 & MANUAL (1SEG), INSTRUCTION zz
- 1-816-429-12 & (English)...PHONE PLUG (GB) zz z
- 2-668-570-11 & WELCOME MAT, 3560(U)(D) zz z z zzz
- 2-654-119-01 & (English,German,French,Italian,Spanish)...REGULATORY BOOKLET ML (D)
- 2-654-130-01 & (Russian)...REGULATORY BOOKLET (RU) (D)
- 2-652-366-11 & (English,German,French,Italian,Spanish)...SPECS ML 3250 (E)(D)
- 2-652-366-21 & (Russian)...SPECS RU 3250 (E)(D)
- 2-654-113-01 & (English,German,French,Italian,Spanish)...TROUBLE GUIDE ML MAJOR (D)
- 2-654-113-11 & (English,Russian)...TROUBLE GUIDE ML MINOR (D)
- 2-668-290-11 & SAFETY/REGULATIONS 2(G)(D) zzzzzzzz z
- 2-668-290-21 & SAFETY/REGULATIONS 2(G)(D) zzzzzzz
- 2-668-294-11 & SPEC SHEET 3560(G)(D) zzz zz
- 2-668-294-21 & SPEC SHEET 3560(G)(D) zz
- 2-668-294-31 & SPEC SHEET 3560(G)(D) zzzzzzz
- 2-668-294-41 & SPEC SHEET 3560(G)(D) zz
- 2-668-287-11 & TROUBLESHOOTING GUIDE (G) (D) zzz zz
- 2-668-287-21 & TROUBLESHOOTING GUIDE (G) (D) zz
- 2-668-287-31 & TROUBLESHOOTING GUIDE (G) (D) zzzzzzz
- 2-668-287-41 & TROUBLESHOOTING GUIDE (G) (D) zz
- 2-670-310-21 & TROUBLESHOOTING (E)(D) z
- 2-670-810-01 & REGULATORY BOOKLET RU (D) z
A-1. Accessories A-1
(END)
TX51B/B TX91PS∗ TX91S∗ TX790P/L TX770P/B TX770P/T TX770P/W TX750P/B TX751P/B TX750FP TX2XP/B TX2XP/L TX2XRP/B TX2HP/W TX27GP/B TX27GP/T TX27GP/W TX27LP/B TX27TP/B TX26GP/W TX26SP/W TX26LP/W TX26TP/W TX28CP/L TX27CP/B TX27CP/L TX26C/B TX26C/T TX26C/W TX25C/W
JAM EU AO
• This parts list contains two different types of parts.
The first type is the parts that are common to all models.
The other type is the parts that are different depending on each model.
• ߎߩㇱຠ⴫ߪޔᯏ⒳౒ㅢߩㇱຠߣޔᯏ⒳ߦࠃߞߡ૶޿ಽߌ߇ᔅⷐߥㇱຠߦಽ߆ࠇߡ޿߹ߔޕ
[MA]
1
[MA]
1
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
1
[MA]
1
[MA]
3
AC Adaptor
2001
AC Adaptor
2002
Power Cord
2006
Power Cord
2019
Power Cord
2008
Power Cord
2021
Power Cord
2022
2018
Power-Supply Cord
2020
Power Cord
2011
Power-Supply Cord
2012
Power-Supply Cord
Power-Supply Cord Set
2014
Headphone
2015
Headset
2016
Battery Pack (S)
Battery Pack (L)
2003
2004
Plug 3P
Adaptor Conversion
2005
Power Cord
2023
[MA]
1
[MA]
2
[MA]
1
[MA]
1
[MA]
2
[MA]
2
[MA]
1
[MA]
2
[MA]
2
[MA]
2
[MA]
1
[MA]
1
[MA]
1
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
1
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
2
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3

CHAPTER 5.
OTHERS
5 - 1
VGN-TX51B/TX91PS/TX91S (J)
VGN-TX750FP/TX750P/TX751P/TX770P/TX790P (AM)
VGN-TX2HP/TX2XP/TX2XRP (EU)
VGN-TX25C/TX26C/TX26GP/TX26LP/TX26SP/TX26TP/TX27CP/TX27GP/TX27LP/TX27TP/TX28CP (AO)
Sony Confidential
[MBX-138 Board]
(Side A)
[LCD Unit]
(Front)
[Keyboard Unit]
(Rear)
[W-LAN Card intel]
[MODEM Card]
[Drive COMBO/RW/SM)
(Rear)
[HDD]
(Type To)
(Rear)
[MEMORY]
A,B
C
D
D
[HDD]
(Type Hi)
(Top)
(Rear)
D
D
D
D
D
[W-LAN Card Atheros]
D
D
D
[WAN Module]
(Top)
D
D
[WAN Module]
(Rear)
D
[MA]
3
[MA]
3
5-1. The Barcode Label
The hatched portion of the barcode label is used as the repair data.
ࡃ࡯ࠦ࡯࠼࡜ࡌ࡞ߩ✂ដߌㇱߪ㧘ୃℂ࠺࡯࠲ߣߒߡ૶↪޿ߚߒ߹ߔޕ
A : Part No.
B : Serial No.
C : Revision No.
D : Product Code
E : Maker Barcode
F : Global User ID (iLink)
G: Mac Address
: Barcode

5 - 2
VGN-TX51B/TX91PS/TX91S (J)
VGN-TX750FP/TX750P/TX751P/TX770P/TX790P (AM)
VGN-TX2HP/TX2XP/TX2XRP (EU)
VGN-TX25C/TX26C/TX26GP/TX26LP/TX26SP/TX26TP/TX27CP/TX27GP/TX27LP/TX27TP/TX28CP (AO)
Sony Confidential
Tray drawn-out state
3 If the power switch is to be turned on with the set in disassembled
state for checking the drive condition, be sure to turn the power
switch on with the tray drawn out.
2 If the power switch is to be turned on with the set in disassembled
state, be sure to load a dummy disc in the drive.
1 Do not turn the power switch on until the palmrest
and the keyboard are installed completely.
Keyboard
Palmrest
1ࡄ࡯ࡓ࡟ࠬ࠻߿ࠠ࡯ࡏ࡯࠼ࠍቢోߦขࠅઃߌࠆ߹ߢߪ
 㔚Ḯࠍ౉ࠇߥ޿ߢߊߛߐ޿ޕ
2
ಽ⸃ߒߚ⁁ᘒߢ㔚Ḯࠍ౉ࠇࠆᔅⷐ߇޽ࠆ႐วߦߪᔅߕ ࠳ࡒ࡯ߩ
 ࠺ࠖࠬࠢࠍ࠼࡜ࠗࡉߦ࠮࠶࠻ߒߡ߅޿ߡߊߛߐ޿ޕ
3 ಽ⸃ߒߚ⁁ᘒߢ㔚Ḯࠍ౉ࠇ ࠼࡜ࠗࡉߩ⁁ᘒࠍ⏕⹺ߔࠆᔅⷐ߇
 ޽ࠆ႐วߦߪᔅߕ ࠻࡟ࠗࠍᒁ߈಴ߒߚ⁁ᘒߢ㔚Ḯࠍ౉ࠇߡ
 ߊߛߐ޿ޕ
5-2. Precautions for Handling the Drive
In performing a repair, observe the following precautions.
ୃℂߩ㓙ߦߪએߩᵈᗧ㗄ࠍ෩቞ߒߡߊߛߐ޿ޕ
࠻࡟ࠗ߇ᒁ߈಴ߐࠇߚ⁁ᘒ

5 - 3
VGN-TX51B/TX91PS/TX91S (J)
VGN-TX750FP/TX750P/TX751P/TX770P/TX790P (AM)
VGN-TX2HP/TX2XP/TX2XRP (EU)
VGN-TX25C/TX26C/TX26GP/TX26LP/TX26SP/TX26TP/TX27CP/TX27GP/TX27LP/TX27TP/TX28CP (AO)
Sony Confidential
(END)
5-3. Note for WWAN Board Replacement
㪌㪄㪊㪅㩷㪮㪮㪘㪥㩷ၮ᧼឵ᤨ䈱ᵈᗧ㩷
㪮㪿㪼㫅㩷㫉㪼㫇㫃㪸㪺㫀㫅㪾㩷㫋㪿㪼㩷㪮㪮㪘㪥㩷㪙㫆㪸㫉㪻㩷㩿㪩㪼㪽㪅㩷㪌㪌㪍㩷㩷㪘㪄㪈㪈㪌㪊㪄㪎㪎㪋㪄㪘㩷㪮㪮㪘㪥㩷㪬㪥㪠㪫㩷㩿㪄㪊㪈㪀㩷㩿㪪㪀㪀㪃㩷㪺㪿㪸㫅㪾㪼㩷㫋㪿㪼㩷㪹㪸㫉㪺㫆㪻㪼㩷㫃㪸㪹㪼㫃㩷㫆㫅㩷㫋㪿㪼㩷㪹㫆㫋㫋㫆㫄㪅
㪮㪮㪘㪥㩷ၮ᧼㩷㩿㪩㪼㪽㪅㩷㪌㪌㪍㩷㩷㪘㪄㪈㪈㪌㪊㪄㪎㪎㪋㪄㪘㩷㪮㪮㪘㪥㩷㪬㪥㪠㪫㩷㩿㪄㪊㪈㪀㩷㩿㪪㪀㪀㩷䉕឵䈚䈢㓙䈮䈲䇮䊗䊃䊛䈱䊋䊷䉮䊷䊄䊤䊔䊦䈱⾍䉍ᦧ䈋૞ᬺ䉕ⴕ䈦䈩䈒䈣䈘䈇䇯
㽲 㪧㪼㪼㫃㩷㫆㪽㪽㩷㫋㪿㪼㩷㪹㪸㫉㪺㫆㪻㪼㩷㫃㪸㪹㪼㫃㩷㫎㪿㫀㪺㪿㩷㫀㫊㩷㪸㫋㫋㪸㪺㪿㪼㪻㩷㫋㫆㩷㫋㪿㪼㩷㪹㫆㫋㫋㫆㫄㪅㩷㩿㪩㪼㪽㪼㫉㩷㫋㫆㩷㫋㪿㪼㩷㪽㫀㪾㫌㫉㪼㩷㪹㪼㫃㫆㫎㪅㪀
㽲 䊗䊃䊛䈮⾍䉌䉏䈩䈇䉎䊋䊷䉮䊷䊄䊤䊔䊦䉕䈲䈏䈚䉁䈜䇯䋨࿑ෳᾖ䋩
㽳 㪘㫋㫋㪸㪺㪿㩷㫋㪿㪼㩷㪹㪸㫉㪺㫆㪻㪼㩷㫃㪸㪹㪼㫃㩷㫎㪿㫀㪺㪿㩷㫀㫊㩷㫀㫅㪺㫃㫌㪻㪼㪻㩷㫎㫀㫋㪿㩷㫋㪿㪼㩷㪮㪮㪘㪥㩷㪙㫆㪸㫉㪻㩷
㫋㫆㩷㫋㪿㪼㩷㫇㫆㫊㫀㫋㫀㫆㫅㩷㫎㪿㪼㫉㪼㩷㫐㫆㫌㩷㫇㪼㪼㫃㪼㪻㩷㫆㪽㪽㩷㫋㪿㪼㩷㫃㪸㪹㪼㫃㩷㫀㫅㩷㫋㪿㪼㩷㫊㫋㪼㫇㩷㩿㪈㪀㪅
㽳 㪮㪮㪘㪥ၮ᧼䈮ห󰩠䈘䉏䈩䈇䉎䊋䊷䉮䊷䊄䊤䊔䊦䉕㽲䈪䈲䈏䈚䈢૏⟎䈮⾍䈦䈩䈒䈣䈘䈇䇯
㪁㪫㪿㪼㫉㪼㩷㫀㫊㩷㫅㫆㩷㫇㫉㫆㪹㫃㪼㫄㩷㫋㪿㫆㫌㪾㪿㩷㫋㪿㪼㩷㪠㪚㪚㪠㪛㩷㫀㫊㩷㫅㫆㫋㩷㫇㫉㫀㫅㫋㪼㪻㩷㫆㫅㩷
㩷㩷㫋㪿㪼㩷㫊㫌㪹㫊㫋㫀㫋㫌㫋㪼㪻㩷㪹㪸㫉㪺㫆㪻㪼㩷㫃㪸㪹㪼㫃㪅㩷
㪁⾍䉍ᦧ䈋䈢䊋䊷䉮䊷䊄䊤䊔䊦䈮䈲㪠㪚㪚㪠㪛䈏ශ೚䈘䉏䈩䈇䉁䈞䉖䈏໧㗴䈅䉍䉁䈞䉖䇯
IMFI: xxxxxxxxxxxxxxx
ICCID: xxxxxxxxxxxxxxxxxxxx
IMFI: xxxxxxxxxxxxxxxx
ICCID: xxxxxxxxxxxxxxxxxxxx
[MA]
3
