Sony VAIO VPCEF Series User manual

Sony Confidential
VPCEF Series
SERVICE MANUAL
Ver 3-2010I
9-852-896-03
PERSONAL COMPUTER
Revision History
• ᧄᯏߩ઀᭽߅ࠃ߮ᄖⷰߪޔᡷ⦟ߩߚ߼๔ߥߊ
ᄌᦝߔࠆߎߣ߇޽ࠅ߹ߔ߇ޔߏᛚߊߛߐ޿ޕ
zDesign and specifications are subject to
change without notice.
Area Model Lineup
VPCEF22FX/BI
US/Canadian VPCEF25FX/BI
American VPCEF34FX/BI
VPCEF37FX/BI
Latin VPCEF21FD/BI
VPCEF34FD/BI
VPCEF2E1E/WI
VPCEF2E1R/WI
VPCEF2S1E/BI
European AEP/UK VPCEF2S1R/BI
VPCEF3E1E/WI
VPCEF3S1E/BI
VPCEF3S1E/WI

- 2 -
VPCEF Series (9-852-896-XX)
Sony Confidential
Information in this document is subject to
change without notice.
Sony, VAIO and CLIE are trademarks or regis-
tered trademarks of Sony. Microsoft, Windows,
Windows Media, Outlook, Bookshelf and other
Microsoft products are trademarks or registered
trademarks of Microsoft Corporation in the
United States and other countries. The word
Bluetooth and the Bluetooth logo are trademarks
of Bluetooth SIG, Inc. AMD, the AMD logo, other
AMD product names and combinations thereof
are trademarks of Advanced Micro Devices, Inc.
Intel Inside logo, Pentium, Celeron and Core are
trademarks or registered trademarks of Intel Cor-
poration. Transmeta, the Transmeta logo, Crusoe
Processor, the Crusoe logo and combinations
thereof are trademarks of Transmeta Corporation
in the USA and other countries. Graffiti, Hot-
Sync, PalmModem, and Palm OS are registered
trademarks, and the Hotsync logo and Palm are
trademarks of Palm, Inc. or its subsidiaries. (M)
and Motrola are trademarks of Motrora, Inc. Other
Motrola products and services with (R) mark like
Dragonball are the trademarks of Motrola, Inc.
All other names of systems, products and services
in this manual are trademarks or registered trade-
marks of their respective owners. In this manual,
the (TM) or (R) mark are not specified.
Caution Markings for Lithium/Ion Battery - The
following or similar texts shall be provided on
battery pack of equipment or in both the operating
and the service instructions.
CAUTION: Danger of explosion if battery is
incorrectly replaced. Replace only with the same
or equivalent type recommended by the manu-
facturer. Discard used batteries according to the
manufacturer’s instructions.
CAUTION: The battery pack used in this device
may present a fire or chemical burn hazard if mis-
treated. Do not disassemble, heat above 60°C
(140°F) or incinerate. Dispose of used battery
promptly. Keep away from children.
CAUTION: Changing the back up battery.
Overcharging, short circuiting, reverse charg-
ing, multilation or incineration of the cells must
be avoided to prevent one or more of the fol-
lowing occurrences; release of toxic materials,
release of hydrogen and/or oxygen gas, rise in
surface temperature.
If a cell has leaked or vented, it should be
replaced immediately while avoiding to touch
it without any protection.
Service and Inspection Precautions
1. Obey precautionary markings and
instructions
Labels and stamps on the cabinet, chassis, and
components identify areas requiring special pre-
cautions. Be sure to observe these precautions,
as well as all precautions listed in the operating
manual and other associated documents.
2. Use designated parts only
The set’s components possess important safety
characteristics, such as noncombustibility and
the ability to tolerate large voltages. Be sure that
replacement parts possess the same safety charac-
teristics as the originals. Also remember that the
mark, which appears in circuit diagrams and
parts lists, denotes components that have particu-
larly important safety functions; be extra sure to
use only the designated components.
3. Always follow the original design
when mounting parts and routing
wires
The original layout includes various safety fea-
tures, such as inclusion of insulating materials
(tubes and tape) and the mounting of parts above
the printer board. In addition, internal wiring has
been routed and clamped so as to keep it away
from hot or high-voltage parts. When mounting
parts or routing wires, therefore, be sure to du-
plicate the original layout.
4. Inspect after completing service
After servicing, inspect to make sure that all
screws, components, and wiring have been
returned to their original condition. Also check
the area around the repair location to ensure that
repair work has caused no damage, and confirm
safety.
5. When replacing chip components...
Never reuse components. Also remember that
the negative side of tantalum capacitors is easily
damaged by heat.
6. When handling flexible print
boards...
The temperature of the soldering-iron tip
should be about 270°C.
z
z
z
z
z
Do not apply the tip more than three times to
the same pattern.
Handle patterns with care; never apply force.
Caution: Remember that hard disk drives are
easily damaged by vibration. Always handle
with care.
ATTETION AU COMPOSANT AYANT
RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFÉS PAR UNE
MARQUE SUR LES DIAGRAMMES
SCHÉMATIQUES ET LA LISTE DES PIÈCES
SONT CRITIQUES POUR LA SÉCURITÉ DE
FONCTIONNEMENT. NE REMPLACER CES
COMPOSANTS QUE PAR DES PIÈSES SONY
DONT LES NUMÉROS SONT DONNÉSDANS
CE MANUEL OU DANS LES SUPPÉMENTS
PUBLIÉS PAR SONY.
The components identified by mark contain
confidential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.

- 3 -
VPCEF Series (9-852-896-XX)
Sony Confidential
TABLE OF CONTENTS

SPECIFICATIONS are listed on Page 3-1 of
"CHAPTER 3. EXPLODED VIEWS AND PARTS LIST".

History of the changes is shown as the"Revision
History" at the end of this data.
䊶㪪㪧㪜㪚㪠㪝㪠㪚㪘㪫㪠㪦㪥㪪䈲䇮㩹㪚㪟㪘㪧㪫㪜㪩㩷㪊㪅㩷㪜㪯㪧㪣㪦㪛㪜㪛㩷㪭㪠㪜㪮㪪㩷
㪘㪥㪛㩷㪧㪘㪩㪫㪪㩷㪣㪠㪪㪫㩹䈱㪊㪄㪈䊕䊷䉳䈮ឝタ䈘䉏䈩䈇䉁䈜䇯
䊶ᄌᦝጁᱧ䈲䇮㵰㩷㪩㪼㫍㫀㫊㫀㫆㫅㩷㪟㫀㫊㫋㫆㫉㫐㩷㵱㩷䈫䈚䈩䇮ᧄ䊂䊷䉺ᧃ䈮
⸥タ䈚䈩䈅䉍䉁䈜䇯
Section Title Page
CHAPTER 1. BLOCK DIAGRAM .............................................................................................. 1-1
(to 1-1)
CHAPTER 2. FRAME HARNESS DIAGRAM ................................................................. 2-1
(to 2-1)
CHAPTER 3. EXPLODED VIEWS AND PARTS LIST
Note ............................................................................................................................................................ 3-2
Main Section
MS-1 ...................................................................................................................................................... 3-3
LCD
L-1 .......................................................................................................................................................... 3-4
Accessories
A-1 ......................................................................................................................................................... 3-5
(to 3-5)
CHAPTER 4. OTHERS
4-1. Replacing the CPU .............................................................................................................................. 4-1
(to 4-1)

1 - 1
CHAPTER 1.
BLOCK DIAGRAM
VPCEF Series (9-852-896-XX)
Sony Confidential
(END)
#1
#2
#0
#1
#2
#3
#4
#5
GLAN
Realtek RTL8111DL-VB-GR
RJ45
WLAN Module
802.11bgn
External Gfx Model
External Gfx Model
Internal Gfx Model
AMD S1G4 CPU
Champlain
638 PIN (uFCPGA)
Hyper Transport
LINK0
16x16
DDRIII 1333MT/S
UNBUFFERED
DDR3
SODIMM-A
DDRIII 1333MT/S
UNBUFFERED
DDR3
SODIMM-A
HDMI
R/G/B
LVDS
HDMI
R/G/B
LVDS
HDMI 1.3
CRT
LCD
ATI
M92 XTX
Madison LP
962 PIN (BGA)
29mm x 29mm
M92
DDR3 128MB*4pcs
Madison
DDR3 128MB*8pcs
RS880M
528 PIN (BGA)
21mm x 21mm
A Link
PCIE(X4)
PCIE-Gen2
SB820M
PCIE-Gen1
External Gfx ModelInternal Gfx Model
605 Pin BGA
21mm x 21mm
528 Pin BGA
21mm x 21mm
Azalia Link
Realtek ALC269Q-VB2-GR
MIC. Jack Audio Jack INT.SPKR. Digital MIC
External Gfx Model
Internal Gfx Model
Card Reader
Realtek RTS5186
MS DOU
SD HC
USB Slot *4
Camera
Blue Tooth
USB 1.1/2.0
Card Reader
RTK RTS5186
MS DOU
SD HC
USB Slot *3
Camera
USB 1.1/2.0
SATA 1 SATA 0
SATA ODD *1 SATA HDD *1
3.3V LPC,33MHZ
PCU
NPCE781
TOUCH PAD
T/P SWITCH
INT.K/B SPI
BIOS
LED
Power/Speep
NUM/CAPS/SCRL
Wireless
HDD
MS/SD
Charge
Button/Switch
POWER
ASSIST
Wireless

CHAPTER 2.
FRAME HARNESS DIAGRAM
2 - 1
VPCEF Series (9-852-896-XX)
Sony Confidential
1
2
CABLE FFC
MB-TP
CABLE FFC MB-USB
CABLE FPC MB-BTNB
BATTERY PACK
Bottom
INVERTER UNIT
LCD CABLE ASSY
(L) (R)
SPEAKER MODULE ASSY
LCD
UNIT
CAMERA
UNIT
KEY BOARD UNIT
Front
MEMORY MEMORY
Bottom Bottom
USB/B
BOARD
Side A
AUX
GRY
BLK
MAIN
ODD
BATTERY
TOUCH PAD
Top
LEFT
BUTTON
RIGHT
BUTTON
MEMORY STICK
SD CARD
BT MODULE
BT ANTENNA
BT Model
SD WIRELESS
OFF ON
R Side
BUTTON/B
BOARD
Side A
ANTENNA
WLAN
ASSY
Top
Front
ASSIST
MBX
BOARD
Side A
HDD
WIRELESS
LAN MODULE
Bottom
L Side
19.5V
CPU
THERMAL
MODULE
PRO
Duo
DC CABLE ASSY
(END)
From board to connector (direct connection)
Harness (connector at both end)
Harness (soldered at one end)
ၮ᧼߆ࠄࠦࡀࠢ࠲߳㧔࠳ࠗ࡟ࠢ࠻ធ⛯㧕
ࡂ࡯ࡀࠬ㧔┵߇ࠦࡀࠢ࠲ઃ߈㧕
ࡂ࡯ࡀࠬ㧔৻ᣇ߇ඨ↰ઃߌ㧕

CHAPTER 3.
EXPLODED VIEWS AND PARTS LIST
3 - 1
VPCEF Series (9-852-896-XX)
Sony Confidential
• ಽ⸃࿑䈫ㇱຠ⴫䈲䇮䊑䊨䉾䉪䈗䈫䈮ಽ䈎䉏䈩䈇䉁䈜䇯
㵘ᯏ⒳䈮䉋䈦䈩䉶䉪䉲䊢䊮䈏⇣䈭䉍䉁䈜䈱䈪䇮⹦⚦䈲৻ⷩ⴫䉕ෳᾖ䈚䈩䈒䈣䈘䈇䇯
•The exploded views and parts list are compiled by blocks.
The sections are different depending on the model.
Please refer to list of contents shown.
• Double-click on the paper clip mark in the Spec column to open the specifications list.
䊶㩷㪪㫇㪼㪺ᰣ䈱䉪䊥䉾䊒䊙䊷䉪䉕䉻䊑䊦䉪䊥䉾䉪䈜䉎䈫䇮䉴䊕䉾䉪⴫䈏㐿䈐䉁䈜䇯
䊶㩷䉴䊕䉾䉪⴫䉕㐿䈒䈢䉄䈮䈲㩷㪤㫀㪺㫉㫆㫊㫆㪽㫋㩷㪦㪽㪽㫀㪺㪼㩷㪜㫏㪺㪼㫃㩷䉁䈢䈲㩷㪜㫏㪺㪼㫃㩷䊎䊠䊷䊪䊷䈏ᔅⷐ䈮䈭䉍䉁䈜䇯
• To open the specifications list, Microsoft office Excel or Excel viewer is required.
EF25FX/BI MS-1 L-1 A-1
EF22FX/BI MS-1 L-1 A-1
AM
EF21FD/BI MS-1 L-1 A-1
EF37FX/BI MS-1 L-1 A-1
EF34FX/BI MS-1 L-1 A-1
EF34FD/BI MS-1 L-1 A-1
EF2S1E/BI MS-1 L-1 A-1
EF2E1E/WI MS-1 L-1 A-1
EF2S1R/BI MS-1 L-1 A-1
EU EF2E1R/WI MS-1 L-1 A-1
EF3S1E/BI MS-1 L-1 A-1
EF3S1E/WI MS-1 L-1 A-1
EF3E1E/WI MS-1 L-1 A-1
Main Section LCD Accessories Spec
Section Page
Note ................................................................................... 3-2
Main Section
MS-1 ......................................................................... 3-3
LCD
L-1 ............................................................................ 3-4
Accessories
A-1 ............................................................................ 3-5
LCD
Main Section

3 - 2
VPCEF Series (9-852-896-XX)
Sony Confidential
Note
Les composants identifiés par une
marque ! sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by mark
! or dotted line with mark ! are
critical for safety. Replace only with
part number specified.
If there is the Remarks column in the parts list,
the features of applicable models are indicated in it
for the parts that are different depending on each model.
For the abbreviations used in the remarks column, please refer to the <table 1>.
䊶ㇱຠ⴫䈮㪩㪼㫄㪸㫉㫂㫊ᰣ䈏䈅䉎႐ว㪃㩷૶䈇ಽ䈔䈏↢䈛䉎ㇱຠ䈮䈧䈇䈩㪃㩷್೎䈱⋡቟䈫䈭䉎ኻᔕ䊝䊂䊦䈱․ᓽ䉕
␜䈚䈩䈇䉁䈜䇯
⸥ㅀ䈱⋭⇛ᣇᴺ䈮䈧䈇䈩䈲㪓㫋㪸㪹㫃㪼㩷㪈㪕䉕ෳᾖ䈒䈣䈘䈇䇯
<table 1>
CameraCamera
SSDFlash Memory
TPMSecurity Chip
FP
Finger Print Sensor
1seg1seg Tuner
WLANWireless LAN
WANWireless WAN
FelicaFelica
Short-NameFull-Name
11
Bluetooth BT
If "No-" is described on the left side of the Short-Name, it means 'not equipped'.
Example: "No-BT" "No-Felica” etc.
When several descriptions are listed, each description is separated with “, (comma)" or " or". "Comma" means plus.
Example.1: The parts for the model equipped with BT and Felica and WLAN 㸢BT, Felica, WLAN
Example.2: The parts for the model equipped with BT or Felica 㸢BT or Felica
If the color is in the remarks column, it indicates the color of parts itself.
䊶䇸ή䈚䇹䉕⴫󱂜䈜䉎႐ว䈮䈲㪃㩷㪪㪿㫆㫉㫋㪄㪥㪸㫄㪼䈱Ꮐ䈮䇸㪥㫆㪄䇹䈫䈧䈔䉁䈜䇯㩷
଀㪀䇸㪥㫆㪄㪙㪫䇹䇸㪥㫆㪄㪝㪼㫃㫀㪺㪸䇹䈭䈬
䊶
ᵈ⸥䉕ⶄᢙ⸥タ䈜䉎㓙䈮䈲䇸㪃㩿䉦䊮䊙㪀䇹෶䈲䇸㫆㫉䇹䈪඙ಾ䉍䉁䈜䇯䇸㪃䋨䉦䊮䊙䋩䇹䈲䊒䊤䉴䈫䈇䈉ᗧ๧䈫䈚䈩૶䈇䉁䈜䇯
଀㪈㪀㩷㪙㪫䈫㪝㪼㫃㫀㪺㪸䈫㪮㪣㪘㪥䈏៞タ䈘䉏䈢䊝䊂䊦䈮䈧䈒ㇱຠ㩷㸢㩷㪙㪫㪃㩷㪝㪼㫃㫀㪺㪸㪃㩷㪮㪣㪘㪥㩷
଀㪉㪀㩷㪙㪫៞タ䊝䊂䊦෶䈲㪝㪼㫃㫀㪺㪸៞タ䊝䊂䊦䈮䈧䈒ㇱຠ㩷
㸢㩷㪙㪫㩷㫆㫉㩷㪝㪼㫃㫀㪺㪸
䊶⦡⴫⸥䈱႐ว㪃㩷⹥ᒰ䈱ㇱຠ⥄૕䈱⦡䉕␜䈚䉁䈜䇯
Basically, the parts marked “” should be used for service.
The parts marked “” in the parts list are substitution parts.
If the part marked “” is not available, you can order the parts marked “”,
but it may not be stocked.
㩷㩸㩷ශ䈱ㇱຠ㪃㩷䉁䈢䈲㩷㩸㩷ශઃ䈐䈱ὐ✢䈪࿐䉁䉏䈢ㇱຠ
䈲㪃቟ోᕈ䉕⛽ᜬ䈜䉎䈢䉄䈮㊀ⷐ䈭ㇱຠ䈪䈜䇯ᓥ䈦䈩
឵ᤨ䈲㪃㩷ᔅ䈝ᜰቯ䈱ㇱຠ䉕૶↪䈚䈩䈒䈣䈘䈇䇯

Parts List is attached on the upper right portion of each EXPLODED VIEW.

Items marked “
*
“ are not stocked since they are seldom required for routine
service. Some delay should be anticipated when ordering these items.

The parts marked “ $ “ are the Reuse Parts.

The parts marked with "&" indicates specific parts handling for Japan region.
˴Disregard "&" marking for other than Japan region.

Color after discription in [ ] shows color variation name of the main body.

The model that is accompanied asterisk (∗) is the CTO model.

Description of [***MBx2], [***MB], [***GBx2], [***GB]indicates the following.
***MB/***GB: size of the part
x2: installed quantity at original production

Be sure to use the parts marked with x/sx together with the parts with the
same number.

When replacing the HDD of RAID setting, please exchange to the same HDD
that was installed.

ㇱຠ⴫䈲㪃㩷ฦಽ⸃࿑䈱ฝㇱ䈮󰵾ઃ䈘䉏䈩䈇䉁䈜䇯

*ශ䈱ㇱຠ䈲Ᏹ஻࿷ᐶ䈚䈩䈍䉍䉁䈞䉖䇯

ㇱຠฬ⒓䈱೨䈮㩻ශ䈱䈧䈇䈢ㇱຠ䈲㪃㩷㪩㪼㫌㫊㪼㩷㪧㪸㫉㫋㫊䈪䈜䇯

ㇱຠฬ⒓䈱೨䈮㩽ශ䈱䈧䈇䈢ㇱຠ䈲㪃㩷䈍ቴ᭽䈪䉅឵น⢻䈭㪚㫌㫊㫋㫆㫄㪼㫉㩷㪩㪼㫇㫃㪸㪺㪸㪹㫃㪼㩷㪧㪸㫉㫋㫊
㩿㪚㪩㪧㪀䈪䈅䉍㪃㩷⽼ᄁน⢻䈪䈜䇯
․䈮㪓㩽㪕ශ䈱䈧䈇䈢ㇱຠ䈲㪃㩷૶䈇ಽ䈔䈏ᔅⷐ䈭ㇱຠ
䈪䈜䈱䈪㪃㩷ᔅ䈝ಽ⸃࿑䈪ኻ⽎ㇱຠ䉕
䈗⏕⹺䈒䈣䈘䈇䇯

ㇱຠฬ⒓䈱ᓟ䈮㪲㩷㪴䈪⦡䈏␜䈘䉏䈩䈇䉎႐ว㪃㩷㪙㫆㪻㫐䈱䉦䊤䊷䊋䊥䉣䊷䉲䊢䊮ฬ⒓䉕⴫䉒䈚䈩
䈇䉁䈜䇯

ᯏ⒳ฬ䈮䋨㪁䋩䈏䈧䈒䉅䈱䈲㪚㪫㪦䊝䊂䊦䈪䈜䇯

ㇱຠฬ䈱㪲㪁㪁㪁㪤㪙x㪉㪴㪃㩷㪲㪁㪁㪁㪤㪙㪴㪃㩷㪲㪁㪁㪁㪞㪙x㪉㪴㪃㩷㪲㪁㪁㪁㪞㪙㪴㩷╬䇱䈲એ䉕⴫䉒䈚䈩䈇䉁䈜䇯
㪁㪁㪁㪤㪙㪆㪁㪁㪁㪞㪙㪑㩷䈖䈱ㇱຠ䈱ኈ㊂
㵘㵘㩷㩷㩷㩷㩷㩷㩷㩷㩷㩷㩷㩷㩷㩷㩷x㪉㪑㩷಴⩄ᤨ䈮៞タ䈘䉏䈩䈇䉎ຬᢙ

x/sx䈮䈭䈦䈩䈇䉎ㇱຠ䈲㪃㩷ห䈛ᢙሼ䈬䈉䈚䈪ᔅ䈝৻✜䈮૶↪䈚䈩䈒䈣䈘䈇䇯

㪩㪘㪠㪛⸳ቯ䈱㪟㪛㪛䉕឵䈜䉎㓙䈲㪃㩷៞タ䈘䉏䈩䈇䈢㪟㪛㪛䈫ห䈛䉅䈱䈮឵䈚䈩䈒䈣䈘䈇䇯
ㇱຠ⴫㵰㵱䈱䈧䈇䈢ㇱຠ䈲㪃㩷ઍᦧㇱຠ䈪䈜䇯ၮᧄ䈲ශ
䈱ㇱຠ䉕૶↪䈚䈩䈒䈣䈘䈇䇯
ශ䈱ㇱຠ䈏ή䈇႐ว䈲㪃㩷ශ䈱ㇱຠ䉕䉥䊷䉻䊷䈜䉎䈖䈫䉅
น⢻䈪䈜䈏㪃㩷࿷ᐶ䈘䉏䈩䈇䈭䈇႐ว䈏䈅䉍䉁䈜䇯
The components identified by mark contain
confidential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
㩷㩷㩷ශ䈱ㇱຠ䈮䈲䋬⒁ኒᖱႎ䈏฽䉁䉏䈩䈇䉁䈜䇯㩷ୃℂ
䈱㓙䈲䋬ᜰ␜䈮ᓥ䈦䈢ኻᔕ䉕ⴕ䈭䈦䈩䈒䈣䈘䈇䇯㩷

3 - 3
VPCEF Series (9-852-896-XX)
Sony Confidential
BT Model
BT Model
Internal Gfx Model
External Gfx Model
BT
Model No-BT
Model
2
26
B2
B2
18
74
B124
28
63
B1
21
20
16
62
27
15
B2
B1
B1
57
B1
25
73
72
57
71
70
B1 45
17
B1
3
1
67
10
31
9
32
B1
B2
B1
B2
B2
6 (1)
5
5
52
(2)
52
(2)
52
(2)
48
B2
B2
B2
B2
23
47
48
47
47
47
22 B5
38
7
41
B7
B2
56
40
51
B5
B5
B5 B4
B4
B5
50
50
36
B10
B1
B10
39
35
8
37
L-1
A
G
D
A
F
J
B
E
L-1
H
B
G
B
F
A
H
B
IDC
G
G
G
H
L-1
P
L-1
Q
L-1
O
E
J
E
E
E
C
D
C
I
D
C
11
B11
69
61
B1
MS-1. Main Section Parts List
• Double-click on the paper clip mark to open the parts list.
䊶㩷䉪䊥䉾䊒䊙䊷䉪䉕䉻䊑䊦䉪䊥䉾䉪䈜䉎䈫䇮ㇱຠ⴫䈏㐿䈐䉁䈜䇯
•To open the parts list, Microsoft office Excel or Excel viewer is required.
䊶ㇱຠ⴫䉕㐿䈒䈢䉄䈮䈲㩷㪤㫀㪺㫉㫆㫊㫆㪽㫋㩷㪦㪽㪽㫀㪺㪼㩷㪜㫏㪺㪼㫃㩷䉁䈢䈲㩷㪜㫏㪺㪼㫃㩷䊎䊠䊷䊪䊷䈏ᔅⷐ䈮䈭䉍䉁䈜䇯
1) When change the CPU (Ref. No. 6), refer to " Replacing
the CPU " in CHAPTER 4.
1) 㪚㪧㪬㩷㩿㪩㪼㪽㪅㩷㪥㫆㪅㩷㪍㪀㩷䉕឵䈜䉎㓙䈮䈲㪃㩷㪚㪟㪘㪧㪫㪜㪩㩷㪋㩷䈱
 䇸㪩㪼㫇㫃㪸㪺㫀㫅㪾㩷㫋㪿㪼㩷㪚㪧㪬䇹䉕䈗ෳᾖ䈒䈣䈘䈇䇯
2) When heat sink is removed from CPU, clean off the
thermal grease and put the Ref. No. 52.
2) 䊍䊷䊃䉲䊮䉪䉕㪚㪧㪬䈎䉌ᄖ䈚䈢㓙䈲㪃㩷䉫䊥䉴䉕᜞ข䉍㪃㩷㪩㪼㪽㪅㩷
 㪥㫆㪅㩷㪌㪉㩷䉕ႣᏓ䈚䈩䈒䈣䈘䈇䇯

3 - 4
VPCEF Series (9-852-896-XX)
Sony Confidential
108
120
114
B8
113
B8
B6
109
101
B6
B1
110
B1
B1
102
106
111
115
112
105
104
B1
B9
B9
B6
B6
B1
B1
MS-1
O
F
MS-1
P
MS-1
QMS-1
I
MS-1
H
N
N
F
L-1. LCD Parts List
• Double-click on the paper clip mark to open the parts list.
䊶㩷䉪䊥䉾䊒䊙䊷䉪䉕䉻䊑䊦䉪䊥䉾䉪䈜䉎䈫䇮ㇱຠ⴫䈏㐿䈐䉁䈜䇯
•To open the parts list, Microsoft office Excel or Excel
viewer is required.
䊶ㇱຠ⴫䉕㐿䈒䈢䉄䈮䈲㩷㪤㫀㪺㫉㫆㫊㫆㪽㫋㩷㪦㪽㪽㫀㪺㪼㩷㪜㫏㪺㪼㫃㩷䉁䈢䈲㩷㪜㫏㪺㪼㫃㩷
 䊎䊠䊷䊪䊷䈏ᔅⷐ䈮䈭䉍䉁䈜䇯

3 - 5
VPCEF Series (9-852-896-XX)
Sony Confidential
A-1. Accessories Parts List
• Double-click on the paper clip mark to open the parts list.
䊶㩷䉪䊥䉾䊒䊙䊷䉪䉕䉻䊑䊦䉪䊥䉾䉪䈜䉎䈫䇮ㇱຠ⴫䈏㐿䈐䉁䈜䇯
•To open the parts list, Microsoft office Excel or Excel viewer is required.
䊶ㇱຠ⴫䉕㐿䈒䈢䉄䈮䈲㩷㪤㫀㪺㫉㫆㫊㫆㪽㫋㩷㪦㪽㪽㫀㪺㪼㩷㪜㫏㪺㪼㫃㩷䉁䈢䈲㩷㪜㫏㪺㪼㫃㩷䊎䊠䊷䊪䊷䈏ᔅⷐ䈮䈭䉍䉁䈜䇯
AC Adaptor
2002
Power Cord
2008
Power Cord Set
2013
Power Cord Set
2014
Power Cord Set
2015
AC Power Cord
2012
Power-Supply Cord
2017
Power-Supply Cord
2018
Battery (VGP-BPS22)
2003
Power Supply Cord Set
2020
(END)

CHAPTER 4.
OTHERS
4 - 1
VPCEF Series (9-852-896-XX)
Sony Confidential
(END)
4-1. Replacing the CPU
1. How to remove the CPU
2. How to install the CPU
lock position
unlock position
unlock position
lock position
1 Rotate the lock with a flat-blade screwdriver toward
the unlock position shown in the figure.
2 Remove up the CPU.
2
CPU
1 Position the mark on the CPU to the mark on the CPU
socket and put in all pins to the holes on the CPU socket.
2 Pressing two corners marked with in the figure,
rotate the lock with a flat-blade screwdriver toward
the lock position.
mark
mark
Note: Lock the CPU properly, or operation
becomes unstable.
CPU socket
CPU socket
1
CPU
2
1

- 12 -
9-852-896-03
VPCEF Series (AM/EU)
Sony Corporation
English / Japanese
2010I2700-1
© 2010 Sony Corporation
Published by Sony Corporation VAIO & Mobile Business Group CS & Quality Div. VAIO Global CS Dept.
This manual and the constituent data may not be
replicated, copied nor reprinted in whole or in part
without prior written authorization of Sony Corporation.
ᧄࡑ࠾ࡘࠕ࡞ߩ৻ㇱ㧘߹ߚߪోㇱߦߟ޿ߡ㧘ήᢿߢ
࠺࡯࠲ߩⶄ⵾㧘ⶄ౮㧘ォタߔࠆߎߣࠍ⑌ߓ߹ߔޕ

VPCEF Series (9-852-896-XX)
[Sony Confidential]
Revision History
Suffix Ver. Date Contents QM No.
-01 Ver. 1 2010.05.20 First Edition -
-02 Ver. 2 2010.07.01 [MA] Front Page, Page 1-1, Page 3-1, Page 3-3, Page 3-4, Page 3-5 -
[ADD] [CHG] Page 3-3, Page 3-5 -
-03 Ver. 3 2010.09.17 [MA] Front Page, Page 3-1, Page 3-3, Page 3-4, Page 3-5 -
[ADD] [CHG] [DEL] Page 3-3, Page 3-4 -
<Remarks>
426
