Sony VGN-TT190NIB - VAIO TT Series User manual

VGN-TT190NIB
VAIO® TT Series Notebook
A new grade in mobility
MOBILE PC PERFORMANCE
Enjoy the performance of Intel ® Centrino ® processor technology with
an Intel ® Core ™2 Duo SU9300 processor (1.20GHz ) with 3MB of L2
cache and 2GB of pre-installed system memory.
The VAIO® TT series notebook comes pre- installed with Genuine
Microsoft ® Windows Vista® Business 32-bit with SP1.
11.1" display with XBRITE-DuraView™ technology with LED backlight for
a brighter LCD with 100% color saturation and scratch-resistant
coating.
ULTRAPORTABLE AND ELEGANT DESIGN
Thin and lightweight, weighing in at only 2.87 lbs .
The softened matte black tone has a suave look and feel to it that
suggests urbane sophistication and grace. Deep black in color, the
subtle textured finish plays well with light and highlights the notebook ’s
clean lines and curved architecture.
Top to bottom carbon -fiber casing delivers an elegant look and
enhanced durability.
Active Noise Cancelling technology and supplied headphones provide
crystal- clear audio in noisy mobile scenarios.
WIRELESS FREEDOM
Offering a massive boost in wireless connection speed and range with
802.11n integrated wireless LAN technology .
Stereo Bluetooth ® technology for wirelessly connecting to useful
peripherals and streaming CD- quality audio.
The ultraportable VAIO® TT notebook establishes a new grade in
mobility with its thin -and- light design in a sleek, silk black shade.
What ’s more, this PC with a stunning 11.1”LCD offers industry- leading
mobile performance, balancing the power of Intel ® Centrino ® 2
processor technology with a host of energy- conserving features that
deliver maximum battery life.
1
5
8
3
14
5

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 01/23/2009
VGN-TT190NIB
VAIO® TT Series Notebook
Specifications
General
Computer Type: Notebook
Type of Use: Ultra Portable
Action Buttons: Mute, Volume -/ +, S1, Eject, WLAN /
Bluetooth® on / off
Pointing Device: Electro-static touch pad
Security: Biometric Fingerprint Sensor
Trusted Platform Module (TPM) TCG Ver.1.2 compliant
Hardware
Keyboard: QWERTY, 82 keys, 17mm pitch, 2mm stroke
Camera: Built -in MOTION EYE® camera and microphone
with face-tracking technology
Processor
Type: Intel® Core™2 Duo Processor SU9300
Speed: 1.20 GHz
Front Side Bus Speed: 800MHz
L2 Cache: 3MB
Technology: Intel® Centrino® 2 processor technology
Memory
Type: DDR3
Installed: 2GB PC3 - 6400 (2GBx1)
Maximum: 4GB
Speed: 800MHz
Hard Drive
Capacity: 160GB
Speed: 5400rpm
Interface: SATA
Impact Protection: G -Sensor™Shock Protection -Hard
Disk Drive Protection
Optical Drive #1
DVD+R DL Write: 4x max.
DVD+R Write: 8x max.
DVD+RW Write: 4x max.
DVD -R Write: 8x max.
DVD -RW Write: 4x max.
CD -R Write: 16x max.
CD -RW Write: 10x max.
DVD ±RW: Yes (DVD±RW/±R DL/RAM Drive)
CD Read: 24x max.
DVD Read: 8x max.
DVD -RAM Write: 5x max.
DVD -R DL Write: 4x max.
DVD -RAM Read: 5x max.
Expansion Slots
Multimedia Card Reader: One Memory Stick PRO™
(Standard/Duo) media slot with MagicGate®
functionality
One ExpressCard® / 34 slot
One Secure Digital (SD™memory card) media slot
Audio
Sound System: Intel® High Definition Audio
Display
Screen or Display Technology: WXGA
Screen Size: 11.1"
Resolution: 1366 x 768
XBRITE- DuraView ™Technology: Yes
Back Light Technology: LED
Graphics
Processor: Mobile Intel® Graphics Media Accelerator
4500MHD with Intel ® Clear Video Technology
Total Available Graphics Memory: 790MB (max.)
Chipset: Mobile Intel® GS45 Express Chipset
Interface: HDMI™ and VGA out with Smart Display Sensor
1
15
2
5
9
Inputs and Outputs
HDMI™Connection Output(s): 1
Headphone Jack: 1
Microphone Input: 1
Port Replicator Connector(s): 1 (Bottom)
USB Port(s): 2 (2.0 compliant)
VGA Output(s): 1
DC -In: 1
i.LINK® Connection: 1 (4pin) i.LINK® connector (IEEE
1394)
Ethernet Connection (s): 1
Networking/Modem
Ethernet Protocol: 10Base - T/100Base - TX/1000Base -T
(Gigabit)
Ethernet Speed: Fast Ethernet (RJ- 45)
Wireless LAN: Intel® WiFi Link 5100AGN (802.11a/b/g/n)
Bluetooth® Technology: Integrated Stereo A2DP
Bluetooth® Technology
Power
Battery Type: Standard Capacity Lithium-ion Battery
(VGP- BPS14/B)
Power Requirements: 68W + 10%
Input Voltage: 100 - 240V
Software
Operating System: Genuine Microsoft® Windows Vista®
Business 32-bit with SP1 and XP Pro Downgrade
Internet Services: AOL® 90 -Day Risk Free Trial -For new
users only
Supplied Software: Microsoft® Works SE 9.0 w/ 60 - Day
Trial Version of Microsoft® Office Small Business 2007
The VAIO® Software Experience: VAIO ® Startup Assistant
Click to Disc Editor -Import, Edit, Burn
VAIO ® Movie Story -Simple Movie Creation
VAIO ® MusicBox -Music by Mood
VAIO ® Media plus -Multimedia Streaming Software
*Please access VAIO® Help and Support from your
PC for a complete list of software applications and
trials.
Anti -Virus & Recovery Software: Microsoft® Windows
Live™OneCare™Trial Version
Service and Warranty Information
Telephone Support: 1 year toll -free technical telephone
assistance, available 24/7 .
Online and Email Support: Support available from
http://www.esupport.sony.com/EN/VAIO
Limited Warranty Term: 1 year limited warranty . See
actual warranty for details.
Environmental Information
RoHS®: Compliant
For more information: www.sony.com/vaioeco
Dimensions
Weight: 2.87 lbs.
Measurements: 10.99"(W) x 0.93"(H) x 7.87"(D)
Supplied Accessories
Noise-Canceling Headphones
Power Cord
AC Adapter (VGP- AC16V13)
Standard Capacity Lithium-ion Battery (VGP- BPS14/B)
Optional Accessories
Large Capacity Battery (VGP- BPL14/B)
Stick AC Adapter (VGP- AC16V10)
Port Replicator (VGP-PRTT1)
Leather Notebook Cover (VGP-CVTT1/B)
Neoprene Case (VGP-AMC6)
Bluetooth® Laser Mouse (VGP- BMS33/B)
Bluetooth® Presentation Controller (VGP-BRMP10)
USB Portable Speaker (VGP- USP1)
Privacy Filter (VGP-FL13)
Color: Silk Black
4
8
3
14
12
13
11
10
7
6,7
14
14
UPC Code: 27242756441
1.GHzdenotesmicroprocessorinternalclockspeed;otherfactorsmay
affectapplication performance. CPU speed will be reduced under
certain operating conditions.
2.GB means one billion bytes when referring to hard drive capacity.
3.Requires802.11ncompatibleaccesspoint.Somefunctionalitymay
requireInternetservices.
4. Requires high definition - capable display with HDMI ™ connector.Image
qualitywillvary.
5. Viewable area measured diagonally.
6.Non - metricweights and measures are approximate and mayvary.
7.Measured at the narrowest point.
8.i.LINKisatrademark of Sony used only to designate that a product
containsanIEEE1394connector.All products with an i.LINK
connectormaynotcommunicatewitheachother.
9.Total Available Graphics Memory refers to the newWindows Vista ®
classificationofgraphicsmemory, which is the total of Dedicated
VideoMemory,System Video MemoryandSharedSystem Memory.
SharedSystemMemory variesdependingonthe operating
condition,driversoftwareversionandsystemmemorysize.
10.Seeactuallimitedwarrantyfordetails.ForacopyofSony'swarranty,
please visit www.esupport.sony.com, call toll - free888 - 476 - 6972(888 -
4SONYPC),orwrite to SonyElectronics,12451Gateway Boulevard,
FortMyers,FL33913.
11.Forcertainthirdpartysoftwareapplications,Sonyprovidesfirst level
phonesupport.Additionaltelephone support may be available from
theapplicable3rdpartyvendor.Availabilityand schedule for any
such support is determined by the applicable software vendor.
12.60 - DayTrial Version of Microsoft ® Office2007 - Thistrial softwarewill
workonlyfor60daysafteryoufirstuseit. You will not be able to use
thesoftwareifyoudonotactivateitasdescribedthefirsttimeyouuse
thesoftware.You can activate thesoftwarebyInternet: Internet
servicechargesmayapply.Ifyouwanttokeepusing the software
afterthe60 - daytrialperiod, you mustconverttothe perpetual
version.Youcanconvertonlinebyfollowingtheconversion
instructions presented during setup and paying the required fees.
13.Microsoft® WindowsLive ™ OneCare ™ TrialVersion - Thistrial
softwarewillworkfor ninety (90) days afteryoufirstuseit.You will not
beableto use the software if you do not activate it asdescribedthe
firsttimeyou use the software. Youcanactivatethesoftware by
Internet:Internetservice charges may apply.Ifyouwantto keep
usingthesoftware after the 90 - daytrialperiod,you must buy a
subscription.Youcan subscribe online by following the conversion
instructions presented during setup and paying the required fees.
14.Interoperability and compatibility among Bluetooth ® devicesvaries.
15.Aportion of the system memory over3GBmaynotbe available to
theoperatingsystem.
ComputerInterface:Forthisproduct,thereare a multitude of varying
software packages and add - onhardwareoptions.Thisproductisnot
manufacturedtoworkwith any specific software, and Sony does not and
cannotmakeany warranty or representationwithrespectto the
performanceofthisproductwithanyparticularsoftwarepackages
and/or non - Sony add - onhardwareoptionsexceptthosementionedhere.
Sonyherebydisclaims any representationsorwarrantiesthat this
product is compatible with any combination of non - Sonyproductsyou
maychooseto connect to it.WhileSonyrepresentativesor Sony
authorizeddealersmaybeabletoassist you and may make
recommendations,theyare NOT authorized tovaryorwaive this
disclaimer.Purchasersmustdeterminefor themselves the suitability and
compatibilityofthehardwareandsoftwareineachandeveryparticular
instance.Softwaretitles pre - installedontheSony computer are subject
tochangewithoutnotice.Preinstalledsoftwaremaynotbeidenticalto
retailversionsorhave all documentation. Features and specifications are
subject to change without notice.
Lampinthisproductcontainsmercury.Disposalofthesematerialsmay
beregulateddueto environmental considerations. For disposal or
recyclinginformation,pleasecontactyourlocalauthorities or the
Electronic Industries Alliance (www.eiae.org).
©2008SonyElectronics Inc. All rightsreserved.Reproductioninwhole or
inpart without written permission is prohibited. Sony, i.LINK, VAIO, XBRITE -
DuraView,Sonylogo,VAIOlogo,MemoryStickPROandMagicGate are
trademarksofSonyintheU.S.andinothercountries.Intel and Core are
trademarksoftheIntelCorporationintheU.S.andinothercountries.
Microsoft,WindowsLive,OneCareandWindowsVistaareregistered
trademarksoftheMicrosoftCorporationinthe U.S. and in other
countries.Allother trademarks aretrademarksoftheir respective
owners.
Printed09/08.
