Sony VGN-Z670N - VAIO Z Series User manual

VGN-Z670N/B
VAIO® Z Series Notebook PC
Uncompromising ultra-portable design
POWERFUL MOBILE PERFORMANCE
Enjoy the powerful performance of an Intel ® Core™2 Duo P9600 processor
(2.66GHz ) with Intel ® Centrino ® 2 processor technology and 4GB of
system memory .
The VAIO ® Z notebook comes pre - installed with Genuine Microsoft ®
Windows Vista ® Business 32 - bit.
Uncompromising elegance weaved into a 3.42 lb (with standard battery)
go - anywhere package.
XBRITE - DuraView™LCD technology with LED backlight for a brighter, crisper,
tougher display.
WIRELESS FREEDOM
Your friends, your news, and your entertainment when you need it. The
VAIO ® Lifestyle PC lets you browse the web in more places with Verizon
Wireless Mobile Broadband Built - In, America's largest and most reliable 3G
network .
Built - in Wireless - N technology offers a boost in wireless connection speed
and range .
Extend the reach of your Z notebook with Stereo A2DP Bluetooth ®
technology that is ideal for advanced wireless communication and
streaming uncompromised CD - quality stereo music to Bluetooth ®
technology enabled speakers or headphones (sold separately).
ENDLESS FEATURES
A hybrid graphics system lets you set graphics performance on the fly –no
reboot necessary .
An HDMI ™output delivers video and audio to external sources via a single
cable so you can enjoy HD entertainment on your compatible big screen
TV without a myriad of extra cables (HDMI™cable sold separately).
G - Sensor™Shock Protection technology makes your data even less
vulnerable to loss or damage. When the built - in 3D acceleration sensor
detects a risky movement, the HDD - head will lock up to secure its position
and help protect the disc from scratching.
ENVIRONMENTALLY ENGINEERED FEATURES
By using a mercury - free backlit LED display, the VAIO ® Z notebook keeps
one less chemical out of both your home and the landfills.
Built tough for business, the VAIO ® Z notebook offers the portability of a
3.42 lbs (with standard battery) form factor with the performance of a
larger computer. Encased in durable carbon fiber and featuring scratch -
resistant XBRITE - DuraView™LCD technology, the Z notebook is designed to
withstand the rigors of the road.
1
15
7
20
3
16
5
17
7

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 12/11/2009
VGN-Z670N/B
VAIO® Z Series Notebook PC
Specifications
General
ComputerType: Notebook
TypeofUse: Ultra - portable
ActionButtons: S1,S2,WLAN/Bluetooth® on/off,Performace Select
PointingDevice: Electro - static touch pad
Security:BiometricFingerprintSensor
TrustedPlatform Module (TPM) TCG Ver.1.2compliant
Hardware
Keyboard: QWERTY,82keyswith2.5mm stroke and 19.05mm pitch
Camera: Built - inMOTIONEYE® camera and microphone
Processor
Type: Intel®Core™2DuoProcessorP9600
Speed: 2.66GHz
FrontSideBusSpeed: 1066MHz
L2Cache: 6MB
Technology: Intel®Centrino® 2processor technology
Memory
Installed: 4GB PC3 - 8500(2GBx2)
Maximum:4GB
Type/Speed: DDR3SDRAM/1066MHz
Hard Drive
Capacity: 320GB
Speed: 7200rpm
Type: SerialATA
ImpactProtection: G - Sensor™ShockProtection - HardDiskDrive
Protection
Optical Drive
CDSupport: Read/Write(CD/ - R/ - RW)
DVDSupport: Read/Write(DVD±R/±RW/±RDL/ - RAM)
Expansion Slots
MultimediaCard Reader: OneMemoryStickPRO™ ( STD/ Duo)media
slotwith MagicGate ® functionality
One ExpressCard ®/ 34media slot
OneSecureDigital(SDmemory card) media slot
Audio
SoundSystem: Intel® High Definition Audio
Display
ScreenSize: 13.1"
Resolution: 1600x900
XBRITE - DuraView ™ Technology: Yes
BackLightTechnology: LED
Graphics
Processor: NVIDIA®GeForce(R)9300MGSGPU with TotalAvailable
GraphicsMemory of 1500MB (max.) andMobile Intel ® Graphics
MediaAccelerator4500MHDwithIntel® ClearVideoTechnology.
TotalAvailable Graphics Memory: 1311MB (max.)
VideoRAM: 256MBofdedicatedvideoRAM
Technology: HybridGraphicsSystem
Chipset: MobileIntel ® GM45Express Chipset
Max.ExternalResolutionvia VGA: 2048x1536
Max.External Display Resolution via HDMI ™ : 1920x1080
Max.ExternalResolutionvia DVI: 1920x1200
Inputs and Outputs
ModemJack: 1
MicrophoneInput: 1
PortReplicator Connector(s): 1(Bottom)
USBPort(s): 2(2.0 compliant)
VGAOutput(s): 1
DC - In: 1
i.LINK ® Connection: 1 (4pin) i.LINK ®connector(IEEE1394)
HeadphoneOutput(s): 1
EthernetConnection(s): 1
HDMI™ Output: 1
Power
BatteryType: StandardCapacity Lithium - ionBattery(VGP - BPS12)
EstimatedBatteryLife: 3.0to 6.0 hours StandardCapacityBattery
4.0to 9.0 hours LargeCapacityBattery
PowerRequirements: 100W+10%
Wireless/Networking
EthernetProtocol: 10Base - T/100Base - TX/1000Base - T (Gigabit)
EthernetSpeed: FastEthernet(RJ - 45)
1
15
15
2
6
10
19
9
17
11
11
Wi - Fi: Intel®WiFiLink5100AGN(802.11a/b/g/n)
Bluetooth ® Technology: IntegratedStereoA2DPBluetooth® Technology
(2.1+EDR)
ModemType: IntegratedV.92/V.90 Modem (RJ - 11)
MobileBroadband: VerizonWireless Mobile Broadband Built - in
Software
OperatingSystem: GenuineMicrosoft ® Windows Vista ® Business32 - bit/
XPPro downgrade
SuppliedSoftware: Microsoft®WorksSE9.0w/ 60 - DayTrialVersion of
Microsoft® OfficeSmall Business 2007
VAIO ® MultimediaSuite: VAIO ®StartupAssistant
Clickto DiscEditor - Import,Edit,Burn
VAIO ®MovieStory - SimpleMovieCreation
VAIO ® MusicBox - Musicby Mood
VAIO ® Mediaplus - MultimediaStreamingSoftware
*Please access VAIO ® HelpandSupportfromyourPCforacomplete
list of software applications and trials.
Anti - VirusSoftware: Microsoft® WindowsLive ™ OneCare ™ Trial Version
Service and Warranty Information
TelephoneSupport: 1yeartoll - freetechnicaltelephoneassistance,
available24/7
OnlineandEmailSupport: Supportavailable from
http://www.esupport.sony.com/EN/VAIO
InternationalService: 1yearinternationalserviceplanavailable.
Registrationrequired. See www.sony.com/IRSP for details.
LimitedWarrantyTerm: 1yearlimitedwarranty .Seeactualwarranty
for details.
Environmental Information
RoHS ® : Compliant
Formore information: www.sony.com/vaioeco
Dimensions
Weight: 3.42 lbs (withstandardbattery)
Measurements: 12.4"(W)x1.0 - 1.3"(H)x 8.3"(D)
Supplied Accessories
StandardCapacity Lithium - ionbattery(VGP - BPS12)
ACAdapter(VGP - AC19V26)
PowerCable
Optional Accessories
StickACAdapter(VGP - AC19V21)
PortReplicator(VGP - PRZ1)
AdditionalStandardCapacityBattery(VGP - BPS12)
LargeCapacityBattery(VGP - BPL12)
VAIO ® ProtectionCase (VGP - CKZ1)
USBOptical Mouse (VGP - UMS20/B)
Bluetooth® LaserMouse (VGP - BMS33/B)
Neoprene Case (VGP - AMB10)
Color: Black
UPCCode: 27242760615
1.GHzdenotesmicroprocessor internal clock speed; other factors may
affectapplication performance. CPU speed willbereduced under
certain operating conditions.
2.GBmeans one billion bytes when referring toharddrivecapacity.
Accessiblecapacitymay vary. A portion of hard disk spaceis
reservedasarecoverypartition.
3.Requires802.11ncompatibleaccess point. Some functionality may
requireInternetservices.
4.BroadbandInternetservicerequiredalongwiththirdpartyservices
whichmay require a subscription orother service fee.
5. VAIO ®ZSeriesnotebooksthat are either pre - installedwithor have
been downgraded to Windows ® XPProfessionalwillneedtobe
rebootedto switch between Speedand Stamina modes.
6. Viewable area measured diagonally.
7.Non - metricweights and measures are approximateand may vary.
8.Measuredatthenarrowest point
9.i.LINKis a trademark of Sony used onlytodesignate that a product
containsanIEEE1394connector.Allproductswithani.LINK
connectormaynotcommunicatewith each other.
10.Total Available Graphics Memory referstothe new Windows Vista ®
classificationof graphics memory, which varies dependingonthe
operatingcondition, version of device driverand system memory size.
11.Actualbatterylifemay vary based on product settings, usage
patternsand environmental conditions.
12.Seeactuallimitedwarranty for details. For a copy of Sony's warranty,
pleasevisit www.sony.com/pcsupport, call toll - free888 - 476 - 6972
(888 - 4SONYPC)orwriteto Sony Electronics, 12451Gateway
Boulevard,FortMyers,FL33913.
13.Forcertainthirdpartysoftware applications, Sony provides first level
phonesupport.Additional telephone support may be availablefrom
theapplicable3rd party vendor. Availability and schedule for any
suchsupport is determined by the aplicable software vendor.
3
16
20
14
18
13
12
7
7,8
16
14.60 - DayTrial Version of Microsoft ® Office2007 - Thistrialsoftware will
workonlyfor 60 days after you first use it. Youwillnotbe able to use
thesoftwareifyoudont activate it as described the first time you use
thesoftware.Youcanactivate the software by Internet: Internet
servicechargesmay apply. If you want to keep usingthesoftware
afterthe60 - daytrialperiod,you must convert to theperpetual
version.Youcanconvertonline by following the conversion
instgructions presented during setup and paying the required fees.
15.Aportionofthesystemmemoryover 3GB may not be available to
theoperatingsystem.
16.Interoperability and compatibility among Bluetooth ®devicesvary.
17. Requires high definition - capable display with HDMI ™ connector.
Imagequality will vary.
18.Microsoft® WindowsLive ™ OneCare ™ TrialVersion – Thistrial
softwarewillworkforninety(90)daysafteryou first use it. You will not
beable to use the software ifyoudo not activate it as describedthe
firsttimeyouusethesoftware. You can activate the software by
Internet:Internetservicechargesmay apply. If you want to keep
usingthe software after the 90 - daytrialperiod,youmustbuya
subscription.You can subscribe online by followingtheconversion
instructions presented during setup and paying the required fees.
19. Windows Vista ® isrequiredforfeaturefunctionality.Rebooting is
necessaryon pre - installed and downgraded Windows ® XPProfessional
models.
20.Subscriptionwithathird party carrier is required. Service activation
andother fees apply. Terms & Conditions andadditionalrestrictions
apply.
ComputerInterface:Forthisproduct,thereareamultitudeofvarying
software packages and add - onhardwareoptions. This product is not
manufacturedtowork with any specific software, andSonydoesnot and
cannotmakeanywarrantyor representation with respect to the
performanceofthisproduct with any particular software packages
and/or non - Sony add - onhardwareoptionsexceptthosementionedhere.
Sonyherebydisclaimsany representations or warranties thatthis
product is compatible with any combination of non - Sonyproductsyou
maychoosetoconnectto it. While Sony representatives or Sony
authorizeddealersmay be able to assist you and maymake
recommendations,theyareNOTauthorized to vary or waive this
disclaimer.Purchasersmustdetermineforthemselvesthesuitabilityand
compatibilityofthehardware and software in each and every particular
instance.Software titles pre - installedontheSonycomputeraresubject
tochangewithoutnotice. Preinstalled software may not be identical to
retailversionsor have all documentation. Features andspecificationsare
subject to change without notice.
©2008SonyElectronicsInc.All rights reserved. Reproduction in whole or
inpartwithoutwritten permission is prohibited. Sony, VAIO, VAIO logo,
XBRITE - DuraView,MemoryStickPRO,MOTION EYE, G - Sensor,
MagicGate,andi.LINK are trademarks of Sony intheU.S.and in other
countries.Microsoft,Windows, Windows Live, OneCare and Windows Vista
aretrademarksoftheMicrosoftCorporation in the U.S. and in other
countries.IntelandCentrinoare registered trademarks and Core is a
trademarkoftheIntelCorporation in the U.S. and in other countries.
BluetoothandtheBluetooth logo are registered trademarks of SIG, Inc.
Allothertrademarksaretrademarks of their respective owners.
PrintedinU.S.A.11/08.
