VGN- CS390JAB
VAIO® CS Notebook PC
Vibrant colors inside and out
CROSS - PLATFORM PERFORMANCE
Backed by powerful Intel ® Core™2 Duo processor, loads of RAM, ample
storage, Bluetooth ® technology and a webcam, the CS notebook delivers
the tools you'll need for all your entertainment and computing endeavors.
BUSINESS MEETS LIFESTYLE
Business and lifestyle merge in the 14.1”(diag.) VAIO ® CS notebook, a
cross - platform performer available in an array of high - gloss colors. Why
own a stodgy PC that fails to reflect your personality and sense of style?
Distinguished by lustrous high - gloss colors that truly make a statement, the
CS notebook was designed to fit into and express your style like no other
PC can.
CRISPER, BRIGHTER LCD
Backed by the company that makes amazing LCD TVs, the Sony VAIO ® CS
notebook boasts a crisper, brighter LCD with XBRITE - ECO™technology to
make those long days (and nights) in front of the computer a little easier
to bear.
A gorgeous 14.1 ” (diag.) notebook adorned by fashionable high - gloss
colors inside and out. This thin - and - light PC features an array of
entertainment extras, including an intuitive AV slide control that lets you
control your media with the slide of a finger and also includes a Blu - ray
Disc™player to enjoy HD movies.
14
ECO
-

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 07/07/2009
VGN- CS390JAB
VAIO® CS Notebook PC
Specifications
General
Computer Type: Notebook
Type of Use: Portable
Action Buttons: Play/ Pause/ Stop, AV Mode, Mute,
Previous, Next, Volume-/+, Capture,WLAN /
Bluetooth® on / off
Pointing Device: Electro-static touch pad
Security: Biometric Fingerprint Sensor
Hardware
Keyboard: QWERTY, 82 keys with 2mm stroke and
18.05mm pitch
Camera: Built -in MOTION EYE® camera and microphone
Processor
Type: Intel® Core™2 Duo Processor T6500
Speed: 2.10GHz
Front Side Bus Speed: 800MHz
L2 Cache: 2MB
Technology: Intel® Centrino® processor technology
Memory
Type: DDR2
Installed: 3GB PC2 - 6400 (2GBx1) + (1GBx1)
Maximum: 8GB
Speed: 800MHz
Hard Drive
Capacity: 320GB
Speed: 5400rpm
Interface: Serial ATA
Optical Drive
CD Support: Read / Write (CD/-R/-RW)
DVD Support: Read / Write (DVD±R/±RW/±R DL/-RAM)
Expansion Slots
Multimedia Card Reader: One Memory Stick PRO™
media slot (Standard/Duo) with MagicGate®
functionality
One ExpressCard® / 34 media slot
One Secure Digital (SD memory card) media slot
Audio
Sound System: Intel® High Definition Audio
Display
Screen Size: 14.1"
Resolution: 1280 x 800
XBRITE-ECO™Technology: Yes
Technology: WXGA
Graphics
Processor: Mobile Intel® Graphics Media Accelerator
4500MHD with Intel ® Clear Video Technology with
Total Available Graphics Memory: 1340MB (max.)
Chipset: Mobile Intel® GM45 Express Chipset
Max. External Resolution via VGA: 2048x1536
Inputs and Outputs
Microphone Input: 1
USB Port(s): 3 (2.0 compliant)
VGA Output(s): 1
DC -In: 1
i.LINK® Connection: 1 (4pin) i.LINK® connector (IEEE
1394)
Headphone Output(s): 1
Ethernet Connection (s): 1
Networking/Modem
Ethernet Protocol: 10Base - T/100Base -TX
1
2
4
13
7
Ethernet Speed: Fast Ethernet (RJ- 45)
Wireless LAN: Intel® WiFi Link 5100AGN (802.11a/b/g/n)
Bluetooth® Technology: Integrated Stereo A2DP
Bluetooth® Technology (2.1+EDR)
Power
Battery Type: Standard Capacity Lithium-ion Battery
(VGP- BPS13/S)
Estimated Battery Life: Up to 4.0 hours Standard
Capacity Battery
Up to 6.5 hours Large Capacity Battery
Power Requirements: 86W + 10%
Software
Operating System: Genuine Microsoft® Windows Vista®
Home Premium 64- bit
Supplied Software: Microsoft® Works SE 9.0 w/ 60 - Day
Trial Version of Microsoft® Office Home and Student
2007
The VAIO® Software Experience: VAIO ® Startup Assistant
VAIO ® Care
VAIO® Multimedia Suite: VAIO ® Startup Assistant
Click to Disc Editor -Import, Edit, Burn
VAIO ® Movie Story -Simple Movie Creation
VAIO ® MusicBox -Music by Mood
VAIO ® Media plus -Multimedia Streaming Software
*Please access VAIO® Help and Support from your
PC for a complete list of software applications and
trials.
Anti -Virus & Recovery Software: Norton Internet
Security™ 2009 30 -Day Trial Offer
Service and Warranty Information
Telephone Support: 1 year toll -free technical telephone
assistance, available 24/7
Online and Email Support: Support available from
http://www.esupport.sony.com/EN/VAIO
Limited Warranty Term: 1 year limited warranty . See
actual warranty for details.
International Service: 1 year international service plan
available. Registration required. See
www.sony.com/IRSP for details.
Environmental Information
RoHS®: Compliant
ENERGY STAR®: 5.0
Dimensions
Weight: 5.7 lbs (with standard battery)
Measurements: 13.2"(W) x 1.14 - 1.57"(H) x 9.6"(D)
Supplied Accessories
Standard Capacity Lithium-ion battery (VGP- BPS13/S)
AC Adapter
Power Cord
Optional Accessories
Large Capacity Battery (VGP- BPL13)
Additional Standard Lithium-ion Battery (VGP- BPS13A/S)
AC Adapter (VGP- AC19V31)
Bluetooth® Laser Mouse/Mouse Pad Combo (VGP-
BMS5P/W)
Slip Case with VAIO Smart Protection® technology (VGP-
CKC3/W)
Neoprene Notebook and AC Adapter Case (VGP-AMC5)
USB Portable Speaker (VGP- USP1)
Color: Matte Black
UPC Code: 027242775145
1.GHzdenotesmicroprocessorinternalclockspeed;otherfactorsmay
affectapplication performance. CPU speed will be reduced under
certain operating conditions.
2.GBmeansonebillionbytes when referring to hard drive capacity.
Accessiblecapacitymayvary.Aportionofharddisk space is
reservedasarecoverypartition.
3.Requires802.11ncompatibleaccesspoint.Somefunctionalitymay
requireInternetservices.
4. Viewable area measured diagonally.
5.Non - metricweights and measures are approximate and mayvary.
6.Measured at the narrowest point.
3
16
8
8
17
11
15
10
9
7
5,6
16
7.i.LINKisatrademark of Sony used only to designate that a product
containsanIEEE1394connector.Allproductswithani.LINK
connectormaynotcommunicatewitheachother.
8.Actualbatterylifemayvarybasedonproductsettings,usage
patternsand environmental conditions.
9.Seeactuallimitedwarrantyfordetails.ForacopyofSony'swarranty,
pleasevisit www.sony.com/pcsupport, call toll - free888 - 476 - 6972
(888 - 4SONYPC)orwritetoSonyElectronics, 12451 Gateway
Boulevard,FortMyers,FL33913.
10.Forcertain third party software applications, Sony provides first level
phonesupport.Additionaltelephone support may be available from
theapplicable3rdpartyvendor.Availabilityand schedule for any
suchsupport is determined by the aplicable software vendor.
11.60 - DayTrial Version of Microsoft ® Office2007 - Thistrial softwarewill
workonlyfor60daysafteryoufirstuseit. You will not be able to use
thesoftwareifyoudontactivate it as described the first time you use
thesoftware. You canactivatethesoftware by Internet: Internet
servicechargesmayapply.Ifyouwanttokeepusing the software
afterthe60 - daytrial period, youmustconvert to the perpetual
version.Youcanconvert online by following the conversion
instgructions presented during setup and paying the required fees.
12.Broadband Internet servicerequiredalongwith third party services
whichmay require a subscription or other service fee.
13.TotalAvailable Graphics Memory refers to the new Windows Vista
classificationofgraphics memory, which varies depending on the
operatingcondition, version of device driver and system memory size.
14.Certaincircumstancesmaylimit/preventBlu - rayDisc™ media
playback.Foroptimal performance, download all updates from
http://esupport.sony.com/EN/DRIVERS.
15.NortonInternetSecurity™200930 - day subscription is pre - installed
onyour Sony VAIO PC. Youneedto activate the software forthe
productto work. You canactivateinthe Sony VAIO StartupAssistant
orby double clicking theNortonInternet Security icon onyour
desktop.Afteryour30 - daysare finished,buyNorton Internet Security
tocontinue to be protected from viruses, hackers andidentify theft.
16.Interoperability and compatibility among Bluetooth ®devicesvary.
17.Compatibility and performance ina64 bit environment mayvary.
Checkwith the manufacturer ofyoursoftware or accessory toensure
youhave the latest updates.
ComputerInterface:For this product, there are a multitude of varying
software packages and add - onhardwareoptions.Thisproductisnot
manufacturedtoworkwith any specific software, and Sony does not and
cannotmake any warrantyorrepresentationwith respect to the
performanceofthisproductwithanyparticularsoftwarepackages
and/or non - Sony add - onhardwareoptions except those mentioned here.
Sonyhereby disclaims anyrepresentationsor warranties that this
product is compatible with any combination of non - Sonyproductsyou
maychoose to connect toit.While Sony representatives orSony
authorizeddealersmaybeabletoassist you and may make
recommendations,they are NOTauthorizedtovary or waive this
disclaimer.Purchasers must determine for themselves the suitability and
compatibilityofthehardwareandsoftwareineachandeveryparticular
instance.Softwaretitles pre - installedon the Sony computer are subject
tochangewithoutnotice.Preinstalledsoftwaremaynotbe identical to
retailversionsorhave all documentation. Features and specifications are
subject to change without notice.
Lampinthisproductcontainsmercury.Disposalofthesematerialsmay
beregulatedduetoenvironmentalconsiderations.Thisproductmeets
thestandards of theInternationalEnergyStar Program for energy
efficiency.Fordisposal or recycling information, please contact your local
authoritiesor the Electronic Industries Alliance (www.eiae.org).
©2009Sony Electronics Inc. Allrightsreserved. Reproduction in wholeor
inpartwithoutwrittenpermissionis prohibited. Sony, VAIO, the Sony logo,
theVAIOlogo,VAIOSmartProtection, XBRITE - ECO,MemoryStick PRO,
MOTIONEYE,MagicGateandi.LINKaretrademarksof Sony in the U.S.
andinothercountries.MicrosoftandWindowsVistaaretrademarksof
theMicrosoftCorporationintheU.S.andinothercountries.Intel,
CentrinoandCorearetrademarksoftheIntelCorporationintheU.S.and
inother countries. Bluetooth is a registered trademark ofSIG, Inc. Blu - ray
Discand the Blu - rayDisc logo isatrademark. Symantec, the Symantec
Logo,and Norton InternetSecurityare trademarks or registered
trademarksofSymantecCorporation or its affiliates in the U.S. and other
countries.Energy Star and itslogoare U.S. trademarks. Allother
trademarksaretrademarksoftheirrespective owners.
PrintedinU.S.A.05/09.
