Sony Bravia KDL-22L4000 User manual

KDL- 22L4000
22" Class BRAVIA® L Series LCD TV (21.6" Diagonally)
Key Features
16:9 720p Resolution Panel (1366x768)
HDMI™interface x1 (1080/60p capable)
1
HD Component YPbPr x1 (1080/60i capable)
PC Input x1
2
VESA ® compatible hole spacing
ATSC/NTSC tuner with QAM
Fast panel response
MPEG video noise reduction circuit
Black semi-gloss finish with chrome accents
Remote: RM-YD025 or RM-YD025/W
Key Technologies
16:9 720p resolution panel 16:9 720p resolution panel (1366x768) provides crisp, detailed, and
vibrant images.
HDMI™ input HDMI ™input (up to 1080/60p input capable) transmits both uncompressed digital
video and multi - channel digital audio on a single cable.
Component input Component YPbPr (1080/60i capable) input provides added HD capable
connectivity.
PC input PC input (HD - 15 pin) offers the added versatility to use your HDTV as a computer monitor.
2
VESA ® compatible hole spacing VESA ® compatible hole spacing use an industry - standard
mounting hole pattern to allow a wide range of VESA compatible wall mount bracket choices.
Built - in ATSC/NTSC tuner Built - in ATSC/NTSC tuner with QAM delivers over - the - air digital TV and
unencrypted HDTV broadcast signals, as well as traditional analog TV broadcasts.
Fast panel response Fast panel response helps provide a crisp, clear image.
MPEG video noise reduction circuit MPEG video noise reduction circuit helps improve image
quality by reducing image artifacts typical when viewing DVDs or digital TV channels.

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 04/21/2009
KDL- 22L4000
22" Class BRAVIA® L Series LCD TV (21.6" Diagonally)
Please visit the Dealer Network for current
information at www.sony.com/dn
Features
General
Closed Captions (CC): Yes
On-Screen Display: Sony OSD
Finish (Surface Color): Black
Display
Display Technology: LCD (178 ° wide viewing angle LCD
display panels)
Video
CineMotion® Reverse 3:2 Pulldown Technology: Yes
Wide Mode: Normal, Full, Wide Zoom
3D Comb Filter: Yes
Picture Mode: Vivid, Standard, Custom
Audio
Digital Amplifier: Yes
Audio Out: Fixed
Stereo System: MTS
Dolby ®: Dolby ® Digital for broadcasting & HDMI)
Sound Mode: Clear Voice, Dynamic, Standard
Convenience
Channel Jump: Yes
Favorite Channel: Yes
Multiple Language Display: English, Spanish, French
Sleep Timer: Yes
Input Skip: Yes
Channel Surf: Yes
ID-1 Detection: Yes
Parental Control: Yes
Specifications
General
Television Type: Flat Panel LCD HDTV
Display
Viewing Angle (Right/Left): 85/85
Viewing Angle (Up/Down): 80/80
On-screen Contrast Ratio: 2,000:1
Dynamic Contrast Ratio: 2,000:1
Screen Size (measured diagonally): 22" Class (21.6 ”)
Native Resolution: 1366 x 768
Display Resolution: 1366 x 768p (HD)
TV System
Tuner (Cable): QAM
Tuner (Terrestrial): ATSC, NTSC
Video
Video Signal: 480/60i, 480/60p, 720/60p, 1080/60i, 1080p
(HDMI™only)
Audio
Audio Power Output: 5W+5W
Inputs and Outputs
Component Video (Y/Pb/Pr ) Input(s): 1 (Rear)
Composite Video Input(s): 2 (1 Side/1 Rear)
Digital Audio Output(s): 1 (Rear) Optical Digital Output
RF Connection Input(s): 1 (Rear)
S -Video Input(s): 1 (Rear)
Headphone Output(s): 1 (Side)
Analog Audio Input(s) (Total): 5 (4 Rear/1 Side)
Audio Out: 1 (Rear)
HDMI™Connection(s) (Total): 1 (Rear)
PC In (D-Sub) + Audio In (Stereo Mini): 1 (Rear)
AC Power Input: 1 (Rear)
Analog Audio Input(s) for HDMI™: 1 (Rear)
Power
Power Consumption (in Standby): Less than 1W
Power Requirements (voltage): AC 110V
Power Consumption (in Operation) max.: 55W
Regulation and Standard Compliance
VESA ® Hole Spacing Compatible: Yes
VESA ® Hole Pitch: 100mm x 100mm
Service and Warranty Information
Limited Warranty Term: 1 Year Parts / 1 Year Labor
Energy Saving & Efficiency
Energy Star® compliant: Yes
PC Power Management: Yes
Dimensions
Weight: 16.8 lbs. (7.3kg) with pedestal; 14.2 lbs. (6.3kg)
without pedestal
Measurements: 21.75 x 17 x 8.5 in (551 x 430 x 214mm)
with pedestal; 21.75 x 15.5 x 3 in (551 x 392 x 76mm)
without pedestal
Supplied Accessories
RM-YD025 Remote Control
Batteries (Type AA x 2)
AC Power Cord
Operating Instructions
Warranty Card
Quick Setup Guide
Optional Accessories
SU-FL300M Stand
SU-WL500 Wallmount Bracket
Color: Satin Black Semigloss finish with Chrome accents
UPC Code: 027242746084
1. HDMI connector (sold separately) and equivalent display capability.
2.LimitedtoresolutionssupportedbyboththePCandtheSonyTV.See
SonyTVusersmanualandPCdocumentationforthesupported
resolutions.
©2008SonyElectronicsInc.Allrightsreserved
Sony,BRAVIA,BRAVIAEngine,XBR,DRC,Speed Surf, Live ColorCreation,
TheatreSync,x.v.Color, Xross Media Bar and CineMotion are trademarks
ofSony.Dolby Digita lisa registered trademark of Dolby Laboratories. This
TV incorporates High - DefinitionMultimediaInterface (HDMI™ )
technology. HDMI, the HMDI logo and High - DefinitionMultimedia
Interfaceare trademarks or registered trademarks of HDMI Licensing LLC.
Allothertrademarks are property of their respective owners.
Features and specifications are subject to change without notice. Non -
metricweights and measures are approximate.
VESAis a trademark of Video Electronics StandardsAssociation Inc.
Lampinthisproduct contains mercury. Disposal of these materials may
beregulatedduetoenvironmental considerations. For disposal or
recyclinginformation, please contact your local authorities or the
Electronic Industries Alliance (www.eiae.org).
