KDL- 40V4100
40" BRAVIA® V Series LCD TV
Key Features
16:9 Full HD 1080p Resolution Panel (1920 x
1080)
Motionflow 60Hz technology
DMeX ™²capable
Xross Media Bar™ ( XMB™ ) user interface
Favorites function with rich 3D graphics
TV Guide® Interactive Program Guide
BRAVIA® Sync ™capable
Up to 1080/24p input capable via HDMI™
interface x4
BRAVIA Engine ™ fully digital video processor
Advanced Contrast Enhancer circuit (ACE)
24p True Cinema
DIGITAL MEDIA PORT connectivity
S - Force ® Front Surround
Voice Zoom
Key Technologies
16:9 Full HD 1080p 16:9 Full HD 1080p resolution panel (1920 x 1080) accepts any HDTV signal and
renders them with optimum resolution.
Motionflow 60Hz technology Motionflow 60Hz technology allows you to enjoy movies and prime -
time TV (film - based content) with a clarity and resolution in motion that will spoil you. Sony’s
Motionflow motion - compensation algorithm identifies film content and removes “judder”. That
means you'll get a clearer picture during sweeping pans with reduced visible jerking or stuttering.
DMeX™² functionality DMeX™ ² functionality lets you expand your HDTV’s capabilities by connecting
optional BRAVIA ® Link Modules, such as the DMX - NV1 BRAVIA ® Internet Video Link module (sold
separately).
Enhanced Xross Media Bar™(XMB™) Enhanced Xross Media Bar™(XMB™) makes it simple and
intuitive to navigate the television's menus, controls, and user settings.
TV Guide Interactive Program Guide TV Guide Interactive Program Guide is integrated into Sony’s
exclusive Xross Media Bar™user interface to deliver continually updated program.
BRAVIA® Sync ™ capability BRAVIA ® Sync™capability combines the one - touch access and control
functionality of BRAVIA ® Theatre Sync™with the ability to control CEC - enabled Sony ® Handycam ®
camcorders using the TV’s remote and an on - screen display.
HDMI™ and PC connectivity HDMI ™and PC connectivity transmit both uncompressed digital video
and multi - channel digital audio on the same cable for maximum versatility. (4) HDMI™inputs deliver
up to 1080/60p input capable video content. Additionally, a PC input1(HD - 15 pin) offers up to a 1920
x 1080p connection to your PC so you can use your HDTV as a computer monitor.
BRAVIA Engine ™ BRAVIA Engine™fully digital video processor significantly reduces noise, enhances
overall image detail, and optimizes contrast.

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 05/21/2009
KDL- 40V4100
40" BRAVIA® V Series LCD TV
Please visit the Dealer Network for current
information at www.sony.com/dn
Features
General
Closed Caption Button: Yes
Closed Captions (CC): Yes
On-Screen Display: 3D GUI + xmb
Auto CC on Mute: Yes
Finish (Surface Color): Piano Black
BRAVIA® Link Module support: Yes
Display
Backlight Type: CCFL
Display Device: LCD
Display Technology: LCD (178 ° wide viewing angle LCD
display panels)
Video
Video Processing: Bravia Engine 2 ™Technology
CineMotion® Reverse 3:2 Pulldown Technology: Yes
Game Mode: Yes
Wide Mode: Wide Zoom, Normal, Full, H Stretch, Zoom
3D Comb Filter: Yes
MPEG Noise Reduction: Yes
Auto Wide: Yes
4:3 Default: Yes
24p True Cinema™Technology: Yes
Picture Mode: Vivid, Standard, Cinema, Custom, Photo-
Vivid, Photo-Standard, Photo-Original, Photo-Custom
Advanced Contrast Enhancer (ACE): Yes
Motionflow™Technology: Motionflow™ 60Hz
Audio
Digital Amplifier: Yes
Voice Zoom: Yes
Auto SAP: Yes
Steady Sound® Automatic Volume Control: Yes
Audio Out: Yes
Sony Original Surround: S -Force® Front
Stereo System: MTS
Dolby ®: Dolby ® Digital
Alternate Audio (Digital): Yes
Sound Booster: Yes
5.1 Channel Audio Out: Yes
Sound Mode: Dynamic, Standard, Clear Voice
Convenience
Channel Jump: Yes
Favorite Channel: Yes
Program Guide Access: Yes
Multiple Language Display: English, Spanish, French
Info Banner: Yes
Sleep Timer: Yes
Power Save Mode: Picture Off, Yes
Input Skip: Yes (Auto)
Channel Surf: Yes
Channel Block (with password): Yes
Edit Channel Labels: Yes
Label Inputs: Yes
ID-1 Detection: Yes
Initial Setup: Yes
On/Off Timer: Yes
PAP (Picture & Picture): Yes
Swap Sound: Yes
Theatre Mode (Theatre Button): Yes
Show/Hide Channels: Yes
PAP (Fixed or Variable): Fixed
BRAVIA® Sync™: Yes
Parental Control: Yes
BRAVIA® Sync™Menu Button: Yes
Freeze: Yes
On-Screen Display for External Input: Yes
PIP (Picture in Picture): PC Input
Channel Labels: Yes
On-Screen Clock: Yes
XMB™(Xross Media Bar™): Yes
TV Guide On-Screen: Yes
Specifications
General
Television Type: Flat Panel LCD HDTV
Display
Viewing Angle (Right/Left): 178 °
Viewing Angle (Up/Down): 178 °
On-screen Contrast Ratio: 2,500:1 (typ)
Dynamic Contrast Ratio: 25,000:1 (typ)
Screen Size (measured diagonally): 40"
Native Resolution: 1920 x 1080
Display Resolution: 1920 x 1080p (Full HD)
Color Range (u'v'): 90%
Color Range (xy): 72%
TV System
Tuner (Cable): QAM Tuner
Tuner (Terrestrial): NTSC Tuner
Channel Coverage: VHF: 2- 13
UHF: 14 - 69
CATV (analog): 1- 135
CATV (digital) : 1- 135
TV System (Analog): M
Number of Tuners (Analog): 1
Number of Tuners (Digital): 1(Hybrid)
TV System (Digital): ATSC
Color System: NTSC 3.58
Video
Video Signal: 480/60i, 480/60p, 720/60p, 1080/60i, 1080/24p
(HDMI™ only), 1080/60p (HDMI ™ / Component)
Audio
Audio Power Output: 20W (10W + 10W)
Inputs and Outputs
Component Video (Y/Pb/Pr ) Input(s): 2 (Rear)
Composite Video Input(s): 3 (1 Side/2 Rear)
Digital Audio Output(s): 1 (Rear) Optical Digital Output
RF Connection Input(s): 1 (Rear)
S -Video Input(s): 1 (Rear)
Analog Audio Input(s) (Total): 6 (1 Side/5 Rear)
Audio Out: 1 (Rear)
HDMI™Connection(s) (Total): 4 (1 Side/3 Rear)
PC In (D-Sub) + Audio In (Stereo Mini): 1 (Rear)
HDMI™PC Input: Yes
S -Video Detection: Yes
AC Power Input: 1 (Rear)
Analog Audio Input(s) for HDMI™: Yes
USB 1.1: 1 (Rear) service only
Power
Power Consumption (in Standby): 0.1W
Power Requirements (voltage): AC 120V
Power Consumption (in Operation) max.: 220W
Regulation and Standard Compliance
VESA ® Hole Spacing Compatible: Yes
VESA ® Hole Pitch: 300 x 300 mm, M6 Screw Type, 16mm
Screw Length
Service and Warranty Information
Limited Warranty Term: 1 Year Parts / 1 Year Labor
Energy Saving & Efficiency
LightSensor™Technology: Yes
Dimensions
Weight: 51 lbs. (23kg) with pedestal; 45 lbs. (20kg)
without pedestal
Measurements: 38 7/8 x 27 x 11 in (986 x 684 x 279mm)
with pedestal; 38 7/8 x 25 1/2 x 4 3/8 in (986 x 646 x
110mm) without pedestal
Supplied Accessories
RM-YD023 Remote Control
Batteries (2 x AA)
AC Power Cord (attached)
Operating Instructions
Quick Setup Guide
Warranty Card
On-line Registration Card
Cable Clamper
Pedestal (separate)
Optional Accessories
RHT- G900 Stand
WS- S10LS Stand
SU-WL500 Wallmount Bracket
Color: Piano Black
UPC Code: 027242736559
1. Resolution Limited. See Sony TV and PC manuals.
