Sony Bravia KLV-40ZX1 User manual

KLV-40ZX1
4-146-299-11(1)
Printed in Japan
4-146-299-11(1)
APPROVED
Customer Support:
TA-2008/1457
TA-2008/1214
© 2009 Sony Corporation 4-146-299-11(1)
KLV-40ZX1
4-146-299-11(1)
GB
CT
VN
TH
KLV-40ZX1
LCD Colour TV
Operating Instructions

2GB
Introduction
Thank you for choosing this Sony product.
Before operating the TV, please read this manual thoroughly and
retain it for future reference.
Trademark information
sHDMI, the HDMI logo and High-Definition Multimedia
Interface are trademarks or registered trademarks of HDMI
Licensing LLC.
s“BRAVIA” and are trademarks of Sony
Corporation.
s“XMB” and “xross media bar” are the trademarks of Sony
Corporation and Sony Computer Entertainment Inc.
Notice for Identification Label
Labels for Model No. and Power Supply rating (in accordance with
applicable safety regulation) are in the following locations:
Monitor: at the inside of the terminal cover
Media receiver: on the underside
Notice for customers in the South
Africa
The Euro/South Africa converter plug should be fitted as follows.
Notice for customers in Thailand
This telecommunication equipment conforms to NTC technical
requirement.
1Insert the power supply or
CEE7 plug in to the
converter plug.
2Use an appropriate
screwdriver to attach the
screw tightly without
damaging the screw head.
3TEST: Grip the converter
plug, and pull the VDE
cord set/transformer to
ensure it is fully secure, if
not then increase the torque
setting and further tighten.
Re-test.
The converter plug is now
ready for use.

3GB
Table of Contents
Start-up Guide 4
Safety Information ..........................................................................................................................15
Precautions .....................................................................................................................................17
Remote and Unit Controls/Indicators............................................................................................18
Watching TV
Watching TV ....................................................................................................................................23
Using the Favourite list ..................................................................................................................25
Using Optional Equipment
Connecting Chart ............................................................................................................................26
Viewing Pictures from Connected Equipment .............................................................................28
Using USB Photo Viewer................................................................................................................29
Using BRAVIA Sync with Control for HDMI..................................................................................30
Using MENU Functions
Navigating through Media Receiver Home Menu (XMB™)..........................................................31
Settings............................................................................................................................................32
Navigating through Monitor Home Menu......................................................................................37
Additional Information
Specifications..................................................................................................................................43
Troubleshooting..............................................................................................................................45
Before operating the TV, please read the “Safety information” section of this manual.
Retain this manual for future reference.
GB

4GB
Start-up Guide
1: Checking the unit and
accessories
Monitor (1)
Media receiver (1)
AC power cord for monitor
AC power cord for AC adaptor
AC adaptor for media receiver (1)
Remote RMF-GA001 (1)
Size AA batteries (R6 type) (2)
IR Blaster (Y-cable) (2)
Stand for media receiver (1)
Terminal cover (1)
Spacers (black) (4)
Table-Top Stand (1) and screws M5 × 8 (4)
Stand Support adaptor (1)
2: Installing the TV
The following steps must be performed to
correspond with the installation steps in the
instruction manual of the optional accessories.
Follow the instructions in this manual
referring to the instruction manual supplied
with the accessories.
Installing on a TV stand
1Remove the Table-Top Stand, accessory
box and accessory bag from the carton.
The screws and booklet can be found in
the accessory bag attached on the rear of
the monitor.
For product protection and safety reasons,
Sony strongly recommends that you use
the screws provided with the display.
~
• Do not remove the blue tape that secures the
plate on the rear of the monitor until you
finish installing the Table-Top Stand.
Table-Top Stand
Accessory box
Monitor
Accessory bag

5GB
Start-up Guide
2Place the Table-Top Stand on a level and
stable surface, then remove the stand
cover.
3Gently slide the monitor onto the neck of
the Table-Top Stand by aligning the F
mark of the plate to the top part of the
Table-Top Stand. Be sure to work with
two or more people.
4Attach the monitor to the Table-Top Stand
using the supplied screws. Attach the two
bottom screws first, then the top two
screws.
~
• If an electric screwdriver is used, set the
torque to tighten at approximately 1.5 N·m
{15 kgf·cm}.
• Do not put stress on the LCD panel or the
frame around the screen.
• Hold the Table-Top Stand firmly with both
hands.
5Connect the AC power cord (supplied) to
the AC IN jack.
~
• Insert the plug fully into the jack.
• When using with an HDMI equipment, also
connect the HDMI cable to the HDMI IN
jack (page 26).
Stand cover
Fmark
Top part
Top screws
Bottom screws
to AC power
outlet
(Continued)

6GB
6Attach the stand cover.
Hang the stand cover over the top of the
Table-Top Stand’s centre post, and then
push down to close until it clicks.
~
• Be sure not to pinch the AC power cord when
attaching the cover.
7Attach the terminal cover.
8Connect the TV to your AC power outlet
(110-240V AC, 50/60Hz).
Removing the Table-Top Stand
If the monitor is to be wall-mounted, remove
the Table-Top Stand.
1Place the monitor face down.
Lay a mat (packing sheet, etc.) on a table
wider than the monitor, then place the
monitor on the table with the stand
hanging over the edge of the table. Be
sure to work with two or more people.
2Remove the four screws from the Table-
Top Stand.
~
• Do not use the screws removed from the
Table-Top Stand for the Wall-Mount
Bracket.
• When you carry the monitor, move the
monitor with a mat laid below.
• Hold the Table-Top Stand firmly with both
hands.
Installing on a wall
Prepare the following items;
– SU-WL700 Wall-Mount Bracket (not supplied)
– SS-WAL700 Speaker System (not supplied)
– Spacers (black) (4) (supplied)
For 4-2 to 4-7 and 5-1 in the following
steps, refer to the corresponding part of the
instruction manual supplied with the Wall-
Mount Bracket.
1Place the supplied spacers (4-2).
1Remove the four screws from the rear of the
monitor.
2Place the spacers (black) on the screw holes
of the previous procedure.
to AC power outlet
to AC power outlet
Packing sheet, etc.
Screw
Spacer

7GB
Start-up Guide
2Follow steps 4-3 to 4-4 referring to the
instruction manual supplied with the
Wall-Mount Bracket.
When using only the Wall-Mount
Bracket
Proceed to the following step 5 in this
manual.
When using the Speaker System
Proceed to the following step 3 in this
manual.
3Lift the Lock Bracket to insert the Speaker
System (4-5).
4Fix the Speaker System with two screws
(supplied with the Speaker System).
5See the instruction manual supplied with
the Wall-Mount Bracket, and follow steps
4-6 to 4-7.
6Connect the AC power cord (supplied) to
the AC IN jack (5-1).
When installing the Speaker System
Fix the AC power cord with the two
hooks, and drop the lead down from the
right edge of the monitor.
~
• When using with an HDMI equipment, also
connect the HDMI cable to the HDMI IN
jack (page 26).
7Follow the instruction manual supplied
with the Wall-Mount Bracket to continue
installing this product on the wall.
~
• You cannot connect the cables to the monitor
after it is wall-mounted.
• When moving the monitor, lift it with a soft
cloth underneath to prevent damage. Do not
hold the speaker.
Mounting Bracket
Speaker System
Lock Bracket Insert to the joint of
the monitor
This part goes on top of the Mounting Bracket
Screws
AC IN
to AC power
outlet

8GB
3: Connecting an antenna/
Set Top Box/recorder (e.g.
DVD recorder) to the Media
Receiver
Connecting an antenna
Connecting a Set Top Box/recorder (e.g.
DVD recorder) with component video
Connecting a Set Top Box/recorder (e.g.
DVD recorder) with HDMI
~
• You can also connect equipment to the HDMI
input on the back side of the monitor.
Connecting the media receiver to the
AC power outlet
~
• Make sure to secure the AC power cord.
Media receiver
Antenna cable
(not supplied)
COMPONENT IN
RLP R /C R P B /C B Y
Set Top Box/recorder (e.g. DVD recorder)
Component
video cable
(not
supplied)
Media receiver
Audio cable
(not supplied) Antenna
cable
(not supplied)
Antenna cable
(not supplied)
IN
Set Top Box/recorder (e.g. DVD recorder)
HDMI cable
(not supplied)
Media receiver
Antenna cable
(not supplied)
Antenna cable
(not supplied)
DCIN 18V
Media receiver
to AC power
outlet

9GB
Start-up Guide
4: Preventing the monitor
from toppling over (only
when placing on a TV stand)
1Remove the screw from the Table-Top
Stand.
2Secure the Stand Support adaptor to the
Table-Top Stand.
3Attach a rope or chain to the adaptor, and
then secure it to the TV stand (not
supplied). Make sure that there is no
excess slack in the rope or chain.
1Install a wood screw (4 mm in diameter, not
supplied) in the TV stand.
2Install a machine screw (M6 × 12-15, not
supplied) into the screw hole of the monitor.
3Tie the wood screw and the machine screw
with a strong cord.

10 GB
5: Performing the initial set-
up
Inserting batteries into the remote
~
• Observe the correct polarity when inserting
batteries.
• Do not use different types of batteries together or
mix old and new batteries.
• Dispose of batteries in an environmentally
friendly way. Certain regions may regulate the
disposal of batteries. Please consult your local
authority.
• Handle the remote with care. Do not drop or step
on it, or spill liquid of any kind onto it.
• Do not place the remote in a location near a heat
source, a place subject to direct sunlight, or a
damp room.
Establishing the wireless
communication between the unit
~
• This unit should be placed in the same room.
• Keep about 30 cm to 20 m distance between the
monitor and media receiver when installing.
• Keep clear the area between the monitor and
media receiver. Otherwise the picture may
deteriorate.
• Rearrange the installation position of the monitor
and media receiver in case of fuzzy picture.
• Do not place either unit on a metallic rack.
• Do not use two units or more at the same time in
an area of radio interference.
1Press 1to turn on the unit power.
2Check the LINK indicator on the media
receiver.
If wireless communication between the
media receiver and monitor is established,
this indicator lights up.
Performing the initial set-up
When you switch on the unit for the first
time, the Language menu appears on the
screen.
Push and lift the cover to open.
POWER button
Media receiver
Monitor
POWER button
LINK
LINK
LINK indicator
1-9
TV
MONITOR
HDMI 2HDMI 1
HDMI
HDMI 3
THEATRE
SYNC MENU
AUDIO
EXT
VIDEO COMPO-
NENT
