Sony KD-65X9500B User manual

3
KD-65/85X9500B

These servicing instructions are for use by qualified service personnel only.
To reduce the risk of electric shock, do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so.
An isolation transformer should be used during any service to avoid possible shock hazard, because of live chassis.
The chassis of this receiver is directly connected to the ac power line.
Be sure to follow these guidelines to protect your property and avoid causing serious injury.
• Carry the TV with an adequate number of people; larger size TVs require two or more people.
C t h d l t hil i th TV i i t t f f t d t id d• Correct hand placement while carrying the TV is very important for safety and to avoid damages.
Components identified by shading and ! mark on the schematic diagrams, exploded views, and in the parts list are critical for safe operation. Replace these components with Sony
parts whose part numbers appear as shown in this manual or in supplements published by Sony. Circuit adjustments that are critical for safe operation are identified in this manual.
Follow these procedures whenever critical components are replaced or improper operation is suspected.
• Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.
O t b k b tt h ld t t t t t• Outer case broken battery should not contact to water.
4
KD-65/85X9500B

WARNINGS AND CAUTIONS
When repairing the LCD panel, be sure you are grounded by using a wrist band.
When repairing the LCD panel on the all the LCD panel m st be sec red sing the 4 mo nting holes on the rear co erWhen repairing the LCD panel on the wall, the LCD panel must be secured using the 4 mounting holes on the rear cover.
1) Do not press on the panel or frame edge to avoid the risk of electric shock.
2) Do not scratch or press on the panel with any sharp objects.
3) Do not leave the module in high temperatures or in areas of high humidity for an extended period of time.
4) Do not expose the LCD panel to direct sunlight.
5) Avoid contact with water. It may cause a short circuit within the module.
6) Disconnect the AC power when replacing the backlight (CCFL) or inverter circuit. (High voltage occurs at the inverter circuit at 650Vrms.)
7) Always clean the LCD panel with a soft cloth material.
8) Use care when handling the wires or connectors of the inverter circuit. Damaging the wires may cause a short.) g g g y
9) Protect the panel from ESD to avoid damaging the electronic circuit (C-MOS).
10) It is recommended not to exceed 1 hour of Power-On nor Burn-in period with LCD panel face down condition, in repair activity.
5
KD-65/85X9500B

After correcting the original service problem, perform the following safety checks before releasing the set to the customer:
1. Check the area of your repair for unsoldered or poorly soldered connections. Check the entire board surface for solder splashes and bridges.
2. Check the interboard wiring to ensure that no wires are “pinched” or touching high-wattage resistors.
3. Check that all control knobs, shields, covers, ground straps, and mounting hardware have been replaced. Be absolutely certain that you have replaced all the insulators.
4. Look for unauthorized replacement parts, particularly transistors, that were installed during a previous repair. Point them out to the customer and recommend their replacement.
5. Look for parts which, though functioning, show obvious signs of deterioration. Point them out to the customer and recommend their replacement.
6. Check the line cords for cracks and abrasion. Recommend the replacement of any such line cord to the customer.6. Check the line cords for cracks and abrasion. Recommend the replacement of any such line cord to the customer.
7. Check the antenna terminals, metal trim, “metallized” knobs, screws, and all other exposed metal parts for AC leakage. Check leakage as described below.
8. For safety reasons, repairing the Power board and/or Inverter board is prohibited.
6
KD-65/85X9500B

SAFETY CHECK-OUT
7
KD-65/85X9500B

The units in this manual contain a self-diagnostic function. If an error occurs, the Smart Core Red LED will automatically begin to flash.
The number of times the LED flashes translates to a probable source of the problem.
A definition of the Smart Core Red LED flash indicators is listed in the instruction manual for the user’s knowledge and reference.
If an error symptom cannot be reproduced, the remote commander can be used to review the failure occurrence data stored in memory to reveal past problems and how often these
DIAGNOSTIC TEST INDICATORS
When an error occurs, the Smart Core Red LED will flash a set number of times to indicate the possible cause of the problem.
If there is more than one error, the LED will identify the first of the problem areas.
problems occur.
Result for all of the following diagnostic items are displayed on screen.
If the screen displays a “0”, no error has occurred .
RED LED blinking count Detection Items
2x <G/B> Main 12V failure [MAIN_POWE]
* This failure is not saved
<G>: Power supply board, <B>: Main board, <T>: Tcon board, <L>: LED driver (LD) board ,
<P>: Panel module , <S>: Speaker , <A>: Power Adapter, <U> Tuner board
* This failure is not saved.
3x
<B> Main 5.0/3.3/1.8/1.0 failure [DC_ALERT]
* 5.0/1.0V failures are not saved.
<B/S> Audio amp. protection / Audio amp. I2C NACK [AUD_ERR]
<B> HDMI equalizer/switch I2C NACK [HDMI_EQ/HDMI_EQ2/HDMI_EQ3] * There is Temp. sensor on the same I2C bus
<B/U> Tuner or demodulator I2C NACK [TU_DEMOD]
3x
<B/U> AFE device I2C NACK [AFE_I2C]
<B/U> AFE device SPI NACK [AFE_SPI] * only for AEP,CH
<B> V-by-One lock monitoring between CXD4746 and NT72324[SC_OUT_ERR]
<B> CXD4746 I2C NACK and V-by-One lock monitoring between CXD4746 and Ayu2[SC_ERR]
<B> FW initialization error and I2C NACK for NT72324[FRCD_I2C]
4x <L/P> LED driver failure [LD_ERR] 4x <L/P> LED voltage error [VLED]
5x
<B/T>Tcon device initialization failure detection [TCON_ERR]
<B/T>Tcon device I2C communication error detection [TCON_ERR]
<P/T/G/B> Panel ID EEPROM I2C NACK (Also panel power failure is a suspect) [P_ID_ERR]
*PCON_ERR and TG_ERR is not used.
6x <G/P/B> Backlight failure [BACKLIGHT] 6x <G/T/P/B> Backlight converter OVP [BACKLIGHT]
7x Over temperature protection [TEMP_ERR]
<B> Temp. sensor I2C NACK [TEMP_ERR] * There is HDMI Eq on the same I2C bus.
8x
Software Error (Also the main boardʼs memory or CAM module is a suspect)
<B> CXD4754 device error and WDT detection [LYON_ERR]
*Even if detecting CXD4745 Device error, the set does not go to safety shutdown (only when user uses CXD4754 function, the set reboots)
8
Even if detecting CXD4745 Device error, the set does not go to safety shutdown (only when user uses CXD4754 function, the set reboots)
and not flash LED, only records error logs.
9x <U>Tuner board error [TU_BOARD]
KD-65/85X9500B

SELF DIAGNOSIS FUNCTION
[SELF DIAGNOSTIC SCREEN DISPLAY]
Error item name *Following error is invalid in RB2.
FAN_ERR
Model Name :KDL-RB2T
Serial Number :1000162
Package Number :PKG0.410EUA
Device ID :B0:00:02:4D:72:88
Wired Mac :D8:D4:3C:A2:EE:9F
SELF CHECK MAC address
of Wi-Fi USB
EMIT_ERR
TCON_ERR
Wired Mac :D8:D4:3C:A2:EE:9F
Wireless Mac :34:23:87:d4:48:a4
USB dongle :N/A
<MAIN> <EXT>
DM0.410EUA WF:3.5.3.9999
WF0.300W00AA WF:---- ----
DF5.137W00AA BT:
YM1 224W00AA 2 1 14 471
002 MAIN_POWE ------------ --- ----- ---- ----- ---- - -- 00
003 AFE_I2C ------- ----- ------------ --- - ---- ---- 00
003 DC_ALERT ------------ - ----- ----- - ---- ---- - --- 00
003 AUD_PROT ------------ -- ---- ----- - ------------ 00
003 HDMI_EQ ------------ - ----- ----- - ------------ 00
003 TU_DEMOD - --------- - - ------------ -- ----- ---- - 00
003 AFE SPI
------------ - ---- ----- -- -- - ---- ----- 00
Error
timestam
p for last
recorded
error
Error
timestam
p for
second
last
recorded
Error
timestam
p for 3rd
last
recorded
error
dongle*1.
YM1.224W00AA 2.1.14.471
M5.503C EFR:03.01.01.18
(DM0.390EUA)
DD0.370W00AA <FS>
PK0.370W00AA SCF:50.10
AM0.410WW ROF:-----------------
MID:2411AB19
PID 0E042040
_
003 SC_OUTERR ------------ - ---------- - ---- ----- --- 00
003 SC_ERR ---- ----- --- ------------ - ---- ----- -- 00
003 FRCD_I2C ------------ ----- ----- -- -- ----- ----- 00
003 HDMI_EQ2 ---- ----- --- -- ---- ----- - ------------ 00
003 HDMI_EQ3
------------ - ---- ----- -- -- - ---- ----- 00
003 LYON_ERR ------------ --- ----- ---- ------------ 00
004 VLED ------------ --- ----- ---- ----- ---- - -- 00
004 LD ERR
------------ - ---- ----- -- -- - ---- ----- 00
Error count
Smart Core
Red LED
blinking count
recorded
error
error
Format of error timestamps
YYMMDDhhmmss (in UTC)
Example: PID:0E042040
PNL:YD4S550LTU010
004 LD_ERR 00
005 TCON_ERR ------------ --- ----- ---- - ---- - ---- -- 00
005 P_ID_ERR ------------ ---- ----- --- ------------ 00
005 PCON_ERR ------------ --- ----- ---- - ---- - ---- -- 00
005 TG_ERR
------------ - ---- ----- -- -- - ---- ----- 00
006 BACKLITE ------------ - ----- ----- - ---- ----- --- 00
007 TEMP_ERR 120823132523 ------------ -- ----- ---- - 01
007 FAN_ERR
------------ - ---- ----- -- -- - ---- ----- 00
008 VPC WDT ------------ - ---- ----- -- -- - ---- ----- 00
g
External module
information
Main CPU
information
*1
Example:
120823132523 -> Aug 23 2012 13:25:23 UTC
* Only when time is set, an error timestamp is saved.
008 VPC_WDT ------------ - ---- ----- -- -- - ---- ----- 00
008 MEPS_WDT ------------ - - ---- ----- - ---- ----- --- 00
008 HOST_WDT ------------ - - ---- ----- - ---- ----- --- 00
008 STBY_WDT ---- ----- --- ------------ ------------ 00
008 AFE_WDT - ----- ----- - ------------ -- ----- ---- - 00
009 TU_BOARD ------------ -- ---- ----- - ------------ 00
00081-000671-00088 00000000000000000570-00000000000000000132
1
1. When no Wi-Fi USB dongle is connected, NA is displayed.
2. If you insert/disconnect Wi-Fi USB Dongle during Self Diagnosis
Display, press <1> -> <4> on remote commander to refresh Mac
address displayed on “USB dongle”.
- Alternatively, you can re-display Self Diagnosis Display to update the
information.
Panel operation time by hour
Count of writing to NAND device:
As vfat partition– As ext4 partition
information.
Panel Operation Time is recorded every 30 min, but Total Operation Time is recorded every 1 hr.
Therefore, the panel op. time might become larger than the total op. time.
9
Total operation time by hour
Boot count
KD-65/85X9500B

SELF DIAGNOSIS FUNCTION
SELF-DIAGNOSTIC SCREEN DISPLAY
For errors with symptoms such as “power sometimes shuts off” or “screen sometimes goes out” that cannot be confirmed, it is possible to bring up past occurrences of failure for
confirmation on the screen:
S[To Bring Up Screen Test]
In standby mode, press buttons on the remote commander sequentially in rapid succession as shown below:
*
* : Note that this differs from entering the service mode (volume +)
Since the diagnostic results displayed on the screen are not automatically cleared always check the self diagnostic screen
Since the diagnostic results displayed on the screen are not automatically cleared, always check the self-diagnostic screen.
After you have completed the repairs, clear the result display to “0”.
Clearing the Self Check Diagnostic List
1. Error history : Press the Channel 8 => Channel 0 .
2. Panel operation time : Press the Channel 7 => Channel 0 .
Exiting the Self-diagnostic screen
To exit the Self Diagnostic screen, turn off the power to the TV by pressing the POWER button on the remote or the POWER button on the TV.
10
KD-65/85X9500B

• There are clutch in the yellow frame[ ]. Therefore please be careful in the case of the disassembly or assembly of parts.
11
KD-65/85X9500B

DISASSEMBLY
1-1-1. STAND
2 Screws (SCREW, +PSW M5X16) P/N: 2-580-608-01 2 Screws (SCREW, +PSW M5X16) P/N: 2-580-608-01
1
2
STAND,RIGHT (2L MIA)
P/N: 4-486-550-02
STAND,LEFT (2L MIA)
P/N: 4-486-545-02
12
KD-65/85X9500B

DISASSEMBLY
1-1-2. CAMERA MODULE EXTERNAL TYPED
1
Screw (SCREW +PSW M4X10) P/N: 4-159-298-01
2CAMERA MODULE
EXTERNAL TYPED
13
KD-65/85X9500B

DISASSEMBLY
1-1-3. COVER, TERMINAL SIDE
2
31
COVER, TERMINAL SIDE
14
KD-65/85X9500B

DISASSEMBLY
1-1-4. COVER, TERMINAL REAR
2
1 3
COVER, TERMINAL REAR
15
KD-65/85X9500B

DISASSEMBLY
1-1-5. LABEL, REAR TERMINAL/LABEL, SIDE TERMINAL
LABEL, SIDE TERMINAL
LABEL REAR TERMINALLABEL, REAR TERMINAL
16
KD-65/85X9500B

DISASSEMBLY
1-1-6. REAR COVER (2L MIA) A 2
1
3
REAR COVER (2L MIA) A
16 Screws (SCREW, +PSW M3X6 STEP) P/N: 4-457-815-02
1 Screw (SCREW, +PSW M4X10) P/N: 4-159-298-01
3 Screws (SCREW, +BVTP 4X12 TYPE2 IT-3) P/N: 2-580-639-01
CATCH, HOOK N
( , )
4 Screws (SCREW, ORNAMENTAL M6X12) P/N: 4-268-126-02
17
KD-65/85X9500B

DISASSEMBLY
1-1-7. TAPE
TAPE
TAPE
TAPETAPE
TAPE
18
KD-65/85X9500B

DISASSEMBLY
1-1-8. WIRE DRESSING
19
KD-65/85X9500B

DISASSEMBLY
1-1-9. TAPE
TAPE
TAPE
20
KD-65/85X9500B

DISASSEMBLY
1-1-10. TAPE
TAPE
TAPE
21
KD-65/85X9500B
