LCD DIGITAL COLOR TELEVISION
SERVICE MANUAL WAX2 CHASSIS
MODEL NAME REMOTE COMMANDER DESTINATION
9-883-730-03
KDL-32S2400 RM-YD005 US/CANADA
KDL-40S2400 RM-YD005 US/CANADA
HISTORY INFORMATION FOR THE FOLLOWING MANUAL:
ORIGINAL MANUAL ISSUE DATE: 9/2006
☛
:UPDATED ITEM
REVISION DATE SUBJECT
9/2006 No revisions or updates are applicable at this time.
1/2007 Corrected PN for BU Boards. Replaced pages 55 & 64.
1/2007 Added new LCD panels for 32” model SN 8,200,001 and up. Replaced page 57.

LCD DIGITAL COLOR TELEVISION
SERVICE MANUAL WAX2 CHASSIS
MODEL NAME REMOTE COMMANDER DESTINATION
9-883-730-03
KDL-32S2400 RM-YD005 US/CANADA
KDL-40S2400 RM-YD005 US/CANADA
Self Diagnosis
Supported model
KDL-40S2400 RM-YD005

3
KDL-32S2400/40S2400
KDL-32S2400/40S2400
TABLE OF CONTENTS
SECTION TITLE PAGE SECTION TITLE PAGE
Specifications ................................................................................. 4
Warnings and Cautions .................................................................. 6
Safety-Related Component Warning .............................................. 7
Safety Check-Out ........................................................................... 9
Self-Diagnostic Function............................................................... 10
SECTION 1: DISASSEMBLY............................................................... 12
1-1. Rear Cover Removal ............................................... 12
1-2. Vesa Bracket Assembly Removal............................ 12
1-3. H1U Board Removal................................................ 13
1-4. G1 Board/G2 Board Removal.................................. 13
1-5. AU Board Removal.................................................. 14
1-6. QT Board Removal .................................................. 14
1-7. QS board and BU Board Removal........................... 15
1-8. H2U Board Removal................................................ 16
1-9. H3U Board and Speaker Removal .......................... 16
1-10. LCD Panel Removal ................................................ 17
SECTION 2: SERVICE ADJUSTMENTS............................................. 18
2-1. Remote Adjustment Buttons and Indicators......................... 18
2-2. Accessing Service Adjustments ........................................... 18
2-2-1. Accessing the Digital Service Adjustment Menus.... 18
2-2-2. Viewing the Digital Module Box
(Q-Box) Service Items ............................................. 19
2-2-3. Accessing the Analog Service Adjustment Menus... 19
2-3. Resetting the User Menu - Factory Reset............................ 20
2-4. Aging Mode .......................................................................... 20
2-5. White Balance Adjustment. .................................................. 21
SECTION 3: DIAGRAMS..................................................................... 22
3-1. Circuit Boards Location ........................................................ 22
3-2. Printed Wiring Boards and
Schematic Diagrams Information ......................................... 22
3-3. Block Diagram...................................................................... 24
3-4. Schematics and Supporting Information .............................. 25
AU Board Schematic Diagram (1 of 2)................................. 25
AU Board Schematic Diagram (2 of 2)................................. 26
BU Board Schematic Diagram (1 of 8)................................. 28
BU Board Schematic Diagram (2 of 8)................................. 29
BU Board Schematic Diagram (3 of 8)................................. 30
BU Board Schematic Diagram (4 of 8)................................. 31
BU Board Schematic Diagram (5 of 8)................................. 32
BU Board Schematic Diagram (6 of 8)................................. 33
BU Board Schematic Diagram (7 of 8)................................. 34
BU Board Schematic Diagram (8 of 8)................................. 35
G1 Board, Power Unit (KDL-32S2400 Only)........................ 37
G2 Board Schematic Diagram (KDL-40S2400 Only) ........... 39
H1U Board Schematic Diagram ........................................... 41
H2U Board Schematic Diagram ........................................... 42
H3U Board Schematic Diagram ........................................... 44
QS Board Schematic Diagram (1 of 5)................................. 45
QS Board Schematic Diagram (2 of 5) ............................... 46
QS Board Schematic Diagram (3 of 5)................................. 47
QS Board Schematic Diagram (4 of 5)................................. 48
QS Board Schematic Diagram (5 of 5)................................. 49
QT Board Schematic Diagram ............................................. 51
3-5. Semiconductors ................................................................... 53
SECTION 4: EXPLODED VIEWS........................................................ 54
4-1. Rear Cabinet and Stand Assembly ..................................... 54
4-2. Chassis ............................................................................... 55
4-3. Speakers .............................................................................. 56
4-4. LCD Panel............................................................................ 57
SECTION 5: ELECTRICAL PARTS LIST............................................ 58
APPENDIX A: ENCRYPTION KEY COMPONENTS..........................A-1

4
KDL-32S2400/40S2400
KDL-32S2400/40S2400
SPECIFICATIONS
Design and specifications are subject to change without notice.
120V-240V AC, 50/60Hz
150W (KDL-32S2400 Only)
200W (KDL-40S2400 Only)
Less than 0.1W
Video (IN) 1/2/3
S Video (4-Pin Mini DIN (VIDEO 1/2 Only)
Y: 1.0 Vp-p, 75 ohms unbalanced, sync negative
C: 0.286 Vp-p (Burst signal), 75 ohms
Video
1.0 Vp-p, 75ohms unbalanced, sync negative
Audio
500 mVrms (100% modulation)
Impedance:47 kilohms
HD/DVD IN 4/5
YPBPR(Component Video)
Y:1.0 Vp-p, 75 ohms unbalanced, sync negative
P
B:0.7 Vp-p, 75 ohms
P
R:0.7 Vp-p, 75 ohms
Signal format: 480i, 480p, 720p, 1080i
AUDIO
500 mVrms (100% modulation)
Impedance: 47 kilohms
Power Requirements
Power Consumption (W)
In Use (Max)
In Standby
HDMI IN 6:
HDMI: Video:480i, 480p, 720p, 1080i
Audio: Two channel linear PCM 32, 44.1 and
48 kHz, 16, 20 and 24 bits
AUDIO: 500 mVrms (100% modulation)
Impedance: 47 kilohms
AUDIO OUT:
500 mVrms (100% modulation)
More than 1 Vrms at the maximum volume setting (Variable)
More than 500 mVrms (Fixed)
PC IN 7:
D-sub 15-pin, analog RGB, 0.7 Vp-p, 75 ohms, positive
PC AUDIO INPUT:
Stereo mini jack, 0.5 Vrms, 1 kilohm
Headphones:
Stereo mini jack
Impedance: 16 ohms
Trademark Information
TruSurround XT, SRS and ( ) symbol are trademarks of SRS Labs, Inc.
TruSurround XT technology is incorporated under license from SRS Labs,
Inc.
Manufactured under license from BBE Sound, Inc.
Licensed by BBE Sound, Inc. under one or more of the following US
patents: 5510752, 5736897. BBE and BBE symbol are registered
trademarks of BBE Sound, Inc.
Macintosh is a trademark licensed to Apple Computer, Inc., registered in
the U.S.A and other countries.
“BRAVIA” and are trademarks of Sony Corporation.
As an ENERGY STAR®Partner, Sony Corporation has
determined that this product meets the ENERGY STAR®
guidelines for energy efficiency.
ENERGY STAR®is a U.S. registered mark.
This TV incorporates High-Definition
Multimedia Interface (HDMI™) technology.
HDMI, the HDMI logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing, LLC.
Manufactured under license from Dolby
Laboratories. “Dolby” and the double-D symbol are
trademarks of Dolb
y
Laboratories.

5
KDL-32S2400/40S2400
KDL-32S2400/40S2400
Television system
NTSC American TV Standard
ATSC (8VSB terrestrial) ATSC compliant 8VSB
QAM on cable ANSI/SCTE 07 2000
Channel coverage
Analog Digital
Terrestrial 2-69 2-69
Cable 1-125 1-135
Antenna
75-ohm external terminal for VHF/UHF
Panel System
LCD (Liquid Crystal Display) Panel
Display Resolution (horizontal x vertical):
1,366 dots x 768 lines
Screen Size (measured diagonally)
32 inches (KDL-32S2400 Only)
40 inches (KDL-40S2400Only)
Supplied Accessories
Remote Commander RM-YD005
Two Size AA (R6) Batteries
75-ohm coaxial cable
AC Power Cord
HD15-HD15 Cable
Suport Belt, Securing Screw, and Wood Screw
Cable Holder
Operating Instructions
Quick Setup Guide
Warranty Card
Optional Accessories
Headphones Plug Adapter
Connecting Cables
Wall-Mount Bracket
SU-WL31 (KDL-32S2400 Only)
SU-WL51 & SU-PW2 (KDL-40S2400 Only)
 








  
  


  
   


  
   
!

"  
#$  

"  
#$  


6
KDL-32S2400/40S2400
KDL-32S2400/40S2400
WARNINGS AND CAUTIONS
CAUTION
These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any
servicing other than that contained in the operating instructions unless you are qualified to do so.
WARNING!!
An isolation transformer should be used during any service to avoid possible shock hazard, because of live chassis. The chassis of
this receiver is directly connected to the ac power line.
!SAFETY-RELATED COMPONENT WARNING!!
Components identified by shading and ! mark on the schematic diagrams, exploded views, and in the parts list are critical for safe
operation. Replace these components with Sony parts whose part numbers appear as shown in this manual or in supplements
published by Sony. Circuit adjustments that are critical for safe operation are identified in this manual. Follow these procedures
whenever critical components are replaced or improper operation is suspected.
ATTENTION!!
Ces instructions de service sont à l’usage du personnel de service qualifié seulement. Pour prévenir le risque de choc électrique, ne
pas faire l’entretien autre que celui contenu dans le Mode d’emploi à moins que vous soyez qualifié faire ainsi.
Afin d’eviter tout risque d’electrocution provenant d’un chássis sous tension, un transformateur d’isolement doit etre utilisé lors de tout
dépannage. Le chássis de ce récepteur est directement raccordé à l’alimentation du secteur.
!ATTENTION AUX COMPOSANTS RELATIFS A LA SECURITE!!
Les composants identifies par une trame et par une marque ! sur les schemas de principe, les vues explosees et les listes de pieces
sont d’une importance critique pour la securite du fonctionnement. Ne les remplacer que par des composants Sony dont le numero
de piece est indique dans le present manuel ou dans des supplements publies par Sony. Les reglages de circuit dont l’importance
est critique pour la securite du fonctionnement sont identifies dans le present manuel. Suivre ces procedures lors de chaque
remplacement de composants critiques, ou lorsqu’un mauvais fonctionnement suspecte.

7
KDL-32S2400/40S2400
KDL-32S2400/40S2400
SAFETY-RELATED COMPONENT WARNING
There are critical components used in LCD color TVs that are important for safety. These components are identified with shading and
!
mark on the schematic diagrams and the electrical parts list. It is essential that these critical parts be replaced only with the part number
specified in the electrical parts list to prevent electric shock, fire, or other hazard.
NOTE: Do not modify the original design without obtaining written permission from the manufacturer or you will void the original parts and
labor guarantee.
USE CAUTION WHEN HANDLING THE LCD PANEL
When repairing the LCD panel, be sure you are grounded by using a wrist band.
When installing the LCD panel on a wall, the LCD panel must be secured using the 4 mounting holes on the rear cover.
To avoid damaging the LCD panel:
 do not press on the panel or frame edge to avoid the risk of electric shock.
do not scratch or press on the panel with any sharp objects.
do not leave the module in high temperatures or in areas of high humidity for an extended period of time.
do not expose the LCD panel to direct sunlight.
avoid contact with water. It may cause a short circuit within the module.
disconnect the AC adapter when replacing the backlight (CCFL) or inverter circuit.
(High voltage occurs at the inverter circuit at 650Vrms.)
always clean the LCD panel with a soft cloth material.
use care when handling the wires or connectors of the inverter circuit. Damaging the wires may cause a short.
protect the panel from ESD to avoid damaging the electronic circuit (C-MOS).
LEAKAGE CURRENT HOT CHECK CIRCUIT

8
KDL-32S2400/40S2400
KDL-32S2400/40S2400
The circuit boards used in these models have been processed using
Lead Free Solder. The boards are identified by the LF logo located
close to the board designation e.g. H1 etc [ see example ]. The
servicing of these boards requires special precautions to be taken as
outlined below.
example 1
It is strongly recommended to use Lead Free Solder material in order to guarantee optimal quality of new solder joints.
Lead Free Solder is available under the following part numbers :
Due to the higher melting point of Lead Free Solder the soldering iron tip temperature needs to be set to 370 degrees centigrade.
This requires soldering equipment capable of accurate temperature control coupled with a good heat recovery characteristics.
For more information on the use of Lead Free Solder, please refer to
http://www.sony-training.com
rebmuntraP retemaiD skrameR
91-500-046-7mm3.0gK52.0
02-500-046-7mm4.0gK05.0
12-500-046-7mm5.0gK05.0
22-500-046-7mm6.0gK52.0
32-500-046-7mm8.0gK00.1
42-500-046-7mm0.1gK00.1
52-500-046-7mm2.1gK00.1
62-500-046-7mm6.1gK00.1

9
KDL-32S2400/40S2400
KDL-32S2400/40S2400
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer:
1. Check the area of your repair for unsoldered or poorly soldered
connections. Check the entire board surface for solder splashes and
bridges.
2. Check the interboard wiring to ensure that no wires are “pinched” or
touching high-wattage resistors.
3. Check that all control knobs, shields, covers, ground straps, and
mounting hardware have been replaced. Be absolutely certain that
you have replaced all the insulators.
4. Look for unauthorized replacement parts, particularly transistors,
that were installed during a previous repair. Point them out to the
customer and recommend their replacement.
5. Look for parts which, though functioning, show obvious signs of
deterioration. Point them out to the customer and recommend their
replacement.
6. Check the line cords for cracks and abrasion. Recommend the
replacement of any such line cord to the customer.
7. Check the antenna terminals, metal trim, “metallized” knobs, screws,
and all other exposed metal parts for AC leakage. Check leakage as
described below.
Leakage Test
The AC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microamperes).
Leakage current can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’ instructions to use these
instructions.
2. A battery-operated AC milliampmeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a VOM
or battery-operated AC voltmeter. The “limit” indication is 0.75
V, so analog meters must have an accurate low voltage scale.
The Simpson’s 250 and Sanwa SH-63TRD are examples of
passive VOMs that are suitable. Nearly all battery-operated digital
multimeters that have a 2 VAC range are suitable (see Figure A).
How to Find a Good Earth Ground
A cold-water pipe is a guaranteed earth ground; the cover-plate
retaining screw on most AC outlet boxes is also at earth ground. If the
retaining screw is to be used as your earth ground, verify that it is at
ground by measuring the resistance between it and a cold-water pipe
with an ohmmeter. The reading should be zero ohms.
If a cold-water pipe is not accessible, connect a 60- to 100-watt
trouble- light (not a neon lamp) between the hot side of the receptacle
and the retaining screw. Try both slots, if necessary, to locate the hot
side on the line; the lamp should light at normal brilliance if the screw
is at ground potential (see Figure B).
To Exposed Metal
Parts on Set
0.15 µF
Earth Ground
AC
Voltmeter
(0.75V)
Trouble Light
AC Outlet Box Ohmmeter
Cold-water Pipe
Figure A. Using an AC voltmeter to check AC leakage. Figure B. Checking for earth ground.

10
KDL-32S2400/40S2400
KDL-32S2400/40S2400
SELF-DIAGNOSTIC FUNCTION
Self Diagnosis
Supported model
Control Buttons
PIC OFF/TIMER STANDBY POWER
TV/VIDEO
VOLUME
MENU
CHANNEL POWER
Description of LED Indictors
LED LED Type Description
* Light is green when the TV set is on
* Functions as failure indicator
*Blinks green in aging mode
TIMER LED Red LED Lights when timer is set
PIC OFF LED Green LED Lights when power saving setting is set to
picture off (See Instruction Manual)
POWER LED Red/Green LED

11
KDL-32S2400/40S2400
KDL-32S2400/40S2400
LED Control
   





    
    

   



    
  


  


  


  


  


   

   





 
The units in this manual contain a self-diagnostic function. If an error occurs, the POWER LED will automatically begin to flash. The number of times
the LED flashes translates to a probable source of the problem. A definition of the POWER LED flash indicators is listed in the instruction manual for
the user’s knowledge and reference. If an error symptom is difficult to reproduced use the Remote Commander to display the record that is stored at
the internal NVM to specify the cause of the failure.
Diagnostic Test Indicators
When an error occurs, the POWER LED will flash a set number of times to indicate the possible cause of the problem. If there is more than one error,
the LED will identify the first of the problem areas. If the errors occur simultaneously, the one that corresponds to the fewest flashes is identified first.
Results for all of the following diagnostic items are displayed on screen. No error has occurred if the screen displays a “0”.

 
 
 
 
 
 
 
 
 

12
KDL-32S2400/40S2400
KDL-32S2400/40S2400
SECTION 1: DISASSEMBLY
1-1. REAR COVER REMOVAL
1-2. VESA BRACKET ASSEMBLY REMOVAL
2
3 Screws, M5X16 (KDL-32S2400 ONLY)
4 Screws, M5X16 (KDL-40S2400 ONLY)
1
One Screw, M4X16
(KDL-32S2400 ONLY)
2 Screws, M5X16
(KDL-40S2400 ONLY)
1
One Screw, M4X16
(KDL-32S2400 ONLY)
2 Screws, M5X16
(KDL-40S2400 ONLY)
Stand Assembly
VESA Bracket Assembly (L)
Rear Cover
2 Screws,
+PSW M6X16
1
2 Screws,
+BVPT 3X12 TYPE2 IT-3
2
12 Screws,
+BVPT2 4X16
3

13
KDL-32S2400/40S2400
KDL-32S2400/40S2400
1-3. H1U BOARD REMOVAL
1-4. G1 BOARD/G2 BOARD REMOVAL
1
2 Screws,
+BVTP2 4X16
H1U Board
Multi Button Assy
Disconnect CN101
1
2 Screws, +BVTP 3X12 TYPE2 IT-3
(KDL-32S2400 ONLY)
4 Screws, +PSW 3SG
(KDL-40S2400 ONLY)
G1 Board
(KDL-32S2400 ONLY)
G2 Board
(KDL-40S2400 ONLY)
G1 Bracket
(KDL-32S2400 ONLY)
G2 Bracket
(KDL-40S2400 ONLY)
Disconnect CN6102, CN6202 AND CN6203
(KDL-32S2400 ONLY)
Disconnect CN6001, CN6200 AND CNCN6202
(KDL-40S2400 ONLY)

14
KDL-32S2400/40S2400
KDL-32S2400/40S2400
1-5. AU BOARD REMOVAL
1-6. QT BOARD REMOVAL
2
4 Screws,
+PSW 3SG
1
2 Screws,
+BVTP 3X12 TYPE2 IT-3
Disconnect CN9502, CN9501,
CN7502, CN7501, CN7000,
CN7503 and CN9532
AU Board
Disconnect CN7803 and CN7800
3
One Screw,
+PSW M3x5
2
3 Screws,
+BVTP 3X12 TYPE2 IT-3
1
One Screw,
+PSW 3SG
QT Board

15
KDL-32S2400/40S2400
KDL-32S2400/40S2400
1-7. QS BOARD AND BU BOARD REMOVAL
6
2 Screws,
+PSW M3X5
3
2 Screws,
+PSW M3X5
2
One Screw,
+BVST 3X8
1
3 Screws,
+PSW 3SG
5
2 Screws,
+PSW 3SG
4
2 Screws,
+BVST 3X8
DTT Shield Bottom
BU Board
Disconnect CN7009, CN1007,
CN5000, CN4701, CN4702,
CN1700, CN1001, CN7008,
CN1008 and CN1002
QS Board
Disconnect
CN7314, CN7306,
CN7802 and CN7317

16
KDL-32S2400/40S2400
KDL-32S2400/40S2400
1-8. H2U BOARD REMOVAL
5
One Screw,
+PSW M4X8
3
2 Screws,
+BVTP2 4X16
2
2 Screws,
+BVTP2 4X16
1
4 Screws,
+PSW M5X8
4
2 Screws,
+KTT 3X10
Speaker
Speaker
H3U Board
Disconnect CN301
Bottom Frame Assembly
AC Inlet
Under Cover
1-9. H3U BOARD AND SPEAKER REMOVAL
Side Terminal Assembly
H2U Board
Disconnect CN201
1
2 Screws,
+BVTP 3x12 TYPE2 IT-3
1
2 Screws,
+BVTP 3x12 TYPE2 IT-3
Side Jack Holdeer

17
KDL-32S2400/40S2400
KDL-32S2400/40S2400
1-10. LCD PANEL REMOVAL
2
LCD Panel
Harness with Connector (LVDS)
Bezel Assembly
2 Screws,
+PSW M4X8
2 Screws,
+PSW M5X8
4 Screws,
+PVTP2 4X12
3
Top Frame
(KDL-40S2400 ONLY)
(KDL-32S2400 ONLY)
Top Frame
Assembly
4
One Screw,
+BVTP2 4X16
1

18
KDL-32S2400/40S2400
KDL-32S2400/40S2400
2-1. REMOTE ADJUSTMENT BUTTONS AND
INDICATORS
RM-YDOO5
POWER
DIGITAL/
ANALOG
Onscreen cursor
and select button
DISPLAY
RM-YD005
5
VOLUME+
SECTION 2: SERVICE ADJUSTMENTS
2-2. ACCESSING SERVICE ADJUSTMENTS
To adjust various set features, use the Remote Commander to put the set
into service mode to display the service menus. The Remote Commander
displays the service menu associated with the Digital or Analog format
depending on which format is on the TV when you enter service mode.
2-2-1. ACCESSING THE DIGITAL SERVICE
ADJUSTMENT MENUS
1. Turn the TV on and view a Digital channel.
2. Put the TV in standby mode. (Power off).
3. Press the following buttons on the Remote Commander within a
second:
DISPLAY Channel
5 Volume
+POWER On.
The Digital service menu displays.
Video 1
MAIN VER. 1009
H PACK VER. 1008
S PACK VER. 1008
CHECK SUM E20E
NVM VER. 1006
ATI VER. 01.06
ATI UD NVM VER. 02
ATI SD NVM VER. 02
ETI 46h 39m
4. Use the button to view the next category listing the white balance
adjustment items.
Video 1
R_DRIVE 256
B_DRIVE 256
R_BKG 512
G_BKG 512
B_BKG 512
COLOR SAVE
5. Use the or button to select the item you want to adjust.
a. To increase the data value of the category, press the button.
b. To decrease the data value of the category, press the button.
6. To save the data value changes, press the button to select Color
Save and then press the button.
a. To save the data value changes, select Save by pressing the
button and then press the button.
b. To cancel the data value changes, select Cancel by pressing
the button and then pressing the button.

19
KDL-32S2400/40S2400
KDL-32S2400/40S2400
2-2-2. VIEWING THE DIGITAL MODULE BOX
(Q-BOX) SERVICE ITEMS
Use the following instructions to display the Digital menu items you want
to adjust.
1. Turn the TV on and view a Digital channel.
2. Put the TV in standby mode. (Power off).
3. Press the following buttons on the Remote Commander within a
second:
DISPLAY Channel
5 Volume
+POWER On.
The Digital service menu displays.
Video 1
MAIN VER. 1009
H PACK VER. 1008
S PACK VER. 1008
CHECK SUM E20E
NVM VER. 1006
ATI VER. 01.06
ATI UD NVM VER. 02
ATI SD NVM VER. 02
ETI 46h 39m
4. To display the Digital Module (Q Box) service adjustment menus,
press JUMP .
The QM category displays.
Category
Item
SERVICE
DTVINFO
QM
Item #
Data Value
Sample DMB (Q Box) Service Menu
00
5. To change the category, press 2or 5on the Remote Commander.
Note: Pressing 2or 5only changes the categories within the service
menu displayed. To return to the Digital Service Menu, press the
JUMP button.
6. To change the adjustment item, press 1or 4on the Remote
Commander.
7. To change the data value, press 3or 6on the Remote Commander.
Note: To go back to the last saved data value, press 0then ENTER
on the Remote Commander to read the memory.
8. To write into memory, press MUTING then ENT on the Remote
Commander.
9. To exit service mode, turn the power off.
2-2-3. ACCESSING THE ANALOG SERVICE
ADJUSTMENT MENUS
1. Turn the TV on and view an Analog channel.
2. Put the TV in standby mode. (Power off).
3. Press the following buttons on the Remote Commander within a
second:
DISPLAY Channel
5 Volume
+POWER On.
The Analog service menu displays.
Video 1
MAIN VER. 1008
H PACK VER. 1005
S PACK VER. 1008
CHECK SUM F99F
NVM VER. 1006
ATI VER.
ATI UD NVM VER.
ATI SD NVM VER. 02
ETI 2h 16m
4. Use the button to view the next category listing the white balance
adjustment items.
Video 1
R_DRIVE 256
B_DRIVE 256
R_BKG 512
G_BKG 512
B_BKG 512
COLOR SAVE
5. Use the or button to select the item you want to adjust.
a. To increase the data value of the category, press the button.
b. To decrease the data value of the category, press the
button.
6. To save the data value changes, press the button to select Color
Save and then press the button.
a. To save the data value changes, select Save by pressing the
button and then press the button.
b. To cancel the data value changes, select Cancel by pressing
the button and then pressing the button.

20
KDL-32S2400/40S2400
KDL-32S2400/40S2400
2-3. RESETTING THE USER MENU - FACTORY
RESET
The TEST RESET option resets all the customer adjustable data back to the
factory defaults.
1. Put the TV in standby mode. (Power off).
2. Press the following buttons on the Remote Commander within a second:
DISPLAY Channel
5 Volume
+POWER On.
The service menu displays.
2-4. AGING MODE
Aging mode is designed to remove image retention from the screen.
NOTE: Once you enter into Aging Mode the Remote Commander no
longer functions with the set. To turn off the set, push the Power Button
on the set.
1. Put the TV in standby mode. (Power off).
2. Press the following buttons on the Remote Commander within a
second:
DISPLAY Channel
5 Volume
+POWER On.
The service menu displays.
Video 1
MAIN VER. 1009
H PACK VER. 1008
S PACK VER. 1008
CHECK SUM E20E
NVM VER. 1006
ATI VER. 01.06
ATI UD NVM VER. 02
ATI SD NVM VER. 02
ETI 46h 39m
3. Use the button to view the next category listing the white balance
adjustment items.
Video 1
R_DRIVE 256
B_DRIVE 256
R_BKG 512
G_BKG 512
B_BKG 512
COLOR SAVE
4. Continue pressing the button until the next category list displays.
Video 1
TEST RESET
AGING MODE Off
AUTO SHUT-OFF On
ETI CLEAR
INFORMATION RESET
SOUND MUTE On
5. Press the button to select AGING MODE.
6. Press the button to display the Aging Mode options.
7. Press the button to select ON.
8. Press the button to start the aging process.
Video 1
MAIN VER. 1009
H PACK VER. 1008
S PACK VER. 1008
CHECK SUM E20E
NVM VER. 1006
ATI VER. 01.06
ATI UD NVM VER. 02
ATI SD NVM VER. 02
ETI 46h 39m
3. Use the button to view the next category listing the white balance
adjustment items.
Video 1
R_DRIVE 256
B_DRIVE 256
R_BKG 512
G_BKG 512
B_BKG 512
COLOR SAVE
4. Continue pressing the button until the next category list displays.
Video 1
TEST RESET
AGING MODE Off
AUTO SHUT-OFF On
ETI CLEAR
INFORMATION RESET
SOUND MUTE On
5. Press the button to select TEST RESET options.
6. Press the button to select OK.
7. Press the button to reset the TV.
