4-174-669-11(1)
LCD
Digital Colour TV
Operating Instructions GB
操作手冊 CT
KDL-46EX500 / 40EX500 / 40EX400 / 32EX500 / 32EX400

2GB
Introduction
Thank you for choosing this Sony product.
Before operating the TV, please read this
manual thoroughly and retain it for future
reference.
~
•The illustrations used in this manual are
of the KDL-40EX500 unless otherwise
state.
•In this manual, following models are
described as EX500 models.
KDL-32/40/46EX500
Following models are described as
EX400 models.
KDL-32/40EX400
Trademark information
HDMI, the HDMI logo and High-
Definition Multimedia Interface are
trademarks or registered trademarks of
HDMI Licensing LLC.
DivX® is a video file compression
technology, developed by DivX, Inc.
DivX, DivX Certified, and associated
logos are trademarks of DivX, Inc. and are
used under license.
ABOUT DIVX VIDEO: DivX® is a
digital video format created by DivX,Inc.
This is an official DivX Certified device
that plays DivX video. Visit
www.divx.com for more information and
software tools to convert your files into
DivX video.
ABOUT DIVX VIDEO-ON-DEMAND:
This DivX Certified® device must be
registered in order to play DivX Video-on-
Demand (VOD) content. To generate the
registration code, locate the DivX VOD
section in the device setup menu. Go to
vod.divx.com with this code to complete
the registration process and learn more
about DivX VOD.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D
symbol are trademarks of Dolby
Laboratories.
“BRAVIA” and are
trademarks of Sony Corporation.
“XMB” and “xross media bar” are
trademarks of Sony Corporation and Sony
Computer Entertainment Inc.
The typefaces used on the screen display
are solely developed by DynaComware.
This television is designed for
use in Hong Kong and ensured
the usage in Hong Kong only.

3GB
Table of Contents
Checking the accessories.............................................................................................................. 3
Inserting batteries into the remote................................................................................................. 3
Setting Up
Attaching the Table-Top Stand...................................................................................................... 4
Connecting an antenna (aerial)/cable/VCR................................................................................... 4
Preventing the TV from toppling over ............................................................................................5
Connecting the AC power cord (mains lead)................................................................................. 6
Performing the initial set-up........................................................................................................... 6
Detaching the Table-Top Stand from the TV................................................................................. 7
Watching TV
To watch programmes................................................................................................................... 8
To utilise the TV’s features ............................................................................................................ 8
To use i-Manual............................................................................................................................. 9
Additional Information
Troubleshooting........................................................................................................................... 10
Specifications .............................................................................................................................. 11
Installing the Accessories (Wall-Mount Bracket) ......................................................................... 12
Safety Information ....................................................................................................................... 15
Precautions.................................................................................................................................. 16
Checking the accessories
AC power cord (mains lead)
(for KDL-46EX500)
Remote (1)
Size AAA batteries (R3 type) (2)
Table-Top Stand (1)*
Fixing screws for stand (M5 × 16) (4)
Assembling screws for stand
(M5 × 16) (4)
(only for KDL-40/32EX500)
Assembling screws for stand
(M4 × 10) (3)
(only for EX400 models)
* Disassembled except for 46-inch TV.
Refer to the supplied Table-Top Stand leaflet to
assemble the stand.
Inserting batteries into the
remote
RM-GD009 remote
RM-GD015 remote
~
•See your remote for the model number.
• Operating instructions are built into your BRAVIA TV. Refer to “To use i-Manual” for operation (page 9).
• Before operating the TV, please read “Safety Information” (page 15). Retain this manual for future reference.
Slide the cover to open.
Push and lift the cover to open.

4GB
Setting Up
Attaching the Table-Top
Stand
1Refer to the supplied Table-Top Stand
leaflet for proper attachment for some
TV models.
2Place the TV set on the Table-Top
Stand.
3Fix the TV to the Table-Top Stand
according to the arrow marks that
guide the screw holes using the
supplied screws.
~
•If using an electric screwdriver, set the tightening
torque at approximately 1.5 N·m {15 kgf·cm}.
Connecting an antenna
(aerial)/cable/VCR
Connecting an antenna (aerial)/cable
Antenna (aerial) cable
(not supplied)
Antenna (aerial) cable
(not supplied)

5GB
Connecting an antenna (aerial)/cable
and VCR Preventing the TV from
toppling over
1Install a wood screw (4 mm in
diameter, not supplied) in the TV stand.
2Install a machine screw (M4 × 16, not
supplied) into the screw hole of the TV.
3Tie the wood screw and the machine
screw with a strong cord (not supplied).
z
•An optional Sony support belt kit is used to secure
the TV. Contact your nearest Sony service centre
to purchase a kit. Have your TV model name
ready for reference.
Antenna
(aerial) cable
(not supplied)
Antenna
(aerial) cable
(not supplied)
AV cable
(not supplied)
VCR
Setting Up

6GB
Connecting the AC power
cord (mains lead)
~
•Do not bundle the AC power cord (mains lead)
together with other cables.
Performing the initial set-up
1Connect the TV to your AC power
outlet (mains socket).
2Press 1on the TV.
When you switch on the TV for the first
time, the Language menu appears on the
screen.
Follow the instructions on the screen.
Programme Sorting: Changes the order of
analogue channels stored in the TV.
1Press F/fto select the channel you want
to move to a new position, then press .
2Press F/fto select the new position for
the channel, then press .
~
•You can also tune channels manually.
12
*For KDL-46EX500
*
3

7GB
Detaching the Table-Top
Stand from the TV
~
•Remove the screws guided by the arrow marks
of the TV.
•Do not remove the Table-Top Stand for any
reason other than to install corresponding
accessories on the TV.
Setting Up

8GB
Watching TV
To watch programmes
To utilise the TV’s features
z
•The number 5, N, PROG + and AUDIO
buttons on the remote have a tactile dot.
Use the tactile dots as a reference when
operating the TV.
1Turn on the TV.
Press 1on the TV to turn on the TV.
2Select a mode.
3Select a TV channel.
Using Digital Electronic Programme
Guide
Press GUIDE in digital mode to display the
programme guide.
HOME button
Press to display various operation and setting
screens.
OPTIONS button
Press to display convenient functions based
on the current input or content.
GUIDE
HOME
2
3
OPTIONS
Settings
TV
System Settings
Sound
BRAVIA ENGINE 3 PRO
Add to Favourites
Lock/Unlock
PAP
Motionflow
Sleep Timer
Headphone Volume
Speaker
System Information

9GB
To use i-Manual
xWelcome to i-Manual
xBRAVIA TV Features
xWatching TV
Introduces convenient features such as EPG
Guide, Favourites, etc.
xUsing the HOME Menu
Customise your TV settings, etc.
xFun Features with Connected
Equipment
Introduces how to connect optional equipment.
xParts Description
xTroubleshooting
Find solutions for your problem.
xIndex
~
•Images and illustrations may differ from what is displayed on the screen.
Operating instructions are built into your BRAVIA
TV and can be displayed on the screen.
You can browse your i-Manual anytime you need
to find the varieties of convenient functions.
1Press i-MANUAL.
2Press G/g/F/f/ to select items.
1
2
Watching TV

10 GB
Additional Information
Troubleshooting
Check whether the 1(standby) indicator is flashing in red.
When the 1(standby) indicator is flashing
The self-diagnosis function is activated.
1Count how many times the 1(standby) indicator flashes between each two second
break.
For example, the indicator may flash three times, go off for two seconds, then flash again three
times.
2Press 1on the TV to turn it off, disconnect the AC power cord (mains lead), and inform
your dealer or Sony service centre of how the indicator flashes (number of flashes).
When the 1(standby) indicator is not flashing
1Check the items in the tables below. (Also refer to “Troubleshooting”in the i-Manual.)
2If the problem persists, have your TV serviced by qualified service personnel.
Condition Explanation/Solution
There is no picture (screen
is dark) and no sound.
•Check the antenna (aerial)/cable connection.
•Connect the TV to the AC power (mains), and press 1on the TV.
•If the 1(standby) indicator lights up in red, press "/1.
Tiny black points and/or
bright points appear on the
screen.
•The screen is composed of pixels. Tiny black points and/or bright
points (pixels) on the screen do not indicate a malfunction.
General
The TV turns off
automatically (the TV
enters standby mode).
•Check if the “Sleep Timer” is activated, or confirm the
“Duration” setting of “On Timer”.
•Check if the “Idle TV Standby” is activated.
The remote does not
function.
•Replace the batteries.
The “Parental Lock” password
has been forgotten.
•Enter 9999 for the PIN code. (PIN code 9999 is always accepted.)
