KDL- 22L5000
22" Class BRAVIA L Series LCD TV (21.6" Diagonally)
®
Key Features
16:9 720p resolution panel (1366 x 768)
Dynamic Contrast Ratio: 8,000:1
Advanced Contrast Enhancer with Dynamic
Backlight Control
HDMI ™connection x 3 (1080/60p capable)
1
PC Input x 1
4
HD Component x 2 (1080/60i capable)
ATSC ™/NTSC tuner with QAM
5
Exceeds ENERGY STAR 3.0 requirements
®
24p True Cinema™capable
BRAVIA Link compatible
®
6
BRAVIA Sync capable
®
2
VESA compatible hole spacing
®
Key Technologies
16:9 720p Resolution Panel (1366 x 768) 16:9 720p resolution panel (1366 x 768) provides crisp,
detailed, and vibrant images for movies, sports, and prime - time HD television broadcasts.
Dynamic Contrast Ratio 8,000:1
HDMI™connection x 3 (1080/60p capable) Get versatile HDMI connection options with three
HDMI inputs (up to 1080/60p input capable) . Connect a Sony PLAYSTATION 3 entertainment
system, Blu - ray Disc™player, or any other HDMI - capable equipment and get uncompressed digital
video and multi - channel digital audio on a single cable.
1
®
®
HD Component x 2 (1080/60p capable) Two Component YPbPr (1080/60i capable) inputs
provide added HD - capable connectivity
One PC input (HD-15 pin) One PC input (HD - 15 pin) offers the added versatility to use your HDTV as
a computer monitor .
4
BRAVIA Sync capable BRAVIA Sync capability combines the one - touch access and control
functionality of BRAVIA Theatre Sync™with the ability to control CEC - enabled Sony Handycam
camcorders using the TV’s remote and an on - screen display via HDMI connector .
®
®
®
2
ENERGY STAR 3.0 Sony L - series HDTVs exceed Energy Star 3.0 requirements.
®
®
24p True Cinema™ 24p True Cinema mode provides a direct connection to 24p video sources,
avoiding conversions and allowing users to enjoy films at their intended 24 fps (frames per second)
cinematic picture quality when using a 24p - capable output device, such as a Blu - ray Disc™player or
PLAYSTATION 3 entertainment system.
®
Dynamic Backlight Control The Dynamic Backlight Control feature adjusts the brightness of the
backlight both to optimize image quality and reduce power consumption. It works in real time,
controlling both bright outdoor images and dark interior shots scene by scene for up to a 50 percent
reduction in power use.
ATSC ™/ NTSC tuner with QAM A built - in ATSC™/NTSC tuner with QAM delivers over - the - air digital TV
and unencrypted HDTV broadcast signals, as well as traditional analog TV broadcasts .
5
VESA compatible hole spacing VESA compatible hole spacing uses an industry - standard
mounting hole pattern that can be used with VESA - compliant mounting brackets, taking the
guesswork out of selecting the proper hardware for hanging your TV on the wall.
®
®

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 06/13/2009
KDL- 22L5000
22" Class BRAVIA L Series LCD TV (21.6" Diagonally)
®
Please visit the Dealer Network for current
information at www.sony.com/dn
Features
General
ClosedCaptions(CC): Analog, Digital
On - ScreenDisplay: Traditional
AutoCConMute: Yes
Finish(SurfaceColor): Black
DemoMode: Yes
BRAVIA® LinkModule support: Yes(except BRAVIA® InternetVideo Link)
Display
BacklightType: CCFL
DisplayDevice: LCD
Video
CineMotion ® Reverse3:2PulldownTechnology: Yes
WideMode: Normal, Zoom, Wide Zoom, Full (Full1 - 2for PC)
3DCombFilter: Yes
AutoWide: Yes
4:3Default: Yes
24p True Cinema ™ Technology: Yes
PictureMode: Vivid, Standard, Cinema
AdvancedContrastEnhancer (ACE): Yes
Audio
DigitalAmplifier: Standard
AutoSAP: Yes
AutoMute(on no signal): Yes
SteadySound ® AutomaticVolumeControl: Yes
AudioOut: Fixed
StereoSystem: MTS
Dolby® : Dolby®Digital
AlternateAudio(Digital): Yes
5.1ChannelAudioOut: Yes
SoundMode: Dynamic,Standard, Clear Voice
5.1chThroughOut(Handycam): Yes
Convenience
ChannelJump: Yes
FavoriteChannel: Yes
MultipleLanguageDisplay: English, French, Spanish
InfoBanner: PSIP,XDS
SleepTimer: Yes
InputSkip: Manual
ChannelSurf: Yes
ChannelBlock(withpassword): Yes
EditChannelLabels: Yes
LabelInputs: Yes
ID - 1Detection: Yes
TheatreMode(Theatre Button): Yes
Show/HideChannels: Yes
BRAVIA®Sync™ : Yes
ParentalControl: Yes
BRAVIA®Sync™MenuButton: Yes(onRemote Control)
On - ScreenDisplayforExternalInput: Yes
PIP(Picture in Picture): PCInput/TV Channel
ChannelLabels: Yes
ProgramBlock: Yes
Controlfor HDMI™ ( HDMI™ CEC): Yes
ShortBanner: Yes
PictureAdjustmentsLock: Yes
WhiteBalance: RGBGain/Bias
FavoritesMenu: Text
StandTilt: Yes
StandTiltRange: Forward3 °/Back 8°
Specifications
General
TelevisionType: FlatPanel LCD HDTV
Display
ViewingAngle(Right/Left): 170(85/85)
ViewingAngle(Up/Down): 160(80/80)
On - screenContrastRatio: 800:1
DynamicContrastRatio: 8,000:1
ScreenSize(measureddiagonally): 21.6"
NativeResolution: 1366X 768
DisplayResolution: 1366X 768p (HD)
PanelBit: 6 - bit+HiFRC
AspectRatio: 16:9
ColorRange(u'v'): 88%OF NTSC
ColorRange (xy): 72%OF NTSC
TV System
Tuner(Cable): ClearQAM
Tuner(Terrestrial): ATSC™/NTSC
ChannelCoverage: VHF: 2 - 13ch
UHF: 14 - 69ch
CATV (analog): 1 - 135ch
CATV (digital) : 1 - 135ch
TVSystem (Analog): M
NumberofTuners(Analog): 1
NumberofTuners(Digital): 1(Hybrid)
TVSystem (Digital): ATSC
ColorSystem: NTSC
Video
VideoSignal: 1080/60p(HDMI™/ COMPONENT),1080/60i,1080/24p
(HDMI™ONLY),720/60p, 480/60p, 480/60i
Audio
AudioPowerOutput: 10W(5W X 2)
Speakers(Total): 2
SpeakerConfiguration: 2
Inputs and Outputs
ComponentVideo(Y/Pb/Pr ) Input(s): 2 (Rear) (1 fixed/1 selectable)
CompositeVideoInput(s): 2(1Side/1Rear - selectable)
DigitalAudio Output(s): OpticalDigitalOutput - 1(Rear)
RFConnectionInput(s): 1(Rear)
S - VideoInput(s): 1(Side)
AnalogAudioInput(s) (Total): 5(1 Side, 4Rear)
AudioOut: 1(Rear)
HDMI™ Connection(s)(Total): 3(1 Side, 2Rear)
PCIn (D - Sub)+Audio In (Stereo Mini): 1(Rear)(see owner's manual for
supportedtimings)
USB2.0: 1(Side for Service Only)
HDMI™ PCInput: Yes (see owner's manual for supported timings)
S - VideoDetection: Yes
ACPowerInput: 1(Rear)
Analog Audio Input(s) for HDMI ™ : 1(Rear)
Power
PowerConsumption(inStandby): Less Than 1W
PowerRequirements(voltage): AC120V
PowerRequirements(frequency): 50/60Hz
PowerConsumption(inOperation) max.: 55W
Regulation and Standard Compliance
VESA® HoleSpacingCompatible: Yes
VESA® HolePitch: 100x100M4/8 - 12mm
Service and Warranty Information
LimitedWarrantyTerm: 1 YearLabor/ 1 Year Parts
Energy Saving & Efficiency
PowerSaving Modes: Yes
EnergyStar® compliant: ExceedsEnergy Star® Version 3.0
EcoSettings: Yes
DynamicBacklightControl: Yes
BacklightOffMode: Yes
PCPowerManagement: Yes
EstimatedAnnualEnergyConsumption(kWh): 82kWh
IdleTVStandby: Yes
PowerConsumption(OnMode) for Energy Star: 43.47W
PowerConsumption(StandbyMode) for Energy Star: 0.39W
Recycled & Recyclable Materials
PackagingMaterials: RECYCLEDCarton (MORE THAN 40%)
PrintedMaterials: RECYCLEDPAPER (MORE THAN 20%)
Dimensions
Weight: 15.2 lbs. (6.9kg) with pedestal; 13.5 lbs. (6.1kg) without pedestal
Measurements: 22x161/2 x 8 1/2 in(558 x417 x215mm) with pedestal;
22x 14 5/8 x31/8in (558 x370 x79mm)without pedestal
Supplied Accessories
RM - YD028Remote Control
Batteries(AA x2)
ACPower Cord (attached)
OperatingInstructions
QuickSetup Guide
WarrantyCard
Pedestal (separate, assembly required)
3Screws (for pedestal)
Optional Accessories
SU - WL100Wallmount Bracket
UPCCode: 027242753051
1. 22" class (21.6" measured diagonally).
2.HDMI™ connector required and sold separately.
3.Works with BRAVIA Sync™or TheatreSync™– labeledhome
audio/videoproducts when connected via HDMI.
4.Distance will vary depending uponenvironmental conditions.
5.Limited to resolutionssupported by both thePC and theSony HDTV.
SeeSony TV user's manualandPC documentation forthesupported
resolutions.
6.Check with yourlocalTV station orcablecompany for details on
accessing or subscribing to HD content.
7.The DMX - DVD,DMX - WL1and DMX - SW1BRAVIA Link modulescannot
beinstalled on tothe rear oftheKDL - 22L5000and the KDL - 26L5000
©2009SonyElectronics Inc. All rights reserved. Reproduction inwhole or
inpartwithoutwrittenpermissionisprohibited. Sony, HDNA, BRAVIA
Sync,BRAVIA, BRAVIA Engine, TheatreSync,Cyber - shot,Handycam, 24p
TrueCinema,and their respectivelogos aretrademarksof Sony.
PlayStationisatrademarkofSonyComputer Entertainment Inc. HDMI
andthe HDMI logoare trademarks ofHDMI Licensing LLC.Blu - rayDiscisa
trademark.ENERGYSTARandtheENERGYSTAR mark are registered
U.S.marks.ENERGYSTARis a registered mark owned bythe U.S.
government.Allothertrademarksaretrademarksoftheirrespective
owners.Features and specificationsaresubject to changewithout notice.
Non - metricweights and measuresare approximate andmay vary.
Lampin this product containsmercury.Disposal of these materialsmay
beregulated due toenvironmentalconsiderations. For disposalor
recyclinginformation,please contact your localauthoritiesorthe
Electronic Industries Alliance(www.eiae.org).
®
®
