Sony XBR-49X835D User manual

SERVICE MANUAL
Version Date Subject
1.0 9/2016 Original manual issue.
LCD TV
9-888-806-01
ORIGINAL MANUAL ISSUE DATE: 9/2016 GN2TR CHASSIS
Segment: QH2

MODEL COLOR COMMANDER DEST.
XBR-49X835D Silver RMF-TX200B (BR6)
BRAZIL
XBR-49X835D 2
MODEL LIST
MODEL COLOR COMMANDER DEST.

XBR-49X835D 3
WARNINGS AND CAUTIONS - ENGLISH
CAUTION
These servicing instructions are for use by qualified service personnel only.
To reduce the risk of electric shock, do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so.
WARNING!!
An isolation transformer should be used during any service to avoid possible shock hazard, because of live chassis.
The chassis of this receiver is directly connected to the ac power line.
CARRYING THE TV
Be sure to follow these guidelines to protect your property and avoid causing serious injury.
• Carry the TV with an adequate number of people; larger size TVs require two or more people.
• Correct hand placement while carrying the TV is very important for safety and to avoid damages.
SAFETY-RELATED COMPONENT WARNING!!
Components identified by shading and ! mark on the schematic diagrams, exploded views, and in the parts list are critical for safe operation. Replace these components with Sony
parts whose part numbers appear as shown in this manual or in supplements published by Sony. Circuit adjustments that are critical for safe operation are identified in this manual.
Follow these procedures whenever critical components are replaced or improper operation is suspected.
CAUTION ABOUT THE LITHIUM BATTERY
• Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.
•Outer case broken battery should not contact to water.

XBR-49X835D 4
WARNINGS AND CAUTIONS - FRENCH
ATTENTION!!
Ces instructions de service sont à l’usage du personnel de service qualifi é seulement.
Pour prévenir le risque de choc électrique, ne pas faire l’entretien autre que celui contenu dans le Mode d’emploi à moins que vous soyez qualifi é faire ainsi.
WARNING!!
Afi n d’eviter tout risque d’electrocution provenant d’un chássis sous tension, un transformateur d’isolement doit etre utilisé lors de tout dépannage. Le chássis de ce récepteur est
directement raccordé à l’alimentation du secteur.
POUR TRANSPORTER LE TÉLÉVISEUR
Tenez compte de ce qui suit pendant l’installation du téléviseur :
• Débranchez tous les câbles avant de transporter le téléviseur.
• Transportez le téléviseur avec le nombre de personnes approprié ; un téléviseur de grande taille doit être transporté par au moins deux personnes.
• Lors du transport du téléviseur, l’emplacement des mains est très important pour votre sécurité, ainsi que pour éviter de causer des dommages.
ALERTE!!
Afi n d’eviter tout risque d’electrocution provenant d’un chassis sous tension, un transformateur d’isolement doit etre utilise lors de tout depannage. Le chassis de ce recepteur est
directement raccorde a l’alimentation du secteur.
ATTENTION AUX COMPOSANTS RELATIFS A LA SECURITE!!
Les composants identifi es par une trame et par une marque sur les schemas de principe, les vues explosees et les listes de pieces sont d’une importance critique pour la securite
du fonctionnement. Ne les remplacer que par des composants Sony dont le numero de piece est indique dans le present manuel ou dans des supplements publies par Sony. Les
reglages de circuit dont l’importance est critique pour la securite du fonctionnement sont identifi es dans le present manuel. Suivre ces procedures lors de chaque remplacement de
composants critiques, ou lorsqu’un mauvais fonctionnement suspecte.

XBR-49X835D 5
WARNINGS AND CAUTIONS
USE CAUTION WHEN HANDLING THE LCD PANEL
When repairing the LCD panel, be sure you are grounded by using a wrist band.
When repairing the LCD panel on the wall, the LCD panel must be secured using the 4 mounting holes on the rear cover.
1) Do not press on the panel or frame edge to avoid the risk of electric shock.
2) Do not scratch or press on the panel with any sharp objects.
3) Do not leave the module in high temperatures or in areas of high humidity for an extended period of time.
4) Do not expose the LCD panel to direct sunlight.
5) Avoid contact with water. It may cause a short circuit within the module.
6) Disconnect the AC power when replacing the backlight (CCFL) or inverter circuit. (High voltage occurs at the inverter circuit at 650Vrms.)
7) Always clean the LCD panel with a soft cloth material.
8) Use care when handling the wires or connectors of the inverter circuit. Damaging the wires may cause a short.
9) Protect the panel from ESD to avoid damaging the electronic circuit (C-MOS).
10) It is recommended not to exceed 1 hour of Power-On nor Burn-in period with LCD panel face down condition, in repair activity.

XBR-49X835D 6
SAFETY CHECK-OUT
After correcting the original service problem, perform the following safety checks before releasing the set to the customer:
1. Check the area of your repair for unsoldered or poorly soldered connections. Check the entire board surface for solder splashes and bridges.
2. Check the interboard wiring to ensure that no wires are “pinched” or touching high-wattage resistors.
3. Check that all control knobs, shields, covers, ground straps, and mounting hardware have been replaced. Be absolutely certain that you have replaced all the insulators.
4. Look for unauthorized replacement parts, particularly transistors, that were installed during a previous repair. Point them out to the customer and recommend their replacement.
5. Look for parts which, though functioning, show obvious signs of deterioration. Point them out to the customer and recommend their replacement.
6. Check the line cords for cracks and abrasion. Recommend the replacement of any such line cord to the customer.
7. Check the antenna terminals, metal trim, “metallized” knobs, screws, and all other exposed metal parts for AC leakage. Check leakage as described below.
8. For safety reasons, repairing the Power board and/or Inverter board is prohibited.

XBR-49X835D 7
SAFETY CHECK-OUT
Leakage Test
(To protect electric shock when customer touch the terminal.)
Leakage current can be measured by V: Voltmeter or oscilloscope (r.m.s. or peak reading)
Stabilized power supply instrument and isolated voltage transformer:
Use too much current capacity and isolated voltage transformer does not need to use stabilized power supply
equipment
Specification of RMS volt meter: Input resistance > 1 Mohm, Input capacitance < 200 pF,
Frequency range: 15 Hz –1MHz (Refer Figure A). Isolated type volt -meter (FLUKE 8921A etc *1)
*1 Not use FLUKE 8920A that connected to protective earth by diode
# Leakage current of measurement instrument is less than 10μArms when under test equipment AC plug is
opened
# Set up the following condition and turn on the set.
Applied voltage: Nominal input voltage (Description on Nameplate)
# Measure the leakage current between one phase conductor and neutral for terminal A and terminal B.
Read rms value, and then calculate to peak value PEAK VALUE =√2 RMS VALUE
Comply with the following requirement
Class II equipment (2-pin plug):
for each terminal, the worst value of measurement must not exceed AC 350uA peak).
Note: including AC adaptor, AC adaptor/DC operated unit combination
How to Find a Good Earth Ground
A cold-water pipe is a guaranteed earth ground; the cover-plate retaining screw on most AC outlet boxes is also
at earth ground.
If the retaining screw is to be used as your earth ground, verify that it is at ground by measuring the resistance
between it and a cold-water pipe with an ohmmeter. The reading should be zero ohms.
If a cold-water pipe is not accessible, connect a 60- to 100-watt trouble- light (not a neon lamp) between the hot
side of the receptacle and the retaining screw. Try both slots, if necessary, to locate the hot side on the line; the
lamp should light at normal brilliance if the screw is at ground potential (see Figure B).
Figure A. Measuring network for Leakage Current

XBR-49X835D 8
SELF DIAGNOSIS FUNCTION
DIAGNOSTIC TEST INDICATORS
When an error occurs, the Smart Core Red LED will flash a set number of times to indicate the possible cause of the problem.
If there is more than one error, the LED will identify the first of the problem areas.
Result for all of the following diagnostic items are displayed on screen.
If the screen displays a “0”, no error has occurred .
The units in this manual contain a self-diagnostic function. If an error occurs, the Smart Core Red LED will automatically begin to flash.
The number of times the LED flashes translates to a probable source of the problem.
A definition of the Smart Core Red LED flash indicators is listed in the instruction manual for the user’s knowledge and reference.
If an error symptom cannot be reproduced, the remote commander can be used to review the failure occurrence data stored in memory to reveal past problems and how often these
problems occur.
RED LED blinking count Detection Items
2x <B/G/A> Main 12V over voltage [MAIN_POWER]
3x <B> Main 5.0V failure [DC_ALERT]
<B/S> Audio amp. protection [AUD_ERR]
4x None
5x <P/T/G/B> Panel ID EEPROM I2C No ACK (Also panel power failure is a suspect) [P_ID_ERR]
6x <G/P/B/LD> Backlight failure [BACKLIGHT]
7x Over temperature protection [TEMP_ERR]
<B> Temp. sensor I2C No ACK [TEMP_ERR]
8x None
<G>: Power supply board, <B>: Main board, <T>: T-con board, <LD> LD board (if AC adapter model, it would power supply for Set),
<P>: Panel module <S>: Speaker <A>: Power Adapter, <D>: 4KBE + audio board (w/ 4KBE only), <Tu>: Tuner board (w/o 4KBE only)
Blue italic: detect at startup sequence only.
Record Only Item Detection Items
TU_DEMOD <B/Tu> Tuner & Demodulator I2C communication failure
Tuner board set detect
TCON_ERR None
FRCTC_I2C <T> FRC device is not finished Initial sequence
FRC device I2C communication failure
AUD_ERR_I2C None
Below items are not included in the “RED LED count” but will be recorded as an error and will be shown on the self diagnostic Screen display on the following page.

XBR-49X835D 9
SELF DIAGNOSIS FUNCTION
[SELF DIAGNOSTIC SCREEN DISPLAY]
•Panel Operation Time is recorded every 30 min,
but Total Operation Time is recorded every 1 hr.
Therefore, the panel op. time might become larger than the total op. time.
Format of error timestamps
YYMMDDhhmmss (in UTC)
Example:
120823132523 -> Aug 23 2012 13:25:23 UTC
* Only when time is set, an error timestamp
is saved.
Since the diagnostic results displayed on the screen are not automatically cleared, always check the self-diagnostic screen.
After you have completed the repairs, clear the result display to “0”.
Panel Operation Time clear : Press the Channel 7 => Channel 0 .
Timestamps and Error Count clear : Press the Channel 8 => Channel 0 .
Total Operation Time and Boot Count clear: Press the Channel 9 => Channel 0 .
To exit the Self Diagnostic screen...
*If you want to finish service mode app, do AC OFF/ON →Service mode app is disable perfectly
*if you want to move home menu, push <HOME>button →Service mode app do background(not disable perfectly)
For errors with symptoms such as “power sometimes shuts off” or
“screen sometimes goes out” that cannot be confirmed,
it is possible to bring up past occurrences of failure for confirmation on the screen:
In standby mode, press buttons on the remote commander sequentially in rapid
succession as shown below:
Smart Core Red LED
blinking count
Total Operation Time [hr] –Boot Count –Panel Operation Time [hr]
Error Item Error count
Error
timestamp for
last recorded
error
Error
timestamp for
second last
recorded
error
Error
timestamp
for 3rd last
recorded
error

HOW TO ENTER SERVICE MODE
1) Go to TV standby condition by remote commander.
2) Press the buttons on the remote commander as follows, and entering service mode.
3) Service mode display.
XBR-49X835D 10
ADJUSTMENT
>>
>>
>>
>>
>>
>>
>>
[</>] Set [Home]Exit
General Setting
Tuner
Wifi
Service Mode
Model Information
Self diagnosis History
Video / Audio
Panel / PQ
4) How to use the remote commander.
*When finished the operation of service mode , please AC Plug OFF/ON the TV set.
If you don’t do AC plug OFF/ON, remain the Service Mode App and User can see the Service Mode after RC ON.
(Refer the previous page.)
Function The flow of control
Service mode on <Display><5><Vol Up><Power>
Service mode off AC plug OFF/Menu*
Item up / down <↑>/ <↓>
Item select left/right <←>/<→>
Execute <OK>

Main Micro PKG2.011.0010NAB
0001 UC2
V1.000
102100006
AQ1.100
00.00.00.00
0
0
0
CameraVID:
CameraPIC:
CameraFW:
SW Version:
NVM Version:
Boot Version:
PQ Version:
AQ Version:
exFRC:
SF1.002
MLFW:
<Ext>
4k BE
SF0.360
MAFW: SF0.501
ADSP SD0.370
NDAT SD0.370
PDAT SD1.011
BDAT SD-------
BCM SD0.002
FDAT SD0.000
UDAT SD0.370
BDIX
XBR-49X835D 11
ADJUSTMENT
SOFTWARE VERSION
1) In Service Mode, select “Model Information”, press “Enter” or “→”button to enter Status Information.
2) Press “Enter” or “Return” button to return to Service Mode.
>>
>>
>>
>>
>>
>>
>>
[</>] Set [Home]Exit
General Setting
Tuner
Wifi
Service Mode
Model Information
Self diagnosis History
Video / Audio
Panel / PQ
>>
>>
>>
>>
>>
>>
>>
[</>] Set [Home]Exit
General Setting
Tuner
Wifi
Service Mode
Model Information
Self diagnosis History
Video / Audio
Panel / PQ
>>
Model Information >>
Model Number Setting >>
SERIAL NUMBER EDIT
[</>] Set [Home]Exit
Model
Status Information
>>

XBR-49X835D 12
ADJUSTMENT
SERIAL NUMBER EDIT (1)
1) In “Service Mode”, select “Model Information” by pressing “↑” or “↓” then pressing “Enter” or
“→” button to enter inside.
2) Select “Serial Number Edit” by pressing “↑” or “↓” button then pressing “→” button.
3) Press “↑” or “↓” to input numbers.
4) After user input data , press <Enter> .
•Pop-up dialog appear to confirm input data correct
•Serial Number can be set ONLY ONCE
5) Press “→” or “←” button to select YES or NO.
Select YES if input data is correct.
Select NO if input data is incorrect.
Press <Enter> to save answer.
Model Number Setting
Serial Number Edit _ _ _ _ _ _ _
Service Mode
Status Information >>
Model Information >>
Model Number Setting
Serial Number Edit 9 9 9 9 9 9 9
Service Mode
Status Information >>
Model Information >>
Yes No
Input Data correct?
>>
>>
>>
>>
>>
>>
>>
>>
>>
[</>] Set [Home]Exit
General Setting
Tuner
Wifi
Service Mode
Self diagnosis History
Video / Audio
Panel / PQ
Model Information

Model Number Setting >>
Serial Number Edit 9 9 9 9 9 9 9
Service Mode
Status Information >>
Model Information >>
XBR-49X835D 13
ADJUSTMENT
SERIAL NUMBER EDIT (2)
If YES is selected, the input data is saved into EEPROM.
SERIAL NUMBER EDIT is greyed out and the serial number that has been input is displayed.
User will not able to edit anymore.
If NO is selected, the input data is not saved into EEPROM.
The serial number that has been input is displayed.
User can still edit the Serial Number.
Model Number Setting
Serial Number Edit 9 9 9 9 9 9 9
Service Mode
Status Information >>
Model Information >>
Yes No
Input Data correct?
>>

XBR-49X835D 14
ADJUSTMENT
MODEL NUMBER SETTING
1) In “Service Mode”, select “Model Information” by pressing “↑” or “↓” then pressing “Enter” or “→” button to enter inside.
2) Select “Model Number Setting” by pressing “↑” or “↓” button then pressing “Enter” or “→” button.
3) Press “↑” or “↓” arrow key to scroll Product Name Candidate.
(e.g. KDL-40X500B CO1,KDL-40X500C BR6)
4) Select one Product Name from the list, press <Enter> will pop dialog to inform user to confirm data. Model dependent settings will be overwritten into EEPROM.
_ _ _ _ _ _ _ _ _ _ _ _
OK
[MODEL_NUMBER_SETTING]
>>
>>
>>
>>
>>
>>
>>
[</>] Set [Home]Exit
General Setting
Tuner
Wifi
Service Mode
Model Information
Self diagnosis History
Video / Audio
Panel / PQ
Service Mode
Serial Number Edit
Status Information >>
Model Information >>
Model Number Setting >>
>>

XBR-49X835D 15
ADJUSTMENT
WB ADJUSTMENT
(Please apply when the Main board or panel is replaced.)
In “Panel/PQ” service mode.
a. Go to “WB Adjustment” category by “↑” or “↓”.
b. To select “WB Adjustment”, press “→” button.
c. To change data , press “←” or “→” on remote commander.
Back
R WB Gain <[ 0]>
G WB Gain <[ 0]>
B WB Gain <[ 0]>
R WB Offset <[ 0]>
G WB Offset <[ 0]>
B WB Offset <[ 0]>
<<
[</>] Set [Home]Exit
>>
>>
>>
>>
>>
>>
>>
Service Mode
[</>] Set [Home]Exit
Tuner
Wifi / BT
Model Information
Self diagnosis History
Video / Audio
Panel / PQ
General Setting

XBR-49X835D 16
ADJUSTMENT
WB/MURA/CUC DATA TRANSFER
(Please apply when the Main board or panel is replaced.)
1. In “Panel/PQ” service mode.
a. Go to “WB/Mura/CUC data transfer” category by “↑” or “↓”.
b. To select “WB/Mura/CUC data transfer”, press “→” button.
c. To change data , press “←” or “→” on remote commander.
2. In “WB/Mura/CUC data transfer”.
a. Select “WB/Gamma data transfer” by pressing “↑” or “↓” on remote commander.
b. To change the items, press “←” or “→” on remote commander and press “Enter”
button.
Selectable items are:
0. SoC to T-con
1. T-con to SoC
2. Not action
c. Select “[start]” and press “Enter” button to start transfer.
>>
>>
>>
>>
>>
>>
>>
Service Mode
[</>] Set [Home]Exit
Tuner
Wifi / BT
Model Information
Self diagnosis History
Video / Audio
Panel / PQ
General Setting
Back <<
<[ 0. SoC to T-con ]>
Mura data transfer <[ 0. SoC to T-con ]>
CUC data transfer <[ 0. SoC to T-con ]>
[Start]
[</>] Set [Home]Exit
WB/Gamma data transfer
*Please refer to another manual “Service Procedure for Panel, Board and Software Change /
Upgrade(P/N:9-888-450-02)” for details. B-board
replace
T-con
replace
Panel
replace
WB/
Gamma
1.T-con to
Soc
0.SoC to
T-con
0.SoC to
T-con
Mura 1.T-con to
Soc
0.SoC to
T-con
1.T-con
to Soc
CUC 1.T-con to
Soc
0.SoC to
T-con
1.T-con
to Soc

Back <<
Aging mode <[On/Off]>
HDD Performance Check >>
AAA >>
Update CI+ Credentials >>
Boot count reset >>
ECS Enable <[On/Off]>
[</>] Set [Home]Exit
General Setting
XBR-49X835D 17
ADJUSTMENT
HDD PERFORMANCE CHECK
1. In “Service Mode”, select “General Setting” by pressing “↑” or “↓” then
pressing “Enter” or “→” button to enter inside.
2. Select “HDD Performance check ” by pressing “↑” or “↓” then pressing
“Enter” or “→” button to enter inside.
3. A message "Please wait ..." is displayed during performance check processing.
4. Result OK or NG will be displayed after performance of HDD is checked.
>>
>>
>>
>>
>>
>>
>>
[</>] Set [Home]Exit
General Setting
Tuner
Wifi / BT
Service Mode
Model Information
Self diagnosis History
Video / Audio
Panel / PQ
Service Mode
Please wait…
<[ NG ]>
Back <<
HDD Performace Check
Result
HDD Performance Check

Back <<
Aging mode <[On/Off]>
HDD Performance Check >>
AAA >>
Update CI+ Credentials >>
Boot count reset >>
ECS Enable <[On/Off]>
[</>] Set [Home]Exit
General Setting
XBR-49X835D 18
ADJUSTMENT
HDD RE-REGISTRATION
1) In “Service Mode”, select “General Setting” by pressing “↑” or “↓” then pressing “Enter” or “→” button to enter inside.
2) Select “AAA” by pressing “↑” or “↓” then pressing “Enter” or “→” button to enter inside.
3) Result OK or NG will be displayed after HDD re-registration is succeed/failed.
>>
>>
>>
>>
>>
>>
>>
[</>] Set [Home]Exit
General Setting
Tuner
Wifi / BT
Service Mode
Model Information
Self diagnosis History
Video / Audio
Panel / PQ
<[ NG ]>
Back <<
HDD Re-Register
Result

XBR-49X835D 19
USB UPDATE
1:Download USB image and unzip file.
2: copy unzip file to USB memory root folder.
3: USB memory insert TV.
4:USB image is newer soft version.
Automatically show message and start update.
Please follow directions.
4:USB image is not newer soft version.
Automatically show message and start update.
Please follow directions.
5: finished
System software update
Your software is up to date
Please remove the USB device and select [OK] to exit
OK
System software update
46%
Copying USB update file. Please wait…
Preparing for system software update. During the system software update, the TV will automatically restart.
Please do not remove the USB device until an update complete message is displayed . The update may take up to
30 minutes to complete.
System software update
The system software update is complete .
Some user settings may have changed during the update.
Please remove the USB device and select ”OK” to exit
OK
5: finished
*Please refer to another manual “Service Procedure for Panel, Board
and Software Change / Upgrade(P/N:9-888-450-02)” for details.
GN2SK chassis is the same as GN1T chassis basically.

XBR-49X835D 20
TROUBLE SHOOTING
TRIAGE
1. Confirm the symptom from the customer.
2. Select that symptom from the chart.
3. Bring all the boards and cables listed for that symptom.
4. Follow the troubleshooting charts in the technical guides to isolate the board.
5. Chart Color Code.
RED DOT: Most likely defective part
BLUE TRIANGLE: Secondary possible defective part
BLACK TEXT: Board that may correct the symptom
GRAY CELL: Items not applicable for this model
Reference
Symptoms - Shutdown. Power LED
blinking red diagnostics sequences
Symproms - no shutdown
Error log record only
No
Power
Video
- missing or distorted
Remote
Network Audio Skype Smart Core Bluetooth
(BT)
2 3 4 5 6 7 8
TU_
DEM
OD
TCO
N_E
RR
FRC
TC_I
2C
AUD_ERR_I
2C
No White Power
LED & does not
reponse to
remote (Dead
Set)
Stationary
colored
lines or
dots
No video
One of
Inputs
NO RF
input
No video
all Inputs
No Remote
Wireless
can't connect No Audio Skype Can't Work
Smart Core no LED
(Set is still alive)
Bluetooth / One
Step Remote
(OSR) can't
connect
B* Board p
l p p l p p p p l l l p p l p p p
DPA Board
(QX only)
G* Board/ADP
l p p l
l p
H* Board
p l l
Speaker
p l
Tuner board
(Except QX)
l
l
Wifi & BT
Module
l p l
LD* Board
(49” only) l
p p l
l p p
V By One FFC
p p
p p
Tcon
l
p p
LCD Panel
l l
l
p
Problem
Power
Power
LD
Panel
(Communication)
Panel
(Backlight)
TEMP
4KBE
Audio
