Sony KDL46S504 - 46" LCD TV User manual

LCD Digital
Color TV
Please Do Not Return
the Product to the Store
Canada
1.877.899.S0NY.
Sony Customer Support
U.S.A.: www.sony.com/tvsupport
Canada: www.sony.ca/support
United States
1.800.222.S0NY
©2009 Sony Corporation
KDL-46S504
KDL-40S504

For customers in Canada
This Class Bdigital apparatus complies with Canadian
ICES-003.
Owner's Record
The model and serial numbers are located at the rear of the TV. i
Record these numbers in the spaces provided below. Refer to
them whenever you call upon your Sony dealer regarding this
TV.
Model Name
To prevent electric shock and blade exposure, do not use
this
polarized AC plug with an extension cord, receptacle or
other outlet unless the blades can be fully inserted.
o Operate the TV only on 120 VAC.
oAvoid operating the TV at temperatures below 41°F
(5 °C).
Declaration of Conformity
Trade Name: SONY
Model: KDL-40S504/KDL-46S504
Responsible Party: Sony Electronics Inc.
Address:
16530 Via Esprillo.
San Diego,
CA 92127 U.S.A.
Telephone Number: 858-942-2230 I
This device complies with part 15 of the FCC rules. I
Operation is subject to the following two conditions: (I) ,.11
This device may not cause harmful interference, and (2)
this device must accept any interference received, I
including interference that may cause undesired
~_operation. ~
This equipment has been tested and found to comply with
the limits for a
Class Bdigital device. pursuant to Part IS
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation.
This equipment generates. uses and
can radiate radio frequency energy and. if not installed and
used in accordance with the instructions. may cause
harmful interference to radio communications. However,
there is no
guarantee that interference will not occur in a
particular installation. If this
equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on. the
user is encouraged to try to correct the interference by one
or more of the following measures:
o Reorient or relocate the receiving antenna.
oIncrease the separation between the equipment and
recetver.
o Connect the equipment into an outlet on acircuit
different from that to which the receiver is
connected.
o Consult the dealer or an experienced radiolTV
technician for help.
FCC Related Information
Pursuant to FCC regulations, you are cautioned that any
changes or modifications not expressly approved in this
manual
could void your authority to operate this
equipment.
The shielded interface cable recommended in this manual
must be used with this equipment in order to comply with
the limits
for adigital device pursuant to Subpart B of Part
15 of FCC Rules.
Note
This television includes a QAM demodulator which should
allow
you to receive unscrambled digital cable television
programming via subscription service to acable service
provider. Availability
of digital cable television
programming in your area depends on the type of
programming and signal provided by your cable service
provider.
I
!
I
i
--'
Serial No.
CAUTION
For Customers in the United States
The lamp in this product contains mercury.
Disposal
of these materials may be regulated
due to environmental considerations. For
disposal
or recycling information. please
contact your local authorities
or the Electronic
Industries Alliance (www.eiae.org).
2

II
11'1i;JIt~ih,ij
Compatible Wall Mount Bracket Information
Use the following Sony WALL-MOUNT BRACKET with
your TV model.
Sony TV Model No.
KDL -405504/KDL -465504
Sony
Wall-Mount
5U-WL500
Bracket
Model No.
Use with other WALL-MOUNT BRACKETS may cause
instability and could result in property damages or injury.
To Customers
Sufficient expertise is required for TV installations. Be
sure to subcontract the installation to aSony dealer or
licensed contractor and pay adequate attention to safety
during the installation.
Licensing Information
Macintosh is atrademark of Apple Inc., registered in the
U.S. and other countries.
HDMI, the HDMI logo and High-Definition Multimedia
Interface are trademarks orregistered trademarks
of HDMI
Licensing, LLC.
Fergason Patent Properties, LLC:
U.S. Patent No. 5,717,422
U.S. Patent No. 6,816,141
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks
of Dolby
Laboratories.
TruSurround XT, SRS and
(e) symbol are trademarks of
SRS Labs, Inc. TruSurround XTtechnology is incorporated
under license from SRS Labs, Inc.
Blu-ray Disc
is atrademark.
"BRAVIA",
BRAVIA, BRAVIA Sync and II are
trademarks or registered trademarks
of Sony Corporation.
"PlayStation"
is aregistered trademark and "PS3" is a
trademark
of Sony Computer Entertainment Inc.
Your BRAVIA TV
is ENERGY STAR<!>
qualified in the "Home" mode.
It meets strict energy efficiency guidelines
set by the U.S. Environmental Protection
Agency and Department
of Energy.
ENERGY STAR
is ajoint program of these government
agencies. designed to promote energy efficient products
and practices.
oWhen the TV is initially set up, it is designed to meet
ENERGY STAR requirements.
oChanges to certain features, settings, and
functionalities
of this TV (i.e. Picture/Sound, Light
Sensor, Power Savings) can slightly change the
power consumption.
Depending upon such changed settings, the power
consumption may increase which possibly couldexceed the
limits required for the ENERGY STAR qualification.
[I]DOLB~
DIGITAL I
HIGH-DEFINITION TELEVISION
3

Contents
Introducing Your New BRA VIA®
Welcome to the World of BRAVIA@ 5
Experiencing Stunning HD with Your
BRAVIA 5
The Four Steps to aFull HD Experience 6
TV Feature Highlights 6
Getting Started
Setting Up Your TV 7
Locating Inputs and Outputs 8
Connecting Other Equipment 10
Bundling the Connecting Cables
11
Securing the TV 11
Inserting Batteries into the Remote
Control 12
Initial Setup 12
Operating the TV
Remote Control Button Description 13
TV Controls and Indicators 15
Using Features
Using BRAVIA@ Sync™ with Control for
HOM!. 16
Favorites 17
Wide Mode 18
Wide Mode with
PC 19
Using the Menus
Navigating through TV Menus 20
Other Information
How to Care for Your BRAVIA 21
Things to consider 21
Troubleshooting 21
Specifications 22
Index 23
0
-.">
'0" ./
4
Customer Support
United States
http://www.sony.com/tvsupport
Canada
http://www.sony.ca/support
On-line Registration
United States
http://productregistration.sony.com
Canada
http://www.SonyStyle.ca/registration

Introducing Your New BRAVIA@
Thank you for purchasing this Sony BRAVIA high-definition television. Use the
documentation listed below to get the most out of your
TV.
Welcome to the World of BRAV/A®
Safety Booklet
Provides precautionary measures
to keep you and your TV safe. Read
this information prior to setting up
your
TV.
Operating Instructions
Provides general
TV operation
information that will allow you to
view your TV with minimal
customizations.
•
5"
-
a
~
CO)
~.
~
c:
..,
Quick Setup Guide ~
Provides TV setup information, :e
illustrates sample optional equipment ~
connection diagrams.
:s
):;
@>
Reference Book
Offers the most complete
TV
operation information available for
your TV and presents advanced
customization details. Access it at
www.sony.com/referencebook.
'\ The TV operation information above has been designed in an eco-friendly
~., manner to reduce the consumption of natural resources.
Experiencing Stunning HD with Your BRAV/A
The quality of the image you see on your BRAVIA TV is only as good as the quality of the
signal
it receives. To experience the stunning detail of your new BRAVIA TV, you need
access to
HD programming. Your BRAVIA TV can receive and display HD programming
from:
•Over-the-air broadcasting via HD-quality antenna
•HD cable subscription
•HD satellite subscription
•Blu-ray
Disc™ player or other HD compatible external equipment
Contact your cable or satellite provider for information on upgrading to HD programming.
This manual is for 40 and 46 inch BRAVIA KDL-S504 series models with screen size measured diagonally.
5

The Four Steps to aFull HD Experience
Set, Sound, Source, and Setup
Along with your BRAVIA TV set, acomplete HD system requires an HD sound system, a
source of HD programming and aproper connection setup. Refer to the Quick Setup
Guide, enclosed separately, for connecting other optional equipment.
16:9 (high-definition) source
Most HDTV signals use awide screen aspect
ratio of 16:9. The 16:9 fills your BRAVIA
screen, maintaining acrisp, clear, vivid
picture.
4:3 (standard-definition) source
Most standard-definition signals use aboxy
4:3 aspect ratio. When a4:3 image is
displayed on
an HDTV, you will see black
bars
on the sides. The picture quality may not
be as sharp as with HD sources.
TV Feature Highlights
Your new BRAVIA High Definition LCD TV will dazzle you with stunning 1 D8Dp image
quality but won't confuse you with complicated operation. The following features have
been included to help you get started enjoying your new
TV.
~ BRAVIA Sync: Your BRAVIA TV communicates with other Sony equipment
supporting the Control for HOMI function (page 16).
~ Favorites: Your favorite channels and inputs are at your fingertips for easy
access to programs and inputs (page 17).
~ Auto Wide Mode: Set your TV to auto adjust the screen based on the signal
resolution (page 18).
~ECO Settings: This model includes anumber of features designed to make
your new BRAVIA HDTV easier on your pocketbook and the environment.
Light Sensor -Detects the amount of light in your room and automatically
adjusts the brightness of the screen resulting
in more comfortable viewing in
any light condition.
Backlight -This feature reduces power consumption by turning off the
backlight.
~ Suggestions
•Check more details on the online Reference Book at www.sony.com/referencebook.
6

Getting Started
.~.' y
Setting Up Your TV
Some TV models are packaged with adetached Table-Top Stand so you can mount it to awall •
right away.
If you are not mounting the TV to awall, you will need to attach the Table-Top Stand.
You will need aPhillips screwdriver and the supplied screws to complete the task. Look for the ~
instructions attached to the TV unit or read the instruction in the online Reference Book. ~
CQ
(I)
Be sure to consider the following while setting up your TV: !it
ii
•Carry the TV with an adequate number of people; larger size TVs require two or more people. Q.
•Correct hand placement while carrying the TV is very important for safety and to avoid
damages.
•Ensure your
TV has adequate ventilation if it is installed against awall or in an enclosed area.
•For best picture quality, do not expose the screen to direct illumination or sunlight.
•Avoid installing the
TV in aroom with reflective wall and floor materials.
•Avoid moving the TV from acold area to awarm area. Sudden room temperature changes may
cause moisture condensation. This may cause the
TV to show poor picture and/or poor color.
Should this occur, allow moisture to evaporate completely before powering the
TV on.
~ Suggestions
•Read the Dos and Don'ts in the Safety Booklet for additional safety information.
•For details about the items listed above, see the online Reference Book.
•When cable connection is completed, be sure to secure the TV to astable surface or mount it to a
wall. The designated Sony wall-mount bracket model name
is available on page 3. For details on
securing the
TV, see page 11.
7

Locating Inputs and Outputs
Rear Panel
Item Description
Side Panel
AUOIO
<0
5 VlOEO ..
I WlEIAHTEWJ
I(V
[ID
VIDEO
0
IJ~
1*-'1
II@
7
AUDIO
~O
2
VIDEOIH
[I] SERVICE
[g] VIDEO IN 11
COMPONENT
IN 1 (1080pl
1080in20pl
480p/480i)1
L-AUDIO-R
8
This port ito be ued when ervice irequired.
This input port can be used acomposite video input (VIDEO
1) or as component
video input (COMPONENT 1). For composite use, connect the yellow
jack to
Y Nideo for video and use audio Land Rfor audio signal. For component
connection, use
Y, PB PR for video ignals and also connect the audio Land Rfor
audio signal.
You mu tconfigure the input
type
if the input is used a
composite or component
video input. Otherwise ablack
&white or distorted picture
may occur.
To configure the input type
press MENU, select Channel
menu then select
Video/Component 1to
choose Video 1or
Component 1ashown
here.

Item Description
-
Connects to apersonal computer's video and audio output connector. Can also be
connected
to other analog RGB equipment.
For some Apple Macintosh computers,
it may be necessary to use an adapter (not
supplied).
If an adapter is used, connect the adapter to the computer before
connecting the HD15-HD15 cable.
You may need to adjust the TV settings or your PC's resolution and timing, see page
19 to setup your PC to this TV.
Connects to the composite video and audio output jacks on your A/V equipment
such as aDVD player or other video equipment. VIDEO IN 2input
is located on the
left side panel
of the TV.
Connects to the SVIDEO output jack of your DVD or other video equipment that
has SVIDEO which provides better picture quality than composite video. The S
VIDEO does not provide sound; you will need to connect the audio cables.
@] AUDIO OUT
(FIX)
I]J HDMIIN 1/213
~ COMPONENT Component video provides better picture quality than the SVideo and composite
IN 2video. The COMPONENT IN 2and COMPONENT
IN Iboth accommodate for
video formats
of 1080p, 1080i, nap, 480p, and 480i as labeled.
Audio connection is required for the COMPONENT IN ports, connect audio (UR).
Connects
to the left and right audio input jacks of your audio equipment. You can
use these outputs to listen to your
TV's audio through your stereo system.
HDMI (High-Definition Multimedia Interface) provides an uncompressed, all-
digital audio/video interface between this TV and any HDMI-equipped audio/video
equipment, such as aset-top box, DVD player, Blu-ray Disc, and
NV receiver.
HDMI supports enhanced, or high-definition video, plus digital audio.
Be sure to use only an HDMI cable that bears the HDMI logo.
If the equipment has aDVI jack and not an HDMI jack, connect the DVI jack to any
HDMI IN (with DVI-to-HDMI cable or adapter) jack, and connect the audio jack
to
the AUDIO IN (UR) jacks below the HDMI IN 1.
[§] DIGITAL AUDIO Connects to the optical audio input of adigital audio equipment that is PCM optical
OUT (OPTICAL) compatible.
[Z] CABLE! RF input that connects to your Cable or over-the-air antenna.
ANTENNA
[ID PC IN
(RGB/AUDIO)
ill] VIDEO IN 2
SVIDEO
VIDEO/
L(MONO)-
AUDIO-R
~. Suggestions
Be sure to refer to the Quick Setup Guide for:
•High quality picture performances
•Combination
of equipment connections
•Cable types to use for connection
To view
48Op, nap, 1080i, and 1080p formats, an HDMI or Component video (YPBPR) is
necessary. Connect your equipment properly and playback the video with capable equipment. This
TV displays all picture format types in aresolution
of 1,920 dots x1,080 lines.
9

Connecting Other Equipment
Blu-ray
Disc Player/ DVD
"PS3" player
Digital
satellite Digital
receiver cable box Audio
system Personal
computer Side panel
VCR/
Game system/
Camcorder
Haml
IN
Homl
IN
rD~
VIDEO
IL~ I
IIMr~ I
AUDIO
~O
~;
AUDIO
II ~O
~~
e
f
I· CABLEIANTENN~ I
CABLE/ANTENNA
I"':
.,
Rear of TV
Digital Analog audio Analog Digital audio
recorder/ equipment audio equipment
DVD/Game (AN Receiver/ equipment
system Home Theater) (DVI only)
p
•Refer to the Quick Setup Guide (supplied) when connecting other equipment to your TV
10

Bundling the Connecting Cables
You can bundle the connecting cables with the supplied cable band as illustrated below.
Do not bundle the
AC power cord with other connecting cables. -
Securing the TV
Sony strongly recommends taking measures to prevent the TV from toppling over. Unsecured TVs
it,
may topple and result in property damage, serious bodily injury or even death. Contact Sony
I Customer Support to purchase the optional Support Belt Kit by providing your TV model name.
• • For United States call: 1-800-488-7669 or visit: www.sony.com/accessories
•For Canada call: 1-877-899-7669
Detailed information available on online Reference Book
,.--- Secure the Stand for the TV Anchor the TV to the Wall
Angle
braces
'*7--- Stand
.----- Secure the TV to the Stand
Wall-
mount
holes
Anchor bolts
•Wall-
,-
'" .: anchor
11

Inserting Batteries into the Remote Control
Insert two size AA batteries (upplied) by
matching 0and 0on the batterie to the
diagram inside the battery compartment
of
the remote control.
Initial Setup
Push to
open
The Initial Setup screen appear when you turn on the TV for the first time.
During this initial setup, you can perform the following:
1Select the language for the on-screen di play text.
2Select HOME or Retail mode.
3Connect cable or antenna, then select OK to run Auto
Program.
p
• If you have cable and antenna available, please connect
cable first.
•IMPORTANT: Auto Program process is only effective
when cable or antenna is connected.
Ifyou cancel Auto Program before completion some channels may not be available.
4Auto Program will scan for available channels from the signal source directly connected to
the
TV's CABLE/ANTENNA input and may take ometime to complete the proce s. Follow
the help text provided on the screen to run Auto Program.
~ Suggestions
•When prompted to select HOME or Retail, be sure to select
HOME for ENERGY STAR compliant mode.
•
If you use bothcable without abox and antenna connections, use an
A-B RF witch (not supplied). For more details, see the online
Reference Book.
•Select your preferred aspect ratio for the creen display. Press
WIDE to select the wide mode or press MENU and setthe Auto
Wide to On under the Screen menu.
•
To change the clock, press MENU and go to Setup menu then
elect ClocklTimers and adjust Current Time.
12

Operating the TV
, , ,'.'m.- "
Remote Control Button Description
(b
•The 5, PLAY and CH +
buttons have atactile
dot. Use them
as a
reference when
operating the
TV.
Button
[jJ DISPLAY
[gJ CC
~ BRAVIA
Sync
@] FAVORITES
-rnJ WIDE
[ill RETURN
[1] MENU
Description
Press to display information about channel/program or input
you are watching, The information banner will disappear in a
few seconds or press again to exit. You can enable or disable
the Info Banner by pressing MENU and go to the Setup
Menu to set Info Banner to On or Off.
(b
The TV will show the remaining time of the current program
you are watching when the program time is less than 24 hours.
Press to turn on and off the Closed Captions (CC).
To change or customize the CC display, see the online
Reference Book for more details.
These buttons are used
to control the connected
equipment with Control for HDMI function (not
available
on all Control for HDMI equipment). Some
other buttons on the remote control may also operate
BRAVIA® Sync™ equipment.
.... (fast reverse): Press to playa program in fast
rewind mode.
~ PLAY: Press to playa program at anormal speed.
II PAUSE: Press to pause playback.
~ (fast forward): Press to playa program in fast
forward mode.
SYNC MENU: Displays the menu of the current
selected BRAVIA Sync device.
•STOP: Press to stop playback.
THEATER: Press to turn on and off the Theater
Mode. The picture settings will
be set for acinema-
like experience and the audio
will be switched to the
audio output ofthe attached speakers
of your BRAVIA
Sync audio system. Your BRAVIA Sync audio system
must
be connected by an HDMI connection to your TV
(see page
16 for details).
13
•

Guidelines to follow
Button
[ID 0-9 ENT
[IDO
IHl +1+1+1.
G
Ml TOOLS
[j]J CH +/-
[IJ JUMP
Description
Press 0-9 to select achannel; the channel changes after
afew seconds, or press ENT to change channels
immediately.
Use with 0-9 and ENT to select digital channels.
For example, to enter 2.1, press
®' 0, CD and ENT.
Press to adjust the volume.
Press to mute the sound. Press again
or press VOL +to
restore the sound.
Press to turn on and
off the TV.
Press to display the list of External Inputs and TV
mode. To toggle through the inputs, press +1+.
Press +1+1+1. to move the on-screen cursor. Press ()
to select/confirm an item.
Press to display alist
of convenient functions and menu
shortcuts. The TOOLS menu items vary based on
current input and content.
Press to scan through channels. To scan quickly
through channels, press and hold down either
+/-.
Press to jump back and forth between two channels.
The
TV alternates between the current channel and the
last channel that was selected.
14
•Point your remote control directly at the IR sensor located on
your
TV.
•Make sure that no objects are blocking the path between the
remote control and the IR sensor on your
TV.
•Fluorescent lamps can interfere with your remote control; try
turning
off the fluorescent lamps.
• If you are having problems with the remote control, reinsert or
replace your batteries and make sure that they are correctly
inserted.

TV Controls and Indicators
•
INPUT
ITJ B----t--rnJ
IMENUI~
Receives IR signals from the remote control.
Senses room light level and adjusts the screen brightness accordingly.
Do not put
anything near the sensor or the nearby general area (as shown above), as its function
may be affected.
Lights up in
amber when the Timeror Sleep functions are set. When the timer is set,
this
LED will remain lit even if the TV is turned off. For details, see the online
Reference Book.
Lights up in green when the Backlight is turned
off (see the online Reference Book
for more details).
Lights up in red when the function PC Power Management is activated and there
is no signal received while in the PC Input (see online Reference
Book for more
details).
If the LED blinks in red continuously, this may indicate the TV needs
servicing (see contacting Sony information on the front cover).
Lights up in green when the
TV is turned on.
Press to turn on and
off the TV.
Press to scan through channels.
To scan quickly through channels, press and hold
down either +/-. In the MENU screen, these buttons serve as up/down buttons.
Press to adjust the volume. In the MENU screen, these buttons serve as left/right
buttons.
Press to display the list
of inputs. To toggle through the inputs. press the buttons
CHANNEL +/-.
In the MENU screen, this button serves to confirm the selection or setting.
Press
to display MENU with TV functions and settings (see "Using the Menus" on page 20).
-...
~
J EFF/TIMER
C
I!D
STANDBY POW~
(IR) Infrared
Receiver
Light Sensor
~ STANDBY LED
[2J PIC OFF/
TIMER LED
lID -~-
I
INPUT
@] POWER LED
[ID POWER
[§J +CHANNEL -
I1J +VOLUME -
[IDMENU
(b;
•The CHANNEL +button has atactile dot. Use it as areference when operating the TV.
15

Using Features
Using BRAVIA@ Sync™ with Control for HDMI
The BRAVIA Sync function allows this TV to communicate with other Sony equipment
supporting the Control for HOMI function.
To connect Sony equipment with Control for HOMI
Use an HDMI cable that bears the HDMI logo for connection. See the HDMI connection shown in
the Quick Setup Guide provided with the TV documentation.
Setting the Control for HOMI
The Control for HOMI function must be set up in order for the TV to communicate with other
Control for HOMI enabled equipment. Refer to the online Reference Book for information on
how to set up this
TV's Control for HOMI function. For other equipment, refer to its operating
instructions.
Available options using Control for HOMI
The following operations are available after you connect the supported Sony equipment with
Control for HOMI function to your TV:
•Automatically turn off the connected equipment when you turn off the TV.
•The TV will automatically turn on and select the respective HDMI input.
•The connected equipment
is turned on by One-Touch-Play.
•Possible operations with BRAVIA Sync buttons, see page
13.
•Equipment listed under External Inputs will turn on automatically when selected.
When aSony AIV receiver with BRAVIA Sync is connected, the following additional operations
are possible:
•Turning on the A/V receiver when the TV is turned on.
•Adjusting the volume and muting
of the A/V receiver with the TV's remote control.
•Pressing
TC:t on the remote control turns on and searches for an external audio system that
supports BRAVIA Sync. When the BRAVIA Sync audio system is on, the internal speakers
of
the TV will turn off and the Picture Mode will change automatically to Cinema.
•When using BRAVIA Sync, the included remote control will change some of the buttons
functions
to accommodate control over the device. If the device does not support this feature,
some buttons will remain without function.
16

Favorites
With Favorites, you can manage your preferred TV channels and External Inputs.
Press TOOLS to add the current channel or input while you are watching it.
Highlight Add to Favorites and pre s
().
Adding to Favorites
1
2
Displaying Favorites
Pres FAVORITES on the remote control.
Video 1Channel
PC Recently viewed items Saved channel or external input
Press +/+ to move between saved selections in acarousel-like fashion.
When the recently viewed items are highlighted, press
+/+ to move between them.
To tune to an item, highlight its icon and press ().
Navigating Favorites
1
2
3
Press TOOLS to remove the current channel or input while you are watching it.
Highlight Remove from Favorites and press
() .
Removing from Favorites
1
2
p
•Auto Program will clear your TV channel from Favorites (ee page 12).
17

Wide Mode
The Wide Mode feature allows you to select the screen display of your preference. Based on the
original source, ablack frame or black bars may surround the picture.
You can manually change the Wide Mode setting while watching TV by pressing the WIDE
button on your remote control.
How to set to Auto Wide
Press MENU then go to the Screen menu.
Select Auto Wide and set to On.
Changing the Wide Screen Mode
Press WIDE repeatedly to cycle through the available modes.
...
Wide Zoom
~
Normal
urn
Full
~
Zoom
~
Full Pixel
This mode is not
available.
Irn B08
...
Wide Zoom
~L]
Normal
This mode is not available.
Zoom
~L]
Full Pixel
[KE B08
(b
•Normal is available with 480i or 480p sources only as they are standard-definition and not from
high-definition source such as component video input, HDMI input and digital
TV.
•Full Pixel is available only for 720p, I080i and I080p formats excluding Cable/Antenna input.
•Full Pixel displays the picture in its native resolution.
18

Wide Mode with PC
•
•..•.....•..•• j
1,280 x768
•
Wide Zoom
~
Normal
EC8
Full
BOB
Zoom
lL]
Full Pixel
1[:]1
bOd 800 x600
•
Wide Zoom
~
Normal
o
Full
~
Zoom
lL]
Full Pixel
I hQd I
Changing the Wide Screen Mode for
PC Timing
Press WIDE repeatedly to cycle
through the available modes while in
the PC input mode.
~
Full Pixel displays the picture in its
native resolution.
PC and HDMllnput Signal Reference Chart
After connecting the PC to the TV, set the output signal from the PC according to the chart below.
Resolution Horizontal
Vertical
Signals Horizontal x Vertical
frequency (kHz) frequency (Hz)
Standard
(Pixel) (Line)
VGA 640 x480 31.5 60 VGA
SVGA 800 x600 37.9 60 VESA Guidelines
XGA 1,024 x768 48.4 60 VESA Guidelines
WXGA 1,280 x768 47.8 60 VESA
1,360 x768 47.7 60 VESA
SXGA 1,280 x1,024 64.0 60 VESA
HDTV 1,920 x1,080 67.5 60 CEA-861
¢JJ
•This TV's PC input does not support Sync on Green or Composite Sync.
•This
TV's PC VGA input does not support interlaced signals.
~ Suggestions
•Adjust Phase to eliminate horizontal lines of the picture when the TV receives an input signal
from the connected
Pc.
19

Using the Menus
The MENU button allows you to access the variety of TV settings for you to customize the settings.
Navigating through TV Menus
+/+ button:
Allows you to highlight options where applicable.
obutton:
Allows you to select the highlighted option and advance to the next screen.
.. button:
Allows you to move back to the previous screen.
+button:
Allows you to move to the next screen.
III
~»
Sound
Screen
d
Channel
C8
Lock
EI
Setup
On Picture Menu, you can adjust the picture you see to fit your viewing preference. These
settings allow you
to customize for the signals your TV receives; such as the broadcasted signal
or signal from your gaming equipment or from your connected equipment.
The Sound Menu allows you
to customize your sound settings to suit your audio preferences.
You can also set the settings to enjoy the sound from your connected audio system.
The Screen Menu allows you to change the proportions
of the screen. Depending on the signal
your TV receives, the images on the screen can fill the screen from edge to edge on the screen or
can be smaller, looking like asquare in arectangle shaped screen. The screen settings allow you
to adjust the size and shape
of image you see on your TV. Use the Wide Mode option or use
Auto Wide, or 4:3 Default to keep the square like screen size.
Channels &Inputs Menu allows you to switch between the cable and antenna signal, run
Auto Program, Add Digital Channels, or you can show or hide channels to appear when
you use the CH+/- button or even label channels or inputs.
Parental Lock Menu allows you to block programs according to their content and rating labels
and block channels (regardless
of the programs). Set the password and limit the access based on
the rating levels or block the channel. Not every program is suited for the general audiences.
Setup Menu allows you to set and customize Closed Captions with different size and color
of the fonts, program the TV to turn off, select the Language for your on-screen display, or
change the settings related
to power consumption.
~, Suggestions
•Many of the options available on your TV come with help texts on screen. If you need further
explanations on how to adjust these settings, see the online Reference Book.
•Sleep can be set from 15, 30,60 or 120 minutes. Press MENU then go to Setup menu, select
ClockJTimers, then Sleep and select your desired minutes.
•Use TOOLS button on the remote control to quickly access convenient functions.
20
