Sony BRAVIA KDL-55EX711 Installation and operation manual

KDL- 55EX711
55" BRAVIA® EX711 Series LED LCD HDTV
Key Features
Full HD 1080p Resolution
Edge LED Backlighting with Slim Design
Wi -Fi® Adapter Ready & BRAVIA® Internet Video
1
Motionflow ™ 120Hz Technology for Smooth Motion
Ambient Sensor adjusts color based on room light
USB port for photos, music & video playback
Presence Sensor technology
Energy Saving Switch eliminates standby power
Key Technologies
Full HD 1080p Resolution Experience Full HD 1080p picture quality, the highest at - home resolution,
and take full advantage of HD sources like a Blu - ray Disc™Player or PlayStation ® 3 gaming console
via the 16:9 wide screen panel (1920 x 1080).
2
Edge LED backlight Enjoy a slim design plus amazing dynamic contrast with an Edge LED backlight.
Wi - Fi ® Adapter Ready Enjoy the convenience of wireless connectivity for your home
entertainment network and make accessing your online entertainment - including movies, photos,
music, videos and more - even easier! (Wi - Fi dongle required. Included.)
4
BRAVIA® Internet Video Instantly stream a wide variety of movies, TV episodes, videos and music
from a large selection of entertainment apps including: Netflix ® , YouTube™, Slacker ® - the list goes
on and on.
1
Motionflow™120Hz Technology Experience smooth motion detail and clarity with Motionflow™
120Hz technology. Motionflow™120Hz technology doubles the frame rate from the standard 60
frames per second and applies Image Blur Reduction technology to deliver a crisp, fluid and realistic
viewing experience during fast - action scenes.
Ambient Sensor Get a natural looking picture whether you are watching movies late at night or
playing video games during the day with an Ambient Sensor that automatically adjusts the picture
color based on a room's lighting.
USB Input Share your home videos or photos on the big screen or listen to your favorite music.
Simply connect your digital camera, USB - enabled MP3 player, or USB storage device directly to your
HDTV's USB input.

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 12/22/2010
KDL- 55EX711
55" BRAVIA® EX711 Series LED LCD HDTV
Please visit the Dealer Source for current
information at www.sony.com/dealersource
Features
General
Closed Captions (CC): Analog, Digital
Finish (Surface Color): Black
XMB: Yes
Audio Return Channel: Yes
HDMI™InstaPort: Yes
Start Up Sony Logo Display: Yes
Display
Backlight Type: Edge LED
Display Device: LCD
Video
Video Processing: BRAVIA Engine 3 ™Technology
CineMotion® Reverse 3:2 Pulldown Technology: Yes
Wide Mode: Normal, Zoom, Wide Zoom, Full (Full1-2 for
PC), H Stretch
Deep Color: Yes
3D Comb Filter: Yes
PhotoTV HD: Yes
MPEG Noise Reduction: Yes
Auto Wide: Yes
4:3 Default: Yes
24p True Cinema™Technology: Yes
Picture Mode: Vivid, Standard, Custom, Cinema, Game-
Standard, Game-Original, Graphics, Sports, Photo-
Vivid, Photo-Standard, Photo-Original, Photo-Custom
Advanced Contrast Enhancer (ACE): Yes
Motionflow™Technology: 120Hz
Cinema Mode: Yes
Live Color™Technology: Yes
Audio
Auto SAP: Yes
Auto Mute (on no signal): Yes
Steady Sound® Automatic Volume Control: Yes
Audio Out: Variable/Fixed
Sony Original Surround: Yes
Stereo System: MTS
Dolby ®: Dolby ® Digital
Alternate Audio (Digital): Yes
Surround Effect: Cinema, Music, Live Sports, Game
5.1 Channel Audio Out: Yes
Sound Mode: Dynamic, Standard, Clear Voice, Custom
5.1ch Through Out (Handycam): Yes
Sound Enhancer: Yes
S -Master: Yes
Clear Voice: Yes
Invisible Speaker (w/Sound Elevation): Yes
Convenience
Channel Jump: Yes
Multiple Language Display: English, French, Spanish
Info Banner: TV Guide on Screen, PSIP, XDS
Sleep Timer: Yes
Input Skip: Automatic
Channel Surf: Yes
Channel Block (with password): Yes
Edit Channel Labels: Yes
Label Inputs: Yes
On/Off Timer: Yes
USB Application(s): Photo Viewer (jpeg), Photo Viewer
(RAW), Music Player (mp3), Video Player (AVCHD),
Video Player (AVC), Video Player (MPEG4)
Theatre Mode (Theatre Button): Yes
Show/Hide Channels: Yes
Auto Shut-off: Yes
BRAVIA® Sync™: Yes
Parental Control: Yes
BRAVIA® Sync™Menu Button: Yes (on Remote
Control)
On-Screen Display for External Input: Yes
PIP (Picture in Picture): PC Input/TV Channel&CVBS
Channel Labels: Yes
Control for HDMI™(HDMI™CEC): Yes
Auto Photo Mode: via HDMI, via DLNA, via USB
On-Screen Clock: Yes
Picture Adjustments Lock: Yes
White Balance: RGB Gain/Bias
Auto Picture Setting w/HDMI™: Cinema, Sport, Music,
Photo, Graphics, Game
Scene Select: Auto, Cinema, Sports, Photo, Music,
Game, Graphics, General
Theatre Mode with Cinema Surround: Yes
On-Screen Operating Instructions: Yes
Favorites (Simple UI): Yes
Picture Frame Mode: Yes
Quick Start: Yes
USB Player: Yes
Network
DLNA: Yes
BRAVIA® Internet Video: Yes
Photo MAP: Yes
Wireless LAN: Ready
Sensing
Ambient Sensor: Yes
Presence Sensor: Yes
Broadcast
TV Guide On-Screen: Yes
Design
Stand Swivel: Yes
Stand Swivel Range: Left 20 ° / Right 20 °
Specifications
Display
Viewing Angle (Right/Left): 178(89/89)
Viewing Angle (Up/Down): 178(89/89)
Dynamic Contrast Ratio: Infinite
Screen Size (measured diagonally): 55"
Display Resolution: Full HD 1080(1920x1080)
Aspect Ratio: 16:9
TV System
Tuner (Cable): Clear QAM
Tuner (Terrestrial): ATSC™ / NTSC
Channel Coverage: VHF: 2- 13ch
UHF: 14 - 69ch
CATV (analog): 1- 135ch
CATV (digital) : 1- 135ch
TV System (Analog): M
Number of Tuners (Digital): 1(Hybrid)
Color System: NTSC
Video
Video Signal: 1080/60p (HDMI ™ / COMPONENT), 1080/60i,
1080/24p (HDMI ™ ONLY), 720/60p, 480/60p, 480/60i
Audio
Audio Power Output: 20W (10W x 2)
Speakers (Total): 2
Inputs and Outputs
Component Video (Y/Pb/Pr ) Input(s): 2 (1 Rear / 1
Rear (Composite input common use))
Composite Video Input(s): 2 ( 1 Rear (Component
input common use)/ 1 Side)
Digital Audio Output(s): Optical Digital Output -1 (Rear)
RF Connection Input(s): 1 (Rear)
Analog Audio Input(s) (Total): 4 (1 Side / 3 Rear)
Audio Out: 1 (Rear)
HDMI™Connection(s) (Total): 4(2 Side/2 Rear)
PC In (D-Sub) + Audio In (Stereo Mini): 1 (Rear)
USB 2.0: 1 (Side)
HDMI™PC Input: Yes
AC Power Input: 1 (Rear)
3
Ethernet Connection(s): 1 (Rear)
Power
Power Consumption (in Standby): 0.14W
Power Requirements (voltage): AC 120V for UL,cUL
AC110 -240V for other
Power Requirements (frequency): 60Hz for UL,cUL
50/60Hz for other
Power Consumption (in Operation) max.: 138W
Power Consumption (in Download Acquisition Mode):
15W
Regulation And Standards Compliance
VESA ® Hole Spacing Compatible: Yes
VESA ® Hole Pitch: 400x300 M6
Service and Warranty Information
Limited Warranty Term: 18 Month Labor / 18 Month Parts
Online Instruction Manual (Reference Book): Yes
Energy Saving & Efficiency
Power Saving Modes: Yes
Energy Star® compliant: Exceeds Energy Star® version
4.0
Eco Settings: Yes
Dynamic Backlight Control: Yes
Backlight Off Mode: Yes
Estimated Annual Energy Consumption (kWh):
165.2kWh/year
Energy Saving Switch: Yes
Recycled & Recyclable Materials
Packaging Materials: Recycled Carton (more than 40%)
Weights and Measurements
Weight (Approx.): 57.5 lbs. (26.1kg) with pedestal; 49.1
lbs. (212.8kg) without pedestal
Dimensions (Approx.): 50 3/8 x 31 1/2 x 13 7/8" (1278 x 797
x 350 mm) with pedestal; 50 3/8 x 30 1/8 x 2 7/8" (1278
x 765 x 73mm) without pedestal
Packaging (Approx.): 60 x 33 1/4 x 9 3/8" (1533 x 842 x
237mm)
Supplied Accessories
Wi-Fi Adapter (UWA- BR100)
Remote Control (RM- YD033)
Batteries (Type AAA x2)
AC Power Cord
Table Top Stand (separate, pre-assembled)
Optional Accessories
Wallmount Bracket (SU-WL500)
Wi-Fi Adapter (UWA- BR100)
1.Broadbandinternetconnectionspeedofatleast2.5Mbps
recommended(10MbpsforHDcontent).Videoqualityandpicture
sizevary and are depended upon broadband speed and delivery by
contentprovider.Selectcontentprovidedsubjecttochange.
Premiumcontentmay require additional fees, a subscription and/or
PCregistration.Wireless connectivity requires UWA - BR100USB
adapterorEthernet cable (sold separately), a home network with an
802.11access point (802,11n recommended).
2. HDMI cable required, sold separately. .
3.Dynamic contrast ratio comparestheluminance of a100IRE (white)
signalwiththatofa 0 IRE (black) signal. When the TV receives a 0 IRE
signalthebacklightisturnedoffandtheluminancemeasurementis
0.00cd/m .The resulting dynamic contrast ratio is infinite.
4.Requires home network with an 802.11accesspoint(802.11n
recommended)andinternet connection. USB adapter (UWA - BR100)
required, sold separately.
©2010Sony Electronics Inc.Allrights reserved. Reproductioninwhole or
inpart without writtenpermissionis prohibited. Sony,BRAVIA,Sync,
Motionflow,BRAVIAEngine,make.believe,and the Sony logo, Full HD
1080plogoand BRAVIA logo are trademarks of Sony. PlayStationisa
trademarkofSony Computer Entertainment. Blu - rayDiscis a
trademark.All other trademarksaretrademarks oftheirrespective
owners.Featuresandspecificationsare subject to change without notice.
Features and specifications are subject to change without notice. Non -
metricweights and measures are approximate. Non - metricweightsand
measuresare approximate and may vary.
2
