Sony BRAVIA Installation and operation manual

KDL- 55EX720
55”Class (54.6”diag.) BRAVIA® EX720-Series LED LCD HDTV
Key Features
Brilliant Full HD (1080p) picture quality for 2D & 3D
LED backlit for incredible contrast & slim design
X -Reality™ Engine for a clear, vivid, life - like picture
Smooth motion clarity with MotionFlow ™XR 240
Internet TV for widest variety of internet content
1
Key Technologies
See It All in 3D Enjoy incredible depth and a sharp, Full HD 1080p picture from the leader in 3D
technology. (3D Active Glasses required, sold separately)
Edge LED Backlighting Experience the next level of picture quality and contrast with Sony’s Edge
LED Backlight technology. This technology sharpens image contrast giving an amazingly crisp
picture you can see. The ultra - thin backlight system allows for a slimmer, sleeker design.
X- Reality ™ Engine Enjoy a vivid, lifelike picture experience. Sony’s X - Reality engine brings out the
best by analyzing each scene so you see sharpened images, and amazing contrast detail.
MotionFlow™XR 240 See smooth and precise detail during fast - action scenes. Sony’s Motionflow
XR 240 technology for fast action movies and sports by reducing blur caused by quick camera
movements, enhancing image sharpness, and overall creates a clearer picture.

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 02/15/2011
KDL- 55EX720
55”Class (54.6”diag.) BRAVIA® EX720-Series LED LCD HDTV
Please visit the Dealer Source for current
information at www.sony.com/dealersource
Features
General
Closed Captions (CC): Analog, Digital
Finish (Surface Color): Black
Audio Return Channel: Yes
HDMI™ InstaPort: Yes
Start Up Sony Logo Display: Yes
Display
Backlight Type: Edge LED
Display Device: LCD
Video
Video Processing: X -Reality™Engine
CineMotion® Reverse 3:2 Pulldown Technology:
Yes
Wide Mode: Full, Normal, Wide Zoom, Zoom,
Caption, Normal/Full1/Full2 for PC
Deep Color: Yes
3D Comb Filter: Yes
PhotoTV HD: Yes
Auto Wide: Yes
4:3 Default: Yes
24p True Cinema ™Technology: Yes
Picture Mode: Vivid, Standard, Photo-Vivid,
Photo-Standard, Photo-Original, Photo-
Custom, Cinema, Game-Standard, Game-
Original, Graphics, Sports, Animation
Advanced Contrast Enhancer (ACE): Yes
Live Color™Technology: Yes
Intelligent Image Enhancer: Yes
Intelligent MPEG Noise Reduction: Yes
Motionflow™XR Technology: 240
Audio
Auto SAP: Yes
Auto Mute (on no signal): Yes
Audio Out: Fixed/variable
Sony Original Surround: S- Force Front Surround 3D
Stereo System: MTS
Dolby® : Dolby Digital, Dolby Digital Plus, Dolby
Pulse
Alternate Audio (Digital): Yes
Surround Effect: Cinema, Sports, Music, Game
Sound Booster: Yes
5.1 Channel Audio Out: Yes
Sound Mode: Dynamic, Standard, Clear Voice,
Custom
5.1ch Through Out (Handycam): Yes
Sound Enhancer: Yes
S- Master: Yes
Invisible Speaker (w/Sound Elevation): Yes
Headphone/Speaker Link: Yes
Convenience
Channel Jump: Yes
Multiple Language Display: English, French,
Spanish
Info Banner: Yes
Sleep Timer: Yes
Input Skip: Automatic
Channel Surf: Yes
Channel Block (with password): Analog & Digital
Edit Channel Labels: Yes
Label Inputs: Yes
On/Off Timer: Yes
USB Application(s): Yes
Show/Hide Channels: Yes
Auto Shut -off: Yes
PAP (Fixed or Variable): PAP(Variable)
BRAVIA® Sync ™ : Yes
Parental Control: Yes
On - Screen Display for External Input: Yes
PIP (Picture in Picture): Yes
Control for HDMI™ ( HDMI™CEC): Yes
On - Screen Clock: Yes
Picture Adjustments Lock: Yes
Scene Select: Photo, Music, Cinema, Game,
Graphics, Sports, Animation
On - Screen Operating Instructions: Yes
Picture Frame Mode: Yes
Skin Naturalizer: Yes
Network
DLNA: Yes
BRAVIA® Internet Video: Yes
Photo MAP: Yes
Wireless LAN: Ready (UWA-BR100 required, sold
separately)
HTML Browser: Yes
3D
3D: Yes
2D to 3D Conversion: Yes
Sensing
Presence Sensor: Yes
LightSensor ™Technology: Yes
Broadcast
TV Guide On - Screen: Yes
Design
Stand Swivel: Yes
Stand Swivel Range: Left 20 °/Right 20°
Stand Tilt: Yes
Stand Tilt Range: 0°-6°Flexible
Specifications
Display
Viewing Angle (Right/Left): 176°
Viewing Angle (Up/Down): 176°
Screen Size (measured diagonally): 55" (54.6")
Display Resolution: Full HD 1080p
Aspect Ratio: 16:9
TV System
Tuner (Cable): Clear QAM
Tuner (Terrestrial): ATSC
Channel Coverage: VHF: 2- 13, UHF: 14 -69, CATV:
1-135
TV System (Analog): M
Number of Tuners (Analog): 1
Number of Tuners (Digital): 1
TV System (Digital): ATSC
Color System: NTSC
Video
Video Signal: 1080/24p (HDMI™only), 1080/60i,
1080/60p (HDMI™/ Component), 720/60p,
480/60i, 480/60p
Audio
Audio Power Output: 10W + 10W
Inputs and Outputs
Component Video (Y/Pb/Pr ) Input(s): 1
(Rear/Hybrid)
Composite Video Input(s): 2 (1 Rear/1 Hybrid)
Digital Audio Output(s): 1 (Rear)
RF Connection Input(s): 1 (Rear)
Headphone Output(s): 1 (Side/Hybrid)
Analog Audio Input(s) (Total): 2 (Rear)
Audio Out: 1 (Side/Hybrid)
HDMI™ Connection(s) (Total): 4 (1 Side/3 Rear)
PC In (D- Sub) + Audio In (Stereo Mini): D-Sub 1
(Side), Mini 1(Rear)
USB 2.0: 2 (Side)
HDMI™ PC Input: Yes
AC Power Input: 1 (Rear)
Ethernet Connection(s): 1 (Rear)
Power
Power Requirements (voltage): AC 120V for
UL,cUL; AC 110 -240V for other
Power Requirements (frequency): 60Hz for UL,cUL;
50/60Hz for other
Regulation And Standards Compliance
VESA® Hole Spacing Compatible: Yes
VESA® Hole Pitch: 300 x 300 mm
Service and Warranty Information
Limited Warranty Term: 1Year Labor / 1 Year Parts
Energy Saving & Efficiency
Energy Star ® compliant: Yes (Exceeds v4.1)
Dynamic Backlight Control: Yes
Backlight Off Mode: Yes
Recycled & Recyclable Materials
Packaging Materials: Recycled Carton (more
than 40%)
Weights and Measurements
Weight (Approx.): 44.5 lbs (20.2 Kg) without
stand; 56 lbs (25.4 Kg) with stand
Dimensions (Approx.): 50 x 30 3/8 x 1 5/8" (1269 x
769 x 41mm) without stand; 50 x 31 1/2 x 12
1/2" (1269 x 799 x 315mm) with stand
Packaging (Approx.): 45 x 35 3/4 x 6 7/8" (1441 x
906 x 172mm); 70 lbs (32 Kg)
Supplied Accessories
Remote Control (RM-YD063)
AC Power Cord (attached)
Table Top Stand (separate, assembly required)
Optional Accessories
Wallmount Bracket (SU- WL500)
UPC Code: 027242816862
1.Broadbandinternetconnectionspeedofatleast2.5Mbps
recommended(10MbpsforHDcontent).Videoqualityandpicture
sizevary and are depended upon broadband speed and delivery by
contentprovider.Selectcontentprovidedsubjecttochange.
Premiumcontentmay require additional fees, a subscription and/or
PCregistration
2.Broadbandinternetconnectionspeedofatleast2.5Mbps
recommended(10Mbps for HD content). Video quality and picture
sizevary and are depended upon broadband speed and delivery by
contentprovider. Premium content may require additionalfees,a
subscriptionand/orPCregistration. Feature is subject to Skype ’ s
termsandconditions, which Skype has the ability to change at
anytime.
3.Requiresall devices to be connected to the same home network.
©2011Sony Electronics Inc.Allrights reserved. Reproductioninwhole or
inpart without writtenpermissionis prohibited. SonyBRAVIA,BRAVIA
Sync,LightSensor, Motionflow and X - Realityaretrademarks of Sony. Wi - Fi
isaregistered trademark of the Wi - FiAlliance. Skype is atrademarkof
SkypeLimited. DLNA isaregistered trademark oftheDigital Living
NetworkAlliance. All othertrademarks are trademarksoftheir
respectiveowners.Featuresandspecificationsaresubjecttochange
withoutnotice.Non - metricweights and measures are approximate and
mayvary.
