Sony A-700T User manual

— 1 —
A-700T
X2FCHASSIS
SERVICE MANUAL
COLOR COMPUTER DISPLAY
N. Hemisphere Model
Chassis No.SCC-L10E-A
A-700T
SPECIFICATIONS
Picture Tube
Video image area
Logical resolution
Physical resolution
Standard image area
Deflection frequency
AC input voltage / current
Dimensions
Mass
Approx. 312 x 234 mm (w/h)
(12
3/8
x 9
1/4
inches)
Horizontal: 30 to 70 KHz
Vertical: 50 to 120 Hz
100 to 120 V, 50-60 Hz, 1.8 A (max.)
220 to 240 V, 50-60 Hz, 1.0 A
406 x 426.5 x 451 mm (w/h/d)
(16 x 16
7/8
x 17
7/8
inches)
Approx. 18.5 kg (40lbs 13oz)
Design and specifications are subject to change without notice.
0.25 mm aperture grill pitch
17 inches measured diagonally
90-degree deflection
(15.9" maximum viewing image)
Approx. 327 x 241 mm (w/h)
(12
7/8
x 9
1/2
inches)
Horizontal: Max. 1280 dots
Vertical: Max. 1024 lines
Horizontal: Max. 1024 dots
Vertical: Max. 768 lines

— 2 —
A-700T
State Power Required u Power indicator POWER SAVING
consumption resumption time indicator
MODE 1 2 3 4 5 6 7
Resolution(H x V)
Dot Clock(MHz)
Hor. Freq. (kHz)
H-Total
H-Blanking
H-Front Porch
H-Sync.
H-Back Porch
H-Active
(µsec)
Ver. Freq. (Hz)
V-Total
V-Blanking
V-Front Porch
V-Sync.
V-Back Porch
V-Active
(lines)
HORIZONTAL
VERTICAL
SYNC.
Int(G)
Ext (H/V)/Polarity
Ext (CS)/Polarity
Int / Non Int Non Int Non Int Non Int Non Int Non Int Non Int Non Int
No
Yes -/-
No
No
Yes +/+
No
No
Yes +/+
No
No
Yes -/-
No
No
Yes +/+
No
No
Yes +/+
No
POWER SAVING FUNCTION
This monitor meets the power saving guidelines set
by the EPA Energy Star Program as well as the more
stringent TC092 guidelines (NUTEK). It is capable of
reduced power consumption when used with a com-
puter equipped with Display Power Management Sig-
naling (DPMS). By sensing the absence of the sync
signal coming from the computer, it will reduce the
power consumption as follows:
< 15W approx. 3 sec. green on orange on
< 15W approx. 3 sec. green on orange on
Suspend
(2nd step of power saving)
Stand-by
1st step of power saving)
Normal Operation < 110W green on off
< 8W approx. 10 sec. off orange on
1
2
3
4
The Power Saving function will automati-
cally put the monitor into Active-off state
if the power switch is turned on without
any video signal input. Once the horizon-
tal and vertical syncs are sensed, the moni-
tor will automatically return to its Normal
operation state.
CAUTION:
TIMING SPECIFICATION
640 x 480
25.175
31.469
31.778
6.356
0.636
3.813
1.907
25.422
59.940
525
45
10
2
33
480
800 x 600
49.500
46.875
21.333
5.172
0.323
1.616
3.232
16.162
75.000
625
25
1
3
21
600
800 x 600
56.250
53.674
18.631
4.409
0.569
1.138
2.702
14.222
85.061
631
31
1
3
27
600
832 x 624
57.283
49.725
20.111
5.586
0.559
1.117
3.910
14.524
74.550
667
43
1
3
39
624
1024 x 768
78.750
60.023
16.660
3.657
0.203
1.219
2.235
13.003
75.029
800
32
1
3
28
768
1280 x 1024
108.000
63.981
15.630
3.778
0.444
1.037
2.296
11.852
60.020
1066
42
1
3
38
1024
1024 x 768
94.500
68.677
14.561
3.725
0.508
1.016
2.201
10.836
84.997
808
40
1
3
36
768
No
Yes +/+
No
Active-off
(3rd step of power saving)

— 3 —
A-700T
SAFETY CHECK-OUT
(US Model only)
After correcting the original service problem, perform
the following safety checks before releasing the set to the
customer:
LEAKAGE TEST
The AC leakage from any exposed metal part to earth ground
and from all exposed metal parts to any exposed metal part having
a return to chassis, must not exceed 0.5 mA (500 microampere).
Leakage current can be measured by any one of three methods.
WARNING!!WARNING!!
WARNING!!WARNING!!
WARNING!!
NEVER TURN ON THE POWER IN A CONDITION IN WHICHTHE
DEGAUSS COIL HAS BEEN REMOVED.
SAFETY-RELATED COMPONENTWARNING!!
COMPONENTS IDENTIFIED BY SHADING AND MARK ¡ON
THE SCHEMATIC DIAGRAMS, EXPLODED VIEWS AND IN THE
PARTS LIST ARE CRITICAL FOR SAFE OPERATION. REPLACE
THESE COMPONENTS WITH SONY PARTS WHOSE PART
NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN
SUPPLEMENTS PUBLISHED BY SONY.CIRCUIT ADJUSTMENTS
THAT ARE CRITICAL FOR SAFE OPERATION ARE IDENTIFIED
IN THIS MANUAL. FOLLOW THESE PROCEDURES WHENEVER
CRITICAL COMPONENTS ARE REPLACED OR IMPROPER
OPERATION IS SUSPECTED.
AVERTISSEMENT!!
NE JAMAIS METTRE SOUS TENSION OUAND LA BOBINE DE
DEMAGNETISATION EST ENLEVEE.
ATTENTION AUX COMPOSANTS RELATIFS A LA
SECURITE!!
LES COMPOSANTS IDENTIFIES PAR UNETRAME ET PAR UNE
MARQUE ¡ SUR LES SCHEMAS DE PRINCIPE, LES VUES
EXPLOSEES ET LES LISTES DE PIECES SONT D'UNE
IMPORTANCE CRITIQUE POUR LA SECURITE DU
FONCTIONNEMENT. NE LES REMPLACER QUE PAR DES
COMPOSANTS SONY DONT LE NUMERO DE PIECE EST
INDIQUEDANSLEPRESENT MANUEL OU DANS DES SUPPLE-
MENTS PUBLIES PAR SONY. LES REGLAGES DE CIRCUIT
DONT L'IMPORTANCE EST CRITIQUE POUR LA
SECURITE DU FONCTIONNEMENT SONT IDENTIFIES DANS
LE PRESENT MANUEL.SUIVRE CES PROCEDURES LORS DE
CHAQUE REMPLACEMENT DE COMPOSANTS CRITIQUES, OU
LORSQU'UN MAUVAIS FONTIONNEMENT SUSPECTE .
1. Check the area of your repair for unsoldered or
poorly-soldered connections. Check the entire board
surface for solder splashes and bridges.
2. Check the interboard wiring to ensure that no wires
are “pinched” or contact high-wattage resistors.
3. Check that all control knobs, shields, covers, ground
straps, and mounting hardware have been replaced.
Be absolutely certain that you have replaced all the
insulators.
4. Look for unauthorized replacement parts,
particularly transistors, that were installed during
a previous repair. Point them out to the customer
and recommend their replacement.
5. Look for parts which, though functioning, show
obvious signs of deterioration. Point them out to
the customer and recommend their replacement.
6. Check the line cords for cracks and abrasion.
Recommend the replacement of any such line cord
to the customer.
7. Check the B+ and HV to see if they are specified
values. Make sure your instruments are accurate;
be suspicious of your HV meter if sets always have
low HV.
8. Check the antenna terminals, metal trim,
“metallized" knobs, screws, and all other exposed
metal parts for AC Leakage. Check leakage as
described below.
1. A commercial leakage tester, such as the Simpson 229 or
RCA WT-540A. Follow the manufacturers' instructions to
use these instructions.
2. A battery-operated AC milliammeter. The Data Precision
245 digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of
a VOM or battery-operated AC voltmeter. The "limit"
indication is 0.75 V, so analog meters must have an accurate
low voltage scale. The Simpson's 250 and Sanwa
SH-63Trd are examples of passive VOMs that are suitable.
Nearly all battery operated digital multimeters that have a
2V AC range are suitable. (See Fig. A)
1.5 k Ω 0.15 µF AC
Voltmeter
(0.75 V)
To Exposed Metal
Parts on Set
Earth Ground
Fig. A. Using an AC voltmeter to check AC leakage.

— 4 —
A-700T
TABLE OF CONTENTS
Section Title Page
1. GENERAL................................................................................... 5
2. DISASSEMBLY
2-1. Cabinet Removal ............................................................8
2-2. Service Position .............................................................. 8
2-3. D Board Removal ........................................................... 8
2-4. Picture Tube Removal ................................................... 9
3. SAFETY RELATED ADJUSTMENT................................. 10
4. ADJUSTMENTS ........................................................................11
5. DIAGRAMS
5-1. Block Diagram ................................................................15
5-2. Circuit Boards Location ................................................. 18
5-3. Schematic Diagrams and Printed Wiring Boards ...... 18
1. D Board - Schematic Diagram .................................19
2. A Board - Schematic Diagram ................................. 23
5-4. Semiconductors ..............................................................27
6. EXPLODEDVIEWS
6-1. Chassis ............................................................................ 29
6-2. Packing Materials .......................................................... 30
7. ELECTRICAL PARTS LIST ................................................ 31

— 5 —
A-700T
4
Adjustments
A number of digital controls are provided to allow you to
optimize the display parameters to your preferences.
You can adjust the picture to your preferences by following
the procedure described below.
You can adjust all items on the OSD (On Screen Display).
POWER
SAVING
Push this part to open the control panel cover.
pAdjustments will be stored automatically.
pThe OSD automatically disappears 3 seconds after you
release the buttons.
Control Panel
Contrast
The adjustment data becomes the common setting for all
input signals.
1 Press the >+/– button.
The >OSD (On Screen Display) appears.
2 Press the >+/– button to adjust picture contrast.
+.... for more contrast
– ....for less contrast
Horizontal centering
The adjustment data becomes the unique setting for the
input signal received.
1 Press the S∫/ıbutton.
The SOSD (On Screen Display) appears.
2 Press the S∫/ıbutton.
∫... to move right
ı... to move left
Brightness
The adjustment data becomes the common setting for all
input signals.
1 Press the ¨+/– button.
The ¨OSD (On Screen Display) appears.
2 Press the ¨+/– button to adjust picture brightness.
+.... for more brightness
– ....for less brightness
Vertical centering
The adjustment data becomes the unique setting for the
input signal received.
1 Press the s◊/√button.
The sOSD (On Screen Display) appears.
2
Press the s◊/√button.
◊... to move up
√... to move down
POWER
SAVING
RESET
3
EN
Installation
•Prevent internal heat buildup by allowing adequate air
circulation. Do not place the unit on surfaces (rugs,
blankets, etc.) or near materials (curtains, draperies) that
may block the ventilation holes.
•Do not install the unit near heat sources such as radiators
or air ducts, or in a place subject to direct sunlight,
excessive dust, mechanical vibration or shock.
•Do not place the unit near equipment that generates
magnetism, such as a converter or high-voltage power
lines.
Maintenance
Clean the cabinet, glass panel, and controls with a soft cloth,
lightly moistened with a mild detergent solution. Do not use
any type of abrasive pad, scouring powder, or solvent, such
as alcohol or benzine.
Transportation
When you transport this monitor for repairing or shipping,
use the original carton box and packing materials.
Table of Contents
Precautions ............................................................................... 3
Getting Started ......................................................................... 3
Adjustments.............................................................................. 4
Power Saving Function ........................................................... 6
Plug and Play ........................................................................... 6
Damper Wire .......................................................................... 6
Use of the Tilt-Swivel ............................................................7
Specifications .......................................................................... 7
Troubleshooting ..................................................................... 7
Precautions
Warning on Power Connection
•Use the supplied power cord.
Before using this monitor, make sure that the following
items are included in your package:
the monitor, power cord and this operating instruction
manual.
This monitor will sync to platforms running at horizontal
frequencies between 30 and 70 kHz.
Connecting the Computer
Step 1: With the computer switched off, attach the video
signal cable to the video output.
Step 2: Attach the power cord to the monitor and then to
the power outlet.
Step 3: Turn on the monitor and computer.
Step 4: If necessary, adjust the user controls according to
your personal preference.
The installation is complete.
Computer
to the video output
Power cord (supplied)
to the power
outlet
Getting Started
for 220 to 240 V AC
for 100 to 120 V AC
For the customers in U.S.A.
If you do not do this, this monitor will not conform to
mandatory FCC standards.
•Before disconnecting the power cord, wait for at least
30 seconds after turning off the power switch to allow for the
discharging of static electricity on the CRT display surface.
•After the power has been turned on, the CRT is
demagnetized for approximately 5 seconds. This
generates a strong magnetic field around the bezel, which
may affect the data stored on magnetic tape or disks near
the bezel. Place such magnetic recording equipment and
tapes/disks at a distance from this unit.
The socket-outlet shall be installed near the equipment
and shall be easily accessible.
The instructions given here are partial abstracts from the Operating Instruction
Manual. Thepagenumbersshown reflect those of the Operating Instruction Manual.
SECTION 1
GENERAL

— 6 —
A-700T
5
EN
RESET
Horizontal size
The adjustment data becomes the unique setting for the
input signal received.
1 Press the Å+/– button.
The ÅOSD (On Screen Display) appears.
2 Press the Å+/– button.
+.... to enlarge
– .... to diminish
Vertical size
The adjustment data becomes the unique setting for the
input signal received.
1
Press the +/– button.
The OSD (On Screen Display) appears.
2 Press the +/– button.
+.... to enlarge
– .... to diminish
2 Press the d+/– button.
+ ... to expand the picture sides
– ... to diminish the picture sides
Pincushion
The adjustment data becomes the unique setting for the
input signal received.
1 Press the d+/– button.
The dOSD (On Screen Display) appears.
Rotation
The adjustment data becomes the common setting for all
input signals.
1 Press the +/– button.
The OSD (On Screen Display) appears.
2 Press the +/– button.
+.... to rotate clockwise
– .... to rotate counterclockwise
Resetting
•Press the RESET button to recall the
factory settings for brightness, contrast,
pincushion, horizontal and vertical size,
and center for the mode currently in
use.
•Press and hold the RESET button for 2
seconds to recall factory settings for all
adjustments in all modes.
Color Adjustment
This adjustment is common to all input signals received.
1 Press the + buttons of the Raster Rotation and the >
Contrast simultaneously. The OSD (On Screen Display)
appears.
2 Press the >+/– button.
+.... for higher color temperature
– .... for lower color temperature
Press the +
buttons
simul-
taneously
6
Required
resumption time
—
approx. 3 sec.
approx. 3 sec.
approx. 10 sec.
State
Normal operation
Stand-by
(1st step of power saving)
Suspend
(2nd step of power saving)
Active-off
(3rd step of power saving)
Plug and Play
Damper Wire
Using a white background, very thin horizontal stripes on
the screen are visible as shown right. These stripes are the
damper wires. These wires are attached to the aperture
grille inside the Trinitron tube and are there to damp
vibrations of the aperture grille in order to prevent them
from influencing the picture quality.
Approx. 6 cm
Approx. 6 cm
Damper wire
Power Saving Function
This monitor meets the power-saving guidelines set by the
International
E nergy S tar Program as well as the more
stringent NUTEK 803299 (TCO92) guidelines. It is capable
of reduced power consumption when used with a computer
equipped with Display Power Management Signaling
(DPMS). By sensing the absence of the sync signal coming
from the computer, it will reduce the power consumption as
follows:
CAUTION: The Power Saving function will automatically
put the monitor into Active-off state if the
power switch is turned on without any video
signal input. Once the horizontal and vertical
syncs are sensed, the monitor will
automatically return to its Normal operation
state.
Power consumption
110 W
15 W
15 W
8 W
uPower indicator
green on
green on
green on
off
POWER SAVING
indicator
off
orange on
orange on
orange on
1
2
3
4
This monitor complies with the DDC
TM
1,DDC2B and
DDC2AB which are the Display Data Channel (DDC)
standards of VESA.
When a DDC1 host system is connected, the monitor
synchronizes with the V. CLK in accordance with the VESA
standards and outputs the EDID (Extended Display
Identification Data) to the data line.
When a DDC2B or DDC2AB host system is connected, the
monitor automatically switches to each communication.
DDC
TM
is a trademark of Video Electronics Standard
Association.
•Your monitor operates according to the VESA DDC Level
2AB. Only computers that support the same guidelines
and operate at the same or higher level can make use of
this feature.
•If your computer does not support the relevant
guidelines, you can still use your monitor and computer.
You may need to specify manually the appropriate
resolution in the computer.
•The highest resolution selected automatically may not
give the best result. In that case select the most suitable
resolution manually in the computer.

— 7 —
A-700T
8
If the message of “OUT OF
SCAN RANGE”
appears on the screen
Picture is scrambled
Color is not uniform
Screen image is not
centered or sized properly
Picture is fuzzy
Picture bounces or has
wavy oscillations
A fine horizontal line
(wire) is visible
Screen image is tilted
Edges of the image are
curved.
Wavy or elliptical (moire)
pattern is visible
Symptom
Troubleshooting
Check these items
*The Auto-degauss function demagnetizes the metal frame of the CRT in order to obtain a
neutral field for uniform color reproduction. If a second degauss cycle is needed, allow a
minimum interval of 20 minutes for the best result.
** Trinitron

is a registered trademark of Sony Corporation.
•If the problem persists, call your authorized dealer from a location near your monitor.
•Note the model name and the serial number of your monitor. Also note the make and name of your computer and video
board.
•Check that the video sync signal is specified for the monitor.
•Check your graphics board manual for the proper monitor setting on your monitor.
•Check this manual and confirm that the graphics mode and the frequency at which you
are trying to operate is supported. Even within the proper range, some video boards
may have a sync pulse that is too narrow for the monitor to sync correctly.
•Trip the upower switch once to activate the Auto-degauss cycle*.
•Adjust centering or size (pages 4, 5).
•Some video modes do not fill the screen to the edge of the monitor. There is no single
answer to solve the problem. There is tendency to have this problem on higher refresh
timings.
•Adjust the Contrast and Brightness controls (page 4). Several brands of SVGA boards
have an excessive video output level which creates a fuzzy picture at max contrast.
•Trip the upower switch once to activate the Auto-degauss cycle*.
•Move electrical (magnetic) devices that may be creating electrical interference away
from the monitor.
•If you have another monitor close to this monitor, increase the distance between them to
reduce the interference.
•Your office may have electric power wiring behind the wall. Move the monitor away
from the wall.
•This wire stabilizes the vertically striped Aperture Grille. This Aperture Grille allows
more light to pass through to the screen giving the Trinitron

** CRT more color and
brightness.
•Trip the upower switch once to active the Auto-degauss cycle∗.
Then, adjust the Rotation (page 5).
•Adjust the Pincushion (page 5).
•Due to the relationship between resolution, monitor dot pitch, and the pitch of some
image patterns, certain screen backgrounds, especially gray, sometimes show moire.
This can only be eliminated by changing your desktop pattern.
7
EN
Check these items
•Check that the power cord is properly connected.
•Check that the upower switch is in the “on” position.
•Check that your computer power switch is in the “on” position.
•The monitor will recover when you press any key on the keyboard of the computer.
•Check that the video cable is properly connected.
•Ensure that no pins are bent or pushed in the HD15 connector of the cable.
•Check that the video card is seated completely in a proper bus slot.
•Check that the video sync signal is within that specified for the monitor.
•Use the monitor’s self-diagnosis function to check for any other problems. To use the self-
diagnosis, power down the monitor, then press and hold the upower switch until the u
(power) indicator begins to blink (after about five seconds), then the screen should turn
white and a display of three colored bars (red, green, and blue) appears in the middle of the
black display. If you observe these conditions, the monitor is working properly.
•Turn the monitor off and on. If the indicator is not flashing, the monitor is in the normal
condition.
•There is a potential monitor failure. Contact your dealer.
Symptom
No picture
If neither the u(power)
indicator nor the POWER
SAVING indicator is lit
If the POWER SAVING
indicator is lit
If the u(power) and the
POWER SAVING
indicators are both flashing
Use of the Tilt-Swivel
45°
15°
45°
With the tilt-swivel base, this unit can be adjusted to be
viewed at your desired angle within 90° horizontally and
20° vertically.
To turn the unit vertically and horizontally, hold it at its
bottom with both hands.
5°
Specifications
Picture tube 0.25 mm aperture grille pitch
17 inches measured diagonally
90-degree deflection
Viewable image size
Approx. 327 ×241 mm (w/h)
(12
7
/ 8 ×9
1
/ 2 inches)
15.9” viewing image
Resolution Horizontal: Max. 1280 dots
Vertical: Max. 1024 lines
Display picture size Approx. 312 ×234 mm (w/h)
(12
3
/ 8 ×9
1
/ 4 inches)
Deflection frequency Horizontal: 30 to 70 kHz
Vertical: 50 to 120 Hz
AC input voltage/current
100 to 120 V, 50/60 Hz, 1.8 A
220 to 240 V, 50-60 Hz, 1 A
Dimensions 406 ×426.5 ×451 mm (w/h/d)
(16 ×16
7
/ 8 ×17
7
/ 8 inches)
Mass Approx. 18.5 kg (40 lb 13 oz)
Design and specifications are subject to change without
notice.
Troubleshooting
This section may help you isolate a problem and, as a result, eliminate the need to contact technical support, allowing continued
productivity.

— 8 —
A-700T
1
2
3
A board
D board
1
2
3
Two screws
(BVTP 4 x 16)
Cabinet
Two claws
PUSH
PUSH
2-3. D BOARD REMOVAL
Cable bracket
Cable stopper
Five screws
(BVTP 3 x 12)
D board
One screw
(BVTT 4 x 8)
1
2
3
5
6
7
A board
Two screws
(BVTP 3 x 12)
4
2-1. CABINET REMOVAL 2-2. SERVICE POSITION
SECTION 2
DISASSEMBLY

— 9 —
A-700T
2-4. PICTURE TUBE REMOVAL
Turn up one side of the rubber cap in
the direction indicated by arrow . When one side of the rubber cap sepa-
rates from the anode button, the anode-
cap can be removed by turning the rub-
ber cap and pulling it in the direction of
arrow .
Use your thumb to pull the rubber cap
firmly in the direction indicated by
arrow .
HOWTO HANDLE AN ANODE-CAP
REMOVAL OFTHE ANODE-CAP
NOTE: Short circuit the anode of the picture tube and the anode cap to the metal chassis, CRT shield or carbon painted on the CRT, after
removing the anode.
REMOVAL PROCEDURES
Do not use sharp objects which may cause damage to the surface
of the anode-cap.
Do not squeeze the rubber covering too hard to avoid damaging
the anode-cap. A material fitting called a shatter-hook terminal is
built into the rubber.
Do not force turn the foot of the rubber cover. This may cause the
shatter-hook terminal to protrude and damage the rubber.
Demagnetization coil
Tension spring
Stand assy
(D board)
A board
Neck assy
Deflection yoke
Four screws
(Tapping screw 5)
Anode cap
Cushion
Picture tube shield
Two screws
(BVTP 4 x 16)
1
6
9
10
5
4
3
2
7
8

— 10 —
A-700T
b) HV Hold-Down Check
1) Using an external DC Power supply, apply the
voltage shown below between cathode of D511
on "D" Board and GND, and confirm that the
HV Hold-Down circuit works. (Raster disappears)
Standard voltage: 35.00 + 0.05 VDC
Check Condition
• Input voltage : 120 + 2 VAC
• Input signal : Any pattern (fH = 64 kHz)
• Controls : CONT 2Maximum
: BRT 2Center
c) Beam Protector Check
1) Using an external DC power supply, apply the
voltage 7.00 + 0.05 VDC between pin 11 of FBT
(T501) and GND, and confirm that the voltage
of both ends C519 is with in the voltage range
shown below.
Standard voltage: Less than 3.26 VDC
Check Condition
• Input voltage : 120 + 2 VAC
• Input signal : Any pattern (fH = 64 kHz)
• Controls : CONT 2Maximum
: BRT 2Center
d) +B MAX. Check
1) Input white cross hatch (fH = 64 kHz) signal.
2) Set CONT and BRT to Maximum
3) Input voltage: 120 + 2 VAC
Note: Use NF power supply or make sure that
distortion factor is 3% or less.
4) Confirm that the voltage is within the voltage
range shown below.
Standard voltage: 151.0 + 4.25 VDC
Measurement Point: CN505 Pin 1 and GND
SECTION 3
SAFETY RELATED ADJUSTMENT
Part Replaced ([)
RV501
Part Replaced (])
D - BOARD
IC801, IC901, IC904, FBT T501, D511, D515, D596,
R532, R533, R534, R535, R538, R539, R540, R541,
R542, R543, R544, R545, R807, R822, R823, R824,
R939, R996, RV501, C509, C515, C516, C517, C519,
C528, C531, C542, C548, C549, C802, C814, C815,
C904, C910, R598, R599
When replacing parts shown in the table below, the
following operational checks must be performed as a
safety precaution against X-rays emissions from the unit.
Allow the unit to warm up for one minute prior to
checking the following conditions:
a) HV Regulator Check
1) Input white cross hatch signal. (fH = 64 kHz)
2) Set H.Size data to minimum.
3) Cut off Screen VR (G2).
4) Input voltage: 120 + 2 VAC
5) Confirm that the voltage is within the voltage range
shown below:
Standard voltage: 25.0KV + 0.2KV
6) When replacing components identified by ], make
sure to recheck the High Voltage.
7) Verify the High Voltage as shown above (25.0KV + 0.2KV)
is within specification. If not, set H. SIZE data at
minimum (-127) and then adjust RV501 on "D" Board.
8) After adjusting the High Voltage within specification,
put the RV cover on RV501 as shown below and apply
sufficient amount of RTV around RV501.
104
RV501

— 11 —
A-700T
Landing Rough Adjustment
1. Enter the full white signal.
2. Adjust the contrast to the maximum.
3. Make the screen monogreen.
4. Reverse the DY, and adjust coarsely the purity magnet so
that a green raster positions in the center of screen.
5. Moving the DY forward, adjust so that an entire screen
becomes monogreen.
6. Adjust the tilt of DY, and fix lightly with a clamp.
Landing Fine Adjustment
1. Place the set in the Helmholtz coil.
2. Enter a green signal only.
3. Degauss the entire screen with hand-degausser.
Then auto degauss it.
4. Attach a wobbling coil to the specified position of CRT
neck.
5. Attach a landing adjuster sensor on the CRT.
6. Using a landing checker, adjust the DY position, purity on
DY, tilt of DY.
7. Clamp the DY screw.
Clamping torque: 22 + 2 kgcm (2.2+ 0.2 Nm)
Convergence Rough Adjustment
1. Enter the white crosshatch signal.
2. Adjust roughly the horizontal and vertical
convergence at four-pole magnet.
3. Adjust roughly HMC and VMC at six-pole
magnet.
SECTION 4
ADJUSTMENTS
*The parts above ( ~ ) are necessary for DAS adjustment.
IBM AT Computer
as a Jig
1-690-391-21
1A-1500-819-A
Interface Unit
2
3
D-sub
(9 Pin [female]) mini Din (8Pin) 4 Pin
3-702-691-01
Connector Attachment
3
To BUS CONNECTOR
4 Pin 4 Pin
1
2
1
R
B
RB
RB
R
B
1
2
R
B
R
B
2
1
2
1+
2
1+
2
1
Set the
finger
Mechanical
Center
Connect the communication cable of the connector located on the D board on the monitor. Run the service software and
then follow the instructions.
Allow a 30 minute warm-up period prior to making the following adjustments.
Convergence Fine Adjustment
Set DY four-pole magnet to mechanical center
before adjustment.
This should be prime mode.
1. Receive R.B. crosshatch.
2. Adjust H. STAT and V. STAT at four-pole magnet.
< 4 Pole Magnet>
NECK Assy
6-pole Mg P.S Mg
XBV
DY CRT
4-pole Mg

— 12 —
A-700T
Zero Position NECK Asssembly
Purity Purity 4-Pole Mg 6-Pole Mg
on DY on NA
Vertical and Horizontal Position and Size
Specification
Convergence Specification
Focus Adjustment
Adjust focus (V) and focus (H) for optimum focus.
15. Adjust V.TILT with TLV VR.
TLV movement
16. Adjust Y.CROSS with YCH VR.
YCH movement
17. Adjust YBH with YBH VR.
YBH Movement
18. Paint lock the four-pole magnet ,six-pole magnet, XBV
reactor, XCV corrector and TLH corrector handle.
<VR Adjustment on DY>
2
1
2
1
G
G
3. Receive White cross-hatch.
4. Adjust HMC and VMC at six-pole magnet.
< 6 Pole Magnet>
5. Display R and B cross hatch patterns.
6. Adjust H STAT and V STAT with 4-pole magnet.
7. Display white cross hatch patterns.
8. Adjust HMC and VMC with 6-pole magnet.
9. Display R and B cross hatch patterns.
10. Adjust XCV and XCV roller.
11. Adjust XBV and XBV reactor.
12. Adjust V.STAT with 4-pole magnet.
Repeat steps 7 to 12 above and make R, G, B of both vertical and
horizontal lines to be overlaid at the center of the x-axis.
13. Adjust H.TILT with TLH Corrector.
14. Adjust XCV with XCV core.
XCV movement
R
B
R
B
B
R
RB
R
B
R B
6-Poles Magnet
(H.STAT/V.STAT
Corrector)
6-Poles Magnet
(HMC/VMC
Corrector)
Purity Magnet
Purity Magnet
(Keep zero position at all times)
A 0.24mm
B 0.30mm
B
A
a < 2.5mm
b < 2.5mm
0.24mm
0.28mm
FOCUS (H)
FOCUS (V)
A B
234mm 312mm
bb
a
a
A
B
R
B
B
R
YCH TLV
XCV

GDS
123
or
1
i‘j
2
i{j
3
i‘
j
1
i‘j
2
i|j
3
i‘
j
ECB
12
34
5
6
7
8
8
1234
5
6
7
MTZJ-T-77-4.7B
MTZJ-T-77-5.6B
MTZJ-T-77-8.2B
RB441QT-77
RD27ES-T1B2
MTZJ-T-77-10B
MTZJ-T-77-18
RD4.7ES-T1B2
RD5.6ES-T1B2
1SS119-25TD
5-4. SEMICONDUCTORS
EGP20DPKG23
EGP10GPKG23
1SS133T-77
UF3ML-6505
RGP02-20EL-6394
3DL41A (LC6-15)
HSS 82
SN74HCT02AN
2SC5022-02
SNY425
GBU4JL-6088NJM4558D GP104005-E-G23
5TUZ52
TDA9105S
TDA 8172
LM2406T
UF4007G23
TDA6103QEGP30D
2SA1037K-T-146-QR
VPC5023CS-095 MC 44603P
SEL1422G-C
SG232D-658
SEL1922D-C
SY432W-M-658
LA 6500-FA
M0C8105TV
CATHODE
ANODE
SB340L-6489
CATHODE
ANODE
5
12346789
1
2
3
4
5
6
7
8
9
E
B
C
BCE
CATHODE
ANODE
CATHODE
ANODE
TL 431CLP
16 9
18
ST7272N5B1/CMI
56 29
128
22 12
111
42
21
22
1
24 13
112
LM1281
28
14
15
1
PST600D-T
Vcc
GND OUT
123
4
5
6
123
4
5
6
5
1
BCE
CATHODE
ANODE
7
1
‘‘
{
|
‘‘
{|
CATHODE
ANODE
CATHODE
ANODE
ECB
ECB
E
LETTER SIDE
CB
ECB
BCE
B
CE
1
14
GS
D
GDS
B
EC
GSD
1
11
2SD2394-F
2SC3941A-Q (TA) 2SA1048TP-VGR
2SC3311A-QRSTA
2SA1309A-QRSTA
2SC3209-TK 2SC2001TP-K2 2SB1375
2SB1565F 2SC5129
2SK2562-01-F1652SK1904IRFIBC40G-LF38 2SD1640Q IRFI9630 DTC124ES-TP
GS
D
CATHODE
ANODE
A-700T
14
1
8
7

— 17 —
A-700T
5-2. CIRCUIT BOARDS LOCATION
Note:
• All capacitors are in µF unless otherwise noted. pF: µµF
50 WV or less are not indicated except for electrolytic.
• Indication of resistance, which does not have one for rating
electrical power, is as follows.
• All resistors are in ohms.
• f: nonflammable resistor.
• F:fusible resistor.
•∆: internal component.
•p:panel designation and adjustment for repair.
• e : earth-ground.
• E : earth-chassis.
• The components identified by [in this basic schematic
diagram have been carefully factory-selected for each set
in order to satisfy regulations regarding X-ray radiation.
Should replacement be required, replace only with the
value originally used.
• When replacing components identified by ],make the necessary
adjustments by using RV501 ([)as indicated. (See page 10)
• All variable and adjustable resistors have characteristic curve B,
unless otherwise noted.
•When replacing parts shown in the table below,
be sure to perform the safety related adjustment.
Part Replaced ([)
RV501
Part Replaced (])
D - BOARD
•All voltages are in volts.
•Readings are taken with a 10 ΜΩ digital multimeter
•Readings are taken with a color-bar signal input.
•Voltage variations may be noted due to normal
production tolerances.
•* : Cannot be measured.
•Circled numbers are waveform references.
•: B +bus.
•: B - bus.
Pitch: 5 mm
Rating electrical power 1/4 W (CHIP: 1/10 W)
Note: The components identified by shading and
mark ¡ are critical for safety. Replace only
with part number specified.
Note: Les composants identifies per un trame et une
marque ¡sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifie.
5-3. SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS
D
A
IC801, IC901, IC904, FBT (T501),
D511, D515, D596, R532, R533,
R534, R535, R538, R539, R540,
R541, R542, R543, R544, R545,
R807, R822, R823, R824, R939,
R996, RV501, C509, C515, C516,
C517, C519, C528, C531, C542,
C548, C549, C802, C814, C815,
C904, C910, R598, R599
— 18 —

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
— 29 —
A-700T
19 1-543-653-11 CORE ASSY, BEAD (DIVISION TYPE)
20 4-389-025-01 SCREW (M4x8) (EXT.TOOTHWASHER)
21 7-685-882-09 SCREW + BVTT 4x10 (S)
22 * 4-045-131-01 STOPPER, CABLE
23 * 1-782-687-11 CABLE ASSY (15P D-SUB)
24 * 4-045-130-01 BRACKET, CABLE
25 * 4-043-646-01 HOLDER, STAND
26 4-046-901-01 SPRING, TENSION
27 4-041-623-01 STOPPER (A), STAND
28 4-059-044-12 COVER, BOTTOM
29 * 4-041-625-21 RING, TILT SWIVEL
30 X-4034-732-2 STAND BASE, ASSY
31 4-041-621-21 STOPPER (B), STAND
32 * X-4034-733-2 CABINET ASSY
33 * 4--061-225-01 LABEL, INFORMATION
34 3-704-372-31 HOLDER, HV CABLE
35 1-452-032-00 MAGNET, DISC
36 X-4029-622-2 PERMALLOY ASSY, CORRECTION
• Items marked " * " are not stocked
since they are seldom required for routine
service. Some delay should be
anticipated when ordering these items.
• Items with no part number and no
description are not stocked because
they are seldom required for routine
service.
• The component parts of an assembly
are indicated by the reference numbers
in the remarks column.
SECTION 6
EXPLODED VIEWS
6-1. CHASSIS
r
¢
7-685-648-79 SCREW +BVTP 3X12
7-685-663-71 SCREW +BVTP 4X16
The components Identified by shading
and mark ¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
Les composants identifies per un trame
et une marque ¡¡
¡¡
¡sont critiques pout la
securite. Ne les remplacer que par une
piece portant le numero specifie.
10
30
21
1
12
22
2
13
23
3
14
24
4
15
25
5
16
26
6
17
27
7
18
28
7
19
29
920
4
11
31
32
34
35
36
8
6
7
8
13
14
23
22
12
9
17
19
18
20
21
12
10
11
24
27
25
28
29
30
31
26
15
16
32 33
33
5
4
3
2
1
1 X-4034-986-1 BEZEL ASSY 2-5
2 4-392-036-01 CATCHER, PUSH
3 * 4-059-036-11 DOOR
4 4-059-038-11 BUTTON, POWER
5 3-571-801-01 SPRING, COMPRESSION
6¡8-738-725-05 CRT 17FRFM (M41LKN15X)
7 4-040-897-01 SPACER, DY
8¡1-452-923-21 NECK ASSY (NA-2914)
9¡8-451-487-11 DY Y17FRG-M
10 ¡8-738-723-80 ITC ASSY (17FRF-R1) 6-9
11 1-500-386-11 FILTER CLAMP (FERRITE CORE)
12 * A-1298-104-A A BOARD, COMPLETE
13 * 4-061-573-01 SPRING, TENSION
14 ¡1-416-282-21 COIL, DEMAGNETIZATION
15 * 4-056-260-01 SPACER, DGC
16 4-365-808-01 SCREW (5), TAPPING
17 * A-1346-612-A D BOARD, COMPLETE
18 ¡X-4034-572-1 TRANSFORMER ASSY, FLYBACK (NX-4103//J1E4)

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
— 30 —
A-700T
51 3-861-115-11 MANUAL, INSTRUCTION
52 ¡1-776-027-41 CORD SET, POWER
53 * 4-046-461-01 CUSHION (UPPER ASSY)
54 * 4-041-927-11 BAG, POLYETHYLENE
55 4-046-460-01 PAD, FIXED TILT
56 * 4-047-033-01 CUSHION (LOWER ASSY)
57 * 4-061-224-01 INDIVIDUAL CARTON
6-2. PACKING MATERIALS
REF.NO. PART NO. DESCRIPTION REMARK
51 52
53
54
55
56
57

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
— 31 —
A-700T
SECTION 7
ELECTRICAL PARTS LIST
RESISTORS
•All resistors are in ohms
•F : nonflammable
CAPACITORS INDUCTORS
• MF =µFUH = µH
MH = mmH
When indicating parts by reference
number, please include the board name.
The components Identified by shading
and mark ¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
Note:
Les composants identifies per un trame
et une marque ¡¡
¡¡
¡sont critiques pout la
securite. Ne les remplacer que par une
piece portant le numero specifie.
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
•All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
Thecomponents identified by[in thismanual
have been carefully factory-selected for each
set in order to satisfy regulations regarding X-
rayradiation. Shouldreplacementbe required,
replace only with the value originally used.
*
•Items marked " " are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
* A-1298-104-A A BOARD, COMPLETE
4-382-854-01 SCREW (M3X8), P, SW (+)
CAPACITOR
C001 1-136-169-00 FILM 0.22MF 5% 50V
C002 1-137-528-11 FILM 0.1MF 10% 250V
C003 1-137-528-11 FILM 0.1MF 10% 250V
C004 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C005 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C006 1-126-934-11 ELECT 220MF 20% 16V
C007 1-104-664-11 ELECT 47MF 20% 25V
C008 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C009 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C010 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C011 1-106-220-00 MYLAR 0.1MF 10% 100V
C012 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C013 1-126-934-11 ELECT 220MF 20% 16V
C014 1-107-932-11 ELECT 47MF 20% 100V
C015 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C016 1-126-933-11 ELECT 100MF 20% 16V
C017 1-126-933-11 ELECT 100MF 20% 16V
C018 1-107-746-11 ELECT 10MF 20% 200V
C019 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C020 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C021 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C022 1-164-346-11 CERAMIC CHIP 1MF 16V
C023 1-163-275-11 CERAMIC CHIP 0.001MF 5% 50V
C024 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C025 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C026 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C027 1-164-346-11 CERAMIC CHIP 1MF 16V
C028 1-107-888-11 ELECT 47MF 20% 25V
C029 1-107-823-11 CERAMIC CHIP 0.47MF 10% 16V
C030 1-164-489-11 CERAMIC CHIP 0.22MF 10% 16V
C031 1-162-318-11 CERAMIC 0.001MF 10% 500V
C035 1-115-349-51 CERAMIC 0.01MF 2KV
C036 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C037 1-126-933-11 ELECT 100MF 20% 16V
C040 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C041 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C055 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C088 1-126-934-11 ELECT 220MF 20% 16V
C092 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C100 1-104-664-11 ELECT 47MF 20% 25V
C101 1-126-960-11 ELECT 1MF 20% 50V
C103 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C104 1-107-823-11 CERAMIC CHIP 0.47MF 10% 16V
C105 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C106 1-137-528-11 FILM 0.1MF 10% 250V
C107 1-164-346-11 CERAMIC CHIP 1MF 16V
C108 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C109 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C110 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C201 1-126-960-11 ELECT 1MF 20% 50V
C202 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C203 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C204 1-107-823-11 CERAMIC CHIP 0.47MF 10% 16V
C205 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C206 1-137-528-11 FILM 0.1MF 10% 250V
C207 1-164-346-11 CERAMIC CHIP 1MF 16V
C209 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C301 1-126-960-11 ELECT 1MF 20% 50V
C302 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C303 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C304 1-107-823-11 CERAMIC CHIP 0.47MF 10% 16V
C305 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C306 1-137-528-11 FILM 0.1MF 10% 250V
C307 1-164-346-11 CERAMIC CHIP 1MF 16V
C309 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C330 1-107-905-11 ELECT 4.7MF 20% 50V
C334 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C351 1-137-528-11 FILM 0.1MF 10% 250V
A
A

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
— 32 —
A-700T
ALes composants identifies per un trame et
une marque ¡¡
¡¡
¡sont critiques pout la
securite. Ne les remplacer que par une
piece portant le numero specifie.
Note: The components Identified by shading
and mark ¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
CONNECTOR
CN301 1-506-108-41 PIN, CONNECTOR (TERMINAL PIN)
CN302 1-695-915-11 TAB (CONTACT)
CN303 1-695-915-11 TAB (CONTACT)
CN305 1-564-513-11 PLUG, CONNECTOR 10P
CN306 * 1-564-510-11 PLUG, CONNECTOR 7P
CN307 * 1-564-512-11 PLUG, CONNECTOR 9P
CN309 1-564-511-11 PLUG, CONNECTOR 8P
CN310 * 1-564-507-11 PLUG, CONNECTOR 4P
CN311 * 1-564-507-11 PLUG, CONNECTOR 4P
CN399 1-695-915-11 TAB (CONTACT)
DIODE
D002 8-719-911-19 DIODE 1SS119-25
D014 8-719-911-19 DIODE 1SS119-25
D016 8-719-109-89 DIODE RD5.6ESB2
D017 8-719-109-89 DIODE RD5.6ESB2
D101 8-719-911-19 DIODE 1SS119-25
D102 8-719-911-19 DIODE 1SS119-25
D104 8-719-970-83 DIODE HSS82
D105 8-719-970-83 DIODE HSS82
D106 8-719-970-83 DIODE HSS82
D201 8-719-911-19 DIODE 1SS119-25
D202 8-719-911-19 DIODE 1SS119-25
D204 8-719-970-83 DIODE HSS82
D205 8-719-970-83 DIODE HSS82
D206 8-719-970-83 DIODE HSS82
D301 8-719-911-19 DIODE 1SS119-25
D302 8-719-911-19 DIODE 1SS119-25
D304 8-719-970-83 DIODE HSS82
D305 8-719-970-83 DIODE HSS82
D306 8-719-970-83 DIODE HSS82
D307 8-719-110-49 DIODE RD18ESB2
FERRITE BEAD
FB001 1-412-911-11 FERRITE
FB003 1-412-911-11 FERRITE
FB004 1-412-911-11 FERRITE
FB005 1-412-911-11 FERRITE
FB006 1-412-911-11 FERRITE
FB007 1-412-911-11 FERRITE
FB008 1-412-911-11 FERRITE
FB009 1-412-911-11 FERRITE
FB010 1-412-911-11 FERRITE
FB011 1-412-911-11 FERRITE
FB012 1-412-911-11 FERRITE
FB013 1-412-911-11 FERRITE
FB101 ¡1-500-104-21 FERRITE
FB102 ¡ 1-414-793-21 FERRITE
FB103 1-500-104-21 FERRITE
FB104 1-412-911-11 FERRITE
FB110 1-412-911-11 FERRITE
FB201 ¡ 1-500-104-21 FERRITE
FB202 ¡1-414-793-21 FERRITE
FB203 1-500-104-21 FERRITE
FB210 1-412-911-11 FERRITE
FB301 ¡ 1-500-104-21 FERRITE
FB302 ¡ 1-414-793-21 FERRITE
FB303 1-500-104-21 FERRITE
FB310 1-412-911-11 FERRITE
IC
IC001 8-759-474-78 IC MM1382
IC002 8-759-435-33 IC LM2405T
IC003 8-759-399-76 IC SNY425
IC004 8-759-434-40 IC TDA6103Q/N3,112
IC005 8-759-634-51 IC M5218AP
JACK
J001 ¡1-251-598-11 SOCKET, CRT
COIL
L001 1-412-537-31 INDUCTOR 100UH
L101 1-407-500-00 INDUCTOR 4.7MMH
L105 1-410-750-41 INDUCTOR 0.47UH
L201 1-407-500-00 INDUCTOR 4.7MMH
L205 1-410-750-41 INDUCTOR 0.47UH
L301 1-407-500-00 INDUCTOR 4.7MMH
L305 1-410-750-41 INDUCTOR 0.47UH
TRANSISTOR
Q001 8-729-032-61 TRANSISTOR 2SC5022-02
Q002 8-729-216-22 TRANSISTOR 2SA1162-G
Q003 8-729-216-22 TRANSISTOR 2SA1162-G
Q004 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q005 8-729-216-22 TRANSISTOR 2SA1162-G
Q006 8-729-216-22 TRANSISTOR 2SA1162-G
RESISTOR
R001 1-216-049-91 RES,CHIP 1K 5% 1/10W
R002 1-216-661-11 METAL CHIP 2.7K 0.50% 1/10W
R003 1-216-101-00 RES,CHIP 150K 5% 1/10W
R004 1-216-085-00 RES,CHIP 33K 5% 1/10W
R005 1-216-049-91 RES,CHIP 1K 5% 1/10W
R006 1-216-025-91 RES,CHIP 100 5% 1/10W
R007 1-216-049-91 RES,CHIP 1K 5% 1/10W
R008 1-216-025-91 RES,CHIP 100 5% 1/10W
