Sony SCPH-10281 User manual

© 2002 Sony Computer Entertainment Inc. All rights reserved.
3-086-430-11(1) F
SCPH-10281/ 97043
Instruction manual
Thank you for purchasing the network adaptor (Ethernet/modem) (for
PlayStation
® 2). You can use this product with PlayStation ® 2 format software
compatible with the network adaptor (for PlayStation ® 2). Before using this product,
carefully read this manual and retain it for future reference.
The network adaptor is exclusively for use with the PlayStation
® 2 computer
entertainment system, and is not recommended for use with any other product.
Mode d’emploi
Nous vous remercions d’avoir fait l’acquisition de l’adaptateur réseau (Éthernet/
modem) (pour PlayStation ® 2). Vous pouvez utiliser ce produit avec des logiciels au
format PlayStation
® 2 compatibles avec l’adaptateur réseau (pour PlayStation ® 2).
Avant d’utiliser ce produit, lisez attentivement ce mode d’emploi et conservez-le pour
pouvoir vous y reporter ultérieurement.
L’adaptateur réseau est conçu pour être utilisé exclusivement avec le système de loisir
interactif PlayStation
® 2, et n’est pas recommandé pour d’autres produits.
Manual de instrucciones
Gracias por adquirir el adaptador de red (Ethernet/modem) (para PlayStation ® 2).
Puede utilizar este producto con software de formato PlayStation
® 2 compatible con el
adaptador de red. Antes de utilizar este producto, lea detenidamente este manual y
consérvelo para consultarlo en el futuro.
Este adaptador de red está diseñado para utilizarse exclusivamente con el sistema de
entretenimiento computarizado PlayStation
® 2 y no se recomienda su uso con otro
tipo de producto.
Network Adaptor (Ethernet/modem)
(for PlayStation®2)
Adaptateur Réseau (Éthernet/modem)
(pour PlayStation®2)
Adaptador de Red (Ethernet/modem)
(para PlayStation®2)

2
WARNING
To prevent fire or shock hazard, do not expose the unit to
rain or moisture.
To avoid electrical shock, do not disassemble.
Refer servicing to qualified personnel only.
This graphical symbol with supplemental marking is located on the PlayStation®2
console.
This symbol is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
This symbol is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature
accompanying the console.
Caution
To reduce the risk of fire, use only No. 26 AWG or larger telecommunication line
cord.
For questions about AWG numbers, contact our technical support line at
1-800-345-7669.

US
3
Information
For customers in the USA
This equipment complies with Part 68 of the FCC rules and the requirements
adopted by the ACTA. On the bottom surface of this equipment is a label that
contains, among other information, a product identifier in the format
US:AAAEQ##TXXXX. If requested, this number must be provided to the telephone
company.
The REN is used to determine the number of devices that may be connected to a
telephone line. Excessive RENs on a telephone line may result in the devices not
ringing in response to an incoming call. In most but not all areas, the sum of the
RENs should not exceed five (5.0). To be certain of the number of devices that may
be connected to a line, as determined by the total RENs, contact the local telephone
company. For products approved after July 23, 2001, the REN for this product is
part of the product identifier that has the format US:AAAEQ##TXXXX. The digits
represented by ## are the REN without a decimal point (e.g., 03 is a REN of 0.3).
For earlier products, the REN is separately shown on the label.
A jack used to connect this equipment to the premises wiring and telephone
network must comply with the applicable FCC Part 68 rules and requirements
adopted by the ACTA.
This product uses the “RJ-11C” telephone jack.
If this equipment causes harm to the telephone network, the telephone company
will, when practical, notify you in advance that temporary discontinuance of
service may be required. If advance notice is not practical, the telephone company
will notify you as soon as possible. Also, you will be advised of your right to file a
complaint with the FCC if you believe it is warranted.
The telephone company may make changes to its facilities, equipment, operations
or procedures that could affect the operation of equipment. If this happens, the
telephone company will provide advance notice so you can make the necessary
modifications to maintain uninterrupted service.
If you have questions about this product, call our technical support line at
1-800-345-7669, or write to:
Sony Computer Entertainment America
Consumer Services/Technical Support
PO Box 5888, San Mateo, CA 94402-0888 U.S.A.

4
This equipment cannot be used on telephone company provided coin service.
Connection to party line service is subject to state tariffs.
Repair of this product should be made only by an authorized Sony Service Center.
For the Sony Service Center nearest you, call 1-800-345-7669.
Telephone Consumer Protection Act of 1991
The Telephone Consumer Protection Act of 1991 makes it unlawful for any person
to use a computer or other electronic device to send any message via a telephone
facsimile machine unless such message clearly contains, in a margin at the top or
bottom of each transmitted page or on the first page of the transmission, the date
and time it is sent and an identification of the business, other entity, or individual
sending the message, and the telephone number of the sending machine or such
business, other entity, or individual. In order to program this information into your
facsimile machine, see your facsimile software documentation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following
measures:
–Reorient or relocate the receiving antenna.
–Increase the separation between the equipment and receiver.
–Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
–Consult the dealer or an experienced radio/TV technician for help.
You are cautioned that any changes or modifications not expressly approved in this
manual could void your authority to operate this equipment.
WARNING (continued)

US
5
For customers in Canada
This product is Industry Canada label identified equipment. This certification
means that the equipment meets certain telecommunications network protective,
operational and safety requirements as prescribed in the appropriate Terminal
Equipment Technical Requirements document(s). The Department does not
guarantee the equipment will operate to the user’s satisfaction. Before installing
this equipment, users should ensure that it is permissible to be connected to the
facilities of the local telecommunications company. The equipment must also be
installed using an acceptable method of connection.
The customer should be aware that compliance with the above conditions may not
prevent degradation of service in some situations.
Repairs to certified equipment should be coordinated by a representative
designated by the supplier. Any repairs or alterations made by the user to this
equipment, or equipment malfunctions, may give the telecommunications
company cause to request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical ground connections
of the power utility, telephone lines and internal metallic water pipe system, if
present, are connected together. This precaution may be particularly important in
rural areas.
Caution: Users should not attempt to make such connections themselves, but
should contact the appropriate electric inspection authority or an electrician.
NOTICE: The Ringer Equivalence Number (REN) assigned to each terminal device
provides an indication of the maximum number of terminals allowed to be
connected to a telephone interface.
The terminals on an interface may consist of any combination of devices subject
only to the requirement that the sum of the Ringer Equivalence Number of all the
devices does not exceed five (5.0).
The Ringer Equivalence Number for this equipment is 0.1.
The term “IC:” before the certification/registration number only signifies that the
Industry Canada technical specifications were met.

6
Owner’s record
The model and serial numbers are located on the network adaptor rear. Record the
appropriate number in the space provided below. Refer to these numbers
whenever you call for technical assistance at 1-800-345-7669.
Model No. SCPH-10281
Serial No. _______________________________
Important notice
Before installing this product in your PlayStation®2 console, review the list
of serial numbers below. A small percentage of PlayStation®2 consoles may
not be compatible with this product. If the serial number of your
PlayStation®2 console (found on the console rear) matches any of the
numbers in this list, contact our technical support line at 1-800-345-7669 for
further information.
Serial numbers
WARNING (continued)
3369556 – 3369651
3372352 – 3372651
3379084 – 3380151
3380260 – 3381867
3381976 – 3382083
3383152 – 3383691
3384652 – 3385191
3386152 – 3386907
3388192 – 3389271
3391084 – 3392055
3393868 – 3394407
3394516 – 3394731
3397192 – 3398055
3399868 – 3400947
3403192 – 3403839
3404692 – 3405339
3406192 – 3406515
3406624 – 3406839
3414661 – 3416388
3417661 – 3418740
3419173 – 3419280
3419821 – 3419928
3420661 – 3421308
3421417 – 3421524
3421633 – 3422064
3423661 – 3424848
3425161 – 3425268
3434377 – 3434592

US
7
Table of contents
WARNING ....................................................................... 2
Important safeguards ..................................................... 8
About this product ........................................................ 16
Precautions ................................................................... 17
Checking the package contents .................................... 21
Part names .................................................................... 22
Installing the network adaptor in the
PlayStation®2 console ................................................ 23
Removing the network adaptor from the
PlayStation®2 console ................................................ 27
Using the network adaptor ........................................... 30
Positioning a console with a network adaptor installed .............. 30
Connecting to a telephone line ................................................... 32
Connecting with a network cable ............................................... 34
Troubleshooting............................................................ 36
Specifications ............................................................... 40
LIMITED WARRANTY ..................................................... 41

8
Important safeguards
For your protection, please read these safety
instructions completely before operating the appliance,
and keep this manual for future reference.
Carefully observe all warnings, precautions and
instructions on the appliance, or those described in the
instruction manual and adhere to them.
USE
Power sources
This unit should be operated only from
the type of power source indicated on
the marking label. If you are not sure of
the type of electrical power supplied to
your home, consult your dealer or local
power company. For those units
designed to operate from battery
power, or other sources, refer to the
operating instructions.
Grounding or polarization
The unit is equipped with a polarized
AC power cord plug (a plug having one
blade wider than the other). This plug
will fit into the power outlet only one
way. This is a safety feature. If you are
unable to insert the plug fully into the
outlet, try reversing the plug. If the
plug should still fail to fit, contact your
electrician to have a suitable outlet
installed. Do not defeat the safety
purpose of the polarized plug by
forcing it in.

US
9
Overloading
Do not overload wall outlets, extension
cords or convenience receptacles
beyond their capacity, since this can
result in fire or electric shock.
Liquid and foreign objects
Never push objects of any kind into the
unit through openings as they may
touch dangerous voltage points or short
out parts that could result in a fire or
electric shock. Never spill liquid of any
kind on the unit.
Attachments
Do not use attachments not
recommended by the manufacturer, as
they may cause hazards.
Cleaning
Unplug the unit from the wall outlet and
disconnect the phone cord from the
telephone wall jack and/or network
cable from the network device before
cleaning or polishing it. Do not use
liquid cleaners or aerosol cleaners. Use a
cloth lightly dampened with water for
cleaning the exterior of the unit. For
detailed instructions on cleaning the
network adaptor, see “Cleaning the
network adaptor” (page 20).

10
Important safeguards (continued)
INSTALLATION
Water and moisture
Do not use the powerline operated unit
near water – for example, near a
bathtub, washbowl, kitchen sink, or
laundry tub, in a wet basement or near
a swimming pool, etc.
Power cord protection
Route the power cord so that it is not
likely to be walked on or pinched by
items placed upon or against it, paying
particular attention to the plugs,
receptacles, and the point where the
cord exits from the unit.
Ventilation
The slots and openings in the cabinet
are provided for necessary ventilation.
To ensure reliable operation of the unit,
and to protect it from overheating,
these slots and openings must never be
blocked or covered.
–Never cover the slots and openings
with a cloth or other materials.
–Never block the slots and openings
by placing the unit on a bed, sofa,
rug or other similar surface.

US
11
Accessories
Do not place the unit on an unstable
cart, stand, bracket or table. The unit
may fall, causing serious injury to a
child or an adult, and serious damage
to the unit.
Use only a cart, stand, tripod, bracket,
or table recommended by the
manufacturer.
An appliance and cart combination
should be moved with care. Quick
stops, excessive force, and uneven
surfaces may cause the appliance and
cart combination to overturn.
–Never place the unit in a confined
space, such as a bookcase, or
built-in cabinet, unless proper
ventilation is provided.
– Do not place the unit near or over a
radiator or heat register, or where it
is exposed to direct sunlight.

12
Important safeguards (continued)
ANTENNAS
Outdoor antenna grounding – If an outdoor antenna or cable
system is installed, follow the precautions below.
An outdoor antenna system should not be located in the vicinity of
overhead power lines or other electric light or power circuits, or
where it can come in contact with such power lines or circuits.
WHEN INSTALLING AN OUTDOOR ANTENNA SYSTEM,
EXTREME CARE SHOULD BE TAKEN TO KEEP FROM
CONTACTING SUCH POWER LINES OR CIRCUITS AS
CONTACT WITH THEM IS ALMOST INVARIABLY FATAL.
Be sure the antenna system is grounded so as to provide some
protection against voltage surges and built-up static charges.
Section 810 of the National Electrical Code provides information
with respect to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an antenna discharge
unit, size of grounding conductors, location of antenna-discharge
unit, connection to grounding electrodes, and requirements for the
grounding electrode.
Ground Clamp
Ground Clamps
Power Service Grounding
Electrode System
(NEC Art 250, Part H)
Grounding Conductors
(NEC Section 810-21)
Electric
Service
equipment
Antenna Lead in Wire
Antenna Discharge unit
(NEC Section 810-20)
NEC- National Electrical Code

US
13
SERVICE
Damage requiring service
Unplug the unit from the wall outlet
and refer servicing to qualified service
personnel under the following
conditions:
–When the power cord or plug is
damaged or frayed.
–If liquid has been spilled or objects
have fallen onto the unit.
–If the unit has been exposed to rain
or water.
FRAYED OR TAUT CORD
CRACKED PLUG
Lightning
For added protection for this unit during a lightning storm, or
when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the phone cord and
the antenna or cable system. This will prevent damage to the unit
due to lightning and power-line surges.
Do not touch the network adaptor during a lightning storm as this
may expose you to the risk of electrical shock.

14
Important safeguards (continued)
–If the unit has been subject to
strong physical shock by being
dropped, or the cabinet has been
damaged.
–If the unit does not operate
normally when following the
instruction manual. Adjust only
those controls that are specified in
the instruction manual. Improper
adjustment of other controls may
result in damage and will often
require extensive work by a
qualified technician to restore the
unit to normal operation.
–When the unit exhibits a distinct
change in performance – this
indicates a need for service.

US
15
Servicing
Do not attempt to service the unit
yourself as opening or removing the
covers may expose you to dangerous
voltage or other hazards.
Refer all servicing to qualified service
personnel.
Replacement parts
When replacement parts are required,
be sure the service technician has used
replacement parts specified by the
manufacturer that have the same
characteristics as the original parts.
Unauthorized substitutions may result
in fire, electric shock, or other hazards.
Safety check
Upon completion of any service or
repairs to the unit, ask the service
technician to perform routine safety
checks (as specified by the
manufacturer) to determine that the
unit is in safe operating condition.

16
About this product
Compatible models
The network adaptor (Ethernet/modem) (for PlayStation®2) is
designed exclusively for use with the PlayStation®2 console.
Compatible software
This product can be used with PlayStation ® 2 format software
compatible with the network adaptor (for PlayStation ® 2).
Usage of the network adaptor may vary depending on the software
in use. Hardware requirements may also vary. For details, refer to
the appropriate software manual.
PlayStation®2 format software compatible with the network
adaptor (for PlayStation®2) is required to use this product.
Notes
• To use the network adaptor (Ethernet/modem) (for PlayStation ® 2),
you may be required to use the supplied network adaptor start-up
disc to create network settings. A memory card (8MB) (for
PlayStation ® 2) (sold separately) is required to save network
settings.
• The network adaptor (Ethernet/modem) (for PlayStation ® 2) is
marked with the letters “ ” to indicate that it can be used
in conjunction with the internal hard disk drive (for PlayStation ® 2)
(sold separately). Internal hard disk drive release date to be
determined. Check for availability.
•Parents are encouraged to monitor children in using this product
to ensure safe and responsible Internet usage.

US
17
Precautions
Safety
This product has been designed with the highest concern for safety.
However, any electrical device, if used improperly, has the
potential for causing fire, electrical shock or personal injury. To
ensure accident-free operation, follow these guidelines:
•Observe all warnings, precautions and instructions.
•Stop use immediately if the device functions in an abnormal
manner, or produces unusual sounds or smells.
•Never connect cables of types other than those specified in this
manual to the line connector and network connector. Connect
only cables of the proper type for each connector.
•If the device does not function properly, contact our technical
support line at 1-800-345-7669 for assistance.
Use and handling
•Do not throw or drop the network adaptor, or subject it to strong
physical shock.
•Do not place the network adaptor on surfaces that are unstable,
tilted or subject to vibration.
•Never move or change the position of a console with a network
adaptor installed while it is turned on.
•Do not expose the network adaptor to high temperatures, high
humidity or direct sunlight (use in an environment where
temperatures range 5°C – 35°C/41°F – 95°F).
•Do not place the network adaptor in locations subject to sudden
temperature change (e.g. temperature changes of 10°C/18°F per
hour or more).
•Do not use the network adaptor in a dusty location.
•Do not allow liquid or small particles to get into the network
adaptor.
•Do not place the network adaptor close to magnetic fields such as
those produced by magnets, loudspeakers or television sets.

18
Precautions (continued)
•Never disassemble or modify the network adaptor.
•Do not put heavy objects on the network adaptor.
•Do not touch the metal parts or insert foreign objects into the
connectors or buzzer port of the network adaptor.
•When you do not intend to use the network adaptor for an
extended period of time, disconnect the power plug for the
PlayStation®2 console from the electrical outlet and the telephone
cord from the wall jack.
•When disconnecting the power plug from an electrical outlet, pull
it out by grasping the plug. Never pull the cord itself.
• Do not connect any unauthorized internal peripheral to the
network adaptor.
•Do not place any rubber or vinyl materials on the exterior of the
network adaptor for an extended period of time. Doing so may
damage the plastic surface.
Connecting to a telephone line
Do not connect a cord of any type other than a home-use phone
cord to the LINE connector.
If you connect a telephone cord or network cable of a type other
than that specified to the line connector, too much electrical current
may pass through the connector, causing a malfunction, excessive
heat or fire in the connector. Never connect phone cords of the
following types (especially a home network or business phone
cord) to the line connector:
•The jack of an ISDN (digital) compatible public phone
•PBX phone lines
•Cellular phone or car phone
•Telephone lines for home networks or business phones

US
19
Connecting with a network cable
Do not connect network cables or telephone cords of the following
types to the NETWORK connector; too much electrical current may
pass through the connector, causing a malfunction, excessive heat
or fire in the connector:
•Network cables of types other than 100Base-TX and 10Base-T
•Normal telephone lines
•The jack of an ISDN (digital) compatible public phone
•PBX phone lines
•Telephone lines for home networks or business phones
•Other types of telephone lines
Telephone line usage
•If a telephone call is received while the modem is in use, the
modem connection may fail or the console may malfunction.
•The modem and the telephone cannot be used at the same time.
Moisture condensation
If brought directly from a cold location to a warm one, moisture
may condense on the outside or inside of the network adaptor.
Should this occur, the network adaptor may not operate properly.
In this case, do not turn on the PlayStation®2 console until the
moisture evaporates (this could take several hours). If the console
or network adaptor still does not operate properly after this period
of time, contact our technical support line at 1-800-345-7669 for
assistance.

20
Precautions (continued)
Cleaning the network adaptor
For safety reasons, before cleaning the network adaptor, 1) turn off
the PlayStation®2 console using the MAIN POWER switch on the
console rear, 2) disconnect the power plug from the electrical outlet
and, 3) remove the telephone cord and/or network cable from the
network adaptor.
•Do not use paint thinner, solvents or other chemicals to clean the
exterior of the network adaptor, as these may damage the surface.
When using a commercially available cleaning cloth, follow the
instructions supplied with the cloth.
• If the exterior of the network adaptor becomes dirty, soak a soft
cloth in a mild detergent solution diluted with water, tightly
squeeze the cloth to remove the excess liquid, wipe the affected
area of the exterior, and finish by wiping with a dry cloth.
Never disassemble the network adaptor
Use the network adaptor according to the instructions in this
manual. No authorization for the analysis or modification of
the network adaptor, or the analysis and use of its circuit
configurations is provided.
