Sony STR-DG1100 User manual

STR- DG1100
7.1 Channel Surround Sound A/V Receiver
Key Features
Xross Media Bar ® inspired graphic user interface
Exclusive Faroudja ® DCDi Cinema™Up Scaling Technology
4
BRAVIA ® Theatre Sync™technology
iPod ® Ready with DIGITAL MEDIA PORT (TDM - IP1 Sold Separately)
100 Watts X 7 Power Amplifier (8 ohms, 20Hz - 20kHz, 0.09% THD)
Optimized for Blu - ray Disc™and other HD sources
6
Supports x.v.Color™technology (xvYCC)
Accepts 1080/60p and 24p video signal via HDMI™
4
HDMI “Active Intelligence”(3 inputs/1 output)
4
Accepts 8ch linear PCM via HDMI™
4
Video up - scaling via HDMI™(up to 1080p)
4
Digital Cinema™Auto Calibration with mono mic
Sirius and XM Connect - and - Play™Ready with Neural 5.1 Surround
3
Portable Audio Enhancer
Key Technologies
Optimized for Blu - ray Disc™and Other HD Sources The STR -DG1100 is engineered to be the ideal Blu-ray Disc® A/V receiver,
fully compatible with the Sony® family of Blu-ray Disc Players. Superior video switching and audio performance ensure seamless
compatibility with today's demanding HD sources. The STR-DG1100 features up to three High Definition Multimedia Interface (HDMI™ )
inputs which are capable of accepting resolutions up to 1080p, offering the full video quality that Blu-ray Disc® format can deliver.
6
Up to 8 channels of Linear PCM audio Provides full compatibility with Blu-ray Disc® format's linear PCM (uncompressed) output,
producing up to eight channels of "high quality" audio reproduction.
HDMI "Active Intelligence" The receiver can detect and receive the best possible video and audio signals from all connected
devices-making connection and performance as simple as plugging in a single wire. Sony's HDMI "Active Intelligence" produces both
audio and video through one HDMI cable (sold separately).
Faroudja ® DCDi Cinema™Chipset for Up Scaling to 1080p IC processor developed by Faroudja, and first used by Sony,
which will up scale and up convert all video signals (less than 1080p) to 1080p via HDMI. This chipset corrects image jaggedness;
reduces block noise and reproduces true to original colors. The end result is a beautiful and smooth high definition image.
4
Xross Media Bar ® Inspired Graphic User Interface An on -screen menu system that simplifies the most complex operations of
an A/V receiver for home theater applications. This advanced menu system incorporates icons, an easy to follow "tree" system and a
blending technique so users know exactly where they are amongst the various settings while still watching their main video source (up
to 1080i). The menu includes access to DIGITAL MEDIA PORT accessories (sold separately), the ability to assign HDMI inputs and
independent A/V sync control for each input. It's simple. Just pick up the remote and a whole new experience will be revealed.
Down Conversion Component and S-video sources can be down converted to lower resolution outputs, thus customizing video
connectivity to home theater requirements from a single source. Also, both receivers can take HD sources from component video and
down convert the signal for use with composite or S-Video ouputs. This is ideal for distributing video through multiple rooms with fewer
wires.
Digital Cinema Auto Calibration An ideal listening experience is only a button away. Simply place the included microphone in
your listening position, push a single button and speaker position, distance and delays are automatically calibrated. Sony's Digital
Signal Processing uses feedback between the microphone and receiver to optimize sound settings.
Sirius and XM Connect - and - Play™Ready with Neural Surround A world of digital radio at your fingertips. Connect the
optional antenna for either Sirius and/or XM subscription service and enjoy the variety and quality of digital radio with the superior
sound quality of an A/V receiver. In addition to stereo, you can enjoy 5.1 surround broadcasting. XM radio is a satellite radio service
that provides pay-for-service radio, analogous to cable television.
3
Portable Audio Enhancer The 7.1 A/V Receivers are ideal for today's portables. A powerful Digital Signal Processor expands the
quality of sound from any connected device. Simplified front-side audio and video connections make it easy to play portables
through the receiver.

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 08/04/2008
STR- DG1100
7.1 Channel Surround Sound A/V Receiver
Please visit the Dealer Network for current
information at www.sony.com/dn
Features
Video
UpConversion: Yes (HDMI, Component
1080p)
UpScaling: Yes (HDMI Up Scaling up to
1080p)
Audio
Dolby ® DigitalDecoding: Yes
Dolby ® Pro Logic ® IIDecoding: Yes
dts ® 96/24Decoding: Yes
dts ® NEO:6Decoding: Yes
Dolby ® Digital EX Decoding: Yes
Dolby ® Pro Logic ® IIX Decoding: Yes
Dolby ® Pro Logic ® Decoding: Yes
dts ® - ES Decoding: Yes
Digital Cinema Sound™ Technology: Yes
dts ® Decoding: Yes
Convenience
A/B Speaker Switch: Yes (A / B / A+B)
Digital Cinema Auto Calibration: Yes (Mic -
Mono)
HDMI™ Technology: Intelligent A/V Selector
On - ScreenDisplay: Yes
Specifications
Speaker
Center Speaker Terminal: Yes
Surround Back Speakers: Yes
Speaker Terminal Type: Screw Binding
Posts (A & B)
Audio
Impedance: 8 Ohms
Channel Power Rating: 7.1 Channel Power
Rating: 100W x 7 Amp Power (8 ohms,
20Hz - 20Khz, 0.09% THD)
SoundFields: Cinema - 4; Music - 6; Auto
Format Decoding - 14; 2 Channel - 1;
Headphone - 4
TunerType: Auto Tuning, Direct Tuning,
Station Name, Presets 30/30/30
(XM/FM/AM)
Convenience
AM/FM Memory Presets: 30 FM - 30 AM
XM ® Connect and Play™Compatible: Yes
(Neural 5.1 Surround Sound Decoding)
XM ® MemoryPresets: 30
PresetMemory: 30 Sirius ® Presets
Inputs and Outputs
Component Video (Y/Pb/Pr ) Input(s): 3
(Rear)
Component Video (Y/Pb/Pr) Output(s): 1
(Rear)
Composite Video Input(s): 5 (1 Front/4
Rear)
Composite Video Output(s): 3 (Rear - 1
Monitor Output, 2 Video Outputs)
Optical Audio Input(s): 5 (1 Front/4 Rear)
Optical Audio Output(s): 2 (Rear)
Coaxial Audio Digital Input(s): 3 (Rear)
RCA Audio Input(s): 5 (Rear)
RCA Audio Output(s): 2 (Rear)
Multi - ChannelInput(s): 1 (Rear, 7.1
Channel)
SubwooferOutput(s): 1 (Rear)
PhonoInput(s): 1 (Rear)
ACOutlet: 2 (Rear) Switched
Antenna Terminal (AM Loop): 1 (Rear)
Antenna Terminal (FM 75 Ohm): 1 (Rear)
HeadphoneOutput(s): 1 (Front - Gold)
HD Component Video Input(s): 3 (Rear)
HD Component Video Output(s): 1 (Rear)
HDMI™ConnectionInput(s): 3 (Rear)
HDMI™ConnectionOutput(s): 1 (Rear)
Repeater
Digital Media Port: Yes
Hardware
RemoteControl: Yes (Advanced
Learning/Pre Programed)
Power
PowerRequirements: AC120V, 60 Hz
Power Consumption (in Operation): 480W
Power Consumption (in Standby): 1W
Dimensions
Weight: 33 lbs 1 oz (15Kg)
Measurements: 16 15/16 x 6 3/4 x 16
15/16" (430 x 171.5 x 430mm)
Supplied Accessories
Instruction Manual
FM Wire Antenna
AM Loop Antenna
Size AA Batteries: 2
Remote Commander ® Remote Control
Color: Black
UPC Code: 027242710931
1.HDMIcompatibleHDTVrequired.Imagequalityandupscalingresults
mayvary.
2.Compatibilitymay vary and is not guaranteed for all players .
3.Requiressatellite radio subscription and radio antenna sold separately.
Antennaplacementrestrictions apply.
4.RequiresHDTVwithHDMIconnectorandequivalentdisplaycapability.
Imagequalitymayvary.
5.DVDMedia/Formatsare not universally compatible.
6.HDSourcerequiresHDMIand/orcomponentvideoconnectivity.
©2007SonyElectronicsInc.
Sony,BRAVIA,Theatresync,XrossMediaBar,x.v.Color,PrecisionCinema
Progressive,RemoteCommanderandDigitalCinemaSoundare
trademarksof Sony. Blu - rayDisc isatrademark. Dolby,DolbyDigital,
ProLogicare registered trademarks of Dolby Laboratories. dts is a
trademarkofDigital Theater Systems, L.P. HDMI, the HDMI logo and High -
DefinitionMultimedia Interfacearetrademarks orregisteredtrademarks
ofHDMI Licensing LLC.Allother trademarks areproperty of their
respectiveowners.
Featuresandspecificationsaresubjecttochangewithoutnotice.All
Weights and Measures are approximate.
