SERVICE MANUAL
Sony Corporation
Published by Sony Techno Create Corporation
SPECIFICATIONS
9-893-767-02
2013K33-1
© 2013.11
US Model
Canadian Model
AEP Model
UK Model
Australian Model
Ver. 1.1 2013.11
• All of the units included in the HT-CT260H
(SA-CT260H/SA-WCT260H) are required to
confirming operation of SA-CT260H. Check
in advance that you have all of the units.
HT-CT260H
SA-CT260H
HT-CT260H
HOME THEATRE SYSTEM
SA-CT260H
ACTIVE SPEAKER SYSTEM
COMPONENT MODEL NAME
HT-CT260H
Sound Bar (Active speaker system) SA-CT260H
Subwoofer (Active Subwoofer) SA-WCT260H
• Please refer to service manual separatery issued for subwoofer.
Formats supported by this system
HDMI
Input/Output (HDMI Repeater block)
Dolby Digital
DTS
Linear PCM 2ch 48 kHz or less
Amplifier section
U.S. models:
POWER OUTPUT AND TOTAL HARMONIC
DISTORTION :
(FTC)
Front L + Front R:
With 4 ohms loads, both channels
driven , from 200 - 20,000 Hz; rated
25 Watts per channel minimum RMS
power, with no more than 1% to tal
harmonic distortion from
250 milliwatts to rated output.
POWER OUTPUT (reference)
Front L/Front R: 85 W
(per channel at 4 ohms, 1 kHz)
Canadian AEP, UK and Australian models:
POWER OUTPUT (rated)
Front L + Front R: 50 W + 50 W
(at 4 ohms, 1 kHz, 1% THD)
POWER OUTPUT (reference)
Front L/Front R: 85 W (per channel at
4 ohms, 1 kHz)
Inputs
HDMI IN
ANALOG IN
OPTICAL IN
Output
HDMI TV OUT (ARC)
BLUETOOTH section
Communication system
BLUETOOTH Specification version
3.0
Output
BLUETOOTH Specification Power
Class 2
Maximum communication range
Line of sight approx. 10 m (33 feet)1)
Frequency band
2.4 GHz band (2.4000 GHz -
2.4835 GHz)
Modulation method
FHSS (Freq Hopping Spread
Spectrum)
Compatible BLUETOOTH profiles2)
A2DP (Advanced Audio Distribution
Profile)
AVRCP 1.4 (Audio Video Remote
Control Profile)
Supported Codecs3)
SBC 4)
Transmission range (A2DP)
20 Hz - 20,000 Hz (Sampling
frequency 44.1 kHz)
1) The actual range will vary depending
on factors such as obstacles between
devices, magnetic fields around a
microwave oven, static electricity,
cordless ph one, reception sensitivity,
operating system, software
application, etc.
2) BLUETOOTH standard profiles
indicate the purpose of BLUETOOTH
communication between devices.
3) Codec: Audio signal compression and
conversion format
4) Subband Codec
Fron t speaker un it
Speaker system
Full range speaker system,
Bass Reflex
Speaker unit
Woofer: 55 mm × 80 mm
(2 1/4 in × 3 1/4 in) cone type
Ra ted impedance
4 ohms
General
Power requirements
120 V AC, 60 Hz (US and Canadian models)
220 V - 240 V AC, 50/60 Hz
(AEP, UK and Australian models)
Power consumption
On: 32 W
“Control for HD MI” is off (Standby
mode):
0.5 W or less
BLUETOOTH Standby mode: 0.5 W
or less
Dimensions (approx.)
940 mm × 102 mm × 95 mm
(37 1/8 in × 4 1/8 in × 3 3/4 in)
(with stands)
940 mm × 90 mm × 100 mm
(37 1/8 in × 3 5/8 in × 4 in)
(without stands)
Mass (approx.)
2.2 kg (4 lb 13 5/8 oz)
Wireless transmitter/receiver
Frequency band
2.4 GHz band (2.404 GHz -
2.476 GHz)
Modulation method
GFSK
Design and specifications are subject to
change without notice.
sStandby power consumption: 0.5 W
or less (Sound Bar), 0.5 W or less
(Subwoofer)
File 2D
3D
Frame packing Side-by-Side
(Half)
Over-Under 
(Top-and -
Bottom)
1920 × 1080p @ 59.94/60 Hz
1920 × 1080p @ 50 Hz
1920 × 1080p @ 23.98/24 Hz
1920 × 1080i @ 59.94/60 Hz
1920 × 1080i @ 50 Hz
1280 × 720p @ 59.94/60 Hz
1280 × 720p @ 50 Hz
720 × 480p @ 59.94/60 Hz
720 × 576p @ 50 Hz
640 × 480p @ 59.94/60 Hz
This system incorporates Dolby* Digital
and t he DTS** Digital Surround System.
* Manufactured under license from
Dolby Laboratories.
Dolby, and the double-D symbol are
trademarks of Dol by Laboratories.
** Manufactured under license under
U.S. Pat ent Nos: 5,956,674; 5,974,380;
6,487,535 & other U.S. and worldwide
patents issued & pending. DTS, the
Symbol, & DTS and the Symbol
together are registered trademarks &
DTS Digital Surround and the DTS
logos are trademarks of DTS, Inc.
Product includes software. © DTS, Inc.
All Rights Reserved.
The BLUETOOTH®word mark and logos
are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such
marks by Sony Corporation is under
license.
This system incorporates High-Definition
Multimedia Interface (HDMI™)
technology.
T
he terms HDMI and HDMI High-
Definition Multimedia Interface, and the
HDMI Logo are trademarks or registered
trademarks of HDMI Licensing LLC in the
United States and other countries.
“x.v.Color”and “x.v.Color” logo are
trade marks of Sony Corporation.
Copyrights
“WALKMAN” and “WALKMAN” logo are
registered trademarks of Sony
Corporation.
“PlayStation®” is a registered trademark
of Sony Computer Entertainment Inc.
Other trademarks and trade names are
those of their respective owners.

HT-CT260H
2
SAFETY CHECK-OUT
After correcting the original service problem, perform the follow-
ing safety check before releasing the set to the customer:
Check the antenna terminals, metal trim, “metallized” knobs,
screws, and all other exposed metal parts for AC leakage.
Check leakage as described below.
LEAKAGE TEST
The AC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microamperes.).
Leakage current can be measured by any one of three methods.
1. Acommercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’ instructions to use these
instruments.
2. A battery-operated AC milliammeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a
VOM or battery-operatedAC voltmeter. The “limit” indication
is 0.75 V, so analog meters must have an accurate low-voltage
scale. The Simpson 250 and Sanwa SH-63Trd are examples
of a passive VOM that is suitable. Nearly all battery operated
digital multimeters that have a 2 VAC range are suitable. (See
Fig. A)
1.5 kΩ0.15 μFAC
voltmeter
(0.75 V)
To Exposed Metal
Parts on Set
Earth Ground
Fig. A. Using an AC voltmeter to check AC leakage.
SAFETY-RELATED COMPONENT WARNING!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE
WITH MARK 0ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS
WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS
MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0SUR
LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES
PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE FONC-
TIONNEMENT. NE REMPLACER CES COMPOSANTS QUE
PAR DES PIÈCES SONY DONT LES NUMÉROS SONT DON-
NÉS DANS CE MANUEL OU DANS LES SUPPLÉMENTS
PUBLIÉS PAR SONY.
1. SERVICING NOTES ............................................. 3
2. DISASSEMBLY
2-1. Disassembly Flow........................................................... 5
2-2. Seat Assy......................................................................... 6
2-3. Cover OPTAssy, Cover HDMI Assy ............................. 6
2-4. Back Case Block............................................................. 7
2-5. Power-supply Cord (AC1).............................................. 8
2-6. Loudspeakers (5.5 × 8 cm) (SP1, SP2)........................... 9
2-7. HDMI Board................................................................... 9
2-8. MAIN Board................................................................... 10
2-9. POWER Board................................................................ 11
2-10. Chassis Block.................................................................. 11
2-11. Speaker Connection Cables (SPC1, SPC2) .................... 12
2-12. BT Board, VFD Board.................................................... 13
3. DIAGRAMS
3-1. Block Diagram (1/2)....................................................... 15
3-2. Block Diagram (2/2)....................................................... 16
3-3. Printed Wiring Board - MAIN Board -........................... 18
3-4. Schematic Diagram - MAIN Board (1/7) -..................... 19
3-5. Schematic Diagram - MAIN Board (2/7) -..................... 20
3-6. Schematic Diagram - MAIN Board (3/7) -..................... 21
3-7. Schematic Diagram - MAIN Board (4/7) -..................... 22
3-8. Schematic Diagram - MAIN Board (5/7) -..................... 23
3-9. Schematic Diagram - MAIN Board (6/7) -..................... 24
3-10. Schematic Diagram - MAIN Board (7/7) -..................... 25
3-11. Schematic Diagram - HDMI Board (1/2) -..................... 26
3-12. Schematic Diagram - HDMI Board (2/2) -..................... 27
3-13. Printed Wiring Board - HDMI Board -........................... 28
3-14. Printed Wiring Board - BT Board -................................. 29
3-15. Schematic Diagram - BT Board - ................................... 29
3-16 Printed Wiring Board - VFD Board -.............................. 30
3-17. Schematic Diagram - VFD Board - ................................ 31
3-18. Printed Wiring Board - POWER Board -........................ 32
3-19. Schematic Diagram - POWER Board - .......................... 33
3-20. Printed Wiring Board - IR Board -.................................. 34
3-21. Schematic Diagram - IR Board - .................................... 34
4. EXPLODED VIEWS
4-1. Overall Section ............................................................... 36
4-2. Back Case Section .......................................................... 37
4-3. MAIN Board Section...................................................... 38
4-4. Front Panel Section......................................................... 39
5. ELECTRICAL PARTS LIST .............................. 40
Accessories are given in the last of the electrical parts list.
TABLE OF CONTENTS
Ver. 1.1

HT-CT260H
3
SECTION 1
SERVICING NOTES
ADVANCE PREPARATION WHEN CONFIRMING OP-
ERATION
All of the units included in the HT-CT260H (SA-CT260H/SA-
WCT260H) are required to confirming operation of SA-CT260H.
Check in advance that you have all of the units.
ABOUT PART REPAIR OF EACH BOARD
When mounted parts on each board installed by this unit are defec-
tive, replace the complete mounted board.
However the U701 on the MAIN board is exchangeable. Refer to
“ELECTRICAL PARTS LIST” (page 40) for U701.
CAPACITOR ELECTRICAL DISCHARGE PROCESSING
When checking the board, for the electric shock prevention, con-
nect the resistors to both ends of respective capacitor (CE502) to
discharge the capacitor (CE502).
– POWER Board (Conductor Side) –
CE502
800 :
2 W
SOFTWARE VERSION DISPLAY
You can set the following items with AMP MENU on the remote control.
Your settings are retained even if you disconnect the AC power cord (mains lead).
1Press AMP MENU to turn on the AMP menu.
2Press (return) / (select)/ (proceed) repeatedly to select the item
and press to decide the setting.
3Press AMP MENU to turn off the AMP menu.
SYSTEM VERSION The current firmware version information appears on the
front panel display.
Menu items Function
NOTE OF REPLACING THE WS T BOARD
When the WS T board is exchanged, you must perform linking
between SA-CT260H and SA-WCT260H.
Linking method:
This operation requires a remote commander.
You can link the Sound Bar (SA-CT260H)
and the subwoofer (SA-WCT260H) again
to enable wireless transmission between
them.
1Press LINK on the rear of the
subwoofer with the point of a
pen, etc .
The subwoofer keeps beeping for
a certain time. Perform steps 2 to 5
before the subwoofer stops
beeping.
2Press AMP MENU.
3Select “WS” with (select),
then press .
4Select “LINK,” then press .
5“START” appears, then press .
“SEARCH” appears, and the Sound
Bar searches for equipment that
can be used with Link. Proceed to
the next step within 1 minute.
To quit the Link function during a
search for equipment, press .
When subwoofer is linked with the
Sound Bar, the indicator on
the subwoofer lights up in green
and the subwoofer beeps once.
“OK” appears on the front panel
display.
If “FAILED” appears or the
subwoofer does not stop beeping,
perform the process again from
ste p 1.
6Press AM P MENU.
The AMP menu turns off.
AMP
MEN U
Ver. 1.1

HT-CT260H
4
MODEL IDENTIFICATION
Distinguish by model number label stuck on the rear side of a main unit.
– Rear view –
MODEL NUMBER LABEL
US and Canadian models AEP model
UK model Australina model
4-463-506-0s4-463-507-0s
4-463-508-0s4-463-509-0s

HT-CT260H
5
SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
SET
2-7. HDMI BOARD
(Page 9)
2-8. MAIN BOARD
(Page 10)
2-9. POWER BOARD
(Page 11)
2-10. CHASSIS BLOCK
(Page 11)
2-11. SPEAKER CONNECTION CABLES (SPC1, SPC2)
(Page 12)
2-12. BT BOARD, VFD BOARD
(Page 13)
2-2. SEAT ASSY
(Page 6)
2-3. COVER OPT ASSY, COVER HDMI ASSY
(Page 6)
2-4. BACK CASE BLOCK
(Page 7)
2-5. POWER-SUPPLY CORD (AC1)
(Page 8)
2-6. LOUDSPEAKERS (5.5 × 8 cm) (SP1, SP2)
(Page 9)

HT-CT260H
6
Note: Follow the disassembly procedure in the numerical order given.
2-2. SEAT ASSY
2seat assy
2seat assy
1screw
(PTT3 u6)
1screw
(PTT3 u6)
front side
rear side
– Bottom view –
Note: Please spread a sheet under
a unit not to injure grill side.
2-3. COVER OPT ASSY, COVER HDMI ASSY
2Remove the cover OPT assy
in the direction of a arrow.
5Remove the cover HDMI assy
in the direction of a arrow.
3cover OPT assy
6cover HDMI assy
1screw
(BTP3 u8)
4screw
(BTP3 u8)
– Rear bottom view – NGOK
NGOK
cover
OPT assy
No gap.
cover HDMI assy cover HDMI assy
cover
OPT assy
&RYHU237DVV\VHWWLQJ
&RYHU+'0,DVV\VHWWLQJ
There is a gap.
There is a gap.
Note 2: Please spread a sheet under
a unit not to injure grill side.
Note 1: cover OPT assy and cover HDMI assy
can be removed from either.
No gap.

HT-CT260H
7
2-4. BACK CASE BLOCK
1screw
(P3.5 u12)
1screw
(P3.5 u12)
1four screws
(P3.5 u12)
1four screws
(P3.5 u12)
1screw
(P3.5 u12)
– Rear bottom view –
Note 1: Please spread a sheet under
a unit not to injure grill side.
2Remove the back case block
in the direction of a arrow.
5back case block
4connector
(XP4)
3cushion
cushion
MAIN board
IR board
1three screws
(P3.5 u12)
1screw
(P3.5 u12)
1screw
(P3.5 u12)
1screw
(P3.5 u12)
Note 2: When you install the connector, please install them correctly.
There is a possibility that this machine damages when not
correctly installing it.
Insert is shallow
Insert is straight
to the interior.
connector
Insert is incline
connector connector connector
connector connector
NGOK NG
:ire VettiQJ

HT-CT260H
8
2-5. POWER-SUPPLY CORD (AC1)
5power-supply cord (AC1)
Note 2: When you install the connector, please install them correctly.
There is a possibility that this machine damages when not
correctly installing it.
Insert is shallow
Insert is straight
to the interior.
connector
Insert is incline
connector connector connector
connector connector
NGOK NG
– Rear bottom view –
3cord bush
1power-supply cord
connector
(CON50)
4Draw out the power-supply cord (AC1)
from the back case block.
Note 1: Please spread a sheet under
a unit not to injure grill side.
back case block
2Remove the cord bush
in the direction of a arrow.
back case block

HT-CT260H
9
2-6. LOUDSPEAKERS (5.5 × 8 cm) (SP1, SP2)
Note: Please spread a sheet under
a unit not to injure grill side.
– Rear bottom view –
3loudspeaker (5.5 u8 cm)
(SP1) (L-ch)
2four tapping screws
(BTP3 u8)
1 terminal (wide side)
[red]
1 terminal (wide side)
[red]
1 terminal (narrow side)
[black]
1 terminal (narrow side)
[black]
2four tapping screws
(BTP3 u8) 2tapping screw
(BTP3 u8)
3loudspeaker (5.5 u8 cm)
(SP2) (R-ch)
2-7. HDMI BOARD
1flexible flat cable (24P) (FFC1)
Note 2: When installing the flexible flat cable
(24P) (FFC1), insert in the correct
orientation after confirming the terminal
face. terminal
face
2three screws
(BTP3 u8)
5HDMI board
4two earth lugs
3Remove the HDMI board in
the direction of an arrow.
– Rear bottom view –
Note 1: Please spread a sheet under
a unit not to injure grill side.
Note 3: When installing the flexible flat cable, ensure the colored line.
No slanting after insertion.
colored line colored line
Insert is straight to the interior. Insert is incline
flexible flat
cable flexible flat
cable
connectorconnector
OK NG

HT-CT260H
10
2-8. MAIN BOARD
– Rear top view –
Note 1: Please spread a sheet under
a unit not to injure grill side.
7screw
(BTP3 u8)
7screw
(BTP3 u8)
9MAIN board
Note 5: When installing the flexible flat cable, ensure the colored line.
No slanting after insertion.
Note 3: Arrange the wire so as not to
protrude to the outside of the
front panel.
Note 4: Check that the connector has fitted in firmly.
colored line colored line
Insert is straight to the interior. Insert is incline
flexible flat
cable flexible flat
cable
connectorconnector
MAIN board
OK NG
5connector
(XP8)
4connector
(XP3)
6connector
(XP9) 8connector
(XP10)
7screw
(BTP3 u8)
7screw
(BTP3 u8)
3flexible flat cable
(18P) (XP5)
1flexible flat cable (24P) (FFC1) (CN2)
Note 2: When installing the flexible flat cable
(24P) (FFC1) (CN2), insert in the correct
orientation after confirming the terminal
face.
terminal
face
Note 6: When you install the connector, please install them correctly.
There is a possibility that this machine damages when not
correctly installing it.
Insert is shallow
Insert is straight
to the interior.
connector
Insert is incline
connector connector connector
connector connector
NGOK NG
Wire setting
Note 3: Arrange the wire so as not to protrude to the outside of the
front panel.
Wire setting
NG
OK
&onneFtor setting
2cushion
MAIN board
Connectors are not
firmly in place.
MAIN board
flexible flat cable (24 core)
flexible flat cable (24 core)
cushion
Connectors are
firmly in place.

HT-CT260H
11
2-9. POWER BOARD
2POWER board
1two screws
(BTP3 u8)
1two screws
(BTP3 u8)
Note: Please spread a sheet under
a unit not to injure grill side.
– Rear bottom view –
2-10. CHASSIS BLOCK
1screw
(BTP3 u8)
2chassis block
Note: Please spread a sheet under
a unit not to injure grill side.
– Rear bottom view –

HT-CT260H
12
2-11. SPEAKER CONNECTION CABLES (SPC1, SPC2)
– Rear bottom view –
– Front panel block inner view –
2 speaker connection cable
(SPC2) (R-ch)
2 speaker connection cable
(SPC1) (L-ch)
speaker connection cable
(SPC2) (R-ch)
speaker connection cable
(SPC2) (R-ch)
speaker connection cable
(SPC1) (L-ch)
speaker connection cable
(SPC1) (L-ch)
Speaker connection cables setting
loudspeaker (5.5 u8 cm)
(SP2) (R-ch) loudspeaker (5.5 u8 cm)
(SP2) (R-ch)
1 terminal (wide side)
[red]
[red] (wide side)
[red] (wide side)
1 terminal (wide side)
[red]
1 terminal (narrow side)
[black]
1 terminal (narrow side)
[black]
[black] (narrow side)
[black] (narrow side)
Note 1: Please spread a sheet under
a unit not to injure grill side.
speaker connection cable
(SPC2) (R-ch) speaker connection cable
(SPC1) (L-ch)
Blank.No blank.
Note 2: When installing speaker connection
cables, check the form of a connector,
in order not to mistake right and left.

HT-CT260H
13
2-12. BT BOARD, VFD BOARD
2VFD board block
1three screws
(BTP3 u8)
1screw
(BTP3 u8)
5flexible flat cable (18P)
(FFC2) (XP5)
– Rear bottom view –
Note 1: Please spread a sheet under
a unit not to injure grill side.
Note 3: When installing the flexible flat cable, ensure the colored line.
No slanting after insertion.
colored line colored line
Insert is straight to the interior. Insert is incline
flexible flat
cable flexible flat
cable
connectorconnector
OK NG
NGOK
4BT board
6VFD board
3connector
(XP9)
Note 2: Check that the connector has fitted in firmly.
&oQQeFtor VettiQJ
Connectors are not
firmly in place.
Connectors are
firmly in place.

HT-CT260H
14
MEMO

HT-CT260H
HT-CT260H
1515
SECTION 3
DIAGRAMS
3-1. BLOCK DIAGRAM (1/2)
DSP
CS497024
IR
MCU
M0516
FRONT PANEL
(VFD DISPLAY+Key )
(PT6312+FV935ND)
HDMI
Repeater
EP92A2E
PWM
ADC
5358
AUX IN
Audio
Processor
STA309
I2S
FLASH
32M
Xtal
24.576M
CEC
SPI
Xtal
18.432M
OPTICAL IN SDRAM
64M
8¡
L 85W
THD 30%
L F
R 85W
THD30%
BTL
BTL
Wireless
IA2S
SUB I2S
BT
BM153
I2S
8¡
HDMI
OUT
DC-DC
SPI
UART
POWER KEY
I/O
I2C
IIS SWITCH
74LVC224
CS8416
SPDIF
I2S
I2S
I2C
I2C
DSP UPGARD
74LVC244
HD I2S
Power Stage
STA518
+31.5V
Standby power 0.5w
+30V
ARC
POWER SUPPLY
Xtal

HT-CT260H
HT-CT260H
1616
3-2. BLOCK DIAGRAM (2/2)
POWER
12v VFD
MAX 166mA
-24v VFD
LDO
5V TO 3.3V 3.3_STB MCU
OTHERS
WLAN
AK5358
26.6V
AMP
5v HDMI
250mA
AZ1117 DSP
1.8V
OPTICAL
3.3V
CS8416
STA516
CS497024
FLASH
STA309
MAX 50mA
IR
MAX 1.7mA
MAX 102mA
MAX 100mA
MAX 9mA
SDRAM
MAX 45mA
MAX 140mA
MAX 7mA
MAX 80mA
MAX 18mA
MAX 350mA
MAX 50mA
MAX 10mA
200mA
60mA
417mA
MAX 10mA
MAX 1400mA
D3.3V
5v
12v
EUP3482A
1400mA
26.6V
5v
-24v
10mA
STB 40mA BT
OTHERS
MAX 10mA
EP92A2
MAX 200mA
OTHERS
MAX 50mA
SWITCH
MAX 3000mA
VCC5v
SWITCH
MAX 20mA
224mA
3.3V
DV33
MAX 400mA
MAX 250mA

HT-CT260H
HT-CT260H
1717
Ver. 1.1
For Schematic Diagrams.
Note:
• All capacitors are in μF unless otherwise noted. (p: pF) 50
WV or less are not indicated except for electrolytics and
tantalums.
• All resistors are in Ωand 1/4 W or less unless otherwise
specified.
THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is printed in each block.)
For Printed Wiring Boards.
Note:
• : Pattern from the side which enables seeing.
(The other layers’ patterns are not indicated.)
Caution:
Pattern face side:
(Conductor Side)
Parts face side:
(Component Side)
Parts on the pattern face side seen
from the pattern face are indicated.
Parts on the parts face side seen from
the parts face are indicated.
• Circuit Boards Location
POWER board
MAIN boardIR board
HDMI board
WS T board
VFD board
BT board
Note:
The components identi-
fied by mark 0or dotted
line with mark 0are criti-
cal for safety.
Replace only with part
number specified.
Note:
Les composants identifiés
par une marque 0sont
critiques pour la sécurité.
Ne les remplacer que par
une pièce portant le nu-
méro spécifié.

HT-CT260H
HT-CT260H
1818
3-3. PRINTED WIRING BOARD - MAIN Board -
MAIN BOARD (COMPONENT SIDE)
MAIN BOARD (COMPONENT SIDE)
A
B
C
D
E
F
G
1 2 3 4 5 6 7 8 9 10
Ver. 1.1
• : Uses unleaded solder.
• See page 17 for Circuit Boards Location.

HT-CT260H
HT-CT260H
1919
3-4. SCHEMATIC DIAGRAM - MAIN Board (1/7) -
0.6*(30+15)/15=1.80V
POWER IN
PCON L: POWER OFF
H: POWER ON
450MA
VCC DV33
A+5V
VCC
+25.5V
+25V
VCC12V
STB+5V
STB+5V
STB+5V +3.3V_STB
M-24V
VCC
+12V
VCC12V
+12V
+25V
VCC
HD+2.1V
STB+5V
M-24V
-24V
1
2
3
4
5
6
7
8
9
10
1
2
3 5
6
4
8 7
1
3
2
32
1
4
1
43
5
2
1
2
34
5
12
3
1
2
3
4
5
6
7
8
9
10
BS
IN
SW
FB
COMP
GND
SS EN
G
DS
VI VO
GND
VO
EN
VIN LX
VFB
GND
VIN
GND
EN NC
VOUT
C537
NC C537 NC
R58
10K
R58
10K
22uF/16V
C983
22uF/16V
C983
C151
0.1uF/25V/Y5V
C151
0.1uF/25V/Y5V
C5440.1uF/50V/X7R C5440.1uF/50V/X7R
R829
100K
R829
100K
C83
0.1uF/50V/Y5V
C83
0.1uF/50V/Y5V
FB502
FB80@100MHz
FB502
FB80@100MHz
XP10
10PIN/2.0mm
XP10
10PIN/2.0mm
R1548
1K
R1548
1K R77
680
R77
680
FB26
300/2A
FB26
300/2A
FB24 500/800mAFB24 500/800mA
U2EUP3482 U2EUP3482
C10090.1uF/50V/Y5V C10090.1uF/50V/Y5V
C5530.1uF/50V/X7R C5530.1uF/50V/X7R
100pF/50V/NP0100pF/50V/NP0
Q6
P_AP2305
Q6
P_AP2305
100uF/16V
CE51
100uF/16V
CE51
R837
10K
R837
10K
R549
NC
R549
NC
C5660.1uF/50V/Y5V C5660.1uF/50V/Y5V
C60.1uF/50V/Y5V C60.1uF/50V/Y5V
Q224
PNP_3CG3906M
Q224
PNP_3CG3906M
C5490.1uF/50V/X7R C5490.1uF/50V/X7R
C188
NC/100pF/50V/NP0
C188
NC/100pF/50V/NP0
R552 2.2R552 2.2
Q7
NPN_3DG3904M
Q7
NPN_3DG3904M
C390
2.2uF/10V/Y5V
C390
2.2uF/10V/Y5V
C545
3300pF/50V/X7R
C545
3300pF/50V/X7R
D16
BAT54S
D16
BAT54S
FB29 500/800mAFB29 500/800mA
R19
56K/1% R19 56K/1%
Q754
NPN_3DG3904M
Q754
NPN_3DG3904M
C191 0.1uF/50V/X7RC191 0.1uF/50V/X7R
C58
0.1uF/25V/Y5V
C58
0.1uF/25V/Y5V
R220
51K
R220
51K
R18
11K
R18
11K
U12
CW1117-3.3V
U12
CW1117-3.3V
C565
NC
C565
NC
R825
10K
R825
10K
C189
0.1uF/25V/Y5V
C189
0.1uF/25V/Y5V
C550
0.1uF/50V/Y5V
C550
0.1uF/50V/Y5V
C981
10uF/10V/Y5V
C981
10uF/10V/Y5V
C65
0.1uF/25V/Y5V
C65
0.1uF/25V/Y5V
R12
7.5K
R12
7.5K
R827
10K
R827
10K
ZD751
ZMM27/27V
ZD751
ZMM27/27V
FB23 500/800mAFB23 500/800mA
ZD752
BZV55C5V1
ZD752
BZV55C5V1
R23
22K
R23
22K
C985
22uF/10V/Y5V
C985
22uF/10V/Y5V
R836
10K
R836
10K
U17G5725 U17G5725
D543
MBRX140/40V/1A
D543
MBRX140/40V/1A
U712
LDO_G9091-330T11U
U712
LDO_G9091-330T11U
R762
4.7K
R762
4.7K
C59
0.1uF/25V/Y5V
C59
0.1uF/25V/Y5V
C66
0.1uF/25V/Y5V
C66
0.1uF/25V/Y5V
470uF/16V
CE542
470uF/16V
CE542
C10100.1uF/50V/Y5V C10100.1uF/50V/Y5V C850.1uF/25V/X7R C850.1uF/25V/X7R
FB30
500/800mA
FB30
500/800mA
C1500.1uF/25V/Y5VC1500.1uF/25V/Y5V
L18
2.2uH
L18
2.2uH
Q3
NPN_3DG3904M
Q3
NPN_3DG3904M
C4
0.1uF/25V/Y5V
C4
0.1uF/25V/Y5V
C86
0.1uF/50V/Y5V
C86
0.1uF/50V/Y5V
R1549 0R1549 0
22uF/50V
CE13
22uF/50V
CE13
D542
NC
D542
NC
47uF/16V
CE540
47uF/16V
CE540
C540
0.01uF/50V/Y5V
C540
0.01uF/50V/Y5V
ZD535
BZV85C12V
ZD535
BZV85C12V
R720
1K
R720
1K
L532INDUCTOR_3P L532INDUCTOR_3P
C986
22uF/10V/Y5V
C986
22uF/10V/Y5V
C12
1000pF/50V/X7R
C12
1000pF/50V/X7R
R230
15K/1%
R230
15K/1%
R105 47R105 47
R57
10K
R57
10K
C1490.1uF/25V/Y5VC1490.1uF/25V/Y5V
R560
2K
R560
2K
CE612
220uF/35V
CE612
220uF/35V
C103
0.1uF/25V/Y5V
C103
0.1uF/25V/Y5V
C551
NC
C551
NC
R104 47R104 47
++
++
++
++
++
++
DV33VCC
+12V
POWER_ON/OFF
POWER_ON/OFF
C391C391
(1/7)MAIN BOARD
A
1386
E
2 9
D
5
B
C
7
F
4
Ver. 1.1

HT-CT260H
HT-CT260H
2020
3-5. SCHEMATIC DIAGRAM - MAIN Board (2/7) -
FROM HDMI BOARD
A+5V
HD_STB3.3V
DV33
DV33
HD+2.1V
+3.3V_STBHD_STB3.3V
DV33
STB+5V
DV33
STB+5V
2
3
5
413
14
6
7
89
11
12
10
115 16
21
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25 26
21
1
3
2
AINL
CKS1
AGND
VCOM PDN
DIF
VA
VD
DGND SDTO
MCLK
SCLK
LRCK
AINR CKS2 CKS0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
GND GND
C250.1uF/25V/Y5V C250.1uF/25V/Y5V
R1534 4.7K R1534 4.7K
R154.7K R154.7K R174.7K R174.7K
U5ADC_AK5358A U5ADC_AK5358A
ESD1
PESD5V0S1BA_5.0V
ESD1
PESD5V0S1BA_5.0V
C364
10pF/50V/NP0
C364
10pF/50V/NP0
R464 100 R464 100
R1556
3.3K
R1556
3.3K
CN2
24PIN/0.5mm
CN2
24PIN/0.5mm
C172 10uF/10V/Y5VC172 10uF/10V/Y5V
ESD2
PESD5V0S1BA_5.0V
ESD2
PESD5V0S1BA_5.0V
CE7
10uF/10V/Y5V
CE7
10uF/10V/Y5V
R1535
4.7K
R1535
4.7K
C160.1uF/25V/Y5V C160.1uF/25V/Y5V
R21
4.7K R21 4.7K
R20NC/4.7K R20NC/4.7K
C95
2200pF//50V/X7R
C95
2200pF//50V/X7R
R465 0 R465 0
R1536
4.7K
R1536
4.7K
FB5500/200mA FB5500/200mA
C96
2200pF//50V/X7R
C96
2200pF//50V/X7R
R14 4.7R14 4.7
R1537
4.7K
R1537
4.7K
C260.1uF/25V/Y5V C260.1uF/25V/Y5V
C7 10pF/50V/NP0C7 10pF/50V/NP0
D21
BAT54C
D21
BAT54C
FB27 500/800mA FB27 500/800mA
C365
10pF/50V/NP0
C365
10pF/50V/NP0
C240.1uF/25V/Y5V C240.1uF/25V/Y5V
C173 10uF/10V/Y5VC173 10uF/10V/Y5V
C366
10pF/50V/NP0
C366
10pF/50V/NP0
R164.7K R164.7K
R842 0R842 0
100uF/16V CE6100uF/16V CE6
FB28 500/800mA FB28 500/800mA
R850 33 R850 33
++
AD_DATA
OPT_IN
AUX_L
AUX_R
M_CEC
HD_RST
H_MAIN_SCL
H_MAIN_SDA
AUX_R
AUX_L
AD_DATA
AD_BCLK AD_MCLK
AD_LRCLK
H_MAIN_SCL
H_MAIN_SDA
HD_MCLK
OPT_IN
HD_RST
M_CEC
HD_SCK
HD_LRCK
HD_SDA3
HD_SDA2
HD_SDA1
HD_SDA0
ARC
(2/7)MAIN BOARD
A
3625
B
14
Ver. 1.1
