Sony SRS-X11 User guide

English
Manuals Supplied
Startup Guide (this document)
Provides you with instructions on how to connect the
unit with BLUETOOTH devices and basic operations.
Reference Guide
Provides you with precautions and product
specifications.
Help Guide
Read the Help Guide on your computer or smartphone
when you want to know how to use the unit in greater
detail. The Help Guide also contains a troubleshooting
guide which provides you with remedies for the
problems you might encounter.
URL:
http://rd1.sony.net/help/speaker/srs-x11/h_zz/
Two-dimensional code:
Charging the Unit
This unit has a built-in lithium-ion rechargeable battery. Charge
the battery before using the unit for the first time.
When the unit is turned off and connected to a booted PC or an AC
outlet, the CHARGE indicator lights up in orange. The CHARGE
indicator will turn off when charging is completed.
The charging time depends on the power output capacity of the
connected device.
Power output capacity Estimated charging time*
Ability to output in 1.5 A About four hours
Ability to output in 500 mA About eight hours
* The time stated above may vary depending on the ambient
temperature or conditions of use.
Hint
A unit that is in use can be charged if it is connected to a booted PC or
an AC outlet, though the CHARGE indicator does not light up. In this
case, it may take longer to charge its battery than the ones stated
above depending on the conditions of use. Therefore, it is
recommended to turn off the unit when charging.
To charge the battery from a PC
Micro-USB
cable (supplied)
DC IN
Lit
(orange)
Hint
The power output capacity varies depending on the PC. For details on
your PC’s power output, refer to the operating instructions supplied
with your PC.
To charge the battery from an AC outlet
USB AC adaptor
(commercially-available)
Micro-USB
cable (supplied)
DC IN
Lit
(orange)
Hint
A commercially-available USB AC adaptor with a power output of 1.5 A or
more is recommended for use, though a USB AC adaptor with a power
output of more than 500 mA, but less than 1.5 A is also compatible with the
unit. Charging using other types of adaptors is not covered by the warranty.
How to Make a Wireless Connection with
BLUETOOTH Devices
Select your case from the three pairing types below. BLUETOOTH
devices need to be “paired” with each other beforehand.
Pairing and connecting with a
BLUETOOTH device
The unit can be paired with up to eight BLUETOOTH devices. When
pairing with two or more BLUETOOTH devices, perform the
following pairing procedure for each device.
1 Press the (power) PAIRING button to turn on
this unit.
The (BLUETOOTH) indicator begins to flash.
Flashing
(white)
2 Press and hold the (power) PAIRING button
until beeps are heard and the (BLUETOOTH)
indicator begins to flash quickly.
The unit enters pairing mode.
Hint
When you turn on the unit for the first time, it enters pairing mode
automatically.
Fast flashing
(white)
3 Perform the pairing procedure on the BLUETOOTH
device to detect this unit.
When a list of detected devices appears on the display of the
BLUETOOTH device, select “SRS-X11.”
If passkey input is required on the display of a BLUETOOTH
device, input “0000.”
4 Make the BLUETOOTH connection from the
BLUETOOTH device.
When the BLUETOOTH connection is established, the
(BLUETOOTH) indicator on the unit stays lit.
Connecting with a paired
BLUETOOTH device
1 Turn on this unit.
The (BLUETOOTH) indicator begins to flash.
2 Make the BLUETOOTH connection from the
BLUETOOTH device.
When the BLUETOOTH connection is established, the
(BLUETOOTH) indicator on the unit stays lit.
Connecting with a smartphone by
One-touch (NFC)
By touching the unit with a smartphone, the unit is turned on
automatically and then proceeds to pairing and BLUETOOTH
connection.
Compatible smartphones
NFC-compatible smartphones with Android 2.3.3 or later installed
NFC
NFC(Near Field Communication) is a technology enabling
short-range wireless communication between various devices,
such as smartphones and IC tags. Thanks to the NFC function, data
communication - for example, BLUETOOTH pairing - can be
achieved easily by simply touching NFC-compatible devices
together (i.e., at the N-Mark symbol or location designated on
each device).
1 Set the NFC function of the smartphone to on.
For details, refer to the operating instructions supplied with
the smartphone.
•If your smartphone OS is Android 2.3.3 or later and less than
Android 4.1, proceed to step 2.
•If your smartphone OS is Android 4.1 or later, proceed to step 4.
2 Download and install the app “NFC Easy Connect.”
“NFC Easy Connect” is a free Android app you can download
from Google Play.
Download the app by searching for “NFC Easy Connect” or
access it by using the following two-dimensional code. Fees
may be charged for downloading the app.
To download by the two-dimensional
code, use a two-dimensional code
reader app.
Note
The app may not be available in some countries and/or regions.
3 Start “NFC Easy Connect” on the smartphone.
Make sure that the app screen is displayed.
4 Touch this unit with the smartphone.
Unlock the screen of the smartphone beforehand.
Keep touching the smartphone on the N marked part of the
unit until the smartphone responds. If the unit is off, it will
turn on when the smartphone touches it.
Smartphone responds
(unit recognized)
Follow the on-screen instructions to establish the connection.
When the BLUETOOTH connection is established, the
(BLUETOOTH) indicator on the unit stays lit.
To disconnect, touch the unit with the smartphone again.
Hints
If you cannot connect the unit, try the following.
•Start the app on the smartphone and move the smartphone
slowly over the N marked part of the unit.
•If the smartphone is in a case, remove it from the case.
•Make sure that the app screen is displayed on the smartphone.
Listening and Calling
Operate the unit after making the BLUETOOTH connection with your
BLUETOOTH device.
Listening to music
Profile: A2DP, AVRCP
Start playback on the BLUETOOTH device and adjust the
volume.
Set the volume at an appropriate level on the connected device
and adjust the volume with the VOL –/+ buttons on the unit.
The VOL + button has a tactile dot.
Hint
For details concerning playback through connection via the AUDIO IN
jack, refer to the Help Guide.
Making a call/Receiving a call
Profile: HSP, HFP
Operate your smartphone to make a call.
To terminate a call, press the (call) button on the unit.
Press the (call) button on the unit when an incoming
call arrives.
Operate in the same way when an incoming call arrives while you
are listening to music.
The (call) button has a tactile dot.
Microphone
Hint
When a portable audio device, etc. is connected to the AUDIO IN jack,
the unit automatically switches to the AUDIO IN mode. In this case,
sound from the BLUETOOTH-connected device is not output from the
unit, but handsfree calling is available.
By connecting two SRS-X11 units via BLUETOOTH, you can select
audio reproduction between the stereo mode (stereo sound)
and double mode (same sound is output from two units
simultaneously). To use this function (speaker add function),
two SRS-X11 units are required.
For more information, see Help Guide on the following website:
http://rd1.sony.net/help/speaker/srs-x11/h_zz/
•The BLUETOOTH® word mark and logos are owned by the Bluetooth
SIG, Inc. and any use of such marks by Sony Corporation is under
license.
•The N Mark is a trademark or registered trademark of NFC Forum, Inc.
in the United States and in other countries.
•Android™ and Google Play™ are trademarks of Google Inc.
•Other trademarks and trade names are those of their respective
owners.
Français
Manuels fournis
Guide de démarrage (le présent document)
Ce guide fournit des instructions sur la procédure de
connexion de l’appareil aux périphériques BLUETOOTH
et décrit les fonctions de base.
Guide de référence
Ce guide fournit les spécifications du produit et vous
informe des précautions à prendre pour l’utiliser.
Guide d’aide
Consultez le Guide d’aide sur votre ordinateur ou votre
smartphone lorsque vous voulez utiliser les fonctions
plus avancées de l’appareil. Le Guide d’aide contient
également un guide de dépannage qui propose des
solutions aux problèmes que vous pouvez rencontrer.
URL:
http://rd1.sony.net/help/speaker/srs-x11/h_zz/
Code en deux dimensions:
Chargement de l’appareil
L’appareil est équipé d’une batterie rechargeable lithium-ion
intégrée. Rechargez la batterie avant d’utiliser l’appareil pour la
première fois.
Quand l’appareil est hors tension et connecté à un PC actif ou à
une prise secteur, le témoin CHARGE s’allume en orange. Le
témoin CHARGE s’éteint quand le chargement est terminé.
La durée de chargement dépend de l’intensité de sortie
d’alimentation du périphérique connecté.
Intensité de sortie
d’alimentation
Durée de chargement
estimée*
Intensité de sortie de 1,5 A Environ quatre heures
Intensité de sortie de 500 mA Environ huit heures
* La durée mentionnée ci-dessus peut varier en fonction de la
température ambiantes ou des conditions d’utilisation.
Conseil
Un appareil en cours d’utilisation peut être rechargé s’il est connecté à
un PC actif ou à une prise secteur, même si le témoin CHARGE ne
s’allume pas. Selon les conditions d’utilisation, la durée de chargement
de la batterie peut alors être supérieure à celles mentionnées ci-dessus.
Il est dès lors recommandé de mettre l’appareil hors tension lorsque
vous le rechargez.
Pour charger la batterie à partir d’un PC
Câble micro-USB (fourni)
ENTRÉE CC
Allumé
(orange)
Conseil
L’intensité de sortie d’alimentation varie selon le PC. Pour plus
d’informations sur la sortie d’alimentation de votre PC, reportez-vous au
mode d’emploi fourni avec celui-ci.
Pour charger la batterie à partir d’une prise secteur
Adaptateur secteur USB
(disponible dans le commerce)
Câble micro-USB (fourni)
ENTRÉE CC
Allumé
(orange)
Conseil
Il est recommandé d’utiliser un adaptateur secteur USB du commerce
dont l’intensité de sortie d’alimentation est de 1,5 A ou davantage, bien
qu’un adaptateur secteur USB d’une intensité de sortie d’alimentation
supérieure à 500 mA, mais inférieure à 1,5 A, soit également compatible
avec l’appareil. La garantie ne couvre pas le chargement au moyen
d’autres types d’adaptateurs.
Comment établir une connexion sans fil
avec des périphériques BLUETOOTH
Parmi les trois types de jumelage ci-dessous, sélectionnez celui qui
correspond à votre cas. Les périphériques BLUETOOTH doivent être
préalablement «jumelés» l’un à l’autre.
Jumelage et connexion à un
périphérique BLUETOOTH
L’appareil peut être jumelé à huitpériphériques BLUETOOTH
maximum. En cas de jumelage à deux périphériques BLUETOOTH
ou davantage, appliquez la procédure de jumelage suivante pour
chaque périphérique.
1 Appuyez sur la touche (alimentation) PAIRING
pour mettre cet appareil sous tension.
Le témoin (BLUETOOTH) se met à clignoter.
Clignote
(blanc)
2 Maintenez la touche (alimentation) PAIRING
enfoncée jusqu’à l’émission de signaux sonores et
jusqu’à ce que le témoin (BLUETOOTH) se mette à
clignoter rapidement.
L’appareil passe en mode de jumelage.
Conseil
La première fois que vous mettez l’appareil sous tension, il passe
automatiquement en mode de jumelage.
Clignote rapidement
(blanc)
3
Effectuez la procédure de jumelage sur le
périphérique BLUETOOTH pour détecter cet appareil.
Lorsque la liste de périphériques détectés apparaît sur l’écran
du périphérique BLUETOOTH, sélectionnez «SRS-X11».
Si la saisie d’une clé d’authentification est requise sur l’écran
d’un périphérique BLUETOOTH, saisissez «0000».
4 Établissez la connexion BLUETOOTH à partir du
périphérique BLUETOOTH.
Lorsque l’appareil est connecté au périphérique BLUETOOTH,
le témoin (BLUETOOTH) de l’appareil reste allumé.
Connexion à un périphérique
BLUETOOTH jumelé
1 Mettez cet appareil sous tension.
Le témoin (BLUETOOTH) se met à clignoter.
2 Établissez la connexion BLUETOOTH à partir du
périphérique BLUETOOTH.
Lorsque l’appareil est connecté au périphérique BLUETOOTH,
le témoin (BLUETOOTH) de l’appareil reste allumé.
Connexion à un smartphone par
simple contact (NFC)
Si vous mettez l’appareil en contact avec un smartphone, il se met
automatiquement sous tension, puis effectue le jumelage et
établit la connexion BLUETOOTH.
Smartphones compatibles
Smartphones compatibles NFC avec Android2.3.3 ou ultérieur installé
NFC
La NFC (Near Field Communication, communication en champ
proche) est une technologie permettant d’établir une
communication sans fil à courte portée entre différents
périphériques, comme les smartphones et les étiquettes CI. Grâce
à la fonction NFC, la communication des données (par exemple, le
jumelage BLUETOOTH) peut être facilement réalisée en mettant
simplement en contact des périphériques compatibles NFC
(autrement dit, au niveau du symbole N-Mark ou de
l’emplacement désigné sur chaque appareil).
1 Activez la fonction NFC du smartphone.
Pour plus de détails, reportez-vous au mode d’emploi fourni
avec le smartphone.
•Si le système d’exploitation de votre smartphone est
Android2.3.3 ou une version ultérieure, mais antérieure à
Android4.1, passez à l’étape2.
•Si le système d’exploitation de votre smartphone est Android4.1
ou une version ultérieure, passez à l’étape 4.
2 Téléchargez et installez l’application «Connexion
NFC facile».
«Connexion NFC facile» est une application Android gratuite
que vous pouvez télécharger sur Google Play.
Téléchargez l’application en recherchant «Connexion NFC
facile» ou accédez-y à l’aide du code en deux dimensions
suivant. Le téléchargement de l’application peut être payant.
Pour télécharger à l’aide du code en
deux dimensions, utilisez une
application de lecture de code en
deuxdimensions.
Remarque
Il est possible que l’application ne soit pas disponible dans
certains pays et/ou dans certaines régions.
3 Démarrez l’application «Connexion NFC facile» sur
le smartphone.
Vérifiez que l’écran de l’application est affiché.
4 Mettez cet appareil en contact avec le smartphone.
Déverrouillez préalablement l’écran du smartphone.
Maintenez le contact avec le smartphone sur la zone de
l’appareil marquée N jusqu’à ce que le smartphone réagisse.
Si l’appareil est hors tension, il se met sous tension lorsque le
smartphone entre en contact avec lui.
Le smartphone réagit
(appareil reconnu)
Pour établir la connexion, conformez-vous aux instructions
affichées.
Lorsque l’appareil est connecté au périphérique BLUETOOTH,
le témoin (BLUETOOTH) de l’appareil reste allumé.
Pour le déconnecter, mettez-le à nouveau en contact avec le
smartphone.
Conseils
Si vous ne parvenez pas à connecter l’appareil, essayez ce qui suit.
•Démarrez l’application sur le smartphone et déplacez lentement
le smartphone par-dessus la zone de l’appareil marquée N.
•Si le smartphone se trouve dans un étui, sortez-le de celui-ci.
•Vérifiez que l’écran de l’application est affiché sur le smartphone.
Écoute et appel
Utilisez l’appareil après avoir établi la connexion BLUETOOTH avec
votre périphérique BLUETOOTH.
Écoute de musique
Profil: A2DP, AVRCP
Démarrez la lecture sur le périphérique BLUETOOTH et
réglez le volume.
Réglez le volume à un niveau correct sur le périphérique connecté
et réglez le volume à l’aide des touches VOL –/+ de l’appareil.
La touche VOL + possède un point tactile.
Conseil
Pour plus d’informations sur la lecture par l’intermédiaire de la prise
AUDIO IN, reportez-vous au Guide d’aide.
Émission/réception d’un appel
Profil : HSP, HFP
Utilisez votre smartphone pour émettre un appel.
Pour raccrocher, appuyez sur la touche (appel) de l’appareil.
Appuyez sur la touche (appel) de l’appareil quand
vous recevez un appel.
Procédez de la même manière quand vous recevez un appel alors
que vous écoutez de la musique.
La touche (appel) possède un point tactile.
Micro
Conseil
Quand un périphérique audio portable, par exemple, est raccordé à la
prise AUDIO IN, l’appareil bascule automatiquement en mode AUDIO IN.
L’appareil cesse alors de reproduire le son provenant du périphérique
BLUETOOTH connecté, mais l’appel mains libres est possible.
En connectant deux appareils SRS-X11 par l’intermédiaire du
BLUETOOTH, vous pouvez sélectionner la reproduction du son
en mode stéréo (son stéréo) et en mode double (reproduction
simultanée du même son par les deux appareils). Pour utiliser
cette fonction (fonction d’ajout d’enceinte), vous devez disposer
de deux appareils SRS-X11.
Pour plus d’informations, consultez le Guide d’aide sur le site
Web suivant:
http://rd1.sony.net/help/speaker/srs-x11/h_zz/
•La marque BLUETOOTH® et les logos appartiennent à Bluetooth SIG, Inc.
et doivent être utilisés par Sony Corporation uniquement sous licence.
•Le repère N-Mark est une marque commerciale ou une marque
déposée de NFC Forum, Inc., aux États-Unis et dans d’autres pays.
•Android™ et Google Play™ sont des marques commerciales de
Google Inc.
•Les autres marques commerciales et noms commerciaux
appartiennent à leurs propriétaires respectifs.
Personal Audio
System
Startup Guide
Guide de démarrage
Einführungsanleitung
Guía de inicio
4-565-374-21(1)
©2015 Sony Corporation Printed in China
SRS-X11
Deutsch
Mitgelieferte Anleitungen
Einführungsanleitung (dieses Dokument)
Enthält Anweisungen, wie das Gerät mit BLUETOOTH-
Geräten zu verbinden ist, und erläutert die
Grundfunktionen.
Referenzhandbuch
Enthält Sicherheitshinweise und die technischen
Daten des Produkts.
Hilfe
Lesen Sie die Hilfe auf Ihrem Computer oder
Smartphone, wenn Sie mehr zur Verwendung des
Geräts erfahren möchten. Die Hilfe enthält auch eine
Fehlersuchanleitung, in der die Behebung eventuell
auftretender Probleme beschrieben wird.
URL:
http://rd1.sony.net/help/speaker/srs-x11/h_zz/
Zweidimensionaler Code:
Laden des Geräts
Dieses Gerät ist mit einem eingebauten Lithium-Ionen-Akku
ausgestattet. Laden Sie den Akku auf, bevor Sie das Gerät zum
ersten Mal verwenden.
Wenn das Gerät ausgeschaltet ist und an einen gebooteten PC
oder eine Netzsteckdose angeschlossen wird, leuchtet die Anzeige
CHARGE orange. Die Anzeige CHARGE erlischt, wenn der
Ladevorgang abgeschlossen ist.
Die Ladedauer hängt von der Stromabgabekapazität des
angeschlossenen Geräts ab.
Stromabgabekapazität Voraussichtliche
Ladedauer*
Abgabekapazität von 1,5 A etwa vier Stunden
Abgabekapazität von 500 mA etwa acht Stunden
* Die oben angegebene Dauer variiert je nach Umgebungstemperatur
und anderen Betriebsbedingungen.
Tipp
Ein Gerät, das gerade benutzt wird, kann geladen werden, wenn es an
einen gebooteten PC oder eine Netzsteckdose angeschlossen wird,
auch wenn die Anzeige CHARGE nicht leuchtet. In diesem Fall kann es je
nach den Nutzungsbedingungen länger als oben angegeben dauern,
bis der Akku geladen ist. Daher empfiehlt es sich, das Gerät zum Laden
auszuschalten.
So laden Sie den Akku an einem PC
Micro-USB-Kabel
(mitgeliefert)
Gleichstromeingang
Leuchtet
(orange)
Tipp
Die Stromabgabekapazität variiert je nach dem PC. Einzelheiten zur
Stromabgabe Ihres PCs finden Sie in der Bedienungsanleitung zum PC.
So laden Sie den Akku an einer Netzsteckdose
USB-Netzteil
(handelsüblich)
Micro-USB-Kabel
(mitgeliefert)
Gleichstromeingang
Leuchtet
(orange)
Tipp
Es empfiehlt sich, ein handelsübliches USB-Netzteil mit einer
Stromabgabe von 1,5 A oder höher zu verwenden, aber ein USB-Netzteil
mit einer Stromabgabe von über 500 mA, aber weniger als 1,5 A ist
ebenfalls mit dem Gerät kompatibel. Wenn das Laden über andere
Netzteiltypen erfolgt, kann keine Garantie übernommen werden.
Herstellen einer Funkverbindung mit
BLUETOOTH-Geräten
Wählen Sie je nach Situation eine der folgenden drei
Verbindungsmethoden aus. Bei BLUETOOTH-Geräten muss zunächst
ein Pairing (eine „Paarbildung“) erfolgen.
Pairing und Herstellen einer
Verbindung mit einem BLUETOOTH-
Gerät
Bei diesem Gerät ist ein Pairing mit bis zu acht BLUETOOTH-
Geräten möglich. Beim Pairing mit zwei oder mehr BLUETOOTH-
Geräten führen Sie das folgende Pairing-Verfahren für jedes Gerät
aus.
1 Drücken Sie die Taste (Ein/Aus) PAIRING, um
dieses Gerät einzuschalten.
Die Anzeige (BLUETOOTH) beginnt zu blinken.
Blinkt
(weiß)
2 Halten Sie die Taste (Ein/Aus) PAIRING
gedrückt, bis Signaltöne zu hören sind und die
Anzeige (BLUETOOTH) schnell zu blinken beginnt.
Dieses Gerät wechselt in den Pairing-Modus.
Tipp
Wenn Sie das Gerät zum ersten Mal einschalten, wechselt es
automatisch in den Pairing-Modus.
Blinkt schnell (weiß)
3 Führen Sie den Pairing-Prozess am BLUETOOTH-
Gerät durch, so dass es dieses Gerät erkennt.
Wenn eine Liste der erkannten Geräte im Display des
BLUETOOTH-Geräts erscheint, wählen Sie „SRS-X11“.
Wenn im Display eines BLUETOOTH-Geräts die Aufforderung
zur Eingabe eines Passworts erscheint, geben Sie „0000“
ein.
4 Stellen Sie die BLUETOOTH-Verbindung vom
BLUETOOTH-Gerät aus her.
Sobald die BLUETOOTH-Verbindung hergestellt wurde,
leuchtet die Anzeige (BLUETOOTH) an diesem Gerät stetig.
Herstellung einer Verbindung zu
einem BLUETOOTH-Gerät, mit dem
ein Pairing ausgeführt wurde
1 Schalten Sie dieses Gerät ein.
Die Anzeige (BLUETOOTH) beginnt zu blinken.
2 Stellen Sie die BLUETOOTH-Verbindung vom
BLUETOOTH-Gerät aus her.
Sobald die BLUETOOTH-Verbindung hergestellt wurde,
leuchtet die Anzeige (BLUETOOTH) an diesem Gerät stetig.
Sofortverbindung mit einem
Smartphone (NFC)
Wenn Sie dieses Gerät an ein Smartphone halten, schaltet sich das
Gerät automatisch ein, führt das Pairing durch und stellt die
BLUETOOTH-Verbindung her.
Kompatible Smartphones
NFC-kompatible Smartphones mit Android 2.3.3 oder höher
NFC
NFC (Near Field Communication) ist eine Technologie zur
drahtlosen Kommunikation über kurze Strecken zwischen
verschiedenen Geräten, z.B. Smartphones und IC-Tags. Dank der
NFC-Funktion lässt sich die Datenkommunikation – beispielsweise
das BLUETOOTH-Pairing – einfach durchführen, indem die
NFC-kompatiblen Geräte nahe aneinander gehalten werden (und
zwar an der N-Markierung bzw. einer festgelegten Stelle an den
Geräten).
1 Schalten Sie die NFC-Funktion am Smartphone ein.
Näheres dazu finden Sie in der mit dem Smartphone
gelieferten Bedienungsanleitung.
•Bei einem Smartphone, auf dem das Betriebssystem Android
2.3.3 oder höher, aber eine frühere Version als Android 4.1
installiert ist, fahren Sie mit Schritt2 fort.
•Bei einem Smartphone, auf dem das Betriebssystem Android 4.1
oder höher installiert ist, fahren Sie mit Schritt4 fort.
2 Laden Sie die App „NFC-Schnellverbindung“
herunter und installieren Sie sie.
„NFC-Schnellverbindung“ ist eine kostenlose Android-App,
die Sie von Google Play herunterladen können.
Zum Herunterladen der App suchen Sie nach „NFC-
Schnellverbindung“ oder greifen Sie über den folgenden
zweidimensionalen Code darauf zu. Beim Herunterladen der
App fallen eventuell Gebühren an.
Wenn Sie die App über den
zweidimensionalen Code
herunterladen möchten, verwenden Sie
eine App zum Lesen eines
zweidimensionalen Codes.
Hinweis
In manchen Ländern und/oder Regionen steht diese Anwendung
möglicherweise nicht für den Download zur Verfügung.
3 Starten Sie „NFC-Schnellverbindung“ auf dem
Smartphone.
Vergewissern Sie sich, dass der Bildschirm der App angezeigt
wird.
4 Halten Sie das Smartphone an dieses Gerät.
Heben Sie zuvor die Bildschirmsperre am Smartphone auf.
Halten Sie das Smartphone so lange an die Stelle mit dem
N-Logo an diesem Gerät, bis das Smartphone reagiert. Wenn
dieses Gerät ausgeschaltet ist, schaltet es sich ein, wenn Sie
das Smartphone daran halten.
Smartphone reagiert
(Gerät erkannt)
Befolgen Sie zum Herstellen der Verbindung die
Anweisungen auf dem Bildschirm.
Sobald die BLUETOOTH-Verbindung hergestellt wurde,
leuchtet die Anzeige (BLUETOOTH) an diesem Gerät stetig.
Zum Trennen der Verbindung halten Sie das Smartphone
erneut an dieses Gerät.
Tipps
Wenn sich die Verbindung nicht herstellen lässt, versuchen Sie
Folgendes.
•Starten Sie die App auf dem Smartphone und bewegen Sie das
Smartphone langsam über die Stelle mit dem N-Logo an diesem
Gerät.
•Wenn sich das Smartphone in einem Etui befindet, nehmen Sie
es heraus.
•Vergewissern Sie sich, dass am Smartphone der Bildschirm der
App angezeigt wird.
Musikwiedergabe und Telefonieren
Stellen Sie eine BLUETOOTH-Verbindung mit einem BLUETOOTH-Gerät
her und bedienen Sie dann dieses Gerät.
Wiedergeben von Musik
Profil: A2DP, AVRCP
Starten Sie die Wiedergabe am BLUETOOTH-Gerät und
stellen Sie die Lautstärke ein.
Stellen Sie die Lautstärke am verbundenen Gerät auf einen
geeigneten Pegel ein und stellen Sie dann mit den Tasten VOL –/+
an diesem Gerät die gewünschte Lautstärke ein.
Auf der Taste VOL + befindet sich ein
fühlbarer Punkt.
Tipp
Informationen zur Wiedergabe bei Anschluss an die Buchse AUDIO IN
finden Sie in der Hilfe.
Tätigen eines Anrufs/
Entgegennehmen eines Anrufs
Profil: HSP, HFP
Bedienen Sie das Smartphone, um einen Anruf zu
tätigen.
Zum Beenden eines Anrufs drücken Sie die Taste (Anruf) an
diesem Gerät.
Drücken Sie die Taste (Anruf) an diesem Gerät, wenn
ein Anruf eingeht.
Gehen Sie genauso vor, wenn ein Anruf während der
Musikwiedergabe eingeht.
Die Taste (Anruf) ist mit einem fühlbaren
Punkt gekennzeichnet.
Mikrofon
Tipp
Wenn ein tragbares Audiogerät o.Ä. an die Buchse AUDIO IN
angeschlossen wird, wechselt dieses Gerät automatisch in den Modus
AUDIO IN. In diesem Fall wird der Ton von dem über BLUETOOTH
verbundenen Gerät nicht über dieses Gerät ausgegeben, aber die
Freisprechfunktion beim Telefonieren ist verfügbar.
Wenn Sie zwei SRS-X11-Geräte über BLUETOOTH verbinden,
können Sie für die Tonwiedergabe den Stereomodus
(Stereoklang) oder den Zweifachmodus (Ausgabe desselben
Tons an zwei Geräten gleichzeitig) auswählen. Wenn Sie diese
Funktion (Funktion zum Anschließen eines weiteren
Lautsprechers) nutzen wollen, sind zwei SRS-X11-Geräte
erforderlich.
Weitere Informationen dazu finden Sie in der Hilfe auf der
folgenden Website:
http://rd1.sony.net/help/speaker/srs-x11/h_zz/
•Der BLUETOOTH®-Schriftzug und die BLUETOOTH®-Logos sind
Eigentum von Bluetooth SIG, Inc., und ihre Verwendung durch die
Sony Corporation erfolgt in Lizenz.
•Die N-Markierung ist in den USA und in anderen Ländern ein
Markenzeichen oder ein eingetragenes Markenzeichen von NFC
Forum, Inc.
•Android™ und Google Play™ sind Markenzeichen von Google Inc.
•Andere Markenzeichen und Produktnamen sind Eigentum der
jeweiligen Rechteinhaber.
Español
Manuales suministrados
Guía de inicio (este documento)
Proporciona instrucciones para conectar la unidad con
dispositivos BLUETOOTH y para realizar las
operaciones básicas.
Guía de referencia
Muestra las precauciones y las características técnicas
del producto.
Guía de ayuda
Lea la Guía de ayuda en el ordenador o el teléfono
inteligente si necesita saber más detalles acerca de
cómo usar la unidad. La Guía de ayuda también
contiene una guía de solución de problemas, que le
ofrece soluciones para los problemas más habituales.
URL:
http://rd1.sony.net/help/speaker/srs-x11/h_zz/
Código bidimensional:
Carga de la unidad
La unidad incluye una batería de iones de litio recargable
incorporada. Cargue la batería antes de utilizar la unidad por
primera vez.
Cuando la unidad está apagada y conectada a un PC encendido o
a una toma de CA, el indicador CHARGE se ilumina de color
naranja. El indicador CHARGE se apaga cuando ha terminado la
carga.
El tiempo de carga depende de la potencia de salida del
dispositivo conectado.
Potencia de salida Tiempo de carga estimado*
Salida en 1,5 A Unas cuatro horas
Salida en 500 mA Unas ocho horas
* El tiempo indicado arriba puede variar en función de la temperatura
ambiente o las condiciones de uso.
Sugerencia
Una unidad en funcionamiento puede cargarse si está conectada a un
PC encendido o a una toma de CA, aunque el indicador CHARGE no se
ilumina. En este caso, el tiempo necesario para cargar la batería puede
ser superior al indicado arriba en función de las condiciones de uso. Por
este motivo, se recomienda apagar la unidad al cargar la batería.
Para cargar la batería desde un PC
Cable micro USB
(suministrado)
CC IN
Encendido
(naranja)
Sugerencia
La potencia de salida varía en función del PC. Para obtener información
sobre la potencia de salida del PC, consulte el manual de instrucciones
suministrado con su PC.
Para cargar la batería desde una toma de CA
Adaptador de CA USB
(de venta en el mercado)
Cable micro USB
(suministrado)
CC IN
Encendido
(naranja)
Sugerencia
Se recomienda usar un adaptador de CA USB disponible en el mercado
con una potencia de salida de 1,5 A o más, aunque un adaptador de CA
USB con una potencia de salida de más de 500 mA pero menos de 1,5 A
también es compatible con la unidad. La garantía no cubre la carga de
la batería con otros tipos de adaptadores.
Cómo establecer una conexión
inalámbrica con dispositivos BLUETOOTH
De los siguientes tres métodos de conexión, elija el más adecuado
para su situación. Los dispositivos BLUETOOTH deben “emparejarse”
los unos con los otros de antemano.
Emparejamiento y conexión con un
dispositivo BLUETOOTH
La unidad puede emparejarse con un máximo de ocho
dispositivos BLUETOOTH. Si empareja dos dispositivos BLUETOOTH
o más, siga las siguientes instrucciones de emparejamiento con
cada dispositivo.
1 Pulse el botón (encendido) PAIRING para
encender esta unidad.
El indicador (BLUETOOTH) empieza a parpadear.
Parpadeo
(blanco)
2 Mantenga pulsado el botón (encendido)
PAIRING hasta que escuche pitidos y el indicador
(BLUETOOTH) empiece a parpadear rápidamente.
La unidad pasa al modo de emparejamiento.
Sugerencia
Al encender la unidad por primera vez, accede al modo de
emparejamiento de forma automática.
Parpadeo rápido
(blanco)
3 Lleve a cabo el procedimiento de emparejamiento
en el dispositivo BLUETOOTH para detectar esta
unidad.
Cuando aparezca una lista de dispositivos detectados en la
pantalla del dispositivo BLUETOOTH, seleccione “SRS-X11”.
Si se requiere la introducción de un código de acceso para el
dispositivo BLUETOOTH, introduzca “0000”.
4 Establezca la conexión BLUETOOTH desde el
dispositivo BLUETOOTH.
Una vez establecida la conexión BLUETOOTH, el indicador
(BLUETOOTH) de la unidad permanece encendido.
Conexión con un dispositivo
BLUETOOTH emparejado
1 Encienda esta unidad.
El indicador (BLUETOOTH) empieza a parpadear.
2 Establezca la conexión BLUETOOTH desde el
dispositivo BLUETOOTH.
Una vez establecida la conexión BLUETOOTH, el indicador
(BLUETOOTH) de la unidad permanece encendido.
Conexión con un teléfono inteligente
con un solo toque (NFC)
Con tan solo tocar la unidad con un teléfono inteligente, la unidad
se enciende automáticamente y se empareja y conecta mediante
BLUETOOTH con el teléfono inteligente.
Teléfonos inteligentes compatibles
Teléfonos inteligentes compatibles con la función NFC con Android
2.3.3 o posterior
NFC
NFC (Near Field Communication) es una tecnología que permite la
comunicación inalámbrica de corto alcance entre diversos
dispositivos, como teléfonos inteligentes y etiquetas IC. Gracias a
la función NFC, es posible transmitir datos fácilmente (como, por
ejemplo, realizar el emparejamiento BLUETOOTH) poniendo en
contacto dispositivos compatibles con la tecnología NFC (por
ejemplo, tocando el símbolo con la marca N o el área designada
en cada dispositivo).
1 Active la función NFC en el teléfono inteligente.
Para obtener más información, consulte las instrucciones
suministradas con el teléfono inteligente.
•Si el sistema operativo de su teléfono inteligente es Android
2.3.3 o posterior y anterior a Android 4.1, vaya al paso 2.
•Si el sistema operativo de su teléfono inteligente es Android 4.1
o posterior, vaya al paso 4.
2 Descargue e instale la aplicación “Conexión fácil
NFC”.
“Conexión fácil NFC” es una aplicación gratuita para Android
disponible en Google Play.
Busque “Conexión fácil NFC” o escanee el siguiente código
bidimensional para descargar e instalar la aplicación. Es
necesario abonar los costes de comunicación para descargar
la aplicación.
Para realizar la descarga mediante el
código bidimensional, utilice una
aplicación de lectura de códigos
bidimensionales.
Nota
Puede que la aplicación no esté disponible en algunos países y/o
regiones.
3 Abra la aplicación “Conexión fácil NFC” en el
teléfono inteligente.
Asegúrese de que se muestre la pantalla de la aplicación.
4 Toque esta unidad con el teléfono inteligente.
Desbloquee primero la pantalla del teléfono inteligente.
Siga tocando la parte de la unidad que tiene la marca N con
el teléfono inteligente hasta que este responda. Si la unidad
está apagada, se encenderá al contacto con el teléfono
inteligente.
El teléfono inteligente responde
(reconocimiento de la unidad)
Siga las instrucciones que aparecen en pantalla para
establecer la conexión.
Una vez establecida la conexión BLUETOOTH, el indicador
(BLUETOOTH) de la unidad permanece encendido.
Toque de nuevo la unidad con el teléfono inteligente para
desconectarlo.
Sugerencias
Si hay problemas para establecer la conexión, intente lo siguiente.
•Abra la aplicación en el teléfono inteligente y mueva el teléfono
inteligente despacio sobre la parte de la unidad que tiene la
marca N.
•Si el teléfono se encuentra en el interior de una funda, quítela.
•Asegúrese de que se muestre la pantalla de la aplicación en el
teléfono inteligente.
Escuchar y llamar
Utilice la unidad después de establecer la conexión BLUETOOTH con
su dispositivo BLUETOOTH.
Escuchar música
Perfil: A2DP, AVRCP
Inicie la reproducción en el dispositivo BLUETOOTH y
ajuste el volumen.
Ajuste el volumen del dispositivo conectado en un nivel moderado
y ajuste el volumen de la unidad con los botones VOL –/+.
El botón VOL + tiene un punto táctil.
Sugerencia
Para obtener más información sobre la reproducción mediante la
conexión a través de la toma AUDIO IN, consulte la Guía de ayuda.
Realizar/recibir una llamada
Perfil: HSP, HFP
Utilice su teléfono inteligente para realizar una llamada.
Para poner fin a una llamada, pulse el botón (llamada) de la
unidad.
Pulse el botón (llamada) en la unidad cuando reciba
una llamada entrante.
Haga lo mismo cuando reciba una llamada entrante mientras
escucha música.
El botón (llamada) tiene un punto táctil.
Micrófono
Sugerencia
Al conectar un dispositivo de audio portátil, etc. a la toma AUDIO IN, se
activa automáticamente el modo AUDIO IN en la unidad. En este caso,
el sonido del dispositivo conectado por BLUETOOTH no se emite por la
unidad, pero puede utilizarse la función llamada manos libres.
Al conectar dos unidades SRS-X11 a través de BLUETOOTH, es
posible seleccionar la reproducción de audio con el modo
estéreo (sonido estéreo) o con el modo doble (se emite el
mismo sonido simultáneamente por las dos unidades). Para
usar esta función (función de suma de altavoces), es necesario
disponer de dos unidades SRS-X11.
Para obtener más información al respecto, consulte la Guía de
ayuda en este sitio web:
http://rd1.sony.net/help/speaker/srs-x11/h_zz/
•La marca de la palabra BLUETOOTH® y sus logotipos son propiedad de
Bluetooth SIG, Inc., y cualquier uso de tales marcas por parte de Sony
Corporation se realiza bajo licencia.
•La marca N es una marca comercial o una marca comercial registrada
de NFC Forum, Inc. en Estados Unidos y en otros países.
•Android™ y Google Play™ son marcas comerciales de Google Inc.
•Las demás marcas y nombres comerciales pertenecen a sus
respectivos propietarios.

Other manuals for SRS-X11

5

Other Sony Stereo System manuals

Sony CMT-DH30 User manual

Sony

Sony CMT-DH30 User manual

Sony CMT-M90DVD - Micro Hi Fi Component System User manual

Sony

Sony CMT-M90DVD - Micro Hi Fi Component System User manual

Sony MEX-BT2500 Product guide

Sony

Sony MEX-BT2500 Product guide

Sony CMT-HX9DAB User manual

Sony

Sony CMT-HX9DAB User manual

Sony SRS-X2 User manual

Sony

Sony SRS-X2 User manual

Sony HCD-DX80 User manual

Sony

Sony HCD-DX80 User manual

Sony SHAKE5 User manual

Sony

Sony SHAKE5 User manual

Sony LBT-D270 - Compact Hi-fi Stereo System User manual

Sony

Sony LBT-D270 - Compact Hi-fi Stereo System User manual

Sony HCD-EP313 - Personal Component System User manual

Sony

Sony HCD-EP313 - Personal Component System User manual

Sony CMT-C5 User manual

Sony

Sony CMT-C5 User manual

Sony SHAKE-X30D User manual

Sony

Sony SHAKE-X30D User manual

Sony HCD-XGV6 User manual

Sony

Sony HCD-XGV6 User manual

Sony HCD-GN77D User manual

Sony

Sony HCD-GN77D User manual

Sony MHC-GX570XM Marketing User manual

Sony

Sony MHC-GX570XM Marketing User manual

Sony CMT-V50iP User manual

Sony

Sony CMT-V50iP User manual

Sony CMT-LX20I Marketing User manual

Sony

Sony CMT-LX20I Marketing User manual

Sony NAS-CZ1 M-Crew User manual

Sony

Sony NAS-CZ1 M-Crew User manual

Sony CMT-SE9 User manual

Sony

Sony CMT-SE9 User manual

Sony MHC-C9EX Primary User manual

Sony

Sony MHC-C9EX Primary User manual

Sony ICF-C11IP/BLK User manual

Sony

Sony ICF-C11IP/BLK User manual

Sony HCD-GNZ333D User manual

Sony

Sony HCD-GNZ333D User manual

Sony LBT-V8900S User manual

Sony

Sony LBT-V8900S User manual

Sony MDS-S500 User manual

Sony

Sony MDS-S500 User manual

Sony HCD-H66 User manual

Sony

Sony HCD-H66 User manual

Popular Stereo System manuals by other brands

AEV MATRIX 88 manual

AEV

AEV MATRIX 88 manual

Philips BTM2180 Short user manual

Philips

Philips BTM2180 Short user manual

Aiwa Z-L620 Service manual

Aiwa

Aiwa Z-L620 Service manual

M&S Systems dmc1 Finish-Out instructions

M&S Systems

M&S Systems dmc1 Finish-Out instructions

CONTINENTAL EDISON CETB100BV2 manual

CONTINENTAL EDISON

CONTINENTAL EDISON CETB100BV2 manual

Lightspeed Cascadia C25 installation guide

Lightspeed

Lightspeed Cascadia C25 installation guide

Sharp CD-XP200W Service manual

Sharp

Sharp CD-XP200W Service manual

Philips MCM108B/12 quick start guide

Philips

Philips MCM108B/12 quick start guide

Aiwa NSX-SZ30 Service  manual field

Aiwa

Aiwa NSX-SZ30 Service manual field

Klipsch STADIUM owner's manual

Klipsch

Klipsch STADIUM owner's manual

JVC UX-G70A instructions

JVC

JVC UX-G70A instructions

camry CR 1173 user manual

camry

camry CR 1173 user manual

Zenith FFH-986A Installation and operating guide

Zenith

Zenith FFH-986A Installation and operating guide

dbx 3BX III Service manual

dbx

dbx 3BX III Service manual

Roadstar HIF-8892EBT user manual

Roadstar

Roadstar HIF-8892EBT user manual

Philips FWM15 user manual

Philips

Philips FWM15 user manual

Zenith LX-230A Installation and operating guide

Zenith

Zenith LX-230A Installation and operating guide

Sonance C4630 SE Specifications

Sonance

Sonance C4630 SE Specifications

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
