Sony KV-27FV310 - 27" Fd Trinitron Wega User manual

KV-27FV310 MODEL:
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
POWER
REQUIREMENTS:
POWER
CONSUMPTION:
27" Wega®
Monitor/Receiver
30 7/8 "x 23 3/4" x 20 1/2"
105 lbs 13 oz
120VAC
60Hz
190w
1w(stby)
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
FRONT VIEW
Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX [phone] • b2b.sel.sony.com
SIDE VIEW
TOP VIEW JACK PACK
Video
VIDEO IN
Audio
L
MONO
R
S Video
1
MONITOR
OUT COMPONENT
IN
Y
Pb
Pr
AUX
3
CONV
OUT
VHF/UHF
RM-Y181 SUPPLIED REMOTE
OPTIONAL STAND SU-27F1
30 7/8"
23 3/4"
IR RECEIVER
S
P
E
A
K
E
R
S
S
P
E
A
K
E
R
S
16 1/2"
21 7/8"
9 3/4”
20 1/2"
18 "
10 3/4"
19 3/8"
20 1/2"
27 1/4"
1 1/2”
4 1/2”
(WHD) 32 "x 20" x 23"
