Sony BRAVIA FW-49BZ35F User manual

Sony FW-49BZ35F / 43BZ35F
[GB, CS, CT, VN, FR, TH, ID, ES, AR] 4-735-249-12(1)
4-735-249-12(1)
1
1.5 N∙m/1,5 N∙m
{15 kgf∙cm}
1 2
*
SB2
SB1 M4L12
IM
FB
4
3
6
5
SB2
SB1
M4L12
Setup Guide
© 2018 Sony Visual Products Inc.
*
EN Setup Guide
CS 设定指南
CT 安裝指南
VN Hướng dẫn cài đặt
FR Manuel de configuration
TH 
ID Panduan Penyetelan
ES Guía de configuración
AR  
Reference Guide / 参考指南 / 參考指南 / Hướng dẫn Tham khảo / Manuel de
référence /  / Panduan Referensi / Guía de referencia /  
FW-49BZ35F / 43BZ35F
Only on limited region/country/model.
仅针对有限的地区/ 国家/ 型号。
僅限受限區域／國家／型號。
Chỉ có ở khu vực/quốc gia/model giới hạn.
Uniquement pour certaines régions/pays/modèles.

Hanya untuk kawasan/negara/model tertentu.
Solo en algunos países/regiones/modelos.
.  // 

Sony FW-49BZ35F / 43BZ35F
[GB, CS, CT, VN, FR, TH, ID, ES, AR] 4-735-249-12(1)
4
2 3
1
3
2
PC
1
2
1
2
1
2
1
2
FB
*
*
FB *
Help / 帮助 / 說明 / Trợ giúp /
Aide /  / Bantuan / Ayuda /

Connections Refer to “Connection Diagram” in the Professional Guide for
additional connection information.
连接 请参见专业指南中的“连接示意图”了解更多连接信息。
連接 有關更多連接資訊，請參閱專業指南中的“連接圖”。
Kết nối Tham khảo phần “Sơ đồ Kết nối” trong Hướng dẫn Chuyên
nghiệp để biết thêm thông tin kết nối.
Raccordements Reportez-vous au « Schéma de connexion » dans
le Guide professionnel pour des informations de raccordement
supplémentaires.
 
Sambungan Lihat “Diagram Sambungan” di dalam Panduan Profesional
untuk tambahan informasi sambungan.
Conexiones Consulte la sección “Diagrama de conexión” en la Guía
profesional para obtener información adicional de conexión.
.         « »    

FW-85BZ35F / 75BZ35F / 65BZ35F / 55BZ35F / 49BZ35F / 43BZ35F
D:\SONY TV\2018\CHH B2B\SY18_CHHB_UC2_PG221\4734761221_US\010COV.fm masterpage: Cover
FW-85BZ35F / 75BZ35F / 65BZ35F / 55BZ35F / 49BZ35F / 43BZ35F
4-734-761-22(1)
4-734-761-22(1)
LCD Display
Écran LCD
Pantalla LCD
Professional Guide
(Supplement) US
Guide professionnel
(Supplément) FR
Guía profesional
(Suplemento) ES

2US
D:\SONY TV\2018\CHH B2B\SY18_CHHB_UC2_PG221\4734761221_US\010COVTOC.fm masterpage: Left
FW-85BZ35F / 75BZ35F / 65BZ35F / 55BZ35F / 49BZ35F / 43BZ35F
4-734-761-22(1)
Table of Contents
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Connection Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Using Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Remote Control Parts Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Pro mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Recommended settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Control functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
RS-232C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Extended software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

3US
D:\SONY TV\2018\CHH B2B\SY18_CHHB_UC2_PG221\4734761221_US\020PAT_US.fm masterpage: Right
FW-85BZ35F / 75BZ35F / 65BZ35F / 55BZ35F / 49BZ35F / 43BZ35F
4-734-761-22(1)
US
Overview
Thank you for purchasing this Sony product. This LCD Display is designed for professional
use. It has functions such as [Pro mode], [RS232C control] function, [IP control] function that
can be used for professional use. Furthermore, by using optional software, you can add
convenient functions. Before operating the LCD Display, please read this manual thoroughly.
Introduction
Connection Diagram
*
5
Headphone/Audio
System/Subwoofer
USB memory/
Keyboard/Mouse
etc.
HDMI Device/PC
Audio System with
ARC/HDMI Device/PC
Home Controller
Audio System with
Optical Audio Input
DVD player with
component output
HDMI Device/PC
VCR/Video game equipment/
DVD player/Camcorder
DVI-HDMI Adapter/
HDMI Device/PC
Router
DVI-Audio Out

4US
D:\SONY TV\2018\CHH B2B\SY18_CHHB_UC2_PG221\4734761221_US\020PAT_US.fm masterpage: Left
FW-85BZ35F / 75BZ35F / 65BZ35F / 55BZ35F / 49BZ35F / 43BZ35F
4-734-761-22(1)
USB 1/2, USB 3
• Connecting a large USB device may
interfere with other connected
devices beside it.
• When connecting a large USB device,
connect to the USB 1 port.
AUDIO OUT /
• Supports 3-pole stereo mini jack only.
• To listen to the LCD Display's sound
through the connected equipment,
press HOME. Select [Settings] 
[Sound] [Headphone/Audio out]
and then select the desired item.
HDMI IN 1/2/3/4
• HDMI interface can transfer the digital
video and audio on a single cable.
•
•HDMI IN 2/3
To enjoy high quality 4K 60p
contents, connect a Premium High
Speed HDMI cable to the HDMI IN 2/3
and set the [HDMI signal format] to
[Enhanced format].
For details of supported formats, refer
to the “Specifications” in Reference
Guide (page 16 - 18).
•HDMI IN 3 ARC (Audio Return
Channel)
Connect your audio system to the
HDMI IN 3 to route LCD Display audio
to your audio system. An audio
system that supports HDMI ARC can
send video to the LCD Display, and
receive audio from the LCD Display
via the same HDMI cable. If your
audio system does not support HDMI
ARC, an additional connection with
DIGITAL AUDIO OUT (OPTICAL) is
necessary.
REMOTE RS-232C
• Terminal for serial communication.
For details, refer to “RS-232C” on the
control functions (page 9).
HDMI 1 AUDIO IN
• If the device has a DVI jack, connect it
to HDMI IN 1 through a DVI - HDMI
adapter interface (not supplied), and
connect the device's audio out jack to
HDMI 1 AUDIO IN.
* When connecting mono equipment, connect to
the L (MONO) audio jack (socket).
< 21 mm
< 12 mm
RX
TX
GND

5US
D:\SONY TV\2018\CHH B2B\SY18_CHHB_UC2_PG221\4734761221_US\020PAT_US.fm masterpage: Right
FW-85BZ35F / 75BZ35F / 65BZ35F / 55BZ35F / 49BZ35F / 43BZ35F
4-734-761-22(1)
US
Using Remote Control
(Input select)
Display and select the input source.
SYNC MENU
Display the BRAVIA Sync Menu.
(LCD Display standby)
Turn on or turn off the LCD Display
(standby mode).
HDMI 1/2/3/4
Switch to the HDMI input.
Number buttons
Use with the 0-9 buttons to select
digital channels.
CC
Turn subtitles on or off (when the
feature is available).
Color buttons
Execute corresponding function at that
time.
Remote Control Parts Description
The remote control shape, location, availability and function of remote control buttons
may vary depending on your region/country/LCD Display model.
Ȫ
ȩ
ȫ
Ȭ
ȭ
Slide and open the lid of the battery
compartment, then insert two R03
(size AAA) batteries.

6US
D:\SONY TV\2018\CHH B2B\SY18_CHHB_UC2_PG221\4734761221_US\020PAT_US.fm masterpage: Left
FW-85BZ35F / 75BZ35F / 65BZ35F / 55BZ35F / 49BZ35F / 43BZ35F
4-734-761-22(1)
HELP
Display the Help menu. Help Guide can
be accessed from here.
(Screen display)
Switch to show/hide the information of
the input source, clock, etc.
/BACK
Return to the previous screen.
OPTIONS
Displays a list of functions that can be
used at that time.
//// (NavigationD-Pad)
On screen menu navigation and
selection.
HOME/MENU
Display the LCD Display Home Menu.
+/– (Volume)
Adjust the volume.
AUDIO
Change the language for the program
currently being viewed.
(Muting)
Mute the sound. Press again to restore
the sound.
CH/PAGE +/–
Press to change a channel or a page.
///.///>
Operate media contents on the LCD
Display and connected BRAVIA Sync-
compatible device.
Guidelines for IR Remote Control
• Point your remote control directly at
the IR sensor located on your LCD
Display.
• Make sure that no objects are blocking
the path between the remote control
and the IR sensor on your LCD Display.
• Fluorescent lamps can interfere with
your remote control; try turning off the
fluorescent lamps.
• If you are having problems with the
remote control, reinsert or replace your
batteries and make sure that they are
correctly inserted.

7US
D:\SONY TV\2018\CHH B2B\SY18_CHHB_UC2_PG221\4734761221_US\030ADD_US.fm masterpage: Right
FW-85BZ35F / 75BZ35F / 65BZ35F / 55BZ35F / 49BZ35F / 43BZ35F
4-734-761-22(1)
US
Settings
In [Pro mode], you can use various convenient functions for professional use. Here, we
introduce how to change to [Pro mode] and typical functions of [Pro mode].
Pro mode
Normal mode: This is the default mode. [Pro mode] functions are not available in this mode.
Pro settings mode: This mode allows you to set various settings of [Pro mode] functions.
Pro mode: This is the operation mode for professional use where you can use the [Pro mode]
functions.
How to change the mode
When the LCD Display is in Normal mode and Pro settings mode
• Go to [Home] t[Apps] t[Pro mode tool], then select the mode you want to change.
When the LCD Display is in the Pro mode
• Press the activation keys described below on the remote control in order within a one
second interval.
After restarting the LCD Display, the mode changes to [Pro settings mode].
Activation key: (Screen display) / (Muting) / +/– (Volume +) / (HOME)
* Initially you cannot change the mode from [Pro mode tool] in [Pro mode]. If you want to change the mode
from [Pro mode tool], go to [Pro settings] t[Function restrictions] t[Apps] and change [Pro mode tool]
to [Enable] in [Pro settings mode].
Introduction of the Pro mode functions
In [Pro mode], you can use various convenient functions. Typical [Pro mode] functions are
introduced below.
Setting LCD Display operation when turning the AC power on
You can set the operation of the LCD Display when unplugging and reinserting the AC
power plug.
Optimized display of the PC input screen
The screen displays the PC input screen with optimum size according to the PC format.
Power supply control and automatic input switching by HDMI signal detection
If you turn on the LCD Display when the HDMI device is connected, you can change to the
connected HDMI input automatically.
Settings of the displaying menu when pressing the HOME button
You can select the menu displayed when pressing the HOME button on the remote control.
Initial input source designation when starting the LCD Display
You can designate the initial input source when starting the LCD Display.
Pro mode lock
You can protect the settings of [Pro mode] by using a PIN.
Initial/maximum volume setting
You can set the initial and maximum volume of the LCD Display.
Restriction of the LCD Display operation on the remote control
You can restrict the LCD Display operation using the remote control.
Restriction of external inputs
You can restrict the use of external inputs.
Pro mode

8US
D:\SONY TV\2018\CHH B2B\SY18_CHHB_UC2_PG221\4734761221_US\030ADD_US.fm masterpage: Left
FW-85BZ35F / 75BZ35F / 65BZ35F / 55BZ35F / 49BZ35F / 43BZ35F
4-734-761-22(1)
Restriction of using applications
You can restrict the use of LCD Display applications.
How to set Pro mode functions
Go to [Home] t[Pro settings] or go to [Home] t [Settings] t[Pro settings] when the LCD
Display is in [Pro settings mode].*
* Varies depending on the version of the OS.
This section introduces recommended settings when using the LCD Display for professional
use.
Setting ECO features
1Go to [Settings] t[Power] t[Eco].
• Set [Idle TV standby] to [Off].
Setting IP features
2Go to [Settings] t[Network] t[Home network] t[IP control].
• Set [Authentication] to [Normal and Pre-Shared Key].
• Set [Simple IP control] to [On].
Automatic Software Download
3Go to [Settings] t[About] t[System software update].
• Set [Automatic software download] to [Off].
Picture settings
4Select the [Inputs] (ex. HDMI 1) whose settings you want to change, then press
OPTIONS and select [Display & Sound] t[Picture adjustments].
• Set [Light sensor] to [Off].
• Select [Picture mode] according to usage.
[Vivid]: When using the digital signage display
[Custom]: When displaying the original image as is
[Graphics]: When displaying the PC screen
Setting values of [Picture mode]
The following is the initial value of each setting item of [Picture mode].
* Since the LCD Display responds faster in [Graphics] mode than it does in [Custom] mode, the LCD Display
can display the mouse movement smoothly when operating the PC screen in [Graphics] mode.
Note
Each setting value is subject to change without notice.
Recommended settings
Items [Picture mode]
[Vivid] [Standard] [Custom]* [Graphics]*
[Brightness] Max.(50) 30 35 35
[Color] 60 60 50 50
[Contrast] Max.(100) Max.(100) 90 90

9US
D:\SONY TV\2018\CHH B2B\SY18_CHHB_UC2_PG221\4734761221_US\030ADD_US.fm masterpage: Right
FW-85BZ35F / 75BZ35F / 65BZ35F / 55BZ35F / 49BZ35F / 43BZ35F
4-734-761-22(1)
US
Control functions
You can control the LCD Display from an external service via RS-232C. The RS-232C connection
is briefly explained in this page.
Interface
Establish the RS-232C connection to the LCD Display by using a 3.5 mm stereo mini plug.
3.5mm Stereo mini plug
Connection settings
When establishing the RS-232C connection, make connection settings as below.
Data format
We introduce the data format for the RS-232C communication below.
(a) Requests from the controller to the LCD Display
RS-232C
Baud rate 9,600 bps
Data 8 bit
Parity None
Start bit 1 bit
Stop bit 1 bit
Flow control None
No. Item Value
1Header 0x8C : Control
2Category 0x00 (fixed)
3Function 0xXX
4Length 0xXX (=Data X+1 byte)
5Data 1 0xXX
: : 0xXX
: : 0xXX
X+4 Data X 0xXX
X+5 Check Sum 0xXX
1234
6 7 8 9
5
TIP
RING
SLEEVE GND
TXD
RXD
TIP: LCD Display tController
RING: Controller tLCD Display

10US
D:\SONY TV\2018\CHH B2B\SY18_CHHB_UC2_PG221\4734761221_US\030ADD_US.fm masterpage: Left
FW-85BZ35F / 75BZ35F / 65BZ35F / 55BZ35F / 49BZ35F / 43BZ35F
4-734-761-22(1)
(b) Responses from the LCD Display to the controller
Command example
Examples of RS-232C communication command are explained below.
For more details on RS-232C, please contact your sales representative.
You can control the LCD Display via IP from an HTML5/Android application on the LCD Display
or on the external device. You can manage and monitor information of input/power, start and
terminate applications, control the display such as changing channels and volume. You can
also restrict commands by the authentication function.
Supported IP protocol
No. Item Value
1Header 0x70 Answer
2Answer* 0x00 Completed (Normal End)
0x01 : Limit Over
(Abnormal End-Exceed maximum value)
0x02 : Limit Over
(Abnormal End-Exceed minimum value)
0x03 : Command Canceled (Abnormal end)
0x04 : Parse Error (Data Format Error)
3Check Sum 0xXX
Control Head Category Function Length Data 1 Data X Checksum
Power
on/off 0x8C 0x00 0x00 0x02 0x00 (off) -0x8E
0x01 (on) -0x8F
HDMI
input
selection
0x8C 0x00 0x02 0x03 0x04
(HDMI)
0x01 (#1) 0x96
0x02(#2) 0x97
0x03(#3) 0x98
0x04(#4) 0x99
IP
Protocol name Layer Format Authentication Explanation
Web API HTTP JSON-RPC Yes The APIs whose purpose is device
control.
IRCCIP HTTP SOAP Yes Infrared Compatible Control over
Internet Protocol.
The technology and formats to
transmit remote control
commands via the Internet.
SSIP TCP Byte stream N/A Only typical functions are
supported.

11US
D:\SONY TV\2018\CHH B2B\SY18_CHHB_UC2_PG221\4734761221_US\030ADD_US.fm masterpage: Right
FW-85BZ35F / 75BZ35F / 65BZ35F / 55BZ35F / 49BZ35F / 43BZ35F
4-734-761-22(1)
US
LCD Display settings
When using [IP control], set the LCD Display as follows first.
Go to [Settings] t[Network] t[Home network] t[IP control].
• Set [Authentication] to [Normal and Pre-Shared Key].
• Set [Pre-Shared Key].
Example of HTTP request and response for Web API
Here is the example of a request and response to acquire the power status to the LCD Display
(IP address: 192.168.0.1 Pre-shared Key “1234”).
URL
http://192.168.0.1/sony/system
Request
Response
For more details on [IP control], please contact your sales representative.
POST /sony/system HTTP/1.1
Host: 192.168.0.1
Content-Type: application/json; charset=UTF-8
Content-Length: 70
X-Auth-PSK: 1234
{"method": "getPowerStatus", "params": [], "id": 50, "version": "1.0"}
HTTP/1.1 200 OK
Content-Type: application/json; charset=UTF-8
Content-Length: 44
{"result": [{"status": "active"}], "id": 50}

12US
D:\SONY TV\2018\CHH B2B\SY18_CHHB_UC2_PG221\4734761221_US\030ADD_US.fm masterpage: Left
FW-85BZ35F / 75BZ35F / 65BZ35F / 55BZ35F / 49BZ35F / 43BZ35F
4-734-761-22(1)
Appendix
You can use the LCD Display more conveniently by using extended software. This page
introduces an example of extended software.
For more details, please contact your sales representative.
Software for office LCD Display
Provides convenient functions for using the LCD Display as an office LCD Display connected to
a PC in a conference room or the like.
Function examples:
• Power management/Power supply monitoring functions.
• White board function.
• System linked with the conference room reservation system (Supports the Microsoft
Exchange Server reservation table, Gsuite).
• Presentation timer.
• You can change inputs or turn the power on/off without the remote control.
Software for digital signage
When using the LCD Display as a digital signage display, the software provides convenient
functions.
Function examples:
• Digital signage distribution management function to multiple LCD Display via the network.
• Easy signage playback function with USB memory.
• Contents and playlist management function.
• Flexible delivery schedule setting by time and day of the week.
Extended software

D:\SONY TV\2018\CHH B2B\SY18_CHHB_UC2_PG221\4734761221_US\060BCO.fm masterpage: BCO
FW-85BZ35F / 75BZ35F / 65BZ35F / 55BZ35F / 49BZ35F / 43BZ35F
4-734-761-22(1)
© 2018 Sony Visual Products Inc. Printed in Mexico
