Sony Bravia KDL-40R38OB User manual

Television
T l viseur Operating Instructions US
(Setup Guide)
Mode d'emploi FR
(Guide d'installation)
BRAVIA
Sony Customer Support
U.S.A.:
http://www.sony.com/tvsupport
Canada:
http://www.sony.ca/support
United States Canada
1.800.222.SONY 1.877.899.SONY
Please Do Not Return
the Product to the Store
Service _ la clientele Sony
Canada :
http://support.sony.ca/fr
t_tats-Unis :
http://www.sony.com/tvsupport
Canada t_tats-Unis
1.877.899.SONY 1.800.222.SONY
Ne retournez pas le produit au magasin

Owner's Record
the model and serial numbers are located at the side and rear
of the rv, Record these numbers in the spaces provided below
Refer to them whenever you carl upon your Sony dealer
regarding this TV,
Model Name
Serial No
CAUTION
fb prevent electric shock and blade exposure, do not use this polarized
AC plug with an extension cord, receptacle or other outlet unless the
blades can be fully inserted,
The 32 class has a 315 inch viewable image size (measured
diagonally)
Locationofthe identification label
[.abels fol the _V Model No,, Power Supply rating (in acc:ordance with
applicable safety regulation) and Manufacturing date are located on
the rear of the TV,
Note:
•The illustrations of the remote control used irl this manual are of the
RM ¥D092 unless otherwise stated,
• The illustrations used in this manual may differ depending on your
TV model
(:leaning
When cleaning, be sure to unplug the power _ord to avoid a ny chance
of electric shock
• Wipe the LCD screen gently with a soft cloth
• Stubborn stains may be removed with a cloth slightly moistened
with a solution of mild soap and warm water,
• If usfflg a chemically pretreated cloth, please follow the instruction
provided on the package
• Never use strong solvents such as a thinner, alcohol or benzine for
cleaning,
• See the supplied Safety Booklet for additional information
2US

Table of Contents
Introducing Your New BRAVIA ®
Getting Started
Checking the Accessories ................ 6
Inserting Batteries into the
Remote Control ........................ 6
Setting Up Your TV ..................... 7
Attaching the Table-Top Stand ........... 7
Connecting the TV ..................... 8
Cable System or VHF/UHF Antenna System... 8
Cable System and VHF/UHF Antenna
System ................................. 8
HD Cable Box/HD Satellite Box ............. 9
Securing the TV ....................... 10
Preventing the TV from Toppling ........... 10
Recommended Measures to
Secure the TV........................... 10
Running Initial Setup ................... 11
Parts and Controls
TV .................................. 12
Remote Control ....................... 13
Watching TV
Changing the Viewing Style ............. 15
Changing the Wide Mode ................. 15
Setting Scene Select ...................... 15
Navigating through Home Menu
Favorites ............................ 16
Applications ......................... 16
Using the TV as a Photo Frame ............ 16
Media ................................ 17
Playing back Photo/Music/Video via USB .... 17
Settings ............................. 18
Preferences ............................ 18
Customer Support ....................... 25
Viewing Pictures from Connected
Equipment
Connection Diagram ................... 26
Using Audio and Video Equipment ....... 27
Additional Information
Using a Wall-Mount Bracket ............ 28
Installing the TV Against a Wall or
Enclosed Area ........................ 28
Troubleshooting ...................... 29
Picture ................................ 29
Sound ................................. 29
Channels .............................. 29
General ................................ 30
Specifications ........................ 30
Safety Information .................... 32
3us

Customer Support
United States
http ://www.sony.com/tvsu pport
Canada
http://www.sony.ca/support
On-line Registration
United States
http://productregistration.sony.com
Canada
htt p://www.sony.ca/registration
4us

Welcometo theWorldofBRAVIA®
Thank you for choosing this Sony BRAVlA _ high-
definition television. Use the documentation listed
below to get the most out of your TV.
Safety Booklet
Contains precautionary measures to
keep you and your TV safe. Read this
information prior to setting up your TV.
Operating Instructions
Provides the most detailed information
to operate your TV.
Quick Setup Guide
Provides TV setup information with
sample connection diagrams.
Please take a moment to register your TV at:
U.S.A.: http://productregistration.sony.com
Canada: http://www.sony.ca/registration
ExperiencingStunningHDwith YourBRAVIA
TV
To experience the stunning detail of your new
BRAVlA TV, you need access to high-definition (HD)
programming. Your BRAVlA TV can receive and
display HD programming from:
• Over-the-air broadcasting via HD-quality antenna
• HD cable subscription
• HD satellite subscription
• Blu-ray Disc TM player or other HD compatible
external equipment
Contact your cable, satellite or HD service provider
for information on upgrading to liD programming.
The Four Stepsto a Full HD Experience
Set, Sound, Source, and Setup
Along with your BRAVIA TV set, a complete HD
system requires an liD sound system, a source of
lid programming and a proper connection setup.
Refer to the Quick Setup Guide, enclosed
separately, for connecting optional equipment.
5us

Checking the Accessories
Remote control (1).1
Size AAA batteries (2)
AC power cord (1)
Table-Top Stand (1)
Fixing screws for Table-Top Stand (M4 x 18) (4)
Operating Instructions (1)
Quick Setup Guide (1)
Safety and Regulatory Booklet (1)
Software License (1)
Stand Installation Guide (1)
"1 Please refer to the model name printed on the remote
control.
Inserting Batteries into the
Remote Control
1Remove the protection sheet.
2Push and slide the cover to open.
Guidelines for Remote Control
• Point your remote control directly at the IR sensor
located on your TV.
• Make sure that no objects are blocking the path
between the remote control and the IR sensor on
your TV.
• Fluorescent lamps can interfere with your remote
control; try turning offthe fluorescent lamps.
• If you are having problems with the remote
control, reinsert or replace your batteries and
make sure that they are correctly inserted.
6us

Setting Up Your TV
Some TV models are packaged with a detached
Table-Top Stand so you can mount your TV to a wall
right away. If you are not mounting the TV to a wall,
you will need to attach the Table-Top Stand. You will
need a Phillips screwdriver (not supplied) and the
supplied screws to complete the task. Look for the
supplied Table-Top Stand instruction leaflet.
Be sure to consider the following while setting up
your TV:
• Disconnect all cables when carrying the TV.
• Carry the TVwith the adequate number of
people; larger size TVs require two or more
people.
• Correct hand placement while carrying the TV is
very important for safety and to avoid damage.
• Do not put stress on the LCD panel or the frame
around the screen.
Attaching the Table-Top Stand
Note
• If using an electric screwdriver, set the tightening torque
at approximately 1.2N.m {12kgf<m}.
• When detaching the Table-Top Stand, reverse the
attaching procedure.
• Be sure the TV is vertical before turning on. To avoid
uneven picture uniformity do not power on the TV with
the LCDpanel facing down.
• When attaching the Table-Top Stand again, be sure to
fasten the screws (previously removed) to the original
holes on the rear of the TV.
KDL-40R380B/40R3SOB
• Ensure your TV has adequate ventilation, see
page 28.
• For best picture quality, do not expose the screen
to direct illumination or sunlight.
• Avoid installing the TV in a room with reflective
wall and floor materials.
• Avoid moving the TV from a cold area to a warm
area. Sudden room temperature changes may
cause moisture condensation. This may cause the
TV to show poor picture and/or poor color. Should
this occur, allow moisture to evaporate
completely before powering the TV on.
• Ensure that there are no objects in front of the TV.
IR Sensor
7us

KDL-32R330B/32R300B
Connecting the TV
You can enjoy high-definition and standard-
definition digital programming (if available in your
area) along with standard-definition analog
programming.
This TV is capable of receiving unscrambled digital
programming for both cable (QAM and 8VSB) and
external VHF/UHF antenna (ATSC).
Cableor VHF/UHF(or VHFonly)
75-ohm
coaxial cable _ _ Rear of]V
CABLE/ANTENNA
Note
• It is strongly recommended that you connect the CABLE/
ANTENNA input using a 7S-ohm coaxial cable to receive
optimum picture quality. A 300-ohm twin lead cable can
easily be affected by radio frequency interference,
resulting in signal degradation.
Use an optional A-B RF switch (not supplied) to
switch between the cable and over-the-air antenna
programming, as indicated below.
Cable
Antenna
A/B RFSwitch
Rear of TV
CABLE/ANTENNA
Note
• Be sure to set the Signal Type setting to Cable or
Antenna found under the Channel settings for your input
signal (page 20).
8us

You can enjoy high-definition programming by
subscribing to a high-definition cable service or a
high-definition satellite service. For the best
possible picture, make sure you connect this
equipment to your TV via the HDMI or component
video (with audio) input located on the back of your
TV.
Shownwith HDMIConnection
/
\//
Shown with Component Connection
Set Top Box
Set Top Box
9us

Securingthe TV
Z_ Sony strongly recommends taking
measures to prevent the TV from toppling
over. Unsecured TVs may topple and result
in property damage, serious bodily injury
or even death.
• Secure the TV to a wall and/or stand.
• Do not allow children to play or climb on furniture
and TV sets.
• Avoid placing or hanging items on the TV.
• Never install the TV on:
- slippery, unstable and/or uneven surfaces.
- furniture that can easily be used as steps, such
as a chest of drawers.
• Install the TV where it cannot be pulled, pushed,
or knocked over.
• Route all AC power cords and connecting cables
so that they are not accessible to curious children.
Consider the following measures when securing
your TV to a TV stand (not supplied).
1 Secure the stand for the TV.
Make sure the TV stand can adequately support
the weight of the TV. Use two angle braces (not
supplied) to secure the stand.
For each angle brace use the appropriate
hardware to:
• Attach one side of the angle brace to the wall
stud.
• Attach the other side to the TV stand.
Angle braces
(not supplied)
Stand
2 Secure the TVto the stand.
Use the optional hardware listed below (not
supplied):
• M4 machine screw (screwed into the screw
hole of the TV).
• A screw or similar (attach it to the TV stand).
• Rope or chain (strong enough to support the
weight of the TV). Make sure that there is no
excess slack in the rope or chain.
Screw hole of the TV M4 machine screw
/\\ (not supplied)
ain
Screvv__ (not supplied)
(not supplied) _
The length of the M4 machine screw differs
depending on the rope or chain diameter. Please
refer to below illustration.
9-13 mm
o Screw M4
TV Rope or chain
lOUS
