Sony KV-32S65 User manual

—1 —
KV-32S65/35S65
TRINITRON ® COLOR TV
MODEL DEST. COMMANDER CHASSIS NO.
US RM-Y167 SCC-S07K-A
CND RM-Y167 SCC-S08M-A
US RM-Y167 SCC-S07M-A
CND RM-Y167 SCC-S08N-A
KV-32S65 RM-Y167
KV-32S65
KV-32S65
KV-35S65
KV-35S65
SERVICE MANUAL
CHASSIS
AA-2D

—2 —
KV-32S65/35S65
SPECIFICATIONS
Television system
American TV standard
Channel coverage
VHF:2-13/UHF:14-69/CATV:1-125
Visible screen size
32-inch picture measured (KV-32S65)
35-inch picture measured (KV-35S65)
Antenna
75 ohm external terminal for VHF/UHF
Supplied Accessories
Remote commander (w/2 size AA (R6) batteries)
RM-Y167
Optional Accessory
Connecting Cables: VMC-810S/820S
VMC-720M,YC-15V/30V,RK-74A
TV-Stand: SU-32A3,SU-35A3
VHF/UHF Mixer: EAC-66
1) 1 Vp-p 75 ohms unbalanced, sync negative
2) Y: 1 Vp-p 75 ohms unbalanced, sync negative
C: 0.286 Vp-p (Burst signal), 75 ohms
3) 500 mVrms (100% modulation), Impedance: 47 kilohms
4) More than 408 mVrms at the maximum volume setting (variable)
Design and specifications are subject to change without notice.
(l)SRS (SOUND RETRIEVAL SYSTEM)
The ( l) SRS (SOUND RETRIEVAL SYSTEM) is manufac-
tured by Sony Corporation under license from SRS Labs,
Inc. It is covered by U.S. Patent No. 4,748,669. Other U.S.
and foreign patents pending.
The word ‘SRS’ and the SRS symbol (l) are registered
trademarks of SRS Labs, Inc.
BBE and BBE symbol are trademarks of BBE Sound,Inc.
and are licensed by BBE Sound, Inc. under USP 4638258
and USP 4482866.
KV-32S65 KV-35S65
Power requirements 120V,60Hz 120V,60Hz
Number of inputs/outputs
Video
1)
22
S Video
2)
11
Audio
3)
22
Audio Out
4)
11
Monitor Out --
TV out --
S-Link Yes Yes
Speaker output(W) 5W x 2 5W x 2
Power Consumption(W)
In use(Max)
180W 210W
In standby 2W 3W
Dimensions(W/H/D) (mm)
791 x 707 x 604.5mm 870 x 761 x 653mm
(in) 31 x 27
13/16
x 23
3/4
34
1/4
x 30 x 25
5/8
Mass (kg)
73kg 83kg
(lbs)
160.5 lbs 183lbs
More than 408 mVrms at the maximum volume setting (fix)
Impedance: 50 kilohms

—3 —
KV-32S65/35S65
1. GENERAL
Connecting and Installing the TV ......................................... 5
Operating Video Equipment................................................... 7
Operating a Cable Box or DBS Receiver............................... 8
Troubleshooting..................................................................... 8
2. DISASSEMBLY
2-1.Rear Cover Removal ...................................................... 9
2-2.Chassis Assembly Removal .......................................... 9
2-3.Service Position ............................................................. 10
2-4-1. Picture Tube Removal (32")....................................... 11
2-4-2. Picture Tube Removal (35")....................................... 11
3. SET-UP ADJUSTMENTS
3-1.Beam Landing................................................................. 12
3-2.Convergence................................................................... 13
3-3.Focus............................................................................... 14
3-4.Screen (G2)..................................................................... 14
3-5.White Balance Adjustments............................................ 14
4. SAFETY RELATED ADJUSTMENTS ................................. 15
5. CIRCUIT ADJUSTMENTS .................................................... 16
6. DIAGRAMS
6-1-1. Block Diagram (1/2) .................................................. 23
6-1-2. Block Diagram (2/2) .................................................. 27
6-2. Circuit Boards Location................................................... 30
6-3.Printed Wiring Boards and Schematic Diagrams ............ 30
TABLE OF CONTENTS
• B Board ..................................................................... 31
• HS Board .................................................................. 33
• HV Board................................................................... 33
• A Board...................................................................... 39
• UV Board................................................................... 43
• C Board .................................................................... 46
• AV Board.................................................................... 47
• G Board .................................................................... 47
• WB Board.................................................................. 50
• P Board...................................................................... 51
• WA Board................................................................... 51
6-4.Semiconductors.............................................................. 54
7. EXPLODED VlEWS
7-1. Chassis ......................................................................... 55
(KV-32S65)
7-2. Chassis.......................................................................... 56
(KV-35S65)
8. ELECTRICAL PARTS LIST
• Table of Contents for Parts List.................................. 57
• Parts Listings............................................................. 58
CAUTION!
AFTER REMOVING THE ANODE, SHORT CIRCUIT THE ANODE
OF THE PICTURE TUBE AND THE ANODE CAP TO THE METAL
CHASSIS, CRT SHIELD, OR CARBON PAINTED ON THE CRT.
WARNING!!
AN ISOLATION TRANSFORMER SHOULD BE USED DURING ANY
SERVICE TO AVOID POSSIBLE SHOCK HAZARD, BECAUSE OF
LIVE CHASSIS.THE CHASSIS OF THIS RECEIVER IS DIRECTLY
CONNECTED TO THE AC POWER LINE.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY SHADING AND MARK ¡ ON
THE SCHEMATIC DIAGRAMS, EXPLODED VIEWS AND IN THE
PARTS LISTARE CRITICAL FOR SAFE OPERATION. REPLACE
THESE COMPONENTS WITH SONY PARTS WHOSE PART
NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN
SUPPLEMENTS PUBLISHED BY SONY. CIRCUIT
ADJUSTMENTS THAT ARE CRITICAL FOR SAFE OPERATION
ARE IDENTIFIED IN THIS MANUAL. FOLLOW THESE
PROCEDURES WHENEVER CRITICAL COMPONENTS ARE
REPLACED OR IMPROPER OPERATION IS SUSPECTED.
ATTENTION
APRES AVOIR DECONNECTE LE CAP DE L'ANODE, COURT-CIRCUITER L'ANODE
DU TUBE CATHODIQUE ET CELUI DE L'ANODE DU CAP AU CHASSIS METALLIQUE
DEL'APPAREIL, OUAU COUCHEDE CARBONEPEINTE SURLE TUBECATHODIQUE
OU AU BLINDAGE DU TUBE CATHODIQUE.
ATTENTION!!
AFIN D'EVITER TOUT RESQUE D'ELECTROCUTION PROVENANT D'UN CHÁSSIS
SOUS TENSION, UN TRANSFORMATEUR D'ISOLEMENT DOIT ETRE UTILISÉ LORS
DE TOUT DÉPANNAGE. LE CHÁSSIS DE CE RÉCEPTEUR EST DIRECTEMENT
RACCORDÉ À L'ALIMENTATION SECTEUR.
ATTENTION AUX COMPOSANTS RELATIFS A LA SECURITE!!
LES COMPOSANTS IDENTIFIES PAR UNE TRAME ET PAR UNE MARQUE ¡ SUR
LES SCHEMAS DE PRINCIPE, LES VUES EXPLOSEES ET LES LISTES DE PIECES
SONT D'UNEIMPORTANCE CRITIQUE POUR LA SECURITE DU FONCTIONNEMENT.
NE LES REMPLACER QUE PAR DES COMPOSANTS SONY DONT LE NUMERO DE
PIECE EST INDIQUE DANS LE PRESENT MANUEL OU DANS DES SUPPLEMENTS
PUBLIES PAR SONY. LES REGLAGES DE CIRCUIT DONT L'IMPORTANCE EST CRI-
TIQUE POUR LA SECURITE DU FONCTIONNEMENT SONT IDENTIFIES DANS LE
PRESENT MANUEL. SUIVRE CES PROCEDURES LORS DE CHAQUE
REMPLACEMENT DE COMPOSANTS CRITIQUES, OU LORSQU'UN MAUVAIS
FONTIONNEMENT SUSPECTE.
WARNINGS AND CAUTIONS
Section Title PageSection Title Page

—4 —
KV-32S65/35S65
SAFETY CHECK-OUT
After correcting the original service problem, perform the
following safety checks before releasing the set to the
customer:
LEAKAGE TEST
The AC leakage from any exposed metal part to earth ground
and from all exposed metal parts to any exposed metal part having
a return to chassis, must not exceed 0.5 mA (500 microampere).
Leakage current can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or
RCA WT-540A. Follow the manufacturers' instructions to
use these instructions.
2. A battery-operated AC milliammeter. The Data Precision
245 digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of
a VOM or battery-operated AC voltmeter. The "limit"
indication is 0.75 V, so analog meters must have an accurate
low voltage scale. The Simpson's 250 and Sanwa
SH-63Trd are examples of passive VOMs that are suitable.
Nearly all battery operated digital multimeters that have a
2V AC range are suitable. (See Fig. A)
1. Check the area of your repair for unsoldered or poorly-
soldered connections. Check the entire board surface
for solder splashes and bridges.
2. Check the interboard wiring to ensure that no wires
are “pinched” or contact high-wattage resistors.
3. Check that all control knobs, shields, covers, ground
straps, and mounting hardware have been replaced.
Be absolutely certain that you have replaced all the
insulators.
4. Look for unauthorized replacement parts, particularly
transistors, that were installed during a previous
repair. Point them out to the customer and
recommend their replacement.
5. Look for parts which, though functioning, show
obvious signs of deterioration. Point them out to
the customer and recommend their replacement.
6. Check the line cords for cracks and abrasion.
Recommend the replacement of any such line cord
to the customer.
7. Check the B+ and HV to see if they are specified
values. Make sure your instruments are accurate;
be suspicious of your HV meter if sets always have
low HV.
8. Check the antenna terminals, metal trim, “metallized"
knobs, screws, and all other exposed metal parts for
AC Leakage. Check leakage as described below.
HOW TO FIND A GOOD EARTH GROUND
A cold-water pipe is guaranteed earth ground; the cover-plate
retaining screw on most AC outlet boxes is also at earth ground.
If the retaining screw is to be used as your earth-ground, verify
that it is at ground by measuring the resistance between it and a
cold-water pipe with an ohmmeter. The reading should be zero
ohms. If a cold-water pipe is not accessible, connect a 60-l00 watts
trouble light (not a neon lamp) between the hot side of the re-
ceptacle and the retaining screw. Try both slots, if necessary, to
locate the hot side of the line, the lamp should light at normal
brilliance if the screw is at ground potential. (See Fig. B)
1.5 k Ω 0.15 µF AC
Voltmeter
(0.75 V)
To Exposed Metal
Parts on Set
Earth Ground
Fig. A. Using an AC voltmeter to checkAC leakage.

—5 —
KV-32S65/35S65
SECTION 1 GENERAL
4
Cable or antenna only 5
Cable and antenna (KV-32S65, 32V65, 35S65, 35V65 only) 5
Cable box 6
Cable box and cable to view scrambled channels (KV-32S65, 32V65, 35S65,
35V65 only) 6
V CR and cable or antenna 7
VCR and cable box 7
Direct Broadcast Satellite Receiver (DBS) 8
VCR and Direct Broadcast Satellite Receiver (DBS) 8
Digital Versatile Disc player (DVD) 9
Audio system 9
A/V receiver 10
Two VCR's for tape editing (KV-32V40, 32V65, 35V65 only) 10
Camcorder to view tapes 11
S-Link connections (KV-32S65, 32V65, 35S65, 35V65 only) 12
Making Connections
Connecting and Installing the TV
Refer to the table below, it will direct you to the diagram suitable to the components you will be
connecting.
If you will be connecting See page
5
B• VHF only
or
• UHF only
or
• VHF/UHF
C• VHF
and
• UHF
Cable or Antenna Connections
Connecting directly to cable or an
antenna
The connection you choose will depend on the
cable found in your home. Newer homes will
be equipped with standard coaxial cable
(see A); older homes will probably have
300-ohm twin lead cable (see B); still other
homes may contain both (see C).
A• VHF only
or
• VHF/UHF
or
• Cable
Antenna connector
(Rear of TV)
VHF/UHF
300-ohm twin
lead cable (Rear of TV)
VHF/UHF
75-ohm
coaxial cable
75-ohm coaxial cable
300-ohm twin lead cable
(Rear of TV)
VHF/UHF
EAC-66 U/V mixer
(not supplied)
(No connection "TO
CONVERTER" in this case)
CATV cable
Antenna cable
TO CONVERTER
VHF/UHF
(Rear of TV)
AUX
Cable and antenna
• KV-32S65, 32V65, 35S65, 35V65 only
If your cable provider does not feature local
channels, you may find this set up convenient
for viewing both local and cable channels.
Select cable or antenna mode by pressing
ANT on the remote control. You will be able
to alternate between the two input sources.
Note
• In order to receive channels with an
antenna, you will need to turn your CABLE
to OFF (see page 26) and perform the
AUTO PROGRAM function.
6

Connecting and Installing the TV (continued)
Cable Box Connections
Some pay cable TV systems use scrambled or
encoded signals that require a cable box to
view all channels.
Cable box
1Connect the coaxial connector from your
cable to the IN on your cable box.
2Using a coaxial cable, connect OUT on
your cable box to VHF/UHF on your TV.
Cable box and cable
• KV-32S65, 32V65, 35S65, 35V65 only
For this set up, you can switch between
scrambled channels (through your cable box),
and normal (CATV) channels by pressing
ANT on your remote control.
Notes
• Your Sony remote control can be
programmed to operate your cable box.
(see page 32)
• When using PIP, you cannot view the
AUX input in the window picture.
Tip z
PressingANTswitches between theseinputs.
Cable box
Cable
OUTIN
(Rear of TV)
VHF/UHF
TO CONVERTER
Cable box
VHF/UHF
(Rear of TV)
AUX
75-ohm coaxial
cable (not supplied)
CATV cable
(unscrambled channels)
(signal)
scrambled
channels
If you will be controlling all channel selection
through your cable box, you should consider using
the CHANNEL FIX feature discussed on page 26.
If you are connecting a cable box through the AUX input and would
like to switch between the AUX and normal (CATV) input you should
consider using the CHANNEL FIX feature discussed on page 26.
The instructions mentioned here are partial abstracts from the Operating Instruction Manual. The page numbers shown reflect those of the Operating Instruction Manual.
3
Using This Manual
Precautions
Welcome!
Thank you for purchasing the Sony
Trinitron®Color TV. This manual is written
for the models listed below. Before reading,
check the model number located on the front
of this manual or on the rear of your TV.
Model KV-35S45 is used for menu and
illustration purposes. Differences in
operation are indicated in the text; for
example, “KV-35S45 only”.
This manual is divided into four major
sections. We recommend that you carefully
review the contents of each section in the
order presented to ensure that you fully
understand the operation of your new TV.
1Connecting and Installing the TV
This section guides you through your
initial set up. It shows how to connect to
your antenna or cable, and connect any
accessories or components.
2Basic Set Up
This section teaches you the basic skills
needed to operate your new TV. It shows
you how to operate special functions of
the remote control.
3Using your New TV
This section shows you how to begin
using your new TV. It shows how to use
the Easy Set Up Guide feature, and how to
use your remote control.
4Using your Menus
This section teaches you how to access
on-screen menus and adjust your TV's
settings.
Instructions in this manual are written for the
remote control. Similar controls may be found on
the TV console.
Safety
• Operate the TV only with 120 V AC .
• The plug is designed, for safety purposes,
to fit in the wall outlet only one way. If
you are unable to insert the plug fully into
the outlet, contact your dealer.
• If any liquid or solid object should fall
inside the cabinet, unplug the TV
immediately and have it checked by
qualified personnel before operating it
further.
• If you will not be using the TV for several
days, disconnect power by pulling the
plug itself. Never pull on the cord.
For details concerning safety precautions, see the
supplied leaflet “IMPORTANT SAFEGUARDS”.
Installing
• To prevent internal heat build-up, do not
block the ventilation openings.
• Do not install the TV in a hot or humid
place, or in a place subject to excessive
dust or mechanical vibration.
Model
Number
Single tuner
(VCR required for PIP)
Dual tuner
("Ready to Use" PIP)
SRS
FAVORITE CHANNEL
with Preview
KV-32S40
KV-32S45
KV-32S65
KV-32V40
KV-32V65
KV-35S40
KV-35S45
KV-35S65
KV-35V65
AUTO VOLUME
Control
SURROUND

—6 —
KV-32S65/35S65
7
AUDIO R AUDIOL VIDEO
S VIDEO
LINE
OUT
OUT
IN
OUT
IN
AUDIO OUT
(VAR/FIX)
VIDEO IN
12
VHF/UHF SVIDEO
VIDEO
L
R
AUDIO
(MONO)
L
R
Disconnectall powersources beforemakinganyconnections.
VCR must be connected and
turned on to operate PIP
(KV-32S45, 35S45 only).
VCR Connections
Connecting an antenna/cable TV
system with a VCR
1Attach the coaxial connector from your cable
or antenna to IN on your VCR.
2Using A/V connectors, connect AUDIO and
VIDEO OUT on your VCR to AUDIO and
VIDEO IN on your TV.*
3Using a coaxial connector, connect OUT on
your VCR to VHF/UHF on your TV.
* If you are connecting a monaural VCR, connect only the
single white audio output to the left input on your TV.
Connecting a VCR and TV with a
cable box
You will need a splitter (not supplied) for the
following connection.
1Connect the single (input) jack of the splitter
to your incoming cable connection. Connect
the other two (output) jacks (using coaxial
cable) to IN on your cable box and VHF/UHF
on your TV.
2Using a coaxial connector, connect OUT on
your cable box to IN on your VCR.
3Using A/V connectors, connect AUDIO and
VIDEO OUT on your VCR to AUDIO and
VIDEO IN on your TV.
Coaxial cable
(Rear of TV)
VMC-810S/820S (not supplied)
Cable VCR
3
12AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
VMC-810S/820S (not supplied)
Cable box
Splitter
(not supplied)
3AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
VCR
Cable
Coaxial cable
2
1
For optimum picture quality, use S VIDEO instead of
the yellow A/V cable. S Video does not provide sound,
your audio connectors must still be connected. (Rear of TV)
AUDIO OUT
(VAR/FIX)
VIDEO IN
12
VHF/UHF SVIDEO
VIDEO
L
R
AUDIO
(MONO)
AUDIO R AUDIO L VIDEO
S VIDEO
LINE
OUT
OUT
IN
L
R
8
AUDIO R AUDIO L VIDEO AUDIO R AUDIO L VIDEO
SATELLITE IN
VHF/UHF
S VIDEO
OUT
IN
LINE OUT
LINE IN
VHF/UHF
S VIDEO
OUT
IN
LINE OUT
AUDIO OUT
(VAR/FIX)
VIDEO IN
12
VHF/UHF SVIDEO
VIDEO
L
R
AUDIO
(MONO)
L
R
Disconnectall power sources beforemakinganyconnections.
DBS receiver
Satellite
antenna
cable
VMC-810S/820S (not supplied)
1
3
2
AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
Connecting and Installing the TV (continued)
For optimum picture quality, use S VIDEO
instead of the yellow A/V cable. S Video does
not provide sound, your audio connectors
must still be connected.
DBS Connections
Connecting a DBS (Direct
Broadcast Satellite) receiver
1Connect the cable from your satellite
antenna to your DBS receiver.
2Attach the coaxial connector from your
cable or antenna to VHF/UHF on your TV.
3Using A/V connectors, connect AUDIO
and VIDEO OUT on your DBS receiver to
AUDIO and VIDEO IN on your TV.
Connecting a DBS (Direct Broadcast
Satellite) receiver and a VCR
1Connect the cable from your satellite
antenna to your DBS receiver.
2Attach the coaxial connector from your
cable or antenna to VHF/UHF IN on your
VCR.
3Using a coaxial connector, connect
VHF/UHF OUT on your VCR to
VHF/UHF on your TV.
4Using A/V connectors, connect AUDIO
and VIDEO OUT on your DBS receiver to
AUDIO and VIDEO IN on your VCR.
5Using A/V connectors, connect AUDIO
and VIDEO OUT on your VCR to AUDIO
and VIDEO IN on your TV.
(Rear of TV)
AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
1
2
3
VMC-810S/820S (not supplied)
VMC-810S/820S (not supplied)
4
5
(Rear of TV)
DBS receiver
VCR
Pressing TV/VIDEO on the remote
control will allow you to view from
the DBS or VCR.
VHF/UHF
S VIDEO
OUT
IN
LINE OUT
SATELLITE IN
AUDIO R AUDIO L VIDEO
AUDIO OUT
(VAR/FIX)
VIDEO IN
12
VHF/UHF SVIDEO
VIDEO
L
R
AUDIO
(MONO)
L
R
Cable/Antenna
Cable/Antenna
9
Additional Connections
The following connections are for accessories
that will enhance your viewing options.
Connecting a DVD Player
1Using A/V connectors, connect LINE OUT
on your DVD to VIDEO IN on your TV.
Connecting an audio system
For enhanced sound, connect your audio
system to your TV.
1Using AUDIO connectors, connect AUDIO
OUT on your TV to one of the unused line
inputs (e.g. TV, AUX, TAPE 2) on your
stereo.
2Set your stereo to the chosen line input.
Refer to page 24 of this manual for
additional audio setup instructions.
VMC-810S/820S (not supplied)
1
(Rear of DVD player)
AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
Line
input
AUDIO-R (red)
AUDIO-L (white) RK-74A
(not supplied)
1
2
Disconnectall power sources beforemakinganyconnections.
For optimum picture quality, use S VIDEO
instead of the yellow A/V cable. S Video
does not provide sound, your audio
connectors must still be connected.
(Rear of TV)
(Rear of TV)
AUDIO OUT
(VAR/FIX)
VIDEO IN
12
VHF/UHF SVIDEO
VIDEO
L
R
AUDIO
(MONO)
HRD
AUDIO R AUDIO L VIDEO
S VIDEO
LINE OUT
AUDIO OUT
(VAR/FIX)
VIDEO IN
12
VHF/UHF SVIDEO
VIDEO
L
R
AUDIO
(MONO)
L
R
10
HRD
L
R
AUDIO
(MONO)
S VIDEO
VIDEO
IN
VIDEO 1 VIDEO 3
TV MONITOR AUDIO
(VAR/FIX)
OUT
S-LINK
L
R
AUDIO
(MONO)
S VIDEO
VIDEO
IN
VIDEO 1 VIDEO 3
TV MONITOR AUDIO
(VAR/FIX)
OUT
S-LINK
LINE
OUT
OUT
IN LINE
IN
OUT
IN
AUDIO R AUDIO L VIDEO AUDIO R AUDIO L VIDEO
Disconnectall power sources beforemakinganyconnections.
Connecting an A/V receiver
• KV-32V65, 35V65 only
1Using A/V cables, connect TV OUT on your
TV to TV IN on your A/V receiver.
2Using a single video connector, connect
Monitor OUT on your A/V receiver to
VIDEO 1 IN on your TV.
Tip z
You may want to use CHANNEL FIX to set your TV's
input to the A/V receiver. See page 26.
Connecting two VCRs
• KV-32V40, 32V65, 35V65 only
MONITOR OUT gives you the ability to use a
second VCR to record a program being played
by the primary VCR or to perform tape
editing and dubbing.
1Connect the VCR intended for playback
using the setup instructions on page 7 of
this manual.
2Using A/V connectors, connect AUDIO
and VIDEO IN on your VCR intended for
recording to MONITOR AUDIO and
VIDEO OUT on your TV.
VCR (for playback) VCR (for recording)
VMC-810S/820S (not supplied) VMC-810S/820S (not supplied)
(Rear of KV-35V65)
VIDEO (yellow)
AUDIO-L (white)
AUDIO-R (red)
1
2
You cannot change video
inputs while editing using
MONITOR OUT.
(Rear of KV-35V65)
VMC-10HG/30HG (not supplied)
VIDEO (yellow)
VIDEO (yellow)
AUDIO-L (white)
AUDIO-R (red)
VMC-810S/820S (not supplied)
A/V inputs
A/V receiver
A/V outputs
2
1
Connecting and Installing the TV (continued)

—7 —
KV-32S65/35S65
11
VIDEO 2 INPUT
L
(MONO)
- AUDIO -RVIDEO
VIDEO 2 INPUT
VIDEO
L
(MONO)
- AUDIO
-R
S VIDEO
Connecting a camcorder
This connection is convenient for viewing a
picture directly from your camcorder.
Using A/V connectors, connect AUDIO and
VIDEO OUT on your camcorder to AUDIO
and VIDEO IN on your TV.
Connection can also be made directly to your
A/V input located on the rear of your TV.
Note
• If you are connecting a monaural camcorder,
connect only the single white audio output
to the left input on your TV.
If you have an S VIDEO equipped
camcorder, you can use an S Video
cable for optimum picture quality.
AUDIO-L (white)
AUDIO-R (red)
VIDEO (yellow)
AV output
VMC-810S/820S
(not supplied)
(Front of KV-32V40*, 32V65, 35V65 only)
Disconnectall power sources beforemakinganyconnections.
*KV-32V40doesnot have SVIDEOon the frontpanel.
12
Connect to the CONTROL
S-IN on your VCR.
LINE
OUT
AUDIO R AUDIO L VIDEO
S-LINK
L
R
AUDIO
(MONO)
S VIDEO
VIDEO
IN
VIDEO 1 VIDEO 3
TV MONITOR AUDIO
(VAR/FIX)
OUT
S-LINK
SATELLITE IN
LINE
OUT
OUTIN
AUDIO R AUDIO L VIDEO
S-LINK
CONTROL S
L
R
AUDIO
(MONO)
S VIDEO
VIDEO
IN
VIDEO 1 VIDEO 3
TV MONITOR AUDIO
(VAR/FIX)
OUT
S-LINK
Disconnectall power sources beforemakinganyconnections.
S-Link connections
• KV-32S65, 32V65, 35S65, 35V65 only
S-Link is designed to allow your Sony
components to ”communicate“.
Connecting S-Link to a VCR
S-Link will automatically power on the TV
and switch to the correct video input when a
tape is inserted in the VCR.
1Using A/V connectors, connect AUDIO
and VIDEO OUT on your VCR to AUDIO
and VIDEO IN on your TV.
2Using an S-Link connector (mono mini
plug), connect S-LINK/CONTROL S-IN on
your VCR to S-LINK on your TV.
Connecting S-Link to a DBS
S-Link will automatically power on the TV
and switch to the correct video input when
you power on the DBS.
1Using A/V connectors, connect AUDIO
and VIDEO OUT on your DBS to AUDIO
and VIDEO IN on your TV.
2Using an S-Link connector (mono mini
plug), connect S-LINK on your DBS to
S-LINK on your TV.
VCR
RK-G69HG
(not supplied)
(Rear of KV-35V65)
AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
1
2
VMC-810S/820S
(not supplied)
(Rear of KV-35V65)
RK-G69HG
(not supplied) VMC-810S/820S (not supplied)
Satellite
Antenna
Cable
DBS Receiver
21
AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
Connecting and Installing the TV (continued)
The S-Link connector must be in the
same VIDEO-IN jacks as the A/V cables
on your TV.
30
Programming the remote
You can use the supplied remote control to
operate Sony or non-Sony video equipment.
Operating Video Equipment
1Press CODE SET.
2Press VTR/DVD (FUNCTION).
3Use the 0-9 buttons to key in the
manufacturer's code number from the
following chart.
4Press ENTER.
VCR code numbers
Manufacturer Code
Sony 301, 302, 303
Admiral (M. Ward) 327
Aiwa 338, 344
Audio Dynamic 314, 337
Broksonic 319, 317
Canon 309, 308
Citizen 332
Craig 302, 332
Criterion 315
Curtis Mathis 304, 338, 309
Daewoo 341, 312, 309
DBX 314, 336, 337
Dimensia 304
Emerson 319, 320, 316, 317, 318, 341
Fisher 330, 335
Funai 338
General Electric 329, 304, 309
Go Video 322, 339, 340
Goldstar 332
Hitachi 306, 304, 305,338
Instant Replay 309, 308
JC Penney 309, 305, 304, 330, 314, 336, 337
JVC 314, 336, 337, 345, 346, 347
Kenwood 314, 336, 332, 337
LXI (Sears) 332, 305, 330, 335, 338
Magnavox 308, 309, 310
Marantz 314, 336, 337
Marta 332
Memorex 309, 335
Minolta 305, 304
Mitsubishi/MGA 323, 324, 325, 326
Multitech 325, 338, 321
NEC 314, 336, 337
Olympic 309, 308
Optimus 327
Panasonic 308, 309, 306, 307
Pentax 305, 304
Philco 308, 309
Philips 308, 309, 310
Pioneer 308
Quasar 308, 309, 306
RCA/PROSCAN 304, 305, 308, 309, 311,
312, 313, 310, 329
Realistic 309, 330, 328, 335, 324, 338
Sansui 314
Samsung 322, 313, 321
Sanyo 330, 335
Scott 312, 313, 321, 335, 323, 324, 325, 326
Sharp 327, 328
Shintom 315
Signature 2000 (M. Ward) 338, 327
SV2000 338
Sylvania 308, 309, 338, 310
Symphonic 338
Tashiro 332
Tatung 314, 336, 337
Teac 314. 336, 338, 337
Technics 309, 308
Toshiba 312, 311
Wards 327, 328, 335, 331, 332
Yamaha 314, 330, 336, 337
Zenith 331
Operating a VCR
To turn on or off
To select a channel
directly
To change
channels
To record
To play
To stop
To fast forward
To rewind the tape
To pause
To scan
To change input
mode
Buttons on the
remote control
Press VTR/DVD (POWER).
Press the 0 – 9 buttons.
Press CH +/–.
Press (and r
simultaneously.
Press (.
Press p.
Press ).
Press 0.
Press P.
To resume normal playback,
press again or press (.
Press )or 0during
playback.
To resume normal playback,
release the button.
Press TV/VTR.
31
MDP (Multi Disc Player)
code numbers
Manufacturer Code
Sony 701
Panasonic 704, 710
Pioneer 702
Operating an MDP
To turn on or off
To play
To stop
To pause
To scan
To search the chapter
forward or backward
Tip z
Ifyouwillnotbe programming aDBSorcableboxinto
theDBS/CABLEinput,you can useittoprogramother
videoequipment(e.g.DVD,MDP, or secondVCR).
(seepage30)
DVD (Digital Versatile Disc)
code numbers
Manufacturer Code
Sony 751
Panasonic 753
Pioneer 752
RCA 755
Toshiba 754
Operating a DVD
player
To turn on or off
To play
To stop
To pause
To scan
To search the
chapter forward or
backward
To select chapters
directly
MENU
To move cursor in
menu
Buttons on the remote
control
Press VTR/DVD (POWER).
Press (.
Press p.
PressP.
To resume normal playback,
press again or press (.
Press )or 0during
playback.
To resume normal playback,
press (.
Press CH +/–.
0–9 + ENTER.
Press to display DVD menu.
Use your arrow buttons
V,v, B, b.
Buttons on the remote
control
Press VTR/DVD (POWER).
Press (.
Press p.
PressP.
To resume normal playback,
press again or press (.
Press )or 0during
playback.
To resume normal playback,
press (.
Press CH +/–.
Tips z
• Insomerarecases, youmaynotbeable to operate
yournon-Sonyvideo equipmentwiththe supplied
remotecontrol.Inthis case,pleaseusethe
equipment’sownremotecontrol.
• Whenyouremove thebatteries,thecode numbermay
reverttothefactory setting.
• Thecodenumbersfor Sony VCR'sareassignedatthe
factoryasfollows:
VHS VCR 301
(preset code for the
supplied remote control)
8 mm VCR 302
Beta, ED Beta VCRs 303

—8 —
KV-32S65/35S65
32
Manufacturer
Hamlin/Regal
Jerrold/G. I.
Oak
Panasonic
Pioneer
Scientific Atlanta
Tocom
Zenith
Programming the remote
You can program the supplied remote control
to operate a cable box or DBS receiver.
1Press CODE SET.
2Press DBS/CABLE (FUNCTION).
3Use the 0-9 buttons to key in the
manufacturer's code number from the
following chart.
4Press ENTER.
For more details on operating the
cable box or DBS receiver
Refer to the operating instructions that were
supplied with the equipment.
If the remote control doesn’t work
• First, try repeating the setup procedures
using the other codes listed for your
equipment.
Tips z
• Ifmorethanone code numberislisted,tryentering
themonebyone untilyoucometothe correctcodefor
yourequipment.
• Ifyouentera newcodenumber,the codenumberyou
previouslyenteredatthat settingiserased.
• Insomerarecases, youmaynotbeable to operate
yourequipmentwith thesuppliedremotecontrol. In
thiscase,use theequipment’ssuppliedremote control.
• Wheneveryouremove thebatteriesthe codenumbers
mayreverttothe factory setting.
Cable box code numbers
Code
222, 223, 224, 225, 226
201, 202, 203, 204, 205, 206,
207, 208, 218
227, 228, 229
219, 220, 221
214, 215
209, 210, 211
216, 217
212, 213
DBS receiver code numbers
Manufacturer
Sony
General Electric
Hitachi
Hughes
Panasonic
RCA/PROSCAN
Toshiba
Code
801 (preset code for
remote control)
802
805
804
803
802, 808
806, 807
Operating a Cable Box or DBS Receiver
33
Problem What it could be What you can do
Cannot operate single tuner PIP
(KV-32S45, 35S45)
A red light keeps flashing on the
TV for more than a few seconds
TV makes a noise when turned
on
Screen is not lit and there is no
sound
Poor or no picture (screen lit),
good sound
Good picture, no sound
No color
Troubleshooting
Consult the table below; it suggests solutions to specific problems.
• VCR may not be connected to your TV properly.
• VCR may not be turned on.
• The remote control may not be programmed to
operate the VCR.
• Your TV may need service.
• This is a normal function of your TV.
• Power cord may not be plugged in.
• Batteries may not have been placed with the correct
polarity.
• TV/VIDEO setting may be incorrect.
• VIDEO menu settings may not be adjusted correctly.
• Antenna/cable connections may be faulty.
• VIDEO LABEL inputs may be set to WEB. (This label
darkens the screen for ideal WebTV viewing)
• Sound may be set to MUTING.
• Your TV may be set to SAP.
• Speaker may not be set correctly.
• Color settings may not be adjusted correctly.
•
Ensure that you have set your VCR correctly. (see page 7)
• Program your remote control to operate the VCR.
(see page 30)
• Call your local Sony service center.
• Press TV/VIDEO until you receive a channel.
• Readjust your VIDEO menu settings.(see page 22)
• Check your VIDEO LABEL settings. (see page 28)
• Press MUTE.
•
Check the MTS setting in the AUDIO menu. (see page 23)
• Check your SPEAKER settings. (see page 23)
• Adjust the COLOR settings in the VIDEO menu.
(see page 22)
34
Problem What it could be What you can do
If, after reading these operating instructions, you have additional questions related to the use of your Sony
television, please call our Direct Response Center at 1-800-222-SONY (7669). (U.S. residents only)
• Ensure that you have selected the
correct CABLE mode in the
SET UP menu. (see page 26)
• Press ANT on your remote
control to change the input mode.
(see page 16)
•
Ensure that CABLE is set to OFF
in the SET UP menu. (see page 26)
• Use AUTO PROGRAM to add
receivable channels that are not
presently in TV memory. (see
page 26)
• Ensure that CABLE is set to ON
in the SET UP menu. (see page 26)
• Use AUTO PROGRAM to add
receivable channels that are not
presently in TV memory. (see
page 26)
• Press TV (FUNCTION) and
adjust the TV's volume.
• Check your CHANNEL FIX
settings. (see page 26)
• CABLE may not be set correctly
in the SET UP menu.
• Antenna/cable connections may
not be correct.
• TV may be set to AUX mode.
• CABLE setting may not be correct
in the SET UP menu.
• CABLE setting may not be set
correctly in the SET UP menu.
• Volume may not be adjusted on
your cable box.
• CHANNEL FIX settings may not
be correct.
Only snow and noise
appear on the screen
Cannot receive upper
channels (UHF) when
using an antenna
Cannot receive any
channels when using
cable
Cannot gain enough
volume when using a
cable box
TV is fixed to one
channel

— 9 —
KV-32S65/35S65
SECTION 2
DISASSEMBLY
2-1. REAR COVER REMOVAL
11
11
1 Twelve Screws
(BVTP 4x16)
22
22
2 Two Screws
(BVTP 3x12)
2-2. CHASSIS ASSEMBLY REMOVAL
11
11
1 Claw
33
33
3 G Board
22
22
2 Chassis Assembly
(KV-32S65) (KV-35S65)
11
11
1 Ten Screws
(BVTP 4x16)
22
22
2 Three Screws
(BVTP 3x12)

— 10 —
KV-32S65/35S65
2-3. SERVICE POSITION
Do not use sharp objects which may cause damage to the sur-
face of the anode-cap.
Do not squeeze the rubber covering too hard to avoid damag-
ing the anode-cap. A material fitting called a shatter-hook ter-
minal is built into the rubber.
Do not force turn the foot of the rubber cover. This may cause
the shatter-hook terminal to protrude and damage the rubber.
HOW TO HANDLE AN ANODE-CAP
Turn up one side of the rubber cap in
the direction indicated by arrow . When one side of the rubber cap sepa-
rates from the anode button, the anode-
cap can be removed by turning the rub-
ber cap and pulling it in the direction of
arrow .
Use your thumb to pull the rubber cap
firmly in the direction indicated by
arrow .
ANODE-CAP REMOVAL
WARNING: High voltage remains in the CRT even after the power is disconnected. To avoid electrical shock, discharge CRT before
attempting to remove the anode cap. Short between anode and coated earth ground strap of CRT.
NOTE: After removing the anode, short circuit the anode of the picture tube and the anode cap to either the metal chassis, CRTshield
or carbon painted on the CRT.
REMOVAL PROCEDURES
22
22
2 G Board
11
11
1 A Board

— 11 —
KV-32S65/35S65
2-4-1. PICTURE TUBE REMOVAL (KV-32S65)
WARNING -- Before removing
anode cap:
High voltage remains in the CRT even
after the power is disconnected.
To avoid electrical shock, discharge CRT
before attempting to remove the anode
cap. Short between anode and coated
earth ground strap of CRT.
Coated earth ground strap
WARNING -- Before removing
anode cap:
High voltage remains in the CRT even
after the power is disconnected.
To avoid electrical shock, discharge CRT
before attempting to remove the anode
cap. Short between anode and coated
earth ground strap of CRT.
2-4-2. PICTURE TUBE REMOVAL (KV-35S65)
Coated earth ground strap
Tension spring(B)
Claw
Two Degaussing
coil holders
Degaussing coil
C board
Neck assy
Deflection yoke
Anode cap
Two Degaussing
coil holders
Four screw
(Tapping
screw )
Picture tube
Cushion
G board Chassis assy
Picture tube
shield assy
Anode cap
Cushion
Deflection yoke
Neck assy
C board
Four screws
(Tapping screw 7) G board
Chassis
Picture tube

— 12 —
KV-32S65/35S65
SECTION 3
SET-UP ADJUSTMENTS
The following adjustments should be made when a
complete realignment is required or a new picture
tube is installed.
These adjustments should be performed with rated
power supply voltage unless otherwise noted.
The controls and switch should be set as follows
unless otherwise noted:
PICTURE control ................. normal
BRIGHTNESS control ......... normal
3-1. BEAM LANDING
Preparation:
1. Input white pattern from pattern generator.
2. Loosen the deflection yoke mounting screw, and set
the purity control to the center as shown below:
3. Input green pattern from pattern generator.
4. Move the deflection yoke backward, and adjust with
the purity control so that green is in the center and
red and blue are even on both sides.
BR
G
Perform the adjustments in order as follows:
1. Beam Landing
2. Convergence
3. Focus
4. Screen (G2)/White Balance
Note: Test Equipment Required
1. Color Bar Pattern Generator
2. Degausser
3. DC Power Supply
4. Digital Multimeter
5. Move the deflection yoke forward, and adjust so that the
entire screen becomes green.
6. Switch over the raster signal to red and blue and confirm
the condition.
7. When the position of the deflection yoke is determined,
tighten it with the deflection yoke mounting screw.
8. When landing at the corner is not right, adjust by using
the disk magnets.
ab
cd
d
a
c
Purity control
corrects this area.
Disk magnets or
rotatable disk
magnets correct
these areas(a-d).
Deflection yoke positioning
corrects these areas.
b
•Input a white pattern signal.
•Face the picture tube in a East or West direction to reduce the influence of geomagnetism.
NOTE: Do not use the hand degausser because it magnetizes the CRT .

— 13 —
KV-32S65/35S65
3-2. CONVERGENCE
(1) Vertical and Horizontal Static Convergence
1. Adjust V. STAT magnet to converge red, green and blue
dots in the center of the screen. (Vertical movement)
B
G
RV.STAT
Magnet
Center dot
Tilt the V. STAT magnet and adjust static convergence
to open or close the V. STAT magnet.
2. When the V. STAT magnet is moved in the direction of
arrow aand b, red, green, and blue dots move as
shown below:
B
R
G
B
R
G
RG B
G
R
B
G
B
R
BG R
1
2
3
a
b
ab
b
b
aa
b
ba
b
ab
Operation of BMC (Hexapole) Magnet
The respective dot positions resulting from moving each
magnet interact, so perform adjustment while tracking.
Use the VSTAT tabs to adjust the red, green, and blue dots
so they line up at the center of the screen (move the dots in
a horizontal direction.)
RG B RGB RGB
RGB
RGB RGB
Y Separation Axis Correction Magnet Adjustment
1. Input cross-hatch pattern, adjust PICTURE to
minimum and BRIGHTNESS to normal.
2. Adjust the deflection yoke upright so it touches the
CRT.
3. Adjust so that the Y separation axis correction magnet
on the neck assembly is symmetrical from top to
bottom (open state).
Purity
V. STAT
BMC (Hexapole)
4. Return the deflection yoke to its original position.
Preparation:
• Before starting, perform FOCUS, V. LIN and V. SIZE adjustments.
• Set BRIGHTNESS control to minimum.
• Input dot pattern.

— 14 —
KV-32S65/35S65
3-4. SCREEN (G2)
1. Input dot pattern from the pattern generator.
2. Set the PICTURE and BRIGHT controls at normal.
3. Adjust S BRT, G CUT, B CUT in service mode with an
oscilloscope so that voltages on the red, green, and blue
cathodes are 170Vdc for 35" and 180Vdc for 32".
4. Observe the screen and adjust SCREEN (G2) VR
to obtain the faintly visible background of dot signal.
3-5. WHITE BALANCE ADJUSTMENTS
NO. Disp. Item Avg/32" Avg/35"
16 GDRV Green Drive 33 45
17 BDRV Blue Drive 33 45
18 GCUT Green Cut-off 3 6
19 BCUT Blue Cut-off 2 6
23 SBRT Sub Bright 14 10
1. Input an entire white signal.
2. Set to Service adjustment Mode.
3. Set DCOL to "0"
4. Set the PICTURE and BRIGHT to minimum.
5. Adjust with SBRT if necessary.
6. Select GCUT and BCUT with 1and 4.
7. Adjust with 3and 6for the best white balance.
8. Set the PICTURE and BRIGHT to maximum.
9. Select GDRV and BDRV with 1and 4.
10. Adjust with 3and 6for the best white balance.
11. Reset DCOL to "1".
12. Write into the memory by pressing then **.
( 2 ) Dynamic Convergence Adjustment
• Before starting, perform Horizontal and Vertical
Static Convergence Adjustment.
1. Slightly loosen deflection yoke screw.
2. Remove deflection yoke spacers.
3. Move the deflection yoke for best convergence as
shown below:
BGRB
G
R
B
G
R
RGB RGB
RGB
RGB BGR
RGBR
G
B
R
G
B
BGR
4. Tighten the deflection yoke screw.
5. Install the deflection yoke spacers.
(3) Screen-corner Convergence
Affix a permalloy assembly corresponding to the
misconverged areas:
ab
cd
b
a
d
c
a-d : screen-corner
misconvergence
3-3. FOCUS
Adjust FOCUS control for best picture.
160 V dc/170 V dc pedestal
NN NN
N
NN NN
N
NN NN
N
GND
170 V dc/ 180 V dc pedestal

— 15 —
+
-
dejital
multimeter
+
-
A
ammeter
3mA dc ran
ge
+
-
dc power supply
11
R530
R531 T503
FBT
TP85
1T40
T503
FBT
TP85
R531 R530
DC Power Supply
digital multimeter
ammeter
3mA DC range
A BOARD: IC351, IC501, D519, D520, D521, C531,
C532, R387, R529, R530, R531, R532,
R533, R550, T503
G BOARD: IC643, R661
Step 1 Preparation before Confirmation
Turn the POWER switch ON.
Input a white signal and set the PICTURE and BRIGHT
controls to maximum.
Confirm that the voltage at the check terminal of TP85 is
more than 18.0 V DC when the set is operating normally.
At AC input: 120.0 ±2.0 VAC
Step 2
Input a white signal and verify that I ABL is within the
specified range: 2160 + 100 µA.
At AC input: 120.0 ±2.0 VAC
+
I ABL
ABL
T504
FBT
range
-
ammeter
3.0 mA DC
A
Step 3
Record the voltage between TP85 and ground.
Step 4
Using an external DC power supply, apply voltage
between TP85 and ground.
Increase the voltage gradually and confirm that the
holdown works (raster disappears) at lower than the
voltage recorded in Step 3.
Lower than 22.05 V DC
At AC input: 120.0 ±2.0 VAC
SECTION 4
SAFETY RELATED ADJUSTMENTS
Always perform the following adjustments when replacing the
following components marked with ]on the schematic diagram:
G BOARD: IC643, R661
1) Using Variac, apply AC input voltage: 130 + 2.0 VAC
2) Input a monoscope signal.
3) Set the PICTURE control and the BRIGHT control to
initial reset value.
4) Confirm the voltage of G BOARD CN641 between
pin 1to ground is less than 135.5 + 1.0 V DC.
5) If step 4 is not satisfied, replace the R661and repeat the
above steps.
B+ VOLTAGE CONFIRMATION AND ADJUSTMENT
R530, R531 CONFIRMATION METHOD (HOLD-DOWN CONFIRMATION) AND READJUSTMENTS
ABOARD - CONDUCTOR SIDE
Step 5
Confirm that a voltage of more than 18.0 V DC appears
between TP85 and ground.
At AC input: 120.0 ±2.0 VAC
Always perform the following adjustments when replacing the following
components marked with a ]mark on the schematic diagram:
KV-32S65/35S65

— 16 —
**WARNING: Do NOT turn off the power or AC immediately after pressing then . Wait at least 10 seconds.
KV-32S65/35S65
ELECTRICAL ADJUSTMENT BY REMOTE COMMANDER
NOTE : Test Equipment Required:
1. Pattern Generator
2. Frequency Counter
3. Digital Multimeter
4. Audio OSC
(1) Method of Setting the Service
Adjustment Mode
SERVICE MODE PROCEDURE
1. Standby mode. (Power off)
2. on the
Remote Commander.
(Press each button within a second.)
SERVICE ADJUSTMENT MODE IN
3. The CRT displays the item being adjusted.
4. Press or on the Remote Commander to select the item.
5. Press or on the Remote Commander to change the
data.
6. Press then to write into memory**.
SERVICE ADJUSTMENT MODE MEMORY
Green
7. Press then on the Remote Commander to
initialize.
SECTION 5
CIRCUIT ADJUSTMENTS
Disp.
(Item) Item
data
SERVICE AFC 0
Use Remote Commander (RM-Y167) to perform the following circuit adjustments:
Red
SERVICE RESET
RM-Y167
Carry out step 7 when adjusting
IDs 0 to 4 and when replacing
and adjusting IC002.
SERVICE WRITE
8. Turn set off and on to exit. * CAUTION: Wait at least
10 seconds before turning off set.
(3) Adjust Buttons and Indicator
(2) Memory Write Confirmation Method
1. After adjustment, pull out the plug from the AC outlet,
then replace the plug in the AC outlet again.
2. Turn the power switch ON and set to Service Mode.
3. Call the adjusted items again to confirm they were adjusted.

— 17 —
**WARNING: Do NOT turn off the power orAC immediately after pressing then . Wait at least 10 seconds.
KV-32S65/35S65
(4) Service Data
No. Register
Name Description Data Adj/Fix Initial Average Data Comments
Range Data 32" 35"
VP CXA2095S
1
VPOS V-Position 0-63 Adj 20 23 33 0:Down, 63:Up
2
VSIZ V-Size 0-63 Adj 20 27 52 0:Min, 63:Max
3
VCOM V-Compensation 0-3 Fix 1 1 0:Min, 3:Max
4
VLIN V-Linearity 0-15 Adj 79 0:Min, 15:Max
5
VSCO S-Correction 0-15 Adj 76 9 0:Min, 15:Max
6
HPOS H-Position 0-15 Adj 711 10 0:Right, 15:Left
7
HSIZ H-Size 0-63 Adj 20 23 39 0:Min, 63:Max
8
PAMP Pin Compensation 0-63 Adj 31 27 19 0:Min, 63:Max
9
UPIN Upper Corner Pin 0-15 Adj 74 7 0:Min, 15:Max
10
LPIN Lower Corner Pin 0-15 Adj 76 10 0:Min, 15:Max
11
PPHA Pin Phase 0-15 Adj 74 5 0:Min(small picture), 15:Max
12
AFC AFC 0-3 Fix 2 2 0:Freerun, 1:Min, 3:Max
13
VBOW AFC Bow 0-15 Adj 76 5 0:Right, 15:Left
14
VANG AFC Angle 0-15 Adj 76 4 0:Right, 15:Left
15
REF Reference Line 0-3 Fix 2 2 0:22H(Rch), 3:16H(Rch)
16
GDRV Green Drive 0-63 Adj 31 22 35 0:Min, 63:Max
17
BDRV Blue Drive 0-63 Adj 31 30 26 0:Min, 63:Max
18
GCUT Green Cutoff 0-15 Adj 75 8 0:Min, 15:Max
19
BCUT Blue Cutoff 0-15 Adj 77 6 0:Min, 15:Max
20
SCON Sub Contrast 0-15 Adj 710 8 0:Min, 15:Max
21
SHUE Sub Hue (RF only) 0-15 Adj 77 (flat-1) 8 (flat-1) 0:+10deg, 15:-10deg
22
1SHU Sub Hue (composite & S-video) 0-15 Adj 77 7 0:+10deg, 15:-10deg
23
SCOL Sub Color (RF only) 0-15 Adj 711 (flat+2) 9 (flat+2) 0:Min, 15:Max
24
1SCO Sub Color (composite & S-video) 0-15 Adj 714 13 0:Min, 15:Max
25
SBRT Sub Brightness 0-63 Adj 31 26 0:Min, 63:Max
26
SSHP Sub Sharpness (RF & Composite video) 0-15 Fix by model 7 8 8 0:Min, 15:Max
27
1SSP Sub Sharpness (S-video only) 0-15 Fix by model 7 10 10 0:Min, 15:Max
28
GMMA Gamma Correction 0-3 Fix by model 1 0 0 0:Off, 1:Min, 3:Max
29 CDM2 Countdown Mode 2 0-1 Fix 0 00: Normal 1: High Speed
Countdown Res
p
onse
30
EYSW External Y Switch 0-1 Fix 0 0 0: Normal 1: EYin disabled
31
DPIX Dynamic Picture 0,1 Fix 1 1 0:Off, 1:On
32
Y-DC DC Transmission Ratio 0,1 Fix 1 1 0:100%, 1:82%
33 ABLM ABL Mode 0,1 Fix 1 10:PictureABL,
1:Picture/Bri
g
htnessABL
34
AXIS Color Demodulation Axis 0,1 Fix 1 1 0:Japan, 1:US
35
NOTC Chroma Trap Filter 0,1 Fix 0 0 0:Off, 1:On
36
CROM Chroma Trap Adjust 0-15 Fix 7 7 0:+300kHz, 1:-300kHz
37
TOT TOT Filter (RF only) 0,1 Fix 1 1 0:Off, 1:On
38
1TOT TOT Filter (Composite & S-video) 0,1 Fix 1 0 0:Off, 1:On
39
PREL Pre/Overshoot Ratio (RF & Composite) 0-3 Fix by model 3 1 0: 2:1, 3: 5:1
40
1PRE Pre/Overshoot Ratio (S-video only) 0-3 Fix by model 3 3 0: 2:1, 3: 5:1
41
SHPF Sharpness fo (RF & Composite) 0-3 Fix by model 2 1 0:2.5MHz, 3:4.0MHz
42
1SPF Sharpness fo (S-video only) 0-3 Fix by model 2 3 0:2.5MHz, 3:4.0MHz
43
RON Red Off 0,1 Fix 1 1 0:Off, 1:On
44
GON Green Off 0,1 Fix 1 1 0:Off, 1:On
45
BON Blue Off 0,1 Fix 1 1 0:Off, 1:On
46
DCOL Dynamic Color 0,1 Fix 0
1 (adjusts @ 0, but shipped as 1)
0:Off, 1:On
47
CDMD V Countdown Mode 0,1 Fix 0 0 0:Auto, 1:Fix
48
HBSW H Blanking Switch 0,1 Fix 0 0 0:Off, 1:On
49
LBLK Left Blanking 0-15 Fix 0 7 0:Min, 15:Max
50 RBLK Right Blanking 0-15 Fix 0 70:Min, 15:Max
AP CXA2021
51 SVOL Sub Volume 0-15 Fix 0 60:-0 Volume steps, 15:-15
Volume ste
p
s
52
SBAL Sub Balance 0-15 Adj 77 0: +Right, 15:+Left
53
SBAS Sub Bass 0-15 Fix by model 7 8 8 0:-7 Steps, 15: +8 steps
54 STRE Sub Treble 0-15 Fix by model 7 10 10 0:-7 Steps, 15: +8 steps
MM1311/1313
55
AUSW Audio Att Sw 0,1 Fix 1 10:-6dB, 1:0dB (Only for VIDEO
input)

— 18 —
**WARNING: Do NOT turn off the power or AC immediately after pressing then . Wait at least 10 seconds.
KV-32S65/35S65
Service Data (cont.)
No. Register
Name Description Data Adj/Fix Initial Average Data Comments
Range Data 32" 35"
PI SDA9288
56
PYSD Select Delay 0-15 Fix by P-bd 3 3 0:Right, 15:Left
57
PIPH PIP H-position 0-127 Fix 78 78 0:Right, 127:Left
58
PIPV PIP V-position 0-63 Fix 18 18 0:Up, 63:Down
59
PYDL PIP Y-delay 0-7 Fix 0 0 0:Right, 7:Left
60
PHDL H-pulse delay 0-15 Fix by P-bd 3 0 0:Right, 15:Left
61 PMVD Main V-pulse delay 0-31 Fix 16 16 7-21: Available (1-6/22-31 Not
Avail
)
62 PIVD Inset V-pulse delay 0-31 Fix 22 22 16-28 Available (1-15/29-31 Not
Avail
)
63
PCON Inset Contrast 0-15 Fix 7 7 0:Min, 15:Max
64
FRMY Frame Y 0-15 Fix 7 7 0:Dark, 15:Bright
65 CHRI Input Polarity 0,1 Fix by P-bd 1 10:+(B-Y)+(R-Y), 1:-(B-Y)-(R-Y)
66 CHRO Output Polarity 0,1 Fix 1 10:+(B-Y)+(R-Y), 1:-(B-Y)-(R-Y)
67
IPER Inset Pedestal R-Y 0-15 Fix 0 0 0:Center, 7:Max, 8:Min
68
IPEB Inset Pedestal B-Y 0-15 Fix 0 0 0:Center, 7:Max, 8:Min
69 PCPS CLPS Bit Control 0,1 Fix 0 00:Depend on HSIDEL, 1:Not
de
p
end
70
PCPF CLPFIX Bit Control 0,1 Fix 0 0 0: 3Clamp line, 1: 2Clamp line
71
PSEL SELDOWN Bit Control 0,1 Fix by P-bd 1 1 0:Open out, 1:TTL out
72
PPLL PLL Filter Bits 0-3 Fix 0 0 Fixed value only
73 PVNR VSPISQ VSP NR 0-1 Fix 0 1SDA9288 IC bypass use 1
IC CXA2019
74
ISCO CDec Sub Contrast 0-15 Fix 7 15 PiP sub contrast
75
ISHP CDec Sharpness 0-15 Fix 7 8 PiP sharpness
76
ISCL CDec Sub Color 0-15 Fix 7 9 PiP sub color
77
ISHU CDec Sub Hue 0-15 Fix 7 6 PiP sub hue
78
ITOT CDec TOT on 0,1 Fix 0 1 PiP TOT 0:Off, 1:On
79
IAFC CDec AFC 0-3 Fix 2 2 0:Max, 2:Min, 3:Freerun
80
ICD2 CDec Countdown Mode2 0,1 Fix 0 0 0:Standard, 1:Fast
81
IYDR CDec Y drive 0-31 Fix 1 5 7 PiP Y-drive gain
82
IVPE CDec V pedestal 0-15 Fix 7 6 PiP V-ped DC
83
IUPE CDec U pedestal 0-15 Fix 7 6 PiP U-ped DC
84
IRVP CDec RV pedestal 0-15 Fix 7 6 PiP V-ped DC (re-input)
85
IRUP CDec RU pedestal 0-15 Fix 7 6 PiP U-ped DC (re-input)
86
IDCT CDec DC transfer 0-7 Fix 2 0 PiP DC transfer 0:Max, 7:Min
87
IRYD CDec RY drive 0-31 Fix 1 5 20 PiP RY Drive (re-input)
88
IABO CDec ABL off 0,1 Fix 1 1 PiP ABL (RY-OUT) 0:On, 1:Off
89
IPRE CDec Pre/Over shoot 0-3 Fix 3 3 PiP Pre/over shoot 0: 1:1, 1: 4:1
90 IRUD CDec RU Drive 0-31 Fix 15 20 PiP RU-gain out 0:-6dB,
31:+3.3bD
91
IABL CDec ABL 0,1 Fix 1 1 PiP ABL gain 0:Std, 1:Min
92
IABC CDec ABL Cent 0-3 Fix 1 1 PiP ABL Center 0:Min, 1:Max
93
IRVD CDec RV drive 0-31 Fix 15 17 PiP RY Drive (re-input)
94 IDLY CDec Delay 0-3 Fix 0 0PiP Y-delay 0:0ns, 1:60ns,
2:120ns, 3:180ns
95 ISCR CDec SCP BGR 0-3 Fix 0 0PiP SCP riseup phase 0:+0.4us,
1:cent, 2:-0.8us
96
ISCF CDec SCP BGF 0-3 Fix 0 0PiP SCP falldown phase
0:+0.4us, 1:cent, 2:-0.8us
CC CXP8584a-011s
97 CRIL CC CRI count low 0-15 Fix 2 27 Clock Run-In Lower Limit (field
1
)
98
CFLD CC Caption Fixed Field Count Fix 5 5 Fixed value only
99
CCDI CC CCD int 0-7 Fix 3 3 Fixed value only
100
CRIP CC CRI & polarity 0-7 Fix 4 4 Fixed value only
101
CRIT CC CRI time constant 0-3 Fix 1 1 Fixed value only
102
CSB1 CC Sync Slice Bias 1 0-3 Fix 3 3 Fixed value only
103
CSB2 CC Synce Slice Bias 2 0-7 Fix 4 4 Fixed value only
104
CREP CC CRI signal end position 0-255 Fix 142 142 Fixed value only
105
CDSD CC Data start delay 0-31 Fix 8 8 Fixed value only
106
CCDS CC Caption data threshold 0-31 Fix 9 9 Fixed value only
107
CHMK CC P8_HMASK 0-63 Fix 4 2 42 Hmask
108
CHSY CC P8_HSYC 0-255 Fix 1 3 6 136 Hsyc
109
DISP TV OSD H Position 0-63 Adj 123 0:Off, 1:Left, 63: Right
110 RTCO Rotation Coil 0-63 Fix 32 32 Fixed value only

— 19 —
**WARNING: Do NOT turn off the power orAC immediately after pressing then . Wait at least 10 seconds.
KV-32S65/35S65
(5) Feature ID Map
Service Data (cont.)
SERVICE IDO 25
Note: Items 1-118 show adjustment order
KV- DESTINATION ID-0 ID-1 ID-2 ID-3 ID-4 ID-5 ID-6 ID-7
132S65 (US/CND) 89 21 31 10 27 133 6 0
235S65 (US/CND) 89 21 31 10 155 133 6 0
No. Register
Name Description Data Adj/Fix Initial Average Data Comments
Range Data 32" 35"
ID MAP
111
ID-0 ID-0 (Language/Color Systems) 0-255 Fix by model 89 See ID map
112
ID-1 ID-1 (Input/Output Conifguration) 0-255 Fix by model 55 See ID map
113
ID-2 ID-2 (Audio) 0-255 Fix by model 175 See ID map
114
ID-3 ID-3 (OSD/Timer/V-chip/Ch Fix) 0-255 Fix by model 0
refer to
See ID map
115
ID-4 ID-4 (CC/Spot Killer/etc) 0-255 Fix by model 155
NVM ID Chart
See ID map
116
ID-5 ID-5 (V-series Features/etc) 0-255 Fix by model 141 See ID map
117
ID-6 ID-6 (PiP/Ant Sw related) 0-255 Fix by model 6 See ID map
118 ID-7 ID-7 (Special Models/etc) 0-255 Fix by model 0 See ID map

— 20 —
**WARNING: Do NOT turn off the power or AC immediately after pressing then . Wait at least 10 seconds.
KV-32S65/35S65
10. Return the following back to normal after adjustment.
PICTURE . . . . . . . . . . . MAX
COLOR . . . . . . . . . . . CENTER
BRIGHT . . . . . . . . . . . CENTER
R ON . . . . . . . . . . . ON (1)
G ON . . . . . . . . . . . ON (1)
B ON . . . . . . . . . . . ON (1)
DISPLAY POSITION ADJUSTMENT (DISP)
1. Input a color-bar signal.
2. Set to Service adjustment Mode.
3. Select DISP with and .
4. Adjust with and for adjustment of characters to center .
5. Write the memory by pressing then **.
SUB HUE, SUB COLOR ADJUSTMENT (SHUE, SCOL)
1. Input a color-bar signal.
2. Set to Service adjustment Mode.
3. Connect oscilloscope probe to C Board, CN1761 Pin3
(BLUE OUT).
4. Select SHUE and SCOL with and .
5. Adjust with and for the V1 = V4 ±0.1Vp-p (SCOL)
and V2 = V3 ±0.1Vp-p (SHUE).
V1 V2 V3 V4
6. Change data according to the following table;
SCOL SHUE
32" +2 steps -1 steps
35" +2 steps -1 steps
7. Write into the memory by pressing then **.
SERVICE AFC 0
SUB BRIGHT ADJUSTMENT (SBRT)
1. Set to Service adjustment Mode.
2. Input a gray scale pattern signal.
3. Set the PICTURE to minimum, and BRIGHT to normal.
4. Select SBRT with and .
5. Adjust SUB BRIGHT level with and so that the stripe
second from the right is faintly visible.
6. Write into the memory by pressing then
**.
white
black
second from the right
SUB CONTRAST ADJUSTMENT (SCON)
1. Input a color-bar signal.
2. Set to Service adjustment Mode.
3. Select the item DCOL to "0" level.
4. Set the conditions as follows.
PICTURE . . . . . . . . . . . MAX
COLOR . . . . . . . . . . . MIN
BRIGHT . . . . . . . . . . . CENTER
R ON . . . . . . . . . . . ON (1)
G ON . . . . . . . . . . . OFF (0)
B ON . . . . . . . . . . . OFF (0)
5. Connect an oscilloscope probe to C Board, CN1761 pin 1
(RED OUT).
6. Select SCON with and .
7. Adjust with and for: 2.10 ±0.01 Vp-p.
8. Reset the item DCOL to "1" level.
9. Write the memory by pressing then ** .
1: ON
0: OFF
SERVICE RON 1
2.10 ±0.1 Vp-p
White
n
n
Black
