TRINITRON®COLOR TELEVISION
SERVICE MANUAL BA-6 CHASSIS
MODEL NAME REMOTE COMMANDER DESTINATION CHASSIS NO.
9-965-982-01
KV-21FA315 RM-Y195 LATIN NORTH SCC-S73N-A
KV-21FA315 RM-Y195 LATIN SOUTH SCC-S73P-A
KV-21FA515 RM-Y195 LATIN NORTH SCC-S73Q-A
KV-21FA515 RM-Y195 LATIN SOUTH SCC-S73R-A
KV-29FA315 RM-Y195 LATIN NORTH SCC-S73J-A
KV-29FA315 RM-Y195 LATIN SOUTH SCC-S73K-A
KV-29FA515 RM-Y195 LATIN NORTH SCC-S73L-A
KV-29FA515 RM-Y195 LATIN SOUTH SCC-S73M-A
HISTORY INFORMATION FOR THE FOLLOWING MANUAL:
ORIGINAL MANUAL ISSUE DATE: 5/2005
REVISION DATE SUBJECT
5/2005 No revisions or updates are applicable at this time.

TRINITRON®COLOR TELEVISION
SERVICE MANUAL BA-6 CHASSIS
MODEL NAME REMOTE COMMANDER DESTINATION CHASSIS NO.
9-965-982-01
KV-21FA315 RM-Y195 LATIN NORTH SCC-S73N-A
KV-21FA315 RM-Y195 LATIN SOUTH SCC-S73P-A
KV-21FA515 RM-Y195 LATIN NORTH SCC-S73Q-A
KV-21FA515 RM-Y195 LATIN SOUTH SCC-S73R-A
KV-29FA315 RM-Y195 LATIN NORTH SCC-S73J-A
KV-29FA315 RM-Y195 LATIN SOUTH SCC-S73K-A
KV-29FA515 RM-Y195 LATIN NORTH SCC-S73L-A
KV-29FA515 RM-Y195 LATIN SOUTH SCC-S73M-A
Self Diagnosis
Supported model
KV-29FA515 RM-Y195

KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515/29FA315/29FA515
3
TABLE OF CONTENTS
SECTION TITLE PAGE SECTION TITLE PAGE
Specifications ................................................................................. 4
Warnings and Cautions .................................................................. 6
Safety Check-Out ........................................................................... 7
Self-Diagnostic Function................................................................. 8
SECTION 1: DISASSEMBLY............................................................... 10
1-1. Rear Cover Removal............................................................ 10
1-2. Chassis Assembly Removal................................................. 10
1-3. Service Position ....................................................................11
1-4. Picture Tube Removal.......................................................... 12
Anode Cap Removal Procedure .......................................... 12
Cable Wire Dressing ............................................................ 13
KV-21FA315/21FA515 Models Only................................ 13
KV-29FA315/29FA515 Models Only................................ 22
SECTION 2: SET-UP ADJUSTMENTS................................................ 32
2-1. Beam Landing ...................................................................... 32
2-2. Convergence........................................................................ 33
2-3. Focus ................................................................................... 34
2-4. Screen (G2).......................................................................... 35
SECTION 3: SAFETY RELATED ADJUSTMENTS............................. 36
3-1.
X R530, R531 Confirmation Method (HV Hold-Down
Confirmation) and Readjustments........................................ 36
3-2. B+ Voltage Confirmation and Adjustment ............................ 36
SECTION 4: CIRCUIT ADJUSTMENTS.............................................. 37
4-1. Remote Adjustment Buttons and Indicators......................... 37
4-2. Accessing the Service Adjustment Mode............................. 37
4-3. Confirming Service Adjustment Changes............................. 38
4-4. Service Data Lists ................................................................ 39
4-5. ID Map Table ........................................................................ 47
4-6. White Balance Adjustments ................................................. 48
4-7. A Board Adjustments............................................................ 48
SECTION 5: DIAGRAMS..................................................................... 51
5-1. Circuit Boards Location ........................................................ 51
5-2. Printed Wiring Board and
Schematic Diagram Information........................................... 51
5-3. Block Diagrams and Schematics ......................................... 52
Signal Flow Block Diagram .................................................. 52
Audio Block Diagram............................................................ 53
A Board Schematic Diagram (1 of 2).................................... 54
A Board Schematic Diagram (2 of 2).................................... 55
K Board Schematic Diagram................................................ 57
CV Board Schematic Diagram
(KV-21FA315/21FA515 Only) .................................. 58
C Board Schematic Diagram
(KV-29FA315/29FA515 Only) .................................. 59
V Board Schematic Diagram
(KV-29FA315/29FA515 Only) .................................. 60
MT Board Schematic Diagram ............................................. 61
HC Board Schematic Diagram ............................................. 63
5-4. Semiconductors ................................................................... 64
SECTION 6: EXPLODED VIEWS ........................................................ 65
6-1. Chassis ................................................................................ 65
6-2. Picture Tube ......................................................................... 66
SECTION 7: ELECTRICAL PARTS LIST........................................... 67

KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515/29FA315/29FA515
4
SPECIFICATIONS
1) 1 Vp-p 75 ohms unbalanced, sync negative
2) Y: 1 Vp-p 75 ohms unbalanced, sync negative
C: 0.286 Vp-p (Burst signal), 75 ohms
3) Y: 1.0 Vp-p, 75 ohms, sync negative; PB: 0.7 Vp-p, 75 ohms;
PR Vp-p, 75 ohms.
4) 500 m Vrms (100% modulation), Impedance: 47 kilohms
5) This specification is the maximum wattage.
Design and specifications are subject to change without notice.
KV-21FA315 KV-21FA515
Power Requirements 120V, 60Hz 120V, 60Hz
220V, 50/60Hz 220V, 50/60Hz
Number of Inputs/Outputs
Video 1) 33
S Video 2) 11
Y,PB, PR
3) 11
Audio 4) 44
RF 5)
External for Center/Subwoofe
r
11
Audio Panel 11
Front Panel Audio 11
Right & Left Satelite Speakers 1
S
p
eaker Out
p
ut
(
W
)
5W x 2 5W x 2
Subwoofe
r
15W 15W
Cente
r
5W 5W
Satelite S
p
eakers 5W x 2
Power Consumption (W)
In Use (Max) 155W 180W
150W 175W
In Standby (Max) 5) 1W 1W
Dimensions with Subwoofer (W x H x D)
mm 648 x 568.5 x 496.4 mm 648 x 568.5 x 496.4 mm
in 25 1/2 x 22 1/2 x 19 1/2 in 25 1/2 x 22 1/2 x 19 1/2 in
Dimensions of Satelite Speakers (W x H x D)
mm 112 x 478.4 x 87 mm
in 43/8 x 18 3/4 x 3 1/2 in
Mass
kg 28.2 kg 28.2 kg
lbs 62 lbs 1 oz 62 lbs 1 oz
Mass of Satelite Speakers
kg .6 kg
lbs 1 lbs 5 oz
(Chile, Perú, Bloivia)
(Chile, Perú, Bloivia)
Manufactured under license from Dolby
Manufactured under license from SRS Labs Inc.,
TruSurround, SRS and the ( )® symbol are
trademarks of SRS Labs, Inc.
Laboratories Licensing Corporation. Dolby, Pro Logic
and the double-D symbol are trademarks of
Dolby Laboratories.
As an ENERGY STAR® Partner, Sony
Corporation has determined that this
product meets the ENERGY STAR®
guidelines for energy efficiency. ENERGY
STAR® is a U.S. registered mark.
Sony, FD Trinitron, WEGA, ClearEdge VM, Intelligent
Picture and Dynamic Bass Response System are trademarks
of Sony.
Manufactured under license from Dolby Laboratories.
"Dolby", "Pro Logic" and the double-D symbol
are trademarks of Dolby Laboratories.

KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515/29FA315/29FA515
5
Television system
American TV standard, NTSC
Channel coverage
VHF: 2-13/ UHF: 14-69/ CATV: 1-125
Antenna
75-ohm external antenna terminal for VHF/UHF
Picture tube
FD Trinitron
®
tube
Visible screen size
20-inch picture measured diagonally (KV-21FA315/21FA515 Only)
27-inch picture measured diagonally (KV-29FA315/29FA515 Only)
KV-29FA315 KV-29FA515
Power Requirements 120V, 60Hz 120V-220V, 50/60Hz
220V, 50/60Hz 220V, 50/60Hz
Number of Inputs/Outputs
Video 1) 33
S Video 2) 11
Y,PB, PR
3) 11
Audio 4) 44
RF 5) 11
External for Center/Subwoofe
r
11
Audio Panel 11
Front Panel Audio
Right & Left Satelite Speakers 1
S
p
eaker Out
p
ut
(
W
)
7W x 2 7W x 2
Subwoofe
r
20W 20W
Cente
r
7W 7W
Satelite S
p
eakers 7W x 2
Power Consumption (W)
In Use (Max) 220W 240W
215W 235W
In Standby (Max) 5) 1W 1W
Dimensions with Subwoofer (W x H x D)
mm 804 x 697 x 509 mm 804 x 697 x 509 mm
in 31 5/8 x 27 1/2 x 20 in 31 5/8 x 27 1/2 x 20 in
Dimensions of Satelite Speakers (W x H x D)
mm 112 x 605 x 87 mm
in 43/8 x 23 3/4 x 3 1/2 in
Mass
kg 49.8 kg 49.8 kg
lbs 109 lbs 10 oz 109 lbs 10 oz
Mass of Satelite Speakers
kg .8 kg
lbs 1 lbs 12 oz
(Chile, Perú, Bloivia)
(Chile, Perú, Bloivia)
1) 1 Vp-p 75 ohms unbalanced, sync negative
2) Y: 1 Vp-p 75 ohms unbalanced, sync negative
C: 0.286 Vp-p (Burst signal), 75 ohms
3) Y: 1.0 Vp-p, 75 ohms, sync negative; PB: 0.7 Vp-p, 75 ohms;
PR Vp-p, 75 ohms.
4) 500 m Vrms (100% modulation), Impedance: 47 kilohms
5) This specification is the maximum wattage.
Actual screen size
21-inch measured diagonally (KV-21FA315/21FA515 Only)
29-inch measured diagonally (KV-29FA315/29FA515 Only)
Supplied Accessories
Remote Commander RM-Y195
Two Size AA (R6) Batteries
Telescopic Antenna (KV-21FA315/21FA515 Only)
Optional Accessories
Connection Cables
VMC-810S/820S
VMC-720M
YC-YC-15V/30V
RK74FA

KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515/29FA315/29FA515
6
WARNINGS AND CAUTIONS
CAUTION
Short circuit the anode of the picture tube and the anode cap to the metal chassis, CRT shield, or carbon painted on the CRT, after
removing the anode.
WARNING!!
An isolation transformer should be used during any service to avoid possible shock hazard, because of live chassis. The chassis of
this receiver is directly connected to the AC power line.
!SAFETY-RELATED COMPONENT WARNING!!
Components identified by shading and ! mark on the schematic diagrams, exploded views, and in the parts list are critical for safe
operation. Replace these components with Sony parts whose part numbers appear as shown in this manual or in supplements
published by Sony. Circuit adjustments that are critical for safe operation are identified in this manual. Follow these procedures
whenever critical components are replaced or improper operation is suspected.

KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515/29FA315/29FA515
7
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer:
1. Check the area of your repair for unsoldered or poorly soldered
connections. Check the entire board surface for solder splashes and
bridges.
2. Check the interboard wiring to ensure that no wires are “pinched” or
touching high-wattage resistors.
3. Check that all control knobs, shields, covers, ground straps, and
mounting hardware have been replaced. Be absolutely certain that
you have replaced all the insulators.
4. Look for unauthorized replacement parts, particularly transistors,
that were installed during a previous repair. Point them out to the
customer and recommend their replacement.
5. Look for parts which, though functioning, show obvious signs of
deterioration. Point them out to the customer and recommend their
replacement.
6. Check the line cords for cracks and abrasion. Recommend the
replacement of any such line cord to the customer.
7. Check the B+ and HV to see if they are specified values. Make sure
your instruments are accurate; be suspicious of your HV meter if sets
always have low HV.
8. Check the antenna terminals, metal trim, “metallized” knobs, screws,
and all other exposed metal parts for AC leakage. Check leakage as
described below.
Leakage Test
The AC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microamperes).
Leakage current can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’ instructions to use these
instructions.
2. A battery-operated AC milliampmeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a VOM
or battery-operated AC voltmeter. The “limit” indication is 0.75
V, so analog meters must have an accurate low voltage scale.
The Simpson’s 250 and Sanwa SH-63TRD are examples of
passive VOMs that are suitable. Nearly all battery-operated digital
multimeters that have a 2 VAC range are suitable (see Figure A).
How to Find a Good Earth Ground
A cold-water pipe is a guaranteed earth ground; the cover-plate
retaining screw on most AC outlet boxes is also at earth ground. If the
retaining screw is to be used as your earth ground, verify that it is at
ground by measuring the resistance between it and a cold-water pipe
with an ohmmeter. The reading should be zero ohms.
If a cold-water pipe is not accessible, connect a 60- to 100-watt
trouble- light (not a neon lamp) between the hot side of the receptacle
and the retaining screw. Try both slots, if necessary, to locate the hot
side on the line; the lamp should light at normal brilliance if the screw
is at ground potential (see Figure B).
To Exposed Metal
Parts on Set
0.15 F1.5 KΩAC
Voltmeter
(0.75 V)
Earth Ground
Trouble Light
AC Outlet Box Ohmmeter
Cold-water Pipe
Figure A. Using an AC voltmeter to check AC leakage. Figure B. Checking for earth ground.

KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515/29FA315/29FA515
8
Detected Symptoms
SELF-DIAGNOSTIC FUNCTION
*If a +B overcurrent is detected, stoppage of the vertical deflection is detected simultaneously. The symptom that is diagnosed first by the
mircrocontroller is displayed on the screen.
**Refer to Screen (G2) Adjustments in Section 2-4. of this manual.
Display of Standby/Timer LED Flash Count
2 times
4 times
5 times
LED ON 0.3 sec.
LED OFF 0.3 sec. LED OFF
3 sec.
Standby/Timer LED
Diagnostic Item Flash Count*
+B Overcurrent 2 times
I-Prot 4 times
IK (AKB) 5 times
*One flash count is not used for self-diagnostic.
Stopping the Standby/Timer LED Flash
Turn off the power switch on the TV main unit or unplug the power cord from the outlet to stop the STANDBY/TIMER LAMP from flashing.
Self Diagnosis
Supported model
The units in this manual contain a self-diagnostic function. If an error occurs, the STANDBY/TIMER LED will automatically begin to flash. The number
of times the LED flashes translates to a probable source of the problem. A definition of the STANDBY/TIMER LED flash indicators is listed in the
instruction manual for the user’s knowledge and reference. If an error symptom cannot be reproduced, the Remote Commander can be used to review
the failure occurrence data stored in memory to reveal past problems and how often these problems occur.
Diagnostic Test Indicators
When an error occurs, the STANDBY/TIMER LED will flash a set number of times to indicate the possible cause of the problem. If there is more than
one error, the LED will identify the first of the problem areas.
Results for all of the following diagnostic items are displayed on screen. No error has occurred if the screen displays a “0”.
Power does not turn on
+B overcurrent (OCP)*
I-Prot
IK (AKB)
Does not light
2 times
4 times
5 times
2:0 or 2:1
4:0 or 4:1
5:0 or 5:1
• Power cord is not plugged in.
• Fuse is burned out (F601). (A Board)
• H.OUT (Q502) is shorted. (A Board)
• IC702 is shorted. (CV Board 21”
models, C Board 29” models)
• +13V is not supplied. (A Board)
• IC561 is faulty. (A Board)
• IC001 is faulty. (MT Board)
• Screen (G2) is improperly adjusted.**
No. of times
STANDBY/ TIMER
lamp flashes
Diagnostic Item Descrip-
tion
Self-Diagnositc
Display/
Diagnostic Result
Probable Cause Location
• Power does not come on.
• No power is supplied to the TV.
• AC Power supply is faulty.
• Power does not come on.
• Load on power line is shorted.
• Has entered standby state after horizontal raster.
• Vertical deflection pulse is stopped.
• Power line is shorted or power supply is stopped.
• No raster is generated.
• CRT Cathode current detection reference pulse
output is small.

KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515/29FA315/29FA515
9
Self-Diagnostic Screen Display
For errors with symptoms such as “power sometimes shuts off” or “screen sometimes goes out” that cannot be confirmed, it is possible to bring up past
occurrences of failure on the screen for confirmation.
To Bring Up Screen Test
In standby mode, press buttons on the Remote Commander sequentially, in rapid succession, as shown below:
DISPLAY Channel 5 Sound Volume - POWER
Self-Diagnostic Screen Display
SELF DIAGNOSTIC
2: +B OCP 0
3: +B OVP N/A
4: VSTOP 0
Numeral “0” means that no fault was detected.
5: AKB 1 Numeral “1” means a fault was detected one time only.
101: WDT N/A
Handling of Self-Diagnostic Screen Display
Since the diagnostic results displayed on the screen are not automatically cleared, always check the self-diagnostic screen during repairs. When you
have completed the repairs, clear the result display to “0”.
Unless the result display is cleared to “0”, the self-diagnostic function will not be able to detect subsequent faults after completion of the repairs.
Clearing the Result Display
To clear the result display to “0”, press buttons on the Remote Commander sequentially when the diagnostic screen is displayed, as shown below:
Channel 8
ENTER
Quitting the Self-Diagnostic Screen
To quit the entire self-diagnostic screen, turn off the power switch on the Remote Commander or the main unit.
Self-Diagnostic Circuit
MT BOARD
IC001
Y/CHROMA JUNGLE
A BOARD
IC561
V. OUT
MT BOARD
IC001
SYSTEM
MT BOARD
IC002
MEMORY
IK-AKBIN
FROM
C BOARD
IC702 PIN 5
I-HLDWN
FROM
A BOARD
IC501
PIN 1
72 O-LED
REF I-Prot
IO-BDAT
BDA
DISPLAY
51 378
79
53 5
+B overcurrent (OCP)
Occurs when an overcurrent on the +B (135V) line is detected by pin 72 of IC001 (M Board). If the voltage of pin 72 of IC001 (M Board) is less than 1V
when V.SYNC is more than seven verticals in a period, the unit will automatically turn off.
I-Prot
Occurs when an absence of the vertical deflection pulse is detected by pin 78 of IC001 (M Board). Power supply will shut down when waveform
interval exceeds 2 seconds.
IK (AKB)
If the RGB levels* do not balance within 2 seconds after the power is turned on, this error will be detected by IC001 (M Board). TV will stay on, but
there will be no picture.
*(Refers to the RGB levels of the AKB detection Ref pulse that detects IK).
Note that this differs from entering the Service Mode (Sound Volume +).

KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515/29FA315/29FA515
10
1-1. REAR COVER REMOVAL
(KV-29FA515 PICTURED)
SECTION 1: DISASSEMBLY
1-2. CHASSIS ASSEMBLY REMOVAL
(KV-29FA515 PICTURED)
Chassis Assembly
Claw
C Board
V Board
NOTE: 21” model has
single CV Board
1
Lift to remove Subwoofer
from top of Rear Cover.
2
Remove screws from back of cover.
5 Screws
SCREW +BVTP 3X12 TYPE2 TT (B)
1 Screw +BVTP 4X16 TYPE2 IT-3
3
Remove screws from sides of cover.
3
SCREW +BVTP 4X16 TYPE2 IT-3 each side
(
KV-29FA315/29FA515 Only)
2 SCREW +BVTP 4X16 TYPE2 IT-3 each side
(KV-21FA315/21FA515 Only)
4
Remove screws from top of cover.
4
SCREW +BVTP 4X16 TYPE2 IT-3
( KV-29FA315/29FA515 Only)
2 SCREW +BVTP 4X16 TYPE2 IT-3
(KV-21FA315/21FA515 Only)
5
Remove rear cover
2
1
3
4
5

KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515/29FA315/29FA515
11
1-3. SERVICE POSITION
(KV-21FA515 SHOWN)
1
Disconnect the CN501 cable from the A Board.
2
Press on catch tab to release A Board.
3
Gently pull the K Board and the A Board forward to access the HC Board.
4
Disconnect the speaker cable from the HC Board.
5
Gently continuing pulling the A Board and HC Board forward to place in
service position.
6
Reconnect CN501 and speaker cables
A Board
CV Board
HC Board
NOTE: 29” model has
seperate C Board and
V Board

KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515/29FA315/29FA515
12
1. Discharge the anode of the CRT and remove the
anode cap.
2. Unplug all interconnecting leads from the
deflection yoke, neck assembly, degaussing coils
and CRT grounding strap.
3. Remove the C Board (KV-29FA315/29FA515) or
CV Board (KV-21FA315/21FA515) from the CRT.
4. Remove the chassis assembly.
5. Loosen the neck assembly fixing screw and
remove.
6. Loosen the deflection yoke fixing screw and
remove.
7. Place the set with the CRT face down on a
cushion and remove the degaussing coil holders.
8. Remove the degaussing coils.
9. Remove the CRT grounding strap and spring
tension devices.
10. Unscrew the four CRT fixing screws [located on
each CRT corner] and remove the CRT [Take
care not to handle the CRT by the neck].
1-4. PICTURE TUBE REMOVAL
WARNING: BEFORE REMOVING THE ANODE CAP
High voltage remains in the CRT even after the power is disconnected. To avoid electric shock,
discharge CRT before attempting to remove the anode cap. Short between anode and CRT
coated earth ground strap.
ANODE CAP REMOVAL PROCEDURE
WARNING: High voltage remains in the CRT even after the power is disconnected. To avoid electric shock, discharge CRT before attempting to
remove the anode cap. Short between anode and coated earth ground strap of CRT.
NOTE: After removing the anode cap, short circuit the anode of the picture tube and the anode cap to either the metal chassis, CRT shield, or carbon
painted on the CRT.
REMOVAL PROCEDURES
HOW TO HANDLE AN ANODE CAP
1. Do not use sharp objects which may cause damage to the surface of the anode
cap.
2. To avoid damaging the anode cap, do not squeeze the rubber covering too
hard. A material fitting called a shatter-hook terminal is built into the rubber.
3. Do not force turn the foot of the rubber cover. This may cause the shatter-hook
terminal to protrude and damage the rubber.
Turn up one side of the rubber cap in
the direction indicated by arrow a.
Use your thumb to pull the rubber
cap firmly in the direction indicated
by arrow b.
When one side of the rubber cap separates from
the anode button, the anode cap can be removed
by turning the rubber cap and pulling it in the
direction of arrow c.
a
b
Anode Button
c
10
4
1
9
8
7
6
2
3
5

13
KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515 MODELS ONLY
CABLE WIRE DRESSING
21FA515,21FA315,21FA515C,21FA315C
REV. 1.1 2/10
Dress right speaker wire using a purse lock (4-
072-499-11) as picture shown.
Dress left speaker wire through DGC band hook
and using a 5mm purse lock (3-703-981-02) as
shown in picture.

14
KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515 MODELS ONLY
21FA515,21FA315,21FA515C,21FA315C
REV. 1.1 3/10
Twist G2 wire without stressing it Dress DY's lead wire harness using a
purse lock (4-081-411-02) as picture
shown. Keep DY's lead wire away
from others harnesses

15
KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515 MODELS ONLY
21FA515,21FA315,21FA515C,21FA315C
REV. 1.1 4/10
100mm
- Dress focus lead and HV cable together using 5mm purse lock
(3-703-981-02), install purse lock 100mm from HV cable's cap. And
pass focus lead through CV board's hook
- Fix Anodo Cap to DGC using a purse lock (4-081-411-02) as
shown in picture.
Dress CRT ground wire through DY's cilp together with
rotation coil.

16
KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515 MODELS ONLY
21FA515,21FA315,21FA515C,21FA315C
REV. 1.1 5/10
Dress subwoofer harness
(K/CN2403~A/J207) pass under F-Pin,
behind video jacks & over AC cord as
picture shown.
subwoofer
cable
Fix RGB harness (MT/CN301~CV/CN705) to rotation coil
using a 9mm purse lock (3-703-982-02) as picture
shown.
RGB harness
Jacks
AC cord

17
KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515 MODELS ONLY
21FA515,21FA315,21FA515C,21FA315C
REV. 1.1 6/10
- Dress 3P (HC/CN2403~K/CN2405), 4P
(HC/CN2401~K/CN2400), 12P harness
(HC/CN2005~MT/CN303) & Right speaker using two
purse lock (4-072-499-11) to avoid primary circuit.
Dress 3P (HC/CN2403~K/CN2405), 4P
(HC/CN2401~K/CN2400), 12P harness
(HC/CN2005~MT/CN303) & Right speaker
using a purse lock (3-703-982-02) as shown
in picture.
Dress right
speaker only with
this purse lock
CAUTION POINT:
Avoid wires to
touch LFT or any
other primary
components

18
KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515 MODELS ONLY
21FA515,21FA315,21FA515C,21FA315C
REV. 1.1 7/10
- [#1] Dress 3P (A/CN412~K/CN2402), 5P (A/CN201~K/CN2600) and 8P
(A/CN411~K/CN2401) audio harnesses using a 5mm purse lock (3-703-981-02)
- [#2] Dress 3P (HC/CN2403~K/CN2405), 4P (HC/CN2401~K/CN2400), 12P harness
(HC/CN2005~MT/CN303) using a 5mm purse lock (3-703-981-02) as shown in
picture.
#2
#1
Pass 3P & 4P
(HC~K board)
behind 3P, 5P
& 8P (A~K
board)

19
KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515 MODELS ONLY
21FA515,21FA315,21FA515C,21FA315C
REV. 1.1 8/10
Dress VM (A/CN502~CV/CN901) and heater
(A/CN503~CV/CN706) harnesses together using a 5mm
purse lock (3-703-981-02) as picture shown.

20
KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515/29FA315/29FA515
KV-21FA315/21FA515 MODELS ONLY
21FA515,21FA315,21FA515C,21FA315C
ONLY FOR CHILE MODELS
REV. 1.1 9/10
Dress AC-Cord wire through DGC band lower hook
and using a purse lock (4-072-499-11) as shown in
picuture.
50mm
Ferrite
P/N:1-500-586-11
