Sony Trinitron KV-G21MW3 User manual

http://cxema.ru
MODEL COMMANDER DEST. CHASSIS NO.MODEL COMMANDER DEST. CHASSIS NO.
KV-G21MW3 RM-869 ME SCC-U07U-A
KV-G21QW3 RM-869 ME SCC-U07T-A
SERVICE MANUAL BG-2S CHASSIS
TRINITRON ® COLOR TV

http://cxema.ru
– 2 –
KV-G21MW3/G21QW3
RM-869
Note
Power requirements 110-240 V AC, 50/60 Hz
Power consumption (W) Indicated on the rear of the TV
Television system B/G KV-G21QW3
B/G, I, D/K, M KV-G21MW3
Color system PAL, PAL 60, SECAM, NTSC4.43, NTSC3.58 KV-G21MW3
PAL, PAL 60, SECAM, NTSC4.43 KV-G21QW3
Channel coverage VHF: E2 to E12 / UHF: E21 to E69 / CATV: S01 to S03, S1 to S41
Audio output (speaker) 3W + 3W
Inputs ˘(antenna): 75 ohms external terminal
…(video input) jacks: phono jacks
D(video): 1 Vp-p, 75 ohms
≥(audio): 500 mVrms, high impedance
Outputs A(earphone) jack: mini jack
Ú(monitor output) jacks: phono jacks
D(video): 1 Vp-p, 75 ohms
≥(audio): 500 mVrms
Picture tube 21 in.
Tube size (cm) 54 Measured diagonally
Screen size (cm) 51 Measured diagonally
Dimensions (w/h/d, mm) 516 ×464 ×478
Mass (kg) 22
Design and specifications are subject to change without notice.
SPECIFICATIONS
CAUTION
SHORT CIRCUIT THE ANODE OF THE PICTURE TUBE AND
THE ANODE CAPTO THE METAL CHASSIS, CRT SHIELD, OR
CARBON PAINTED ON THE CRT, AFTER REMOVING THE
ANODE.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY SHADING AND MARK !ON
THE SCHEMATIC DIAGRAMS,EXPLODEDVIEWS AND INTHE
PARTS LIST ARE CRITICALTO SAFE OPERATION. REPLACE
THESE COMPONENTS WITH SONY PARTS WHOSE PART
NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN
SUPPLEMENTS PUBLISHED BY SONY.

http://cxema.ru
– 3 –
KV-G21MW3/G21QW3
RM-869
TABLE OF CONTENTS
SELF DIAGNOSIS FUNCTION.................................. 4
1. GENERAL.................................................................... 5
2. DISASSEMBLY
2-1. Rear Cover Removal............................................ 10
2-2. A Board Removal ................................................ 10
2-3. Service Position ................................................... 10
2-4. Replacement of Parts ........................................... 11
2-4-1. Replacement of Multi Button .................................... 11
2-4-2. Replacement of Light Guide ..................................... 11
2-5. Terminal Board Bracket Removal ....................... 11
2-6. Demagnetization Coil Removal .......................... 11
2-7. Picture Tube Removal.......................................... 12
3. SET-UP ADJUSTMENTS
3-1. Beam Landing ...................................................... 13
3-2. Convergence......................................................... 14
3-3. Focus Adjustment ................................................ 15
3-4. Remote Commander Adjustment ........................ 16
3-5. G2 (Screen) and White Balance Adjustments ..... 16
4. CIRCUIT ADJUSTMENTS
4-1. Adjustments with Commander ............................ 17
4-2. Adjustment Method ............................................. 18
4-3. A Board Adjustment after IC003 (Memory)
Replacement......................................................... 23
4-4. Picture Distortion Adjustment ............................. 23
5. DIAGRAMS
5-1. Block Diagram ...................................................... 25
5-2. Circuit Boards Location ....................................... 28
5-3. Schematic Diagrams and Printed Wiring Boards 28
(1) Schematic Diagram of A Board ........................... 33
(2) Schematic Diagram of C Board ........................... 37
5-4. Semiconductors..................................................... 41
6. EXPLODEDVIEW
6-1. Chassis .................................................................. 43
7. ELECTRICAL PARTS LIST.................................... 45
Section Title Page Section Title Page

http://cxema.ru
– 4 –
KV-G21MW3/G21QW3
RM-869
If no acknowledgement is returned from a device which is turned "ON", the device has a problem.
In this case, one of the LED's responding to the problem device will flicker a defined number of times.
Flickering is operated by lighting the LED's for 60ss each time.
The flickering frequency responding to each failed device is shown below.
SELF DIAGNOSIS FUNCTION
Board name
Ref. No.
Device
Flickering Frequency
A Board
IC003
NONVOLATILE
MEMORY
(ST24C08FB6)
1
A Board
IC300
Y/C JUNGLE
(TDA8374A)
3
All the devices are checked one after another from the left of the table.
If an error is found, the responding LED will start flickering.
So, if more than 1 device have failed, only the one on the left side will flicker.

http://cxema.ru
– 5 –
KV-G21MW3/G21QW3
RM-869
3
1
– PROGR +
SELECT
– PROGR +
– VOLUME +
TV/VIDEO
SELECT
VHF LOW B/G
1
SECTION 1
GENERAL
The operating instructions mentioned here are partial abstracts from the Operating Instruction Manual. The page numbers of the Operating Instruction Manual remain as in the manual.
2

http://cxema.ru
– 6 –
KV-G21MW3/G21QW3
RM-869
Getting Started
4
-EN
Connecting a VHF antenna or a combination VHF/UHF antenna
— 75-ohm coaxial cable (round)
Attach an optional IEC antenna connector to the 75-ohm coaxial cable.
Plug the connector into the (antenna) socket at the rear of the TV.
Connections
On a wall
or
Getting Started
Rear of TV
Rear of TV
5
Getting Started -EN
Connecting optional equipment
You can connect optional audio/video equipment to your TV such as a VCR, multi disc player, camcorder, or video
game.
Connecting video equipment using the
…
(video input) jack
EN
When connecting video equipment to the
…
(video input) jack
Do not connect video equipment to the
…
(video input) jacks at the front and the rear of your TV simultaneously; otherwise the picture
will not be displayed properly on the screen.
Connecting audio/video equipment using the
Ú
(monitor output) jack
Rear of TV
to antenna socket
VCR
to antenna
output
≥
Ú
…
D
to video
and audio
inputs
: Signal flow
Rear of TV
to antenna
output
to video
and audio
outputs
VCR
to antenna socket
≥
Ú
…
D
: Signal flow
Front of TV
Camcorder
D
…
≥
to video and
audio outputs
: Signal flow
to
…
(video input)
D
(video) and
≥
(audio) inputs
to
Ú
(monitor output)
D
(video) and
≥
(audio) outputs
to
…
(video input)
D
(video) and
≥
(audio) inputs
When recording through the
Ú
(monitor output) jack
Do not change the channel or video input while recording with a VCR; otherwise the channel or video input you are recording also will be
changed.

http://cxema.ru
– 7 –
KV-G21MW3/G21QW3
RM-869
7
Getting Started -EN
5
Press +/– on the remote commander or
.
+/– on the TV again.
To start presetting channels automatically
from the specified program position
Press PROGR +/– or number buttons on the remote
commander or PROGR +/– on the TV until the
required program position appears on the screen after
step 4 of “Presetting channels automatically”.
Presetting channels manually
1
Press SELECT on the remote commander or the
TV until “TV SYSTEM” appears on the screen
(for
KV-G21MW3
only).
2
Press +/– on the remote commander or
.
+/– on the TV to select the TV system (for
KV-G21MW3
only).
3
Press SELECT on the remote commander or
the TV until “MANUAL PROGRAM” appears
on the screen.
4
Press +/– on the remote commander or
.
+/– on the TV.
5
Press PROGR +/– or number buttons on the
remote commander or PROGR +/– on the TV
until the required program position
appears on the screen.
6
Press +/– on the remote commander or
.
+/– on the TV until the required channel
picture appears on the screen.
7
Press SELECT on the remote commander or
the TV.
Disabling program positions
1
Press PROGR +/– or number buttons on the
remote commander or PROGR +/– on the TV
until the unused or unwanted program
position appears on the screen.
2
Press SELECT on the remote commander or
the TV until “MANUAL PROGRAM” appears
on the screen.
3
Press +/– on the remote commander or .
+/– on the TV.
4
Press PIC MODE on the remote commander.
5
Press SELECT on the remote commander or
the TV.
To preset the disabled program position again
Preset the channel quickly, automatically or manually
.
TV SYSTEM
SELECT SELECT
or
or
B/G I D/K M
–
.
+
MANUAL PROGRAM
SELECT SELECT
or
123
46
789
÷0
5
PROGR
– PROGR +
or
or
VHF LOW B/G
–
.
+
1
SELECT SELECT
or
1231
–
.
+
123
46
789
÷0
5
PROGR
– PROGR +
or
or
or
or
–
.
+
or
Getting Started
6
-EN
Presetting channels
If the picture color is poor and/or the sound is
noisy (for KV-G21MW3 only)
Select the appropriate TV system as follows:
1Press SELECT on the remote commander or the TV
until “TV SYSTEM” appears.
2Press +/– on the remote commander or
.
+/– on
the TV until the picture and sound becomes
normal.
Notes
•If you do not know your local TV system, consult your nearest
authorized service center or dealer.
•The setting of the “TV SYSTEM” is memorized for each
program position.
Presetting channels automatically
1
Press SELECT on the remote commander or
the TV until “TV SYSTEM” appears on the
screen (for KV-G21MW3 only).
2
Press +/– on the remote commander or
.
+/– on the TV to select the TV system
(for KV-G21MW3 only).
3
Press SELECT on the remote commander or
the TV until “AUTO PROGRAM” appears on
the screen.
4
Press +/– on the remote commander or
.
+/– on the TV.
You can preset up to 100 TV channels in numerical
sequence from program position 1 using the buttons on
the remote commander or the TV.
You can preset TV channels quickly, automatically or
manually.
Quick channel presetting
1
Press
U
to turn on the TV.
When the TV is turned on in standby mode, press
u
on the remote commander.
2
Press SELECT and PROGR + on the TV
simultaneously for one to two seconds.
Remote commander
TV SYSTEM
SELECT SELECT
or
1231
– PROGR +
SELECT
U
TV
–
PROGR
+
–
.
+
TV/VIDEO
SELECT
R
U
u
Number
PROGR +/–
+/–
SELECT
or
or
or
AUTO PROGRAM
SELECT SELECT
B/G I D/K M
–
.
+
VHF LOW B/G
1
–
.
+
Front of TV

http://cxema.ru
– 8 –
KV-G21MW3/G21QW3
RM-869
Operations
8
-EN
Watching the TV
Turning off the TV
To turn off the TV temporarily
Press
u
on the remote commander. The
u
indicator
on the TV lights up.
To turn off the TV completely
Press
U
on the TV.
If the power on the TV is turned off in standby mode, the
u
indicator on the TV may remain alight for a while.
Watching the video input
Press
…F
.
To watch TV
Press
;
.
Muting the sound
Press
¤
.
1
Press
U
to turn on the TV.
When the TV is turned on in standby mode, press
u
on the remote commander.
2
Select the TV program you want to watch.
To select a program position directly
Press the number button.
To select a two-digit program position, press
“-/--” before the number buttons.
For example: to select program position 25, press
“-/--”, and then “2” and “5”.
To scan through program positions
Press PROGR +/– until the program position you
want appears.
3
Press
.
+/– to adjust the volume.
123
46
789
÷0
5
÷25
PROGR
Operations
U
.
u
¤
MUTING
U
…
F
VIDEO 1
;
9
Operations -EN
1
AUTO B/G
DYNAMIC
-EN
•If no buttons or controls are pressed for more than two hours
after the TV is turned on using the Wake Up Timer, the TV
automatically turns into standby mode. If you want to
continue watching the TV, press any button or control on the
TV or remote commander.
After 30 minutes After 60 minutes
After 90 minutes
No sleep timer
SLEEP TIMER:30M SLEEP TIMER:60M
SLEEP TIMER:OFF SLEEP TIMER:90M
C
I
Displaying on-screen information
Press
E
G
.
The program position, local system, and TV settings are
displayed on the screen.
EG
Setting the Sleep Timer
You can set the TV automatically turned off as you
program.
Press
C
I
.
To cancel the Sleep Timer, press
C
I
repeatedly
until “SLEEP TIMER: OFF” appears, or turn off the TV.
Changing the on-screen display
language
You can use buttons on the remote commander or the
TV to change the on-screen display language.
1
Press SELECT until the screen appears as
follows:
2
Press +/– to select “ ”.
Note
•You can also use SELECT and
.
+/– on the TV to select the
on-screen display language.
Setting the Wake Up Timer
You can set the TV automatically turned on as you
program.
1
Press
B
©
repeatedly to set the timer.
The on-screen display appears and the
B
indicator
on the TV lights up.
2
If you want a particular TV program or video
input to be displayed using the Wake Up Timer, select the TV program or video input.
3
Press
u
on the remote commander or set
the Sleep Timer to turn off the TV in
standby mode.
To cancel the Wake Up Timer, press
B
©
repeatedly
until “WAKE UP TIMER: OFF” appears, or turn off the
main power of the TV.
Notes
•The Wake Up Timer starts immediately after the on-screen
display disappears.
•The last TV program position or video input just before the TV
turns into standby mode will appear when the TV is turned on
using the Wake Up Timer.
After 10 minutes
No wake up timer After 12 hours
WAKE UP TIMER:10M
WAKE UP TIMER:OFF WAKE UP TIMER:12H00M
B©
+/–
SELECT
LANGUAGE / : ENGLISH
SELECT
: LANGUAGE /

http://cxema.ru
– 9 –
KV-G21MW3/G21QW3
RM-869
Additional Information
11
-EN
Troubleshooting
No picture
No sound
/Press
U
or
u
.
/Check the antenna connection.
/Check the VCR connections.
/Check the power cord connection.
/Check the standby mode.
Good picture
No sound
/Press
.
+.
/Press
¤
.
No color
/Adjust the COLOR level in the on-screen
display.
/Check the COLOR SYSTEM setting.
TV cabinet creaks
/Even if the picture or the sound is normal,
changes in the room temperature
sometimes make the TV cabinet expand or
contract, making a noise. This does not
indicate a malfunction.
Note on the remote commander
•The supplied remote commander is used on several models of
the TV. If you do not find instructions for some controls that
are on the remote commander, that means your TV does not
employ the features of those controls, e.g.
L
and SOUND
MODE.
Notes
•When you turn on the TV, you may hear the “boon” sound
that is caused by the demagnetization of the TV. This does not
indicate a malfunction.
•The picture color may become abnormal if you change the
direction of your TV. To obtain the normal picture color, press
U
on the TV to turn off the TV for five minutes and then turn
it on again.
•Design and specifications are subject to change without notice.
•All contents in the instruction manual are subject to change
without notice.
WARNING
Do not install the appliance in a confined space, such as
a bookcase or built-in cabinet.
If you have any problems, read this manual again and
check the countermeasure for each of the symptoms
listed below.
If the problem persists after trying the methods below,
contact your nearest authorized service center or dealer.
Snowy picture
Noisy sound
/Check the antenna.
/Check the antenna connection on the TV
and on the wall.
/Check the TV SYSTEM setting (for
KV-G21MW3 only).
Dotted lines or stripes
/This may be caused by local interference
(e.g. cars, neon signs and hair dryers).
Adjust the antenna for minimum interference.
Double images or “ghosts”
/This may be caused by reflections from
nearby mountains or buildings. A highly
directional antenna may improve the
picture.
Good picture
Noisy sound
/Check the TV SYSTEM setting (for
KV-G21MW3 only).
Additional Information
Operations
10
-EN
Adjusting the
Each time you press SELECT, the screen changes as
follows:
2
Press +/– to adjust the item.
3
To adjust other items, repeat steps 1 and 2.
Note
•You can also use SELECT and
.
+/– on the TV to adjust the
picture setting.
If the picture color is abnormal when receiving
programs through the
˘
(antenna) terminal
Change the “TV SYSTEM” (for KV-G21MW3 only) or
“COLOR SYSTEM” setting or adjust the “COLOR”
level in the on-screen display until the color becomes
normal.
If the picture is abnormal when receiving
programs through the
…
(video input) jack
Change the “COLOR SYSTEM” setting or adjust the
“COLOR” level in the on-screen display until the color
becomes normal.
Note
•Normally set “COLOR SYSTEM” to “AUTO”.
If the sound is distorted or noisy when
receiving programs through the
˘
(antenna)
terminal
Change the “TV SYSTEM” setting (for KV-G21MW3
only) in the on-screen display until the sound becomes
clear.
Note on the SOUND MODE button
•The sound mode feature is unavailable for your TV. Thus, the
SOUND MODE button on the remote commander is not used
for your TV.
Selecting the picture mode
Press PIC MODE until the mode you want
appears.
Each time you press PIC MODE, the screen changes as
follows:
Note
•If you change the picture mode after the following
adjustments, the adjustment changes in accordance with the
picture mode.
Adjusting the picture setting
1
Press SELECT until the item you want to
adjust appears.
÷0
SOUND
MODE
SELECT
PIC MODE
PIC MODE
High contrast
Soft picture
(good for video
games)
DYNAMIC STANDARD
SOFT
+/–
SELECT
PICTURE COLOR BRIGHT
HUE
SHARPNESS
(Operative for
NTSC signal
only)
…
SELECT –
PROGR
+
–
.
+
Front of TV
Normal

http://cxema.ru
– 10 –
KV-G21MW3/G21QW3
RM-869
2-1. REAR COVER REMOVAL
2-2. A BOARD REMOVAL
2-3. SERVICE POSITION
SECTION 2
DISASSEMBLY
Four screws
(BVTP 4×16)
1
2Two screws
(BVTP 4×16)
Lever
Lever
A board

http://cxema.ru
– 11 –
KV-G21MW3/G21QW3
RM-869
2-4. REPLACEMENT OF PARTS
For replacement of the Multi Button and Light Guide, cut the welded portions
from them, exchange with the new parts, and fix them with screws (+BVTP) respectively.
2-4-1. REPLACEMENT OF MULTI BUTTON
2-5. TERMINAL BOARD BRACKET REMOVAL
2-6. DEMAGNETIZATION COIL REMOVAL
Two claws
A board
Terminal board bracket
A board
Terminal board bracket
1Demagnetization coil
2Tension spring
Picture tube
Cut
Cut
Multi button
Multi button
Three screws
(BVTP 3×12)
•SCREWING TORQUE
7±1 kg•cm
2-4-2. REPLACEMENT OF LIGHT GUIDE
Light guide
Cut
Cut
Light guide
Two screws
(BVTP 3×12)
•SCREWING TORQUE
7±1 kg•cm

http://cxema.ru
– 12 –
KV-G21MW3/G21QW3
RM-869
2-7. PICTURETUBE REMOVAL
2Using a thumb press down,then pull up the rubber cap firmly in the direction indicated
by the arrow b.
3When one side of the rubber cap is separated from the anode button, the anode-cap
can be removed by turning up the rubber cap and pulling it up in the direction of the
arrow c.
•HOWTO HANDLE AN ANODE-CAP
1Do not damage the surface of anode-cap with sharp shaped objects.
2Do not press the rubber too hard so as not to damage the inside of anode-cap.
A metal fitting called the shatter-hook terminal is built into the rubber.
3Do not turn the foot of rubber over too hard.
The shatter-hook terminal will stick out or damage the rubber.
•REMOVAL OF ANODE-CAP
NOTE : After removing the anode, short circuit the anode of the picture tube and the
anode cap to the metal chassis, CRT shield or carbon paint on the CRT.
•REMOVING PROCEDURES
1Turn up one side of the rubber cap in the direction indicated by the arrow a.
2A board
4C board
5Deflection yoke
Cushion
6Four screws
(Tapping screws)
1Anode cap
a
a
b
b
c
Anode button

http://cxema.ru
– 13 –
KV-G21MW3/G21QW3
RM-869
Perform the adjustments in the following order:
1. Beam Landing
2. Convergence
3. Focus
4. White Balance
Note : Test Equipment Required:
1. Color-bar/Pattern Generator
2. Degausser
3. Oscilloscope
SECTION 3
SET-UP ADJUSTMENTS
Fig. 3-4
Fig. 3-3
Fig. 3-2
Fig. 3-1
}normal
•The following adjustments should be made when a complete
realignment is required or a new picture tube is installed.
•These adjustments should be performed with rated power
supply voltage unless otherwise noted.
Controls and switch should be set as follows unless otherwise noted:
PICTURE control........................................................... normal
BRIGHTNESS control................................................... normal
Preparation :
•In order to reduce the influence of geomagnetism on the set's
picture tube, face it east or west.
•Switch on the power and degauss with the degausser.
3-1. BEAM LANDING
1. Input a white signal with the pattern generator.
Contrast
Brightness
2. Set the pattern generator raster signal to green.
3. Move the deflection yoke to the rear and adjust with the purity
control so that the green is at the center and the blue and the red
take up equally sized areas on each side.
(See Figures 3-1 through 3-3.)
4. Move the deflection yoke forward and adjust so that entire
screen is green. (See Figure 3-1.)
5. Switch the raster signal to blue, then to red and verify the
condition.
6. When the position of the deflection yoke has been decided,
fasten the deflection yoke with the screws.
7. If the beam does not land correctly in all the corners, use a
magnet to adjust it. (See Figure 3-4.)
..............................................................................................................................................................................................................................
Purity control
Deflection yoke positioning
corrects these areas.
Purity control corrects
this area. Disk magnets or rotatable
disk magnets correct
these areas (a-d).
b
c
a
d
ba
cd
GREEN
BLUE RED

http://cxema.ru
– 14 –
KV-G21MW3/G21QW3
RM-869
•Operation of V.STAT magnet.
If the V.STAT magnet is moved in the direction of the aand
barrows, the red, green and blue dots move as shown below.
•Operation of BMC (Hexapole) magnet.
If the blue or red dot does not converge with the other two dots,
perform following steps.
Move BMC magnet (a) to correct insufficient H.static
convergence.
Rotate BMC magnet (b) to correct insufficient V.static
convergence.
In either case, repeat Beam Landing Adjustment.
1. (Moving vertically), adjust theV.STAT magnet so that the red,
green and blue dots are on top of each other at the center of the
screen.
2. (Moving horizontally), adjust the H.STAT VR so that the red,
green and blue dots are on top of each other at the center of the
screen.
3-2. CONVERGENCE
Preparation :
•Before starting this adjustment, adjust the focus, horizontal size,
and vertical size.
•Minimize the brightness setting.
•Provide dot pattern.
(1) Horizontal and Vertical Static Convergence
R G B
G
R
B
Center dot
C board RV 701
SCREEN (G2)
V.STAT Magnet
V.STAT
Purity
B
R
B
R
ab
bb
a
b
a
b
a
R
G
B
b
B
G
R
b
ba
a
1
2
3
GG
B G R
R G B
a
BMC magnet
b

http://cxema.ru
– 15 –
KV-G21MW3/G21QW3
RM-869
3-3. FOCUS ADJUSTMENT
Adjust FOCUS control on the flyback transformer for the best
focus.
(3) Screen-corner Convergence
(2) Dynamic Convergence Adjustment
Preparation :
•Before starting this adjustment, adjust the horizontal static
convergence and the vertical static convergence.
1. Slightly loosen the deflection yoke screws.
2. Remove the deflection yoke spacer.
3. Move the deflection yoke as shown in the figure below and
optimize the convergence.
4. Tighten the deflection yoke screws.
5. Install the deflection yoke spacer.
B G R B
G
R
R
G
BR G B
R G B R
G
B
B
G
RB G R
R G BB G R
B G RR G B
a-d : screen-corner
misconvergence
ba
cd
a
d
c
b
a to d : Permalloy assembly
Fix a Permalloy assy
corresponding to the
misconverged areas
Note: Screen VR is not used.
FOCUS
SCREEN
(NOT USED)

http://cxema.ru
– 16 –
KV-G21MW3/G21QW3
RM-869
3-4. REMOTE COMMANDER ADJUSTMENT
a. AN ITEM OF ADJUSTMENT
b. METHOD OF CANCELLATION FROM SERVICE
MODE
Set the standby condition (Press
POWER
button on the
commander) and then press
POWER
button again, hereupon it
becomes TV mode.
c. METHOD OF WRITE FOR MEMORY
1) Set to Service Mode.
2) Press 1(UP) and 4(DOWN) to select an item of adjustments.
3) Press
MUTING
button and it will indicateWRITE on screen.
4) Press -button to write into memory.
d. MEMORY WRITE CONFIRMATION METHOD
1) After adjustment, pull out the plug from AC outlet, and then
plug into AC outlet again.
2) Turn the power switch ON and set to Service Mode.
3) Call the adjusted items again, confirm they were adjusted.
Note
WHITE POINT R
WHITE POINT G
WHITE POINT B
Initial DATA
28
20
20
3-5. G2 (SCREEN) AND WHITE BALANCE
ADJUSTMENTS
1. G2 (SCREEN) ADJUSTMENT (RV701)
1) Set the PICTURE and BRIGHTNESS to normal.
2) Put to VIDEO input mode without signals.
3) Connect R, G and B of the C board cathode to the oscilloscope.
4) Adjust G2 (RV701) volume to the value below.
Item
number
09
0A
0B
Adjustment
Item
RDR
GDR
BDR
177 ± 2 V DC
2. WHITE BALANCE ADJUSTMENTS
1) Set to Service Mode.
2) Input an entire white signal.
3) Set the PICTURE to maximum.
4) Select RDR(09) with 1and 4, and then set the level to 25
with 3and 6.
5) Select GDR(0A) and BDR(0B) with 1and 4, and adjust
the level with 3and 6for the best white balance.
6) Write into the memory by pressing
MUTING
, then -.
SERVICE
MUTING
1 FRDR09 6000V3.2C058S/
060S
6000V3.2C058S/
060S
OEM CODE
PAL or
NTSC
German A2 Stereo
Software Version #
WRITE1 FRDR09
0
Executes the writing
Green
WRITE1 FRDR09
0
Executes the writing
(bottom line disappears)
0 V

http://cxema.ru
– 17 –
KV-G21MW3/G21QW3
RM-869
Entering service mode
With the unit on standby
↓
DISPLAY
↓
5
↓
VOL
( + )
↓
POWER
The operation sequence puts the unit into service mode.
SECTION 4
CIRCUIT ADJUSTMENTS
4-1. ADJUSTMENTS WITH COMMANDER
Service adjustments are made with the RM-869 that comes with
this unit. 1, 4Raise/lower the service item number
3, 6Raise/lower the data
[MUTING] Writes
-Executes the writing
7, -All data becomes the values in memory
8, -All user control goes to the standard state
5, -Service data initialization (Be sure not to use
usually.)
2, -Write 50Hz adjustment data to 60Hz, or
viceversa.
The screen display is :
1, 4Select the adjustment item.
↓
3, 6Raise/lower the data.
↓
MUTING
Writes
↓
-Executes the writing.
RM-869
SERVICE Mode08
Data
HSF
50 Depends on the signals
PAL, SECAM : 50
NTSC : 60
Adjustment item
00
ModeItem #
00V3.2C058S/
060S
OEM CODE
German A2 Stereo
Software Version #
1
SERVICE00OP0
50
3D
0000000000
2
(Bit options adjustable)
¤EG u
V…F;
B©
SELECT p
PIC MODE p
SOUND
MODE
.
PROGR
A/B H
CI
++
123
46
789
0
+ p
– p
5
TV

http://cxema.ru
– 18 –
KV-G21MW3/G21QW3
RM-869
Use the same method for Items Number 00-40. Use 1and 4to
select the adjustment item, use 3and 6to adjust, write with
MUTING
, then execute the write with -.
WRITE
WRITE
GREEN0CVSF08
SERVICE
50
50
GREEN0CVSF08
Adjusted with 3and 6buttons
Written with MUTING
Write executed with 0
GREEN
The WRITE display
will change back to
SERVICE.
(2nd line disappear
when written)
0CVSF08
00V3.2C058S/
060S
00V3.2C058S/
060S
Blank
4-2. ADJUSTMENT METHOD
Item Number 08
This explanation uses V-SHIFT as an example.
1. Select 08 V-SHIFT with the 1and 4buttons.
2. Raise/lower the data with the 3and 6buttons.
3. Select the optimum state. (The standard is 0F for PAL
reception.)
4. Write with the
MUTING
button.
5. Execute the writing with the -button. (The WRITE
display returns to green SERVICE.)

http://cxema.ru
– 19 –
KV-G21MW3/G21QW3
RM-869
Data Range
Adjustment ItemTable
No. Item Initial Function Note for Different Data Device/Category Register
(OSD) Max. Min. Data (Slave Address) No. (bit)
00 HSF 3F 00 0 H Shift [2C/33/31/38] 50/60Hz/RGB50/RGB60 TDA8375(8A) 03 (5-0)
01 HSZ 3F 00 0 HSize [35/35/35/35] 50/60Hz/RGB50/RGB60 04 (5-0)
02 PAP 3F 00 0 Pin Amplitude [25/25] 50/60Hz 05 (5-0)
03 CNP 3F 00 0 Corner Pin [10/0C] 50/60Hz 06 (5-0)
04 TLT 3F 00 0 Tilt [20/2D] 50/60Hz 07 (5-0)
05 VSL 3F 00 0 V Slope [1F/1F] 50/60Hz 08 (5-0)
06 VAP 3F 00 0 V Amplitude [1C/1B] 50/60Hz 09 (5-0)
07 SCR 3F 00 0 S Correction [16/16] 50/60Hz 0A (5-0)
08 VSF 3F 00 0 V Shift [10/10] 50/60Hz 0B (5-0)
09 RDR 3F 00 28 R Drive 0C (5-0)
0A GDR 3F 00 20 G Drive 0D (5-0)
0B BDR 3F 00 20 B Drive 0E (5-0)
0C FO 03 00 0 ø1 Time Constant [00/00/00] TV/Video/Teletext 00 (3-2)
0D AGC 3F 00 0 AGC Take Over [28/28/28] TV/Video/Teletext 13 (5-0)
0E VSW 1 0 0 Video Mute Switch [0/1/0] TV/Video/Teletext 13 (6)
0F FOR 03 00 03 Forced Field Frequency 01 (7-6)
10 DL 1 0 0 De-interlace 01 (5)
11 POC 1 0 0 Fixed ø1 Synchro. mode 01 (3)
12 COR 1 0 0
Noise Coring [01/00/00] TV/Video/Teletext 10 (6)
13 VPX FF 00 00 Extra Bits (see below)
14 PMX 3F 00 27 Picture Maximum Data TV/Video/Teletext [28/28/28] 12 (5-0)
15 PMI 3F 00 04 Picture Minimum Data 12 (5-0)
16 SBR 7F 00 4B Sub Brightness 10 (6-0)
17 SHU 0F 00 07 Sub Hue 02 (3-0)
18 SSH 03 00 0 Sub Sharpness [01/03] TV/Video 0F (1-0)
19 SC1 3F 00 0 Sub Color Lower [26/29] 50/60Hz 11 (5-0)
1A SC2 3F 00 0 Sub Color Higher [0C/0D] 50/60Hz 11 (5-0)
1B AIP 7F 00 3C Adjustment IF-PLL 15 (6-0)
1C VZM 3F 00 19 Vertical Zoom 16 (5-0)
1D WST FF 00 15 W/G Stereo Threshold MSP3410D(80)
1E WBT FF 00 EA W/G Bilingual Threshold
1F WLL FF 00 05 W/G Monaural Threshold
20 ACG 1 0 1 AGC Switch auto/constant BB (7)
21 CDB 3F 00 28 AGC Gain at Constant Mode BB (6-1)
22 FGP 7F 00 1B FM Prescale for B/G, I, D/K 0E (7-0)
23 FMP 7F 00 32 FM Prescale for M 0E (7-0)
24 FMH 7F 00 36
FM Prescale for HDEV (non-M) 0E (7-0)
25 FMM 7F 00 65 FM Prescale for HDEV (M) 0E (7-0)
26 WGP 7F 00 2A W/G Prescale 0E (7-0)
27 NIP 7F 00 6D NICAM Prescale 10 (7-0)
28 SCP 7F 00 3B SCART Input Prescale 0D (7-0)
29 SCV 7F 00 2A SCART Output Prescale 07 (7-0)
2A CRM 1 0 0 Carrier Muting on/off BB (9)
2B ACO 1 0 1 Audio Clock-out on/off 83 (5)
2C WAC 0F 00 00 W/G Agreement Count
2D NFT FF 00 50 Auto FM Switch Threshold 21 (10-3)
2E DLG FF 00 30 W/G Search Delay
2F DLN FF 00 20 NICAM Search Delay
30 DLS FF 00 10 Stereo Status Read Delay MSP3410D(80)
31 SMX 7F 00 0 DFP Volume Maximum 72 00 (14-8)
32 ING 0F 00 00 Input Gain [03/00/00] M system/non-M/Video TDA7438(88) 01 (3-0)
33 VOM 3F 00 01 Volume Output Gain M system only 02 (5-0)
34 TXH 03 00 01 Teletext Horizontal Position SAA5261(58) 16 (1-0)

http://cxema.ru
– 20 –
KV-G21MW3/G21QW3
RM-869
Data Range
Adjustment ItemTable
No. Item Initial Function Note for Different Data Device/Category Register
(OSD) Max. Min. Data (Slave Address) No. (bit)
35 BKP 3F 00 00 Picture Data at Blanking OFF Other Control
36 ODL FF 00 10 Power ON Delay
37 OFR 0F 00 00
RGB Output Time (STBY OFF)
38 OFM 0F 00 00 RGB Output Time (AC OFF)
39 OSH 3F 00 0A OSD H Position
3A DKS 1 0 1 D/K Stereo enable/disable
3B MUT 1 0 0 Muting on/off at No Sync
3C ABL 1 0 0 Bright ABL Switch
3D SCM 1 0 0 SECAM Trap active/ inactive
3E FBT 1 0 1 FBT L/S C /M Strict/plain
3F OP0 FF 00 2F Optional Flags 0 (see below)
40 OP1 FF 00 0F Optional Flags 1 (see below)
41 OP2 FF 00 00 Optional Flags 2 (see below)
