Sony SLV-679HF - Video Cassette Recorder User guide

MODEL:
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
SLV-662/679HF DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
POWER
REQUIREMENTS:
POWER
CONSUMPTION:
1/4 inch =1 inch Scale 4:1
FRONT VIEW
SIDE VIEW
VHS HI-FI VCR
14" X 3 3/4" X 11
8 lbs. 2 oz.
120
V
60
H
25
Watts
11"
8 5/8" 3/4"
Sony Electronics Inc • Consumer Integrated Systems • Park Ridge, New Jersey 07656
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
BACK VIEW
AC
IN
1/4"9 3/4"
3 3/4"
7/8"
3/4"
OU
IN
RF UNIT
3
4
VHF/UHF
L Audio R VIDEO
LINE
IN
LINE
OUT
HI-FI Stereo
VHS
R
14"
1 7/8 1 7/8"1/4
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
