Sony SRW-5000 User manual

INSTALLATION MANUAL
1st Edition (Revised 3)
Serial No. 10101 and Higher: SRW-5000 (SY)
Serial No. 10001 and Higher: SRW-5500 (SY)
HD DIGITAL VIDEOCASSETTE RECORDER
SRW-5000
SRW-5500

SRW-5000/5500
!WARNING
This manual is intended for qualified service personnel only.
To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so. Refer all servicing to
qualified service personnel.
!WARNUNG
Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.
Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die
Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei
Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben
Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung
dazu besitzen.
!AVERTISSEMENT
Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien. Afin
de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les
réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.
Pour toute réparation faire appel à une personne compétente uniquement.
Attention-when the product is installed in Rack:
1. Prevention against overloading of branch circuit
When this product is installed in a rack and is
supplied power from an outlet on the rack, please
make sure that the rack does not overload the supply
circuit.
2. Providing protective earth
When this product is installed in a rack and is
supplied power from an outlet on the rack, please
confirm that the outlet is provided with a suitable
protective earth connection.
3. Internal air ambient temperature of the rack
When this product is installed in a rack, please make
sure that the internal air ambient temperature of the
rack is within the specified limit of this product.
4. Prevention against achieving hazardous
condition due to uneven mechanical loading
When this product is installed in a rack, please make
sure that the rack does not achieve hazardous
condition due to uneven mechanical loading.
5. Install the equipment while taking the operating
temperature of the equipment into consideration
For the operating temperature of the equipment, refer
to the “1-3. Operating Conditions” in this manual.
6. When performing the installation, keep the
following space away from walls in order to
obtain proper exhaust and radiation of heat.
Right, Left: 4 cm (1.6 inches) or more
Rear: 10 cm (4 inches) or more
When using a Ethernet cable:
For safety,do not connect to the connector for
peripheral device wiring that might have excessive
voltage.

SRW-5000/5500
For the customers in the Netherlands
Voor de klanten in Nederland
Hoe u de batterijen moet verwijderen, leest u in de
Onderhoudshandleiding.
Gooi de batterij niet weg maar lever deze in als klein
chemisch afval (KCA).
Für Kunden in Deutschland
Entsorgungshinweis: Bitte werfen Sie nur entladene
Batterien in die Sammelboxen beim Handel oder den
Kommunen. Entladen sind Batterien in der Regel dann,
wenn das Gerät abschaltet und signalisiert “Batterie
leer” oder nach längerer Gebrauchsdauer der Batterien
“nicht mehr einwandfrei funktioniert”. Um
sicherzugehen, kleben Sie die Batteriepole z.B. mit
einem Klebestreifen ab oder geben Sie die Batterien
einzeln in einen Plastikbeutel.
1 (P)

1
SRW-5000/5500
Table of Contents
Manual Structure
Purpose of this manual .............................................................................................. 2
Related manuals ......................................................................................................... 2
Trademark .................................................................................................................. 2
1. Installation
1-1. Installation Procedure .................................................................................. 1-1
1-2. Supplied Accessories .................................................................................. 1-1
1-3. Operating Conditions .................................................................................. 1-1
1-4. Power Supply .............................................................................................. 1-2
1-4-1. Voltage and Power Requirements .............................................. 1-2
1-4-2. Recommeded Power Cord .......................................................... 1-2
1-5. Installation Space ........................................................................................ 1-3
1-6. Rack Mounting ............................................................................................ 1-4
1-7. Matching Connectors and Cables ................................................................ 1-9
1-8. Signal Inputs and Outputs ......................................................................... 1-10
1-9. Switch Settings on Connector Panel ......................................................... 1-14
1-10. Switch Settings on Circuit Boards ............................................................ 1-15
1-10-1. APR-62 Board .......................................................................... 1-15
1-10-2. CUE-13 Board .......................................................................... 1-16
1-11. System Setting ........................................................................................... 1-17
1-11-1. Setting the System for SRW-5000 ........................................... 1-17
1-11-2. Setting the System for SRW-5500 ........................................... 1-20
1-11-3. Compatibility of REC and PB .................................................. 1-23
1-11-4. Setting to Store Meta Data ....................................................... 1-24
1-11-5. Input/Output Phase Settings ..................................................... 1-28
1-11-6. Storing and Reading System Settings in/from System Bank ... 1-30
1-11-7. Storing/Reading System Settings in/from Memory Stick ........ 1-32
1-11-8. Editing Titles of the System Bank ........................................... 1-35
1-11-9. Checking Saved System Bank Data in Detail .......................... 1-36
1-11-10. Compatibility of System Bank Data ........................................ 1-36
1-12. Opening/Closing the Lower Control Panel ............................................... 1-37
1-13. Reference System ...................................................................................... 1-38
1-14. Settings when Editor is Connected ........................................................... 1-39
1-14-1. Settings for Time Code ............................................................ 1-39
1-14-2. VTR Constant Values Settings of Editor ................................. 1-39
1-15. Removing/Reattaching Plug-in Board ...................................................... 1-40
1-16. Taking Out the Cassette in Tape Slacking ................................................ 1-41
Appendix A Setting Check Sheet

2
SRW-5000/5500
Purpose of this manual
This manual is the installation manual of the HD Digital Videocassette Recorder
SRW-5000/5500.
This manual is intended for use by trained system and service engineers, and
provides the information that is required to install (environment, connection infor-
mation, initial setting, etc.) and the setting check sheet.
Related manuals
Besides this “installation manual”, the following manuals are available for this unit.
If these manuals are required, please contact your local Sony Sales Office/Service
Center.
..
..
.Operation Manual (Supplied with this unit.)
This manual is necessary for application and operation (and installation) of this
unit.
..
..
.Maintenance Manual (Available on request)
Volume 1 : Service Instruction
Volume 2 : Parts List, Block Diagrams, and Board Layouts
Volume 3 : Schematic Diagrams
These manuals describe the maintenace and service information (service over-
view, adjustments, board layouts, schematic diagrams, detailed parts list, etc.) for
this unit.
..
..
.Protocol Manual of Remote (9-pin) Connector (Available on request)
This manual explains the protocol for controlling the VTR via the RS-422A (9-pin
serial remote).
..
..
.Interface Manual of Parallel I/O (50-pin) Connector (Available on
request)
This manual explains the protocol for controlling the VTR via the parallel (50-
pin).
..
..
.“Semiconductor Pin Assignments”CD-ROM (Available on request)
This “Semiconductor Pin Assignments” CD-ROM allows you to search for
semiconductors used in this unit.
The maintenance manual (volume 2) contains a complete list of semiconductors
and their ID Nos., and thus should be used together with the CD-ROM.
Part number: 9-968-546-XX
Trademark
Registered trademark used in this manual is as follows.
.Ethernet is a registered trademark of Xerox Corporation.
Manual Structure

1-1
SRW-5000/5500
Section 1
Installation
1-2. Supplied Accessories
Operation manual
Japanese ......................................................................... 1
English ........................................................................... 1
Operation manual CD-ROM (PDF) .................................. 1
Installation manual
Japanese ......................................................................... 1
English ........................................................................... 1
1-3. Operating Conditions
c
Good air circulation is essential to prevent internal heat
build-up. Place the unit in location with sufficient air
circulation.
Do not block the ventilation holes of the cabinet and the
front and rear panels.
Operating temperature: 5 dC to 40 dC
Operating humidity: 25 % to 80 % (non-condensing)
Storage temperature: _20 dC to 60 dC
Locations to avoid:
.Areas where the unit will be exposed to direct sunlight
of any other strong lights.
.Areas near heat sources.
.Dusty areas or areas subject to vibration.
.Areas with strong magnetic field.
.Areas with much electrical noise.
.Areas with much static electricity.
.Areas that is impossible to find a specified room for
installation. (Refer to “1-5. Installation Space”.)
.Areas windtight.
Tilt allowance: Within 30d(Do not slant the front
and rear of the unit more than 30d.)
c
Fix the unit securely to avoid drop when the unit is operat-
ed at not-horizontal place.
1-1. Installation Procedure
Installation procedure of this unit is shown on the follow-
ing flowchart.
Refer to each section about detail of each flow.
The operation manual is also required to do *-marked
flow.
1-3. Operating Conditions
1-4. Power Supply
1-5. Installation Space
1-6. Rack Mounting
1-7. Matching Connectors and
Cables
1-8. Signal Inputs and Outputs
1-9. Switch Settings on Connector
Panel
1-10. Switch Settings on Circuit
Boards
1-11. System Setting
1-12. Opening/Closing the Lower
Control Panel
1-13. Reference System
1-14. Settings when Editor is
Connected
Start
Determination of
installation place
Unpacking
Rack mounting
*Connection
*Initial setup
*Operation check
End
n
If an error message appears on the time data
display area, refer to the operation manual.
(For more details, refer to the maintenance
manual volume 1.)
n
When the unit is transported, it is required to
pack the unit into the specified new packing
materials.
Do not reuse the packing materials.

1-2
SRW-5000/5500
AC inlet
2
1
21
AC inlet
21
AC inlet
AC inlet
2
1
1-4. Power Supply
1-4-1. Voltage and Power Requirements
This unit’s power line has a switching regulator.
c
Be sure to operate the unit within the range of following
power voltage.
Power voltage: AC 100 to 240 V ±10 %
Power frequency: 50 Hz or 60 Hz
Power consumption: Maximum 320 W
(With all of the presumed optional kits.)
n
The power consumption becomes the
maximum at record-starting.
Rush current: Power voltage 100 V IN: 17 A
Power voltage 240 V IN: 54 A
n
AC power supply is required a capacity which is commen-
surate with rush current.
If the capacity of the AC power supply is not enough, the
breaker of AC power of a supply side may operate or this
unit may not operate normally.
1-4-2. Recommeded Power Cord
This unit does not come with a power cord.
To get a power cord, please contact your local Sony Sales
Office/Service Center.
w
.Use the approved Power Cord (3-core mains lead)/
Appliance Connector/Plug with earthing-contacts that
conforms to the safety regulations of each country if
applicable.
.Use the Power Cord (3-core mains lead)/Appliance
Connector/Plug conforming to the proper ratings (Volt-
age, Ampere).
If you have questions on the use of the above Power Cord/
Appliance Connector/Plug, please contact your local Sony
Sales Office/Service Center.
w
.Never use an injured power cord.
For customers in the U.S.A. and Canada:
1Power cord 125 V 10 A (2.4 m): !1-557-377-11
2Plug holder (Brown): 3-613-640-01
For customers in the United Kingdom:
1Power cord 250 V 10 A (2.4 m): !1-782-165-11
2Plug holder (Brown): 3-613-640-01
For customers in European countries except the United
Kingdom:
1Power cord 250 V 10 A (2.0 m): !1-551-631-00
2Plug holder (Brown): 3-613-640-01
For customers in the China:
1Power cord 250 V 10 A (1.8 m): !1-783-481-41
2Plug holder (Brown): 3-613-640-01
If the unit is used in the area except above, please contact
your local Sony Sales Office/Service Center.

1-3
SRW-5000/5500
15.9
454
39.5153.5
577(Maximum traveling distance)
156 3232
12.7
123.8
34
263.5
415.9
457.5
42.5 (38.5)
218
37
465
482
22020
149.2
36431.5
427
53345.5
538.5
416(Rail-installed width)
427(Unit width)
Unit : mm
(Mass of this unit : approx. 30 kg)
Moreover, an air flow that is effective in cooling the unit is
essential. If the ventilation is not enough, the unit may be
damaged because of an increase of the internal tempera-
ture.
n
This unit is air-cooled by the fans. The operation with the
upper lid is removed affects the air cooling by the fans.
Complete the work in a short time as possible when
operating the unit for inspection with the upper lid re-
moved. If it takes a long time, blow to the unit by an
electric fan to cool the unit.
1-5. Installation Space
When installing, the installation space must be secured in
consideration of the ventilation and service operation.
.Do not block the ventilation slots at the left side and
right side panels, and vents of the fans.
.Leave a space around the unit for ventilation.
.Leave more than 40 centimeters of space in the rear of
the unit to secure the operation area.
When the unit is installed on the desk or the like, leave at
least four centimeters of space in the left and right sides.
Leaving 40 centimeters or more of space above the unit is
recommended for service operation.
Dimensions when Rack-Mounting
nRemove the feet when rack mounting.

1-4
SRW-5000/5500
Specified Rack Mount Kit
RMM-110 (Optional accessory) or
RMM-111 (Optional accessory)
The color of rack angle of RMM-110 fits to the unit.
RMM-111 is the same consistency, strength and dimension
as RMM-110, but the color of rack angle is different.
m
.When mounting this unit into Sony LMS (Library
Management System) VTR console, it is necessary to
modify the VTR console.
.When mounting this unit into Flexicart, be sure to use
the specified kit below.
VTR Mounting Kit: BKFC-53/3
Parts Packed in RMM-110/111
.Slide rails ......................................... 2
.Rack angles (handles) ..................... 2
.Rail brackets .................................... 4
.Plate nuts (large) ............................. 4
.Plate nuts (small) ............................. 4
.Screws (PSW4 x 16) ...................... 4
.Screws (B4 x 8) .............................. 8
.Hexagon socket head cap screws .... 8
.Flat washers ..................................... 8
.Screws (RK5 x 14) ......................... 2
.Ornamental washers ........................ 2
.L-shaped hexagon wrench .............. 1
1-6. Rack Mounting
Explains how to mount this unit into a 19-inch standard
rack.
Be sure to mount this unit (*) into a rack accurately
following the procedure and notes mentioned below.
w
.To prevent toppling over the rack, fix it on the horizontal
and firm floor securely with bolts, etc.
.When installing the unit in an Outside Broadcasting van,
be sure to fix the unit to the rack using the screws and
ornamental washers supplied with the rack mount kit.
c
.Use the specified rack mount rail.
The use of other rail of low strength may drop the unit
and cause the risk of injury.
.Mount the unit into a rack with a steady posture.
m
.When other equipment with built-in hard disk drive is
already mounted in the same rack for mounting this unit,
turn off the power of the equipment before mounting this
unit.
.Connect long enough cables on the connector panel,
considering that the unit is pulled out from the rack.
.Do not operate this unit without the upper lid and bottom
plate except when servicing it.
.To reduce an increase in the internal temperature of this
unit, keep the following space away from walls.
Right, Left: 4 cm (1.6 inches) or more
Rear: 10 cm (4 inches) or more
.Adjust the temperature inside the rack within the range
of the unit’s operating temperature.
(Refer to Section 1-3.)

1-5
SRW-5000/5500
B3 x6
Lock plate
Lock plate
PS4 x20
Feet
PS4 x20
Feet
Spacers
Spacers
Rack Mounting Procedure
.Removing the feet
1. Set the unit its side panel down.
2. Remove the two screws and remove the lock plates.
3. Unscrew the four screws to remove the feet and
spacers from the bottom plate of the unit.
4. Set the unit in a horizontal position.
n
Keep these screws, spacers and the feet.
When operating the unit after demounting it from the rack,
be sure to reattach the feet.
Tightening torque: 98 x10 _2N.m {10 kgf.cm}
.Attaching the inner rails
5. Pull each inner rail from the two intermediate rails.
6. Pull each inner rail out of the intermediate rails while
pressing each stopper.
7. Remove the ten screws from both sides (left and right)
of the unit as shown in the figure below.
8. Attach the two inner rails to both sides (left and right)
of unit with the removed screws in the step 7.
Tightening torque: 120 x10 _2N.m {12.2 kgf.cm}
m
.Be sure to use the (B4 x 6) screws when attaching
the inner rail. The use other-sized screws may cause
a malfunction.
.Pay attention not to fasten the screws to the screw
holes other than actually used screw holes for fixing
the inner rails on both sides of the unit.
If unnecessary screws are fastened, rack mounting
will be unenabled.
B4 x6
Inner rail
Inner rail
B4 x6
Outer rail
Intermediate rail
Inner rail
Stopper
Pull out
Press

1-6
SRW-5000/5500
B4 x8
Plate nut (large) Rail bracket
Outer rail
Slide Intermediate
rail
Ball retainer
B4 x8
Plate nut (large)
Rail bracket
Outer rail
Intermediate rail
Slide
PSW4 x16
PSW4 x16
PSW4 x16
Rack angle
Rack angle
B4 x 6
B4 x 6
.Loosely attaching the rail brackets
11. Slide the intermediate rail as shown in the figure, and
then loosely attach the rear rail bracket to the outer rail
with a plate nut (large) and the two screws.
12. Slide the ball retainer in the direction of the arrow, and
then loosely attach the front rail bracket to the outer
rail with a plate nut (large) and the two screws.
.Attaching the rack angles (handles)
9. Remove the four screws from both sides (left and
right) of the unit.
n
Keep these screws (B4 x6).
Be sure to use these screws when directly fixing the
side panels without the rack angles.
The use of longer screws such as the screws (PSW 4 x
16) for fixing the rack angles will cause a malfunction
of the unit.
10. Attach the two rack angles to both sides (left and right)
of the unit with the four screws (PSW4 x16) supplied
with the rack mount kit.
Tightening torque: 120 x10 _2N.m {12.2 kgf.cm}

1-7
SRW-5000/5500
A'
A
Intermediate rails
Front side
Rear side
Rail bracket fixing screws
Rail bracket fixing screws
A = A' = 416 mm
Hexagon socket
head cap screw
2 pcs
Hexagon socket
head cap screw
2 pcs
Hexagon socket
head cap screw
2 pcs
Hexagon socket
head cap screw
2 pcs
2U
Plate nut (small)
Rail
Flat washer
Hexagon socket
head cap screw
L-shaped hexagon wrench
By 5U
.Attaching the outer rails
13. Loosely attach the two outer rails to the middle of the
5U space in the rack for mounting this unit, with the
eight hexagon socket head cap screws, eight flat
washers, and four plate nuts (small).
Rail bracket fixing screws
B4 x8
Rack
50 to 55 mm
Outer rail
Rack angle
Rail bracket
14. Check that the two intermediate rails attached to the
rack are parallel.
15. As shown in the following figure, adjust each front-
side position of the outer rails on both sides (left and
right) so that the distance from the surface of the rack
to the tip of the rail becomes within the range of 50 to
55 millimeters.
16. To fix the four rail brackets, fully tighten the eight
loosely fitted rail bracket fixing screws (B4 x 8) in
steps 11 and 12.
Tightening torque: 120 x10 _2N.m {12.2 kgf.cm}
17. To fix the two outer rails to the rack, fully tighten the
eight loosely fitted hexagon socket head cap screws in
step 13 using the L-shaped hexagon wrench.

1-8
SRW-5000/5500
Ornamental
washer
RK5 x14
Ornamental
washer
RK5 x14
Stopper
Stopper
Inner rail
Intermediate rail
Intermediate rail
Ball retainer
Front side
Slide
22. Slide the unit in and out from the rack about three
times and check that the slide rails move smoothly.
If they are not smoothly, demount the unit and go back
to “Attaching the outer rails”(step 13).
c
When demounting the unit, carry it by the two persons
or more.
n
This unit does not have the feet at this operating.
Put down the unit on the floor or other, being careful
not to damage the unit.
23. Push the unit in the depths of the rack. The unit is
fixed to the rack by the lock mechanism.
Attempt to pull the rack angles and confirm that the
unit cannot be pulled out of the rack.
24. Secure the unit to the rack with the four screws (RK5
x14) and four ornamental washers.
Tightening torque: 120 x10 _2N.m {12.2 kgf.cm}
.Mounting in rack
c
Be sure to carry the unit by the two persons or more.
18. Set each ball retainer to the position as shown in the
figure in the direction of the arrow.
19. Pull equal length of each rail on both sides out.
20. Lift the unit holding the gripes on both sides, slowly
insert the inner rails into the intermediate rails.
21. While pressing each stopper of inner rails on both
sides, slowly push the unit into the rack.
c
Be careful not to catch your finger or hand in rack
mount rail.

1-9
SRW-5000/5500
1-7. Matching Connectors and Cables
When external cables are connected to the connector of this unit, the hardware listed below (or equiva-
lents) must be used.
Panel indication Matching connector (cable) Sony part No. Remarks
TIME CODE IN XLR 3P, MALE 1-508-084-00
CUE IN
AUDIO OUTPUT XLR 3P, FEMALE 1-508-083-00
CUE OUT
MONITOR OUTPUT
TIME CODE OUT
REF. INPUT BNC 75Z, MALE 1-569-370-12
HD REF. OUT
SD OUT
AUDIO INPUT (AES/EBU) BNC 75Z, MALE (*1) 1-569-370-12
AUDIO OUTPUT (AES/EBU)
REMOTE 2 PARALLEL I/O (50P) D-SUB 50P, MALE and 1-565-516-11
JUNCTION SHELL 50P 1-563-379-11
REMOTE 1-IN (9P) 9P remote control cable (RCC-G series) _
REMOTE 1-I/O (9P) or or
D-SUB 9P, MALE and 1-560-651-00
JUNCTION SHEEL 9P 1-561-749-00
RS232C D-SUB 9P, FEMALE 1-563-815-21
VIDEO CONTROL (9P) D-SUB 9P, MALE and 1-561-651-00
JUNCTION SHELL 9P 1-561-749-00
HD SDI INPUT BNC 75Z, MALE (*2) 1-569-370-12
HD SDI OUTPUT
FORMAT CONV. OUT (OPTION)
FC OUT B (OPTION)
SD SDI OUT BNC 75Z, MALE (*3) 1-569-370-12
PHONES JM-60 stereo phone plug _Upper control panel
ETHERNET Separately available
USB Separately available
*1: Coaxial cable length : max. 600 meters (Reference value based on this unit)
It is recommended to connect the BELDEN 8281 cable or equivalent to this connector.
*2: Coaxial cable length : max. 100 meters (Reference value based on this unit)
It is recommended to connect the BELDEN 1694A cable or equivalent to this connector.
*3: Coaxial cable length : max. 200 meters (Reference value based on this unit)
It is recommended to connect the BELDEN 8281 cable or equivalent to this connector.

1-10
SRW-5000/5500
Reduced drawing of rear panel
5
12
3
4
1-8. Signal Inputs and Outputs
Input connectors
1TIME CODE IN XLR 3-pin x 1
Time code 0.5 to 18 V p-p, 10 kZ, balanced
1CUE IN XLR 3-pin x1
(SRW-5500 only) Analog audio
+4 dBm (Standard) 600 Ztermination, balanced (when ON)
+4 dBu (Standard), high impedance, balanced (when OFF)
2REF. INPUT 1 BNC x 4 (Loop through output x2)
REF. INPUT 2 (OPTION) External reference video signal
HD : 0.6 V p-p, 75 Z, sync negative (HD analog tri-level sync)
SD : 0.3 V p-p, 75 Z, sync negative (Black burst or composite sync)
3AUDIO INPUT (AES/EBU) BNC x 6 (1 set : CH1/2, CH3/4, CH5/6, CH7/8, CH9/10, and CH11/12)
AES/EBU digital audio
Complies with SMPTE 299M, SMPTE 276 (AES-3id-1995)
5HD SDI INPUT A BNC x 1 (outputs the input monitor x 1)
Serial digital interface (1.485 Gbit/s), complies with SMPTE 292M, SMPTE 372M
5HD SDI INPUT B (OPTION) BNC x 1 (outputs the input monitor x 1)
(Option HKSR-5003) Serial digital interface (1.485 Gbit/s), complies with SMPTE 292M, SMPTE 372M
Remote connectors
4REMOTE 2 PARALLEL I/O (50P) *D-SUB 50P connector
4REMOTE1-IN (9P) D-SUB 9P connector (RS-422A interface), Remote control
4REMOTE1-I/O (9P) D-SUB 9P connector (RS-422A interface), Remote control
4RS232C D-SUB 9P connector (RS-232C interface) for ISR (Interactive Status Reporting)
4VIDEO CONTROL (9P) D-SUB 9P connector for a HD digital video controller (HKDV-900) connection
4ETHERNET RJ-45 modular jack
Complied with 10BASE-T/100BASE-TX
4USB USB series B
Complied with USB standard Ver 1.1
*: Refer to Optional “Interface manual” for details.

1-11
SRW-5000/5500
Output connectors
1AUDIO OUTPUT XLR 3-pin x4 (1 set : CH1, CH2, CH3, and CH4)
Analog audio
+4 dBm (Standard) (600 Zload), low impedance, balanced
1CUE OUT XLR 3-pin x1
Analog audio
+4 dBm (Standard) (600 Zload), low impedance, balanced
1TIME CODE OUT XLR 3-pin x1
Time code 2.2 V p-p, low impedance, balanced
1MONITOR OUTPUT XLR 3-pin x2 (1 set : L and R)
Analog audio
+4 dBm (Standard) (600 Zload), low impedance, balanced
2HD REF. OUT BNC x2
0.6 V p-p, 75 Z, sync negative (HD analog tri-level sync)
2SD OUT COMPOSITE (MONITOR) BNC x1 (for character superimpose)
Analog composite video
VBS : 1.0 V p-p, 75 Z, sync negative
2SD OUT SYNC BNC x1
SYNC (NTSC/PAL) : 0.286/0.3 V p-p, 75 Z, sync negative
BURST (NTSC/PAL) : 0.286/0.3 V p-p, 75 Z, sync negative
3AUDIO OUTPUT (AES/EBU) BNC x6 (1 set : CH1/2, CH3/4, CH5/6, CH7/8, CH9/10, and CH11/12)
AES/EBU digital audio
Complies with SMPTE 299M, SMPTE 276M (AES-3id-1995)
5HD SDI OUTPUT A BNC x3 (including 1 for character superimpose)
Serial digital interface (1.485 Gbit/s), complies with SMPTE 292M, SMPTE 372M
5HD SDI OUTPUT B (OPTION) BNC x3 (including 1 for character superimpose)
(Option HKSR-5003) Serial digital interface (1.485 Gbit/s), complies with SMPTE 292M, SMPTE 372M
5SD SDI OUTPUT BNC x3 (including 1 for character superimpose)
Serial digital interface (270 Mbit/s), complies with SMPTE 259M, ITU-R BT.656
5FORMAT CONV. OUT (OPTION) BNC x2 (for character superimpose)
(Option HKSR-5001) Serial digital interface (1.485 Gbit/s), complies with SMPTE 292M, SMPTE 372M
5FC OUT B (OPTION) BNC x2 (for character superimpose)
(Option HKSR-5001) Serial digital interface (1.485 Gbit/s), complies with SMPTE 292M, SMPTE 372M
PHONES JM-60 stereo phone jack
(Upper control panel) Analog audio
up to _12 dBu (8 Zload), unbalanced
Other
Memory stick Memory stick x1
(Lower control panel) Applicable memory stick : 8 MB to 128 MB
n
The memory card (PCMCIA type) can be used by removing the memory stick adaptor
under the lower control panel.
For removing the memory stick adaptor, refer to the maintenance manual volume 1.

1-12
SRW-5000/5500
117
External view
3450
33 18
REMOTE 2 PARALLEL I/O: 50-pin (female)
Pin No. I/O **
**
*1Setting change **
**
*2Signal Description
1INOFF CLOSURE SW (FF)
2 OUT XREC SW PANEL REC SW OUT
3 OUT XPLAY SW PANEL PLAY SW OUT
4 OUT XSTOP SW PANEL STOP SW OUT
5 OUT XENTRY SW PANEL ENTRY SW OUT
6 OUT XREF SYSTEM ALARM Non-REFERENCE
7 OUT XCF LOCK COLOR FRAME LOCK STATUS
8 OUT XDRUM LOCK LOCK STATUS OF DRUM SERVO
9 OUT XCAP LOCK LOCK STATUS OF CAPSTAN SERVO
10 OUT OCUE PRESET EDIT PRESET STATUS of the CUE Channel
11 OUT OTC PRESET EDIT PRESET STATUS of the TC Channel
12 OUT OCASSETTE OUT/IN CASSETTE OUT/IN STATUS
13 OUT OTAPE HDCAM SR TAPE STATUS
14 OUT XSPARE SPARE
15 OUT XSPARE SPARE
16 —— —— +12V (Maximum output current 50 mA)
17 —— —— GND SIGNAL GND
18 IN OPREROLL CLOSURE SW (PREROLL)
19 IN OSTBY ON CLOSURE SW (STANDBY ON)
20 IN OREW CLOSURE SW (REW)
21 IN OENTRY IN CLOSURE SW (ENTRY IN)
22 IN OSTBY OFF CLOSURE SW (STANDBY OFF)
23 IN OEJECT CLOSURE SW (EJECT)
24 OUT XREC REC STATUS
25 OUT XCH CONDITION RED CHANNEL CONDITION RED STATUS
26 OUT OASSEMBLE PRESET ASSEMBLE PRESET STATUS
27 OUT OEDIT OUT EDIT STATUS
28 OUT OEJECT OUT EJECT STATUS
29 OUT OETHERNET ETHERNET STATUS
30 OUT OREEL HUB REEL HUB STATUS
31 OUT XCURRENT SETUP DATA CHANGE CURRENT SETUP DATA CHANGE STATUS
32 OUT XALL REC INHIBIT ALL REC INHIBIT STATUS
33 —— —— GND
34 IN OPLAY CLOSURE SW (PLAY)
35 IN OSTOP CLOSURE SW (STOP)
(Continue)

1-13
SRW-5000/5500
External view
51
69
External view
15
96
(Continued)
Pin No. I/O **
**
*1Setting change **
**
*2Signal Description
36 IN OREC CLOSURE SW (REC)
37 OUT XREV LAMP REV LAMP STATUS
38 OUT ODA2 PRESET DA2 EDIT PRESET STATUS
39 OUT ODA1 PRESET DA1 EDIT PRESET STATUS
40 OUT XFWD LAMP FWD LAMP STATUS
41 OUT ODA4 PRESET DA4 EDIT PRESET STATUS
42 OUT ODA3 PRESET DA3 EDIT PRESET STATUS
43 OUT XSTOP STOP STATUS
44 OUT OVIDEO PRESET VIDEO EDIT PRESET STATUS
45 OUT OINSERT PRESET INSERT EDIT PRESET STATUS
46 OUT XSTBY ON STANDBY ON STATUS
47 OUT XPLAY PLAY STATUS
48 OUT XREMOTE REMOTE STATUS
49 OUT XALARM SYSTEM ALARM STATUS
50 OUT OPREROLL PREROLL STATUS
*1: Input ; 47 kZpull up to +5 V (close/open)
Output ; 10 kZpull up to +5 V (0 V or open)
*2: The pins described as Omark are possible to change the setting.
Refer to the optional interface manual for changing the setting.
RS232C: 9-pin (male)
REMOTE 1-IN: 9-pin (female)
REMOTE 1-I/O: 9-pin (female)
Pin No. Signal
1 GND
2 RM TX(_)
3 RM RX(+)
4 GND
5 PRIORITY
6 GND
7 RM TX(+)
8 RM RX(_)
9 GND
Pin No. Signal
1 DCD ; Data Carrier Detect (Input)
2 RXD ; Received Data (Input)
3 TXD ; Transmitted Data (Output)
4 DTR ; Data Terminal Ready (Output)
5 SG ; Signal Ground
6 DSR ; Data Set Ready (Input)
7 RTS ; Request to Send (Output)
8 CTS ; Clear to Send (Input)
9NC

1-14
SRW-5000/5500
12
43
External view
81
External view
External view
15
96
USB: USB series B
Standard : USB standard Ver1.1
Pin No. I/O Signal
1–Vcc (+5 V)
2 I/O DATA (_)
3 I/O DATA (+)
4–GND
1-9. Switch Settings on Connector Panel
When the unit is installed, be sure to perform the following
setup.
Refer to the operation manual “Section 2 Location and
Function of Parts”for setup.
.75 Ztermination switch of reference video input
.600 Ztermination switch of CUE input
VIDEO CONTROL: 9-pin (female)
Pin No. Signal
1 GND
2 RM TX (_)
3 RM RX (+)
4 GND
5——
6 GND
7 RM TX (+)
8 RM RX (_)
9 GND
ETHERNET: RJ-45 modular jack
Standard : Complied with IEEE 802.3u (100BASE-TX)
and IEEE 802.3 (10BASE-T)
Pin No. I/O Signal
1 O TXD (+)
2 O TXD (_)
3 I RXD (+)
4—NC
5—NC
6 I RXD (_)
7—NC
8—NC
