Soul SV3 User manual

SV3
Pro Hi-Definition Wireless
On-Ear Headphones
User Manual
2To answer a call, press the multifunction button or use the keys on the
phone.
To reject the call, press and hold the multifunction button for about 1
seconds.
To end a call, press the multifunction button or use the keys on the phone.
Note: If you receive or make a call while listening to music, the music will stop
automatically until the call is ending. To pause or resume playing, press the
multifunction button. To stop playing music, press the multifunction button again.
3
4
BUTTON FUNCTION CHART (BLUETOOTH SOURCE)
FUNCTION BUTTON
SYMPTOM SOLUTION
OPERATION
Turn On
Turn Off
Answer Call
End Call
Refuse Call
Last Call Redial
Volume Up
Forward track
Volume Down
Backward track
Pair
Multifunction Button
Multifunction Button
Multifunction Button
Multifunction Button Single Press
Single Press
Single Press
Single Press
Single Press
Double Press (quickly)
Multifunction Button
Multifunction Button
Multifunction Button
Multifunction Button
Multifunction Button
Volume up button
Volume up button
Volume down button
Volume down button
Press and hold (Approximately 4s)
Press and hold (Approximately 6s)
LEDs are not lighting up
Unable to Pair with
Bluetooth devices
Hearing Distortion
Press and hold (Approximately 3s)
Press and hold (Approximately 1s)
Press and hold
Single Press
Press and hold
Pause（Music Mode）
Play（Music Mode）
TROUBLE SHOOTING
See below for solutions to common problems.
Power button is not turned on. The battery is out of power.
Charge your device.
Confirm that your phone/music player is Bluetooth
compatible.
Failed to pair successfully within 3 minutes. Please repeat the
pairing procedure.
Make sure the input password is correct if required.
Lower Volume on your phone/music player/device. Charge
your device.
Don’t turn on too many headsets and Bluetooth devices at the
same time when connecting. Please turn off other headsets
and turn on the paired headset in order to avoid interference.
Make sure the blue LED is flashing quickly(under pairing
mode)
Clear the pairing list on your phone and try again.
SAFETY INFORMATION
Follow these tips and safety instructions to preserve the operational lifespan of
your Bluetooth Stereo Headset:
SPECIFICATIONS
Bluetooth 4.0 + EDR
Handsfree Profile (HFP) for talking and operating the
phone
Advanced Audio Distribution Profile (A2DP) for audio
streaming
Audio Video Remote Control Profile (AVRCP) for music
control
Call time up to 12 hours, music time up to 10 hours (Varies
by volume level and content)
Up to 15 days
Approx. 3 hrs from empty to full charge
33 ft (10m)
Omni-directional
Lithium ion polymer
Bluetooth® Version:
Bluetooth® Profiles:
Battery Life:
Standby Time:
Charging Time:
Bluetooth® Range:
Microphone:
Battery Type:
1
2
Do not use this headset in extreme temperatures. Keep away from extreme
hot, cold, dry, or damp areas. Also keep away from water, fire, and
radiation.
It is recommended that you allow the battery to fully charge before using the
device for the first time. (approximately 3 hours. Do not recharge
unattended for longer than 8 hours)
The effective range for this wireless device is 10 Meters. Performance may
be affected by distance and interference from other devices or conditions
within the operating environment.
Barriers and other wireless devices may affect the performance of headset.
Check the laws and regulations on the use of mobile phones and
hands-free equipment in areas you intend to use this product.
3
4
5
Compliance with FCC rules (U.S.A., only)
This device complies with Part 15 of the FCC rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.
FCC WARNING
• Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
this equipment.
• Proper connections must be used for connection to a host computer
and/or peripherals in order to meet FCC emission limits.
WARNING
5
1
2
Permanent hearing damage or hearing loss may occur if earphones are used at
a high volume. Hearing experts suggest not continuously listening to music at a
high volume. If you hear a “hissing” noise in your ears, or if you experience
discomfort, lower the volume, or temporarily discontinue use of this product until
discomfort subsides.
Do not disassemble your Bluetooth Stereo Headset.
Do not allow young children to use your Headset unsupervised.
Observe all signs and instructions that require an electrical device or radio
product to be switched off in designated areas, such as petrol/refueling stations,
hospitals, blasting areas, potentially explosive atmospheres or aircraft.
Do not use or connect adaptors and/or chargers to this product that are not
approved of or specified in this quick start guide.
3
4
!

Bluetooth stereo headset
Micro-USB cable
3.5mm stereo cable
Carrying Pouch
CONTENTS
Volume up button/Forward track
Blue/Red LED
Volume down button/Backward track
Multifunction button (Power on/off, Pairing,
Answer call/End call/Reject call, Play/Pause)
Micro-USB jack for charging
3.5mm AUX jack
Microphone
Adjustable headband
Foldable design
A
B
D
E
F
G
H
1
2
3
2
1
4
3
4
I
LAYOUT AND CONTROLS
BASIC OPERATIONS
1
2
CHARGING THE BATTERY
The LED will continually flash when battery power is low. When the battery is
completely drained, no indicator light will work. Before using, allow the battery
to charge for at least 3 hours.
Connect the Micro-USB cable to the USB Jack on your headset.
Connect the USB end to a USB port on your computer or Laptop.
1
3
4
5
2
If the headset has not been previously paired with a device, press and hold
the multifunction button for about 6 seconds until the blue/red LEDs light
flash quickly, indicating that the device is in “pairing” mode.
If the headset has been previously paired with the device, you just need to
press and hold the multifunction button for about 4 seconds until the blue
indicator light is on and flashes slowly which indicates standby mode, and
then headset could connect to the device (its Bluetooth function should be
turned on) automatically.
Turn on Bluetooth function on the device, and set it to search for Bluetooth
devices.
Once the device is discovered, make the connection by selecting “SOUL
SV3”.
Enter “0000” if a passcode is asked.
POWER ON/OFF
To switch the headset on, press and hold the multifunction button for about 4
seconds and then release.
Note: If the Bluetooth Stereo Headset has already been paired or connected to
another Bluetooth device before, the Blue LED light will slowly flash as the headset
automatically attempts to reconnect to the paired device. If the headset is unable to
locate a device within 5 minutes, it will be in standby state, and if the headset is unable
to locate a device within 30 minutes, it will shut down automatically.
To turn the power off, press and hold the multifunction button for about 3 seconds and
then release. The red LED will light for 1 second, then all LED lights will go off.
PAIRING HEADSET WITH BLUETOOTH ENABLED
DEVICES
WHEN CHARGING
The blue LED will flash slowly during charging.
WHEN FULLY CHARGED
The blue LED indicator will light up.
DISCONNECTING THE HEADSET
Switch off the headset, or disconnect it in the Bluetooth menu of your device.
You do not need to delete pairing with the headset to disconnect it.
Note: If you have paired and connected the headset with one of your Bluetooth
device, disconnect the headset from it before pairing the headset with another
Bluetooth device, and then follow the instructions in the section above to pair and
connect again.
RECONNECT HEADSET
To connect the headset to the mobile phone or music player that you have last
used:
Switch on the headset, and open the Bluetooth function of your device. In your
device, you may be able to allow the headset to connect to it automatically. For
further instructions, refer to your device’s user’s guide.
USING THE HEADSET
Place headset on your ears by matching the L/R markers to your ears
accordingly. Adjust the length of the headband until the speaker pads rest
comfortably on your ears.
1
2
Pair and connect the headset to a Bluetooth device such as a mobile
phone and music player. Then press the multifunction button. The music
player must support the A2DP Bluetooth profile. The music functions
available depend on your mobile phone or music player.
To control forward track, backward track, press and hold the volume up
or down button to have “Forward or Backward track” function.
To adjust the headset volume, single press the volume up or down button
to adjust volume during a call or while listening to music.
To listen to music from wired audio source, connect 3.5mm stereo cable
from AUX jack to music player such as MP3, PC, CD player, etc. You will
be able to adjust the volume or track on player only.
3
LISTEN TO MUSIC
Note: Audio content via 3.5mm stereo cable will override wireless audio via
Bluetooth
4
CALL HANDLING
1To make a call, while connected to the headset, use your mobile phone
and dial as you normally do. And double press the multifunction button of
headset can redial last call directly.

Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
