Sound Sation hyper bass series User manual

Hyper TOP series
PROFESSIONAL active speakers
Please read this manual carefully and properly take care of it
USER MANUAL
Leggete questo manuale e conservatelo per future consultazioni
MANUALE UTENTE

Dear customer,
First of all thanks far purchasing a SOUNDSATION® product. Our mission is to satisfy
all possible needs of musical instrument and professional audio users oering a wide
range of products using the latest technologies.
We hope you will be satised with this item and, if you want to collaborate, we are
looking for a feedback from you about the operation of the product and possible
improvements to introduce in the next future. Go to our website www.soundsation-
music.com and send an e-mail with your opinion, this will help us to build instruments
ever closer to customer’s real requirements.
One last thing: read this manual before using the instrument, an incorrect operation
can cause damages to you and to the unit. Take care!
The SOUNDSATION Team
Gentile Cliente,
Grazie per aver scelto un prodotto SOUNDSATION®. La nostra missione è quella di
orire ai nostri utenti una vasta gamma di strumenti musicali ed apparecchiature audio
e lighting con tecnologie di ultima generazione.
Speriamo di aver soddisfatto le vostre aspettative e, se voleste collaborare, saremmo
lieti di ricevere un vostro feedback sulla qualità del prodotto al ne di migliorare co-
stantemente la nostra produzione. Visitate il nostro sito www.soundsationmusic.com ed
inviateci una mail con la vostra opinione, questo ci aiuterà a sviluppare nuovi prodotti
quanto più vicini alle vostre esigenze.
Un’ultima cosa, leggete il presente manuale al ne di evitare danni alla persona ed al
prodotto, derivanti da un utilizzo non corretto.
Il Team SOUNDSATION

3
ENGLISH
TABLE OF CONTENTS
1. BEFORE YOU START...................................................................................................5
1.1. Accessories...............................................................................................................................................................5
2. OVERVIEW..................................................................................................................6
2.1. Hyper Top Active Series.......................................................................................................................................7
3. SETUP..........................................................................................................................7
3.1. Connections .............................................................................................................................................................7
3.2. Fixed Installation ....................................................................................................................................................8
4. REAR PANEL DESCRIPTION......................................................................................9
4.1. Hyper Top 6A...........................................................................................................................................................9
4.2. Hyper Top 8A.........................................................................................................................................................10
4.3. Hyper Top 10A, 12A, 15A..................................................................................................................................12
5. HOOKUP DIAGRAMS ..............................................................................................14
5.1. Examples of Input connections ......................................................................................................................14
5.2. Stereo Operation with a Mixer........................................................................................................................14
5.3. Bi-Amping with HYPER BASS Active Subs..................................................................................................15
6. INSTALLATION.........................................................................................................15
6.1. Wall-Mount Brackets for HYPER TOP 6-8-10A.........................................................................................16
6.2. Wall-Mount Speaker Stand..............................................................................................................................18
6.3. Hanging with Eye-bolts.....................................................................................................................................19
7. SPECIFICATIONS ......................................................................................................20
8. WARRANTY AND SERVICE .....................................................................................22
9. WARNING ................................................................................................................22
IMPORTANT SAFETY SYMBOLS
The symbol is used to indicate that some hazardous live terminals are
involved within this apparatus, even under the normal operating con-
ditions, which may be sucient to constitute the risk of electric shock
or death.
The symbol is used in the service documentation to indicate that spe-
cic component shall be replaced only by the component specied in
that documentation for safety reasons.

4
ENGLISH
Hyper TOP series User manual
Protective grounding terminal
Alternating current/voltage
Hazardous live terminal
Denotes the apparatus is turned on
Denotes the apparatus is turned o
WARNING: Describes precautions that should be observed to prevent the danger
of injury or death to the operator.
CAUTION: Describes precautions that should be observed to prevent danger of
the apparatus.
TAKING CARE OF YOUR PRODUCT
fRead these instructions
fKeep these instructions
fHeed all warning
fFollow all instructions
1) Water / Moisture
The apparatus should be protected from moisture and rain and can not be used near
water; for example near a bathtub, a kitchen sink, a swimming pool, etc.
2) Heat
The apparatus should be located away from heat sources such as radiators, stoves or
other appliances that produce heat.
3) Ventilation
Do not block areas of ventilation opening. Failure to do could result in re. Always
install according to the manufacturer’s instructions.
4) Object and Liquid Entry
Objects do not fall into and liquids are not spilled into the inside of the apparatus for
safety.
5) Installation
Always secure speakers using safety chain sand carrying handles. Never carry the unit
by its cord.
6) Power Cord and Plug
Protect the power cord from being walked on or pinched particularly at plugs, conve-
nience receptacles, and the point where they exit from the apparatus. Do not defeat
the safety purpose of the polarized or grounding-type plug. A polarized plug has two
poles; a grounding-type plug has two poles and a third grounding terminal. The third
prong is provided for your safety. If the provided plug does not t into your outlet,

5
ENGLISH
Hyper TOP series User manual
refer to an electrician for replacement.
7) Fuse
To prevent the risk of re and damaging the unit, please use only of the recommend-
ed fuse type as described in the manual. Before replacing the fuse, make sure the unit
turned o and disconnected from the AC outlet.
8) Electrical Connection
Improper electrical wiring may invalidate the product warranty.
9) Cleaning
Clean only with a dry cloth. Do not use any solvents such as benzene or alcohol.
10) Servicing
Do not implement any servicing other than those means described in the manual. Refer
all servicing to qualied service personnel only. Only use accessories/attachments or
parts recommended by the manufacturer.
11) Warning
Please remember the high sound pressure do not only temporarily damage your sense
of hearing, but can also cause permanent damage. Be careful to select a suitable vol-
ume.
1. BEFORE YOU START
Thank you for purchasing HYPER TOP Series active speakers. Each unit has been well
tested and shipped in perfect operating conditions. Carefully unpack the carton and
check the contents to ensure that all parts are present and in good conditions:
f1 Loudspeaker
f1 Power cable
f1 User manual
If anything damaged during transport, notify the shipper immediately and keep pack-
ing material for inspection. Again, please save the carton and all packing materials. If
the unit must be returned to the manufacturer, it is important that the unit is returned
in the original manufacturer’s packing. Please do not take any action without rst con-
tacting us.
WARNING: Packaging box is not a toy! Keep out of reach of children!!! Keep
in a safe place the original packaging material for future use.
1.1. Accessories
SOUNDSATION can supply a wide range of quality accessories that you can use with
HYPER TOP speaker, like Brackets, Dust Covers, Mixers, Cables, Microphones, etc. The
main accessories are listed below.

6
ENGLISH
Hyper TOP series User manual
SKU Description
E872E HYPER TOP 6A WALL-MOUNT BRACKET
E873E HYPER TOP 8A WALL-MOUNT BRACKET
E874E HYPER TOP10A WALL-MOUNT BRACKET
N162N WSS-08 WALL-MOUNT STAND FOR HYPER TOP SERIES
E867E DUST COVER FOR HYPER TOP 6A
E868E DUST COVER FOR HYPER TOP 8A
E869E DUST COVER FOR HYPER TOP 10A
E870E DUST COVER FOR HYPER TOP 12A
E871E DUST COVER FOR HYPER TOP 15A
Wall- Mount Bracket for
HYPER TOP 6-8-10A
Wall- Mount Bracket for
HYPER TOP Series
Dust Cover for
HYPER TOP Series
All products in our catalogue has been long tested with these devices so we recom-
mend to use Genuine SOUNDSATION accessories and spare parts. Ask your SOUND-
SATION dealer for any accessories you could need to ensure best performance of the
product or visit our website www.soundsationmusic.com.
2. OVERVIEW
HYPER TOP Series speakers are part of a wider range of SOUNDSATION Pro Audio
product line. These active speakers are compact, lightweight and very easy to use. They
are ideal for any live music or xed installation purpose.
Make sure there is enough space around the unit for proper ventilation and prevent
overheating; do not place the unit on top of hot devices such as radiators or power
ampliers. The speaker is connected to mains through the supplied cable. The product
meets the required safety standards.
Make sure that all units must be properly grounded. For your safety, you
should never remove any ground connector from electrical devices or power
cables, or make them inoperative.
Our products are subject to a process of continual further development. Therefore
modications to the technical features remain subject to change without further notice.

7
ENGLISH
Hyper TOP series User manual
2.1. Hyper Top Active Series
HYPER TOP ACTIVE Series is the result of years of experience gathered by SOUNDSA-
TION in Portable Sound System market, a segment where quality, versatility and value
for money are absolutely essential.
It consists of 5 two-way PP active speakers with woofers from 6” to 15” - called HYPER
TOP Series - and 3 bass-reex active subwoofers from 1x12 “to 1x18” with birch ply-
wood enclosures - called HYPER BASS Series.
The HYPER TOP series features 4 Bi-Amped models with Class-D ampliers on low
frequencies and Class-AB con high - from 240W to 500W rated powers - driving 8” to
15” high-performance woofers; and a smart and extremely versatile 2-way active model
with 100W Class-AB amp module on a 6” high-excursion woofer.
All models have got a sturdy, lightweight and stylish PP enclosure with full metal grille
and acoustic fabric behind to protect the transducers and give a pleasant look. Further-
more, they feature four M8 xing points (1 on each side), a dierent number of handles
(from 1 on top for the 6” model to 3 for the 15” model) and a standard D36mm pole
mount hole, in order to allow any xed installation or portable applications as well as
easily move them everywhere.
3. SETUP
3.1. Connections
1) Mains Connections
Connect the device to the mains with the power-plug. The wire correspondence is as
follow:
Cable Pin International
Brown Live L
Blue Neutral N
Yellow/Green Earth
The earth must to be connected! Pay attention to the safety! Before taking
into operation for the rst time, the installation has to be approved by an
expert.
2) Audio Connections
You will need several cables for the various connections to and from the speaker. See
the pictures below that show the internal wiring of these cables.

8
ENGLISH
Hyper TOP series User manual
Balanced use of XLR connectors
1= Ground/Shield
2= Hot (+)
3= Cold (-)
INPUT OUTPUT
In case of unbalanced use Pins 1 and 3 will be jumped
Use commercial RCA cables to wire stereo unbalanced sources with RCA output con-
nectors to stereo RCA LIne inputs of HYPER TOP units. You can, of course, also connect
unbalanced equipment to balanced inputs.
Unbalanced use of 1/4” jack TS connector
Strain relief
clamp
Sleeve
Tip
Sleeve
(Ground shield)
Tip
(Signal)
Balanced use of 1/4” jack TRS connector
Headphones connection with 1/4” TRS connector
Strain relief
clamp
Sleeve
Tip
Sleeve
Ground shield
Ring Ring
Cold (-)
Tip
Hot (+)
Use either mono and stereo jack, making sure ring and collar are connected together
(or pins 1 & 3 in the case of XLR connectors)
3.2.Fixed Installation
The installation of HYPER TOP speakers has to be built and constructed in a way that it
can hold 10 times the weight for 1 hour without any harming demolishment. The instal-
lation must always be secured with a secondary safety attachment, e.g. an appropriate
security wire. This secondary safety attachment must be constructed in a way that no
part of the installation can fall down if the main attachment fails.
Pay attention to the safety! Please respectively consider the EN 60598-2-17
and the national standard during the installation. The authorized dealer must
only carry out the installation.
When rigging, de-rigging or servicing the unit, staying in the area below the installation
place, on bridges, under high working places and other endangered areas is forbidden.
The operator has to make sure that the safety measure and the unit’s technical instal-
lation is approved by an expert before taking into operation for the rst time and after
changes before taking into operation another time.
IMPORTANT: Overhead rigging requires extensive experience, including (but
not limited to) calculating working load limits, installation material being
used, and periodic safety inspection of all installation material and the pro-

9
ENGLISH
Hyper TOP series User manual
jector. If you lack these qualications, do not attempt the installation your-
self, but instead use a professional structural rigger. Improper installation can
result in bodily injury or property loss.
If the unit shall be lowered from the ceiling or high joists, professional trussing systems
have to be used. The speaker must never be xed swinging freely in the room.
CAUTION: Speakers may cause severe injuries when crashing down. If you
have doubts concerning the safety of a possible installation, do not install
the unit!
4. REAR PANEL DESCRIPTION
HYPER TOP Series active loudspeakers have several connectors, controls, and indicators
the use of which you should understand.
4.1. Hyper Top 6A
1) IEC Socket with Fuse holder
Plug the line cord into an AC socket proper-
ly congured for your particular model. In
case of fuse burn, to prevent the risk of re
and damaging the unit, please use only of
the recommended fuse type as described in
the manual. Before replacing the fuse, make
sure the unit turned o and disconnected
from the AC outlet.
Note: If it happens to loose the AC
line-cord, always use a three-pin
plug with a ground pin.
2) POWER Switch
Switch up to turn the speaker on, and
switch down to turn it o. Make sure the
level control is down before you turn it on.
3) MIC/LINE INPUT
There is a female XLR-type connector and
a 1/4” Jack plug that accept a balanced or
unbalanced mic- or line-level signal. The
switch Line/Mic has to be pressed in case of
microphone level signals. There is no phan-
tom power for a microphone, so you should
use a dynamic mic, or use a condenser type
HYPER TOP 6A
Power
ON
OFF
010010-10 +10
-10 +10
MIC/LINE INLINE IN EQ
VOL 1VOL 2 HIGH
LOW
CLIP
POWER
L/R
mix out
AC INPUT
AC 230V 50HZ
T1.0A/250V
LINE
MIC
1
2
3
4
5 6 7
8
9
10

10
ENGLISH
Hyper TOP series User manual
if it has its own battery power.
WARNING: Pressing MIC/LINE switch on line level signals may cause damag-
es to the speaker. Be careful!
4) MIC/Line LEVEL
This controls the overall signal level at the Mic-Line inputs.
5) Line LEVEL
This controls the overall signal level at the stereo mini jack plug and RCA inputs.
6) POWER on indicator
When POWER switch is turned on, and line-cord is connected to an active AC Mains
supply, this indicator is lit.
7) CLIP indicator
This LED lights up only when the input signal is too high and limiter operates in order
to prevent unwanted damage to amplier or transducers.
NOTE: To better adjust levels and avoid limiter to intervene and cut signals,
once connected the desired sound source, slowly turn up MIC/LINE or LINE
LEVEL controls until the desired volume is reached (and the CLIP light comes
on occasionally). Always protect your hears if you are close when it is playing
at high levels.
8) EQ
This 2-band EQ optimizes the frequency response in order to better adapt the speaker
to the environment in which it is used.
9) MIX Out
This is a male XLR-type connector that produces a “EQed” mix of both Mic/Line Inputs.
Use it to daisy-chain several active monitors together.
10) Line In Input section
There is a pair of RCA plugs and a 1/8” mini jack plug that accept a unbalanced
line-level signals.
4.2.Hyper Top 8A
1) POWER Switch
Switch up to turn the speaker on, and switch down to turn it o. Make sure the level
control is down before you turn it on.
2) IEC Socket with Fuse holder
Plug the line-cord into an AC socket properly congured for your particular model. In
case of fuse burn, to prevent the risk of re and damaging the unit, please use only
of the recommended fuse type as described in the manual. Before replacing the fuse,

11
ENGLISH
Hyper TOP series User manual
make sure the unit turned o and discon-
nected from the AC outlet.
Note: If you happen to loose the AC
line-cord, always use a three-pin plug
with a ground pin.
3) MIX Out
This is a male XLR-type connector that pro-
duces a EQed mix of both Mic/Line Inputs.
Use it to daisy-chain several active monitors
together.
4) MIC/LINE INPUT Section
There is a female XLR-type connector and
a 1/4” Jack plug that accept a balanced or
unbalanced mic- or line-level signal. The
switch Line/Mic has to be pressed in case of
microphone level signals. There is no phan-
tom power for a microphone, so you should
use a dynamic mic, or use a condenser type
if it has its own battery power.
WARNING: Pressing MIC/LINE switch
on line level signals may cause dam-
ages to the speaker. Be careful!
5) MIC/Line LEVEL
This controls the overall signal level at the Mic-Line inputs.
6) EQ
This 2-band EQ optimizes the frequency response in order to better adapt the speaker
to the environment in which it is used.
7) CLIP indicator
This LED lights up only when the input signal is too high and limiter operates in order
to prevent unwanted damage to amplier or transducers.
NOTE: To better adjust levels and avoid limiter to intervene and cut signals,
once connected the desired sound source, slowly turn up LEVEL control until
the desired volume is reached (and CLIP light comes on occasionally). Always
protect your hears if you are close when it is playing at high levels.
8) POWER ON Indicator
When POWER switch is turned on, and the line-cord is connected to an active AC Mains
supply, this indicator is lit.
AC INPUT
AC 230V 50HZ
T2.0A/250V
Power
ON
OFF
HYPER TOP 8A
inputmic/line high
low
link
out
CLIPPOWER
MIC/LINE levelEQ
010-10 +10
-10 +10
LINE
MIC
5
1
2
4
6
7
8
3

12
ENGLISH
Hyper TOP series User manual
4.3.Hyper Top 10A, 12A, 15A
1) POWER Switch
Switch up to turn the speaker on, and switch
down to turn it o. Make sure the level con-
trol is down before you turn it on.
2) IEC Socket with Fuse
holder
Plug the line-cord into an AC socket properly
congured for your particular model. In case
of fuse burn, to prevent the risk of re and
damaging the unit, please use only of the
recommended fuse type as described in the
manual. Before replacing the fuse, make sure
the unit turned o and disconnected from
the AC outlet.
Note: If you happen to loose the AC
line-cord, always use a three-pin plug
with a ground pin.
3) MIC/LINE INPUT Section
There is a female XLR-type connector and
a 1/4” Jack plug that accept a balanced or
unbalanced mic- or line-level signal. The
switch Line/Mic has to be pressed in case of
microphone level signals. There is no phan-
tom power for a microphone, so you should
use a dynamic mic, or use a condenser type if
it has its own battery power.
WARNING: Pressing MIC/LINE switch on line level signals may cause damag-
es to the speaker. Be careful!
4) Aux In
This is a 1/8” mini jack plug that accept an unbalanced stereo line-level signal. This
auxiliary input is directly routed to EQ and master Level controls.
WARNING: Turn the LEVEL (control n. 8) down (counterclockwise) before
connecting any source, especially if you’re using the LINE OUT connection. If
not, you could be in for a startling surprise and this may cause a damage to
the unit and to your hearing.
5) Level 1
This controls the overall signal level at the Mic-Line inputs.
Power
ON
OFF
signal flow
mic/line in line in master
mic inline in
stereo
line in line out
HYPER TOP 15A
in
level 1 level 2
LINE
MIC
high lowlevel
010 010 -10 +10 -10 +10 010
on
limit
aux in
AC INPUT
AC 230V 50HZ
T2.0AL/250V
5
1
2
3
4
6 7 8
9
10
11
12

13
ENGLISH
Hyper TOP series User manual
6) Level 2
This controls the overall signal level at the stereo mini jack plug and RCA inputs.
7) High/Low
This 2-band EQ optimizes the frequency response in order to better adapt the speaker
to the environment in which it is used.
8) Level (Master)
This controls the overall signal level of all inputs, including the AUX Input.
9) POWER
When the POWER switch is turned on and the line-cord is connected to an active AC
Mains supply, this indicator is lit.
10) Limit
This LED lights up only when the input signal is too high and limiter operates in order
to prevent unwanted damage to amplier or transducers.
NOTE: To better adjust levels and avoid limiter to intervene and cut signals,
once connected the desired sound source, slowly turn up LEVEL 1 or 2 and
MASTER LEVEL control until the desired volume is reached (and the LIMIT
light comes on occasionally). Always protect your hears if you are close when
it is playing at high levels.
11) Line Out
This is a male XLR-type connector that produces a “EQed” mix of both Mic/Line Inputs.
Please notice that this output is not aected by Master Level control. Use it to dai-
sy-chain several active speakers together.
12) Line In Input section
There is a pair of RCA plugs and a 1/8” mini jack plug that accept a unbalanced
line-level signals.

14
ENGLISH
Hyper TOP series User manual
5. HOOKUP DIAGRAMS
5.1. Examples of Input connections
HYPER TOP 6A
0 10 0 10 -10 +10
-10 +10
MIC/LINE IN LINE IN EQ
VOL 1 VOL 2 HIGH
LOW
CLIP
POWER
L/R
mix out
LINE
MIC
Keyboard usign a 1/4” jack unbalanced LINE input
(remember to leave LINE/MIC switch off)
Dinamic microphone, usign an XLR balanced MIC input
(remeber to press LINE/MIC switch)
MP3 player, usign a stereo mi-
ni-jack unbalanced LINE input
CD player, usign a stereo RCA
unbalanced LINE input
5.2. Stereo Operation with a Mixer
Power
ON
OFF
signal flow
mic/line in linein master
mic in line in stereo
line in line out
HYPER TOP 15A
in
level 1 level 2
LINE
MIC
high low level
010 010 -10 +10 -10 +10 010
on
limit
aux in
AC INPUT
AC 230V 50HZ
T2.0AL/250V
Power
ON
OFF
signal flow
mic/line in linein master
mic in line in stereo
line in line out
HYPER TOP 15A
in
level 1 level 2
LINE
MIC
high low level
010 010 -10 +10 -10 +10 010
on
limit
aux in
AC INPUT
AC 230V 50HZ
T2.0AL/250V
Power
ON
OFF
signal flow
mic/line in linein master
mic in line in stereo
line in line out
HYPER TOP 15A
in
level 1 level 2
LINE
MIC
high low level
010 010 -10 +10 -10 +10 010
on
limit
aux in
AC INPUT
AC 230V 50HZ
T2.0AL/250V
Power
ON
OFF
signal flow
mic/line in linein master
mic in line in stereo
line in line out
HYPER TOP 15A
in
level 1 level 2
LINE
MIC
high low level
010 010 -10 +10 -10 +10 010
on
limit
aux in
AC INPUT
AC 230V 50HZ
T2.0AL/250V
Power
ON
OFF
signal flow
mic/line in linein master
mic in line in stereo
line in line out
HYPER TOP 15A
in
level 1 level 2
LINE
MIC
high low level
010 010 -10 +10 -10 +10 010
on
limit
aux in
AC INPUT
AC 230V 50HZ
T2.0AL/250V
Power
ON
OFF
signal flow
mic/line in linein master
mic in line in stereo
line in line out
HYPER TOP 15A
in
level 1 level 2
LINE
MIC
high low level
010 010 -10 +10 -10 +10 010
on
limit
aux in
AC INPUT
AC 230V 50HZ
T2.0AL/250V
Right OutputLeft Output
MIXER
HYPER TOP
Speaker
HYPER TOP
Speaker
LINE OUT
LINE OUTLINE IN
LINE OUT
HYPER TOP
Speaker
HYPER TOP
Speaker
HYPER TOP
Speaker
HYPER TOP
Speaker
LINE OUTLINE INLINE IN LINE IN
LINE IN LINE IN
Daisy-chaining
HYPER TOP Speakers

15
ENGLISH
Hyper TOP series User manual
5.3.Bi-Amping with HYPER BASS Active Subs
Right OutLeft Out
MIXER
HYPER TOP
Speaker
HYPER TOP BASS
Active Subwoofer
(plays low-frequencies)
HYPER TOP
Speaker
HYPER TOP BASS
Active Subwoofer
(plays low-frequencies)
Left & Right
full-range outputs
Left full-range
input
Left hi-pass
output
Right full-range
input
Right hi-pass
output
Line balanced input
SOUNDSATION
SUB ST100-M20
Speaker Pole
SOUNDSATION
SUB ST100-M20
Speaker Pole
Line balanced input
6. INSTALLATION
Read these instructions carefully before installing and using the product.
fWhen the speaker is installed in a wall, check that the wall structure is reliable and
that the speaker is rmly attached.
fDo not install speakers in ne wood or soft wall material because the screws can get
loose, causing the crash or breakdown of the speakers and personal injury. Do not
use nails, adhesives or other unauthorized devices. Long-term use and vibrations
may cause it to fall easily.

16
ENGLISH
Hyper TOP series User manual
6.1. Wall-Mount Brackets for HYPER TOP 6-8-10A
a
b
c
HYPER TOP 6-8-10A loudspeakers can be xed to the wall in a horizontal or vertical
position by using the specic brackets indicated in the table listed at section”1.1. Acces-
sories” on page 5.
HYPER TOP 6A WALL-MOUNT BRACKET
Ø=13mm
196mm
403mm
45mm
66mm
76,5mm
76,5
mm
250mm
75mm
35mm
Ø=35mm
30°
15°
0°
-15°
-30°
Ø=13mm
109mm
35mm
Ø=35mm
265mm
520mm
45mm
74mm
110mm
110mm
300
mm
HYPER TOP 8A WALL-MOUNT BRACKET
40°
25°
10°
-5°
-20°

17
ENGLISH
Hyper TOP series User manual
85mm
35mm
Ø=35mm
Ø=13mm
280mm
556mm
79mm
104mm
103
mm
103
mm
175
mm
175
mm
HYPER TOP 10A WALL-MOUNT BRACKET
40°
26.6°
13.3°
0°
-40°
-26.6°
-13.3°
As you can see by checking the drawings above, these brackets allow various angles
of inclination according to each speaker model. The set consists of a C-bracket (a), a
cylinder (b) to be inserted into the hole for pole on the bottom of the speaker, and
three screws (c) for xing the parts. Follow the steps below for correct installation of the
bracket and speaker.
1. Draw marks on the wall corresponding to the two or three holes on the C-bracket,
and drill the wall using proper tools for the type of wall.
2. Secure the C-bracket to the wall using wall plugs and screws of adequate size to
support the weight of the speaker.
3. Remove the rubber caps (4a, 4b) located on the top and bottom of the speaker.
4a 4b
4. Insert the cylinder into the 36mm hole on the bottom of the speaker.

18
ENGLISH
Hyper TOP series User manual
5
5. Place the speaker into the C-bracket and lock with 6a, 6b, 6c screws.
6a
6b
6c
6. Adjust the position of 6c screw according to the 5 or 7 holes on the lower part of
the bracket, and move the speaker so that the selected hole corresponds to the
thread on the cylinder. This way you can adjust the inclination of the speaker.
Model Angles
HYPER TOP 6A 30°, 15°, 0°, -15°, -30°
HYPER TOP 8A 40°, 25°, 10°, -5°, -20°
HYPER TOP 10A 40°, 26.6°, 13.3°, 0°, -13.3°, -26.6°, -40°
6.2.Wall-Mount Speaker Stand
120mm
350mm
(max)
Max Load: 50kg
Ø=35mm
120mm
104mm
160mm
180mm
Ø=8mm
230mm
(max)

19
ENGLISH
Hyper TOP series User manual
All HYPER TOP Active series loudspeakers can be xed to walls in vertical position by
using the SOUNDSATION WSS-08 wall-mount speaker stand.
This accessory (optional) uses the 36mm pole hole on the bottom of the HYPER speak-
ers and allows a horizontal inclination of +/- 90 °, and 3-position vertical inclination at 0
°, -19 °, -39 °. Maximum load is 50kg.
6.3.Hanging with Eye-bolts
HYPER TOP Active speakers come with four M8 xing
points (one on each side) for suspended use.
Remove the rubber plugs that normally cover these
holes, and use high-quality safety wires (like the ones
listed below). Hang the speaker to stable structures, and
bes ure they can bear at least 10 times the weight of the
speaker.
SKU Description
E519E LW3-76A Safety cable 3*76mm with hook
E520E LW4-76A Safety cable 4*76mm with hook
E521E LW5-100A Safety cable 5*100mm with hook
For safety reasons, do not place one loudspeaker on top of another without proper
fastening systems. If you use the loudspeakers outdoors avoid places that are exposed
to bad weather or saltiness.
WARNING: Never use the handles to hang the speaker!
HYPER TOP Series speakers, in addition to the wall-mount xing and the hanging with
eye-bolts described in the previous sections, has the following mounting options:
fFloor or stacked use as normal speaker in vertical;
fStand-mount (tripod or pole through the Ø36mm hole on bottom);
fFloor use as stage monitor in horizontal with 30° o 45° angles).

20
ENGLISH
Hyper TOP series User manual
7. SPECIFICATIONS
HYPER TOP 6A HYPER TOP 8A
Speaker Type 2-Way Active Speaker Bi-Amped Active Speaker
Frequency Response [- 10dB] 67Hz - 19KHz 56Hz - 19KHz
Frequency Response [- 3dB] 72Hz - 19KHz 61Hz - 19KHz
Max SPL(PEAK) 108dB 111dB
Sensitivity 89dB 91dB
HF Type 1” Compression Driver (1” v.c.)
Horn Type Symmetric
Sensitivity(1W/1m) 101 dB
Directivity (HxV) 90° x 60°
Woofer Diameter 6” (1.2” v.c.) 8” (1.5” v.c.)
Crossover Frequency 3.5KHz 3.5KHz
Crossover Filter Slope 18dB / Octave 24dB / Octave
Amplier Class Class AB 2 x Class D
Rated Power 100W 240W
Peak Power 200W 480W
Input XLR + 1/4” Jack (Mic Line In), Stereo RCA + Stereo Mini jack (Line In)
Output XLR (Mix Out)
Mic/Line In Control Mic/Line switch, Volume
Line In Control Volume
LED Power On (Green), Clip (Red)
Common EQ High and Low
EQ High 2.5KHz-18KHz (+/- 12 dB)
EQ Low 42Hz-150Hz (+/- 12 dB)
Power Requirement 230Vac - 50 Hz
Power Consumption 60W 125W
Connector VDE
Fuse T1A - 250V T2A - 250V
Housing material PP
Grille material and thickness 1.0mm steel
Flyable 4 x M8 (1 each side)
Handles 1 on top
Pole Mount Standard D36 mm
Stage Monitor Use Angle 30°and 45°
Speaker Dimension (WxHxD) 217 x 367 x 209 mm 270 x 495 x 270 mm
Packing Dimension (WxHxD) 300 x 430 x 300 mm 350 x 570 x 350 mm
Net Weight 5.8 kg 7.2 kg
Gross Weight 6.8 kg 9.4 kg
NOTE: Our products are subject to a process of continual further development. Therefore modications to the tech-
nical features remain subject to change without further notice.
