Sound Sation PA-120 MK2 User manual

2
Dear customer,
first of all thanks for purchasing a SOUNDSATION® product. Our mission is to satisfy all the
possible needs of musical instrument and professional audio users offering a wide range of
products using the latest technologies for a reasonable price.
We hope you will be satisfied with this item and, if you want to collaborate, we are looking
for a feedback from you about the operation of the product and for possible
improvements to introduce in the next future. Go to our website
www.soundsationmusic.com and send an e-mail with your opinion, this will help us to build
instruments ever closer to customer’s real requirements.
One last thing: read this manual before using the instrument, an incorrect operation can
cause damages to you and to the unit. Take care!
The SOUNDSATION Team

3
UNBOXING
When you’ll open the box you will find the following items:
-1 PA-120 Mk2 Active Mixer
-2 Passive Speakers
-1 Power Cord
-2 Cables to connect the mixer to the speakers
-1 Dynamic Microphone with cable
-User Manual
The packaging bag is not a toy! Keep out of reach of children!!!
Keep in a safe place the original packaging material for future use.
SOUNDSATION can supply a wide range of quality accessories that you can use with the PA-
120 MK2 system like Cables, Microphones, Stands, Headphones etc.
All the products from our catalogue has been long tested with this device so we
recommend to use Genuine SOUNDSATION Accessories and Spare Parts.
Ask your SOUNDSATION dealer for any accessories you could need to ensure best
performance of the product.
ACCESSORIES

4
-
If any foreign objects enter the instrument, please contact your dealer or an authorized
SOUNDSATION center.
The serial number, electrical features and international standards are printed in the back
panel of the Active Mixer.
In case of problems remember to give the serial number to the responsible of the technical
assistance.
GENERAL WARNINGS
To prevent possible damages read the following list of actions:
- Do not place the instrument in wet or dirty environments.
- Do not remove the protective coverings.
-Do not cover any of the instrument’s ventilation holes.
-Air must circulate freely around the instrument.
-Do not set the instrument on a surface with excessive vibration.
- Do not expose the instrument to electro-magnetic interference.
-Do not expose the instrument to heat, cold, wet or dust.
-Do not leave the instrument in direct sunlight.
-Do not expose the instrument to electrostatic forces.
- Do not place items with flames, such as candles or lighters, on the
instrument.
-Do not place the instrument on anything containing water or other
fluids.

5
The PA-120 MK2 system is designed to be a powerful resource for live and educational
purpose. The friendly user interface is one of the best features of this product and this
allow you to configure your sound device in a fast and easy way.
The 6 Channel Active Mixer let you plug all the microphones or instrument you need for
the entertainment thanks to the XLR inputs, the RCA and the mini-jack interface on Ch5/6
that allows you to plug a computer (Win or Mac), a smartphone or a portable MP3 player.
To increase the quality and get a great response the Mixer features Dual Band EQ on each
Channel and a Trial Band EQ on the Master Section. This helps to improve the Sound
Quality as well as removing some possible disturb on the input signal.
To reach the best performance PA-120 MK2 is equipped with a Reverb+Delay 24BIT DSP FX
to add to your MIC inputs choosing the amount for each Channel with the related knob
integrated in every Channel Strip. In the FX section you can adjust the General Level, the
Time and the Repeat of the effect
To let the PA-120 MK2 be an advanced Multimedia device SOUNDSATION introduced in this
system the USB input to plug an USB Mass Storage as well as an SD Slot Card allowing you
to reproduce all your music tracks in the best way.
The bundle is completed by a Dynamic Microphone supplied with is own cable.
OVERVIEW

6
FRONT VIEW
BACK VIEW
POWER AND SPEAKERS CONNECTION
MIXER

7
Channel Strip
1- Use this XLR input to connect a Microphone. The Input Impedance is 2KOhm.
2- Use this Jack input to connect a Guitar, a Keyboard, a Drum Machine or any other Jack
based source.
3- This Stereo Input can be used to connect an Educational keyboard, a CD input or any
4- These controls allow to adjust the Equalization of each Channel:
LO adjust Bass frequencies +/- 15 dB with 80Hz cut point
HI adjust High Frequencies +/- 15 dB with 12KHz cut point
5- The VOLUME knob adjust the level of each channel to send to the Master Out
6- This knob regulates the amount of the FX for each Channel

8
FX SECTION
PA-120 mk2 is equipped with a Genuine 24 bit FX DSP featuring a Delay/Reverb
effect useful to add more emphasis to the human voices.
These 3 knobs allow to adjust:
LEVEL - the total amount of the FX to send to the Master Section
TIME - the interval between 2 delays
REPEAT - the rate of the delays
EQ SECTION
Each channel has got his own Equalization but, in order to improve the quality
of the sound, there is also a general Equalization that helps to define the final
mix result.
The 3 knobs adjust:
-LO adjust Bass frequencies +/- 15 dB with 80Hz cut point
-MID adjust Middle frequencies +/- 15dB with 3 KHz cut point
-HI adjust High Frequencies +/- 15 dB with 12KHz cut point

9
LINE IN, MONITOR OUT & RCA
1 - This input is useful to connect a stereo line source
like MP3 player, a computer or a smartphone with a
3,5mm jack.
2 -This stereo output (balanced) is useful to connect
to the mixer a couple of active speakers or a stage
monitor. The signal is a copy of the Master out.
3 - This RCA input accepts a stereo line source like a
CD/DVD player or a TAPE recorder. The level of this
input can be adjusted with the related control placed
next to the Master Knob.
4 –The REC OUT is useful to send a stereo line signal
to a recorder via RCA connectors.
MASTER SECTION
These 2 knobs controls respectively:
-the amount of CD/Tape input signal to send to the
Master Out
-the general Volume of the Mixer (what you will hear
trough the speakers)

10
DIGITAL PLAYER
1 Play/Pause - Press this button to play the chosen song. Press it again to momentarily
interrupt the playing. Press a third time to continue the reading of the song.
2 Stop - Press this button to end the song
3 Volume + -Use this button to increase the Volume
4 Volume - -Use this button to disincrease the Volume
5 Next Song -Press this button once to go to the next song.
6 Prev Song -Press this button once to go to the previous song.
7 Repeat -Press this button once to play the current song repeatedly
8 EQ -Use this button to select different Equalization preset (Normal, Jazz,Rock,Pop,Classic)
9 USB/SD - This button let you choose between USB or SD card source

11
The 2 passive speakers are 150W power (max) and features 1 x 10” Woofer and
1 x Piezo Tweeter with a Frequency Response of 50Hz to 18 KHz. Under each
wood case there is a typical 35mm Fixing hole plate to let you setup these units with
a Speaker Stands. (we strongly recommend to use genuine SOUNDSATION stands
to prevent possible damages to the items).
BACK PANEL
In the back panel of each speaker you find this metal plate
Use the INPUT to connect the unit to the Mixer
The LINK output can be used to connect another passive speaker in chain.
SPEAKERS

12
2 x 100 W Active Mixer
2 x Bass Reflex 150 W Passive Speakers
6 Audio Channel Inputs (4 x Mono /Line –1 x Stereo Line)
Stereo Monitor Out
24 BIT DSP FX with Adjustable Level, Time and Repeat
USB/SSD Inputs (max 8Gb)
Dual Band EQ (Bass- Treble) for each Channel
Trial Band EQ (Bass- Mid- Treble) for Master Section
35mm Mounting Hole
1 x 10” LF Speaker
1 x Piezo Tweeter
Frequency Range: 65Hz to 20KHz
AC Input 230 V –50Hz - Fuse T2A 250V
SPECIFICATION

13
All SOUNDSATION products feature a limited two-year warranty. This two-year warranty is
specific to the date of purchase as shown on your purchase receipt.
The following cases/components are not covered from the above warranty :
-Any accessories supplied with the product
-Improper use
-Fault due to wear and tear
-Any modification of the product effected by the user or a third party
SOUNDSATION shall satisfy the warranty obligations by remedying any material or
manufacturing faults free of charge at SOUNDSATION’s discretion either by repair or by
exchanging individual parts or the entire appliance. Any defective parts removed from a
product during the course of a warranty claim shall become the property of SOUNDSATION
While under warranty period, defective products may be returned to your local
SOUNDSATION dealer together with original proof of purchase. To avoid any damages in
transit, please use the original packaging if available. Alternatively you can send the product
to SOUNDSATION SERVICE CENTER –Via Enzo Ferrari , 10 –62017 Porto Recanati - Italy
. In order to send a product to service center you need an RMA number. Shipping charges
have to be covered by the owner of the product.
For further information please visit www.soundsationmusic.com
WARRANTY & SERVICE

14
WARNING
PLEASE READ CAREFULLY –EU and EEA (Norway, Iceland and Liechtenstein) only
This symbol indicates that this product is not to be disposed of with your household waste, according to the WEEE
Directive ( 2202/96/EC) and your national law.
This product should be handed over to a designated collection point, e.g., on an authorized one-for-one basis when
you buy a new similar product or to an authorized collection site for recycling waste electrical and electronic
equipment (WEEE) .
Improper handling of this type of waste could have a possible negative impact on the environment and human health
due to potentially hazardous substances that are generally associated with EEE. At the same time , your cooperation
in the correct disposal of this product will contribute to the effective usage of natural resources.
For more information about where you can drop off your waste equipment for recycling , please contact your local city
office , waste authority , approved WEEE scheme or your household waste disposal service.
Contents and images shown on this manual can be changed without any notice. Please visit our website
www.soundsationmusic.com to check latest version.
DESIGNED IN ITALY BY SOUNDSATION®
PA-120 MK2 USER MANUAL REV. 1.01
All the Trademarks are property of their respective owners
SOUNDSATION® is a registered trademark of
FRENEXPORT SPA –Via Enzo Ferrari, 10 - 62017 Porto Recanati –Italy
© SOUNDSATION 2013 –All rights reserved –All total or partial reproduction of this manual by any other company or
person without express authorization of Soundsation is strictly forbidden.
